BMW C1 User manual

1
Service and Technical Booklet
C1
C1 200


Please note
dWarning:
This symbol stands for precau-
tions and measures which are
essential in order to protect the
rider or other persons from pos-
sibly severe or fatal injury.
eImportant:
Specific instructions and safety
precautions intended to prevent
damage to the vehicle. Disregard-
ing them may render the warranty
invalid.
LNote:
Specific instructions on how to op-
erate, control, adjust or look after
items of equipment on the vehicle.


11
1
BMW Service
1
For safety reasons and to main-
tain the value of your vehicle,
regular maintenance intervals
have been laid down.
Always keep to the specified
maintenance intervals. This is
the only way to ensure that war-
ranty claims are not invalidated.
The contents of maintenance
schedules can change for
safety reasons, owing to
changes of materials, for exam-
ple.
Your authorised BMW dealer
can provide details of the cur-
rently specified Service,
Inspection and Annual Service
work needed.
Important:
BMW refuses to accept liability
for damage or consequential
damage due to repairs or serv-
ice work carried out by other
than BMW-authorised work-
shops.
Have service and inspection
work carried out by specialists,
preferably by your authorised
BMW dealer's specially trained,
expert personnel, and con-
firmed by an entry in the Service
and Technical Booklet.
Authorised BMW dealers are
supplied with the latest techni-
cal information and have the
necessary technical know-how
and specially trained staff.
If you have any questions about
your vehicle, it is always best to
contact your authorised BMW
dealer.
Authorised BMW dealers are
fully informed about all aspects
of your vehicle and will gladly
advise and assist you.
Best wishes,
BMW Motorrad
Dear BMW C1 enthusiast


2
BMW Service
1
For your own safety, use only
genuine BMW spare parts and
accessories approved by
BMW.
If you choose genuine accesso-
ries and spare parts that have
been tested and approved by
BMW, you can be sure that the
appropriate tests have been
carried out to confirm their suit-
ability for use on your vehicle.
BMW accepts full liability for
these products.
Note however that BMW is
unable to accept any liability
for spare parts and accesso-
ries which it has not
approved.
BMW cannot assess every sin-
gle product of outside origin in
order to decide whether it can
be used on or with a BMW vehi-
cle without constituting a safety
hazard.
Nor is approval by an official
technical inspection authority,
or even the granting of a gen-
eral operating permit necessar-
ily a sufficient guarantee, since
these test procedures are not
always adequate.
Genuine BMW spare parts,
accessories and other products
which BMW has approved can
be obtained from all authorised
BMW dealers, together with
expert advice on their installa-
tion and use.
Important safety information


11
3
BMW Service
1
Maintenance work is divided up
into Service, Inspection and
Annual Service.
Inspection after the first
1,000 km (600 miles)
BMW Running-in Check after
the first 1,000 km/600 miles.
BMW Service
After the first 7,500 km
(4,500 miles) and each
additional 15,000 km (9,000
miles)(22 500 km, 37 500 km…/
13,500 miles, 22,500 miles…)
BMW Inspection
After the first 15,000 km
(9,000 miles) and each additional
15,000 km (9,000 miles),
(30000 km, 45000 km…/
18,000 miles, 27,000 miles…)
BMW Annual Service
Certain items of maintenance
work depend on elapsed time
as well as the distance the vehi-
cle has covered. They should
therefore be carried out at least
once a year (e. g. changing the
brake fluid).
If these items cannot be carried
out during a Service or an
Inspection, an Annual Service
must be performed.
LNote:
Every authorised BMW dealer
has a fixed scale of charges
based on work times and care-
fully calculated hourly rates.
Fuel, lubricants and similar sub-
stances, filters, gaskets etc. are
charged separately.
Maintenance work


4
BMW Service
1
1,000 km Inspection BMW Service BMW Inspection BMW Annual Service
Read out the fault memory with the
MoDiTeC or Dis Plus unit XXXX
Change the engine oil while at regular
operating temperature and replace the
oil filter element 1) *)
XXXX
Clean oil strainer and the magnetic oil
drain plug. XXXX
Change transmission fluid, (every
30,000 km/18,000 miles or 3 years) *) x7) X4)
Check coolant, top up if necessary,
check hoses for damage and abrasion XX
Change coolant (every 2 years) *) X3)
Check valve clearances and adjust if
necessary *) XXX
Replace spark plug X X
Replace air filter element 2) XX
Drain condensate drain hose from air
manifold X
Brake hoses and connections: check
condition and routing XX
Check operation of brake system and
check for leaks; repair/replace as nec-
essary *)
XX
Maintenance schedule


