Blaupunkt 49/148O-GB-11B-FEGU User manual

Full HD LED TV with Freeview HD, Saorview and
USB media player
Model No
User Guide
49/148O-GB-11B-FEGU

4
Important safety instruction
Please read these instructions. All
the safety and operating instructions
should be read before the appliance
is operated.
Warnings
• Television sets which weigh 20kg or more must be
lifted and carried by at least 2 people.
• This television does not contain any parts that are
serviceable by the user. In case of a fault, contact the
manufacturer or authorised service department.
Exposing the internal parts inside the TV may endanger
your life. The manufacturers guarantee does not
extend to faults caused by repairs carried out by
unauthorised third parties.
To prevent spread of fire,
keep candles or other open
flames away from this product
at all times
• To reduce the risk of fire, electric shock or damage
to the TV, do not expose it to dust, rain or moisture.
Never expose the TV to dripping or splashing and do
not place objects filled with liquids on or near the TV.
• Do not connect any external devices (DVD player,
games console etc) when the TV is switched on.
Disconnect both the TV and device from the mains
before connecting. Only switch appliances on when
the connection process is complete.
• Do not place the television in a confined space and
do not obstruct the ventilation openings at the rear of
the television.
• When installing on a wall, ensure the TV is at
least 5cm from the wall for ventilation.
• Always ensure that the TV’s ventilation openings
are not covered with items such as newspapers, table-
cloths, curtains, etc.
• Dispose of this television and any components
including batteries in an environmentally friendly
manner. If in doubt, please contact your local authority
for details of recycling.
• Ensure this TV is used in moderate climates only.
WARNING: Never place a television set on an
unstable location. A television set may fall,
causing serious personal injury or death. Many
injuries, particularly to children, can be avoided
by taking simple precautions such as:
• Use cabinets or stands recommended by the
manufacturer of the television set.
• Only use furniture that can safely support the
television set.
• Ensure the television set is not overhanging the
edge of the supporting furniture.
• Do not place the television set on tall furniture
(for example, cupboards or bookcases) without
anchoring both the furniture and the television
set to a suitable support.
• Do not place the television set on cloth or other
materials that may be located between the television
set and supporting furniture.
• Please educate children about the dangers of
climbing on furniture to reach the television set or its
controls.
• If your existing television set is being retained and
relocated, the same considerations as above should be
applied.
Safety
• For your safety, this appliance is fitted with a fused
3 pin mains plug. Should the fuse need to be replaced,
ensure that any replacement is of the same amperage
and approved with the BSI mark.
• Never try and replace the mains plug unless
you have adequate qualifications and are legally
authorised to do so. In the event that a replacement
mains cable is required, contact the manufacturer for a
suitable replacement.
• Never use the television if it is damaged in any way.
• Always place the television on a flat level surface
avoiding anywhere which may be subject to
strong vibration.
• The ideal distance to watch the television is
approximately five times the length of the diagonal
measurements of the TV screen.
• Ensure the television is not placed on top of the
power cable as the weight of the television may
damage the cable and cause a safety hazard.
• Never place mobile phones, speakers or any
other device which may cause magnetic or radio
interference, near the television. If interference is
apparent, move the device causing the interference
away from the television.
• To disconnect the apparatus from the mains, please
use the mains plug located on the underside/rear of
the TV.
• Ensure that the mains plug is always easily
accessible.
WARNING: Excessive noise when using
earphones and headphones can cause loss of
hearing.
User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:4User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:4 14/04/2016 10:19:2514/04/2016 10:19:25

