Blanco BMOS38X Installation guide

Instructions for the Use and Care and Installation of
BMOS38X
Built-In Microwave Oven

Table of contents
INFORMATION FOR THE USER
••Safety instructions _________________________________________ 4
••Care for the environment ____________________________________ 5
INSTALLING YOUR APPLIANCE
••Choice of location__________________________________________ 6
••Fitting ____________________________________________________ 6
••Electric connection_________________________________________ 7
DESCRIPTION OF YOUR APPLIANCE
••Introduction to your oven____________________________________ 9
••Accessories_______________________________________________ 10
••Introduction to the programmer ______________________________ 11
••Introduction to the selecting buttons __________________________ 11
••Introduction to microwave cooking modes _____________________ 12
USING YOUR APPLIANCE
••Using the programmer
ºHow to set the time_____________________________________ 13
ºHow to change the time _________________________________ 13
••Programmed cooking
ºMicro-wave cooking ____________________________________ 14
ºAutomatic micro-wave defrosting _________________________ 15
ºDefrosting guide _______________________________________ 16
ºKeep warm mediumpower, full power, simmer and low power__ 17
••Customising the cooking power ______________________________ 18
••How to record cooking programmes using the memory functions __ 19
••How to start a cooking programme using the memory function ____ 21
••Locking the controls________________________________________ 22
••Display stand-by mode ______________________________________ 23
CARING FOR AND CLEANING YOUR APPLIANCE
••Cleaning the outer surfaces__________________________________ 24
TROUBLESHOOTING _____________________________________________ 25
CONTACT INFORMATION AND WARRANTY _________________________ 26
2

3
Dear Customer,
Thank you for buying a BLANCO Microwave.
Before we continue telling you about this microwave, we cordially invite
you to become part of the Blanco family by subscribing online. Please
visit our website where you can easily subscribe and request such things
as ‘invitations to future cooking classes. Go to
www.meaappliances.com.au and fill in the subscription details.
You will find that the clean lines and modern look of your Blanco
microwave blends in perfectly with your kitchen décor. It is easy to use
and performs to a high standard.
Blanco also makes a range of products that will enhance your kitchen
such as oven cooktops, rangehoods, dishwashers, sinks and taps. There
are models to complement your new Blanco microwave.
Of course, we make every effort to ensure that our products meet all
your requirements, and our Customer Relations department is at your
disposal, to answer all your questions and to listen to all your
suggestions (see back cover of manual).
Please complete the warranty section of this manual and keep your
receipt as proof of purchase. Retain all documents relating to the
purchase of this product.
Blanco is commited to providing increasingly efficient products, that are
easy to use, respect the environment, and are attractive and reliable.
BLANCO

4
Information for the user
SAFETY INSTRUCTIONS
• Your appliance is designed for standard
household use for cooking, reheating and
defrosting foods. The manufacturer declines
any responsibility in the case of inappropriate
use.
• Before each use, ensure that any
receptacles and accessories are suitable for
use in your micro-wave oven (for example:
pyrex, porcelain, etc.)
• To avoid damaging your appliance, never
operate it while empty or without the
turntable.
• Do not interfere with the orifices on the
lock on the front of the appliance; this could
cause damage to your appliance that would
require a service call.
• Check the oven regularly when cooking or
heating food in disposable containers made
from plastic, paper or other flammable
materials to avoid the risk of fire.
• It is not recommended to use metallic
cookware, forks, spoons, knives or metal
staples or fasteners for defrosting bags.
However, occasionally you can defrost food
packaged in low-rise aluminium containers
(maximum 4cm) without the lid. However, the
reheating time will be slightly longer. In this
case, make sure that the container is placed
in the centre of the base of the oven; it must
never be placed less than 1 cm away the
metallic walls or the door of the appliance.
• For children, always:
- heat bottles without the teat, shake
the liquid and check its temperature on the
back on your hand before feeding the child.
- mix and check the temperature of
children’s food before eating in order to avoid
serious internal burns.
WWAARRNNIINNGG: Do not allow children to use the
micro-wave oven without supervision, unless
appropriate instructions have been given so
that the child can use the oven safely and
understands the dangers of incorrect
operation.
• It is recommended to cover food in most
cases; it will have more flavour and your
appliance will remain cleaner for longer.
However, before cooking or reheating liquids
in a bottle or sealed container, you must
remove the cap or lid to avoid the risk of
explosion.
• Never heat or cook eggs in the microwave
in their shells, on a dish or on a plate. They are
liable to explode even after the cooking has
finished and risk causing serious burns
and/or irreparable damage to your microwave
oven.
• Heating beverages in the micro-wave oven
can cause sudden and/or delayed splattering
of boiling liquid, so precautions must be
taken when handling their containers.
• In the case of small quantities (a sausage,
croissant, etc.) place a glass of water next to
the food.
• Excessive cooking times may dry out
foods and burn them. To avoid such
incidents, never use the same times
recommended for cooking in a traditional
oven.
• If you notice the appearance of smoke,
leave the door of the appliance shut, turn off
the power or disconnect the oven from the
power supply.
••
Warning
Keep this user guide with your appliance. If
the appliance is ever sold or transferred to
another person, ensure that the new owner
receives the user guide. Please become
familiar with these recommendations
before installing and using your oven. They
were written for your safety and the safety
of others.

