Blaupunkt VOLCANO 600 User manual

PS-600
Instruction Manual
DJ Pro | Karaoke | Bluetooth | USB
VOLCANO 600

PS-600
2
1 To assure the finest performance, please read this
manual carefully. Keep it in a safe place for future
reference.
2 Install this sound system in a well ventilated, cool,
dry, clean place - away from direct sunlight, heat
sources, vibration, dust, moisture, and/or cold. For
proper ventilation, allow the following minimum
clearances around this unit.
Top: 10 cm (4 inch)
Rear: 10 cm (4 inch)
Sides: 10 cm (4 inch)
3 Locate this unit away from other electrical
appliances, motors, or transformers to avoid
humming sounds.
4 Do not expose this unit to sudden temperature
changes from cold to hot, and do not locate this unit
in an environment with high humidity (i.e. a room
with a humidifier) to prevent condensation inside
this unit, which may cause an electrical shock, fire,
damage to this unit, and/or personal injury.
5 Avoid installing this unit where foreign object may
fall onto this unit and/or this unit may be exposed to
liquid dripping or splashing. On the top of this unit,
do not place:
Other components, as they may cause damage
and/or discoloration on the surface of this unit.
Burning objects (i.e. candles), as they may cause
fire, damage to this unit, and/or personal injury.
Containers with liquid in them, as they may fall and
liquid may cause electrical shock to the user and/or
damage to this unit.
6 Do not cover this unit with a newspaper, tablecloth,
curtain, etc. in order not to obstruct heat radiation.
If the temperature inside this unit rises, it may cause
fire, damage to this unit, and/or personal injury.
7 Do not plug in this unit to a wall outlet until all
connections are complete.
8 Do not operate this unit upside-down. It may
overheat, possibly causing damage.
9 Do not use force on switches, knobs and/or cords.
10 When disconnecting the power cable from the wall
outlet, grasp the plug; do not pull the cable.
11 Do not clean this unit with chemical solvents; this
might damage the finish. Use a clean, dry cloth.
12 Only voltage specified on this unit must be used.
Using this unit with a higher voltage than specified is
dangerous and may cause fire, damage to this unit,
and/or personal injury. We will not be held
responsible for any damage resulting from use of
this unit with a voltage other than specified.
13 To prevent damage by lightning, keep the power
cable and outdoor antennas disconnected from a
wall outlet or this unit during a lightning storm.
14 Do not attempt to modify or fix this unit.
Contact Qualified service personnel
when any service is needed. The
cabinet should never be opened for
any reasons .
15 When not planning to use this unit for
long periods of time (i.e. vacation),
disconnect the AC power plug from the
wall outlet.
16 Be sure to read the
TROUBLESHOOTING section on
common operating errors before
concluding that this unit is faulty.
17 Before moving this unit, disconnect the
AC power plug from the wall outlet.
18 Condensation will form when the
surrounding temperature changes
suddenly. Disconnect the power cable
from the outlet, then leave this unit
alone.
19 When using this unit for a long time,
this unit may become warm. Turn the
power off, then leave this unit alone for
cooling.
20 Install this unit near the AC outlet and
where the AC power plug can be
reached easily.
21 The batteries shall not be exposed to
excessive heat such as sunshine, fire
or the like. When you dispose of
batteries, follow your regional
regulations.
22 Excessive sound pressure from
earphones and headphones can cause
hearing loss.

PS-600
3
REAR PANEL
1.FM ANTENNA
2.AUX A AUDIO INPUT JACK
Connect to AUX A signal output jack.
3.POWER SWITCH
.Press this switch to turn the unit on or off
4.AC INPUT
AC 240V~, 60Hz.
TOP PANEL
1
2
3
4
5
6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
23
24
25
26
272829303132
33
34353637383940
41
MIC 2 VOL
MIC 1 VOL
USE
-
+
-
+
-
+
-
+
YEAH
SCRATCH
REVB
B.BOX
GEYA
OFF
MP3 IN
PORT IN
PARTY
EFFECT
SCRATCH/DJ EFFECT SCRATCH/VOLUME/MULTI
BRING IT
YEA
CLUB
MARVEL LASER
PROC
PHONES
MODE
MENU