55
Important safety instruction
Maintenance
• To clean your TV, wipe with a soft, dry cloth. If the
surfaces are extremely dirty, use a soft cloth dipped
in a soap and water solution or a weak detergent
solution.
• Never use alcohol, paint thinner or benzene to
clean this unit.
• Before using a chemically treated cloth, read the
instructions that came with the cloth carefully.
CAUTION: If water or other liquid enters the
television through the display panel surface,
a malfunction may occur.
Packaging
• The safest way to transport your item is in the
original box/packaging - please save your packaging
for this.
• You will need the original box/packaging in the
event of warranty/service repair or support. We are
unable to carry out warranty/service if you are unable
to package the item correctly.
Important information regarding use of video
games, computers, captions or other xed image
displays
The extended use of fixed image program material can
cause a permanent “shadow image” on the LCD/LED
panel, also known as “screen burn”.
This “shadow image” can appear in the background
during normal viewing. This type of irreversible LCD/
LED panel deterioration can be limited by observing
the following steps:
1. Reduce the brightness/contrast setting to a minimum
suitable viewing level.
2. Do not display the fixed image for extended periods
of time.
3. Turn the power off when not in use.
Examples of images that are more likely to cause
“screen burn” are as follows (this is not an exhaustive
list):
• TV channel logos: e.g. shopping channel logos
and pricing displays - especially if they are bright and
stationary. Moving or low-contrast graphics are less
likely to cause ageing of the screen.
• Time displays.
• Teletext: Do not view a stationary page for a long
period of time
• TV/DVD menus: e.g. listings of DVD disc content.
• Pause mode: Do not leave the TV in pause mode
for long periods of time, e.g. when watching DVDs
or videos.
Important: Once‘shadow image/screen burn’
occurs, it will never disappear and is not
repairable under warranty.
How do I dispose of this product?
UK: Waste electrical products should not
be disposed of with household waste.
Please dispose of the product at a
designated collection point for recycling
of WEEE. For your nearest facilities, please
see www.recycle-more.co.uk or in store
for details.
ROI: Waste electrical products should
not be disposed of with household waste.
Separate disposal facilities exist. Check
with your local authority or retailer for
recycling advice.
Batteries
• Do not expose batteries to high temperatures,
excessive heat, prolonged sunshine or fire as this may
cause leakage, explosion or ignition.
Observe the correct polarity when inserting batteries.
• Do not use different types of batteries together or
mix old and new batteries.
• Dispose of batteries in an environmentally
friendly way.
• Certain regions may regulate the disposal of
batteries. Please consult your local authority.
Cd
User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:5User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:5 14/04/2016 10:19:2514/04/2016 10:19:25

6
Trademarks
The terms HDMI and HDMI High-Denition Multimedia
Interface, and the HDMI Logo are trademarks or registered
trademarks of HDMI Licensing, LLC in the United States and
other countries.
HDTV
The“HD TV” Logo is a trademark of DIGITALEUROPE.
DVB
The DVB logo is the registered trademark of the Digital Video
Broadcasting (DVB) project.
Manufactured under license from Dolby Laboratories.
Dolby, Dolby Audio and the double-D symbol are trademarks
of Dolby Laboratories.
FREEVIEW
The FREEVIEW words and logos are trade marks of DTV Services
LTD. © DTV Services Ltd.
SAORVIEW
SAORVIEW is a registered trademark owned by RTÉ.
User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:6User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:6 14/04/2016 10:19:2514/04/2016 10:19:25

77
CONTENTS
Manufacturers Guarantee Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Important Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
What is Included in the Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Attaching the Stand / Detaching the Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Securing the TV to a Wall / Wall Mounting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Remote Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
TV Buttons and Input Source Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-15
TV Menu Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-23
Picture Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-17
Sound Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Channel Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Lock Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Time Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Settings Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Network Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
7 Day TV Guide and Channel List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
USB Mode / Media Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-31
Using your TV with a Sky digital set top box . . . . . . . . . . . . . . . . . . . . . . . . 27
Frequently Asked Questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28-29
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30-31
User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:7User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:7 14/04/2016 10:19:2514/04/2016 10:19:25