5
CARE FOR THE ENVIRONMENT
••
— This appliance’s packing materials are recyclable. Recycle them and play a role in protecting
the environment by depositing them in municipal containers provided for this purpose.
— Your appliance also contains many recyclable materials. It is therefore marked with
this logo to indicate that used appliances must not be mixed with other waste.
Recycling of the appliances organised by your manufacturer will thus be undertaken
in optimum conditions, in accordance with European directive EC/2002/96 relating to
electrical and electronic equipment waste. Consult your city hall or your retailer to
find the drop-off points for used appliances that is nearest to your home.
— We thank you for your help in protecting the environment.
Warning
Installation should only be performed by installers and qualified technicians.
This appliance complies with the following European directives:
- Low Voltage Directive EEC/73/23 modified by directive EEC/93/68 for insertion of
EC marking.
- Electromagnetic Compatibility Directive 89/336/EEC modified by directive 93/68/EEC for
insertion of EC marking.
- EC regulation no. 1935/2004 concerning materials and objects intended for contact with
food substances.
— This appliance is not intended for use by people (including children) with impaired physical,
sensorial or mental abilities, or people lacking in knowledge or experience, unless they receive
prior supervision or instructions on using the appliances through a person responsible for their
safety.
— Never use steam or high-pressure devices to clean the oven (requirement imposed by
electrical safety concerns).
— Do not modify or attempt to modify any of the characteristics of this appliance. This would be
dangerous to your safety.
— During cooking, ensure that the door of your oven is completely closed so that the seal can
do its job properly.
Information for the user

6
Installing your appliance
FITTING
To do this:
1) Remove the rubber screw covers to access
the mounting holes.
2) Drill a Ø 2 mm hole in the cabinet panel to
avoid splitting the wood.
3) Attach the oven with the two screws.
4) Replace the rubber screw covers (they also
serve to absorb the shock caused by closing
the oven door).
(*) if the cabinet is open, its opening must be
70 mm (maximum).
Tip
To be certain that you have properly
installed your appliance, do not hesitate to
seek advice from a household appliance
specialist.
••
CHOICE OF LOCATION
The diagrams above determine the
dimensions of a cabinet that will be able to
hold your oven.
The oven can be installed under a work top or
in a column of cabinetry (open* or closed)
having the appropriate dimensions for built-in
installation (see above diagram).
Your oven has optimised air circulation that
allows it to achieve remarkable cooking and
cleaning results if the following guidelines are
followed:
• Centre the oven in the cabinet so as to
guarantee a minimum distance of 5 mm
between the appliance and the neighbouring
cabinet.
• The material or coating of the cabinet must
be heat-resistant.
• For increased stability, fix the oven in the
cabinet by means of 2 screws (B) through the
holes designed for this purpose on the lateral
mounts.
••
560
595
540
22
376
380
560-580
20 50
10 50
550
mini
560-580
550 mini 400
310
390

