Bluther e-Klavier 1 User manual
Owner’s Manual
Made in Germany
Congratulations on your purchase of your new
lüthner e-Klavier Digital Piano.
We thank you for your condence in our product
and wish you lots of enjoyment with your lüthner e-Klavier.
lüthner e-Klavier 1
lüthner e-Klavier 1
We recommend that you read this operation manual carefully to become
familiar with the many advantages and features of the
lüthner e-Klavier.
lüthner e-Klavier 1
The Blüthner Digital Team wishes you lots of fun making music!
lüthner
e
-Klavi
er 1
1 & 2
lüthner e-Klavier
Owner’s Manual
Made in Germany Page 1
lüthner
e
-Klavi
er 1
1 & 2
e
-Klavier 1
e
-Klavier 2
for EU Countries: NOTICE
is Product complies with the requirements or European Directive EMC 2004/108/ EC
Dieses Produkt entspricht der europäischen Richtlinie EMC 2004/ 108/EC
Ce produit conforme aux exigences de la directive europeenne EMC 2004/108/EC
Questo Prodotto e conforme alle esigenze della direttiva europea EMC 2004 / 108/EC
Este producto cumple con la directrice EMC 2004/108/EC
Dit product beantwoordt aan de richtlijn EMC/108/EC
For Canada: NOTICE
is digital apparatus meets all requirements of the Canadian Interference-Causing regulations.
For Canada: AVIS:
cet appareil numerique respecte toutes les exigencies du Reglements sur la materiel brouilleur du
Candada.
For USA: NOTICE
FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERRERENCE STATE-
MENT
is Equipment has been tested and found comply with the limits for a digital device of the FCC Rules.
ese limits are designed to provide reasonable protection against harmful interference in a residen-
tial installation. is equipment generates, uses, and can radiate radio frequency energy, and, if not
installed and used in accordance with the instructions, maycause harmful interference to radio com-
munications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be deter-
mined by turning the equipment on and o, the use is encouraged to try correcting the interference by
one or more of the following points:
- decrease or increase the separation between the equipment or receiver.
- Relocate or reorient the receiving antenna
- Connect the equipment onto a other outlet from that to which the receiver is connected
- Consult your dealer or an experienced RADIO/ TV technician for help
Notice: Unauthorized Modication or changes on this system/ equipment can void the user authority
to operate this equipment. is Equipment requires shielded interface in order to meet FCC Rules.
DECLARATION OF CONFORMITY: for USA
Model Name: Blüthner e-Klavier 1
Type of Equipment: Digital Piano
Responible Party: Julius Blüthner Pianofortefabrik G.m.b.H
Adress: Dechwitzerstraße 12, 04463 Großpösna
Telephone: +49(0)34297 75130
Dieses Symbol bedeutet, dass dieses Produkt in EU- Ländern getrennt
vom Hausmüll gesammelt werden muss. Mit diesem gekennzeichnete
Produkte dürfen NICHT zusammen mit dem Hausmüll entsorgt werden.
Dies sind regionale Bestimmungen.
lüthner e-Klavier
Owner’s Manual
Made in Germany Page 2
lüthner
e
-Klavi
er 1
1 & 2
Owner’s Manual
TABLE OF CONTENTS
Forward .............................................................................. 4
Features............................................................................... 5
Safety Instructions ............................................................ 6-7
Installation, Operations, and Maintenance.................... 7-8
Accessories.......................................................................... 8
Before You Play
Controls & Functions ....................................................... 9
Connections ....................................................................... 10-11
MIDI Settings ..................................................................... 10
MIDI Channel (transmit/ receive) .................................. 10
Playing Your Instrument
Selecting Sounds ................................................................ 12
Using the Pedals ................................................................. 13
Metronome ......................................................................... 13
Internal Songs
Demo Songs ........................................................................ 14
List of Demosongs .............................................................. 14
Recording............................................................................... 14
Settings
1 Touch (Setting Touch Sensitivity) ................................. 15
2 Transpose (Transposing Keys) ....................................... 16
3 Tuning ............................................................................... 16
Appendix
Specications ...................................................................... 17-18
MIDI Implementation Chart ............................................ 19
Assembly Instructions ....................................................... 20-23
Customer service Information …..................................... 24
lüthner e-Klavier
Owner’s Manual
Made in Germany Page 3
lüthner
e
-Klavi
er 1
1 & 2
FORWARD
About this manual:
First, you should refer to the chapter entitled “Before You Play” (page 9-11) in this
manual. ere the names of the controls and their functions are explained, as well as
their connections and the instrument set up.
e Chapter entitled, “Playing the Instrument” (page 12-13) gives an overview of the
instrument and the most frequently used functions, such as sound selection, pedal
function, metronome, and the Demo song selection and song list.