8
What is Included in the Box
Please save your box/packaging as you will need this in the event of warranty/service repair or support.
We are unable to carry out warranty/service if you are unable to package it correctly. The safest way to
package your item in the event of warranty/service repair is in it’s original box/packaging.
WHAT IS INCLUDED IN THE BOX
1 x User Guide
1 x Quick Start Guide
2 x AAA Batteries
1 x TV
1 x Remote Control
User Guide
Quick Start
Guide
1 x RF Cable
Accessories
Included with this TV are the following accessories
1 x Stand installation pack
6 x
1 x L (left) 1 x R (right)
User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:8User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:8 14/04/2016 10:19:2514/04/2016 10:19:25

99
Attaching the Stand
ATTACHING THE STAND
Back/Shortest
Front/Longest
6 x
5
4
6
1
2
3
6 x
5
4
6
1
2
3
1
2
3
Screws that are included.
(fig.1) Place the TV set on a flat and
clean surface with the panel facing
downwards to avoid damage, then fix
the stand feet shown.
(fig.2) When the stand feet are
installed correctly the stand feet will
be longest at the front of the TV
and shortest at the back with the
feet pointing away from each other.
(fig.3) When the stand feet are
in the correct position, secure the
stand feet to the underside of the
TV set using the 6 screws provided.
Attaching the stand feet
To complete the stand feet installation you will require a cross head screw driver.
6 x
Detaching the stand
Remove the screws highlighted then remove the stand feet from the underside of the TV set.
TV panel must be facing downwards.
User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:9User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:9 14/04/2016 10:19:2814/04/2016 10:19:28

10
Wall Mounting
IMPORTANT - Before drilling any holes in the wall ensure you are not drilling
where there could be any electrical wires, water or gas pipes.
1) Remove the four screws highlighted that are supplied in the wall mounting
holes.
2) The wall mount can now be easily attached to the mounting holes on the
rear of the TV.
For VESA wall mounting information please refer to the Technical
Specification page.
For optimum viewing, if wall mounting the TV higher than eye level, the TV should be tilted downwards
so that the TV’s screen is ‘face on’. See fig 1 and 2.
Important – If wall mounting this TV, only use the screws already provided in the wall mounting holes.
Using other screws which are longer could cause irreparable damage to internal parts.
Securing the TV to a Wall/Wall Mounting
SECURING THE TV TO A WALL
Note - Please ensure that children do not climb on the TV set.
Securing the TV to a wall with anti-tip straps
For maximum security in the home when using a TV with its stand anti-tip straps should be fitted. These
are available from supermarket websites and other websites and are an easy, inexpensive and effective
way of ensuring your TV stays safely upright. Straps are designed to be attached to the rear of the TV and
then tethered to the wall or the furniture the TV is stood on.
The Royal Society for the Prevention of Accidents is urging people to take care with flat-screen televisions.
RoSPA stated in 2010 that “Toddlers are particularly at risk of pulling flat-screen televisions on to
themselves. They are unsteady on their feet and are attracted by colourful television images.”
The risk is increased as televisions become lighter.
A) Using one or both of the top wall-mounting
holes and screws (the screws are already supplied
in the wall mounting holes) fasten one end of the
fastening cord/s to the TV.
B) Secure the other end of the fastening cord/s to
your wall. (you will need screws/fixings suitable
for your wall type - available separately from most
DIY stores).
fi
g 1 fig 2
TV
TV
Viewing angle
Viewing angle
INCORRECT CORRECT
User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:10User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:10 14/04/2016 10:19:2814/04/2016 10:19:28

