DIGITAL CAMERA
Instruction
Manual
Getting to know your
camera better
Quick Start Guide
Get started using your
camera right away.
Button operations
Menu operations
Printing pictures
Using OLYMPUS Master
(Thank you for purchasing an Olympus digital camera. Before you start to use your new camera, please
read these instructions carefully to enjoy optimum performance and a longer service life. Keep this manual
in a safe place for future reference.
(We recommend that you take test shots to get accustomed to your camera before taking important
photographs.
(In the interest of continually improving products, Olympus reserves the right to update or modify
information contained in this manual.
Appendix
FE-280/X-820/
C-520
d4348_33_e_0000_7.book Page 1 Thursday, June 21, 2007 7:24 PM

2 EN
Contents
Test out the functions of the camera
buttons by following along with the
illustrations.
Learn how to print pictures you have
taken.
Learn how to transfer and save
pictures to a computer.
Find out more about camera
operations and how to take better
pictures.
Read about convenient functions and
safety precautions on how to use your
camera more effectively.
Learn about the menus that control the
functions and settings for basic
operation.
Button operations
Menu operations
Printing pictures
Getting to know your camera
better
Appendix
P. 11
P. 17
P. 29
P. 42
P. 50
Using OLYMPUS Master P. 35
Quick Start Guide P. 3
d4348_33_e_0000_7.book Page 2 Thursday, June 21, 2007 7:24 PM

EN 3
Quick Start Guide
Gather these items (box contents)
(Pull the strap tight so that it does not come loose.
Digital Camera Strap Lithium Ion Battery
(LI-42B)
Battery Charger
(LI-40C)
USB Cable AV Cable OLYMPUS Master 2
CD-ROM
Items not shown: Instruction Manual (this manual) and the Warranty Card. Contents may vary
depending on purchase location.
Attach the strap
Quick Start Guide
d4348_33_e_0000_7.book Page 3 Thursday, June 21, 2007 7:24 PM

4 EN
Quick Start Guide
Prepare the camera
a. Charge the battery.
(Battery comes partially charged.
b. Insert the battery and an xD-Picture Card (optional).
1
Red light on: Charging
Light off: Charging complete
(Charging time: Approx. 5 hours)
AC Wall
Outlet
Power Cable
Battery
Charger
Lithium Ion Battery
3
W
2Charging Indicator
3
(To remove the battery, press the battery
lock knob in the direction of the arrow.
1
2
(Insert the battery by
putting in the marked
side first, with the
marks toward the battery
lock knob.
If you insert the battery
incorrectly, you will not be able to
remove it. Do not use force.
Contact authorized distributors/
service centers.
Damage to the battery exterior
(scratches, etc.) may produce
heat or an explosion.
Battery lock knob
d4348_33_e_0000_7.book Page 4 Thursday, June 21, 2007 7:24 PM

EN 5
Prepare the camera
Quick Start Guide
(With this camera, you can take pictures without inserting the optional xD-
Picture Card™ (hereinafter referred to as “the card”). If you shoot pictures with
this camera without using an xD-Picture Card, the pictures will be recorded in
the internal memory. For details on the card, please refer to “The card” (P. 53).
56
Notch
Contact area
(Orient the card as shown, and insert the
card straight in until it clicks into place.
(To remove the card, push the card all the
way in, release slowly, grasp the card,
then remove.
4
d4348_33_e_0000_7.book Page 5 Thursday, June 21, 2007 7:24 PM

