Over The Range Convection
Microwave Oven
Installation Manual
BOTR30200CSS
EN FR
Document number : 01M-8851303800-3516-02

Ths product has been manufactured n envronmental frendly modern plants wthout gvng any harm to the nature.
Please read this manual first!
Dear Customers!
Thank you for preferring a Blomberg product. We hope that you get the best results
fromyourproductwhichhas beenmanufactured withhigh qualityandstate-of-the-art
technology. Therefore, please read this entire user manual and all other accompanying
documents carefully before using the product and keep it as a reference for future use.
If you handover the product to someone else, give the user manual as well. Follow all
warnings and information in the user manual.
Meanings of the Symbols
Following symbols are used in the various section of this manual:
C
Important information and useful hints about
usage.
AWARNING:
Warnings for dangerous situa-
tions concerning the safety of life and property.
B
Warning for electric shock.
Warning for hot surfaces.

3 / 63 EN
Over The Range Convection Microwave Oven / Installation Manual
CONTENTS
1 Important instructions 4
1.1 General safety........................................................... 4
1.1.1 Electrical safety......................................................5
2 Your over the range convection
microwave oven 6
2.1 Overview..................................................................... 6
2.2 Technical data.......................................................... 6
3 Mounting space 7
4External exhaust 8
4.1 Installing hood exhaust........................................ 8
4.1.1 Outside top exhaust (example only)........... 8
4.1.2 Outside back exhaust (example only)........ 9
4.1.3 Exhaust connection........................................... 9
4.1.4 Maximum duct length.....................................10
4.1.5 Elbows, transitions, wall and
roof caps, etc.,................................................................10
4.2 Damage – Shipment / Installation..................11
4.3 Parts Included .........................................................11
4.3.1 Hardware packet ................................................11
4.3.2 Additional parts................................................. 12
4.4 Tools and Materials Needed ............................ 13
5 Installation 14
5.1 Placement of the Mounting Plate ..................14
5.1.1 Removing the microwave oven from the
carton/ removing the mounting plate................. 14
5.1.2 Finding the wall studs .....................................14
5.1.3 Determining wall plate location
under your cabinet ......................................................14
5.1.4 Aligning the wall plate.....................................16
5.2 Installation Types (Choose A, B or C) ............ 17
5.2.1 Outside Top Exhaust (Vertical Duct) ......... 17
5.2.2 Outside Back Exhaust (Horizontal Duct).23
5.2.3 Recirculating (non-vented ductless) ........28
6 How to use the product 32

Over The Range Convection Microwave Oven / Installation Manual
4 / 63 EN
1 Important instructions
1.1 General safety
C
Read and save these in-
structions
Doing so will:
•make installation easier.
•help you in the future if you have
questions.
•help if you have an electrical in-
spection.
Call your dealer when you have
questions or need service. When
you call, you will need the micro-
wave model and serial numbers.
A
WARNING: To reduce
the risk of fire, electric
shock, or injury to per-
sons, always exercise ba-
sic safety precautions, in-
cluding the following:
Read all instructions before using
the appliance.
This product requires a three-prong
grounded outlet. The installer must
perform a ground continuity check
on the power outlet box before
beginning the installation to in-
sure that the outlet box is properly
grounded.
If not properly grounded, or if the
outlet box does not meet elec-
trical requirements noted (under
ELECTRICAL REQUIREMENTS), a
qualified electrician should be em-
ployed to correct any deficiencies.
For personal safety, remove house
fuse or open circuit breaker before
beginning installation to avoid se-
vere or fatal shock injury.
For personal safety, the mounting
surface must be capable of sup-
porting the cabinet load, in addition
to the added weight of this 63–85
pound (28.5–38.5 kg) product, plus
additional oven loads of up to 50
pounds (22.7 kg) or a total weight of
113–135 pounds (51.3–61.2 kg).
For personal safety, this product
cannot be installed in cabinet ar-
rangements such as an island or a
peninsula. It must be mounted to
BOTH a top cabinet AND a wall.
For easier installation and personal
safety, it is recommended that two
people install this product.
For personal safety, this appliance
must be properly grounded to avoid
severe or fatal shock.

