Blomberg BRFB1920SS User manual

CONFIDENTIAL
ARÇELİK A.Ş.
K76540NEB
INSTALLATION INSTRUCTIONS

CONFIDENTIAL
1
Table of Contents
Symbols and Their Meanings ........................................................................................................................................ 3
Product weight.............................................................................................................................................................. 5
Load bearing capacity of the doors............................................................................................................................... 5
Climate class.................................................................................................................................................................. 5
Product Information: .................................................................................................................................................... 6
Furniture: ...................................................................................................................................................................... 8
Ventilation:.................................................................................................................................................................... 8
Combining Kit:............................................................................................................................................................... 8
Electrical Connection .................................................................................................................................................... 9
Water Connection......................................................................................................................................................... 9
TOOL LIST ........................................................................................................................................................................10
ALTERNATIVES FOR INSTALLATION.................................................................................................................................11
PREPARATION FOR INSTALLATION .................................................................................................................................12
Cabin Dimensions........................................................................................................................................................12
Location of the Electrical Wiring.................................................................................................................................13
Location of the Water System ....................................................................................................................................14
Product Dimensions:................................................................................................................................................... 16
Unpacking ...................................................................................................................................................................21
Removing the Connectors on the Side Wall ...............................................................................................................23
Removing the Mounting Parts in the Freezer Compartment .....................................................................................24
Removing the FRZ Crisper........................................................................................................................................... 27
Removing the FRZ Door .............................................................................................................................................. 28
Removing the Lower Vent Hole Assembly..................................................................................................................29
Removing the Upper Vent Hole Part .......................................................................................................................... 30
PRE-INSTALLATION.......................................................................................................................................................... 31
Mounting the Anti-Tip Brackets..................................................................................................................................31
Alternative anti-tip method: ...................................................................................................................................34
Preparing the Water Hose and the Power Plug .......................................................................................................... 35
INSTALLATION TO THE CABIN .........................................................................................................................................36
Taking the Refrigerator from the Wooden Pallet ....................................................................................................... 36
Placing the refrigerator into the cabin........................................................................................................................38
Adjusting the height of the refrigerator in the cabin.................................................................................................. 42
Adjusting the refrigerator according to the cabin flange ...........................................................................................44
Screwing the side brackets .........................................................................................................................................46
Screwing the upper bracket........................................................................................................................................ 48

CONFIDENTIAL
2
INSTALLING THE CABIN BOTTOM ...................................................................................................................................49
Water connection .......................................................................................................................................................49
Attaching the upper vent hole part ............................................................................................................................51
Attaching the lower vent hole assembly .................................................................................................................... 52
Attaching the kick plate sheet assembly..................................................................................................................... 54
Attaching the decorative parts ................................................................................................................................... 55
FURNITURE DOOR PREPARATION................................................................................................................................... 56
Choosing the Door Thickness......................................................................................................................................56
Removing the Mechanism Covers ..............................................................................................................................58
Removing the 3D Adjusting Mechanism on the Refrigerator..................................................................................... 59
Preparing the Fridge Furniture Door .......................................................................................................................... 61
Preparing the Freezer Furniture Door ........................................................................................................................65
Kick Plate Position Adjustment: ..................................................................................................................................70
INSTALLING FURNITURE DOORS .....................................................................................................................................71
Installing the Fridge Furniture Door............................................................................................................................ 71
Installing the Freezer Furniture Door.......................................................................................................................... 76
Adjusting the Furniture Door......................................................................................................................................78
Attaching the covers ................................................................................................................................................... 89
HINGE ADJUSTMENT....................................................................................................................................................... 91
Adjusting the hardness of the hinges .........................................................................................................................91
CHANGING THE DIRECTION OF THE FF DOOR ................................................................................................................93
Removing the FF clad door ......................................................................................................................................... 93
Removing and preparing the Fridge Inner Door.........................................................................................................97
Replacing the hinges ................................................................................................................................................. 100
Installing the FF PU Door...........................................................................................................................................106
Installing the Fridge Furniture Door and adjusting the door .................................................................................... 107
INSTALLING THE DUAL CABIN .......................................................................................................................................107
Cabin Dimensions......................................................................................................................................................107
Location of the Electrical Wiring...............................................................................................................................108
Location of the Water System ..................................................................................................................................109
Removing the Side Brackets...................................................................................................................................... 111
Attaching the Fasteners ............................................................................................................................................ 112

CONFIDENTIAL
3
Symbols and Their Meanings
Symbols used in the installation manual are as follows.
Important information or useful usage tips
WARNING: Conditions that may damage the product or its operating functions
ATTENTION: Conditions containing serious injury risk
Conditions containing electric shock risk
Packaging materials of the product have been manufactured from recyclable materials in accordance
with our National Environment Regulations.
Disposing the packaging materials
The package has been designed to protect the product during transport. The packaging materials used for the
product do not harm the nature during disposal and they need to be recycled.
All plastic packaging materials, bags etc. must be disposed safely and kept out of the reach of children. Please return
the packaging to your dealer.
WARNING:
This installation manual has been prepared to help installation teams. The User Manual provided with the product
must also be taken into consideration.
You may get seriously injured and your product may get damaged if you ignore the warnings given in this manual.
Please read the following carefully.
WARNING:
R600a Refrigerant
This product contains R600a isobutane refrigerant, which is a very eco-friendly natural gas. However, it is also
flammable. Please follow the warnings given below:
If the product has been transported horizontally, you must wait for 4 hours minimum before plugging it in.
The following instructions must be followed during installation:
Dimensions of the installation area must be suitable.
Dimensions, features and position of the object used to support and fix the product to this area must be
suitable.

