Blomberg LDF30110W User manual

www.blomberginternational.com
[email protected]
Dishwasher
User manual
LDF30110W

Dishwasher
User manual
LDF30110W

Explanation of symbols
Throughout this User Manual the following symbols are used:
CImportant information or
useful hints about usage.
AWarning for hazardous
situations with regard to life
and property.
BWarning for electric shock.
Packaging materials of the
product are manufactured
from recyclable materials
in accordance with our
National Environment
Regulations.
Do not dispose of the packaging materials together with the domestic or other
wastes. Take them to the packaging material collection points designated by
the local authorities.
Please read this user manual first!
Dear Customer,
We hope that you get the best results from your product which has been
manufactured with high quality and state-of-the-art technology. Therefore,
please read this entire user manual and all other accompanying documents
carefully before using the product and keep it as a reference for future use.
If you handover the product to someone else, give the user manual as well.
Follow all warnings and information in the user manual.
Remember that this user manual is also applicable for several other models.
Differences between models will be identied in the manual.

CONTENTS
1 INSTRUCTIONS FOR SAFETY
AND ENVIRONMENT 4
General safety ...........................................4
Intended use..............................................5
Children’s safety ........................................5
Disposing of packaging material................5
Transportation of the product ....................5
Compliance with WEEE Directive and
Disposing of the Waste Product ................6
Compliance with RoHS Directive...............6
Package information..................................6
2 DISHWASHER 7
Overview....................................................7
Technical specications.............................8
3 INSTALLATION 9
Appropriate installation location.................9
Connecting water supply ...........................9
Connection to the drain ...........................10
Adjusting the feet.....................................10
Electrical connection................................10
This appliance must be earthed .............. 11
Fitting a different plug..............................11
Initial use .................................................11
4 PREPARATION 12
Tips for energy saving .............................12
Water softening system ...........................12
Adjusting the water softening system......12
Adding salt...............................................14
Detergent.................................................15
Tablet detergents.....................................16
Rinse aid..................................................17
Items not suitable for washing in the
dishwasher ..............................................17
Placing the dishes into the dishwasher ...18
Collapsible lower basket tines .................20
Cutlery basket .........................................20
Adjusting the height of the upper basket .21
Upper basket multipurpose service rack .22
Upper basket height adjustable rack .......22
5 OPERATING THE PRODUCT23
Keys.........................................................23
Preparing the machine ............................23
Programme selection...............................23
Auxiliary functions....................................25
Starting the programme...........................25
Programme follow-up ..............................26
Cancelling the programme ......................26
Salt indicator............................................26
Rinse Aid indicator...................................26
Adjusting the amount of rinse aid ............27
End of programme...................................27
6 MAINTENANCE AND
CLEANING 28
Cleaning the outer surface of the product28
Cleaning the interior of the machine........28
Cleaning the lters...................................28
Cleaning the hose lter............................29
Cleaning the impellers.............................30
Lower impeller .........................................30
Upper impeller ........................................30
7 TROUBLESHOOTING 31
8 GUARANTEE 36
Guarantee Details....................................36

4Dishwasher / User manual
/40 EN
Instructions for safety and envIronment
1
This section contains safety
instructions that will help to
give protection from risk of
personal injury or property
damage. Failure to follow
these instructions shall void
all warranties.
General safety
• Never place the product
on a carpet-covered oor;
otherwise, lack of airow
beneath the product will
cause electrical parts
to overheat. This will
cause problems with your
product.
• Do not operate the product
if the power cable / plug
is damaged! Call the
Authorised Service Agent.
• Connect the product to a
grounded outlet protected
by a fuse complying
with the values in the
“Technical specications”
table. Do not neglect
to have the grounding
installation made by a
qualied electrician. Our
company shall not be
liable for any damages
that will arise when the
product is used without
grounding in accordance
with the local regulations.
• The water supply and
draining hoses must be
securely fastened and
remain undamaged.
• Unplug the product when
not in use.
• Never wash the product by
spreading or pouring water
onto it! There is the risk of
electric shock!
• Never touch the plug
with wet hands! Never
unplug by pulling on the
cable, always pull out by
grabbing the plug.
• The product must
be unplugged during
installation, maintenance,
cleaning and repairing
procedures.
• Always have the repair
procedures carried out by
the Authorised Service
Agent. Manufacturer
shall not be held liable for
damages that may arise
from procedures carried
out by unauthorised
persons.
• Never use chemical
solvents in the product.
They bring forth the risk of
explosion.
• When you pull the upper
and lower baskets out
completely, the door of
the product will bear all
the weight of the baskets.
Do not put other loads on
the door; otherwise, the
product may tilt.
• Never leave the door
of the product open
apart from loading and
unloading procedures.
• Do not to open the door
of the product when it is
running unless necessary.
Be careful for the rush of
hot steam when you need
to open the door.