5 / 63 EN
Over The Range Convection Microwave Oven / Installation Manual
1 Important instructions
The power cord of this appliance
is equipped with a three-prong
(grounding) plug which mates with
a standard three-prong (grounding)
wall receptacle to minimize the pos-
sibility of electric shock hazard from
this appliance.
Do not, under any circumstances,
cut, deform or remove any of the
prongs from the power cord. Do not
use with an extension cord.
1.1.1 Electrical safety
Product rating is 120 volts AC, 60
Hertz, 15 amps and 1500 watts.
This product must be connected to
a supply circuit of the proper volt-
age and frequency.
Wire size must conform to the re-
quirementsoftheNationalElectrical
Code or the prevailing local code for
this kilowatt rating. The power sup-
ply cord and plug should be brought
to a separate 15- to 20- ampere
branch circuit single grounded out-
let. The outlet box should be located
in the cabinet above the microwave
oven. The outlet box and supply cir-
cuit should be installed by a quali-
fied electrician and conform to the
National Electrical Code or the pre-
vailing local code.

Over The Range Convection Microwave Oven / Installation Manual
6 / 63 EN
2 Your over the range convection microwave oven
2.1 Overview
2.2 Technical data
Product Dimensions
A-Height 15.7  (39.9 cm)
B-Width 29.9  (75.9 cm)
C-Depth 15.0  (38.1 cm)
B
A
C
Cutout Dimensions
Height (Min.) 16.75  (42.5 cm)
Height (Max.) 17.0  (43.2 cm)
Width (Min.) 30.0  (76.2 cm)
Depth (Min.) 12.0  (30.5 cm)
Depth (Max.) 13.0  (33.0 cm)

7 / 63 EN
Over The Range Convection Microwave Oven / Installation Manual
3 Mounting space
Bottom Edge of
Cabinet Needs to
be 30 (76.2 cm)
or More from the
Cooking Surface
Backsplash
66 (167.6 cm)
or More from
the Floor to the
Top of the
Microwave
30
“(76.2 cm)
2“ (5.1 cm)
30“
(76.2 cm)
min.
163⁄4“ (42.5 cm)
[12“ (30.5 cm) min.]
C
The space between the cabinets
must be 30“ (76.2 cm)wide and free
of obstructions.
C
If you are going to vent your micro-
wave oven to the outside, see Hood
Exhaust Section for exhaust duct
preparation.
C
When installing the microwave oven
beneath smooth, flat cabinets, be
careful to follow the instructions on
the top cabinet template for power
cord clearance.

Over The Range Convection Microwave Oven / Installation Manual
8 / 63 EN
4 External exhaust
4.1 Installing hood exhaust
C
Read these instructions only if you
plan to vent your exhaust to the out-
side. If you plan to recirculate the air
back into the room, proceed to title 5
4.1.1 Outside top exhaust
(example only)
The following chart describes an example of one
possible ductwork installation.
Duct pieces Equivalent
Length
x
Number
used
=
Equivalent
Length
Roof Cap 24 Ft. (7.3 m) x (1) = 24 Ft. (7.3 m)
12 Ft. (3.6 m)
Straight Duct
(6”/15.2 cm
Round)
12 Ft. (3.6 m) x (1) = 12 Ft. (3.6 m)
Rectangular-to-
Round
Transition Adap-
tor*
5 Ft. (1.5 m) x (1) = 5 Ft. (1.5 m)
Equivalent lengths of duct pieces are based on actual tests
and reflect requirements for good venting performance
with any vent hood.
Total Length = 41 Ft. (12.5 m)
C
If a rectangular-to-round transition
adaptor is used, the bottom corners
of the damper will have to be cut to
fit, using the tin snips, in order to al-
low free movement of the damper.

9 / 63 EN
Over The Range Convection Microwave Oven / Installation Manual
4 External exhaust
4.1.2 Outside back exhaust
(example only)
The following chart describes an example of one
possible ductwork installation.
Duct pieces Equivalent
Length
x
Number
used
=
Equivalent
Length
Wall Cap 40 Ft. (12.2 m) x (1) = 40 Ft. (12.2 m)
3 Ft. Straight
Duct (31⁄4” x
10”/8.2 x 25.4
cm Rectangular)
3 Ft. (0.9 m) x (1) = 3 Ft. (0.9 m)
90° Elbow 10 Ft. (3 m) x (2) = 20 Ft. (3 m)
Equivalent lengths of duct pieces are based on actual tests
and reflect requirements for good venting performance with
any vent hood.
Total Length = 63 Ft. (19.2 m)
C
For back exhaust, care should betak-
en to align exhaust with space be-
tween studs, or wall should be pre-
pared at the time it is constructed by
leaving enough space between the
wall studs to accommodate exhaust.
C
If you need to install ducts, note
that the total duct length of 31⁄4” x
10” (8.2 x 25.4 cm) rectangular or
6” (15.2 cm) diameter round duct
should not exceed 120 equivalent
feet (36.5 m).
C
Outside ventilation requires a HOOD
EXHAUST DUCK. Read the following
carefully. It is important that venting
be installed using the most direct
route and with as few elbows as
possible. This ensures clear vent-
ing of exhaust and helps prevent
blockages. Also, make sure dampers
swing freely and nothing is blocking
the ducts.
4.1.3 Exhaust connection
The exhaust adaptor has been designed to mate
with a standard 31⁄4” x 10” (8.2 x 25.4 cm) rectan-
gular duct. If a round duct is required, a rectangu-
lar-to-round transition adaptor must be used. Do
not use less than a 6” 6” (15.2 cm) diameter duct.

