Shark CORDLESS SV780 Series User manual

WARNING
To reduce the risk of injury, fire, electric shock, and property damage
resulting from improper use of the appliance, carefully observe the
following instructions. This unit contains electrical connections and
moving parts that potentially present risk to the user.
POWER SUPPLY, CHARGING ADAPTER, AND HAND VACUUM
CONTAIN ELECTRICAL CONNECTIONS:
1. There are NO serviceable parts.
2. DO NOT use to vacuum any liquids.
3. DO NOT immerse in water or other liquids.
4. Inspect charging adapter cord and plug for any damage before use. DO NOT use hand vacuum with a damaged charging
adapter cord or plug. Turn off all controls before plugging in or unplugging the hand vacuum from the adapter.
5. DO NOT use or charge unit outdoors or on wet surfaces. Use only on dry surfaces.
6. If hand vacuum is not working as it should, or has been dropped, damaged, left outdoors, or dropped into
water, return it to SharkNinja Operating LLC for examination, repair, or adjustment.
7. DO NOT pull or carry the charging adapter by the cord or use the cord as a handle.
8. DO NOT unplug the charging adapter by pulling on the cord. Grasp the plug, not the cord.
9. DO NOT handle charging adapter or hand vacuum with wet hands.
10. DO NOT use charging adapter with an extension cord.
11. Use only the charging adapter model XA780N supplied with this appliance.
12. Keep charging adapter cord away from heated surfaces.
13. This hand vacuum includes rechargeable nickel metal hydride batteries. Batteries must be recycled or
disposed of properly. DO NOT incinerate batteries or expose to high temperatures as they may explode.
14. Leaks from battery cells can occur under extreme conditions. If the liquid gets on skin, wash immediately
with soap and water. If the liquid gets into eyes, flush them immediately with clean water for a minimum
of 10 minutes and seek medical attention.
GENERAL USE
15. Use only as described in this manual.
16. Keep your work area well lit.
17. Keep the vacuum cleaner moving over the carpet surface at all times to avoid damaging the carpet fibers.
18. DO NOT place hand vacuum on unstable surfaces such as chairs or tables.
19. DO NOT put any objects into openings. DO NOT use with any opening blocked; keep free of dust, lint, hair, and
anything that may reduce airflow.
20. DO NOT allow the appliance to be used by children. Close attention is necessary when used near children. This is not a toy.
21. DO NOT use without dust cup and filter in place.
22. ALWAYS turn o the hand vacuum before connecting or disconnecting the air-intake nozzle.
DUST CUP, FILTER, AND ACCESSORIES
Before turning on the
hand vacuum :
23. Make sure filter is thoroughly dry after routine cleaning.
24. Make sure dust cup and filter are in place.
25. Make sure accessories are free of blockages.
26. Use only Shark®brand filters and accessories. Using other brands will void warranty.
GENERAL CLEANING
27. DO NOT vacuum up large objects.
28. DO NOT vacuum up hard or sharp objects such as glass, nails, screws, or coins that could damage the hand vacuum .
29. DO NOT vacuum up drywall dust, fireplace ash, or embers. DO NOT use as an attachment to power tools for dust collection.
30. DO NOT vacuum up smoking or burning objects such as hot coals, cigarette butts, or matches.
31. DO NOT vacuum up flammable or combustible materials (e.g., lighter fluid, gasoline, or kerosene) or use hand
vacuum in areas where they may be present.
32. DO NOT vacuum up toxic solutions (e.g., chlorine bleach, ammonia, or drain cleaner).
33. DO NOT use in an enclosed space where vapors are present from paint, paint thinner, moth-proofing
substances, flammable dust, or other explosive or toxic materials.
34. Use extra care when cleaning on stairs.
NI-MH BATTERY
35. WARNING: The cordless hand vacuum is powered by Ni-MH batteries, which must be recycled or disposed of
properly in accordance with state, federal, and local laws.
36. If uncertain as to how to remove the battery pack, we suggest that you take your hand vacuum to a reputable small
appliance service technician to have this service performed.
37. WARNING: DO NOT attempt to replace the batteries used in this hand vacuum with any other type of battery.
38. WARNING: NEVER use ordinary batteries for replacement as these may leak and damage your hand vacuum . Use only the
battery pack provided by SharkNinja.
MAXIMIZING THE LIFE OF YOUR BATTERY
39. DO NOT store the unit with the charging adapter attached and plugged in.
40. DO NOT store in areas of high temperature or humidity.
41. Use only the charging adapter supplied with the hand vacuum . If other chargers are used, the batteries can fail, causing
damage to the battery, hand vacuum, or personal property.
42. After 3 months of non-use, the hand vacuum should be fully discharged and then recharged to maximize battery power.
43. If the hand vacuum has never been stored for an extended period of time without use, it will take several complete
charge and discharge cycles to realize the full operational time of your hand vacuum .