Dishwasher / User manual 5 / 40 EN
Instructions for safety and envIronment
Intended use
• This product has been
designed for domestic
use.
• It must be used to do the
domestic type dishes only.
• This appliance is intended
to be used in household
and similar applications
such as:
- Staff kitchen areas in shops,
ofces and other working
environments.
• Only dishwasher safe
detergents, rinse aids and
additives must be used.
• The manufacturer waives
any responsibility arisen
from incorrect usage or
transportation.
• This appliance can be
used by children aged
from 8 years and above
and persons with reduced
physical,sensory or
mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use
of the appliance in a safe
way and understand the
hazards involved. Children
shall not play with the
appliance. Cleaning and
user maintenance shall
not be made by children
without supervision.
Children’s safety
• Electrical products are
dangerous for the children.
Keep children away from
the product when it is in
use. Do not let them to
tamper with the product.
• Do not forget to close the
door of the product when
leaving the room where it
is located.
• Store all detergents and
additives in a safe place
away from the reach of the
children.
Disposing of packaging
material
Packaging materials are
dangerous to children. Keep
packaging materials in a safe
place away from reach of the
children.
Packaging materials of the
product are manufactured
from recyclable materials.
Dispose of them properly
and sort in accordance with
recycled waste instructions.
Do not dispose of them with
normal domestic waste.
Transportation of the
product
AIf you need to move
the product, do it
in upright position
and hold from the
rear side. Tilting
the product onto its
front side may cause
the electronic parts
in it get wet and
damaged.

6Dishwasher / User manual
/40 EN
Instructions for safety and envIronment
1. Unplug the product before
transporting it.
2. Remove water drainage
and water supply
connections.
3. Drain the remaining water
in the product completely.
Compliance with WEEE
Directive and Disposing
of the Waste Product
This product complies
with EU WEEE Directive
(2012/19/EU). This
product bears a
classication symbol for
waste electrical and electronic
equipment (WEEE).This
product has been
manufactured with high
quality parts and materials
which can be reused and are
suitable for recycling. Do not
dispose of the waste product
with normal domestic and
other wastes at the end of its
service life. Take it to the
collection center for the
recycling of electrical and
electronic equipment. Please
consult your local authorities
to learn about these collection
centers.
Compliance with RoHS
Directive
The product you have
purchased complies with EU
RoHS Directive (2011/65/EU).
It does not contain harmful
and prohibited materials
specied in the Directive.
Package information
Packaging materials of the
product are manufactured
from recyclable materials in
accordance with our National
Environment Regulations. Do
not dispose of the packaging
materials together with the
domestic or other wastes.
Take them to the packaging
material collection points
designated by the local
authorities.

Dishwasher / User manual 7 / 40 EN
Dishwasher
2
Overview
1. Upper basket
2. Upper impeller
3. Lower impeller
4. Silverware basket
5. Door
6. Rating Label
7. Control panel
8. Detergent dispenser
9. Lower basket
10. Filters
11. Salt reservoir lid
12. Upper basket rail
13. Upper cutlery basket (depends on model)
14. Tabletop (depends on model)
15. Fan drying system (depends on model)
15