Over The Range Convection Microwave Oven / Installation Manual
10 / 63 EN
4 External exhaust
4.1.4 Maximum duct length
For satisfactory air movement, the total duct
length of 31⁄4” x 10” (8.2 x 25.4 cm) rectangular or
6” (15.2 cm) diameter round duct should not ex-
ceed 120 equivalent feet (36.5 m).
4.1.5 Elbows, transitions, wall
and roof caps, etc.,
Present additional resistance to airflow and are
equivalent to a section of straight duct which is
longer than their actual physical size. When cal-
culating the total duct length, add the equivalent
lengths of all transitions and adaptors plus the
length of all straight duct sections. The chart be-
low shows you how to calculate total equivalent
ductwork length using the approximate feet of
equivalent length of some typical ducts.
Duct pieces Equivalent
Length
x
Number
used
=
Equivalent
Length
Rectangular-to-Round
Transition Adaptor* 5 Ft. (1.5 m) x ( ) = Ft. or m
Wall Cap 40 Ft. (12.2 m) x ( ) = Ft. or m
90° Elbow 10 Ft. (3 m) x ( ) = Ft. or m
45° Elbow 45° Elbow x ( ) = Ft. or m
90° Elbow 25 Ft. (7.6 m) x ( ) = Ft. or m

11 / 63 EN
Over The Range Convection Microwave Oven / Installation Manual
4 External exhaust
45° Elbow 5 Ft. (1.5 m) x ( ) = Ft. or m
Roof Cap 24 Ft. (7.3 m) x ( ) = Ft. or m
Straight Duct 6“ (15.2 cm)
Round or
31⁄4” x 10” (8.2 x 25.4
cm) rectangula
1 Ft. (0.3 m) x ( ) = Ft. or m
Total Ductwork = Ft. or m
C
If a rectangular-to-round transition
adaptor is used, the bottom corners
of the damper will have to be cut to
fit, using the tin snips, in order to al-
low free movement of the damper.
C
For back exhaust, care should betak-
en to align exhaust with space be-
tween studs, or wall should be pre-
pared at the time it is constructed by
leaving enough space between the
wall studs to accommodate exhaust.
4.2 Damage – shipment /
installation
•If the unit is damaged in shipment, return the
unit tı the store in which it was bought for repair
or replacement.
•If the unit is damaged by the customer, repair
or replacement is the responsibility of the
customer.
•If the unit is damaged by the installer /if other
than the customer), repair or replacement must
be made by arrangement between customer
and installer.
4.3 Parts included
4.3.1 Hardware packet
Part Quantity
Wood Screws
(1⁄4“ x 2“) 2
Toggle Bolts (and
wing nuts) (3⁄16“
x 3“)
2
Self-Aligning Machine
Screws
(1⁄4“-28 x 31⁄4“)
3
Nylon Grommet
(for metal cabinets) 1
You will find the installation hardware contained in a packet
with the unit. Check to make sure you have all these parts.
NOTE: Some extra parts are included.

