BN Thermic T16C Series User manual

Thank you for purchasing a BN Thermic product. Manufactured to a high standard this product will, if used according to these instructions and
properly maintained, give you years of trouble free performance.
INSTALLATION INSTRUCTIONS
INSTRUCTIONS FOR:-
PROGRAMMABLE THERMOSTAT
T16C Series
PLEASE READ ALLTHESE INSTRUCTIONS, NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS,
AND CAUTIONS. USE THIS PRODUCT CORRECTLY, AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED.
FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY.
See next page for wiring diagrams

Please Note:- You can drive directly up to 3,600W (16A) with this thermostat (see fig 1), If the total load is above 3,600W (16A) you must install
an external relay or contactor to take the load (see fig 2).
Mounting instruction:
All electrical conduits to the thermostat box that contain heating cable or floor sensors must be sealed to protect the thermostat against hot air
currents coming up the conduit and into the thermostat. Failure of the thermostat is not covered by the guarantee if it over heats!
At least one floor sensor must be used when using this thermostat with underfloor heating (supplied) and all floor sensors MUST be mounted
alone in a separate conduit to avoid electrical interference. Again seal this conduit to avoid hot thermal air reaching the thermostat.
Back view of Thermostat
FloorSensors
Connectfirstoneto Sensor1
Connectoptional secondone
tosensor 2

IMPORTANT!
The thermostat power supply must be disconnected when inserting the
display part (the screen) into the base or removing it from the base!
Failure to follow this instruction may result in an irreparable damage to
the thermostat.
Before starting work the installer should carefully read this Installation & Operation
Manual, and make sure all instructions contained therein are understood and
observed.
- The thermostat should be installed by suitablyqualified electrician.
- All instructions in this Installation & Operation manual should be observed when
working with the thermostat. Any other application shall not comply with the
regulations. The manufacturer shall not be liable in case of incompetent use of the
thermostat. Any modifications and amendments are not allowed for safety
reasons. The maintenance may be performed by service shops approved by the
manufactureronly.
- The functionality of the controller depends on the model and equipment.
This installation leaflet is part of the product and has to be obtained.
APPLICATION
- The thermostats are developed to control and manage all type of
heating installations.
- The controllers have been designed for use in residential rooms, office spaces
and industrialfacilities.
Verify that the installation complies with existing regulations before operation to
ensure proper use of the installation.
SAFETYINSTRUCTIONS
Before starting work disconnect the power supply!
- All installation and wiring work related to the thermostat must be carried out
only when de-energized. The appliance should be connected and
commissioned by qualified personnel only. Make sure to adhere to valid safety
regulations.
- The thermostats are neither splash- nor drip-proof. Therefore, they must
be mounted at a dry place.
- Do not interchange the connections of the sensors and the 230V connections
under any circumstances! Interchanging these connections may result in life
endangering electrical hazards or the destruction of the appliance and the
connected sensors and other appliances.
FIRSTINSTALLATION
Batteries inside the thermostat must be charged for at least 6 hours to reach
maximum capacity to back up time.
1. Product overview
Touch screen programmable thermostat specially designed to control different
types of heating systems.
The thermostat will allow you to optimize your energy consumption and increase
your comfort levels.
- Modern design with touch screen.
- Simplified wiring & Installation.
- “Easy program creation” function.
- Fullyprogrammable.
- Temporary override function.
- Anti freeze function.
- Holidayor Reception function.
- Connections for 2 sensors.
- Estimation of the cost and consumption of the installation
Options
Additional 2nd floor sensor with several possibilities
of regulation. (Floor, combined…)
Or
Remote air sensor (T16R) for use in damp
conditions e.g. wet rooms or shower rooms
2. Menu structure
Mode Manuel
Timer
OFF
Anti freeze
Vacation Vacationsettings
OFF
Anti freeze
Reduce
Sunday’s program
Set Return Date
Program Program Menu
View Current Program
SelectProgram
EditProgram
User 1
User 2
User 3
Settings Language English
German
Czech
Spanish
French
Date and Time
Date
Time
DST
Display Colour
- Blue
- Red
- Green
- None
Clean Screen
ScreenLock
Floor Temperature Display
- Yes
- No
DegreeFormat
- °C
- °F
Time Format
- 12h
- 24h
Installation
Sensor
 SensorCalibration
- Int
- Ext1
- Ext2
 Ext. Sensor Type
- Ext1 (10K –12K –15K)
- Ext2 (10K –12K –15K)
Regulation
 SensorRegulation
- Air
- Air + Floor
- Floor
- Air (Ext) + Floor
- Air + Floor (x2)
 RegulationType
- ON/OFF
- PID
 Floor Limit
- Low
- High
 First Heating
- Wood (10 days)
- Concrete (21 days)
- Ceiling (10 days)
 Smart Start
o Yes
o No
 Open window function
o Yes
o No
RESET (press 2 seconds on the RESET button to reset your installation)
Statistics View
 View Last Day
 View Months
 View Year
kWh Price
Heating
Power
T16R–Remotewallsensor