8Dishwasher / User manual
/40 EN
Dishwasher
Technical specifications
Compliance to standards and test data / EC declaration of conformity
This product complies with the following EU directives;
Development, production and sales stages of this product comply with the
safety rules included in all pertaining European Community regulations.
2014/35/EU, 2014/30/EU, 93/68/EC, IEC 60436/DIN 44990, EN 50242
Power input 220-240 V, 50 Hz (see rating label)
Total power consumption 1800-2100 W (see rating label)
Heater power consumption 1800 W (see rating label)
Total current (depends on the model) 10 A (see rating label)
Drain pump power consumption 30 W (see rating label)
Water pressure 0.3 –10 bar (= 3 – 100 N/cm² = 0.01-
1.0 Mpa)
CTechnical specications may be changed without prior notice to
improve the quality of the product.
CFigures in this manual are schematic and may not match the product
exactly.
CValues stated on the markings of the product or in the printed
documents accompanying the product are obtained in the laboratory
on basis of the relevant standards. Depending on operational and
environmental conditions of the product, these values may vary.
Note for test institutions:
Data required for performance tests shall be provided upon request. Requests
can be e-mailed to the following address:
[email protected]
Do not forget to provide the code, stock and serial numbers of the product to be
tested in your request e-mail along with your contact information. Code, stock and
serial numbers of the product may be found on the type label attached to the side
wall of the door.

Dishwasher / User manual 9 / 40 EN
3Installation
To make the product ready for use,
make sure that the electricity, tap
water supply and water drainage
systems are appropriate before calling
the Authorised Service Agent. If they
are not, call a qualied technician
and plumber to have any necessary
arrangements carried out.
CPreparation of the location
and electrical, tap water and
waste water installations
at the place of installation
is under customer's
responsibility.
BManufacturer shall not
be held responsible for
damages arising from
processes carried out by
unauthorised persons.
APrior to installation, visually
check if the product has any
defects on it. If so, do not
have it installed. Damaged
products cause risks for
your safety.
CMake sure that the water
inlet and discharge hoses
are not folded, pinched or
crushed while pushing the
product into its place after
installation or cleaning
procedures.
When placing the product, pay
attention not to damage the oor, walls,
piping, etc. Do not hold the product
from its door or panel to move it.
Appropriate installation
location
• Place the product on a solid and
at oor that has sufcient load
carrying capacity! The product
must be installed on a at surface
in order for the door to be closed
comfortably and securely.
• Do not install the product at places
where temperature may fall below
0ºC.
• Place the product on a rigid oor.
Do not place it on a long pile rug
or similar surfaces.
BEnsure the power cable
does not get trapped under
the product.
• Make sure that you select a
location that will allow you to load
and unload the dishes in a fast
and comfortable manner.
• Install the product in a place close
to the tap and the drain. Select the
installation location by considering
that it will not be changed after the
connections are made.
Connecting water supply
• Do not use old or used water inlet
hose on the new product. Use the
new water inlet hose supplied with
the product.
• Connect the water inlet hose
directly to the cold water tap.
Permitted water temperature up
to 25°C. Pressure coming from
the tap should be minimum 0.3
and maximum 10 bars. If the
water pressure exceeds 10 bars,
a pressure relief valve should be
installed in between.
• Open the tap completely after
making the connections to check
for water leaks.

10 Dishwasher / User manual
/40 EN
Installation
AFor your safety, close the
water inlet tap completely
after the washing
programme is over.
Connection to the drain
Water discharge hose can directly be
connected to the drain hole or sink’s
drainage. The length of this connection
must be min. 50 cm and max. 100 cm
from the oor. A discharge hose longer
than 4 meters will cause washing
performance to be affected.Attach the
water discharge hose to the drainpipe
without bending it. Tightly x the water
discharge hose to the drainpipe in
order to prevent any dislocation of the
water discharge hose during operation
of the product.
min 300
min 120
max 1000
min 500
CDrainpipe must be
connected to the foul water
system and it should not be
connected to any surface
water drain.
Adjusting the feet
If the door of the product cannot
be closed properly or if the product
wobbles when you push it slightly,
then you need to adjust the feet of the
product. Adjust the feet of the product
as illustrated in the relevant section.
ADiswashers door must be
aligned properly otherwise
hot steam can escape!
Danger of serious burns,
other injury or may damage
furniture.
Electrical connection
Before you insert the plug into the wall
socket make sure that the voltage and
the frequency shown in the rating label
corresponds to your electricity supply.
We recommend that this appliance be
connected to the mains supply via a
suitable switched and fused socket in a
readily accessible position.
If the supply cord or the mains lead
is damaged please do not replace it
yourself. The supply cord or the mains
lead must be replaced by a Authorised
Service Agent or a similarly qualied
person.

