BlueSpot 35183 User manual

40W GLUE GUN
User Manual
35183

01
Thank you for purchasing a BlueSpot product, you can find further information on our
range at www.BlueSpot.uk.com. Please ensure that you are using the product correct-
ly and that all guidance and cautions are followed in accordance with the instructions.
Please retain these instructions for future reference.
General Information
Please make sure that you read these instructions carefully in order to avoid injury when using
the tool. Follow all health and safety rules and regulations. If in doubt and available please
contact a more knowledgeable source.
DO NOT use if damaged.
WARNING: ALWAYS use safety goggles and the correct PPE when using the glue gun.
WARNING: ALWAYS work in a well ventilated area when using the glue gun.
WARNING: DO NOT touch the nozzle or molten adhesive as they will be extremely hot during and
for some time after use.
WARNING: Noxious and irritating fumes may be released - from heating glue stick. Molten
material may cause burns.
WARNING: DO NOT use the glue gun in damp or wet conditions.
WARNING: DO NOT expose to rain.
• If tool is damaged do not use as this may cause damage to property or injury.
• Maintain tool in good and clean condition for best and safest performance.
• Keep the work area clean, uncluttered and ensure there is adequate lighting.
• Maintain correct balance and footing. Ensure the floor is not slippery and wear
non-slip shoes.
• Keep children and unauthorised persons away from the work area.
• In case of contact with eyes, rinse immediately with plenty of water and seek medical advice.
• Ensure the Glue Stick (2) is inserted correctly into the glue gun before connecting to the
mains power supply.
• Never leave a glue gun unattended. Always make sure the glue gun is disconnected from the
power supply.
• The hot nozzle must never come into contact with flammable materials.
Safe use
• Always practice applying adhesive to scrap materials until confident.
• The glue gun is fitted with a BS1363/A 13 Amp 3 pin plug.
If the cable or plug is damaged during use, remove from use immediately.
Replace a damaged plug with a BS1363/A 13 Amp 3 pin plug. If you are in doubt please contact
a qualified electrician.

Please make sure that you read these instructions carefully in order to avoid injury when using
the tool. Follow all health and safety rules and regulations. If in doubt and available please
contact a more knowledgeable source.
DO NOT use if damaged.
WARNING: ALWAYS use safety goggles and the correct PPE when using the glue gun.
WARNING: ALWAYS work in a well ventilated area when using the glue gun.
WARNING: DO NOT touch the nozzle or molten adhesive as they will be extremely hot during and
for some time after use.
WARNING: Noxious and irritating fumes may be released - from heating glue stick. Molten
material may cause burns.
WARNING: DO NOT use the glue gun in damp or wet conditions.
WARNING: DO NOT expose to rain.
• If tool is damaged do not use as this may cause damage to property or injury.
• Maintain tool in good and clean condition for best and safest performance.
• Keep the work area clean, uncluttered and ensure there is adequate lighting.
• Maintain correct balance and footing. Ensure the floor is not slippery and wear
non-slip shoes.
• Keep children and unauthorised persons away from the work area.
• In case of contact with eyes, rinse immediately with plenty of water and seek medical advice.
• Ensure the Glue Stick (2) is inserted correctly into the glue gun before connecting to the
mains power supply.
• Never leave a glue gun unattended. Always make sure the glue gun is disconnected from the
power supply.
• The hot nozzle must never come into contact with flammable materials.
02
Product Introduction
The BlueSpot 40W Glue Gun is ideal for general use. Hot melt glue dries in approximately 60
seconds depending on the quantity of glue you have applied. Bonds to paper, plastic, wood,
ceramics and some metals. Includes two hot melt glue sticks.This product is double insulated.
Specifications
Input voltage: 50Hz
Max power: 40W
Constant temperature power: 12W
Pre-heating time: 3 - 5min
1. Nozzle
2. Glue Stick
3. Handle
4. Power Cord
5. Trigger
6. Mounting Points For Stand
7. Stand
8. Second Glue Stick 1
2
3
4
5
6
7 8
• Always practice applying adhesive to scrap materials until confident.
• The glue gun is fitted with a BS1363/A 13 Amp 3 pin plug.
If the cable or plug is damaged during use, remove from use immediately.
Replace a damaged plug with a BS1363/A 13 Amp 3 pin plug. If you are in doubt please contact
a qualified electrician.
Safe use (continued)

03
1. Attach the stand (7) to the glue gun using the Mounting Points (6).
2. Insert a Glue Stick (2) into the rear of the glue gun. Push the glue stick forward
until slight resistance is felt.
Before Use
1. Ensure the glue gun is positioned on a clean, stable service area.
2. Plug the Power Cord (4) into a mains power supply.
3. Leave the glue gun for 3-5 minutes so it can reach the normal operating temperature.
4. Gently squeeze the Trigger (5) to advance the glue stick and release the molten adhesive.
5. Release the trigger to stop.
6. Apply the adhesive to one surface only. Bring the two surfaces together immediately. Hold
the joint together for 20-30 seconds to complete the bond.
7. Once you have finished gluing place the glue gun on a flat surface.
NEVER place the tool on its side whilst the glue gun is still connected to the power supply.
Make sure the nozzle is not touching or able to cause damage to surrounding materials.
8. Remove the power cord from the mains supply.
9. Store the glue gun away correctly after allowing the gun to fully cool down from operating
temperature.
Operating the Glue Gun
• When you are gluing different materials apply the adhesive to the least porous material.
• If you are gluing onto cold materials, a better bond can be achieved by pre-warming before
applying the adhesive.
• When gluing textiles or similar materials it is recommended to apply the adhesive in
wavy lines.
• Surplus adhesive can be trimmed with a sharp knife when cooled.
Notes

04
• Ensure all parts of the glue gun are completely cool before storing.
• NEVER wrap the power cord around a tool that has not completely cooled.
• Store the tool in a secure, dry place that is out of the reach of children.
Storage
Notes
ContactDistance to Spot Size
Always check and adhere to national regulations when disposing of any power tools that are no
longer functional and cannot be repaired.
• Do not dispose of power tools with household waste.
• Refer to the glue stick manufacturers recommendations when disposing of residual glue
and unused glue sticks.
• Contact your local waste disposal authority for information on how to correctly dispose of
power tools and chemicals.
Disposal
ContactDistance to Spot Size
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and
packaging should be sorted, taken to a recycling centre and disposed of in a manner which is
compatible with the environment.When the product becomes completely unserviceable and
requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
Environmental Protection
Notes
ContactDistance to Spot Size
Dispose of this product at the end of its working life in compliance with the EU Directive on
Waste Electrical and Electronic Equipment (WEEE). When the product is no longer required,
it must be disposed of in an environmentally protective way. Contact your local solid waste
authority for recycling information.
WEEE Regulations

05
Contact
Notes
Contact
Find out more about the BlueSpot®Lifetime Guarantee at www.BlueSpot.uk.com
Tel: [phone]
Email: [email protected]
Orme Business Centre,
Greenacres Road,
Oldham,
OL4 3NT