Over The Range Convection Microwave Oven / Installation Manual
12 / 63 EN
4.3.2 Additional parts
Part Quantity
To p C abinet
Template and 1
Rear Wall Template 1
Installation
Instructions 1
Separately Packed
Grease Filters 2
Exhaust adaptor 1
Glass tray 1
Turntable ring 1
You will find the installation hardware contained in a packet
with the unit. Check to make sure you have all these parts.
NOTE: Some extra parts are included.
4 External exhaust

13 / 63 EN
Over The Range Convection Microwave Oven / Installation Manual
4 External exhaust
4.4 Tools and materials
needed
#1Phillips screwdriver Pencil
Ruler or tape measure and
straight edge Carpenter square
(optional)
Tin snips (for cutting
damper, if required)
Electric drill with 3⁄16“,1⁄2“and5⁄8“
drill bits
Hammer (optional)
Stud nderor
Filler blocks or scrap
wood pieces, if needed
for top cabinet spacing
(used on recessed
bottom
cabinet installations
only)
Gloves
Saw (saber, hole or keyhole)
Level Duct and masking tape
Scissors
(to cut template, if necessary)
Safety goggles

Over The Range Convection Microwave Oven / Installation Manual
14 / 63 EN
5 Installation
5.1 Placement of the
mounting plate
5.1.1 Removing the microwave
oven from the carton/ removing
the mounting plate
1. Remove the installation instructions, filters,
glass tray and the small hardware bag. Do not
remove the Styrofoam protecting the front of
the oven.
2. Fold back all 4 carton flaps fully against carton
sides. Then carefully roll the oven and carton
over onto the top side. The oven should be
resting in the Styrofoam.
Carton
Styrofoam
3. Pull the carton up and off the oven.
4. Cut the middle of the outer protective plastic
bag to remove the mounting plate
Screws Screws
Mounting Plate
5. Remove the screws from the mounting plate.
This plate will be used as the rear wall template
and for mounting. Reinstall the screws into the
holes where they were removed.
5.1.2 Finding the wall studs
1. Find the studs, using one of the following
methods:
•Stud finder – a magnetic device which locates
nails.
•Use a hammer to tap lightly across the mounting
surface to find a solid sound. This will indicate a
stud location.
2. After locating the stud(s), find the center by
probing the wall with a small nail to find the
edges of the stud. Then place a mark halfway
between the edges. The center of any adjacent
studs should be 16“(40.6 cm) or 24“(61 cm)
from this mark.
3. Draw a line down the center of the studs.
AWARNING:
The microwave must
be connected to at least one wall
stud.
5.1.3 Determining wall plate
location under your cabinet
16-1/2
Atleast30
ʺ
C
L
3/8"TOEDGE
NOTE:ITISVERYIMPORTANTTO
READANDFOLLOW THE DIRECTIONS
INTHEINSTALLATIONINSTRUCTIONS
BEFOREPROCEEDINGWITHTHIS
REARWALL TEMPLATE.
ThisRearWallTemplate serves topositionthebottom
mountingplateandtolocatethehorizontalexhaust
outlet.
1.Usea leveltocheckthatthetemplateispositioned
accurately.
2.Locateandmarkatleast onestudontheleftor
rightside ofthecenterline.
Itisimportanttouseat leastonewood
screwmountedfirmlyinastudtosupport theweight
ofthemicrowave.Marktwo additional, evenlyspaced
locationsforthesuppliedtoggle bolts.
3.Drillholesinthemarkedlocations. Where thereis
astud, drill a 3/16" holefor wood screws. For holes
thatdonotline up with a stud, drill 5/8"holesfor
togglebolts.
DONOTINSTALLTHE MOUNTING PLATE
ATTHISTIME.
4.Removethetemplatefrom the rearwall.
5.ReviewtheInstallationInstruction book foryour
installationsituation.
Locateandmarkholes toalign with holes in the
mountingplate.
IMPORTANT:
LOCATEATLEASTONE STUD ON EITHER SIDE OF
THECENTERLINE.
MARKTHE LOCATION FOR2ADDITIONAL, EVENLY
SPACEDTOGGLEBOLTS IN THEMOUNTING PLATE
AREA.
Locateand mark holes to align with holes in the
mountingplate.
IMPORTANT:
LOCATEATLEASTONE STUD ON EITHER SIDEOF
THECENTERLINE.
MARKTHELOCATION FOR 2ADDITIONAL, EVENLY
SPACEDTOGGLE BOLTSINTHEMOUNTING PLATE
AREA.
Trimthe rear walltemplatealong thedotted line.
Trimthe rear walltemplate alongthedotted line.
12"
4"
Darlevueltaalahoja paraconsultar la
versiónenEspañol.
Draw a vertical line on the wall at the center of the
30ʺwide space. Tape the Rear Wall Template
onto the wall matching the centerline and touching
the bottom of the cabinet.
Plate position—beneath at bottom
cabinet
ʺ