Dishwasher / User manual 11 / 40 EN
Installation
2. Connect the blue (neutral) wire to
the terminal in the plug marked ‘N’ or
coloured black.
3. Connect the brown (live) wire to the
terminal in the plug marked ‘L’ or
coloured red.







With the alternative plugs a 13A fuse must
be tted either in the plug or adaptor or
in the main fuse box. If in doubt contact a
qualied electrician.
Initial use
Before starting to use the product, make
sure that all preparations are made
in accordance with the instructions in
sections “Important safety instructions”
and “Installation”.
• Before using the product, ll the salt
reservoir with 1 litre of water, add salt
(see next page) and stir to dissolve.
Run the Dishwasher without dishes
on a short programme with a small
amount of detergent.
AThere might be a small
amount of water left in the
product after factory quality
control tests. This causes no
harm to the product.
AThis appliance must
be earthed
If the tted moulded plug is
not suitable for your socket,
then the plug should be cut
off and an appropriate plug
tted.
Destroy the old plug, which
is cut off as a plug with a
bared cord could cause a
shock hazard if inserted into
a socket elsewhere in the
house.
The moulded plug on this
appliance incorporates a
13A fuse. Should the fuse
need to be replaced an
ASTA approved BS1362
fuse of the same rating must
be used. Do not forget to
ret the fuse cover. In the
event of losing the fuse
cover, the plug must not be
used until a replacement
fuse cover has been tted.
Colour of the replacement
fuse cover must be the
same colour as that visible
on the pin face of the plug.
Fuse covers are available
from any good electrical
store.
Fitting a different plug
As the colours of the wires in the
mains lead of this appliance may not
correspond with the coloured markings
identifying the terminals on your plug,
proceed as follows:
1. Connect the green - yellow or
green (earth) wire to the terminal
in the plug marked ‘E’ or with the
symbol or coloured green
and yellow or green.

12 Dishwasher / User manual
/40 EN
Preparation
4
Tips for energy saving
Following information will help you
use the product in an ecological and
energy-efcient manner.
Wipe away any coarse food remnants
on the dishes before putting them in
the product.
Operate the product after lling it
completely.
When selecting a programme, consider
the table of "Programme data and
average consumption values".
Do not put more detergent than
suggested on the detergent package.
Water softening system
The product is equipped with a water
softening system which reduces the
hardness of incoming water. This
system softens the supply water to a
level that will allow washing the dishes
with the required quality.
CThe mains water hardness
must be softened if it is over
7°dH. Otherwise, hardness
ions will accumulate
on the dishes that are
washed and may affect
the washing, rinsing and
drying performances of the
machine.
Adjusting the water softening
system
Cleaning, rinsing and drying
performance of your dishwasher will
increase when water softening system
is adjusted properly.
Adjust the new water hardness level
according to the Water hardness level
instruction in this booklet.
Use the test strip supplied with the
product according to the steps given
below to determine hardness level of
your supply water.