CONFIDENTIAL
4
Minimum clearances between product parts and surrounding structures must be suitable.
Minimum dimensions and proper organisation of ventilation holes must be observed.
The product must be connected to the mains power, and corresponding connections of other components
must be suitable.
The product must be disconnectable from the power supply after installation.
The socket or fuse must be accessible to de-energise the product.
Extension cables or ungrounded (two-terminal) adapters must not be used.
ATTENTION:
You must wear gloves and eye protectors when installing the product.
You must also take measures against high noise levels when drilling the floor or using a drill.
ATTENTION:
Make sure that your product is suitable for your local mains.
ATTENTION:
The product must be installed by a qualified technician according to the installation instructions.
WARNING:
The product may tip over since it is quite heavy. For this reason, precautions must be taken against tipping over. The
doors of the product must be kept closed until it reaches the destination and it must be transported in accordance
with the installation instructions.

CONFIDENTIAL
5
Product weight
BRFB1920SS: 486.00 lbs (220.44 Kg)
Load bearing capacity of the doors
Max. load that the Fridge Door can bear: 55 lbs (25 kg)
Max. load that the Freezer Door can bear: 22 lbs (10 kg)
Climate class
Climate range
Ambient temperature of the room
SN
N
ST
T
Between +50oF (10oC) and +90oF (32oC)
Between +60oF (16oC) and +90oF (32oC)
Between +60oF (16oC) and +110oF (38oC)
Between +60oF (16oC) and +120oF (43oC)
This appliance has been designed to be used in certain climate ranges (ambient temperatures). It must not be used
out of this range. Climate range of this device is specified on the Barcode Label located inside the appliance.

CONFIDENTIAL
6
Product Information:
As illustrated in the figure below, you can see the Barcode Level at the top right corner of the FRZ Compartment.
Installation Place
You must follow the instructions below:
The floor on which the product will be installed must be capable of bearing 1,200 pounds (544 kg) minimum.
Kitchen floor and the bottom of the product must be at the same level. Otherwise, problems may occur with
the air suction of the product.
There must be no objects preventing the installation of the product at the back and on the side walls of the
product's installation place.
The power socket must be at the correct place.
Dimensions of the furniture where the product will be installed must be in strict conformity with the
dimensions given in the manual.
Do not install the product with the fridge and the freezer are adherent next to each other. Otherwise,
condensation and damage may occur in the product. (Please see "Dual Cabin Installation" for detailed
information)
Flatness of the floor where the product will be installed must be checked with a Bubble Level Tool.
Installation area must not be subjected to direct sunlight and it must be away from heat sources, ovens,
radiators etc.

CONFIDENTIAL
7
The ambient temperature must be between 55°F (13°C) and 110°F (43°C). Otherwise, function errors may
arise when the product is running.
If it is not possible to avoid installing the product near a heat source, the minimum clearances given below
must be maintained between the product and the said source:
11/4" (3 cm) from electric hobs or ovens
12" (30 cm) from gas or fuel operated hobs or ovens
Please observe the following rules:
The power socket or fuse must be easily accessible in case of an emergency; it must not be hidden behind
the product.
Plug or cable must not touch the back surface of the product. Otherwise, it may get damaged due to the
vibration of the product.
Do not connect the plugs of other appliances behind this product.
If the humidity level is high where the product is used, corrosion may be seen on the outer surface of the product.
Keep the installation room dry and well-cleaned to avoid corrosion.
To avoid the risk of electric shock:
Connect the plug to a grounded 3-pin socket.
Do not remove the ground terminal of the plug.
Do not use adapters.
Do not use extension cables.
ATTENTION:
Failure to follow these instructions may result in death, fire or electric shock. Connecting the grounding conductor of
the equipment to an improper place may lead to electric shock. Please have the grounding checked by a qualified
electrician or service technician if you have any doubt about the proper grounding of the product.
Installation, repair and other procedures performed by unqualified persons may cause danger. Before installing the
appliance, make sure that the voltage, load and circuit current parameters on the data plate are in compliance with
the power mains in your house.