15 / 63 EN
Over The Range Convection Microwave Oven / Installation Manual
5 Installation
33ʺto Cooktop
Draw a vertical line on the wall at the center of the
30ʺspace.
Tape the Rear Wall Template onto the wall
matching the centerline and touching the bottom
cabinet frame.
C
L
3/8"TO EDGE
NOTE:IT IS VERYIMPORTANT TO
READANDFOLLOW THE DIRECTIONS
INTHEINSTALLATION INSTRUCTIONS
BEFOREPROCEEDINGWITHTHIS
REARWALL TEMPLATE.
ThisRearWall Templateservesto positionthebottom
mountingplate andto locatethe horizontalexhaust
outlet.
1.Usealeveltocheckthat thetemplateispositioned
accurately.
2.Locateand mark atleast onestudon the left or
rightsideofthecenterline.
Itisimportant touse atleast one wood
screwmountedfirmlyinastudto supportthe weight
ofthemicrowave.Marktwo additional,evenlyspaced
locationsfor thesupplied toggle bolts.
3.Drillholesinthemarkedlocations.Wherethere is
astud,drilla3/16" holefor wood screws. For holes
that do not line upwithastud, drill5/8" holes for
togglebolts.
DONOTINSTALLTHEMOUNTING PLATE
ATTHIS TIME.
4.Remove the template from therearwall.
5.ReviewtheInstallation Instructionbookfor your
installation situation.
Locateandmark holes to alignwith holesin the
mountingplate.
IMPORTANT:
LOCATEAT LEAST ONE STUD ON EITHERSIDEOF
THECENTERLINE.
MARKTHELOCATION FOR 2ADDITIONAL,EVENLY
SPACEDTOGGLEBOLTSIN THE MOUNTING PLATE
AREA.
Locateand markholes to alignwith holesin the
mountingplate.
IMPORTANT:
LOCATEATLEASTONESTUD ON EITHERSIDEOF
THECENTERLINE.
MARKTHE LOCATIONFOR 2 ADDITIONAL, EVENLY
SPACEDTOGGLE BOLTS INTHEMOUNTING PLATE
AREA.
Trimthe rearwall template along the dottedline.
Trimtherear walltemplate alongthe dottedline.
12"
4"
Darlevueltaa la hoja para consultarla
versiónen Español.
Plate position—beneath framed recessed
cabinet bottom
Draw a line on the
backwallequal to the
depth of the front
overhang.
33" to Cooktop
C
L
3/8"TOEDGE
NOTE:ITISVERYIMPORTANTTO
READANDFOLLOWTHEDIRECTIONS
INTHEINSTALLATIONINSTRUCTIONS
BEFOREPROCEEDINGWITHTHIS
REARWALLTEMPLATE.
ThisRearWallTemplateservestopositionthebottom
mountingplateandtolocatethehorizontalexhaust
outlet.
1.Usealeveltocheckthatthetemplateispositioned
accurately.
2.Locateandmarkatleastonestudontheleftor
rightsideofthecenterline.
Itisimportanttouseatleastonewood
screwmountedfirmlyinastudtosupportthe weight
ofthemicrowave.Marktwoadditional,evenlyspaced
locationsforthesuppliedtogglebolts.
3.Drillholesinthemarkedlocations. Where thereis
astud,drilla3/16"holeforwoodscrews. Forholes
thatdonotlineupwithastud,drill5/8"holesfor
togglebolts.
DONOTINSTALLTHEMOUNTINGPLATE
ATTHISTIME.
4.Removethetemplatefromtherearwall.
5.ReviewtheInstallationInstructionbookforyour
installationsituation.
Locateandmarkholes to ali gnwithholesinthe
mountingplate.
IMPORTANT:
LOCATEATLEASTONESTUDONEITHERSIDEOF
THECENTERLINE.
MARKTHELOCATIONFOR2ADDITIONAL,EVENLY
SPACEDTOGGLEBOLTSINTHEMOUNTINGPLATE
AREA.
Locateandmarkholestoalign withholesinthe
mountingplate.
IMPORTANT:
LOCATEATLEASTONESTUDONEITHERSIDE OF
THECENTERLINE.
MARKTHELOCATIONFOR2ADDITIONAL,EVENLY
SPACEDTOGGLEBOLTSINTHEMOUNTINGPLATE
AREA.
Trimtherearwalltemplatealongthe dotted line.
Trimtherearwalltemplatealong thedottedline.
12"
4"
Darlevueltaalahojapara consultarla
versiónenEspañol.
3/8"TOEDGE
NOTE:ITIS VERY IMPORTANT TO
READAND FOLLOWTHE DIRECTIONS
INTHEINSTALLATIONINSTRUCTIONS
BEFOREPROCEEDINGWITHTHIS
REARWALL TEMPLATE.
ThisRearWall Template serves to position thebottom
mountingplateandto locatethe horizontal exhaust
outlet.
1.Usea level to checkthatthe template is positioned
accurately.
2.Locate and markat leastonestud onthe leftor
rightsideofthe centerline.
Itis important touse at least onewood
screwmountedfirmly in a studto support the weight
ofthe microwave.Mark two additional, evenlyspaced
locationsfor the supplied toggle bolts.
3.Drill holesin the marked locations. Where there is
astud, drill a3/16" hole forwood screws. For holes
thatdo not lineupwith a stud, drill 5/8" holes for
togglebolts.
DONOTINSTALLTHEMOUNTINGPLATE
ATTHIS TIME.
4.Removethetemplate from therear wall.
5.Review the InstallationInstruction book foryour
installationsituation.
Locateand mark holes to align withholesin the
mountingplate.
IMPORTANT:
LOCATEAT LEAST ONE STUDON EITHER SIDE OF
THECENTERLINE.
MARKTHELOCATIONFOR2 ADDITIONAL,EVENLY
SPACEDTOGGLE BOLTS INTHEMOUNTING PLATE
AREA.
Locateandmark holes to align with holesin the
mountingplate.
IMPORTANT:
LOCATEAT LEAST ONE STUDON EITHER SIDEOF
THECENTERLINE.
MARKTHELOCATIONFOR 2 ADDITIONAL, EVENLY
SPACEDTOGGLEBOLTSIN THE MOUNTING PL
AREA.
Trimthe rear wall templatealong the dotted line.
Trimtherear walltemplate along the dotted line.
12"
4"
Darlevueltaala hoja para consultarla
versiónenEspañol.
Plate position—beneath recessed bottom
cabinet with front overhang
Your cabinets may have decorative trim that inter-
feres with the microwave installation. Remove the
decorative trim to install the microwave properly
and to make it level
The microwave must be level.
Use a level to make sure the cabinet bottom is lev-
el.
If the cabinets have a front overhang only, with
no back or side frame, install the mounting plate
down the same distance as the front overhang
depth. This will keep the microwave level.
1. Measure the inside depth of the front overhang.
2. Draw a horizontal line on the back wall an equal
distance below the cabinet bottom as the inside
depth of the front overhang.
3. For this type of installation with front overhang
only, align the mounting tabs with this
horizontal line, not touching the cabinet bottom
as described in subtitle 5.1.4.

