Blaupunkt 32/138o-gb-11b4-egp User manual

HD Ready LED TV with Freeview, Saorview & USB PVR

Model No

User Guide

32/138O-GB-11B4-EGP

32/138O-GB-11B4-EGDP

Important safety instruction

Please read these instructions. All

the safety and operating instructions

should be read before the appliance

is operated.

Warnings

• Television sets with 40” screens or more must be

lifted and carried by at least 2 people.

• This television does not contain any parts that are

serviceable by the user. In case of a fault, contact the

manufacturer or authorised service department.

Exposing the internal parts inside the TV may endanger

your life. The manufacturers guarantee does not

extend to faults caused by repairs carried out by

unauthorised third parties.

To prevent spread of ﬁre,

keep candles or other open

ﬂames away from this product

at all times

• Do not use TV set directly after unpacking. Wait

until TV warms up to the room temperature before

using it.

• To reduce the risk of ﬁre, electric shock or damage

to the TV, do not expose it to dust, rain or moisture.

Never expose the TV to dripping or splashing and do

not place objects ﬁlled with liquids on or near the TV.

• Do not connect any external devices (DVD player,

games console etc) when the TV is switched on.

Disconnect both the TV and device from the mains

before connecting. Only switch appliances on when

the connection process is complete.

• Do not place the television in a conﬁned space and

do not obstruct the ventilation openings at the rear of

the television.

• When installing on a wall, ensure the TV is at

least 5cm from the wall for ventilation.

• Always ensure that the TV’s ventilation openings

are not covered with items such as newspapers,

table-cloths, curtains, etc.

• Dispose of this television and any components

including batteries in an environmentally friendly

manner. If in doubt, please contact your local authority

for details of recycling.

• Ensure this TV is used in moderate climates only.

• In case of electrostatic discharge (ESD) the TV may

display incorrect functions. In such case, switch

the TV off and switch the TV back on. The TV will

work normally.

WARNING: Never place a television set on an

unstable location. A television set may fall,

causing serious personal injury or death. Many

injuries, particularly to children, can be avoided

by taking simple precautions such as:

• Use cabinets or stands recommended by the

manufacturer of the television set.

• Only use furniture that can safely support the

television set.

• Ensure the television set is not overhanging the

edge of the supporting furniture.

• Do not place the television set on tall furniture

(for example, cupboards or bookcases) without

anchoring both the furniture and the television

set to a suitable support.

• Do not place the television set on cloth or other

materials that may be located between the television

set and supporting furniture.

• Please educate children about the dangers of

climbing on furniture to reach the television set or its

controls.

• If your existing television set is being retained and

relocated, the same considerations as above should be

applied.

Safety

• For your safety, this appliance is ﬁtted with a fused

3 pin mains plug. Should the fuse need to be replaced,

ensure that any replacement is of the same amperage

and approved with the BSI mark.

• Never try and replace the mains plug unless

you have adequate qualiﬁcations and are legally

authorised to do so. In the event that a replacement

mains cable is required, contact the manufacturer for a

suitable replacement.

• Never use the television if it is damaged in any way.

• Always place the television on a ﬂat level surface

avoiding anywhere which may be subject to

strong vibration.

• The ideal distance to watch the television is

approximately ﬁve times the length of the diagonal

measurements of the TV screen.

• Ensure the television is not placed on top of the

power cable as the weight of the television may

damage the cable and cause a safety hazard.

• Never place mobile phones, speakers or any

other device which may cause magnetic or radio

interference, near the television. If interference is

apparent, move the device causing the interference

away from the television.

• To disconnect the set from the mains, remove the

mains plug from the socket.

• Ensure that the mains plug is always easily

accessible.

WARNING: Excessive noise when using

earphones and headphones can cause loss of

hearing.

User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:4User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:4 09/06/2017 11:19:4709/06/2017 11:19:47

Important safety instruction

Maintenance

• To clean your TV, wipe with a soft, dry cloth. If the

surfaces are extremely dirty, use a soft cloth dipped

in a soap and water solution or a weak detergent

solution.

• Never use alcohol, paint thinner or benzene to

clean this unit.