7
••
ELECTRIC CONNECTION
Monophase 20A Counter
220-240V~50Hz
Electrical outlet
2 prong receptacle +eeaarrtthh
CEI Standard 60083
Monophase line 220-240 V ~
Power
supply cable
length 1.50 m approx.
15A fuse or differential
circuit breaker
Electrical safety must be ensured by a correct
build-in. During fitting and maintenance
operations, the appliance must be unplugged
from the electrical grid; fuses must be
switched off or removed.
The electrical connection should be
performed before the appliance is installed in
the cabinet.
Ensure that:
- the electrical installation has sufficient
voltage,
- the electrical wires are in good condition
- the diameter of the wires complies with the
installation requirements.
Warning
In the case of connection to an electric wall
socket, it must remain accessible after
installation.
The fuse in your set-up must be 15s amperes.
If the power cable is damaged, it must be
replaced by the manufacturer, its After-
Sales Service Department or a similarly
qualified person to avoid danger.
Installing your appliance

8
Installing your appliance
Warning
We cannot be held responsible for any accident or incident resulting from non-existent,
defective or incorrect earthing.
If the electrical installation in your residence requires any changes in order to hook up your
appliance, call upon a professional electrician.
If the oven malfunctions in any way, unplug the appliance or remove the fuse corresponding
to the sector where the oven is hooked up.

9
INTRODUCTION TO YOUR OVEN
••
A
B
Controls
Programmer
C
D
Lamp
Wire shelf supports
D
C
B
A
•Accessories
Your appliance is equipped with a flat rack and a glass dish.
Description of your appliance

10
Please note:
At the end of cooking, do not touch the
dishes with bare hands.
Please note:
In order to keep your oven clean for all
cooking functions, you can place the dish
on the base of the oven.
Please note:
Take care to place the drip tray in the
centre of the side grills to avoid modifying
the circulation of air.
Description of your appliance
ACCESSORIES
••
fig.1
fig.2
fig.3
•Rack (fig.1):
Can be used a shelf in micowave when re-
heating/cooking two dishes simultaneously.
The rack should not under any circumstances
be used with other metal cookware on the
micro-wave.
However, you can reheat food in an aluminium
tray if you insulate it from the rack using a
plate.
•Glass drip tray (fig.2):
Can be used half-full of water for double-
boiler cooking methods using the circulating
heat function(keep warm). It can be used as a
cooking dish.
•Rack + glass drip tray (fig.3):
To roast and retain the cooking juices, place
the grill on the drip tray.

11
••
INTRODUCTION TO THE PROGRAMMER
AB
C
D
G
E
F
A
B
Cooking modes display
Cooking time indicator
Power level indicator
Clock or timer display
Timer indicator
Memory 1,2,3 display
Control panel lock indicator
(Child safety device).
C
D
E
F
G
INTRODUCTION TO THE SELECTING BUTTONS
••
Description of your appliance
A
B
C
D
E
F
D
Start / Stop
Touch controls cooking mode
selection
Micro-wave power
Memory 1
Memory 2
Memory 3
Control panel lock indicator
EFG
AC
B
G

12
Oven cooking modes
MMIICCRROO--WWAAVVEE
(recommended positions 11000000WWmin 100 max 1000)
•The energy source is supplied by the micro-waves.
•Energy is distributed by a combination of
- 1 upper element
- 1 lower element.
AAUUTTOOMMAATTIICCDDEEFFRROOSSTTIINNGG
(recommended power 220000WW)
• This function allows optimised defrosting.
KKEEEEPPIINNGGWWAARRMM
(recommended power 335500WW)
• Food is kept warm by the fan which circulates heated air.
The temperature never exceeds 50°C to avoid drying out the food.
MMEEDDIIUUMMPPOOWWEERR
(recommended power 775500WW)
• This function is used to reheat or cook all types of liquid or solid food as well as fresh
or frozen prepared meals.
FFUULLLLPPOOWWEERR
(recommended power 11000000WW)
• This function can be used to speed up cooking of liquids (e.g.: soups, etc.) and food
with high water content (tomatoes, courgettes, etc.).
SSIIMMMMEERRIINNGGAANNDDLLOOWWPPOOWWEERR
(recommended power 550000WW)
• This function is used to finish cooking ready-prepared food: (white beans, lentils,
dairy products), to cook fish and reheat two plates at the same time on level 0 and level
2 placed on the rack.

