Blue elephant Ele6090 User manual

Jinan Blue Elephant CNC Machinery Co.,Ltd

Email：[email protected] Mobile：0086-15064026772 Web：www.elephant-cnc.com

1

ELE6090 and ELE1212 cnc router with Mach 3 control system

BLUE ELEPHANT

Jinan Blue Elephant CNC Machinery Co.,Ltd

Email：[email protected] Mobile：0086-15064026772 Web：www.elephant-cnc.com

2

Thank you for buying our CNC Router.

（Mach3 USB port）

This technical instruction goes with machines, it is also the instructional document which makes sure

you’re correct using. Please read it carefully and keep it well.Please operate the machine according

to this instruction, if any problems or questions, please contact us freely.In order to bring the superior

function of our machine into play, and ensure the safety of the user, please read this instruction carefully

before installation and operating. Then you can have acknowledge in details about what should be paid

attention to, and the parameters of installation and operation, inspection of the abnormality and daily

maintenance rules etc. It is our target to make the customers satisfactory. Thank you for your

cooperation.

BLUE ELEPHANT

Jinan Blue Elephant CNC Machinery Co.,Ltd

Email：[email protected] Mobile：0086-15064026772 Web：www.elephant-cnc.com

3

Thank you for buying our CNC Router........................................................................................................................................1

ⅠUnpacking Inspection............................................................................................................................................................. 3

ⅡSafety Notice.......................................................................................................................................................................... 4

III Control system introduction.................................................................................................................................................... 5

Mach3 install........................................................................................................................................................................ 5

Set Mach3 by yourself(ANVANCE)..................................................................................................................................26

IV. Machine introduction and installation..................................................................................................................................29

.Machine parts introduction................................................................................................................................................30

Electrical cabinet introduction............................................................................................................................................32

Files in the CD you can refer to;........................................................................................................................................ 34

Machine installation........................................................................................................................................................... 35

Lubrication system for moving parts................................................................................................................................. 36

How to connect dust colletor .............................................................................................................................................38

Connect vacuum pump....................................................................................................................................................... 39

Pump for spindle water cooling..........................................................................................................................................40

Connect to main power.......................................................................................................................................................50

Power on the machine ....................................................................................................................................................... 51

Here is the way of setting tool bits on spindle................................................................................................................... 52

How to use the table .......................................................................................................................................................... 52

Calibrator using.................................................................................................................................................................. 54

How to set workpiece zero point .......................................................................................................................................57

V Maintenance.......................................................................................................................................................................... 61

VI. The rules of cutters operation................................................................................................................................63

PS 1MACH3-USB

FAQ solutions

....................................................................................................................................... 64

PS2 Electrical diagram............................................................................................................................................................... 76

PS3There are some other common problem reason and solution..............................................................................................79

ⅠUnpacking Inspection

Before sending, all the parts of CNC router are inspected strictly and packaged carefully. However, damages

may occur during transportation process due to various factors. Please check the following items before

BLUE ELEPHANT

Jinan Blue Elephant CNC Machinery Co.,Ltd

Email：[email protected] Mobile：0086-15064026772 Web：www.elephant-cnc.com

4

unpacking. Inform the distributor or us if any abnormity:

1. Make sure that the machine is not be damaged or distorted during the transportation process.

2. After open the package, check whether the spare parts are the same with the packing list.

3. Check whether the specification you ordered fits the machine’s nameplate (voltage and KVA)

4. Check whether there is any abnormity or foreign material in the machine.

ⅡSafety Notice

This chapter mainly introduces the machine usage notice; the user must read this carefully to avoid the

suddenness.

2.1 The machine should put on the balanced table, adjust the fundus to make sure the machine can’t shake

and keep it horizontal.

2.2 Please use the appointed voltage according to the instruction, connect power and put through the

grounding wire.

2.3 Please do not connect many electronic products on one outlet to avoid overburden.

2.4 The engraving machine is high speed working machine; the main spindle speed can reach to 24000RPM.

So the operator should wear work clothes and hat, forbidden to wear gloves.

2.5 When the machine is working, the operator should keep distance with it. Forbidden to touch the cutter

and other motorial parts.

2.6 Make sure the electric power is off when clean the machine. Do not clean it with the liquid or the

spray, but the dry dust cloth and meanwhile with slushing oil.

2.7 when checking the machine faults Please make sure the power is off.

2.8 Do not use this machine near water, for example: near the bathtub, the bison, and the launder of

the kitchen, wet floor, or swimming pool and so on.

2.9 Do not put this machine on the unstable truck, shelf or tables. Otherwise it may fall down and cause

the machine damage or the hurt of people.

2.10 Only the electric variety on the nameplate can be used in this machine. If you are not familiar

with the electric variety in your place, please ask the vender or the local bureau of supplying

electricity.

2.11 Triangle plug (ground wire) is available for this machine. This just for ground wire type plug use

and this is the safety device. If you cannot use this kind of plug, please ask the electrician

for help. But do not discard the safety device.

2.12 Do not put anything on the electrical power cable, and do not put the cable in the place that someone

BLUE ELEPHANT

Jinan Blue Elephant CNC Machinery Co.,Ltd

Email：[email protected] Mobile：0086-15064026772 Web：www.elephant-cnc.com

5

else can touch.

2.13 Do not make the receptacle or the branch wires afford over-voltage, or there may fire hazard and

electric shock.