Dishwasher / User manual 13 / 40 EN
Preparation
Remove the test
strip from the
packet.
Turn on the tap and
let the water run for
about a minute.
Hold the test strip in
the water for about
a second.
Remove the test
strip from the water
and shake it.
Wait for 1 minute. The test strip shows
you the hardness
level.
After determining hardness level of the supply water:
1. When the Programme Selection key is at “Off” position, keep Start/Pause/Cancel
key pressed and turn the Programme Selection key to position “1” within 5 seconds.
Machine will enter into the regeneration adjustment mode at the end of this period.
2. Regeneration level in the memory will be illuminated for 5 seconds when the
regenerator adjustment mode is activated.
3. To adjust the new Water Hardness Level, move the Programme Selection key
to the position that is suitable for your supply water. (see, “Water Hardness Level
Adjustment Table”)
4. Press Start/Pause/Cancel key for once to store the level you have selected.
Machine returns to the normal operating mode after the new setting is stored.
* Programme Selection key rotates in 5 steps regardless of the number of the
programmes contained on the machine.
5. Press “Start/Pause/Cancel” key for once to store the level you have selected.
Water hardness level adjustment table
Hardness
Level
English Water
Hardness °dE
German Water
Hardness °dH
French Water
Hardness °dF
Position of
Program
Selection Key*
Water Hardness Level Indicator
0th Level 0-5 0-4 0-8 1 Washing lamp on the panel will
illuminate.
1st Level 6-9 5-7 9-13 1
2nd Level 10-15 8-12 14-22 2 Drying lamp on the panel will
illuminate.
3rd Level 16-19 13-15 23-27 3 End lamp on the panel will illuminate.
4th Level 20-24 16-19 28-34 4 Washing, Drying and End lamps on
the panel will illuminate.
5th Level 25-62 20-50 35-90 5
Washing, Drying and End lamps on
the panel will ash with an interval of
1 second.
If the hardness level of the supply water is above 90 °dF or if you are using well
water, then it is recommended to use water purication devices and special lters.
If the hardness level of the supply water is below 13°dF, there is no need to use salt
in your dishwasher. If this is the case, “No Salt Warning Indicator” (if any) illuminates
continuously on the panel of your machine.
If the water hardness level adjustment is set to level 1, the “No salt warning indicator”
will illuminate continuously although it is not necessary to use salt. If you use
salt under this condition, salt will not be consumed and the Salt indicator will not
illuminate.

14 Dishwasher / User manual
/40 EN
Preparation
CIf you move your house,
it is necessary to readjust
water hardness level of your
machine by considering the
information given above
according to the hardness
level of the supply water
in your new location. Your
machine will display the
most recently adjusted water
hardness level.
Adding salt
Water softening system needs to be
regenerated in order for the product
operates with the same performance
continuously. Dishwasher salt is used
for this purpose.
CUse only special softening
salts produced particularly
for the dishwashers in your
machine.
CIt is recommended to use
granule- or powder-formed
softening salts in the
water softening system.
Do not use salts that do
not completely dissolve in
water such as table salt or
rock salt. Otherwise the
performance of the system
may deteriorate in time.
CSalt reservoir will be lled
with water when you start
the product. For this reason,
add salt before operating the
machine.
1. Firstly, take the lower basket out to
add softening salt.
2. Turn the salt reservoir lid counter-
clockwise to open it (A).
3. Add 1 litre of water to salt reservoir
of your machine only in initial use.
4. Fill the salt reservoir with salt by
using the salt funnel (D). To speed
up dissolution rate of salt in water,
stir it with a spoon.
CYou can put about 2 kg of
softening salt into the salt
reservoir.
5. Replace the lid and tighten it when
the reservoir is full.
CYou need to add salt right
before starting the machine.
Thus, the overowing
salty water will be ushed
immediately, preventing
the risk of corrosion in
machine. In cases where
you would not start washing
immediately, run your
machine empty in the
shortest program.

Dishwasher / User manual 15 / 40 EN
Preparation
CSince different salt brands
in the market have different
particle sizes and since the
water hardness may vary,
dissolution of the salt in
water may take a couple
of hours. Therefore, Salt
Indicator remains on for a
while after adding salt into
the machine.
Detergent
You can use powder, liquid/gel or tablet
detergents in the machine.
AOnly use in the machine
the detergents produced
particularly for use
with dishwashers. We
recommend you not to use
detergents that contain
chlorine and phosphate
as they are harmful for the
environment.
Adding detergent
CPay attention to the
warnings on the detergent
packaging to get better
washing and drying results.
Contact the manufacturer
of the detergent for further
questions.
ADo not put solvents into the
detergent dispenser. There
is the risk of explosion!
Put the detergent into the detergent
dispenser just before operating the
machine as illustrated below.
1. Push the latch to right to open the
detergent dispenser lid (A).
2. Put suggested amount of powder,
liquid/gel or tablet detergent in the
reservoir.
CInside the detergent
dispenser there are level
markings that help you
use appropriate amount of
powder detergent. When
brimful, detergent dispenser
will contain 45 cm³ of
detergent. Fill detergent up
to 15 cm³ or 25 cm³ level
marks in the detergent
dispenser according to
fullness of the machine and/
or soiling degree of the
dishes. One tablet is enough
if you are using detergent
tablets.

