Blue Aura Blackline PH 1 User manual
Please unpack the products carefully and take a moment to read the instructions.
Please visit our
website for more
information
Page | 2
All safety and operating instructions should be read thoroughly before attempting to operate this equipment
• Retain Instructions for future reference
• Follow all of the instructions detailed in this manual
• Observe all safety warnings stated in this manual
• This unit should NOT be situated in close proximity to water.
• Avoid placement near bathtubs, sinks, washing machines, etc.
• Avoid exposure to direct sunlight or to extremes of temperature or humidity
• Do not place near direct heat sources such as radiators, stoves, gas res, naked ames or candles.
• 1 x Power cable
Contents
• 1 x Pre-Amplier
• Phono Pre-amplier
PH 1
Please read the following precautions before attempting to
operate the pre-amplier
PH 1
Page | 3
• The should be serviced by an authorised
service engineer in the event of any of the following
circumstances
1. The power supply or cord sustains damage
2. The unit is struck by a falling object
3. The unit is exposed to rain or moisture
4. Liquid is inadvertently spilt on the unit
5. The unit does not seem to operate normally or
exhibits a sudden change in performance
6. The unit has been dropped
7. Any unauthorised changes or modifications to
this equipment would render the manufacturer’s
Warranty null and void
• Ensure that the unit is placed on a clean, dry and at surface
before operation
• Do not drop the unit, apply excessive force to the controls or
place heavy objects on top of the unit.
• Do not allow excessive levels of dust to gather on the
• To clean, use a soft dry cloth. If necessary, use a damp cloth
without any solvents
• Ensure that the area in which the unit is situated has adequate
ventilation.
• Do not place the in a position where its ventilation may
become obstructed.
• Avoid placement on beds, sofas, rugs, enclosed bookcases/
cabinets and any other area which may cause interference to the
ventilation of the product thus causing it to overheat
• Ensure that the unit is connected to the correct power supply as
indicated on the unit.
• Unplug the when not in use for a long period.
• Always make sure power cables are placed safely and are not
obstructing a walkway.
• To avoid risk of electric shock, do not attempt to remove the cover
or the baseplate of the unit. There are no user serviceable parts
inside.
PH 1
PH 1
PH 1 PH 1
PH 1
• Allow unit to cool completely before cleaning.
• Do not attempt to clean the product with chemical
solvents as this may damage the nish of the .
Page | 4
Front & Back Of
PH 1
Page | 5
www.blueaura/information
!
Making Connection
INPUT:
Using the stereo pair of RCA/Ground Phono cables that
connect to your existing Turntable or Record Player,
connect the white RCA plug into the white (L) input
socket. Then connect the red RCA plug into the red
input socket (R).
GND - Where available.
Loosen the GND (Ground) terminal with your fingers
and insert the fork connector on the end of your ground
wire of your RCA Phono cables from your turntable or
record player under the screw terminal. Then tighten
the GND terminal securely by hand. Do not use tools
as this may overtighten and strip the threads.
If your ground wire does not have a fork connector
on the end, simply strip 5mm of insulation off the end
of the ground wire and twist the wire strands tightly.
You can then wrap the ground wire around the GND
terminal and tighten securely. The proper connection of
the ground wire is essential to prevent any hum through
your sound system.
CARTRIDGE TYPE:
Refer to the instructions or specifications that came
with your turntable or record player to determine which
cartridge type your player uses.
If your turntable uses a Moving Magnet type cartridge,
set the CARTRIGDE TYPE switch to ‘MM’.
If your turntable uses a Moving Coil type cartridge, set
the CARTRIGDE TYPE switch to ‘MC’.
OUTPUT:
Using a stereo pair of high quality standard RCA audio
cables, connect the white RCA plug into the white (L)
output socket. Then connect the red RCA plug into the
red output socket (R).
Then connect the other end of your RCA cables to a
suitable Line Input (AUX/CD/TAPE) on your existing
Amplier, Receiver, Mixer or other such music player.
Page | 6
If your system fails to operate normally, please check the following points to determine if the fault
can be corrected with one of the suggestions below.
If you feel your system is still faulty after reading this, please contact your authorised dealer or Service
Troubleshooting
FAULT POSSIBLE CAUSE SOLUTION
No sound on left, right or
both channels.
A loss of connection between your
Turntable and the Phono Stage or
between the Phono Stage and your
Amplier due to loose connections
or damaged cables.
Ensure you have properly connected
your RCA and Phono cables. Also
check that your cables are not
damaged or faulty and replace if
required.
Loud humming sound
through speakers.
Loose, missing or damaged Ground
wire connection.
Ensure your ground wire is properly
and securely connected to both your
turntable ground terminal and the
Phono Stage GND terminal. Replace
your ground wire if damaged.
Output sound is either
too loud, too quiet or
sound is distorting.
MM/MC Switch is incorrectly set.
Check the specications of the
cartridge in use with your turntable
and set MM/MC switch accordingly.
Output sound is either
too loud, too
quiet or sound is
distorting.
Incorrect input being used on your
Amplier or Receiver.
Only plug the output of the Phono
Stage into a LINE input. Never
connect to a Phono input.
PH 1
Page | 7
Specications
Output Level 2.44V 659 mV
Maximum Input 17.55 mV >7 mV
Maximum Output 8.7V >8.52V
Input Impedance 45~56K Ω 80~120 Ω
Output Impedance 110 Ω 110 Ω
Gain (1 KHz) 55 dB 58~62 dB
Distortion (5mV Input) <0.02% <0.08%
S/N (A Weighting) 82.8 dB >64 dB
RIAA Accuracy ±1 dB ±1 dB
Channel Balance <0.23 dB <0.21 dB
Channel Separation >72 dB >55 dB
Input Power 12V DC, 1A
Standby Power Consumption 0.3 Watts Max (115/240V) No Load
Dimensions 152mm (W) x 49mm (H) x 180mm (D) Including Plugs
Weight 850g Main Unit Only
MM MC
Blue Aura Worldwide Guarantee
This entitles you to have the unit repaired free of charge, during the first year after purchase, at any
authorised Blue Aura distributor provided that it was originally purchased from an authorised Blue Aura
dealer or distributor. The manufacturer can take no responsibility for defects arising from accident,
misuse, abuse, wear and tear, neglect or through unauthorised adjustment and/or repair; neither can they
accept responsibility for damage or loss occurring during transit to or from the person claiming under the
guarantee.
The warranty covers: Parts and labour costs for rst year from the purchase date. After one years you
must pay for both parts and labour costs, the warranty does not cover transportation costs at any time.
Claims under guarantee:
This equipment should be packed in the original packing and returned to the dealer from whom it was
purchased, or failing this, directly to the Blue Aura distributor in the country of residence. It should be sent
carriage prepaid by a reputable carrier. No responsibility can be accepted for the unit whilst in transit to
the dealer or distributor and customers are therefore advised to insure the unit against loss or damage
whilst in transit.
All Blue Aura products undergo exhaustive tests and inspections both before and during manufacture to
ensure we deliver products of the highest quality. However, for complete peace of mind please register
your product within 30 days to take advantage of our extended 12 month guarantee.
Please register your product on line at http://www.blueaura.co.uk/register