1111
Remote Control
REMOTE CONTROL
STANDBY - Switch on TV when in standby or vice versa
MUTE - Mute the sound or vice versa
DTV - Switch to Freeview source
RADIO - Switch to radio whilst in Freeview source
USB - Switch to USB source
DVD - Switch to DVD source
NUMBER BUTTONS - 0 – 9 to select a TV channel directly.
TV GUIDE - Opens the 7 Day TV Guide (Freeview mode)
- To return to the previous channel viewed
VOL (+/-) - To increase / decrease the sound level
P.MODE - Scrolls through picture mode options
S.MODE - Scrolls through sound mode options
FAV - To display favourites menu
CH (+/-) - To increase or decrease the channel being watched
MENU - To display OSD menu
EXIT - To exit all menus
- Allows you to navigate the on-screen menus
and adjust the system settings to your preference
SOURCE - To display the input/source menu
INFO - Press once for now/next channel information
Press twice for programme information about current
programme
ASPECT - To switch the screen between the different picture
formats
SLEEP - Press repeatedly to cycle through the sleep options
AUDIO - To change the audio language (if available)
SUBTITLE - To switch the dialogue at the bottom of the screen
(on/off)
TEXT - To enter/exit Text
TEXT HOLD - Teletext mode - Hold current page which is
displayed (Analogue TV)
DISPLAY - To switch off the screen when listening to radio
TEXT/DVD ZOOM - Zoom function for Teletext and DVD
DVD MENU/RECORD - Access the DVD root menu and USB
record function
- To restart the current chapter
- To advance forward to the next chapter
- To stop the playback/Eject Disc
(To EJECT the disc press/hold the button for 4 seconds)
- To play in fast rewind mode
- To play in fast forward mode
- To play/pause
DVD SETUP/REC LIST - Opens up DVD Menu or Opens the list
of what has been previously recorded
GOTO - To go to a specific chapter
A-B - Press once to set point, press a second time to return
to point
ANGLE - Select different angle of DVD
REPEAT - To repeat playback
For Models with Integrated DVD players
For Models with PVR Function
For Models with USB Playback
1
1
2
3
4
4
2
3
User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:11User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:11 14/04/2016 10:19:2814/04/2016 10:19:28

Standby Power On/Off
Displays the input source menu
Displays Menu/OSD
Programme/Channel down and menu down
Programme/Channel up and menu up
Volume down and menu left
Volume up and menu right
1
2
3
4
5
6
7
12
TV BUTTONS AND INPUT SOURCE MENU
1234567
Choosing Mode Input/Source
To switch between the different input/
connections.
For further information on input/connections
please view ‘Connections’ pages.
A) Using the buttons on the remote control:
1) Press [SOURCE] - The source menu will appear.
2) Press [\/] or [/\] to select the input you require.
3) Press [OK].
B) Using the buttons on the Television:
1) Press [SOURCE].
2) Scroll up / down using CH+/ CH- buttons to
the input/source you require.
3) Press Vol+ to change input/source to the
one selected.
TV Buttons and Input Source Menu
Example of Source menu
depending on the TV model
User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:12User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:12 14/04/2016 10:19:2814/04/2016 10:19:28

1313
CONNECTIONS
Connections
ACDEFG
HIJKLM
B
Earphones Earphone Input
Ethernet/LAN* Network Connection
Digital Audio Digital Audio output
SCART SCART input
HDMI 1 (ARC) HDMI input
HDMI 2 HDMI input
RF IN RF / TV Aerial Input
HDMI 3 HDMI input
2 x USB USB port
CI CARD IN Common Interface module
Video Video Input
YPbPr HD input (YPbPr)
A
I
L
B
J
M
C
D
E
F
G
H
K
*The Ethernet/LAN port is used for Freeview HD services only.
R/L Audio shared for Video/Composite
and component/ YPbPr
R/L
3USB (2.0)
5V
500mA MAX
CI CARD IN
VIDEO L (Audio In) R (Audio In) Y Pb Pr
EARPHONE ETHERNET 2
OPTICAL
DIGITAL
AUDIO OUT
ARC
1
SCART RF IN
User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:13User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:13 14/04/2016 10:19:2914/04/2016 10:19:29

