Hyundai H-LED2202-F User manual

ТЕЛЕВИЗОР
ЦВЕТНОГО ИЗОБРАЖЕНИЯ
С ЖИДКОКРИСТАЛЛИЧЕСКИМ
ЭКРАНОМ (LCD)
LED TV
Руководство по эксплуатации Instruction manual
H-LED2202-F

Table of contents
Before you start
Utilization of the product
Important safeguards
Stand installation
Accessories
Connection
Connection
Outdoor antenna connection
Other connections
Operation
Control elements
Front and lateral panel
Back panel
Remote controller
Changing the battery
General operations
AV signal sources
Teletext operations
PC screen
OSD operation
Picture setting
Sound setting
TV Setting
Function setting
PC setup
General information
Troubleshooting
Causes of interference
Specifications
2 3
Table of contents Before you start
Dear customer!
Thank you for purchasing our product. For safety, it is strongly recommended to read
this manual carefully before connecting, operating and/or adjusting the product and keep
the manual for reference in the future.
2
3
3
3
4
4
5
5
5
5
6
6
6
6
7
7
8
8
8
8
9
9
9
9
10
10
11
11
11
12

2 3
Table of contents Before you start
If you want to dispose this product, do not mix it with general household waste. There is
a separate collection system for used electronic products in accordance with legislation
that requires proper treatment, recovery and recycling.
Please contact your local authorities for the correct method of disposal. By doing so,
you will ensure that your disposed product undergoes the necessary treatment, recovery
and recycling and thus prevent potential negative effects on the environment and human
health.
Utilization of the product
Important safeguards
• Before connecting the AC power cord
to the DC adapter outlet, make sure that
the voltage designation of the DC adapter
corresponds to the local electrical supply.
• Accessories include a DC adaptor KPA-
060F. Do not use other adaptors with this unit.
• Please unplug the power cord from the AC
outlet and contact a service center for repair
if following occurs: any obvious abnormality
appears in the unit, such as smoky, peculiar
smell or strange sound; liquid has been spilled or
other objects have fallen into the unit; no picture
or sound; cover or panel is broken; although you
have operated the unit following the operating
instructions, it still cannot work normally.
• This unit should only be connected to a
wall socket having grounding.
• Always disconnect the power cord and
antenna during a storm.
• Do not fix the power cord with a metal nail.
• Unplug the power cord from the AC outlet;
also unplug the signal cables from the input
ports when the unit is unused for long periods
of time.
• When unplugging the plug, always hold
the wide slot, do not touch the metal part, and
do not destroy, refit, twist, pull or roast the
power cord.
• Please contact the service center
immediately if you found that the core is
showed in the air or has been broken.
• Please replace the AC outlet if the metal
bolt cannot be inserted into the power socket
completely or it cannot be fastened even when
it was pushed in, otherwise, any accidents of
shocks and fires would happen.
• Never touch the antenna lie or power plug
if it stars to thunder.
• Do not touch the power plug with wet
hands.
• Do not use any non-rated power socket
with numerous devices jointed on one power
socket or cable device. The wire of non-
designated capacity may cause the fire due to
the generation of heat.
• All instructions must be read and
understood well before you operate the unit.
Heed all warnings and follow all instructions.
• Please use the accessories provided
by the manufacturer. Using inadequate
accessories may result in accidents.
• Please adjust the product through the
panel buttons or the remote controller, do
not remove the cover or attempt to service
the product by yourself. Do not disassemble
back cover and do not make maintenance by
yourself to avoid the electric shock.
• Over-press the panel may destroy the
product.
• Do not place the product on an unstable
cart, stand surface, tripod, bracket, or table.
The product may fall, causing serious accidents
as well as the damage to the product.

4
Before you start
• Please place the product on a flat surface
in a well-ventilated location. Keep it away from
the burning-light, direct sunlight, vibration,
high-temperature and humidity. Store the
product with a temperature from –200C ~500C;
otherwise you may destroy the product.
• Do not place any vase, potted plant, cup,
medicine and any container with water on this
product. If the liquid is spilt, it may cause the
fire, electric shock or breakdown.
• Do not install it at the place on the strong
magnetic field or current field. It may cause
break down. This equipment may be observed
deterioration of the picture by electromagnetic
radiation in electromagnetic environment.
• Fasten the wheel of the product or shelf
with wheels when installing this product. If it
moves or is tipped over, it may be damaged.
• Do not place any fire source such as
candlelight close to this product or place it on
this product. If it is tipped over or fallen down, it
may cause damage or fire.
• Do not place the unit into closed space
of TV for better ventilation; it can reduce the
product lifetime. Keep a space at list 10cm at
above, left, and right of the TV.
• Please place all the signal cords behind of
rear panel.
• Do not overexert or touch the panel when
you convey the product. Do not transfer the
LCD TV up or down display direction.
• Do not transport it with the power cord
or the connection cable connected. If you
move this product with the power cord or the
connection cable connected, the damaged
power cord, connection cable or connection
terminal may cause the fire, the electric shock
or breakdown.
• 2 persons or more shall transport the
device, which is heavier than 18 kg. If you drop
or tip over the device, it may damage it.
• The temperature of the product’s body
becomes a little higher after a long period use.
This phenomenon indicates that heat exchange
in normal working mode, thus please do not
let children or anyone who is sensitive of
temperature to touch.
Stand installation
Insert the fixer in the bottom of the unit body
into the hole of the stand. Rotate the stand
clockwise until a click to lock it in place.
All images provided herein are schematic
drawings and may differ from their real
objects.
Accessories
1. LED TV 1 pc
2. Remote controller 1 pc
3. Power cord 1 pc
4. Stand installation sheet 1 pc
5. Batteries ААА 1,5 V 2 pcs
6. DC adapter 1 pc
7. Consumer information 1 pc
8. Warranty card 1 pc
9. Instruction manual 1 pc