3. Installation menu
This section will guide you through setting up your thermostat for the first time.
3.1. Language
Press the (◄) or (►) keys near the flags to select the chosen
language. The active language is framed.
Press the ►key in the bottom right corner to continue the settings of the installation.
3.2. Degreeformat
Select the degree format chosen by pressing on the touch button near the
degrees. The active option is coloured red
Press the ►key in the bottom right corner to continue to the next part of the
installation
You can return to the previous menu by pressing the key.
3.3. Date and Time
Select the time format 12H or 24H using the same method as above.
Press the (◄) or (►) keys to activate the value to be modified.
Each time a value is highlighted, it can be modified bypressing the (+) or (-) keys.
Press the ►key in the bottom right corner to continue to the next part of the
installation
You can return to the previous menu by pressing the key.
3.4. Sensor Regulation
Select the chosen sensor regulation by pressing on the touch button near the
sensor regulationpossibilities
The active touch is
coloured red
Press the ►key in the bottom right corner to continue to the next part of the
installation
You can return to the previous menu by pressing the key.
3.5. Heating power
Press the (◄) or (►) keys to select a unit, press the (+) or (-) keys to modify the
heating power.
This value is used to estimate the running cost of the system. You can return to
the previous menu by pressing the key.
Press the ►key in the bottom right corner to continue.
The main screen is displayed.
The default working mode will automatically be set to manual mode.
4. Mode of operation
Main screen
How to change the current mode?
Press on the key on the main screen and then press on the “Mode” button to
access to the operating modes.
You can now press the (◄) or (►) keys to scroll and select a mode.
The selected mode is framed, to select a mode press the key to return to the
main screen.
4.1 Programmable mode
In this mode the thermostat will follow the chosen program (Built-in or customized)
according to the actual time
You can temporarily override the selected program, by pressing the temperature
displayed on the main screen.
The small hand logo will be displayed when the override function is active. To exit
override mode, switch to manual then back to automatic mode
You will have the choice between 4 built-in programs that can’t be modified and 3 user
programs that you can customize.
1- How to customize a user program
Press on the “Mode” button then on “Edit Program” button and choose a user
program.
Then you will have to choose between 3 configurations:
a- Set day by day
You will set a new program for each day.
Automatically, the first day you will program is Monday.
The minimum program step is 15 minutes.
You will have to configure several periods.
The first period begins at 00:00. Then, choose the end time period with the (+) and (-)
keys and the temperature to be followed during this period.
Press “Next” button to continue the program. The next period will start at the end of
the last period.
For all periods you will define, you have to choose the end period and the
temperature. The last period stops at 24:00. Then press on the Next button.