14
Connecting to a device with Composite AV/Video output
TV Source should be set to Composite/AV.
L (white)
R (red)
Video
(yellow)
L (white)
R (red)
Video
(yellow)
Connecting to a device with HDMI output
A HDMI cable can output both video and audio and enables you to enjoy digital-quality video and audio
with minimal loss of quality.
TV Source should be set to the corresponding HDMI port (HDMI 1, HDMI 2 etc).
CONNECTIONS
Connecting to a device with SCART output
TV source should be set to SCART.
Note: Connecting cables are shown for example only and may not be included. Please check ‘What Is
Included In The Box’ page.
Scart
Scart
Connections
User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:14User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:14 14/04/2016 10:19:2914/04/2016 10:19:29

1515
Connections
CONNECTIONS
Connecting to a device with Component/YPbPr output
If you are supplied with a cable from the device which has RED, GREEN, BLUE, RED & WHITE connectors
you must connect via Component (for picture) and by phono cable (for sound).
TV Source should be set to Component/YPbPr.
Y (green)
PB (blue)
PR (red)
R (red)
L (white)
Y (green)
PB (blue)
PR (red)
R (red)
L (white)
Connecting to an external audio device (Amplifiers, Surround Sound,
Sound Bars etc)
When connecting via the TV’s 3.5mm Earphone output, this will disable the TV speakers.
There are two options when connecting a device via the 3.5mm Earphone Output and the
Digital Optical Audio Output.
3.5mm
earphone
OPTION 1 for 3.5mm EARPHONE Output
OPTION 2 for Digital Optical Audio Output
Digital
audio
out
(optical)
3.5mm
audio
in
Digital
audio
in
(optical)
Connecting an Ethernet/Network cable
The Ethernet port is used only for Freeview HD services only.
Ethernet
port
Ethernet
port
User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:15User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:15 14/04/2016 10:19:2914/04/2016 10:19:29

16
TV Menu Operation
PICTURE MENU
Picture Mode - Choose from the following presets:
Dynamic Recommended settings for fast moving pictures
Standard Standard settings
Mild Set to be lighter in colour and less bright
Personal Lets you manually alter all the settings
Economy Power saving mode which reduces the energy used by up to
25% (by reducing the power to the LED/LCD panel).
In Economy mode, the TV will switch itself to Standby mode
after 3-5 hours in the event that the TV buttons or remote
control buttons are not pressed (change the picture mode
to another setting to de-activate this function)
You can make the following adjustments in Personal mode:
Contrast - Switch the balance between black and white.
Brightness - Increase or decrease the brightness of the picture.
Colour - Increases the colour from black and white.
Tint - Lets you increase or decrease the level of tint within the picture
(only available for NTSC source signal).
Sharpness - Increase or decrease the sharpness of the picture.
Colour Temperature Choose from the following presets:
Normal Default settings
Warm Increases red within the picture
Cold Increases blue within the picture
To access this menu, press [MENU] button on the remote control.
To select a sub menu press [OK]
If you wish to make changes to any of the default settings, use the scroll buttons.
To confirm any settings press [OK] button. To exit this menu at anytime, press [EXIT] button.
User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:16User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:16 14/04/2016 10:19:2914/04/2016 10:19:29

1717
Noise Reduction - Choose from the following presets:
Off Turns noise reduction off
Low Minor system adjustment
Middle Medium system adjustments
High Maximum system adjustments
TV Menu Operation
PICTURE MENU
Auto
Automatically displays the best picture format so
the picture is in the correct position. Black lines may
appear at the top/bottom and/or sides.
Zoom1 and
Zoom2
Original
16:9
The picture
is the correct
proportion
but zoomed
in to fill the
screen
Will display the picture from the broadcaster
without any change
4:3 Displays the 4:3
picture in its
original size.
Side bars are
shown to fill the
16:9 screen
Fills the screen with
a regular 16:9 signal
and 4:3 picture
format will be
stretched to fill
the screen
Aspect Ratio - Within the UK the picture format varies depending on the channel/broadcast. There are a
number of different options to best meet your needs
Active Contrast - Automatically optimises the ‘backlight’ and ‘contrast’ of the picture according to the
brightness of the screen. Choose one of the following presets: low, middle, high and Off.
User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:17User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:17 14/04/2016 10:19:2914/04/2016 10:19:29

