Blaupunkt 40FB5000 User manual

Union Distribution s.r.o. address: Na Srtzi
1702/65, 140 00 Prague 4, Czech Republic
USER'S MANUAL
LED TV
40FB5000

Table of contents
Help/Package contents ........................................................................................................ 1
Warning................................................................................................................................ 2
Safety instructions................................................................................................................5
Getting started .....................................................................................................................7
Controls and connections.....................................................................................................8
Connecting antennae, Internet and external devices..........................................................
Getting started ...................................................................................................................12
After use.............................................................................................................................12
Trouble-shooting................................................................................................................ 13
Specifications..................................................................................................................... 15
Service and certification information................................................................................... 15
Figures and illustrations in this Operation Manual are provided for reference
only and may differ from actual product appearance. Product design and
specifications may be changed without notice.
Help
The Help feature offers a lot of information about your TV operation. To use the Help featur
e, press the Home button, and then use the arrow and OK buttons to access to the Help
menu. You can find how to troubleshoot from the list or keyword search. If you update APK,
the Help feature and information will be updated.
Package contents
1.Led TV
1
2.Remote Control
1
3.Stand
2
4.User Manual 1
5.Screw
4
1
10

2

3

4
Operating conditions: air temperature from 15 to 35 ° C; humidity from 45 to 75%;
atmospheric pressure from 86 to 106 to Pa (from 650 to 800 mm of mercury).
Transportation: Packed TVs are allowed to be transported by all modes of transport
air temperature from +50 to - 40 ° C and humidity from 75 to 100%.

5

6

Getting started
Fitting the stand
Before you can install your TV set, you need to fit the stand. Alternatively, you can mount it
on the wall. A Phillips screwdriver is needed to perform the installation.
Setting up the TV set
Place your TV set on a flat, stable surface (e.g. a table or a specially designed TV stand).
Make sure that all cables are laid simply and safely and do not represent a trip hazard. The
device must be connected to a mains socket using the mains cable. This mains socket must
be easily accessible so that the mains plug can be removed immediately in the event of an
emergency.
Fitting the batteries into the remote control
1. Turn the remote control over with its underside facing upwards, insert a finger into the
recess, and push the battery compartment cover in the direction of the arrow. Remove
the battery compartment cover.
2. Insert the batteries supplied into the remote control. Make sure that you insert the
batteries correctly with the polarity as shown inside the battery compartment.
3. Replace the battery compartment cover and push in the opposite direction to the arrow
until it clicks into place.
Caution: Remove the batteries from the remote control if you are not going to
use the device for an extended period of time. Otherwise, the remote control
can be damaged by leaking battery acid.
7

Controls and connections
Caution: Before connecting or disconnecting any cables, switch off all related
devices (also the TV). Otherwise you could damage the devices.
Back
8
1
USB2.0
(5V 500mA)
HDMI3 HDMI2
LAN
ANT1 ANT2
SATELLITE DIGITAL
AUDIO OUT
AV USB2.0
(5V 500mA)
13/18V 400mA13/18V 400mA
COMMON
INTERFACE
HDMI1(ARC/CEC)
2
89
3
4
5
6
7
8
3
8
1. Headphone out : Earphones/headphones jack.
2. Common Interface slot.
3. USB2.0: USB port. Connector a USB Storage device for multimedia file playback.
4. AV IN: AV audio/video signal input.
5. DIGITAL AUDIO OUT: Connect to an external digital audio device.
6. ANT2:Connection for satellite antenna (ANT 2) (SATELLITE)
7. ANT1:For connection of the external antenna.
8. HDMI1/HDMI2: HDMI (High-Definition Multimedia Interface) input.
(HDMI1 supports ARC function)
9. LAN: Local area network (LAN) port. Connect a LAN cable to this port to connect to
the Network.

Remote control
Definition of the buttons on remote control:
Buttons escription
1 Power Turn on/off TV
2 Mute Mute or restore sound
3 Media
Control media playback in Media
mode
4 Number Number buttons
5 Info Display program information
6 EPG Launch Electronic Program Guide
7 Settings Display System Settings Menu
8 Source Select signal source
9 Direction/
OK
Press the direction buttons to
select menu options or settings.
Press OK to select or confirm
menu item.
10 Menu Display main menu
11 Back Return to last viewed program
12 Voice Activate Voice command function
13 Volume Adjust the volume
14 Program Select programs in ascending or
descending order
15 Home Open Android TV Homepage
16 NETFLIX Open Netflix App
17 YouTube Open YouTube App
18 Color Use in accordance with the
Operation interface instructions
19 Audio Select audio languages and
Audio channels
20 Subtitle Select subtitle
21 TTX Show or hide Teletext
9