In the Chapter entitled, “Recording” (page 14) you will nd the explanation for how to
record the songs you play and how to listen to your recording.
In the “Settings” chapter (page 15-16), you will nd descriptions for the touch, tone
and transposition functions.
e Chapter entitled “Appendix” (page 17-23) includes a list of specications and a
MIDI Implementation chart, as well as step-by-step assembly instructions.
e Service Hotline and environmental protection can be found on page 24.
lüthner e-Klavier
Owner’s Manual
Made in Germany Page 4
lüthner
e
-Klavier
1
1 & 2
FEATURES
BLÜTHNER PIANO SOUND
e Blüthner e-Klavier recreates the unique sound of the hand-made, world-renowned
Blüthner Model One concert grand piano. All 88 keys of this exceptional instrument
have been meticulously recorded and analyzed. While playing on the new Blüthner
e-Klavier, the nuances of each note have been faithfully reproduced by new Acoustic
Piano Simulation (APS) Blüthner sound technology.
is unique process accurately recreates the broad dynamic range of the original
instrument with a natural sound. e large selection of high-quality sounds are
further supported by additional eects, such as Harmonic Damper Modeling, Aliquot
Resonance Modeling and reverb, which provide a more realistic sound reproduction.
SONG-RECORDER
With the built-in song recorder you can record your music to the internal memory
bank and play it back. is function is especially useful for beginning students learning
the piano.
e-Klavier 1
BLÜTHNER GRAND-TOUCH KEYBOARD
e Grand-Touch Keyboard with Escapement provides a unique action dynamic. e
mechanical implementation gives the pianist an excellent feel comparable to a concert
grand action.
e-Klavier 2
BLUTHNER WOODEN GRAND-TOUCH KEYBOARD
e wooden Grand-Touch Keyboard provides a unique action dynamic with the
enhanced weight and feel of wooden keys. e mechanical implementation gives the
pianist an excellent feel comparable to a concert grand action.
*e white keys are made of wood and the black keys are synthetic.
lüthner e-Klavier
Owner’s Manual
Made in Germany Page 5
lüthner
e
-Klavi
er 1
1 & 2
®
®®
SAFETY ADVISORY
Please read carefully before you continue!
WARNING!
Always follow the precautions described below to avoid the risk of serious injury
or death, electric shock, short-circuiting, damages, re or similar hazards. ese
precautions include the following points, but do not constitute an exhaustive list:
POWER CORD / POWER SUPPLY
Always use the correct power voltage printed on the nameplate and the associated
power cord. Protect the power cord from heaters, radiators, and similar heat-emitting
sources. Do not bend or turn the power cord too much, and avoid the laying the
power cable in places where someone could trip or roll something over it.
DO NOT OPEN
Never try to open any part of your keyboard to disassemble or modify it in any way.
If you encounter any problem, please contact our qualied Blüthner Customer Service
Team (See page 24).
IMPORTANT
Never connect or pull out the power plug with wet hands.
lüthner e-Klavier
Owner’s Manual
Made in Germany Page 6
lüthner
e
-Klavier
1
1 & 2
WATER HAZARD
Please always make sure that the instrument is not exposed to moisture or dampness.
e instrument should not be used in damp or wet environments. Do not place
containers with liquid contents, e.g. glasses, bottles, vases, etc., on the instrument, as
this can cause liquid to penetrate into the instrument. In the event liquid enters the
instrument, immediately turn o the power and unplug the power cord.
FIRE PROTECTION
Do not put candles or open ames on the instrument.
An open ame could cause a re.
