Bogen AH15A User manual

The AH5A and AH15A metal horn speakers are rugged, self-contained one-way amplified paging horn
assemblies with screwdriver-adjustable volume controls.
Their sturdy, weatherproof, all-aluminum construction make them ideal for use in industrial plants,
warehouses, schools, construction sites, transportation terminals, and recreation areas.
Universal mounting brackets permit adjustment in vertical and horizontal planes; banding slots are provided for
ease in securing the horns to beams and pillars. Quick connections to audio and power sources are easily made
with the supplied 4-conductor, color-coded cable. A plastic cover protects the volume control and provides
cable strain relief.
• 5- and 15-watt models with built-in amplifiers
• Screwdriver-adjustable volume controls
•Universal tilt-and-swivel mount
• Banding slots easily secure horns to beams
and pillars
• 4-conductor, color-coded cable for quick connec-
tions to audio and power sources
• Plastic cover protects volume control and provides
cable strain relief
• Weatherproof, all-aluminum housing
• Self-aligning, field-replaceable diaphragm
• Speaker and brackets have textured mocha
enamel finish
• Mountable to an I-beam flange using Bogen’s BC1
beam clamp (not included)
Amplified Horns
With Volume Control
Models AH5A (5W),
AH15A (15W)
Specifications subject to change without notice.
© 2005 Bogen Communications, Inc.
Part No.54-7757-04B Printed in U.S.A. 0506
AH5A
AH15A
Description
Features

AH5A AH15A
Typical Operating Current : 6 CU (300 mA)*18 CU (900 mA)*
Maximum Output Power (RMS): 5W 15W
Frequency Response: 275 Hz to 14 kHz 275 Hz to 14 kHz
Input Impedance: 1000 ohms 1000 ohms
Voltage: 24V DC 24V DC
Sensitivity (across 600 ohms): 32 mV 58 mV
SPL @ 4' on axis with rated input @ 1kHz: 116 dB 121dB
Dispersion: 110º 110°
Dimensions: 9" Diameter x 9-1/4" D 9" Diameter x 9-1/4" D
Product Weight: 4 lb. 4 lb.
Finish: Textured mocha enamel Textured mocha enamel
*1CU = 50 mA
The loudspeaker shall be a Bogen Model _____ ampli-
fied horn-type loudspeaker, or approved equivalent,
and shall incorporate a ___-watt amplifier with vol-
ume control. (Specify AH5A/5-watt or AH15A/15-
watt.) Frequency response shall be from 275 Hz to
14 kHz; dispersion shall be 110°.The loudspeaker shall
operate from 24V DC source, and shall provide an
input impedance of 1000 ohms.
AH5A
Maximum power output shall be 5 watts RMS. Sound
pressure level, measured four feet on axis with 5 watt
output @ 1kHz shall be at least 116 dB. Typical oper-
ating current shall be 6 CU (300 mA). Sensitivity shall
be 32 mV across 600 ohms.
AH15A
Maximum power output shall be 15 watts RMS.
Sound pressure level, measured four feet on axis with
15 watt output @ 1kHz shall be at least 121dB.
Typical operating current shall be 18 CU (900 mA).
Sensitivity shall be 58 mV across 600 ohms.
The loudspeaker shall be of weatherproof, all-metal
construction, with driver enclosed within a water-
proof housing. A 4-conductor, color-coded cable shall
be provided for quick connection to audio and power
sources. The loudspeaker shall include a self-aligning,
field-replaceable diaphragm. A plastic cover shall be
provided for strain relief and to protect the volume
control.
An all-purpose mounting bracket shall provide precise
positioning in the vertical and horizontal planes with a
single adjustment. The bracket shall include banding
slots to permit mounting on beams and pillars. The
bracket and loudspeaker shall be finished in textured
mocha enamel. The unit shall measure 9" diameter x
9-1/4" deep.Product weight shall be 4 pounds.
Architect and
Engineer
Specifications**
Technical
Specifications
50 Spring Street, Ramsey,NJ 07446, U.S.A.
201-934-8500 FAX: [phone]
Web Site: www.bogen.com
** Architect and Engineer Specifications are available online in a
Microsoft
Word®document to assist you with preparing your bids.