11
5
BMW Service
1
Check brake-fluid level in front and rear
systems, top up if necessary *)XXX
Examine brake pads and discs for wear,
renew if necessary *)XX
Change the brake fluid annually X
Replace variator drive belt X X
Check clutch liner, replace if
necessary *) X
Clean variator strainer (filter) X X
Grease driving variator
(C1 only - not C1 200) X 5) X 5)
Replace driving variator assembly
(C1 only - not C1 200, every 22500 km/
14,000 miles) *)
X5, 6)
Check wheel bearings for play; replace
if necessary *) X
Check that trailing link bearing has zero
play XX
Battery: check battery acid level, if nec-
essary add distilled water XX
Clean/grease battery poles if necessary X
1,000 km Inspection BMW Service BMW Inspection BMW Annual Service
Maintenance schedule


6
BMW Service
1
Check freedom of movement of Bow-
den cables, check for abrasion and
damage
XX
Easy-lift mechanism: check operation of
mechanism and check freedom of
movement
XXX
Check windscreen washer system;
adjust nozzles if necessary and top up
washer fluid in reservoir
XXX
Check windscreen wiper; replace wiper
blade if necessary *) XXX
Safety elements: check cable for
release, belt buckles, belt strap, inertia
reels, and belt locks
XXXX
Check crash element for damage X X X X
Check shoulder bars for damage, if nec-
essary replace deformation element*) XXXX
Replace fuel filter
(every 37,500 km/22,500 miles) X8)
Vehicles with ABS only:
Replace sealing boot in brake master cyl-
inder (every 30,000 km/18,000 miles) *)
X7)
1,000 km Inspection BMW Service BMW Inspection BMW Annual Service
Maintenance schedule


11
7
BMW Service
1
Check tightness of bolts and nuts at
engine mountings and quick-release
axles
X
Final inspection with road safety and
functional check:
–Clutch engagement, steering, brakes
(front and rear)
–Condition of tyres and rims, tyre pres-
sures
–Lights and signalling equipment, tell-
tale and warning lights, instruments
–Trial run if necessary
XXX
1) If the vehicle is ridden for short distances only or at outside
temperatures below 0 °C: every 3 months or after every
3,000 km (1,800 miles) at the latest
2) Change more frequently if vehicle is used in very dirty or
dusty conditions
3) Every 2 years at the latest
4) Every 3 years at the latest
5) C1 only - not C1 200
6) Every 22,500 km (13,500 miles)
7) Every 30,000 km (18,500 miles)
8) Every 37,500 km (23,000 miles)
*) Charged as an additional item
1,000 km Inspection BMW Service BMW Inspection BMW Annual Service
Maintenance schedule


8
BMW Service
1
Confirmation of maintenance work
BMW Inspection
1,000 km
Carried out in accordance with
manufacturer's instructions
at odometer
reading
Date, stamp, signature
BMW Inspection
15,000 km
Carried out in accordance with
manufacturer's instructions
at odometer
reading
Date, stamp, signature
BMW
Pre-delivery Check
Carried out in accordance with
manufacturer's instructions
at odometer
reading
Date, stamp, signature
BMW Service
7,500 km
Carried out in accordance with
manufacturer's instructions
at odometer
reading
Date, stamp, signature


11
9
BMW Service
1
Confirmation of maintenance work
BMW Inspection
30,000 km
Carried out in accordance with
manufacturer's instructions
at odometer
reading
Date, stamp, signature
BMW Inspection
45,000 km
Carried out in accordance with
manufacturer's instructions
at odometer
reading
Date, stamp, signature
BMW Service
22,500 km
Carried out in accordance with
manufacturer's instructions
at odometer
reading
Date, stamp, signature
BMW Service
37,500 km
Carried out in accordance with
manufacturer's instructions
at odometer
reading
Date, stamp, signature


10
BMW Service
1
Confirmation of maintenance work
BMW
Annual Service
Carried out in accordance with
manufacturer's instructions
Brake fluid changed:
yes no
Coolant changed:
yes no
Date, stamp, signature
BMW
Annual Service
Carried out in accordance with
manufacturer's instructions
Brake fluid changed:
yes no
Coolant changed:
yes no
Date, stamp, signature
BMW
Annual Service
Carried out in accordance with
manufacturer's instructions
Brake fluid changed:
yes no
Coolant changed:
yes no
Date, stamp, signature
BMW
Annual Service
Carried out in accordance with
manufacturer's instructions
Brake fluid changed:
yes no
Coolant changed:
yes no
Date, stamp, signature