6 EN
Quick Start Guide
Turn the camera on
This explains how to turn on the camera in shooting mode.
a. Set the mode dial to h.
Still picture shooting modes
b. Press the obutton.
(To turn off the camera, press the obutton once again.
hThe camera determines the optimum settings for the shooting conditions automatically.
PThe camera automatically sets the optimum aperture value and shutter speed.
hThis function reduces the blur incurred by a moving subject, or camera shake when taking
pictures.
BSuitable for taking pictures of people.
ESuitable for taking pictures of a landscape.
fSelect from 15 available scene modes according to the shooting conditions.
RUse the shooting guide displayed on the screen to shoot pictures according to the
situation.
When shooting movies
When shooting still pictures
obutton
MENU
TIME
TIME
DMY
----
----
.--.-- --:--
.--.-- --:--
CANCEL
Y/M/
Y / M /
D
(This screen is
displayed if the date
and time are not set.
O
N
YX
Hint
The directions of the arrow pad is indicated with ONXY in the supplied
instruction manual.
d4348_33_e_0000_7.book Page 6 Thursday, June 21, 2007 7:24 PM

EN 7
Quick Start Guide
Set the date and time
a. Press the OF/<and NYbuttons to select [Y].
• The first two digits of the year are fixed.
b. Press the Y#button.
c. Press the OF/<and NYbuttons to
select [M].
About the date and time setting screen
MENU
TIME
TIME
DMY
----
----
.--.-- --:--
.--.-- --:--
CANCEL
Y/M/
Y / M /
D
Y-M-D
Cancels the setting
Hour
Date formats (Y-M-D, M-D-Y, D-M-Y)
Minute
OF/<button
NYbutton
MENU
2007
2007
.--.-- --:--
.--.-- --:--
TIME
TIME
DMY
CANCEL
Y/M/
Y / M /
D
Y#button
MENU
2007
2007
. 12
12
.-- --:--
.-- --:--
TIME
TIME
DMY
CANCEL
Y/M/
Y / M /
D
d4348_33_e_0000_7.book Page 7 Thursday, June 21, 2007 7:24 PM

8 EN
Set the date and time
Quick Start Guide
d. Press the Y#button.
e. Press the OF/<and NYbuttons to
select [D].
f. Press the Y#button.
g. Press the OF/<and NYbuttons to
select the hours and minutes.
• The time is displayed in the 24-hour format.
h. Press the Y#button.
i. Press the OF/<and NYbuttons to
select [Y/M/D].
j. After all settings have been set, press .
• For a more accurate setting, press when the time signal hits 00 seconds.
MENU
2007
2007
. 12
12
. 10
10
--:--
--:--
TIME
TIME
DMY
CANCEL
Y/M/
Y / M /
D
MENU
OK
2007
2007
. 12
12
. 10
10
12
12
: 30
30
TIME
TIME
DMY
CANCEL
Y/M/
Y / M /
D
SET
MENU
OK
2007
2007
. 12
12
. 10
10
12
12
: 30
30
SET
TIME
TIME
DMY
Y/M/
Y / M /
D
CANCEL
button [IN
IN
]
44
[ ]
HQ
HQ
3264
3264
×2448
2448
d4348_33_e_0000_7.book Page 8 Thursday, June 21, 2007 7:24 PM

EN 9
Quick Start Guide
Take a picture
a. Hold the camera.
c. Shoot.
Horizontal grip Vertical grip
b. Focus.
Shutter Button
(Press Halfway)
HQ
HQ
3264
3264
×2448
2448
[IN
IN
]
44
[ ]
1/1000
1/1000
F3.1
F3.1
When the focus and exposure are
locked, the green lamp lights up, and the
shutter speed and aperture value are
displayed.
Place this mark over
your subject.
The number of pictures
that can be taken is
displayed.
(Press
Completely)
Shutter Button
The card access lamp blinks.
d4348_33_e_0000_7.book Page 9 Thursday, June 21, 2007 7:24 PM

