Blomberg MEE 1030 X Setup guide

Owner’s Instruction Manual
MEE 1030 X
20 Litre Electronic
Microwave

EN
2
Read the Instructions carefully and Keep for Future Reference
IMPORTANT SAFETY INSTRUCTIONS. READ CAREFULLY AND KEEP FOR
FUTURE REFERENCE
WARNING: When the appliance is operated in the combination mode, children
should only use the oven under adult supervision due to the temperatures
generated;
WARNING: If the door or door seals are damaged, the oven must not be operated
until it has been repaired by a competent person;
WARNING: It is hazardous for anyone other than a competent person to carry out
any service or repair operation that involves the removal of a cover which gives
protection against exposure to microwave energy;
WARNING: Liquids and other foods must not be heated in sealed containers since
they are liable to explode
WARNING: Only allow children to use the oven without supervision when adequate
instructions have been given so that the child is able to use the oven in a safe way
and understands the hazards of improper use;
• Only use utensils that are suitable for use in microwave ovens
• When heating food in plastic or paper containers, keep an eye on the oven due to
the possibility of ignition;
• If smoke is observed, switch of or unplug the appliance and keep the door closed
in order to stifle any flames;
• Microwave heating of beverages can result in delayed eruptive boiling, therefore
care must be taken when handling the container;
• The contents of feeding bottles and baby food jars shall be stirred or shaken and
the temperature checked before consumption, in order to avoid burns;
• Eggs in their shell and whole hard-boiled eggs should not be heated in microwave
ovens since they may explode, even after microwave heating has ended;
• The oven should be cleaned regularly and any food deposits removed;
• Failure to maintain the oven in a clean condition could lead to deterioration of the
surface that could adversely affect the life of the appliance and possibly result in a
hazardous situation;
• If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.

EN
3
1 Specifications ..............................................4
2 Radio Interference.......................................5
3 Installation....................................................5
4 Important Safety Instructions ....................7
5 Safety Instructions For General Use .........8
6 Operation Instruction................................11
7 Care Of Your Microwave Oven ................14
Table of Content

EN
4
Power consumption: 230 V~50 Hz,1280 W
Output: 800 W
Operating Frequency: 2.450 MHz
Outside Dimensions: 470mm (W) X 377mm (D) X 282mm (H)
Oven Cavity Dimensions: 315mm (W) X 330mm (D) X 195mm (H)
Oven Capacity: 20 litres
Uncrated Weight: Approx. 13.5 kg
1 Specifications
1. If the oven will not perform at all,
the display does not appear or the
display disappears:
a) Check to ensure that the oven
is plugged in securely. If it is not,
remove the plug from the outlet,
wait 10 seconds and plug it in again
securely.
b) Check the premises for a blown
circuit fuse or a tripped main
circuit breaker. If these seem to be
operating properly, test the outlet
with another appliance.
2. If the microwave power does not
function:
a) Check to see whether the timer is
set.
b) Check to make sure that the door
is securely closed to engage the
safety interlocks. Otherwise, the
microwave energy will not flow into
the oven.
Note:
The appliance is for household use
for heating food and beverages using
electromagnetic energy and for indoor
use only.
BEFORE YOU CALL FOR SERVICE
IF NONE OF THE ABOVE RECTIFIES THE SITUATION, THEN CONTACT THE
AUTHORIZED SERVICE AGENT.