INSTALLATION/ ASSEMBLY (of e-Klavier 1)
Please read the attached installation and assembly instructions carefully, which
describes the precise assembly of the instrument (Page 20-23). Failure to observe the
instructions in the installation chapter of this manual may cause damage or even cause
injury.
PLACE OF INSTALLATION
Do not expose the instrument to excessive dust, vibrations, or extreme heat or cold.
Avoid placing the instrument near TV sets, mobile phones, or other electrical devices,
as this can lead to noise, interference or cross-modulation. Place the instrument
on a solid and secure base to prevent accidental tipping or falling. Your instrument
should be placed a minimum distance of 5 cm away from the wall in order to
provide adequate air circulation. Disconnect all connected cables before moving the
instrument.
WARNING
Only remove dust or dirt with a so cloth. Only use slight pressure while cleaning to
avoid scratcing the surface of the instrument. When cleaning, do not use thinners,
solvents or liquids with chemical substances.
lüthner e-Klavier
Owner’s Manual
Made in Germany Page 7
lüthner
e
-Klavi
er 1
1 & 2
HANDLING WARNING
Please be careful not to jam your ngers in the movable keyboard cover.
Please do not insert objects into any of the openings in the instrument.
In the event that an object does become lodged in the instrument, immediately unplug
the power cord and contact the Blüthner Customer Service Team (Service page 24).
e instrument may only be repaired by authorized personnel.
ADVISORY
Blüthner Piano Factory is not responsible for damage caused by the improper use or
handling of the instrument, or by any unauthorized changes to the instrument, or for
the loss or destruction of stored data. Always turn the power o when the instrument
is not in use! Even if your power is o, current still ows to the instrument. If
the instrument will not be used for some time, ensure a galvanic separation of the
instrument from the power lines by unplugging the power cord from the outlet.
ACCESSORIES
MANUAL (Complete instructions for the Blüthner e-Klavier 1 & 2).
POWER CORD
ASSEMBLY INSTRUCTIONS for e-Klavier 1
TUNING: e Blüthner e-Klavier does not need to be tuned.
TRANSPORT: e instrument can be shipped assembled.
lüthner e-Klavier
Owner’s Manual
Made in Germany Page 8
lüthner
e
-Klavier
1
1 & 2
BEFORE YOU PLAY
DIRECT CONTROL
INTERFACE
Power ON / OFF: (To the right of the key-
board.) Turns the instrument on and o.
Volume: Adjusts the volume of the piano
and the headphones.
Metronome: Starts and Stops the
metronome function (See page 13).
Record: Starts the recording mode to
record songs (See page 14).
Play: Starts and stops the playback of your
recorded pieces (See page 14).
Transpose: Turns the transpose function
ON and OFF (See page 16).
Touch: Adjusts the touch sensitivity or
velocity of the keyboard (See page 15).
Tune: Changes the number of Herz of the
tuning in 10 Hz increments (See page 16).
2
3
4
5
6
7
8
9
10
11
2
34 5
678
910 11
lüthner e-Klavier
Owner’s Manual
Made in Germany Page 9
lüthner
e
-Klavier
1
1 & 2
Select Le: e two Selection buttons <</>> cycle through the sound library.
Grand Piano Button: Returns the instrument to the default Blüthner piano
sound.
Select Right: e two Selection buttons <</>> cycle through the sound library.
Demo Function: Press buttons 9 and 10 together to play the Demo songs (See
page 14).
Audio OUT : Here you can connect your Blüthner e-Klavier to an amplier,
recorder, or other active speaker system.
Audio IN: Here you can connect other devices to the Blüthner e-Klavier, e.g.
MP3 players, CD players, keyboards or sound modules and
expanders.
Pedals: is connection is used to connect the pedals to the instrument.
MIDI- jacks: ere are 3 available connectors: IN / OUT / THRU
Here you can connect your instrument to other MIDI devices, e.g.
Expander, sound modules, or other MIDI compatible devices.
USB-HOST: Here you are able to connect a PC for MIDI and data transmission.
MIDI SETUP
MIDI is an acronym for Musical Instrument Digital Interface. It is an international
standard that allows devices such as electronic instruments and computers to
communicate with each other.
MIDI Connections: e Blüthner e-Klavier 1 & 2 contain the classic MIDI trio, i.e.