10 EN
Quick Start Guide
Review your pictures
a. Press the qbutton.
a. Press the X&and Y#buttons to display the picture you want
to erase.
b. Press the /Sbutton.
c. Press the OF/<button, select [YES], and press .
HQ
HQ
[IN
IN
]
3264
3264
×2448
2448
F3.1 1/1000 0.0
F3.1 1/1000 0.0
’07.12.10 12:30
07.12.10 12:30
ISO 1600
ISO 1600
4
100-0004
100-0004
Arrow pad
Displays the next image
Displays the previous image
qbutton
Erase pictures
/Sbutton
OK
MENU
[IN]
YES
NO
[IN]
SET
BACK
ERASE
OF/<button
button
OK
MENU
YES
NO
[IN]
SET
BACK
ERASE
d4348_33_e_0000_7.book Page 10 Thursday, June 21, 2007 7:24 PM

EN 11
Button operations
Button operations
Shooting still pictures
Set the mode dial to a setting other than n, and lightly press the shutter button (halfway). When the focus
and exposure are locked, the green lamp lights up (focus lock), and the shutter speed and aperture value are
displayed (only when the mode dial is set to h, P, h). Now press the shutter button all the way
(completely) to shoot a picture.
Locking the focus and then composing the shot (focus
lock)
Compose your picture with the focus locked, and then completely press
the shutter button to shoot a picture.
• When the green lamp blinks, the focus is not adjusted properly. Try
locking the focus again.
AF Lock - Locking the focus position
When the scene is kH, you can lock the focus position by pressing N.
Press Nagain to cancel the AF lock.
g“fShooting pictures by selecting a scene mode according to the
situation” (P. 12)
• AF lock is automatically canceled after one shot.
Recording movies
Set the mode dial to n, and lightly press the shutter button to lock the focus, and then press the shutter button
completely to start recording. Press the shutter button again to stop recording.
obutton Turning the camera on and off
Power on: Camera turns on in shooting mode.
• Lens extends
• Monitor turns on
Shutter button Shooting pictures/movies
[IN
IN
]
44
[ ]
HQ
HQ
3264
3264
×2448
2448
3
Shooting mode
12
4
bc
5
8
9
0
a
6
7
Self-timer
Flash mode
Macro mode
d
1
2
HQ
HQ
3264
3264
×2448
2448
[IN
IN
]
44
[ ]
1/1000
1/1000
F3.1
F3.1
Green lamp
HQ
HQ
3264
3264
×2448
2448
[IN
IN
]
44
[ ]
kk
AF lock mark
d4348_33_e_0000_7.book Page 11 Thursday, June 21, 2007 7:24 PM

Button operations
12 EN
Shooting mode is selected.
This function is used to set the camera to turn on in shooting mode when Kis pressed with the camera off.
g“K/qTurning on the camera with the Kor qbutton” (P. 27)
The last picture taken is displayed.
• Press the arrow pad to view other pictures.
• Use the zoom lever to switch between close-up playback and index display.
• Press to hide the information displayed on the screen for 3 seconds during single-frame playback.
This function is used to set the camera to turn on in playback mode when qis pressed with the camera off.
g“K/qTurning on the camera with the Kor qbutton” (P. 27)
gMovie playback “MOVIE PLAY Playing back movies” (P. 22)
Set the mode dial to the desired shooting mode.
The camera determines the optimum settings for shooting pictures.
[CAMERA MENU] settings such as [WB], [ISO] cannot be changed.
The camera automatically sets the optimum aperture value and shutter speed for the brightness of the subject.
[CAMERA MENU] settings such as [WB], [ISO] can be changed.
This function reduces the blur incurred by a moving subject, or camera shake when taking pictures.
Use PORTRAIT and LANDSCAPE to shoot pictures with the optimal settings.
Select from 15 available scene modes, according to the shooting conditions.
Press to set.
• The scene selection screen displays sample images and the shooting
mode to best suit the situation.
• To switch to a different scene mode after a scene mode has been
selected, press mto select [SCENE] from the top menu and display
the scene selection screen.
• By switching to another scene, most settings will be changed to the
default settings of each scene.
*1 Use an underwater housing in this setting.
*2 The focus distance is fixed at approximately 5 m (16.4ft.).
*3 The image that has just been taken does not show up on the monitor
while recording.
Kbutton (Shooting) Selecting shooting mode/Turning the camera on
qbutton (Playback) Selecting playback mode/Turning the camera on
Mode dial Switching shooting modes
hShooting pictures with automatic settings
PSet the optimum aperture value and shutter speed
hShooting pictures using digital image stabilization
BEShooting pictures according to the situation
fShooting pictures by selecting a scene mode according to the
situation
/NIGHT+PORTRAIT /jSPORT /NINDOOR /WCANDLE /RSELF PORTRAIT
/SSUNSET /XFIREWORKS /PBEHIND GLASS /VCUISINE
/dDOCUMENTS /iAUCTION /SSMILE SHOT /kUNDER WATER WIDE1*1
/lUNDER WATER WIDE2*1*2*3 /HUNDER WATER MACRO*1
3
4
5
M
C
N
W
R
OK
MENU
1 NIGHT+PORTRAIT
SETBACK
d4348_33_e_0000_7.book Page 12 Thursday, June 21, 2007 7:24 PM

