Blue Wave Pool Blaster FUSION PV-5 User manual

READ AND SAVE
THESE INSTRUCTIONS
WARNING: Read carefully
and understand all safety
warnings before operating. Failure
to do so may result in serious
personal injury.
AVERTISSEMENT: Lisez
attentivement et comprenez tous les
avertissements de sécurité avant
de l’utiliser. Ne pas le faire peut
entraîner des blessures graves.
ADVERTENCIA: Lea
atentamente y comprenda todas las
advertencias de seguridad antes de
operar. De lo contrario, puede ocasionar
lesiones personales graves.
LISEZ ET CONSERVEZ
CES INSTRUCTIONS
LEA Y GUARDE ESTAS
INSTRUCCIONES
Cordless Pool &
Spa Vacuum
•
Sans l Aspirateur pour
Piscine et Spa
•
Aspiradora Inalámbrica para
Piscina y Spa
Operator Manual
Manuel de l’opérateur
Manual de uso
FUSION PV-5
®
TM

1
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
WARNINGS AND USAGE INFORMATION
DANGER!
DANGER!
WARNING!
WARNING!
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, CAREFULLY FOLLOW
THESE INSTRUCTIONS. When using electrical
products, read, understand and follow all the
instructions stated in this manual.
DO NOT ALLOW WATER OR OTHER HIGHLY
CONDUCTIVE FLUIDS TO CONTACT THE
USB CHARGING CORD OR CHARGING
JACK PRIOR TO OR WHILE CHARGING THE
APPLIANCE. Pool water is highly corrosive and
will cause damage to the USB charging cord
or charging jack and can cause short-circuit
resulting in smoke, re and/or serious personal
injury. Make sure all surfaces of the USB
charging cord and charging jack are dry and no
water is present before charging the appliance.
CHARGING THE UNIT REQUIRES A USB
CHARGING ADAPTER (NOT INCLUDED)
Use charging adapter with a safety output of
5.0V DC and 1.0A. For EU, a CE-certicated
adapter shall be used. For U.S.A. and Canada,
a limited power source (LPS) or Class 2 type
adapter certied by North American standards
shall be used. Refer to the instruction manual
of USB charging adapter (not included) for
instructions concerning safety and operation.
DROWNING HAZARD. This device produces
suction. Risk of entrapment present. DO NOT
use when bathers are present. Never permit
children to use this product. Never permit
persons who cannot swim to use this product to
prevent the chance of drowning.
WARNINGS
1. Read carefully and understand all safety warnings before using this appliance.
2. Do not attempt to operate if the cleaner or USB charging cord appear to be damaged in any way.
3. All cautions and warnings on the equipment should be noted.
4. Never allow children to operate this product. This is NOT a toy. Children should be supervised
to ensure they do not play with this product.
5. Keep the cleaner and its accessories out of reach of children.
6. This cleaner is not intended for use by persons with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning the use of the appliance by a person responsible for their safety.
7. Charge indoor only.Do not use or store the USB charging cord outdoors. Charge your
cleaner in a clean, dry place and only with the USB charging cord provided. Do not use a USB
charging cord supplied with any other appliance.
8. The warnings, cautions, and instruction discussed in this instruction manual cannot cover all
possible conditions or situations that could occur. It must be understood, the operator should
always exercise intensive caution and common sense when utilizing the cleaner.
9. Risk of electric shock. Do not expose to liquid, vapor or rain. Store cleaner in a clean dry place.
Do not store in direct sunlight or expose to extreme temperatures.
10. Do not plug or unplug the USB charging cord into a power source or the appliance with wet hands.
11. Do not operate this cleaner in the presence of ammable or combustible liquids.
12. Never service the cleaner while the unit is on or connected to the USB charging cord.
13. Installation work and electrical wiring must be done by qualied person(s) in accordance
with all applicable codes and standards, including re-rated construction.
14. Use only the USB charging cord supplied with the cleaner. Never carry the USB charging cord
by its cord or disconnect it from an outlet by pulling on the cord.
15. For pluggable equipment, the socket-outlet shall be installed near the equipment and shall be
easily accessible.
16. Keep proper footing and balance at all times when using the cleaner. Do not overreach.
17. Please disconnect this equipment from AC outlet before cleaning. Don’t use liquid or sprayed
detergent for cleaning. Use moisture sheet or cloth for cleaning.
18. This cleaner contains rechargeable batteries. Do not incinerate the battery as it will explode at
high temperatures. Always dispose of batteries in accordance with local law.
19. Leaks from a battery may occur under extreme conditions. If battery liquid gets on the skin,
wash immediately with water. If it gets in your eyes, immediately ush your eyes with a mild
solution of baking soda and water, and seek medical attention.
20. Keep hair, loose tting clothing and all body parts away from openings and moving parts of
this cleaner.