CONFIDENTIAL
8
The appliance is provided with a NEMA 5-15 P plug and a 3-pin power cable which is in the UL list and ready to be
connected to a 120 V, 60 Hz power supply. Fuse is 15 A. The appliance must be connected to a 3-pin socket. The plug
must be installed only by a licensed electrician.
If the electrical wiring or the electric power supply of the house needs alteration, the necessary procedures must be
performed by a qualified electrician.
ATTENTION:
Do not install you refrigerator:
In open areas
In environments where water is dripping
In environments where temperature is lower than 55° F (0°C)
Furniture:
Make sure that the furniture where you will install the appliance has been safely mounted in your kitchen. Your
furniture must be connected to the floor and the wall properly and with suitable connections.
For the best installation, clearances between the furniture and the product must be in compliance with the values
specified in the installation instructions.
Side walls must be free of clearances and their surfaces must be flat.
Minimum thickness of the side walls must be 5/8" (16 mm).
Minimum thickness of the doors to be attached to the product must be ¾" (19 mm) .
ATTENTION:
There is a stainless steel door and stainless kick plate option. Please consult the authorised service.
Ventilation:
Vent holes where the air enters and exits the unit must not be blocked or obstructed. In addition, you must
periodically clean the dust and dirt that accumulate on these holes in time.
Combining Kit:
There is a combining kit if you wish to use the two refrigerator combined next to each other. If you are going to use
them side by side, you will need to demand this kit separately from the authorised service. (Please see "Dual Cabin
Installation" for detailed information)

CONFIDENTIAL
9
Electrical Connection
Never use an extension cable.
The power socket must definitely be grounded and checked by an authorised person.
Location of the electrical wiring must comply with the dimensions specified in the manual.
ATTENTION:
RISK OF ELECTRIC SHOCK
Electrical grounding is necessary. This appliance is equipped with a three-pin plug to protect you against
possible electric shocks.
•Do not remove the round grounding terminal from the plug.
•Do not use two-pin grounding adapters.
•Do not use extension cables to energise the product.
ATTENTION:
Do not connect the grounding cable to the gas pipe. Please have the grounding checked by a qualified
electrician if you are not sure about the grounding of the product. Do not install a fuse on the neutral line or
grounding circuit.
WARNING:
Please wait for ½-1 hour before energising the product to protect it against possible damages. This way, the
refrigerant and the lubricants in the system get balanced.
Water Connection
Pressure of the mains water must be in compliance with the values specified in the manual.
Location of the water system must comply with the dimensions specified in the manual.
IMPORTANT INFORMATION:
Bypass is recommended for the water filtering system if a reverse osmosis system is used.

CONFIDENTIAL
10
TOOL LIST
Tools to be used when installing the product are as follows:
Cordless
Drill
Safety
Goggles
½"
Wrench
Hammer
Ladder
Ø2.4
Drill bit
Ø2.4
Drill bit
Box
Cutter
Safety
Gloves
Tape
measure
Star bit
T27
Torx Bit
T25
Torx Bit
T20
Torx Bit
¼"
Wrench Flat
Bubble
Level
Tool
Wheelbarrow
Tape

CONFIDENTIAL
11
ALTERNATIVES FOR INSTALLATION
The product can be placed in various ways based on the kitchen design. It must be installed at a place where it is
ensured that the door can be opened and closed properly. If the doors cannot be opened 90 degrees at least, you
cannot completely open the drawers inside the product.
Single cabin placement methods
Dual cabin placement methods

CONFIDENTIAL
12
PREPARATION FOR INSTALLATION
The instructions below have been prepared according to Built-in type.
Built-in: The Appliance and Panels fully seat into the gap, and a material that can be their own box is jammed
between the two kitchen cabinets or decorative columns. This is the most common installation scenario.
Cabin Dimensions
Cabin dimensions below must be checked before starting the
installation.

CONFIDENTIAL
13
Location of the Electrical Wiring
Location of the electrical wiring must be within the range given below.
ATTENTION:
Do not use extension cables or two-pin adaptors and do not remove the ground terminal of the grounding cable.
ATTENTION:
A qualified electrician must ensure that the poles of the socket are connected correctly. Verify that the grounding of
the socket is correct.

CONFIDENTIAL
14
Location of the Water System
The water connected to the water mains must be potable.
Location of the water system must be within the range given below.
Water system of the refrigerator must be connected to the water mains system in the house. The user must be able
to switch it on/off with the valve when necessary.
Objects that might pierce the water hoses or cause them to twist must not be present where the water line is
installed.
Pressure of the water system must be between 25-80 psi (1.7-5.5 Bar).
If the water pressure exceeds 80 psi, install a pressure limiting device or water impact protector to the inlet valve.
Never install the product or operate the appliance if it is possible for the water pressure to exceed 120 psi.
WARNING:
Make sure that there is no water leakage when making the water connections. Otherwise, there will be water on the
floor and the furniture will get damaged.
You will need a hose with a minimum length of 60" (1.5 meters) and a diameter of ¼" for water connections of the
product during installation. A connector that has a thread with an external diameter of ¼ must be used to connect
the hose end to the product.
Before completing the installation, make sure that water flows and there is no water leakage.

CONFIDENTIAL
15
WARNING:
Flatness of the floor where the product will be installed must be checked with a Bubble Level Tool.
Uprightness of the furniture flanges must be checked with a Bubble Level Tool.
If the flatness and uprightness of the product is not proper, problems may arise with the installation.

CONFIDENTIAL
16
Product Dimensions:

CONFIDENTIAL
17

CONFIDENTIAL
18

CONFIDENTIAL
19
Distances between the furniture doors and the kitchen furniture must be 1/8" (3 mm) minimum.