• Before using a chemically treated cloth, read the

instructions that came with the cloth carefully.

CAUTION: If water or other liquid enters the

television through the display panel surface,

a malfunction may occur.

Packaging

• The safest way to transport your item is in the

original box/packaging - please save your packaging

for this.

• You will need the original box/packaging in the

event of warranty/service repair or support. We are

unable to carry out warranty/service if you are unable

to package the item correctly.

Important information regarding use of video

games, computers, captions or other xed image

displays

The extended use of xed image program material can cause

a permanent“shadow image”on the LCD/LED panel, also

known as “screen burn”.

This“shadow image”can appear in the background during

normal viewing. This type of irreversible LCD/LED panel

deterioration can be limited by observing the following steps:

1. Reduce the brightness/contrast setting to a minimum

suitable viewing level.

2. Do not display the xed image for extended periods

of time.

3. Turn the power o when not in use.

Examples of images that are more likely to cause“screen burn”

are as follows (this is not an exhaustive list):

• TV channel logos: e.g. shopping channel logos

and pricing displays - especially if they are bright and

stationary. Moving or low-contrast graphics are less

likely to cause ageing of the screen.

• Time displays.

• Teletext: Do not view a stationary page for a long

period of time

• TV/DVD menus: e.g. listings of DVD disc content.

• Pause mode: Do not leave the TV in pause mode

for long periods of time, e.g. when watching DVDs

or videos.

Important: Once‘shadow image/screen burn’

occurs, it will never disappear and is not

repairable under warranty.

How do I dispose of this product?

UK: Waste electrical products should not

be disposed of with household waste.

Please dispose of the product at a

designated collection point for recycling

of WEEE. For your nearest facilities, please

see www.recycle-more.co.uk or in store

for details.

ROI: Waste electrical products should not be

disposed of with household waste. Separate

disposal facilities exist. Check with your local

authority or retailer for recycling advice.

Batteries

• Do not expose batteries to high temperatures,

excessive heat, prolonged sunshine or ﬁre as this may

cause leakage, explosion or ignition.

Observe the correct polarity when inserting batteries.

• Do not use different types of batteries together or

mix old and new batteries.

• Dispose of batteries in an environmentally

friendly way.

• Certain regions may regulate the disposal of

batteries. Please consult your local authority.

User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:5User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:5 09/06/2017 11:19:4709/06/2017 11:19:47

CAUTION:

THIS UNIT IS A CLASS 1 LASER PRODUCT. THIS UNIT USES A VISIBLE LASER BEAM WHICH COULD CAUSE HAZARDOUS

RADIATION EXPOSURE IF DIRECTED. BE SURE TO OPERATE THE PLAYER CORRECTLY AS INSTRUCTED.

WHEN THIS UNIT IS PLUGGED INTO THE WALL OUTLET, DO NOT PLACE YOUR EYES CLOSE TO THE OPENINGS TO LOOK

INTO THE INSIDE OF THIS UNIT.

USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY

RESULT IN HAZARDOUS RADIATION EXPOSURE.

DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF. REFER SERVICING TO QUALIFIED PERSONNEL.

CLASS 1

LASER PRODUCT

This caution label is located on the rear panel of the unit

Trademarks

The terms HDMI and HDMI High-Denition Multimedia

Interface, and the HDMI Logo are trademarks or registered

trademarks of HDMI Licensing, LLC in the United States and

other countries.

HDTV

The“HD TV” Logo is a trademark of DIGITALEUROPE.

DVB

The DVB logo is the registered trademark of the Digital Video

Broadcasting (DVB) project.

JBL is trademark of HARMAN International Industries,

Incorporated, registered in the United States and/or other

countries.

Manufactured under license from Dolby Laboratories.

Dolby, Dolby Audio and the double-D symbol are trademarks

of Dolby Laboratories.

FREEVIEW HD

The FREEVIEW HD words and logos are trade marks of DTV

Services LTD. © DTV Services Ltd.

SAORVIEW

SAORVIEW is a registered trademark owned by RTÉ.