44. Ni-MH batteries have a long, useful life but will eventually need to be replaced. To purchase replacement batteries, visit
sharkaccessories.com
IMPORTANT SAFETY INSTRUCTIONS – FOR HOUSEHOLD USE ONLY
READ CAREFULLY BEFORE USE – SAVE THESE INSTRUCTIONS
FEATURES
SV780
AAir-Intake Nozzle
BDust Cup
CDust Cup Filter
DDust Cup Release Button
ECharging Indicator Light
FOn/O Switch
GMotor Housing
HCharging Base
ICharging Adapter
JMotorized Brush
KCrevice Tool
HAND VACUUM ASSEMBLY AND USE
NOTE: During first use, discharge fully to properly condition the
battery. It takes approximately 2.5 hours to charge battery completely.
NOTE: For maintenance, see reverse side.
CHARGING YOUR HAND VACUUM
4
OFF
ON
11 22
33
1. Push the Dust-Cup Release button and remove the dust cup
to verify that the filter is inside. Reinstall the dust cup.
2. Insert the desired accessory into the air-intake nozzle.
3. Press the power switch to turn on the hand vacuum.
1. Before charging for the first
time, make sure the power
switch is o.
2. Connect charging adapter
to port on the bottom of the
charging base. Turn the charge
adapter plug clockwise one-
quarter of the way around to
secure it place.
3. Plug charging adapter into a
wall outlet and place the hand
vacuum on the charging base.
The Charging Indicator light
will illuminate.
4. Remove the hand vacuum
from the charging adapter
when the Charging Indicator
light turns o. See “Maximizing
the Life of Your Battery.”
A
E
F
H
I
J
K
D
G
TECHNICAL SPECIFICATIONS: 15.6-Volt DC
B
C

Hand vacuum is not picking up debris. No suction or light suction.
(Refer to Maintenance section for more information.)
• Check filter to see if it needs cleaning. Follow instructions
for rinsing and drying the filter before reinstalling.
• Dust cup may be full; empty dust cup.
• Check for blockages in the dust cup filter.
• Make sure that the battery is fully charged.
Hand vacuum will not operate.
• The battery needs to be recharged or replaced.
• The battery may be depleted. Charge the battery until
the Charging Indicator light turns o.
• Ensure nothing is blocking the air-intake opening.
• There is no power in electrical outlet used for charging.
Try to charge using dierent outlet.
Charging Indicator does not illuminate.
• Check to see if the charging adapter is plugged in properly
to the outlet and to the charging port in the base.
• Ensure there is no debris accumulated on the metal charge
contacts on the hand vacuum or charging adapter.
• Ensure that the electrical outlet is supplying power to the
charging adapter.
Dust escapes from hand vacuum.
• Empty the dust cup.
• Ensure that the filter is inserted completely into its holder.
• Check for punctures in dust cup filter or cracks in the dust
cup and replace parts if necessary.
Hand vacuum turns o on its own.
•
Charge the unit until the Charging Indicator light turns o.
Runtime has decreased, charge doesn’t last as long.
Perform the following steps:
• Run hand vacuum until the sound drops significantly, then
turn o the unit.
• Charge the battery for 6 hours.
MAINTENANCE MAINTENANCE
4
1. Press down on the Dust Cup
Release button and remove
the dust cup.
2. Remove filter after taking
dust cup o unit. Empty
debris from dust cup and
filter into a trash bin.
3. Hand wash the filter with
water only. Allow filter to
air-dry completely before
reinstalling.
EMPTYING THE DUST CUP AND CLEANING THE FILTER
TWO-YEAR LIMITED WARRANTY
The 2-Year Limited Warranty applies to purchases made from authorized retailers of
SharkNinja Operating LLC. Warranty coverage applies to the original owner and to
the original product only and is not transferable.
SharkNinja warrants that the unit shall be free from defects in material and
workmanship for a period of 2 years from the date of purchase when it is used under
normal household conditions and maintained according to the requirements outlined
in this instruction manual, subject to the following conditions and exclusions.
What is covered in my warranty?
1The original unit and/or non-wearable components deemed defective, in
SharkNinja’s sole discretion, will be repaired or replaced for up to 2 years from the
original purchase date.
2In the rare event that a replacement unit is issued, the warranty coverage ends six
months following the receipt date of the replacement unit or the remainder of the
existing warranty, whichever is greater. If the unit is replaced, SharkNinja reserves
the right to replace the unit with one of equal or greater value.
What is not covered in my warranty?
Our Customer Service/Product Specialists are available to provide all the warranty
service options available to you, including the possibility of upgrading to our VIP
Warranty Service Options for select product categories.