MIDI IN, MIDI OUT and MIDI THROUGH.
MIDI IN: receives notes and commands from other devices / instruments.
MIDI Out: sends notes and commands to other devices / instruments.
MIDI ru: MIDI signals received by the MIDI IN go straight to the MIDI ru
jack, which can be connected to multiple devices.
MIDI Channels: e Blüthner e-Klavier sends out a signal (MIDI OUT) through
MIDI channel 1. e Blüthner e-Klavier receives a signal (MIDI IN) through MIDI
channel 1. e MIDI-channels on the Blüthner e-Klavier 1 & 2 are xed and cannot be
changed.
CONNECTIONS
(e-Klavier 1 - beneath the keyboard bed)
(e-Klavier 2 - beneath the soundboard)
lüthner e-Klavier
Owner’s Manual
Made in Germany Page 10
lüthner
e
-Klavi
er 1
1 & 2
Caution: If you connect the power cord into the outlet,
make sure that the voltage matches the voltage specied on the nameplate.
Caution: Never unplug the power cord with wet hands.
is may result in electric shock or electrical shock may result.
HEADPHONE PORTS
Headphone A: Upon inserting the headphones, the built-in
loudspeakers turn o.
Headphone B: is jack can be used in the same manner as the
Headphone A jack. Using the Headphone B jack,
the built-in speaker system does not switch o.
NOTE: You should not use the headphones for too long at too high a
volume level. is can lead to severe and permanent hearing damage (Tinnitus).
Upon inserting the headphones, the built-in
is jack can be used in the same manner as the
POWER SUPPLY
(e-Klavier 1 - Beneath the keyboard bed)
(e-Klavier 2 - Beneath the soundboard)
lüthner e-Klavier
Owner’s Manual
Made in Germany Page 11
lüthner
e
-Klavier
1
1 & 2
Owner’s Manual
PLAYING YOUR INSTRUMENT
SOUND SELECTION
By pressing the GRAND PIANO button, you will always return to the default sound
of the Blüthner Concert Grand Piano. Use the SELECTION buttons << / >> to scroll
through the available sounds of your Blüthner e-Klavier one by one.
SOUNDLIST
1 Blüthner Grand Piano 1
2 Blüthner Grand Piano 2
3 Vintage E- Piano 1
4 Vintage E- Piano 2
5 Vintage E- Piano 3
6 Vibraphone
7 Harpsichord
8 Clavinet
9 Organ 1
10 Organ 2 (Dynamic Switching Sound)
11 Church Organ 1
12 Small Church Organ
13 Church Organ 2 (Dynamic Switching Sound)
14 Classic Strings
15 Synth Pad
16 Choir
17 Classic Guitar
Layers:
18 Grand Piano & Strings
19 Vintage Piano 1 & Pad
20 Vintage Piano 2 & Strings
21 Vintage Piano 3 & Strings
22 Church & Choir
Split :
23 Grand Piano & Upright Bass
24 Vintage E- Piano 1 & E-Bass
25 Vintage E- Piano 2 & E-Bass
lüthner e-Klavier
Owner’s Manual
Made in Germany Page 12
lüthner
e
-Klavi
er 1
1 & 2
USING THE PEDALS
e Blüthner e-Klavier is tted with 3 pedals, which function like the pedals of a
grand piano.
So Pedal: reduces the volume level and makes the sound soer.
Sostenuto Pedal: sustains all the notes currently held down when rst depressed,
while allowing subsequent notes to play normally.
Sustain Pedal: simulates the withdrawal of the dampers in an acoustic piano,
allowing the sound to continue aer releasing the keys until the
pedal is released.
METRONOME
e metronome gives to you a precise rhythm optimally oriented to practice by.
Turning the metronome ON and OFF:
Press the METRONOME button on the control panel. e metronome starts and the
METRONOME LED lights up. Pressing the METRONOME button again stops the
metronome, and turns the LED light o.
Changing the metronome TEMPO:
e tempo of the metronome begins at a default rate of 120 BPM (Beats Per Minute).
To change the pace, use the SELECTION buttons << / >> on the control panel.