EN
5
2 Radio Interference
3 Installation
IMPORTANT
The wires in this mains lead are
coloured in accordance with the
following code:
Green-and-yellow : Earth
Blue : Neutral
Brown : Live
As the colours of the wires in the mains
leads of the appliance may not correspond
with the coloured markings identifying the
terminals in your plug, proceed as follows:
The wire which is coloured green-and-
yellow must be connected to the terminal
in the plug which is marked with the letter
E or by the earth symbol coloured
green of green-and-yellow.
The wire which is coloured blue must be
connected to the terminal which is marked
with the letter N or coloured black.
The wire which is coloured brown must be
connected to the terminal which is marked
with the letter L or coloured red.
Microwave oven may cause interference
to your radio, TV, or similar equipment.
When interference occurs, it may be
eliminated or reduced by the following
procedures.
a. Clean the door and sealing surface
of the oven.
b. Place the radio, TV, etc. as far
away from your microwave oven as
possible.
c. Use a properly installed antenna for
your radio, TV, etc. to get a strong
signal reception.
1. Make sure all the packing materials
are removed from the inside of the
door.
2. Inspect the oven after unpacking for
any visual damage such as:
- Misaligned Door
- Damaged Door
- Dents or Holes in Door Window
and Screen
- Dents in Cavity
- If any of the above are visible, DO
NOT use the oven.
3. This Microwave Oven weighs
13.5 kg and must be placed on a
horizontal surface strong enough to
support this weight.
4. The oven must be placed away from
high temperature and steam.
5. DO NOT place anything on top of
the oven.
6. Keep the oven at least 8 cm away
from both sidewalls and 10 cm
away from rear wall to ensure the
correct ventilation.
7. DO NOT remove the turn -table
drive shaft.
8. As with any appliance, close
supervision is necessary when used
by children.
WARNING - THIS APPLIANCE MUST
BE EARTHED.
1. The plug socket should be within
easy reach of the power cord
2. This oven requires 1.5 KVA for
its input consultation with service
engineer is suggested when
installing the oven.
CAUTION: This oven is protected
internally by a 250V,10 Amp Fuse.

EN
6
ATTENTION: The following steps are for
the Microwave Oven models with the
Built-in Trim Kit Frame Only.
1. After taking all the accessories
out of the microwave oven, turn
the microwave oven over on its
back and keep the base of the
microwave oven facing towards
you.
2. Remove the adjustable feet (Fig.
No. 2) from the plastic bag and
screw them into the holders (Fig.
No. 1), one by one.
3. Once all 4 feet are fitted, turn the
microwave oven back over onto
its feet to check if the adjustable
feet are level. If the microwave
oven is unstable, adjust the feet
by screwing them up or down
accordingly.

EN
7
WARNING: When the appliance is
operated in the combination mode,
children should only use the oven
under adult supervision due to the
temperatures generated; (Only for the
model with grill function)
WARNING: If the door or door seals
are damaged, the oven must not be
operated until it has been repaired by a
competent person;
WARNING: It is hazardous for anyone
other than a competent person to carry
out any service or repair operation that
involves the removal of a cover which
gives protection against exposure to
microwave energy;
WARNING: liquids and other foods
must not be heated in sealed containers
since they are liable to explode.
WARNING: Only allow children to use
the oven without supervision when
adequate instructions have been given
so that the child is able to use the oven
in a safe way and understands the
hazards of improper use;
• The oven must have sufficient air
flow. Keep 10 cm space at back;15
cm at both sides and 30cms from
top of the oven. Don’t remove
oven’s feet, do not block air events
of the oven.
• Only use utensils that are suitable
for use in microwave ovens.
• When heating food in plastic or
paper containers, keep an eye on
the oven due to the possibility of
ignition;
4 Important Safety Instructions
• If smoke is observed, switch off or
unplug the appliance and keep the
door closed in order to stifle any
flames;
• Microwave heating of beverages
can result in delayed eruptive
boiling, therefore care must be
taken when handling the container;
• The contents of feeding bottles
and baby food jars shall be stirred
or shaken and the temperature
checked before consumption, in
order to avoid burns;
• Eggs in their shell and whole hard-
boiled eggs should not be heated
in microwave ovens since they may
explode, even after microwave
heating has ended;
• When cleaning surfaces of door,
door seal, cavity of the oven, use
only mild, nonabrasive soaps, or
detergents applied with a sponge
or soft cloth.
• The oven should be cleaned
regularly and any food deposits
removed;
• Failure to maintain the oven in
a clean condition could lead to
deterioration of the surface that
could adversely affect the life of the
appliance and possibly result in a
hazardous situation;
• If the supply cord is damaged,
it must be replaced by the
manufacturer, its service agent or
similarly qualified persons in order
to avoid a hazard.