Over The Range Convection Microwave Oven / Installation Manual
16 / 63 EN
Area EHole A
Hole B
Centerline
notchesDraw a Vertical Line
on Wall from Center
of Top Cabinet
Draw a Horizontal line on wall from
bottom of “Rear Wall Template”.
Horizontal Line
Horizontal Line
C
L
3/8" TO EDGE
NOTE: IT IS VERY IMPORTANT TO
READ AND FOLLOW THE DIRECTIONS
IN THE INSTALLATION INSTRUCTIONS
BEFORE PROCEEDING WITH THIS
REAR WALL TEMPLATE.
ThisRear Wall Template serves to position the bottom
mountingplate and to locate the horizontal exhaust
outlet.
1.Use a level to check that the template is positioned
accurately.
2.Locate and mark at least one stud on the left or
right side of the centerline.
Itis important to use at least one wood
screwmounted firmly in a stud to support the weight
ofthe microwave. Mark two additional, evenly spaced
locationsfor the supplied toggle bolts.
3.Drill holes in the marked locations. Where there is
a stud, drill a 3/16" hole for wood screws. For holes
that do not line up with a stud, drill 5/8" holes for
toggle bolts.
DONOT INSTALL THE MOUNTING PLATE
ATTHIS TIME.
4.Remove the template from the rear wall.
5.Review the Installation Instruction book for your
installation situation.
Locate and mark holes to align with holes in the
mounting plate.
IMPORTANT:
LOCATE AT LEAST ONE STUD ON EITHER SIDE OF
THE CENTERLINE.
MARK THE LOCATION FOR 2 ADDITIONAL, EVENLY
SPACED TOGGLE BOLTS IN THE MOUNTING PLATE
AREA.
Locate and mark holes to align with holes in the
mounting plate.
IMPORTANT:
LOCATE AT LEAST ONE STUD ON EITHER SIDE OF
THE CENTERLINE.
MARK THE LOCATION FOR 2 ADDITIONAL, EVENLY
SPACED TOGGLE BOLTS IN THE MOUNTING PLATE
AREA.
Trim the rear wall template along the dotted line.
12"
4"
Darle vuelta a la hoja para consultar la
versión en Español.
A
Wear gloves to avoid cutting fingers
on sharp edges.
5.1.4 Aligning the wall plate
1. Draw a Vertical line on the wall at the center of
the 30” wide space.
2. Draw a Horizontal line on the wall at the bottom
of “Rear Wall Template”.
3. Drill 5/8” holes for toggle bolts on 2 locations
(Hole A, Hole B) but if the location of hole is
same as that of stud, drill a 3/16” hole for wood
screw. In other words, toggle bolt can not be
used to the location of stud.
C
DO NOT MOUNT THE PLATE AT THIS
TIME.
5 Installation
C
Holes A and B are inside area E. If
both of A and B are not in a stud,
find a stud somewhere in area E and
draw a forth circle to line up with the
stud. It is important to use at least
one wood screw mounted firmly in
a stud to support the weight of the
microwave. Set the mounting plate
aside.