For DTS patents, see http://patents.dts.com. Manufactured

under license from DTS Licensing Limited. DTS, the Symbol,

& DTS and the Symbol together are registered trademarks.

DTS TruSurround is a trademark of DTS, Inc. © DTS, Inc.

User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:6User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:6 09/06/2017 11:19:4709/06/2017 11:19:47

CONTENTS

Manufacturers Guarantee Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Important Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5

Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

What is Included in the Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Attaching the Stand / Detaching the Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Securing the TV to a Wall / Wall Mounting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Remote Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

TV Control Stick, DVD buttons and Input Source Menu. . . . . . . . . . . . . . . . . . . . . . . . . 12

Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-15

TV Menu Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-23

Picture Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-17

Sound Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18-19

Channel Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Lock Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Time Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Settings Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Network Conﬁguration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

DVD Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

7 Day TV Guide and Channel List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

USB Mode / Media Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

USB record - Freeview / Saorview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29-33

Using your TV with a Sky digital set top box . . . . . . . . . . . . . . . . . . . . . . . . 29

Frequently Asked Questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30-31

Technical Speciﬁcations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32-33

User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:7User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:7 09/06/2017 11:19:4809/06/2017 11:19:48

What is Included in the Box

Please save your box/packaging as you will need this in the event of warranty/service repair or support.

We are unable to carry out warranty/service if you are unable to package it correctly. The safest way to

package your item in the event of warranty/service repair is in it’s original box/packaging.

WHAT IS INCLUDED IN THE BOX

1 x User Guide

1 x Quick Start Guide

1 x TV

1 x Remote Control and 2 x AAA Batteries

User Guide

Quick Start

Guide

1 x RF Cable

Accessories

Included with this TV are the following accessories

1 x Mini AV / Composite cable

1 x Stand installation pack

4 x

1 x L (left) 1 x R (right)

1 x Mini Component / YPbPr

1 x Power Cord

User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:8User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:8 09/06/2017 11:19:4809/06/2017 11:19:48

Attaching the Stand

ATTACHING THE STAND

4 x

Screws that are included.

(ﬁg.1) Place the TV set on a ﬂat and

clean surface with the panel facing

downwards to avoid damage, then ﬁx

the stand feet shown.

(ﬁg.2) When the stand feet are

installed correctly the stand feet will

be longest at the front of the TV

and shortest at the back with the

feet pointing away from each other.

(ﬁg.3) When the stand feet are

in the correct position, secure the

stand feet to the underside of the

TV set using the 4 screws provided.

Attaching the stand feet

To complete the stand feet installation you will require a cross head screw driver.

4 x

Detaching the stand

Remove the screws highlighted then remove the stand feet from the underside of the TV set.

TV panel must be facing downwards.

User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:9User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:9 09/06/2017 11:19:5109/06/2017 11:19:51

Wall mounting

IMPORTANT - Before drilling any holes in the wall ensure you are not drilling where there

could be any electrical wires, water or gas pipes.

1) Remove the four screws located at the back of the TV set.

2) The wall mount can now be easily attached to the mounting holes, located

on the back of the TV, using the same four screws removed.

For VESA wall mounting information please refer to the Technical

Speciﬁcation page.

For optimum viewing, if wall mounting the TV higher than eye level, the TV should be tilted downwards

so that the TV’s screen is ‘face on’. See ﬁg 1 and 2.

Securing the TV to a wall/wall mounting

SECURING THE TV TO A WALL

Note - Please ensure that children do not climb on the TV set.

Securing the TV to a wall with anti-tip straps

For maximum security in the home, when using a TV with its stand, anti-tip straps should be ﬁtted. These

are available from supermarket websites and other websites and are an easy, inexpensive and effective

way of ensuring your TV stays safely upright. Straps are designed to be attached to the rear of the TV and

then tethered to the wall or the furniture the TV is stood on, these are ﬁtted as follows.

The Royal Society for the Prevention of Accidents is urging people to take care with ﬂat-screen televisions.

RoSPA stated in 2010 that “Toddlers are particularly at risk of pulling ﬂat-screen televisions on to

themselves. They are unsteady on their feet and are attracted by colourful television images.”

