Deck-Mounted Basin Mixer
Installation Guide
TSP101


2013-07
1 866 907 0122 blubathworks.com
®
1
Attention – Before Installation
1. Inspect this product to ensure you have all parts as shown that are required for proper installation.
2. The valve cartridge has been factory tested and adjusted – DO NOT TAKE THE CARTRIDGE APART. Taking the
cartridge apart will void the warranty.
3. Ensure that both hot and cold water feeds are properly connected to the marked lav connecting.
4. This product must be installed by a professional contractor.
5. Refer to the specification and assembly drawings attached for installation directions.
6. Flow Pressure –Min. 25 PSI, Max. 80 PSI. Recommended pressure – 50 to 60 PSI.
Installation Requirements
Please read the instructions carefully so as to avoid any damage to the fixture.
1. To ensure this product is installed properly, you must read and follow these guidelines.
2. The owner/user of the faucet must keep this information for future reference.
3. Be sure your installation conforms to local codes.
4. Refer to the specification and assembly drawings attached. Faucet is sold partially assembled but shown fully
disassembled for illustrative and service purposes only.
5. Inspect this product to ensure you have all parts required for proper installation.
6. Use only a strap wrench or protected/smooth-jaw wrench on any finished surface.
7. If possible, install the faucet assembly on the sink or mounting surface before setting.
8. Do NOT use putty during this installation.
Cleaners For Fittings And Accessories
To avoid damaging the surface and working components of the fittings, certain precautions must be taken in terms of us-
age and subsequent cleaning as many cleaning agents contain acids for general cleaning and removing calcium depos-
its. When caring for your fittings and accessories, please note the following:
- Only apply cleaners which are expressly intended for the use
- Never use any cleaner containing hydrochloric acid, formic acid or acetic acid on or near the fitting, as they can
cause considerable damage
- Do not use cleaners containing phosphoric acid
- Do not use cleaners containing chlorine bleach solutions
- Never mix or combine cleaning agents
- Abrasive cleaners and unsuitable scouring agents such as scouring pads
Technical Support Assistance
If further assistance is required, please contact:
Product support at 1.866.907.0122 (09:00 - 17:00hrs PST) or email
[email protected]
North America
Blu Bathworks Inc.
188 Smithe Street, Vancouver BC, Canada, V6B 6A9
T+1.604.299.0122 F+1.604.299.0125

2013-07
1 866 907 0122 blubathworks.com
®
2
INSTALLATION
• Screw the flexible hoses on the body (1).
• Fix the 2 connecting tie rods (5) fix the base (2) and the gasket (3).
• Place the mixer on the sink, graft the shaped gaskets made of rubber and metal (4) and
screw with the tightening nuts (6).
• Screw the nuts (7) on the cold and the hot side (8) , interposing the gaskets (9)
• Open the main water inlets and verify possible losses from the connections.


2013-07
1 866 907 0122 blubathworks.com
®
3
MAINTENANCE
Cartridge Change
To replace:.
• Shut off water supply to both inlets
• Remove the control lever (1), remove the grub screw (2), take off the control handle (3) and pull out the
cup (4).
• Pay attention not to lose the O-ring (5).
• Unscrew the flange (6) using 30mm/11/16”spanner. Remove the cartridge (7).
• Before re-assembling cartridge (7) clean its housing with wet cloth.
• Re-assembling the flange (6) and the O-ring (5).
• Re-fit the cup (4).
• Re-fit the control knob (3) and fix it with the grub screw (2).
• Re-fit the lever (1).




2013-07
1 866 907 0122 blubathworks.com
®
4
TSP101
"
[170]
"
[242]
9/16-24 UNEF
1"
[24]
"
[6]
ø"
[40]
ø "
[47]
1"
[25]
1"
[25]
ø "
[10]
18"
[459]
8"
[202]
"
[165]

2013-07
1 866 907 0122 blubathworks.com
®
5
TSP101


2013-07
1 866 907 0122 blubathworks.com
®
6