EN
8
Listed below are, as with all appliances,
certain rules to follow and safeguards to
assure top performance from this oven:
1. Always have the glass tray, roller
arms, coupling and roller track in
place when operating the oven.
2. Do not use the oven for any reason
other than food preparation, such
as for drying clothes, paper, or
any other nonfood items, or for
sterilizing purposes.
3. Do not operate the oven when
empty. This could damage the
oven.
4. Do not use the oven cavity for any
type of storage,such a papers,
cookbooks, etc.
5. Do not cook any food surrounded
by a membrane,such as egg
yolks,potatoes,chicken livers,etc
without first being pierced several
times with a fork.
6. Do not insert any object into the
openings on the outer case.
7. Do not at any time remove parts
from the oven such as the feet,
coupling, screws, etc.
8. Do not cook food directly on the
glass tray. Place food in/on proper
cooking utensil before placing in the
oven.
9. IMPORTANT-COOKWARE NOT TO
USE IN YOUR MICROWAVE OVEN
Do not use metal pans or dishes
with metal handles.
Do not use anything with metal
trim.
Do not use paper covered wire
twist-ties on plastic bags.
5 Safety Instructions For General Use
Do not use melamine dishes as
they contain a material which will
absorb microwave energy. This
may cause the dishes to crack
or char and will slow down the
cooking speed.
Do not use Centura Tableware. The
glaze is not suitable for microwave
use. Corelle Livingware closed
handle cups should not be used.
Do not cook in a container with
a restricted opening, such as a
pop bottle or salad oil bottle, as
they may explode if heated in a
microwave oven.
Do not use conventional meat or
candy thermometers.
There are the thermometers
available specifically for microwave
cooking. These may be used.
10. Microwave utensils should be
used only in accordance with
manufacturer’s instructions.
11. Do not attempt to deep-fry foods in
this oven.
12. Please remember that a microwave
oven only heats the liquid in a
container rather than the container
itself. Therefore, even though the
lid of a container is not hot to the
touch when removed from the
oven, please remember that the
food/liquid inside will be releasing
the same amount of steam and/or
spitting when the lid is removed as
in conventional cooking.

EN
9
13. Always test the temperature of
cooked food yourself especially if
you are heating or cooking food/
liquid for babies. It is advisable
never to consume food/liquid
straight from the oven but allow it
to stand for a few minutes and stir
food/liquid to distribute heat evenly.
14. Food containing a mixture of fat
and water, e.g.stock,should stand
for 30-60 seconds in the oven after
it has been turned off. This is to
allow the mixture to settle and to
prevent bubbling when a spoon is
placed in the food/liquid or a stock
cube is added.
15. When preparing/cooking food/
liquid and remember that there
are certain foods, e.g. Christmas
puddings, jam and mincemeat,
which heat up very quickly. When
heating or cooking foods with a
high fat or sugar content do not use
plastic containers.
16. Cooking utensil may become hot
because of heat transferred from
the heated food. This is especially
true if plastic wrap has been
covering the top and handles of the
utensil. Potholders may be needed
to handle the utensil.
17. To reduce the risk of fire in the oven
cavity:
(a) Do not overcook food. Carefully
attend microwave oven if paper,
plastic, or other combustible
materials are placed inside the oven
to facilitate cooking.
(b) Remove wire twist-ties from bags
before placing bag in oven.
(c) If materials inside the oven should
ignite, keep oven door closed, turn
the oven off at the wall switch, or
shut off power at the fuse or circuit
breaker panel.
(1) Door Safety Lock System
(2) Oven Window
(3) Oven Air Vent
(4) Roller Ring
(5) Glass Tray
(6) Control Panel
4
2
1
536
1
Feature Diagram

EN
10
Computer Control Panel
T
i
m
e
S
e
t
t
i
n
g
Micro
Defrost
Slow Cook
Auto MenuCleaMemory
StartPause/
Cancel
+ -
Clock/Time
r
(1) Display Window
(3) Defrost
(2) Slow Cook
(5) Memory
(8) Clock/Time
(4) Micro
(10) Start
(6) Clear
(7) Auto Menu
(9) Pause/Cancel
(11) Time Setting