16 Dishwasher / User manual
/40 EN
Preparation
Water softening salt and rinse aid
must also be used together with the
detergent if the water hardness level is
above the mentioned level.
CThe best washing
performance in dishwashers
is obtained by using
detergent, rinse aid and
water softening salt
individually.
CObserve the instructions of
the detergent manufacturer
on the package when using
tablet detergents.
CContact the detergent
manufacturer if your dishes
are wet and/or if you notice
limescale spots particularly
on your glasses after the
washing programme is
over when using a tablet
detergent.
When you switch to powder
detergent from tablet detergent:
1. Make sure that salt and rinse aid
reservoirs are full.
2. Set the water hardness to the
highest level and perform an empty
run.
3. After the empty washing cycle,
review the user manual and
3. Push the lid of the detergent
dispenser to close it. A "click" will
be heard when the lid is closed.
1
2
3
CUse powder or liquid/
gel detergent in short
programmes without
prewash since the solubility
of the tablet detergent
changes depending on the
temperature and time.
Tablet detergents
In addition to the conventional
tablet detergents, there are also
commercially available detergent
tablets that show water softening salt
and/or rinse aid effect. Some types
of these detergents contain special-
purpose components such as glass
and stainless steel protectors. These
tablets show their effects up to a
certain water hardness level (21°dH).

Dishwasher / User manual 17 / 40 EN
Preparation
3. Slightly press the point (B) of the
reservoir lid to close it.
4. If there are stains on tableware
items after washing, level must
be increased and if there is a blue
trace after wiping them by hand, it
must be decreased. This is set to
position 3 as factory default.
CThe rinse aid adjustment is
described under "Adjusting
the amount of rinse aid" in
the section for operating the
machine.
CWipe clean any spilled
rinse aid outside the
reservoir. Rinse aid that
spilled accidentally will
cause foaming and it will
eventually decrease washing
performance.
Items not suitable for washing
in the dishwasher
• Never wash dishes soiled by
cigarette ash, candle remnants,
polish, dyestuff, chemicals, etc. in
your dishwasher.
• Do not wash silverware and
cutlery with wooden or bone
stems, glued pieces, or pieces that
are not resistant to heat, as well as
copper and tin-plated containers in
the dishwasher.
readjust the water hardness level
so as to suit the water supply.
4. Make the appropriate rinse aid
settings.
Rinse aid
CThe rinse aid used in
dishwashers is a special
combination that aims to
increase drying efciency
and prevent water or lime
stains on the washed items.
For this reason, care must
be paid to have rinse aid in
the rinse aid reservoir and
to use rinse aids produced
specially for dishwashers
only.
1. Open the lid of the rinse aid
reservoir with the help of the latch.
2. Fill the reservoir until “MAX” level.

18 Dishwasher / User manual
/40 EN
Preparation
CDecorative prints of
chinaware as well as
aluminum and silver items
may get discoloured or
tarnished after washing in
the dishwasher just as it
happens in handwashing as
well. Some delicate glass
types and crystals may
become dull in time. We
strongly recommend you
to check if the tableware
you are going to purchase
is suitable for washing
especially in the dishwasher.
Placing the dishes into the
dishwasher
You can use your dishwasher in the
optimum way with respect to energy
consumption and washing and drying
performance only if you place the dishes
in an orderly way.
• Wipe away any coarse food
remnants (bones, seeds, etc.) on
the dishes before placing them in
the dishwasher.
• Place thin, narrow pieces in the
middle sections of baskets if
possible.
• Place the heavily soiled and bigger
items in the lower basket and
smaller, delicate and light items in
the upper basket.
• Place the hollowed dishes such as
bowls, glasses and pans upside
down in the dishwasher. Thus,
accumulation of water in deep
hollows is prevented.
ATo prevent possible injuries,
always place the sharp and
pointed dishes such as
service fork, bread knife,
etc. upside down so as their
pointed ends will face down
or they will lie horizontally in
the dish basket.
Unload dishes in the lower basket
rst and then the dishes in the upper
basket.

Dishwasher / User manual 19 / 40 EN
Preparation
Suggestions for loading the dishwasher
Lower basket
Upper basket
Improper Loading Of Dishware
Improper Loading Of Dishware
