Blaupunkt CD3000 User manual

Cordless Compact Drill
CD3000

THANKS FOR CHOOSING BLAUPUNKT POWER TOOLS
GARDENING TOOLS –GENERAL SAFETY GUIDELINES
• Please read these instructions carefully before using this Power Tool. Keep this manual in a safe place for future reference.
• This Power Tool is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities or lack of experience or knowledge
• Failure to comply with the following safety instructions can cause electric shock, fire and/or serious injury.
• Accidents can be avoided in many cases by recognizing a potentially hazardous situation before it occurs and by
observing appropriate safety procedures
• Do not use this product for other applications than those specified in this manual
WORK AREA SAFETY
• Keep work area clean and well lit
• Cluttered and dark areas invite accidents
• Do not handle power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dusts
• Keep away from children and curious while operating a power tool
• Distractions can cause you to lose control
PERSONAL SAFETY
• Be attentive, concentrate on the job and use common sense when working with power tools. Do not operate a power
tool when you are tired or under the influence of drugs, alcohol or medication. A moment of carelessness when using the
power tool can lead to serious injury.
• Avoid unintentionally starling the power tool. Ensure that the power switch is in the‘OFF’ position before connecting the
power tool to the mains. Carrying the power tool with your finger on the trigger or connecting the power tool to mains
when switched on can lead to accidents.
• Remove any adjusting tools or keys before turning the power tool on. A tool or key connected to a rotating part of the
power tool can lead to injuries.
• Do not over-reach. Maintain a stable posture and keep your balance. This can improve your control over the power tool in
unexpected situations.
• Wear appropriate clothing. Do not wear loose fitting clothes or jewellery. Keep hair, clothing, and gloves away from
moving parts. Loose fitting clothes, jewellery or long hair can be caught up in moving parts.
• lf dust extraction or collection power tools can be fitted, ensure these are connected and correctly operated. Using these
power tools reduces the danger posed by dust
USE PPE’S
• Use protection glasses according EN166
• Use protection masks according EN149
• lf required by the type of work, use other precise PPE.
ELECTRICAL SAFETY
• The main plug must fit the socket. The plug may not be modified in any way. Do not use adaptors with earthed
equipment. Unmodified plugs and appropriate sockets reduce the risk of electric shock.
• Avoid bodily contact with earthed objects (such as pipes, radiators, ovens and refrigerators). There is an increased risk
of electric shock when your body is earthed.
• Keep the power tool out of rain and wet environments. Water increases the risk of electric shock.
• Do not use the main cable for purposes for which it is not intended, such as carrying or hanging up the power tool and
do not pull the cable to disconnect the tool or the charger from the mains. Protect the cable from heat, oil, sharp edges
and moving parts.
• Damaged or twisted cables increase the risk of electric shock. Damaged mains cables must be replaced using original
Blaupunkt replacement parts Main cables may only be replaced by the manufacturer, an authorised service centre or
qualified person.

• Check extension cables regularly for signs of damage. Damaged extension cables must be replaced. Cable reels should
only be used when fully unwound.
ELECTROMAGNETIC FIELDS (EMF)
• This Power Tool complies with all standards regarding electromagnetic fields (EMF). lf handled properly and according
to the instructions in this user manual, the Power Tool is safe to use based on scientific evidence available today.
DANGER
• Never soak/immerse the power tool in water or any other liquids.
• Do not put cleaning detergents, vinegar or other cleansers on to the power tool.
• Do not use chemically processed water.
WARNING
• Check if the voltage quoted on the model plate of the power tool is suitable for the local mains voltage before
connecting the Power Tool to the mains.
• DO NOT use if the Power Tool has signs of damage to the mains plug / cable, casing or if the Power Tool itself is
damaged). lf the Power Tool leaks or is cracked DO NOT use.
• Please contact Blaupunkt if your Power Tool is damaged.
• Do not allow the Power Tool to run unattended. Always switch the Power Tool offand unplug from the mains when
not in use. Do not leave the power tool until it has come to a complete stop. - DO NOT LEAVE THE POWER TOOL
UNATTENDED IN THE PRESENCE OF CHILDREN OR ANIMALS.
• Keep children far from the area where you are working and DO NOT allow children to drag / pull the power cable, this
could cause serious injury.
• Do not use other high-power electrical Power Tools on the same circuit, this will help prevent overload.
• Always place and use the Power Tool on a stable, level and horizontal surface.
• Disconnect the power tool from the mains switch in the locked offposition before making any adjustments, changing
accessories, or storing the power tool. Such preventative safety measures reduce the risk of starting the power tool
accidentally.
• Use clamps or another practical way to secure and support the work piece to a stable platform. Holding the work by
hand or against your body is unstable and may lead to a loss of control.
• Maintain / clean power tools with care
• Use only accessories that are recommended by the Blaupunkt for your model. Accessories that may be suitable for one
power tool may create a risk of injury when used on another power tool.