The risk is increased as televisions become lighter.

A) Using one or both of the top wall-mounting

holes and screws fasten one end of the fastening

cord/s to the TV. (the screws are already supplied in

the wall mounting holes)

B) Secure the other end of the fastening cord/s to

your wall. (you will need screws/ﬁxings suitable

for your wall type - available separately from most

DIY stores).

ﬁg 1 ﬁg 2

Viewing angle

INCORRECT CORRECT

Important – If wall mounting this TV, only use the screws already provided in the wall mounting holes.

Using other screws which are longer could cause irreparable damage to internal parts. When using a

wall bracket, please ensure the screws in the back of the TV set are not over tightened.

User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:10User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:10 09/06/2017 11:19:5109/06/2017 11:19:51

1111

Remote Control

REMOTE CONTROL

STANDBY - Switch on TV when in standby or vice versa

MUTE - Mute the sound or vice versa

DTV - Switch to Freeview source

RADIO - Switch to radio whilst in Freeview source

USB - Switch to USB source

DVD - Switch to DVD source

NUMBER BUTTONS - 0 – 9 to select a TV channel directly.

TV GUIDE - Opens the 7 Day TV Guide (Freeview mode)

- To return to the previous channel viewed

VOL (+/-) - To increase / decrease the sound level

P.MODE - Scrolls through picture mode options

S.MODE - Scrolls through sound mode options

FAV - To display favourites menu

CH (+/-) - To increase or decrease the channel being watched

MENU - To display OSD menu

EXIT - To exit all menus

- Allows you to navigate the on-screen menus

and adjust the system settings to your preference

SOURCE - To display the input/source menu

INFO - Press once for now/next channel information

Press twice for programme information about current

programme

ASPECT - To switch the screen between the different picture

formats

SLEEP - Press repeatedly to cycle through the sleep options

AUDIO - To change the audio language (if available)

SUBTITLE - To switch the dialogue at the bottom of the screen

(on/off)

TEXT - To enter/exit Text

TEXT HOLD - Teletext mode - Hold current page which is

displayed (Analogue TV)

DISPLAY - To switch off the screen when listening to radio

TEXT/DVD ZOOM - Zoom function for Teletext and DVD

DVD MENU/RECORD - Access the DVD root menu and USB

record function

- To restart the current chapter

- To advance forward to the next chapter

- To stop the playback/Eject Disc

(To EJECT the disc press/hold the button for 4 seconds)

- To play in fast rewind mode

- To play in fast forward mode

- To play/pause

DVD SETUP/REC LIST - Opens up DVD Menu or Opens the list

of what has been previously recorded

GOTO - To go to a speciﬁc chapter

A-B - Press once to set point, press a second time to return

to point

ANGLE - Select different angle of DVD

REPEAT - To repeat playback

For Models with Integrated DVD players

For Models with PVR Function

For Models with USB Playback

User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:11User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:11 09/06/2017 11:19:5209/06/2017 11:19:52

TV CONTROL STICK, DVD BUTTONS AND INPUT

SOURCE MENU

TV Control Stick, DVD buttons and Input Source Menu

An example of the ‘Input Source’ menu

(will vary by model)

TV Control Stick

The TV control stick is located on the back of the TV in the left bottom corner. The control stick can be

used to control many of the TV functions. The shape of the TV control stick may vary by model.

While TV is in standby mode:

• Press the centre of the control stick once - Power on the TV set

While watching TV:

• RIGHT/LEFT – volume up/volume down

• UP/DOWN – changes channel up/down

• Long press UP (or DOWN) – Displays Sources/Inputs menu

• Press the centre of the control stick once – Displays Menu

• Press and hold the centre of the control stick – Standby Power Off

While in menu:

• RIGHT/LEFT/UP/DOWN – navigation of cursor in on-screen menus

• Press the centre of the control stick once – OK/Conﬁrm selected item

• Press and hold the centre of the control stick – Back to previous menu

DVD Buttons

The DVD buttons are located on the side of the TV near the DVD Slot. Available for DVD models only.

• TOP BUTTON – STOP/EJECT (Hold down for 4 seconds to eject a DVD).