Button operations
EN 13
[SSMILE SHOT]
• When the camera detects a smiling face in shooting standby mode, 3 frames are taken in high speed
sequential shooting mode automatically. You can also shoot pictures manually by pressing the shutter
button in this mode.
• There may be cases in which the camera cannot detect a smiling face.
• When [SMILE SHOT] is selected, the self-timer lamp lights. Shooting is not available while the self-timer
lamp is blinking.
Follow the shooting guide displayed on the screen to set the target items.
• Press mto display the shooting guide again.
• To change the setting without using the shooting guide, set the shooting
mode to another one.
• The content set using the shooting guide will change to the default
setting by pressing mor changing the mode using the mode dial.
Shoot pictures by comparing previews of different effects
Select one of the [1 Shoot w/ effects preview.] options from the
[SHOOTING GUIDE] menu to preview a live, multi-frame window on the
monitor showing four different levels of the selected shooting effect. You
can use the four preview frames to compare and select your desired
setting/effect.
• Use the arrow pad to select the frame with the settings you want, and
press . The camera automatically switches to shooting mode and
allows you to shoot with the selected effect.
Audio is recorded with the movie.
• During audio recording, only the digital zoom can be used. To record the movie with the optical zoom, set
[R] to [OFF].
g“R(movies) Recording movies with or without sound” (P. 21)
Use the arrow pad to select scenes, playback picture, and the items on the menus.
This button is used to confirm your selection.
RFollow the shooting guide for setting
nRecording movies
Arrow pad (ONXY)
button
OK
SET
4
Shooting into backlight.
5
Brightening subject.
Shoot w/ effects preview.
Set particular lighting.
Blurring background.
3
2
1SHOOTING GUIDE 1/3
+0.3
0.3
+0.7
0.7
+1.0
1.0
0.0
0.0
0.0 +0.3
+0.7 +1.0
Exposure effects.Exposure effects.
Exposure effects.
Exposure effects.
Use XY to change
the display.
When [Exposure
effects.] is selected
A
00:36
00:36
00:36
This lights red during movie recording.
The remaining recording time is displayed. When the
remaining recording time reaches 0, recording stops.
6
7
d4348_33_e_0000_7.book Page 13 Thursday, June 21, 2007 7:24 PM