13
Using your appliance
•How to set the time
--When supplied with electricity
The display flashes at 12:00 (fig.1)
Set the time by pressing the + or - buttons
(holding your finger on the button allows you
to scroll through the numbers rapidly).
Example: 12:30
Press the
SSTTAARRTT
button to validate.
The time display no longer flashes (fig.2).
fig.1
fig.2
fig.2
fig.1
•How to change the time
- To set the time on the clock
Press and hold the W button for a few
seconds until the display is flashing (fig.1),
then release.
Audible beeps indicate that it is now possible
to set the time.
Adjust the clock setting with the + and -
touch controls (fig.2).
Press the
SSTTAARRTT
button to validate.

14
• Micro-wave cooking
fig.2
Warning
Never turn on the oven in any mode when
empty.
fig.1
fig.3
Press once on the START button to select the
function (fig.1).
Press the START button a second time
to access the cooking time settings (fig.2):
- 0.00 flashes
- Adjust by pressing the + or – buttons.
Example: 30 seconds
Adjusting the power level:
- Press the W button, “850 w” begins flashing
(fig.3).
- Adjust by pressing the + or - buttons.
Example: 800W
- Make sure that the door is firmly closed.
Confirm your selection by pressing START.
Your oven starts by counting down second by
second.
If necessary, cooking can be stopped by
pressing on START/STOP for 1 second.
OPENING THE DOOR DURING COOKING
When the door is opened during cooking, the
oven stops operating.
When the door is closed again, cooking can
be recommenced by pressing START/STOP.
Using your appliance

15
Using your appliance
• AUTOMATIC MICRO-WAVE DEFROSTING
With your new micro-wave, say goodbye to
hours of waiting for your food to defrost! The
micro-wave is the freezer’s best ally, making it
possible to defrost food up to 10 times
quicker than at room temperature.
Press once on start button enter the cooking
program selection (fig.1).
Use the < or > buttons to scroll to the
Automatic Defrost function. (fig.2)
Press the SSTTAARRTTbutton to confirm your
selection and access the cooking time
setting.
-0.00 flashes
-Adjust the defrost time by pressingthe + or -
buttons.(fig.3)
Confirm your selection by pressing the
SSTTAARRTTbutton.
Your oven will start by counting down by
second.
Please note:
The function does not need power adjustment.
Tip:
Defrosting time depends on the type of appliance. It also depends on the shape, size, initial
temperature and quality of the food.
Be sure to remove the metallic tie from the defrosting bag when defrosting food directly in
the bag.
If there are any ice crystals on the food, remove them with a knife, otherwise the ice will act
as a screen and the food will take longer to defrost.
Defrost meat and fish by placing it on an upside-down saucer on a plate; this will allow any
juices to drain away which otherwise would cause the food to begin to cook if left in contact
with it.
In order to obtain even defrosting, as soon as possible separate poultry breasts or fish
fillets and break apart cubes of meat.
Turn over or stir food half-way through defrosting.
Leave the food to stand after defrosting. General guidelines: resting time = defrosting time.
Never refreeze food unless it has been cooked
fig.1
fig.2
fig.3