PS-600
4
1. STANDBY
2. REVERB mode
3. SCRATCH mode
4. INPUT A VOLUME
This is used to adjust the volume with INPUT A
5. SCRATCH/DJ EFFECT
Adjust this knob to create different DJ music
effect.
6. USB A input jack
7. INPUT A
Press this key to choose INPUT A mode
8. INPUT A PREV
Press this key to choose previous music with
INPUT A
9. INPUT A PAUSE
Press this key to choose play/pause music with
INPUT A
10. INPUT A NEXT
Press this key to choose next music with
INPUT A
11. MUTE
12. ECHO
13. MICROPHONE 1 VOLUME
14. DELAY
15. MICROPHONE 2 VOLUME
16. LED DISPLAY
17. INPUT B
Press this key to choose INPUT B mode.
18. INPUT B PREV
Press this key to choose previous music with
INPUT B
19. INPUT B PAUSE
Press this key to choose play/pause music with
INPUT B
20. INPUT B NEXT
Press this key to choose next music with
INPUT B
21. MENU
22. USB B input jack
23. SCRATCH/VOLUME/MULTI
Rotate the knob to adjust the volume and
choose different music effect.
24. INPUT B VOLUME
This is used to adjust the volume with INPUT B
25. PHONES MODE
Press this key to choose different
EARPHONES mode, INPUT A,
INPUT B, INPUT AB
26. YEA mode
27. MICROPHONE 2 JACK
28. MICROPHONE 1 JACK
29. LASER mode
30. USE mode
31. MARVEL mode
32. CLUB mode
33. MP3 or PORT IN JACK
Connect an output (earphone or line
out) of portable device (MP3 or PMP
etc) to the PORT. IN connector.
34. PARTY EFFECT mode
Press this key to choose different
PARTY effect, THRUST, ALARM,
VECTOR, FIREWORK, RAINING
35. PARTY EFFECT
Slide the lever to create a party
atmosphere
36. PHONES JACK
37. GEYA mode
38. PROC mode
39. BRING IT mode
40. YEAH mode
41. BEAT BOX mode

PS-600
5
A
B
REMOTE CONTROL
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
40
39
1. STANDBY
2. SCRATCH
3. DIMMER
4. BEAT BOX
5. X DRIVE
6. TREBLE-
7. LIGHT
8. BASS-
9. DISCONNECT A
10. AUX A
11. BT A
12. VOLUME-
13. INPUT A NEXT
14. INPUT A BACKWARD
15. BT B
16. INPUT B FORWARD
17. DISCONNECT B
18. INPUT B BACKWARD
19. TUNING+
20. TUNING-
21. FM
22. AUTO
23. MUTE
24. REVER B
25. YEAH
26. TREBLE+
27. BASS+
28. USB-A
29. VOLUME+
30. INPUT A PLAY/PAUSE
31. INPUT A FORWARD
32. INPUT A PREVIOUS
33. USB-B
34. PORT IN
35. INPUT B NEXT
36. INPUT B PLAY/PAUSE
37. INPUT B PREVIOUS
38. CHANNEL-
39. CHANNEL+
40. NUMBER BUTTON(0 TO 9)
REMOTE CONTROL OPERATION:
• If the remote control conflicts with other devices, the operation will be affected.
• Do not simultaneously press buttons on the unit and the remote control.
• Avoid using two remote controls at the same time as this will cause a malfunction.
• Use only UM-4 ``AAA`` size batteries. Do not mix old batteries with new ones.
• If the batteries leak, clean thoroughly before replacing with new ones.
• Do not short two terminals of the batteries. Dispose of old batteries in a suitable place.
PORT IN

PS-600
OPERATING
Normal function
1. Be sure to switch off the power and to connect to corresponding input jacks.
2. Turn on the power and wait 3-4 seconds till the speaker functions are connected.
3. Select an audio source by pressing the INPUT A key on the front panel to display FM,AUX A,
USB A, BT-A. Press the INPUT B key on the front panel to display PORT, USB B, BT-B.
4. Adjust the SCRATCH/VOLUME/MULTI knob on the front panel or the VOL+/- key on the
remote control to adjust the setting of the main volume. Then turn the left push shot to adjust
the volume of INPUT A, turn the right push shot to change the volume of the INPUT B.
5. Press the LIGHT button on the remote control to display light mode, then press the
SCRATCH/VOLUME/MULTI knob to change the OFF, R, G, B, RG, RB, GB, RGB, AUTO,
DEMO light mode.
6. Press the MUTE key on the panel or remote to mute, press it again to reset.
Press the X Drive on the remote to turn on/off X-Bass effect.
SOUND EFFECT
1. DJ EFFECT
Press SCRATCH, REVB, B.BOX, YEAH, BRING IT, PROC, GEYA, on the front panel, or
select SCATCH, REVER B, BEAT BOX, YEAH on the remote control, then turns the
SCRACH/DJ EFFECT big knob to get the corresponding DJ effects.
2. MUSIC EFFECT
Press CLUB, MARVEL, USER, LASER, YEA, on the front panel, then turn the
SCRACH/VOLUME/MULTI big knob to get the corresponding Music effects.
3. PARTY EFFECT
Press “PARTY EFFECT” on the front panel can select PARTY effect, THRUST, ALARM,
VECTOR, FIREWORK, RAINING.
Push the PARTY EFFECT rod, can get the corresponding PARTY EFFECT, when rod arrive
the MAX position, can get the corresponding special PARTY EFFECT,
When pull the rod back to OFF, PARTY EFFECT turn off.
The complete process is OFF--->PARTY EFFECT---> PARTYMAX
Light color control function
To control the light modes coming from the speaker panels by "Speaker" menu or "light model"
button on remote control
● R = red lights flash
● G = green lights flash
● B = blue lights flash
● RG = red and green lights flash
● RB = red and blue lights flash
● GB = green and blue lights flash
● RGB = red, green, and blue lights flash
● Auto = the various color combinations cycle through and flash.
● Demo = lights flash and change color as if they were responding to the beat of the music.
Tuner applications
1. Before using the radio functions, you must attach the supplied antenna. Adjust the antenna to
obtain optimum reception.
Press the INPUT A key on the top control panel or the FM key on the remote control, to select
"FM" function.
2. Press the CH+/CH- key on the remote control to find radio bands that you have previously
Saved.
3. Press or hold the TU+/TU- key on the remote control to adjust the radio frequency manually.
4. Press the AUTO key on the remote control, the machine will scan radio channels from
low-frequency to high-frequency by itself and memorize the channels one by one.
6