Button operations
14 EN
Shooting mode: Changing picture brightness
Press OF/<in shooting mode, select a picture in your desired
brightness with XY, and press .
• Adjustable from -2.0 EV to +2.0 EV
Playback mode: Printing pictures
Display a picture to print out in playback mode, connect the camera to the printer, and then press OF/<to
print the picture.
g“Direct printing (PictBridge)” (P. 29)
Press X&in shooting mode to select the macro mode. Press for setting.
Press NYin shooting mode to select on or off for the self-timer.
Press for setting.
• After setting the self-timer, press the shutter button completely. Then the self-timer lamp lights for
approximately 10 seconds, blinks for approximately 2 seconds, and the shutter is released.
• To cancel the self-timer, press NY.
• Self-timer shooting is automatically canceled after one shot.
Press Y#in shooting mode to select the flash mode.
Press for setting.
Displays the top menu.
OF/<button Changing picture brightness (Exposure compensation)/Printing pictures
X&button Shooting pictures close to the subject
OFF Macro off Cancels macro mode.
&Macro on This mode lets you shoot from as close as 10 cm/3.9 in. (when
the zoom is set for the zoom-out angle) and as close as 60 cm/
23.6 in. (when the zoom is set for the zoom-in angle) to your
subject.
%Super macro This mode lets you shoot from as close as 5 cm/2.0 in. to your
subject.
The zoom position is fixed automatically and cannot be changed.
NYbutton Self-timer shooting
OFF Self-timer off Cancel the self-timer.
YSelf-timer on Set the self-timer.
Y#button Flash shooting
AUTO Flash auto The flash fires automatically in low light or backlight conditions.
!Redeye This emits pre-flashes for red-eye reduction.
#Fill-in The flash fires regardless of the available light.
$Flash off The flash does not fire.
mbutton Displaying the top menu
8
F
+
0.3
0.3
+
0.7
0.7
+
1.0
1.0
0.0
0.0
0.0
+
0.3
+
0.7
+
1.0
9
0
a
b
d4348_33_e_0000_7.book Page 14 Thursday, June 21, 2007 7:24 PM

Button operations
EN 15
Press in shooting mode. The monitor becomes brighter. If there is no operation for 10 seconds, the
previous brightness resumes.
In playback mode, select the picture you want to erase, and press S.
• Once erased, pictures cannot be restored. Check each picture before erasing to avoid accidentally erasing
pictures you want to keep.
g“0Protecting pictures” (P. 25)
Shooting mode: Zooming in on your subject
Optical zoom: 3x
Digital zoom: 4x (optical zoom × digital zoom: Max. 12x)
/Sbutton Increasing the brightness of the monitor (Backlight boost)/
Erasing pictures
Increasing the brightness of the monitor
SErasing pictures
Zoom lever Zooming while shooting/Close-up playback
c
d
[IN
IN
]
44
[ ]
HQ
HQ
3264
3264
×2448
2448
HQ
HQ
3264
3264
×2448
2448
[IN
IN
]
44
[ ]
Zoom out:
Turn the zoom
lever to the W-
side.
Zoom in:
Turn the zoom
lever to the T-side.
The white area is the optical zoom area. The red area is the
digital zoom area. When the slider enters the red area, the
digital zoom activates and the image is further enlarged.
Zoom bar
d4348_33_e_0000_7.book Page 15 Thursday, June 21, 2007 7:24 PM

Button operations
16 EN
Playback mode: Switching the picture display
1 2
4
3
[IN
IN
]
3264
3264
×2448
2448
0.0
0.0
HQ
HQ
[IN
IN
]
F3.1 1/1000
F3.1 1/1000
’07.12.10 12:30
07.12.10 12:30
ISO 1600
ISO 1600
4
100-0004
100-0004
1 2 3
4 5 6
7 8 9
[IN
IN
]
[IN
IN
]
[IN
IN
]
Close-up playback
• Turn and hold the zoom lever to
the T-side to incrementally zoom
in (up to 10 times the original
size), and to the W-side to zoom
out.
• Press the arrow pad during close-
up playback to scroll the picture in
the indicated direction.
• When returning to the single-
frame playback, press .
Index display
• Use the arrow pad to select a
picture for playback, and press
to play back the single-
frame of the picture selected.
Single-frame playback
• Use the arrow pad to browse pictures.
W
TW
W
T
W
T
W
T
T
d4348_33_e_0000_7.book Page 16 Thursday, June 21, 2007 7:24 PM