11
11
BMW Service
1
Confirmation of maintenance work
BMW
Annual Service
Carried out in accordance with
manufacturer's instructions
Brake fluid changed:
yes no
Coolant changed:
yes no
Date, stamp, signature
BMW
Annual Service
Carried out in accordance with
manufacturer's instructions
Brake fluid changed:
yes no
Coolant changed:
yes no
Date, stamp, signature
BMW
Annual Service
Carried out in accordance with
manufacturer's instructions
Brake fluid changed:
yes no
Coolant changed:
yes no
Date, stamp, signature
BMW
Annual Service
Carried out in accordance with
manufacturer's instructions
Brake fluid changed:
yes no
Coolant changed:
yes no
Date, stamp, signature


12
BMW Service
1
This list is intended as a record of maintenance, warranty and
repair work, of the installation of accessories, and also to confirm
that special campaign work has been carried out.
Record of all work carried out in workshop
Work details Odometer reading Date
Confirmations of Service work


11
13
BMW Service
1
This list is intended as a record of maintenance, warranty and
repair work, of the installation of accessories, and also to confirm
that special campaign work has been carried out.
Record of all work carried out in workshop
Work details Odometer reading Date
Confirmations of Service work


14
BMW Service
1
This list is intended as a record of maintenance, warranty and
repair work, of the installation of accessories, and also to confirm
that special campaign work has been carried out.
Record of all work carried out in workshop
Work details Odometer reading Date
Confirmations of Service work


11
15
BMW Service
1
Confirmations of service work
Odometer
replaced
Odometer reading,
not total distance covered.
at odometer
reading
Date, stamp, signature
Odometer
replaced
Odometer reading,
not total distance covered.
at odometer
reading
Date, stamp, signature
Odometer
replaced
Odometer reading,
not total distance covered.
at odometer
reading
Date, stamp, signature
Odometer
replaced
Odometer reading,
not total distance covered.
at odometer
reading
Date, stamp, signature


2
16
Maintenance and care
Your vehicle is equipped with a
digital electronic engine man-
agement system (BMS) and a
high-output ignition system.
dWarning:
When the engine is running or
the ignition is switched on, do
not touch electrically live
components, terminals or
wiring.
– Risk of fatal accident.
Work on the electrical system
only when the circuit has
been interrupted (switch off
ignition and lights). For great-
er safety, disconnect and in-
sulate the negative battery
lead.
If you intend to perform the
maintenance and general care
work described in the following
section yourself, you must pos-
sess the necessary knowledge
of technical matters and
mechanical skills.
Your vehicle is built to high
technological standards.
Special tools and purpose-
designed diagnosis and testing
equipment, together with the
appropriate knowledge, are
needed to keep your vehicle in
optimum working order.
General instructions


2
17
Maintenance and care
General instructions
Your BMW dealer has the nec-
essary technical know-how and
specially trained mechanics.
He can guarantee that your
vehicle is always maintained in
a fault-free technical condition.
Remember: the safety and reli-
ability of your vehicle are the
most important considerations.
You should therefore not
attempt any complex repair or
maintenance tasks.
Keep to the specified Inspec-
tion and Service intervals.
BMW refuses to accept liability
for damage or consequential
damage due to repairs or serv-
ice work carried out by other
than BMW-authorised work-
shops.


2
18
Maintenance and care
General instructions
Technical modifications
dWarning:
The data stored in the BMW
engine management system
(BMS) control unit derive from
exhaustive tests and trials.
Consequently, manipulation
of the BMW engine manage-
ment system (BMS) control
unit invariably means an in-
creased risk to your safety on
the road.
LNote:
Manipulation of the BMW en-
gine management system
(BMS) control unit voids the
warranty.
Technical modifications are
only permitted to a limited
extent.
If you are planning such modifi-
cations, comply with all the
legal requirements. The vehicle
must not infringe your national
road-vehicle construction and
use regulations.
Your authorised BMW dealer
will gladly advise you on techni-
cal requirements, the manufac-
turer's recommendations and
the overall benefit likely to be
obtained.
Genuine BMW parts
For reasons of safety, use only
genuine BMW parts and acces-
sories.
Genuine BMW parts are identi-
cal with those fitted to your
BMW C1 as original equipment.
BMW Motorrad guarantees
against material defects and
poor workmanship, but cannot
accept any liability for spare
parts or accessories of outside
origin.