>> = Faster (10 BPM per click)
<< = Slower (10 BPM per click)
lüthner e-Klavier
Owner’s Manual
Made in Germany Page 13
lüthner
e
-Klavier
1
1 & 2
Owner’s Manual
Damper PedalSostenuto PedalSo Pedal
RECORDING
Recording a Song/ Piece:
Press the REC button on the keypad.
e REC LED lights up and you can start recording.
Press the REC button to stop recording.
Playing back your recording:
Press the PLAY / STOP button.
e PLAY / STOP - LED lights and your recordings will be played.
Press the PLAY / STOP button to stop playback.
DEMOSONGS
e Blüthner e-Klavier is equipped with fourteen (14) Demo songs, featured so you
can gain an impression of the extensive sonic possibilities of the Blüthner e-Klavier.
Playing and Selecting DEMO SONGS:
By simultaneously pressing the SELECTION buttons << / >>, the demo songs will
play. You can choose between songs by using the SELECTION buttons << / >>.
Press the SELECTION buttons << / >> again simultaneously to stop the DEMO
function.
LIST OF DEMO SONGS
Every Time You Smile Blüthner Grand 1 played by Gianni Giudici
Claire de Lune Blüthner Grand 1 played by Silvia Filomena
Dr. Gradus Blüthner Grand 1 played by Silvia Filomena
Greensleeves Blüthner Grand 1 played by Gianni Giudici
Oh My Beloved Daddy Blüthner Grand 1 played by Gianni Giudici
Rhodex Demo 1 Vintage Piano 1 played by Gianni Giudici
RhoDX Demo 1 Vintage Piano 3 played by Gianni Giudici
Wurlixer Demo 1 Vintage Piano 2 played by Gianni Giudici
Clavinet Demo 1 Clavinet played by Gianni Giudici
Hammond Demo 1 Organ 1 played by Gianni Giudici
Strings 1 Strings played by Gianni Giudici
Classic Guitar Classic Guitar played by Gianni Giudici
Church Organ Demo Church Organ 1 played by Gianni Giudici
Choir Demo Choir played by Gianni Giudici
lüthner e-Klavier
Owner’s Manual
Made in Germany Page 14
lüthner
e
-Klavi
er 1
1 & 2
SETTINGS
TOUCH (TOUCH SENSITIVITY OF THE KEYBOARD)
With the TOUCH function, you can customize the touch sensitivity and response of
your keyboard. Similar to our grand pianos, this changes the key strike velocity, the
volume and the sound of the entire instrument.
To adjust the TOUCH function:
Press the TOUCH button on the keypad to enter the TOUCH adjustment mode.
e TOUCH LED lights up, and you can press the SELECTION buttons << / >> to
adjust the value of the touch sensitivity as follows:
LIGHT: With this setting, a light touch produces a higher volume. is is
particularly suitable for beginners who may not have sucient nger
strength, or for players with a lighter playing style.
NORMAL: (default) normal velocity and response of a grand piano.
HEAVY: With this setting, a heavier touch is required to produce a higher
volume. is setting is particularly suited for players with a heavy
touch, or a heavier playing style.
To save TOUCH settings and play:
Press the TOUCH button a second time to save the new touch setting and exit the
TOUCH adjustment mode. e TOUCH LED will blink, indicating the new TOUCH
setting is active, while the SELECTION buttons << / >> and other control panel
functions become available again to use.
To re-enter the TOUCH adjustment mode:
Press the TOUCH button so it lights up without blinking. You may now use the
selection buttons <</>> to modify the TOUCH setting again. You may also restore
the default TOUCH setting by pressing the GRAND PIANO button.
To turn o the TOUCH function:
From within the TOUCH adjustment mode, restore the default settings with the
GRAND PIANO button and press the TOUCH button a nal time.
lüthner e-Klavier
Owner’s Manual
Made in Germany Page 15
lüthner
e
-Klavier
1
1 & 2
Owner’s Manual
TRANSPOSE (TRANSPOSING)
With the TRANPOSE function, you can transpose the entire keyboard by halones.
To Adjust the TRANSPOSE function:
Press the TRANSPOSE button to enter the TRANSPOSE adjustment mode. e
TRANSPOSE LED lights up. Now the SELECTION buttons << / >> can be used
to transpose up or down by one halone per click. You may also restore the default
TRANPOSE setting by pressing the GRAND PIANO button.