EN 17
Menu operations
Menu operations
Press mto display the top menu on the monitor.
• The contents displayed on the top menu differ according to the mode.
• Select [CAMERA MENU], [PLAYBACK MENU], [EDIT], [ERASE], or [SETUP], and press . The screen
for selecting the menu item is then displayed.
• When the mode dial is set to Rand the settings are made by following the shooting guide, press m
to display the shooting guide screen.
During menu operations, the buttons and their respective functions are displayed at the bottom of the screen.
Follow these guides to navigate the menus.
About the menus
Operation guide
mbutton

Arrow pad (ONXY)
Kbutton (Shooting mode)
qbutton (Playback mode)
OK
MENU
RESET
SILENT
MODE
SET
EXIT
RESET
SILENT
MODE
CAMERA
CAMERA
MENU
MENU
QUALITY
QUALITY
SCENE
SCENE
SETUP
SETUPSETUP
OK
MENU
1
3
2
MEMORY FORMAT
NO
PIXEL MAPPING
ENGLISH
BACKUP
SETUP
SET
BACK
Top menu
(Still picture shooting mode)
SETUP menu items
OK
MENU
RESET
SILENT
MODE
SET
EXIT
RESET
SILENT
MODE
CAMERA
CAMERA
MENU
MENU
QUALITY
QUALITY
SCENE
SCENE
SETUP
SETUPSETUP
Operation
guide m
button 
Arrow pad
(ONXY)
: Moves back one menu.
: Exits the menu.
: Press the arrow pad (ONXY) to select an item.
: Sets the selected item.
MENU
BACK
MENU
EXIT
OK
SET
d4348_33_e_0000_7.book Page 17 Thursday, June 21, 2007 7:24 PM

Menu operations
18 EN
This explains how to use the menus with the [8] (warning sound) setting as an example.
1Set the mode dial to a setting other than R.
2Press mto display the top menu. Press Yto
select [SETUP], and press .
•[8] is on a menu in [SETUP].
3Press ON to select [8], and press .
• Unavailable settings cannot be selected.
• Press Xon this screen to move the cursor to the page display.
Press ON to change the page. To return to the item selection
screen, press Yor .
4Press ON to select [OFF], [LOW] or [HIGH], and
press .
• The menu item is set and the previous menu is displayed.
Press mrepeatedly to exit the menu.
• To cancel any changes and continue operating the menus,
press mwithout pressing .
Using the menus
Shooting mode menu K
OK
MENU
RESET
SILENT
MODE
SET
EXIT
RESET
SILENT
MODE
CAMERA
CAMERA
MENU
MENU
QUALITY
QUALITY
SCENE
SCENE
SETUP
SETUPSETUP
OK
MENU
1
3
2
MEMORY FORMAT
NO
PIXEL MAPPING
ENGLISH
BACKUP
SETUP
SET
BACK
OK
MENU
1
2
3
SETUP
BACK
SET
LOW
LOW
NORMAL
LOW
BEEP
SHUTTER SOUND
VOLUME
The selected item is displayed in a
different color.
Page display:
This mark is displayed when there are more
menu items on the next page.
OK
MENU
1
2
3
BEEP
SHUTTER SOUND
VOLUME
SETUP
SET
BACK
LOW
HIGH
OFF
WB
ISO
FINE ZOOM
R(still pictures)
R(movies)
PANORAMA*
AF MODE
* An Olympus xD-Picture Card is required.
OK
MENU
RESET
SILENT
MODE
SET
EXIT
SETUP
RESET
SILENT
MODE
SETUPSETUP
CAMERA
CAMERA
MENU
MENU
QUALITY
QUALITY
SCENE
SCENE
2
4
3
1
5
4CAMERA MENU
d4348_33_e_0000_7.book Page 18 Thursday, June 21, 2007 7:24 PM