Then, you can define another program for Tuesday by pressing the ‘EDIT” button
or you can copy the Monday Program by pressing the “Copy to” button
Continue to program as above for the remaining days of the week.
a- Set Weekday / Weekend
You will determine 2 programs: 1 for the weekdays (Monday to Friday) and 1 for
the weekend (Saturday and Sunday)
Use the same process as explained above to customize your program.
b- Set all Days at once
You will determine 1 program which will be the same for every day of the week
Use the same process as explained above to customize your program.
1- How to choose a program
Press on the “Mode” button then on “Program Menu” button, then “Select
Program” button you can choose between 4 built-in programs and 3 user
programs.
Use the “See Next” button to scroll through the different programs and the “Select”
button to confirm your selection.
You can view the current program by pressing on “View current program”.
If you return to the main screen, press on the button to see the current
program.
•Timer mode
The Timer mode allows you to set a temperature and duration for a period of up to
5 hours.
This function can be used to override the existing program for short periods. You
will have to adjust the temperature and the duration (Default value 22°C). When
you have validated your choice, the logo appears on the left of the
temperature with the remaining duration below.
•Manual mode
Manual mode, the set temperature will be followed all the time.
•OFFmode
Use this mode if you need to switch off your installation. Be Careful: In this mode
your installation can freeze.
•Antifreezemode
The antifreeze mode is used to protect your installation against frost. The default
value is 7°C but can be adjusted between 2°C and 15°C
•Holidaymode
You will have to select a mode which will be followed during the vacation time.
You have 4 possibilities:
•OFF Mode
•Antifreeze Mode
•ReducedMode
•Sunday mode : the installation follows Sunday’s current program
Then, select a return date and time
The logo and date of return are displayed on the main screen
If you want to cancel the holiday function before the return date, you can simply
change operating mode.
5. Special Function
5.1 Keyboards lock Function
Use this function to prevent all change of your settings (In a child room, public
area…)
- To activate the Key lock function, first press on Settings -> Display ->
Screen Lock
- The “ ”logo will be displayed on the screen.
- press on the key and then press 7 seconds on the logo
5.2 First heating
This function should be used after installation to prevent your floor from getting
damaged byits first heating cycles.
The first heating function works as follows:
- Concrete: 2 hours of operation during first 24 hours, and 1 extra hour is
added for the 21 subsequent days. During this period, floor temperature (or
room temperature unless floor sensor is activated) is limited to 20°C.
- Wood: 2 hours of operation during 24 hours on the first day, and 2 extra
hours are added for the10subsequent days. During this period, floor temperature
(or room temperature unless floor sensor is activated) is limited to 20°C +
0.8°C*number of days (20°C the 1st day, 20.8°C the 2nd day, 21.6°C the 3rd day,
etc, etc...).
- Ceiling: 2 hours of operation during the first 24 hours, and 2 extra hours
are added for the 10 subsequent days. During this period, air temperature is
limited to 20°C.
5.3 Open window function
The user activates / de-activates the function in the Open Window menu.
Conditions of open window detection:
The thermostat detects an "Open window" if the displayed temperature
(internal or ambient sensor) decreases by 3°C or more during a 5 minutes
period (or less).
In this case, the thermostats stops heating for 15 minutes.
The function remains active during those 15 minutes so the stop can last more
time if the temperature continues decreasing.
Return to normal mode:
The thermostat returns automatically to normal mode after the stop period.
The function can be overridden: pressing the screen during the stop heating
phase, will display a specific menu asking the user to stop or continue the stop
phase.
Special cases:
 This function doesn't work if Thermostat is in Floor regulation
 This function doesn't work if Thermostat is in OFF / Antifreeze Mode
 If temperature is less than 10°C, thermostat will regulates at 10°C during
the stop phase
5.4 Information
On the right bottom corner, a button is displayed. This button is a shortcut
depending of the current state of the thermostat:
o If a warning logo is displayed: press on the icon to access the information
screen. The information screen will provide more information on the current
fault.
o If a “i” is displayed: you can access the current set point and change it
o If a “step” icon is displayed, it means that you are in Programmable mode
and you can view the current program directly.
o If a “padlock” logo, it means that the screen is locked, pressing the icon
will take you to the unlock screen.

