BLODGETT
www.blodgett.com
1100 Old Honeycutt Road Fuquay-Varina, NC 27526 USA
Phone: [phone] • Fax: [phone]
SPECIFY
Gas Type Natural Gas Propane
Manifold Front (1-1/4”) Rear (1”)
Flue Riser Height 5” 24” (option) 36” (option)
Range Depth Standard Deep (option)
Position in Battery Left End Right End Not at End
Operating altitude (if above 2000 ft (700 meters) _____________________
Blodgett can often accommodate special or custom requirements. Contact your
Blodgett representative.
STANDARD FEATURES (All models)
Two open-top 35,000 BTU burners with separate controls
Removable welded grates
5” flue riser
7" stainless-steel front rail with “belly bar”
Standard range depth
Battery end-units have solid side (no manifold cover plate)
Stainless-steel front and sides
Fully insulated lining and burner boxes
6" adjustable legs (except on modular range-top model)
Warranty: two year parts and labor from date of purchase
STANDARD FEATURES (Base Cabinets)
Stainless-steel door
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Flue riser
24”
36”
Single-shelf (mounts on 24” flue riser)
Solid shelf
Tubed shelf
Double-shelf (mounts on 36” flue riser)
Solid shelves
Tubed shelves
Stainless-steel back
Deep range depth
Bolt down flange feet
Casters (in lieu of legs)
Open frame base with casters
Cable restraint kit for units on casters
B12-B
12” Heavy Duty Sectional Range with
Two Open-Top 35K BTU Burners
MODEL B12-B
Project
Item No.
Quantity
Model B12C-B (Cabinet Base)
Model B12N-B (Modular Range-Top)
The Blodgett 12"-wide sectional-range with two open-top burners is avail-
able with a either a storage cabinet or with no base (for mounting as a
modular range-top). Three flue-riser heights are available, and the flue riser
can support up to 250 lbs for an optional shelf. An optional rearward-
extending flue riser is available to increase the overall depth to match a
deep battery. Battery-design assistance is available!
Model B12C-B with 24” Flue Riser

BLODGETT
www.blodgett.com
1100 Old Honeycutt Road Fuquay-Varina, NC 27526 USA
Phone: [phone] • Fax: [phone]
MODEL B12-B
SHORT FORM SPECIFICATIONS
The item shall be a 12"-wide front-manifold sectional range with two 35,000 BTU open-top burners with two removable welded grates. The item shall have a 7" front rail and a belly bar.
The item shall have 6" adjustable legs [casters]. The item shall have a [5" 24" 36"] flue riser able to support 250 pounds. The exterior (except for the back) shall be constructed of 430
stainless steel #3 polish. If the item is at the end of a battery, the end side shall be solid (rather than have a coverplate over the end of the front manifold).
Model B12C-B: The item shall have a cabinet base with stainless steel door.
Printed in U.S.A. NOTE: FOR COMMERCIAL USE ONLY
NOTE: The company reserves the right to make substitutions of components without prior notice
APPROVAL/STAMP
P/N BR00023 Rev C (7/07)
OTHER TECHNICAL INFORMATION
Exterior surfaces are 430 stainless steel #3 polish, except the back is aluminized steel.
Each burner has a separate control knob located on the front panel.
Check local codes for fire and sanitary regulations.
UTILITY INFORMATION GAS: Each unit has a 1-1/4" front gas manifold that couples to the adjacent sectional unit(s), and can be ordered with a 1" rear
gas connection with a male NPT connector. Minimum supply pressure is 7" W.C. for natural gas, 11" W.C. for propane. An exter-
nal pressure regulator and shut off valve must be provided. If using a flexible-hose gas connection, the I.D. of the hose must not
be smaller than the connector on the unit and must comply with ANSI Z21.69. Provide an adequate means of restraint to prevent
undue strain on the gas connection.
FLUE EXHAUST: Installation under a vented hood is recommended.
MODEL
GAS (BTU/hr)
Natural Gas Propane
B12N-B 70,000 60,000
B12C-B 70,000 60,000