• BOTTOM BUTTON – PLAY/PAUSE.

Choosing Mode Input/Source

Use the source menu to switch between input/connections.

A) Using the buttons on the remote control:

1. Press [SOURCE] - The source menu will appear.

2. Press [ ] or [ ] to select the input you require.

3. Press [OK].

B) Using the TV control stick:

1. Press control stick UP (or DOWN) for few seconds to enter SOURCES menu.

2. Press the control stick up/down to scroll through and select the input/source you require.

3. Press the centre of the control stick to select the chosen input/source option highlighted.

For further information on input/connections please view ‘Connections’ pages.

Control Stick DVD Buttons

User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:12User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:12 09/06/2017 11:19:5209/06/2017 11:19:52

1313

CONNECTIONS

Connections

Earphones Earphone Input

Ethernet/LAN* Network Connection

Digital Audio Digital Audio output

SCART SCART input

HDMI 1 (ARC) HDMI input

HDMI 2 HDMI input

RF IN RF / TV Aerial Input

HDMI 3 HDMI input

2 x USB USB port

CI CARD IN Common Interface module

AV IN Audio/Video Input

YPbPr HD input (Ypbpr)

*The LAN/Ethernet port is used for Freeview HD services only.

User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:13User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:13 09/06/2017 11:19:5309/06/2017 11:19:53

Connecting to a device with Composite AV/Video output

TV Source should be set to Composite/AV

L (white)

R (red)

Video

(yellow)

AV in

Connections

Connecting to a device with HDMI output

A HDMI cable can output both video and audio and enables you to enjoy digital-quality video and audio

with minimal loss of quality.

TV Source should be set to the corresponding HDMI port (HDMI 1, HDMI 2 etc)

CONNECTIONS

Connecting to a device with SCART output

TV source should be set to SCART

Note: Connecting cables are shown for example only and may not be included. Please check ‘What Is

Included In The Box’ page.

Scart

User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:14User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:14 09/06/2017 11:19:5409/06/2017 11:19:54

1515

Connections

CONNECTIONS

Connecting to a device with Component/YPbPr output

If you are supplied with a cable from the device which has RED, GREEN, BLUE, RED & WHITE connectors

you must connect via Component (for picture) and by phono cable (for sound).

TV Source should be set to Component/YPbPr

AV in

YPbPr

Y (green)

PB (blue)

PR (red)

Video (yellow)

is not connected

R (red)

L (white)

Connecting to an external audio device (Ampliﬁers, Surround Sound,

Sound Bars etc)

When connecting via the TV’s 3.5mm Earphone output, this will disable the TV speakers.

There are two options when connecting a device via the 3.5mm Earphone Output and the

Digital Optical Audio Output

3.5mm

earphone

OPTION 1 for 3.5mm EARPHONE Output

OPTION 2 for Digital Optical Audio Output

Digital

audio

out

(optical)

3.5mm

audio

Digital

audio

(optical)

Connecting an Ethernet/Network cable

The Ethernet port is used only for Freeview HD services only.

Ethernet

port

Ethernet

port

User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:15User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:15 09/06/2017 11:19:5509/06/2017 11:19:55

TV Menu Operation

PICTURE MENU

Picture Mode - Choose from the following presets:

Dynamic Recommended settings for fast moving pictures

Standard Standard settings

Mild Set to be lighter in colour and less bright

Personal Lets you manually alter all the settings

Economy Power saving mode which reduces the energy used by up to

25% (by reducing the power to the LED/LCD panel).

In Economy mode, the TV will switch itself to Standby mode

after 3-5 hours in the event that the TV buttons or remote

control buttons are not pressed (change the picture mode

to another setting to de-activate this function)

You can make the following adjustments in Personal mode:

Contrast - Switch the balance between black and white.

Brightness - Increase or decrease the brightness of the picture.

Colour - Increases the colour from black and white.

Tint - Lets you increase or decrease the level of tint within the picture

(only available for NTSC source signal).

Sharpness - Increase or decrease the sharpness of the picture.