Using Thermostat with remote wall sensor –T16R
1) Connectthe remotesensorto “Sensor1” terminals on the back of the thermostat.
2) Connectfloor probe to “Sensor2” terminals on the back of the thermostat.
3) When programming the thermostat make sure you set the “sensor regulation” –Thisis done bygoing tothe installationmenu-
> Regulation-> SensorRegulation(seeabove).
6. Parameter’s precision
N°
Default value &other possibilities
In
Date andTime
Menu
DST:Daylight Summertime change Summer<->Winter
YES automaticchangeaccording todate.
NO no daylight summer time automatic change.
In
Installation
Menu
-> Sensor
-> Sensor
Calibration
ProbeCalibration
Thecalibrationmust bedoneafter 1day working with thesamesetting
temperature in accordancewiththe followingdescription:Put a
thermometer in theroom at1.5M distance from the floor (likethe
thermostat) andcheck therealtemperature in the room after 1hour.
Selectthe probeyouwanttocalibrate then usethe (-)or (+)keys to
enter the real value. Calibration is erased by the “RESET” function
*Payattention:
Onlytheheating elementdriven bythe thermostatmustbeusedduring
thecompletestepofthe calibration.
In
Installation
Menu
-> Sensor
-> Extsensor
type
Probes Type
Forext1and ext2 probes, you canhavedifferent types of NTC.
10,12 and15KNTCare recognized.
10K : B25/85 = 3950K
12K : B25/85 = 3740K
15K : B25/85 = 3965K
In
Installation
Menu
-> Regulation
-> Sensor
Regulation
Air:onlyinternalprobeisused, no floorlimitation
Air + Floor :internalprobeisusedfortheregulationandExt1forfloor
limits
Floor :onlyExt1probeisusedfor regulation,nofloorlimitation
Air (Ext) +Floor :Internal probe isnotused,regulationis done by
connectingT16RremotesensortoExt1andfloor limitationprobe by
Ext2
Air + Floor (x2) :internal probeisusedfor theregulation andExt1,
Ext2forfloorlimits
In
Installation
Menu
-> Regulation
-> Regulation
Type
ON/OFF:regulationmadebyhysteresis+:-0.3°C
PID: usea PID regulation(Seenextpagefor furtherinformation)
In
Installation
Menu
-> Regulation
-> FloorLimit
in Air+ Floor/ Air(Ext) +Floor/Air+ 2Floorsregulations :
High: if floortemperatureisabove theHighlimit,thermostat stops
heating
Low: if floor temperatureis belowthe Lowlimit,thermostat starts
heating
In
Installation
Menu
-> Regulation
-> First
Heating
Innewinstallationsthe heating must be progressive, therearetwo first
heatingprogramsavailable,dependingon thefinishedfloor covering.
In
Installation
Menu
-> Regulation
-> SmartStart
Functionthatcan beactivated /deactivated:
Inprogram mode,thepositivestepswillbeanticipatedaccordingtothe
currenttemperatureandthenextsetpoint.
7. Technical characteristics
Measuredtemperatureprecision
0.1°C
Environmental:
Operating temperature:
Shipping andstorage temperature:
0°Cto 40°C
-10°C to+50°C
Setting temperaturerange
Comfort, Reduced
Holiday(Antifreeze)
5°C to35°Cby0,5°Cstep
7°C (adjustable)
Regulation characteristics
PID(10mincycle)orHysteresisof0.5°C
Electrical Protection
ClassII - IP21
Maximum load
Without Relay- 16Amps 250Vac
Included External sensors
10K ohmsat25°C
OptionalExternalsensors
10K,12K or15K ohms at 25°C
Software version
Displayed inthe usermenu.
Your thermostat hasbeendesignedin
conformitywiththe followingstandards
orothernormative documents:
EN 60730-1: 2003
EN 61000-6-1: 2002
EN 61000-6-3: 2004
EN 61000-4-2: 2001
EN 60730-2-9
Lowvoltage2006/95/CE
EMC2004/108/CE
Measuredtemperatureprecision
0.1°C
BatteryLife(upon powerfailure)
24 hoursminimum(batteryfullycharged)
8. Troubleshooting and solutions
My thermostat doesn’t start
SupplyProblem
-Checkiftheproductiscorrectlywired
-Press theReset button throughthesmallholeunderthe
productonthe bottom rightcorner
-inthe case of uneven wallsorinadequatelyembedded
wiringboxes,excessive fastening of theinstallationscrews
mayresult in loss of contactwith thepowersupplyofthe
display.
Warninglogoisdisplayed
GeneralProblems
Press thewarninglogoonthe bottom rightcorner.
More informationonthe faultis displayedi.e.the sensor or
the fault type (error, floor limit, …)
If errorreferstothesensor:
-Checksensorconnections,
-CheckRegulationtype (Air / Floor / Air+Floor …)
Mythermostatseems towork correctlybut the heating doesn’t work correctly
Output
-Checktheconnections.
- Contact your installer.
Mythermostatseems towork correctlybut the temperature in theroomwas neverin
accordancewiththe program.
Program
-Check theClock.
-Thetemperaturesteps aretoo high?
- Thestepinthe program is too short?
- Contact your installer, to check& adjustthe regulation
parameters with your heating system.
General
-Check calibrationsensor
-Checkexternalsensortype (10k,12k,15k)
T16R–Remotewallsensor.
Availableasanoptional extra.

NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
This product conformsto EU Directive 2002/96/EC.
This appliance bears the symbol of the crossed waste bin. This indicates that, at the end of its useful life, it must not be disposed of as domestic
waste, but must be taken to a collection centre for waste electrical and electronic equipment. It is the user's responsibility to dispose of this appliance
through theappropriatechannels.Failure to dosomay incur penalties established by laws
governingwastedisposal.
BNThermicLtd,
34 StephensonWay,ThreeBridges,
Crawley, RH10 1TN
Tel: [phone]
Email:[e-mail]
Web: www.bnthermic.co.uk
Turning PID mode ON or OFF - PID mode (set ON by default) uses hysteresis to turn the heating system on or
off. Easiest explained by the thermostat working out how quickly the temperature is raising and turning the system off
before the temperature set point is reached making sure the system does not over run the set point. It then works out how
quickly the room is cooling down and turns the heating on before the set point is reached so trying to stop the room
cooling down too much. If you would rather the heating being turned on and off at the exact set point follow this guide
which explains how to turn PID off.
1) Viewing themainscreen 2) Press settingsicon 3) From newscreenpress Settings
4) From new screen press “Down Arrow” 5) Fromnew screen press “Installation” 6) From new screen press “Regulation”
7) From new screenpress “RegulationType”8) From new screen press “ON/OFF” 9) If you wishtousePID mode select “PID”red dotshould
Youshould nowsee a red dot against “ON/OFF”be lit asinabovepicture otherwise return to main screen by
pressingthe return 5times.
Please note:–If you don’t touch any screen for1Minutethe displaywill automaticallyreturntothemainscreen.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Your BN Thermic product is guaranteed for one year from date of purchase. We will repair
or replace at our discretion any part found to be defective. We cannot assume any consequential liability.
This guarantee in no way prejudices your rights under common law and is offered as an addition to
consumer liability rights.
T16CINS-v03-1