5
Сonnection
Outdoor Antenna Connection
Use 75Ω coaxial cable plug or 300-75Ω
impedance converter to plug in antenna input
terminal on the rear of the cabinet.
Other connections
• Connect the audio sources (Including
DVD, VCDR, CAMCORDER and PC) to the
proper stereo audio input jacks ‘L’ and ‘R’.
• Connect the video source to the composite
video jack by RCA cable.
• If the video source has a SCART output
jack, you can connect the signal to the monitor
by the SCART cable.
• Insert the power cord to the DC adaptor,
then connect the adaptor to the power socket
of the unit.
• When using the LCD as a computer
screen, connect the PC to the VGA jack from
the monitor by the relevant cable.
Connection
• This unit has PC audio in jack. Connect
this jack to PC main unit with related audio
cable in PC mode and adjust the volume to
what you want.
• If the video source has a HDMI output
jack, you can connect the signal to the monitor
by the HDMI cable.
• Component input Y/Pb/Pr is intended for
receiving component video signal if connected
to the component output of external signal
source.
• Connect your headphones or earphones
(not included) to the headphone socket of
this unit. When earphones are connected, the
sound output through the built-in speakers of
this unit is mute.
75 Ohm co-axis cable
TVRF antenna jack
Antenna cable connector

6
Operation
Control elements
Front and top panel
1. MENU button
2. CH+/CH- buttons
3. VOL+/VOL- buttons
4. INPUT button
5. POWER button
6. IR sensor
7. Power indicator
Back panel
1. TVRF antenna socket
2. Stereo audio input
3. Composite video input
4. Component (YPbPr) input
5. Power socket
6. HDMI input
7. VGA input
8. PC audio input
9. SCART connector
10. Headphone output
1 2 3 4 5
6
7
1
2
3
4
5 6 7 8 9 10

7
Operation
Remote controller (RC)
1. POWER button
2. Number buttons
3. PICTURE button
4. SOUND button
5. VOL+/VOL- buttons
6. MUTE button
7. EXIT button
8. OK button/cursor buttons ( / / /
)
9. CANCEL button
10. TV/TXT button
11. SIZE button
12. HOLD button
13. Red button
14. Green button
15. INPUT button
16. button
17. DISPLAY button
18. SLEEP button
19. CH+/CH- buttons
20. MENU button
21. REVEAL button
22. NICAM/A2 button
23. SUBPAGE button
24. INDEX button
25. Blue button
26. Yellow button
Changing the battery
1. Remove the battery compartment cover
on the back of the RC.
2. Insert the batteries into the battery
compartment making sure that the correct
polarity is observed.
3. Install the cover back.
• Use two AAA batteries for the RC. The RC
should be pointed at remote sensor within 8
meters and within 30 degrees at the left or the
right side.
• Take the battery out of the RC if it is not
used for a long time. Do not mix new and used
batteries or different types of batteries. Weak
batteries can leak and severely damage the RC.
• Do not expose the RC to shock, liquids, and
do not place it in an area with high humidity.
1
2
3
4
5
6
7
8
9 21
10 22
20
19
18
17
16
15
11 23
12 24
13 25
14 26