Colour Temperature Choose from the following presets:

Normal Default settings

Warm Increases red within the picture

Cold Increases blue within the picture

To access this menu, press [MENU] button on the remote control.

To select a sub menu press [OK]

If you wish to make changes to any of the default settings, use the scroll buttons.

To conﬁrm any settings press [OK] button. To exit this menu at anytime, press [EXIT] button.

User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:16User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:16 09/06/2017 11:19:5509/06/2017 11:19:55

1717

TV Menu Operation

PICTURE MENU

Auto

Automatically displays the best picture format so

the picture is in the correct position. Black lines may

appear at the top/bottom and/or sides.

Zoom1 and Zoom2

Original

16:9

The picture

is the correct

proportion

but zoomed

in to ﬁll the

screen

Will display the picture from the broadcaster without

any change, only available in HDMI input source.

4:3

Full Screen

Displays the 4:3

picture in its

original size.

Side bars are

shown to ﬁll the

16:9 screen

Displays a picture in

the full screen mode

with out overscan.

16:9 signal will be

displayed in original

proportion. Other

picture format will

be stretched to ﬁll

the screen.

Fills the screen with

a regular 16:9 signal

and 4:3 picture

format will be

stretched to ﬁll

the screen

Aspect Ratio - Within the UK the picture format varies depending on the channel/broadcast. There are a

number of different options to best meet your needs

Noise Reduction - Switch ON or OFF. Noise Reduction ﬁlters and reduces the noise (interference) of

the picture.

Active Contrast - Switch ON or OFF. Automatically optimises the ‘backlight’ and ‘contrast’ of the picture

according to the brightness of the screen.

User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:17User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:17 09/06/2017 11:19:5509/06/2017 11:19:55

To access this menu, press [MENU] button on the remote control and scroll right.

To select a sub menu press [OK]

If you wish to make changes to any of the default settings, use the scroll buttons.

To conﬁrm any settings press [OK] button. To exit this menu at anytime, press [EXIT] button.

TV Menu Operation

SOUND MENU

Treble - To adjust the amount of high frequency within the sound.

Bass - To adjust the amount of low frequency within the sound.

Balance - To switch the sound between the left and right speakers.

Auto Volume Level (AVL) - When ‘on’ is selected, the volume will attempt to stay at a constant level

regardless of TV programme and advertisements.

Sound Mode - Choose from the following presets

Standard Default settings

Music Emphasises music over voices

Movie Provides live and full sound for movies

Sports Emphasises sound for sports

Personal Selects your personal sound settings

For DTS patents, see http://patents.dts.com. Manufactured under license from

DTS Licensing Limited. DTS, the Symbol, & DTS and the Symbol together are

Off Off

TruSurround TruSurroundTM creates an immersive, feature-rich surround sound experience

from two speakers, complete with rich bass, high frequency detail and clear dialog

DTS TruSurround - Choose from the following options:

User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:18User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:18 09/06/2017 11:19:5509/06/2017 11:19:55

1919

To access this menu, press [MENU] button on the remote control and scroll right.

To select a sub menu press [OK]

If you wish to make changes to any of the default settings, use the scroll buttons.

To conﬁrm any settings press [OK] button. To exit this menu at anytime, press [EXIT] button.

TV Menu Operation

SOUND MENU

Off To turn off Digital Output

Auto Selects the best settings automatically

PCM Select this option if you are connecting to a Stereo Hi-ﬁ via digital audio cable

(Pulse-code modulation (PCM) is a digital representation of an analogue signal)

Audio Description - This allows the user to increase and decrease the AD (Audio Description) volume level.

(Audio Description is a service available on certain programmes. It provides a description of what is

happening during the selected programme for a person who is visually impaired).

AD Volume - This allows the user to increase and decrease the AD (Audio Description) volume level.

Audio Delay - Enables the user to adjust setting to sync picture and audio.

SPDIF Delay - Enables the user to adjust sound setting to sync picture and audio for external speakers

connected via digital audio output.

Digital Output - This is the digital audio output. Choose from the following options:

User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:19User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:19 09/06/2017 11:19:5509/06/2017 11:19:55

TV Menu Operation

CHANNEL MENU

To access this menu, press [MENU] button on the remote control and scroll right.