To save TRANSPOSE settings and play:
Press the TRANSPOSE button a second time to save the new touch setting and exit
the TRANPOSE adjustment mode. e TRANPOSE LED will blink, indicating the
new TRANPOSE setting is active, while the SELECTION buttons << / >> and other
control panel functions become available again to use. To re-enter the TRANPOSE
adjustment mode, press the TRANPOSE button so it lights up again without
blinking.
To turn o the TRANPOSE function:
From within the TRANSPOSE adjustment mode, restore the default settings with the
GRAND PIANO button and press the TRANSPOSE button a nal time.
TUNE (TUNING)
With the TUNE function, you can change the tuning by 10 Hz increments.
To adjust the TUNE function:
Press the TUNE button to enter the TUNE adjustment mode. e TUNE LED light
will turn on. e default tuning scale is 440 Hz. Now the SELECTION buttons <<
/ >> can be used to move the tuning up or down by 0.5 Hz per click. You may also
restore the default 440 Hz tuning scale by pressing the GRAND PIANO button.
To save TUNE settings and play:
Press the TUNE button a second time to save the new tuning setting and exit the
tuning adjustment mode. e TUNE LED will blink, indicating the new tuning setting
is active, while the SELECTION buttons << / >> and other control panel functions
become available again to use. To re-enter the TUNE adjustment mode, Press the
TUNE button so it lights up again without blinking.
To turn o the TUNE function:
From within the TUNE adjustment mode, restore the default tunings setting with the
GRAND PIANO button and press the TUNE button a nal time.
lüthner e-Klavier
Owner’s Manual
Made in Germany Page 16
lüthner
e
-Klavi
er 1
1 & 2
lüthner
e
-Klavier 1
Owner’s Manual
lüthner e-Klavier
Owner’s Manual
Made in Germany Page 17
lüthner
e
-Klavier
1
1 & 2
SPECIFICATIONS
Number of Keys 88 Notes
Keyboard Blüthner Grand Touch 4 zones, Graded Hammers with
Escapement
Touch Sensitive Ye s Ye s
Pedals 3 Pedals with Half Damper Damper (Half Damper), Sostenuto, So
Panels Control & Function Panels 9 Button Backlit Panel, 1x Volume
Cabinet
Cabinet Blüthner e-Klavier 1 Cabinet PVC and Lacquered versions available
Key Cover Ye s Sliding lid design
Colors Black Satin, White Satin Black High Gloss available
Music Rest Ye s
Technology & Voice
Tone Generation Blüthner APS Technology (APS) Acoustic Piano Simulation
Damper Resonance APS Damper Modeling (APS) Acoustic Piano Simulation
String Resonance Blüthner Aliquot Modeling Aliquot String Resonance Modeling
Polyphony 144 Notes maximum 128 Notes Polyphony
Voices 25 Blüthner Sounds 25 Special APS Sound Presets
Eects Reverb, Chorus, Phaser, Tremolo Damper Resonance, String Resonance
Song Recorder 1 Track - 1 Channel 30,000 notes maximum
Metronome Ye s Tempo-range 30 to 280 BPM
Transpose 24 Semitones up 24 Semitones down
Tuning Fine-Tune by 0.5 Hz steps up Fine-Tune by 0.5 Hz steps down
Headphones 2 headphone jacks
MIDI MIDI IN, OUT, THRU MIDI Trio
Audio IN Mono IN le and right Stereo
Audio OUT Mono OUT le and right Stereo
USB USB Host MIDI USB Connection
Ampliers 2 x 50 Watt digital amplier New Blüthner digital 100 Watt amplier
Speakers Blüthner 6” wide range Designed by Günter Phillip PCL Audio
®®
®
®
APPENDIX
SPECIFICATIONS
lüthn
er e-Klavier 1
e
-Klavier 2
lüthner e-Klavier
Owner’s Manual
Made in Germany Page 18
lüthner
e
-Klavi
er 1
1 & 2
Number of Keys 88 Notes
Keyboard Blüthner Grand Touch
(Wooden)
4 zones, Graded Hammer, Wooden