17 / 63 EN
Over The Range Convection Microwave Oven / Installation Manual
5 Installation
5.2 Installation types (choose
A, B or C)
this microwave oven is designed for adaptation to
the following three types of ventilation:
•Outside Top Exhaust (Vertical Duct Type A)
Adaptor in Place for
Outside Top Exhaust
•Outside Back Exhaust (Horizontal Duct Type B)
Adaptor Must Be
Moved to the Back for
Outside Back Exhaust
•Recirculating (Non-Vented Ductless Type C)
C
This microwave is shipped assem-
bled for Recirculating. Select the
type of ventilation required for your
installation and proceed to that sec-
tion.
5.2.1 Outside top exhaust
(vertical duct type A)
installation overview
A1. Attach Mounting Plate to Wall
A2. Prepare Top Cabinet
A3. Adapting Microwave Blower for
A4. Check Damper Operation
A5. Mount Microwave Oven
A6. Adjust Exhaust Adaptor
A7. Connect Ductwork
A
Make sure the screws for the blower
motor and blower plate are securely
tightened when they are reinstalled.
This will help to prevent excessive
vibration.
A
Make sure the motor wiring has
been properly routed and secured,
and that the wires are not pinched.
3/8"TO EDGE
NOTE:IT IS VERY IMPORTANT TO
READAND FOLLOW THE DIRECTIONS
INTHE INSTALLATION INSTRUCTIONS
BEFOREPROCEEDING WITH THIS
REARWALL TEMPLATE.
ThisRearWallTemplate serves to position thebottom
mountingplateandto locate the horizontal exhaust
outlet.
1.Usea level to checkthat the template is positioned
accurately.
2.Locateand markat least one stud on theleft or
rightside of the centerline.
Itisimportant to use at least one wood
screwmountedfirmlyina stud to support the weight
ofthemicrowave. Marktwo additional, evenly spaced
locationsforthe supplied toggle bolts.
3.Drillholes in the marked locations. Where there is
astud, drilla 3/16" hole for wood screws.For holes
thatdo not line up with a stud, drill 5/8"holesfor
togglebolts.
DONOTINSTALL THE MOUNTINGPLATE
ATTHISTIME.
4.Removethe template fromthe rearwall.
5.Reviewthe Installation Instruction book for your
installationsituation.
Locateand mark holes to align with holes in the
mountingplate.
IMPORTANT:
LOCATEAT LEAST ONE STUD ON EITHER SIDE OF
THECENTERLINE.
MARKTHE LOCATION FOR 2 ADDITIONAL, EVENLY
SPACEDTOGGLE BOLTS IN THE MOUNTING PLATE
AREA.
Locateand markholes to align with holes in the
mountingplate.
IMPORTANT:
LOCATEAT LEAST ONE STUD ON EITHER SIDE OF
THECENTERLINE.
MARKTHE LOCATION FOR 2 ADDITIONAL, EVENLY
SPACEDTOGGLE BOLTS IN THE MOUNTING PLATE
AREA.
Trimthe rear wall template along the dotted line.
Trimthe rear wall template along the dotted line.
12"
4"
Darlevueltaalahoja para consultarla
versiónen Español.