1Normal wear and tear of wearable parts which require regular maintenance
and/or replacement to ensure the proper functioning of your unit are not covered
by this warranty.
2Any unit that has been tampered with or used for commercial purposes.
3SharkNinja will cover the cost for the customer to send in the unit to us for repair
or replacement. A fee of $19.95 (subject to change) for return shipping costs will
be charged at the time of return shipment of the repaired or replacement unit.
4Damage caused by misuse, abuse, or negligent handling, or damage due to
mishandling in transit.
5Consequential and incidental damages.
6Defects caused by or resulting from damages from shipping or from repairs,
service or alteration to the product or any of its parts which have been performed
by a repair person not authorized by SharkNinja.
7Products purchased, used or operated outside of North America.
Problems with your unit/How to get service:
If your appliance fails to operate properly while in use under normal household
conditions within the warranty period, visit sharkclean.com/support for product
care/maintenance self-help.
Our Customer Service and product specialists are also available at
1-800-798-7398 to assist with product support and warranty service options.
How to initiate a warranty claim:
You can call 1-800-798-7398 to have a Customer Service specialist assist you.
Please note you must call 1-800-798-7398 to initiate a warranty claim. Return and
packing instruction information will be provided at that time.
For Customer Service hours, visit sharkclean.com/support
Replacement parts are available for purchase at sharkaccessories.com. For more
information on which parts are classified as wearable or non-wearable, please visit
sharkclean.com/warranty. This warranty gives you specific legal rights, and you also
may have other rights that vary from state to state.
Some states do not permit the exclusion or limitation of incidental or consequential
damages, so the above may not apply to you.
© SharkNinja Operating LLC 2018
Needham, MA 02494/Ville St. Laurent, Québec H4S 1A7
1-800-798-7398
sharkclean.com
SHARK is a registered trademark of SharkNinja Operating LLC. RBRC is a trademark of
Rechargeable Battery Recycling Corporation.
For Shark | Ninja U.S. Patent information visit sharkninja.com/uspatents
Printed in China.
Illustrations may dier from actual product.
BATTERY REMOVAL AND DISPOSAL
This product uses a rechargeable and reusable Ni-MH battery. When the battery no
longer holds a charge, it should be removed from the hand vacuum and recycled. DO
NOT incinerate or compost the battery.
When your Ni-MH battery needs to be replaced, dispose of it or recycle it in accordance
with local ordinances or regulations. In some areas, it is illegal to place spent
Ni-MH
batteries in the trash or in a municipal solid waste stream. Return spent battery to an
authorized recycling center or to retailer for recycling. Contact your local recycling center
for information on where to drop o the spentbattery.
For more information on battery removal for disposal, please visit
sharkclean.com/batterysupport
TROUBLESHOOTING GUIDE
REPLACING THE BATTERY PACK
1
1
1. Locate the battery
compartment cover on the
underside of the unit. Use a
Phillips-head screwdriver to
remove the single screw in
the batterycover.
2. Slide the battery bar over
and lift out the battery pack.
3. Pull the strap on the battery
pack to disconnect the
terminals.
4. Connect the terminals to new
battery pack. Tuck the wiring
completely into the battery
compartment. Make sure
the terminals are completely
pushed into position.
REGISTER YOUR PURCHASE
TECHNICAL SPECIFICATIONS
registeryourshark.com
Scan QR code using mobile device
Battery Voltage: 16.8V
Motor Watts: 135W
Battery Part Number: XB780N
Hand Vacuum Charging
Adapter Part Number: XA780N
The RBRC™ (Rechargeable Battery Recycling Corporation) seal on the Ni-MH battery
indicates that the costs to recycle the battery at the end of its useful life have already
been paid by SharkNinja. In some areas, it is illegal to place spent Ni-MH batteries
in the trash or municipal solid waste stream and the RBRC program provides an
environmentally conscious alternative.
RBRC, in cooperation with SharkNinja and other battery users, has established
programs in the United States and Canada to facilitate the collection of spent Ni-MH
batteries. Help protect our environment and conserve natural resources by returning
the spent Ni-MH battery to an authorized SharkNinja service center or to your local
retailer for recycling. You may also contact your local recycling center for information
on where to drop o the spent battery, or call 1-800-798-7398.
NI-MH BATTERY MUST
BE RECYCLED OR
DISPOSED OF PROPERLY
RECORD THIS INFORMATION
Model Number: �����������������������������������������
Date of Purchase: ���������������������������������������
(Keep receipt)
Store of Purchase: ���������������������������������������
3
2
2
3
SV780�IB�E�Sheet�EB0�Mv4
WARNING: To reduce the risk of shock and unintended
operation, turn power o and unplug unit before servicing.
R
E
C
Y
C
L
E
1
.
8
0
0
.
7
9
8
.
7
3
9
8
RBRC
NiMh
®