To select a sub menu press [OK]

If you wish to make changes to any of the default settings, use the scroll buttons.

To conﬁrm any settings press [OK] button. To exit this menu at anytime, press [EXIT] button.

Tip: If you do not press any buttons for 30 seconds, the menu will automatically exit. You can change

the length of time before the menu exits automatically - see ‘OSD Timer’ in the Time Menu

Important: To receive Freeview channels, in particular

Freeview HD channels, you will need a Digital TV aerial

and be in a good Freeview coverage area. You can check

coverage for your postcode at www.freeview.co.uk

Please note that any Freeview HD channels found during

tuning will be placed in channel positions above 100.

For example, 101 (BBC1 HD) 102 (BBC2 HD) etc.

Auto Tuning - Allows you to retune the television for all digital channels, digital radio stations and

analogue devices.

Analogue Manual Tuning - Allows you to manually tune your analogue signal.

Freeview Manual Tuning - Allows you to manually tune your digital signal.

Channel Edit - Allows you to delete, move, skip and favourite channels.

Signal Information - Allows you to view signal frequency, signal quality and signal strength.

CI Information - Pay per view services require a “smartcard” to be inserted into the TV. If you subscribe to

a pay per view service the provider will issue you with a ‘CAM’ and a “smartcard”. The CAM can then be

inserted into the COMMON INTERFACE PORT (CI Card In).

Schedule List - Lists your programme reminders.

Software Update (OAD) - Switch on/off OAD updates.

User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:20User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:20 09/06/2017 11:19:5509/06/2017 11:19:55

2121

TV Menu Operation

LOCK MENU

To access this menu, press [MENU] button on the remote control and scroll right.

To select a sub menu press [OK]

If you wish to make changes to any of the default settings, use the scroll buttons.

To conﬁrm any settings press [OK] button. To exit this menu at anytime, press [EXIT] button.

System/Hotel Lock - Allows you to lock or unlock the menu. You will be asked to enter a 4 digit password

Use the ◄button to quit the password input or use the ► button to clear. Default password is 0000.

Change Password - Allows you to change the password.

Channel Lock - Allows you to lock certain channels manually.

Parental Guidance - Allows you to set the rating to block certain content based on age information.

TV Button Lock - Allows you to lock the buttons on the side of the TV set.

Default Source - Allows the user to set the default source. The default source is the source the TV starts on

when ﬁrst switched on.

Default Channel - Allows the user to set a channel as the default channel on the Digital source. The

default channel is the channel the TV starts on when ﬁrst switched on.

Max Volume - Allows you to adjust and set the maximum volume.

Source Lock - Allows you to lock the source menu.

User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:21User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:21 09/06/2017 11:19:5609/06/2017 11:19:56

TV Menu Operation

TIME MENU

Auto Sync - Automatically syncs time and date.

Clock - Shows the date and time.

Off Time - Allows you to set a speciﬁc time for your TV to turn off.

On Time - Allows you to set a speciﬁc time for your TV to turn on, the channel it will then display, the

source it will be on and also the volume. This function can then be toggled to repeat every day or

a certain day.

Sleep Timer - Lets you set the sleep timer so the television automatically switches off after a set amount of

time. Off -> 10min -> 20min -> 30min -> 60min -> 90min -> 120min -> 180min -> 240min.

OSD Timer - Lets you adjust the amount of time the On Screen Menu stays on the screen before

disappearing.

Auto standby - Set Auto standby between Off, 3 hours, 4 hours and 5 hours.

Time Zone - Change your current time zone.

To access this menu, press [MENU] button on the remote control and scroll right.

To select a sub menu press [OK]

If you wish to make changes to any of the default settings, use the scroll buttons.

To conﬁrm any settings press [OK] button. To exit this menu at anytime, press [EXIT] button.

User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:22User Guide - Blaupunkt - 32-138O-GB-11B4-EGDP-UK - BLA-MAN-0368.indd Sec1:22 09/06/2017 11:19:5609/06/2017 11:19:56