4
2
SAFETY AND USAGE SYMBOLS
The following symbols and meanings are intended to explain the levels of risk associated with this product:
The following symbols and meanings are intended help you operate the product better and safer. Please study them and learn
their meanings.
Indicates a hazardous situation, which, if not avoided, could result in death or serious injury.
Indicates a hazardous situation, which, if not avoided, could result in death or serious injury.
Indicates a hazardous situation, that, if not avoided, may result in minor or moderate injury.
Indicates a potential personal injury hazard. Basic precautions should
always be followed when seeing this symbol.
Indicates by NO MEANS water should touch the indicated part with this
symbol. If not avoided, may result in minor or moderate injury.
Indicates to charge product for the 4 complete hours.
Recycle batteries in accordance to local law.
Dispose any unwanted product in accordance to local law.
SYMBOL SIGNAL MEANING
SYMBOL NAME EXPLANATION
WARNING!
DANGER!
CAUTION!
SAFETY ALERT
DO NOT GET WET
CHARGE FOR
4 FULL HOURS
BATTERY
RECYCLE
DISPOSAL
USAGE INFORMATION
21. Use this product only for its intended purpose as described in this manual. Use only Water Tech accessories and lters.
22. This product is not intended for commercial use.
23. If the equipment is not in use for long time, disconnect the equipment from mains to avoid being damaged by transient over-voltage.
24. Never leave your cleaner in water when it is “OFF” or when it has run out of power.
25. Do not use your cleaner for pool openings; the cleaner is designed for routine maintenance of your pool or spa.
26. The cleaner is designed for underwater use in swimming pools or spas only. It is not an all purpose vacuum cleaner.
27. Submerge the cleaner in water immediately after turning the unit “ON” to prevent damage to the seal on the motor shaft. Failure to do so will shorten the life of
the water seal and / or void the warranty.
28. Avoid picking up sharp objects as they may damage the lter. Keep all openings on the cleaner free of debris which may reduce water ow.
29. Do not place the cleaner or the USB charging cord on or near hot surfaces.
30. For best results use the USB charging cord in locations where temperatures are between 50˚ F / 10˚C and 100˚ F / 37.7˚ C.
31. For connection to a supply not in the U.S.A., use an attachment plug adapter of the proper conguration for the power outlet.

3
Product Breakdown Panne de Produit Avería de Producto
FCC Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not used
in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation, If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o󰀨 and on, the user is
encouraged to try and correct the interference by one or more of the following measures:
- Reorient or relocated the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit di󰀨erent than that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
NOTE: Changes or modications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Industry Canada Regulatory Information
CAN ICES-3 (B)/NMB-3 (B)
Avis d’Industrie Canada
CAN ICES-3 (B)/NMB-3 (B)
Input.........................................................................................100-240V AC, 50-60Hz
Charging the battery:
It requires USB charging adapter (not included) with the following specications:
Operation
• Make sure the charging receptacle on the product is
dry before any charging.
• A full charge takes up to 4 hours. For EU Market, a
CE-certicated USB charging adapter shall be used.
For US and Canada market, a Class 2 type adapter
certicated by North America standards.
Output..............................................................................................5.0V DC and 1.0A
Battery Tech Data........................................................3.7V, 2200mAH, 8.14Wh Li-Ion
Water temperature range.......................Maximum 96°F, (35°C) Minimum 40°F, (5°C)
Operation Depth.............................Maximum 12 ft. (3.5 m), Minimum 10 in. (0.25 m)
Model: NE9871
Charge Temperature.......................Maximum 100°F, (37.7°C) Minimum 50°F, (10°C)
(1)Vacuum Head
Tête d’aspirateur
Cabeza de la aspiradora
(P14X006)
(2)Head Cover
Couvre de la tête
Cubierta de la cabeza
(3)All Purpose Filter Bag
Sac ltrant tout usage
Bolsa de ltr Bolsa de ltro de todo propósito
(P10XAP)
(4)Power Head
Tête motrice
Cabezal de potencia
(5)Battery Chamber
Corps de l’aspirateur
Compartimiento de baterías
(P14X003LI)
(7)USB Charging Cable
Câble de charge USB
Cable de carga USB
(1S-CBL-01)
(6)Pool Pole (Set of 4)
Piscine Pole (Jeu de 4)
Palo de Piscina (Juego de 4)
Additional Filters (not included): • Sand & Silt Filter Bag (P10XSS)
• Micro Filter Bags - 5 Pack (P30X022MF)
Filtres supplémentaires (non inclus): • Sac ltrant de limon de sable (P10XSS)
• Micro-sacs ltrants - paquet de 5 (P30X022MF)
Filtros adicionales (no incluidos): • Bolsa de ltro de arena y limo (P10XSS)
• Bolsas de microltro - Paquete de 5 (P30X022MF)

C
A
B
D
4
Charging time: 4 hours
Temps de charge: 4 heures
Tiempo de carga: 4 horas
A.1
A.3 Adapter - Not included
Adaptateur - non inclus
Adaptador - No incluido
A.2
OPTIONAL - NOT INCLUDED
OPTIONNEL - NON INCLUS
OPCIONAL - NO INCLUIDO