Over The Range Convection Microwave Oven / Installation Manual
18 / 63 EN
5 Installation
A1. Attach Mounting Plate to Wall
Attach the plate to the wall using toggle bolts. At
least one wood screw must be used to attach the
plate to a wall stud.
1. Remove the toggle wings from the bolts.
2. Insert the bolts into the mounting plate through
the holes designated to go into drywall and
reattach the toggle wings to 3⁄4” (19 mm) onto
each bolt.
To use toggle bolts:
Wall
Mounting
Plate
Spacing for Toggles
More Than Wall
Thickness
Bolt End
Toggle
Bolt
Toggle Wings
3. Place the mounting plate against the wall and
insert the toggle wings into the holes in the wall
to mount the plate.
C
Before tightening toggle bolts and
wood screw, make sure the tabs on
the mounting plate touch the bot-
tom of the cabinet when pushed
flush against the wall and that the
plate is properly centered under the
cabinet.
A
Be careful to avoid pinching fingers
between the back of the mounting
plate and the wall.
4. Tighten all bolts. Pull the plate away from the
wall to help tighten the bolts.
A2. Use top cabinet template For
preparation of top Cabinet
You need to drill holes for the top support screws,
a hole large enough for the power cord to fit
through, and a cutout large enough for the ex-
haust adaptor.
•Read the instructions on the TOP CABINET
TEMPLATE.
•Tape it underneath the top cabinet.
•Drill the holes, following the instructions on the
TOP CABINET TEMPLATE.
A
Wear safety goggles when drilling
holes in the cabinet bottom.

19 / 63 EN
Over The Range Convection Microwave Oven / Installation Manual
5 Installation
A3. Adapting microwave blower for
outside top exhaust
1. Place the microwave in its upright position, with
the top of the unit facing up. Remove the screw
that holds the blower plate to the microwave.
Remove and save the screw holding the blower
motor to the microwave.
Blower Plate
Blower Motor
Screw
Back of
Microwave
2. Carefully pull out the blower unit. The wires will
extend far enough to allow you to adjust the
blower unit.
End B
End A
Back of
Microwave
3. Roll the blower unit 90° so that fan blade
openings are facing out the top of the
microwave.
Back of
Microwave
Before Rotation After Rotation
Back of
Microwave
4. Place the blower unit back into the opening.
Back of
Microwave
AFTER: Fan Blade
Openings Facing Top
5. Secure blower unit to microwave with the screw
removed in Step 1. Make sure the screw is tight.
6. Replace blower plate with the screw removed in
Step 1. Make sure the screw is tight.
Back of
Microwave
7. Attach the exhaust adaptor to the top of the
blower plate by sliding it into the guides of
the blower plate. Push in securely until it is in
the locking tabs. Take care to assure that the
damper hinge is installed so that the damper
swings freely.
Back of
Microwave
Guide
Adaptor
Locking Tab

Over The Range Convection Microwave Oven / Installation Manual
20 / 63 EN
5 Installation
A4. Check for proper damper opera-
tion
Exhaust Adaptor
Blower Plate
Damper
Back of
Microwave
•Make sure tape securing damper is removed
and damper pivots easily before mounting
microwave.
•You will need to make adjustments to assure
proper alignment with your house exhaust duct
after the microwave is installed.
A5. Mount the microwave oven
C
For easier installation and person-
al safety, we recommend that two
people install this microwave oven.
A
Do not grip or use handle during in-
stallation.
C
If your cabinet is metal, use the ny-
lon grommet around the power cord
hole to prevent cutting of the cord.
C
We recommend using filler blocks if
the cabinet front hangs below the
cabinet bottom shelf.
A
If filler blocks are not used, case
damage may occur from overtight-
ening screws.
1. Lift microwave, tilt it forward, and hook slots
at back bottom edge onto four lower tabs of
mounting plate.
2. Rotate front of oven up against cabinet bottom.
C
When mounting the microwave
oven, thread power cord through
hole in bottom of top cabinet. Keep
it tight throughout Steps 1–3. Do not
pinch cord or lift oven by pulling cord.
1
2
3. Insert a self-aligning screw through top center
cabinet hole. Temporarily secure the oven by
turning the screw at least two full turns after
the threads have engaged. (It will be completely
tightened later.) Be sure to keep power cord
tight. Be careful not to pinch the cord, especially
when mounting flush to bottom of cabinet.