8 9
Operation Operation
General operations
• Press POWER button on the unit or on the
RC to switch on the power, the indication light
will be in green color. Press POWER button
again to switch the unit to standby mode, and
the light will be in red color.
• The picture setup, sound setup, previous
channel can be memorized before you switch
off the unit. The unit will restart under the
previous state when you switch on it again.
• Press VOL- button repeatedly to decrease
the volume; press VOL+ button repeatedly to
increase the volume.
• Press SLEEP button repeatedly to set the
sleep time.
• Press INPUT button on the RC to select
the TV function mode. Channel ‘1’ will appear
on the right top corner after channel searching
is completed. Press CH-/CH+ buttons to select
previous or next channels; or press number
buttons to enter a channel number directly;
or press [-/--] button until the screen displays
‘-’ or ‘--’, then use number buttons to enter a
channel number from 1 to 199.
• Press button on the RC to select
from the present channel and the previously
displayed channel.
• Press PICTURE button repeatedly to cycle
through the available video picture modes from
the following 4 types: User => Normal => Soft
=> Vivid.
• Press SOUND button repeatedly to cycle
through the available sound modes from the
following 4 types: User => Normal => News =>
Movie.
• Press MUTE button to cut off sound, press
this button again or adjust volume to resume
sound.
• Press DISPLAY button to display the
preset TV channel play information.
• Press ZOOM/ASPECT button repeatedly
to select a screen display size from the
available list.
Available aspects may differ for different
signal sources.
AV signal sources
Press INPUT button on the RC, then
press / cursor buttons or CH+/
CH- buttons on the panel to cycle through
the available source list as follows: TV - AV -
YPbPr - SCART - VGA - HDMI. Press cursor
button to confirm.
TELETEXT operations (option)
Select TV channel in order to pick up the
picture signal of Teletext. Teletext button
functions are as follows:
TV/TEXT: Press TV/TEXT button to enter
into TEXT mode. Press this button again to
return to the channel you are watching.
HOLD: Press this button to stop the move
to the next page. Press this button again to
cancel operation.
INDEX: Press this button to go to page 100.
SIZE: Press this button to enlarge the text
shown on the teletext screen, and one half of
page could be shown.
Press this button again to view the second
half of this page.
Press this button third time to normal size
text page view.
REVEAL: Press this button to reveal the
cancelled information. Press this button again
to cancel the information.
CANCEL: Press this button to cancel the
Teletext function.
SUBPAGE: Press this button to select
subpage. Enter the number of sub page and use
numeric buttons in the format 0001 for sub page
1. The teletext will search for the sub page.
Red/Green/Yellow/Blue buttons: Press
these 4 color buttons to access directly to
corresponding color page displayed at the
lower parts of teletext screen.
PC screen
Select the VGA input mode. The unit has a
VGA jack for a normal computer. Connect the
monitor to a PC by this jack and the unit can
be used as the monitor for the PC.

8 9
Operation Operation
OSD operation
Press MENU button on the RC to enter
the OSD menu. Use / buttons to
select a setting page displayed on the screen.
Press button to go the page. Press /
buttons to select the needed item, then
use / buttons to select available setting or
to adjust the selected item. Press OK button to
confirm.
After setting, press MENU button to return
to the root menu or press EXIT button to exit
menu setting.
Picture setting
Move Select Exit
Picture mode
Brightness
Contrast
Saturation
Sharpness
Hue
Scale
• Picture Mode: User/Normal/Soft/Vivid.
• Brightness
• Contrast
• Saturation
• Sharpness
• Hue: adjust the tint of color when your
system is in NTSC.
• Scale: select 16:9/4:3 picture mode.
In PC mode only brightness and
contrast are adjustable.
Sound setting
Move Select Exit
Sound mode
Volume
Bass
Treble
Balance
Sound
• Sound Mode: User/Normal/News/Movie.
• Volume
• Bass
• Treble
• Balance: adjust output between left and
right speakers.
TV setting (only in TV mode)
Move Select Exit
Auto tune
Manual tune
Fine tune
Skip
Sound sys
Channel swap
TV
• Auto tune: enter into auto tuning menu.
Then press button to start auto tuning. When
it finds a station it will automatically store this
in first location and move to the next. When
auto tuning is completed, the TV will show the
first station found. You can stop the auto tuning
proces by pressing MENU button.
• Manual tune: this item allows you to
select preset channel’s frequency one by one

10
Operation
with / buttons.
• Fine tune: perform fine adjustment of the
current frequency.
• Skip: select On/Off. When set On, the
corresponding channel will be skipped while
listing channels up/down.
• Sound system: select the sound system.
• Channel swap: Press button to
go to swap menu. Under CHANNEL1 and
CHANNEL2 select channel numbers you
want to swap, then press button to confirm
operation.
Function setting
Move Select Exit
Language
Blue back
TTX language
Color temp.
Reset
Function
• Language: select the OSD language.
• Blue Back: select On/Off. Selecting On
means the screen background colour could be
in blue if there is no or weak signal (only in TV
mode).
• TTX language: select the area of teletext
language.
• Color temperature: Cool/Warm/Normal/
User.
• Reset: Press button to reset all settings.
PC Setup (only in VGA mode)
Move Select Exit
H-Position
V-Position
Clock
Phase
Auto adjust
PC
• H-Position/V-Position: adjust horizontal
and vertical position of the image.
• Clock: adjust the image frequency
manually.
• Phase: adjust the phase manually.
• Auto adjust: automatical setting of the
parameters.
In this manual, the OSD Menu maybe
changed and different from your real TV’s
screen without further notice. This manual is
just a sample to help you how to operate menu
setting.