1
18
23
25
26
19
20
22
12
2
13
4
15
16
28
3
14
56
7
8
9
10
11
24
21
27
1. Screw M5*20
2. Chuck
3. Torque Sleeve
4. Gear Box Assembly
5. Spring
6. Screw M3*8
7. Motor Gear
8. Motor
9. PCB
10. Label
11. Plate Spring
12. Double Speed Button
13. Steel Wire
14. Magnet
15. Left Housing
16. Hook
17. Screw M4*12
18. Upper Cover
19. Pole Piece
20. Lower Cover
21. Trigger
22. Switch
23. Right Housing
24. Magnet Tube
25. Screw St2.9*12
26. Screw St2.6*10
27. Label
28 Label
DESCRIPTION OF THE PRODUCT
Fig. 1

TECHNICAL CHARACTERISTICS
• Voltage-frequency 230V-50Hz
• Battery 12V max -1.5 AH Li-ion
• Battery charge 1h
• Protection index IP20
• Electronic
• Reversible
• Driver
• Speed rate range 0-350 min-1
• Speed rate range li 0-1300 min-1
• Torque positions 17+1
• Chuck measure 1O mm
• Wood drilling capacity 20 mm
• Metal drilling capacity 8 mm
• Driving capacity 6 mm
• Acoustic pressure LpA9 3.1 dB(A)
• Respective uncertainty KpA 3 dB(A)
• Acoustic power LwA 83.1 dB(A)
• Respective uncertainty KwA 3 dB(A)
• Vibration Ah 0.545m/s’
• Respective uncertainty Kh 1.5 m/s’
1
4
5
2
6
7
89
3
1. Chuck
2. Switch
3. Rotation selector
4. Handle
5. Battery
6. Torque selector
7. Gear selector
8. Battery charge indictor
9. LED lamp
10. Belt clip
Fig. 2
Fig. 5
Fig. 8
Fig. 3
Fig. 6
Fig. 9
Fig. 4
Fig. 7
Fig. 10

BATTERY AND CHARGER
• If the battery housing is damaged, do not insert it in the charger, as there may be a risk of electric shock
• The charger and battery are designed to work together, do not attempt to charge the battery with any other model of
charger
• Do not expose the charger to damp conditions
• The charger is designed for use with rechargeable batteries; any other type of use may pose a fire risk or cause electric
shocks
• Keep the charger away from sources of heat
• Do not open the charger; incorrect reassembly may increase the risk of fire, explosion or electric shocks
• Do not allow liquids to enter the charger, as they may cause electric shocks
• Never use the charger at a different voltage to that specified by the manufacturer
• The batteries must not be opened under any circumstances
• Do not attempt to bum batteries, even when they are empty or broken, as they may explode
• Do not charge the batteries in air temperatures any lower than 4.5°C or higher than 40.5°C to prevent damage
• Both the charger and battery may heat up during the charging process, this is normal, and does not mean there is a
problem
• The battery must be recharged when it does not produce enough energy in situations when it previously did, do not
use the battery in these conditions
• Disconnect the charger from the mains when it does not have a battery inserted.
CHARGING BATTERY
• Insert the charger jack into the socket on the battery
• Connect the charger to the power supply
• lt will take between 3 and 5 hours to charge the battery fully at 20°C
• lf the battery overheats as a result of direct sunlight or other factors, the pilot light may not illuminate . ln this case,
leave the battery to cool and then restart the charging process
• Due to their internal chemical composition, batteries that have never been used or left unused for long periods of time
may not produce their full output during their first or second use
• This is a temporary phenomenon, to restore the optimal battery activity, repeat this process three times with each of
them.
TURNING ON THE FRONT LAMP
• Pull the switch trigger to turn on the light
• The lamp keeps on lighting while the switch trigger is being pulled
• The lamp turns off10 -15 seconds after releasing the trigger (4).
TORQUE SELECTION
• To select the torque, turn the selector to the desired position (5)
• There are 17 positions indicated on the selector
• When working with small screws on light jobs, select low torque grader
• Each click in the clockwise means to increase the produced torque
• The maximum torque position is the drilling position, indicated with an icon of a drill bit on the regulator in this
position the clutch mechanism is not active, for tougher screwing jobs (6).
INSTALLING/REMOVING ACCESSORIES
• After inserting the accessory in the automatic bit holder, tighten the holder firmly by turning it to the right (clockwise)
as seen from the front (7)
• If accessory comes loose during use, turn offthe cordless driver drill and tighten the bit holder firmly