2.14 Please don’t put anything into the aperture or put thing in the machine, or else may get an

electronic shock, on fire or other danger caused by dangerous pressure or short circuit.,

2.15 In order to avoid getting an electric shock, please do not disassemble this machine. If it needs

repairing, please take it to the qualified repairing center. Disassembly of this machine may bring

the electric or some other dangers. The incorrect reassembly may cause electric shock in the future

using (unless operation under the instruction of professional engineers).

2.16 Under the following conditions, you need to pull the plug out from the receptacle, and consign the

repairing work to the qualified repairing center:

A. when the cable and the plug are broken.

B. if some liquid inflow the machine.

C. if this machine is rained or watered.

D. if operation is done as what the instruction says, but this machine cannot work, you can only

adjust the controlling part of this machine. Otherwise if you adjust other parts incorrectly,

you may cause damage of this machine. As to the complex work, you had better ask the qualified

worker for help, which can make the machine work orderly.

E. if this machine falls down to the floor from the high position or the body of the machine

are broken.

F. if obvious changes of the machine’s function occur.

2．17 Avoid using the machine when it thunders. Or it can cause faraway electric shock.

The transportation, installation and maintenance make the machine operate well.

III Control system introduction

Mach3 install

Please connect the Mach 3 card to computer with USB cable.

BLUE ELEPHANT

Jinan Blue Elephant CNC Machinery Co.,Ltd

Email：[email protected] Mobile：0086-15064026772 Web：www.elephant-cnc.com

6

Then

Computer Side

Mach 3card Side

BLUE ELEPHANT

Jinan Blue Elephant CNC Machinery Co.,Ltd

Email：[email protected] Mobile：0086-15064026772 Web：www.elephant-cnc.com

7

Find the CD with machine and open this file

Then install mach3 ( USB port) software , Double-click the icon on the left mouse button .

You will see like this .

BLUE ELEPHANT

Jinan Blue Elephant CNC Machinery Co.,Ltd

Email：[email protected] Mobile：0086-15064026772 Web：www.elephant-cnc.com

8

BLUE ELEPHANT

Jinan Blue Elephant CNC Machinery Co.,Ltd

Email：[email protected] Mobile：0086-15064026772 Web：www.elephant-cnc.com

9

BLUE ELEPHANT

Jinan Blue Elephant CNC Machinery Co.,Ltd

Email：[email protected] Mobile：0086-15064026772 Web：www.elephant-cnc.com

10

BLUE ELEPHANT

Jinan Blue Elephant CNC Machinery Co.,Ltd

Email：[email protected] Mobile：0086-15064026772 Web：www.elephant-cnc.com

11

BLUE ELEPHANT

Jinan Blue Elephant CNC Machinery Co.,Ltd

Email：[email protected] Mobile：0086-15064026772 Web：www.elephant-cnc.com

12

BLUE ELEPHANT

Jinan Blue Elephant CNC Machinery Co.,Ltd

Email：[email protected] Mobile：0086-15064026772 Web：www.elephant-cnc.com

13

Wait a moment ……

BLUE ELEPHANT

Jinan Blue Elephant CNC Machinery Co.,Ltd

Email：[email protected] Mobile：0086-15064026772 Web：www.elephant-cnc.com

14

BLUE ELEPHANT

Jinan Blue Elephant CNC Machinery Co.,Ltd

Email：[email protected] Mobile：0086-15064026772 Web：www.elephant-cnc.com

15

BLUE ELEPHANT

Jinan Blue Elephant CNC Machinery Co.,Ltd

Email：[email protected] Mobile：0086-15064026772 Web：www.elephant-cnc.com

16

after installation, mach3 will appear on your PC screen.

BLUE ELEPHANT

Jinan Blue Elephant CNC Machinery Co.,Ltd

Email：[email protected] Mobile：0086-15064026772 Web：www.elephant-cnc.com

17

Insert USB card driver : ,we need it to copy and Paste it into your C:\Mach3\PlugIns

folder

1) find the folder ,then open it .you will see the usb file .

2) Please copy the file . Then open C:\Mach3\PlugIns

BLUE ELEPHANT

Jinan Blue Elephant CNC Machinery Co.,Ltd

Email：[email protected] Mobile：0086-15064026772 Web：www.elephant-cnc.com

18

Paste to here.

BLUE ELEPHANT

Jinan Blue Elephant CNC Machinery Co.,Ltd

Email：[email protected] Mobile：0086-15064026772 Web：www.elephant-cnc.com

19

Start the Mach3 software, a dialogueof “Motion Control Hardware PlugIn sensed!!”

Please select the“Mach3-USB-Motion-Card”，you can also check ”Don't ask me this again”.

When the Mach3 is connecting with the card, the Status indicator (LED on the card) is flashing.

Then we can control machine by mach3, but before that, we have other one thing to do.

After finishing install. We have backup the machine system setting, you just to copy the backup date

to the C:\Mach3

Here is the step .

First find the folder “Mach3 config file”.

Select the“Mach3-USB-Motion-Card”

BLUE ELEPHANT

Jinan Blue Elephant CNC Machinery Co.,Ltd

Email：[email protected] Mobile：0086-15064026772 Web：www.elephant-cnc.com

20

Open it you will see .

Open yours ,and you will see .copy the file ,then paste it into the folder “C:\Mach3”

For3axis machine.

For4axis machine.

For 6axis machine.

BLUE ELEPHANT