16
DDeeffrroossttiinngg
bbrreeaaddaanndd
ppaassttrryy
DDeeffrroossttiinngg
ccrruussttaacceeaannss
DDeeffrroossttiinngg
FFiisshh
DDeeffrroossttiinngg
MMeeaatt
DDeeffrroossttiinngg
FFrruuiittss
ppllaacceetthhee
ggllaassssddiisshh
oonntthheebbaassee
ppllaacceetthhee
ggllaassssddiisshh
oonntthheebbaassee
ppllaacceetthhee
ggllaassssddiisshh
oonntthheebbaassee
ppllaacceetthhee
ggllaassssddiisshh
oonntthheebbaassee
ppllaacceetthhee
ggllaassssddiisshh
oonntthheebbaassee
Food Quantity Time
French bread
Loaf of bread
Flaky or short crust
100g
200g
400g
300g
45 to 55 sec.
1 to 1 min. 30 secs
2 to 2 min. 30 secs
1 minutes
Food Quantity Time
Scallops
Shelled prawns
Whole pink shrimp
Prawns (10)
Langoustines
500g
100g
200g
500g
1,000g
5 minutes
1 min 30 secs to 2 min
5 to 7 min.
11 to 13 min.
10 to 11 min.
Food Quantity Time
Cod or haddock fillets
Atlantic cod, hake
Sole, plaice (2)
Slices of hake
Pollock, salmon
Trout (3)
400g
500g
300g
1 piece
4 pieces
540g
3 to 4 min.
3 to 4 min.
2 to 2 min. 30 secs
1 min 30 secs to 2 min
4 to 5 min.
4 to 5 min.
Food Quantity Time
Cockerel, pigeon
Chicken breast (2)
Chicken legs (4)
Whole chicken
Veal ribs
Roast beef
Beefburgers (4)
Cubes of meat
500g to 600g
200g
1,000g
1,000g
600g
1,000g
360g
600g
5 to 7 min.
3 to 4 min.
7 to 9 min...........
11 to 13 min.
5 minutes
10 minutes
3 to 4 min.
6 to 7 min.
Food Quantity Time
Strawberries
Raspberries/cherries
Gooseberries,
blueberries, black
currants
250g
250g
250g
2 to 3 min.
2 to 3 min.
2 min 3 secs to 4 min
Turn midway through
• DEFROSTING GUIDE
Using your appliance

••KKEEEEPPIINNGGWWAARRMM
••MMEEDDIIUUMMPPOOWWEERR
••FFUULLLLPPOOWWEERR
••SSIIMMMMEERRAANNDDLLOOWWPPOOWWEERR
Press once on the START button to enter
the cooking program selection (fig. 1)
Use the < or > buttons to scroll to the
desired cooking function. (fig. 2)
Example: keeping warm
Press the START button to confirm your
selection and access the cooking time
setting.
- 0.00 flashes
- Adjust the cooking time by
pressing the + or – buttons. (fig. 3)
Confirm your selection by pressing the
START button.
Your oven will start by counting down
second by second.
17
Please note:
The function does not need power
adjustment.
Warning
Never turn on the oven in any mode when
empty.
Using your appliance
fig.1
fig.2
fig.3

18
Using your appliance
CUSTOMISING THE COOKING POWER
••
When selecting the cooking mode or during a
cooking programme, you can customise the
ppoowweerrfor micro-wave cooking:
Press once on the START button to select the
function.
Press the START button a second time
to access the cooking time settings.
- 0.00 flashes
- Adjust by pressing the + or – buttons.
Example: 30 seconds:
- Press the W button (approx. 2 seconds) until
the power digits begin flashing (fig.1).
- Use the + and - buttons to adjust the power
setting you wish to record (fig.2).
- Validate by pressing the W button (fig.3).
For subsequent cooking programmes, the
power you have just entered will be taken into
account.
This procedure for customising the cooking
temperature can be repeated as many times
as you wish.
fig.2
fig.1
fig.3
• Use this feature to set the default cooking power for Micrawave Cooking

19
••
HOW TO RECORD COOKING PROGRAMMES USING THE MEMORY
FUNCTIONS M1/M2/M3
Your oven is equipped with 3 memory buttons
- M1, M2 and M3 - that allow you to save the
features of your 3 most frequently used
cooking modes.
This memory function is possible for the
following functions
Example of use in the function
- Select the cooking programme with
the + or - buttons (fig.1):
Press the START to access the cooking time
settings.
- 00:00 flashes (fig.2).
- Use the + or - buttons to set the cooking
time, e.g.: 20 seconds (fig.3):
- You can then memorise your choice by
pressing on the M1, M2 or M3 button for
2 seconds.
- 2 beeps confirm your selection and M1, M2
or M3 is displayed (fig.4).
AUTO
fig.1
fig.2
fig.3
fig.4
Using your appliance

20
Using your appliance
••
HOW TO RECORD COOKING PROGRAMMES USING THE MEMORY
FUNCTIONS M1/M2/M3
- When using the function, you can also
record the power
setting after choosing the cooking time.
- After setting the cooking time, press the WW
button.
WWflashes.
- Set the power by pressing the ++or --buttons.
example: 900W
- Record your choice by pressing MM11or MM22
for a few seconds. 2 beeps confirm your
choice and M2 is displayed.