18
TV Menu Operation
SOUND MENU
Treble - To adjust the amount of high frequency within the sound.
Bass - To adjust the amount of low frequency within the sound.
Balance - To switch the sound between the left and right speakers.
Auto Volume Level (AVL) - When ‘on’ is selected, the volume will attempt to stay at a constant level
regardless of TV programme and advertisements.
Surround Sound - Allows you to turn the function On or Off.
Sound Mode - Choose from the following presets
Standard Default settings
Music Emphasises music over voices
Movie Provides live and full sound for movies
Sports Emphasises sound for sports
Personal Selects your personal sound settings
Tip: Equaliser settings can only be
adjusted when the sound mode ‘Personal’
is selected.
Off To turn off Digital Output
Auto Selects the best settings automatically
PCM Select this option if you are connecting to a Stereo Hi-fi via digital audio cable
(Pulse-code modulation (PCM) is a digital representation of an analogue signal)
Audio Description - This allows the user to increase and decrease the AD (Audio Description) volume level.
(Audio Description is a service available on certain programmes. It provides a description of what is
happening during the selected programme for a person who is visually impaired).
AD Volume - This allows the user to increase and decrease the AD (Audio Description) volume level.
Audio Track - This allows the user to change the audio language.
Audio Delay - Enables the user to adjust setting to sync picture and audio.
SPDIF Delay - Enables the user to adjust sound setting to sync picture and audio for external speakers
connected via digital audio output.
Digital Output - This is the digital audio output. Choose from the following options:
User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:18User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:18 14/04/2016 10:19:3014/04/2016 10:19:30

1919
TV Menu Operation
CHANNEL MENU
To access this menu, press [MENU] button on the remote control and scroll right.
To select a sub menu press [OK]
If you wish to make changes to any of the default settings, use the scroll buttons.
To confirm any settings press [OK] button. To exit this menu at anytime, press [EXIT] button.
Tip: If you do not press any buttons for 30 seconds, the menu will automatically exit. You can change
the length of time before the menu exits automatically - see ‘OSD Timer’ in the Time Menu
Important: To receive Freeview channels, in particular
Freeview HD channels, you will need a Digital TV aerial
and be in a good Freeview coverage area. You can check
coverage for your postcode at www.freeview.co.uk
Please note that any Freeview HD channels found during
tuning will be placed in channel positions above 100.
For example, 101 (BBC1 HD) 102 (BBC2 HD) etc.
Auto Tuning - Allows you to retune the television for all digital channels, digital radio stations and
analogue devices.
Analogue Manual Tuning - Allows you to manually tune your analogue signal.
Freeview Manual Tuning - Allows you to manually tune your digital signal.
Channel Edit - Allows you to delete, move, skip and favourite channels.
Signal Information - Allows you to view signal frequency, signal quality and signal strength.
CI Information - Pay per view services require a “smartcard” to be inserted into the TV. If you subscribe to
a pay per view service the provider will issue you with a ‘CAM’ and a “smartcard”. The CAM can then be
inserted into the COMMON INTERFACE PORT (CI Card In).
Schedule List - Lists your programme reminders.
Software Update (OAD) - Switch on/off OAD updates.
User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:19User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:19 14/04/2016 10:19:3014/04/2016 10:19:30