Touch Sensitive Ye s Ye s
Pedals 3 Pedals with Half Damper Damper (Half Damper), Sostenuto, So
Panels Control & Function Panels 9 Button Backlit Panel, 1x Volume
Cabinet
Cabinet Blüthner e-Klavier 2 Cabinet Lacquered versions available
Key Cover Ye s
Colors Black Satin, White Satin Black High Gloss available upon request
Soundboard Authentic Acoustic Behavior Acoustic Piano Simulation (APS)
Music Rest Ye s
Technology & Voice
Tone Generation Blüthner APS Technology Acoustic Piano Simulation (APS)
Damper Resonance APS Damper Modeling Acoustic Piano Simulation (APS)
String Resonance Blüthner Aliquot Modeling Aliquot String Resonance Modeling
Polyphony 144 Notes maximum 128 Notes Polyphony
Voices 25 Blüthner Sounds 25 Special APS Sound Presets
Eects Reverb, Chorus, Phaser,
Tremolo
Damper Resonance, String Resonance
Song Recorder 1 Track - 1 Channel 30,000 notes maximum
Metronome Ye s Tempo-range 30 to 280 BPM
Transpose 24 Semitones up 24 Semitones down
Tuning Fine-Tune by 0.5 Hz steps up Fine-Tune by 0.5 Hz steps down
Headphones 2 headphone jacks
MIDI MIDI IN, OUT, THRU MIDI Trio
Audio IN 2 x Mono IN le and right Stereo In
Audio OUT 2 x Mono OUT le and right Stereo Out
USB USB Host MIDI USB Connection
Ampliers 2x 50 Watt digital amplier New Blüthner digital 100 Watt amplier
Speakers Blüthner 6” wide range Designed by Günter Phillip PCL Audio
®
®
®
®
®
®
Function Transmit Receive Remarks
Basic Channel 1 1
Note Number 0-127 0-127 including Transpose
Volume 7 7 Control Change
Damper 64 64 Right Pedal
Sostenuto 66 66 Middle Pedal
So 67 67 Le Pedal
Program Change 1-25 1-25 Sound Select
Aertouch x x
Velocity Ye s Ye s
Song Record 1 1
Song Play 1 1
Transpose x x change on panel
Pitch Bend xYe s from Midi Controller
MIDI Implementation Chart
lüthner
e
-Klavier
1
1 & 2
Owner’s Manual
lüthner e-Klavier
Owner’s Manual
Made in Germany Page 19
lüthner
e
-Klavier
1
1 & 2
ASSEMBLY INSTURCTIONS for e-KLAVIER 1
ATTENTION!
Please assemble the piano on a level oor.
All parts must be assembled in the correct order.
Use only the original parts (screws, brackets, etc.)
Using the wrong parts or screws can cause damage to the Blüthner e-Klavier 1.
For optimal setup, two people are required to assemble to Blüthner e-Klavier 1.
It is recommended that you ensure all the assembly parts are accounted for and
prepared in their proper quantity, as listed below, before beginning the assembly
process.
WARNING!
Please read the attached installation and assembly instructions carefully, which
describes the precise assembly of the instrument. Failure to observe the instructions in
the installation chapter of this manual may cause damage or even injury.
LIST OF ASSEMBLY PARTS:
4 - wooden dowels 6 x 35 mm (Part No. SPN 01627)
2 - countersunk screws 5 x 70 mm (Part No. SPN 210175070)
4 - wooden dowels 8 x 30 mm (Part No. SPN 01631)
4 - socket head screws M6 x 50 mm (Part No. 00656 - black; 00657 - white)
6 - countersunk screws 4 x 30 mm (Part No. VIT 00587 - black; VIT 00588 - white)
6 - round head screws 3,9 x 13,5 mm (Part No. 250990018 - black; 250990017 - white)
4 - countersunk screws M4 x 20 mm (Part No. VIT 00586 - black; VIT 00535 - white)
8 - socket head screws M6 x 50 mm (Part No. VIT 00656 - black; VIT 00657 - white)
2 - metal corner brackets (Part No. STF00200 - black; STF00201 - white)
1 - allen wrench (Part. No. 394000142)
Page 20
lüthner
e
-Klavier
1
1Assembly Instructions
This manual suits for next models
1
Table of contents