PS-600
OPERATING
KARAOKE Function
1. The machine can auto detect whether MIC 1, MIC2 is inserted. Please turn off the microphone
volume and adjust the volume gradually after inserting the microphone.
2. Press VOL+/- on the remote or adjust the MIC.VOL knob on the front panel to change the
microphone VOLUME.
3. Adjust the ECHO knob on the front panel to change the microphone ECHO.
4. Adjust the MIC1/MIC2 VOL knob on the top control panel to change the microphone VOLUME
Note: Do not touch the top of the microphone when singing in oder to avoid howling effect.
Adjust the microphone volume gradually to avoid howling effect.
BLUETOOTH pair and connect
This unit has two BT Function.
● Turn off any BT devices previously paired (linked) with this unit.
● Turn on the BT features on your phone or music player.
● Turn on and set this unit to BT mode. The flashing blue light BT on LED display indicates it is in
pairing mode.
● Set your phone or music player to search for BT devices.
● Select BLAUPUNKT-PS600 A / BLAUPUNKT-PS600 B from search results on your phone or
music player.
● Select OK or YES to pair this unit with your phone or music player.
● If protected, enter 0000 for passkey steady blue light indicates successful connection.
● Press the DISCONNECT key on the remote to disconnect the BT.
Function of USB reader
This unit has two USB jacks. Press the INPUT A key to select USB A, press the INPUT B key
to select USB B, then you can insert a USB to play music.
When two USB inserted at the same time, you can play music at the same time.
Important: The USB port is intended only for data transfer only, other devices cannot be
used with this USB connection. The use of USB extension cords is not recommended.
HEADPHONE JACK
For private listening,insert a 3.5mm earphone into the PHONE JACK.
PHONES OUTPUT selection. Press the PHONES MODE button on the front panel to display
INPUT A, INPUT B, or INPUT AB.
PHONES VOLUME adjustment. Press the PHONES MODE button on the front panel to
display INPUT A or INPUT B or INPUT AB, then rotate the VOLUME/MULTI knob to adjust the
PHONES VOLUME of INPUT A or INPUT B or INPUT AB.
CAUTION: Listening At High Power For A Long Moment Could Damage User’s Ears.
7
ACCESSORIES
SPECIFICATION
Remote control-------------------------------------------------------------------------------------------------------1 pc
FM antenna-----------------------------------------------------------------------------------------------------------1 pc
Instruction Manual-------------------------------------------------------------------------------------------------- 1 pc
RCA 1.5 meters input cable-------------------------------------------------------------------------------------- 1 set
Microphone----------------------------------------------------------------------------------------------------------- 1 pc
Frequency Response -----------------------------------------------------------------------------------20Hz-20KHz
Power Source --------------------------------------------------------------------------------------- AC 240V~,50Hz
Power Consumption --------------------------------------------------------------------------------------------500W
□The specification presents only as a reference. The value of weight and size are approximation.
□Our product is Improved ceaselessly and the specification and function may be changed without
prior notice.

PS-600
WARRANTY INFORMATION 1 YEAR*
If you have issue with our PS-600 product please contact our service center.
Authorized Service Center Blaupunkt Speakers
Address: Envent World Wide Pvt. Ltd.,
Khasra No- 15/15 (4-16), Village Samalkha, Tehsil Vasant Vihar, New Delhi-110037.
E-Mail: [e-mail] Tel: [phone]
Please prepare and submit the following information during the telephone or e-mail notication to
facilitate the process:
- Serial number
- Date of purchase
- A copy of proof of purchase in case of warranty
Note - Important information:
Please use the original packaging or other suitable packaging to
protect the unit in transit.
8
CAUTION
The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids,•
such as vases, shall be placed on the apparatus.
Minimum distances 10 cm around the apparatus for sufficient ventilation.•
The ventilation should not be impeded by covering the ventilation openings with items,such as•
newspapers, table-cloths, curtains, etc.
No naked flame sources, such as lighted candles, should be placed on the apparatus.•
When the mains plug or an appliance coupler is used as the disconnect device,the disconnect device•
shall remain readily operable.
To be completely disconnected the power input, the mains plug of apparatus shall be disconnected
from the mains completely.
The main plug of apparatus should not be obstructed or should be easily accessed during intended•
use.
The use of apparatus in tropical climates.•
Attention should be drawn to the environmental aspects of battery disposal.•
Batteries shall not be exposed to excessive heat such as sunshine, fire or the like.•
Excessive sound pressure from earphones and headphones can cause hearing loss.•