• To remove the accessory, loosen the bit holder by turning it to the left (anti-clockwise) as seen from the front
• Check that the battery is correctly installed
• Make sure you select the correct spin direction (8).
GEAR SELECTOR
• The cordless driver drill has two gears; a short one and another long one
• To change gear, move the selector to the desired position (9).
SWITCH
• When pressed, the bit will turn
• The spin speed may be controlled by varying pressure on the trigger
• lf pressed gently, the bit will turn slowly, increasing with the pressure applied.
BELT CLIP
• With the belt clip the cordless driver drill can be hung anta a belt (10)
• The user has both hands free and the cordless driver drill is always at hand.

You must read the instrution manual Wear protective footwear
Product is compliant with CE
safety standards Wear ear protection
Product is compliant with RoHS safety
satndards Wear safety gloves
General Warning Wear protective cothing
Dispose of in compliance
with WEEE standards Wear safety mask
Cantains Lithium-ion battery Wear eye protection
Product is double insulated Wear head protection
Fire hazard Wear respiratory protection
Electrocution hazard
SYMBOLS
The manual or rating plate on your tool may show symbols.
These represent important information about the product or instructions on its use.
DISPOSAL AND RECYCLING
This marking indicates that this product should not be disposed with other household wastes throughout
the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable reuse of material resources. To return your used device,
please use the return and collection systems or contact the retailer where the product was purchased. They
can take this product for environmental safe recycling.

November 2018
Authorized Representative
WARRANTY
This product has 2 Years Warranty for manufacturing defects. The warranty period will be counted from the date of purchase
of the product, according to purchase invoice. Product warranty only covers manufacturing defects, defects resulting from
improper use, such as dropping, improper transportation, connection to the mains power supply not in compliance with the
voltage specified in this manual, insertion of foreign objects and natural wear of parts and parts Such as plastic parts (caps,
buttons, handles, latch locks, power cables, etc.) and metal parts (wires, motors, etc.).
Also not covered are damages due to agents of nature, lightning, food, sea, oxidation, humidity etc.). The product will lose its
warranty if it presents defects, which after analysis by our technicians, are characterised as being improperly used, used for
professional use or for the purpose for which it is not intended (according to the Owner’s Manual). This warranty will be void if it
is found that the device has been tampered with, has been repaired by a person or service not authorised by Blaupunkt.
The guarantee is only valid with the receipt/invoice provided at purchase.
We undertake to provide the above-mentioned services within the warranty period only in places where it maintains an
authorised service. Consumers not located near an authorised service centre are responsible for the costs and risks of transport
to an authorised service.
Territorial Limitations: Any repair, replacement, or support of the Products provided under the Warranty (or any other support
service oered in our sole discretion), shall be restricted to, and provided solely within, the Distribution Territory as then in eect
on the date the Product is delivered to you. If you purchase a Product within a defined Distribution Territory and later transport
the Product outside of the Distribution Territory, we cannot provide returns, warranty, out-of-warranty, or aftermarket support of
any kind outside the Distribution Territory.
Natural ‘wear and tear’ is not covered under warranty.
This product is for domestic use only.
CE DECLARATION OF CONFORMITY
We hereby declare that the machine described below complies with the relevant basic safety and health requirements
of the listed EU Directives, both in its basic design and construction as well as in the version put into circulation by us.
Product: Cordless Compact Drill
Brand: Blaupunkt
Model: CD3000
Is in conformity with the following Directives and harmonized standards:
EN62841-1:2015
EN62841-2-1:2018
EN62841-2-2:2014
EN505014-1:2017
EN55014-2:2015
Guarenteed sound power level : LwA 83.1 dB(A)

www.blaupunkt.com