Menu operations
EN 19
• Some functions are not available according to the selected mode.
g“Functions available in shooting modes and scenes” (P. 49)
g“SETUP menus” (P. 26)
• The factory default settings are displayed in gray ( ).
Still picture image quality and their applications
Movie image quality
Restore shooting functions back to default settings.
Functions for returning the settings to the original when the reset function is
executed
IMAGE QUALITY Changing the image quality
Image quality/Image size Compression Application
SHQ 3264 × 2448 Low
compression
• This is useful for printing large images on
full-size paper.
• This is useful for performing computer
image processing, such as contrast
adjustment and red-eye correction.
HQ 3264 × 2448 Standard
compression
SQ1 2048 × 1536 Standard
compression
• This is useful for A4 (11.7×8.5 in.)/
postcard-size prints.
• This is useful for computer editing such
as rotating or adding text to a picture.
SQ2 640 × 480 Standard
compression
• This is useful for sending as e-mail
attachments.
16:9 1920 × 1080 Standard
compression
• This is useful for expressing the
broadness of a subject such as
landscapes and for viewing pictures on a
wide-screen television.
• [PANORAMA] cannot be set.
Image quality/Image size
SHQ 640 × 480
HQ 320 × 240
SQ 160 × 120
RESET Changing the shooting functions back to default settings
Function Factory default setting Ref. Page
fMNIGHT+PORTRAIT P. 12
F0.0 P. 14
&OFF P. 14
YOFF P. 14
#AUTO P. 14
IMAGE QUALITY HQ P. 19
WB AUTO P. 20
ISO AUTO P. 20
FINE ZOOM OFF P. 20
1
2
NO /YES
d4348_33_e_0000_7.book Page 19 Thursday, June 21, 2007 7:24 PM

Menu operations
20 EN
The scene selection screen displays sample images and the shooting mode to best suit the situation. This can
be set only when the mode dial is set to f.
• By switching to another scene, most settings will be changed to the default settings of each scene.
g“fShooting pictures by selecting a scene mode according to the situation” (P. 12)
This function allows you to zoom up to approximately 15x by combining
the optical zoom and image cropping. There is no deterioration in the
image quality since data conversion (by increasing pixel resolution) is not
performed.
• The available magnification varies depending on the [IMAGE QUALITY]
setting.
• The available [IMAGE QUALITY] setting is [SQ1] or lower.
When activated [ON], the camera will record about 4 seconds of audio after
the picture is taken.
When recording, aim the camera microphone at the source of the sound
you want to record.
R(still pictures) OFF P. 20
R(movies) ON P. 21
AF MODE iESP P. 21
f(Scene) Shooting pictures by selecting a scene according to the situation
CAMERA MENU
WB................................................................................................. Adjusting the color of a picture
AUTO The white balance is adjusted automatically for natural color,
regardless of the light source.
5Sunny day For shooting under a clear sky.
3Cloudy day For shooting under a cloudy sky.
1Tungsten light For shooting under tungsten lighting.
wFluorescent
lamp 1
For shooting under daylight fluorescent lighting. (This type of lamp is
mainly used in homes.)
xFluorescent
lamp 2
For shooting under a neutral white fluorescent lamp. (This type of
lamp is mainly used in desk lamps.)
yFluorescent
lamp 3
For shooting under a white fluorescent lamp. (This type of lamp is
mainly used in offices.)
ISO......................................................................................................Changing the ISO sensitivity
AUTO Sensitivity is automatically adjusted according to the conditions of the
subject.
50/100/200/400/
800/1600
A low value lowers the sensitivity for daylight shooting of clear, sharp
pictures. The higher the value, the better the camera’s light sensitivity and
ability to shoot with a fast shutter speed and in low light conditions.
However, high sensitivity introduces noise into the resulting picture, which
may give it a grainy appearance.
FINE ZOOM .............................. Zooming in on your subject without reducing image quality
R(still pictures).......................................................................Recording sound with still pictures
Function Factory default setting Ref. Page
3
4
OFF /ON
OFF /ON
d4348_33_e_0000_7.book Page 20