20
TV Menu Operation
LOCK MENU
To access this menu, press [MENU] button on the remote control and scroll right.
To select a sub menu press [OK]
If you wish to make changes to any of the default settings, use the scroll buttons.
To confirm any settings press [OK] button. To exit this menu at anytime, press [EXIT] button.
System/Hotel Lock - Allows you to lock or unlock the menu. You will be asked to enter a 4 digit password
Use the ◄button to quit the password input or use the ► button to clear. Default password is 0000.
Change Password - Allows you to change the password.
Channel Lock - Allows you to lock certain channels manually.
Parental Guidance - Allows you to set the rating to block certain content based on age information.
TV Button Lock - Allows you to lock the buttons on the side of the TV set.
Default Source - Allows the user to set the default source. The default source is the source the TV starts on
when first switched on.
Default Channel - Allows the user to set a channel as the default channel on the Digital source. The
default channel is the channel the TV starts on when first switched on.
Max Volume - Allows you to adjust and set the maximum volume.
Source Lock - Allows you to lock the source menu.
User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:20User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:20 14/04/2016 10:19:3014/04/2016 10:19:30

2121
TV Menu Operation
TIME MENU
Auto Sync - Automatically syncs time and date.
Clock - Shows the date and time.
Off Time - Allows you to set a specific time for your TV to turn off.
On Time - Allows you to set a specific time for your TV to turn on, the channel it will then display, the
source it will be on and also the volume. This function can then be toggled to repeat every day or
a certain day.
Sleep Timer - Lets you set the sleep timer so the television automatically switches off after a set amount of
time. Off -> 10min -> 20min -> 30min -> 60min -> 90min -> 120min -> 180min -> 240min.
OSD Timer - Lets you adjust the amount of time the On Screen Menu stays on the screen before
disappearing.
Auto standby - Set Auto standby between 3 hours, 4 hours and 5 hours ( to turn off this function you must
exit Home Mode in the Picture Menu).
Time Zone - Change your current time zone.
To access this menu, press [MENU] button on the remote control and scroll right.
To select a sub menu press [OK]
If you wish to make changes to any of the default settings, use the scroll buttons.
To confirm any settings press [OK] button. To exit this menu at anytime, press [EXIT] button.
User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:21User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:21 14/04/2016 10:19:3014/04/2016 10:19:30

22
TV Menu Operation
SETTINGS MENU
Language - Allows you to change the language of the menu.
Audio Language 1 - Set the primary audio language.
Audio Language 2 - Set the secondary audio language.
Subtitle Language 1 - Set the primary subtitle language.
Subtitle Language 2 - Set the sceondary subtitle language.
Hearing Impaired - This allows the user to turn on the Hearing Impaired function, this produces subtitles
on the screen which provide a description of what is happening during the selected program.
Blue Screen - Changes the background when there is no input between clear and a blue background (Only
available on some sources).
First Time Installation - Allows you to access the First Time Installation menu and retune the TV set.
Reset TV - This resets the menus to factory settings and clears all the TV channels from the television.
Software Update (USB) - From time to time we may release new firmware to improve the operation of
the television (available to download). This menu lets you install the new software/firmware onto the
television. Further details of how to do this will be issued with the firmware. Contact the helpline or refer
to the ‘product support’ section of the website.
HDMI CEC (Consumer Electronic Control) - Allows HDMI devices to control each other and allows the user
to operate multiple devices with one remote control. (only available with compatible devices).
Network Configuration - Allows you to manually set your network settings on the TV (for more
information please see ‘Network Configuration’ page.
LED Status - Allows the user to switch the LED power indicator light ON or OFF when the TV is being
operated. (When this option is set to OFF the LED power indicator light will flash when the remote
control is used and will flash red during the normal start up process).
Version info - Allows you to view the version/information of the software installed on the TV set.
To access this menu, press [MENU] button on the remote control and scroll right.
To select a sub menu press [OK]
If you wish to make changes to any of the default settings, use the scroll buttons.
To confirm any settings press [OK] button. To exit this menu at anytime, press [EXIT] button.
User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:22User Guide - Blaupunkt - 49-148O-GB-11B-FEGU-UK - BLA-MAN-0309.indd Sec1:22 14/04/2016 10:19:3014/04/2016 10:19:30
