Bohemian Travel Gear 30088 User manual

STITCH LINE
1
Setup Instructions:
2
NOTE:2 people will be needed to erect and extend
the tent poles.
• Lift up on ARM JOINTS then extend
UPPER EAVE POLES until
the silver LOCKING
BUTTON “clicks” into
locked position.
• Repeat until all UPPER
EAVE POLES are
extended.
IMPORTANT: Only
the two MAIN ROOF
POLES telescope on
this instant tent.
3
• Extend TELESCOPING LEG POLES until the silver LOCKING BUTTONS “click” into locked position.
NOTE:You can now easily move your tent to its final position before installing the Rainfly and securing
with stakes and guylines.
10 PERSON 3 ROOM INSTANT CABIN TENT -20 x 10 Item No. WMT-201080
Model No. 30088
4
• Unfold LEG POLES and spread out tent.
“Click”
• Drape RAINFLY over tent then clip HOOK attached to SHOCKCORDS of Rainfly onto FABRIC LOOPS
on tent.
• Secure RAINFLY to both LEG POLES with HOOK & LOOP FASTENERS (located on underside
of Rainfly).
• Extend both AWNING SUPPORT POLES then insert into metal ring of AWNING FLAP.
• Insert METAL PIN on each side of DOOR into bottom of AWNING POLE.
NOTE:In inclement weather be sure to close all WINDOW FLAPS; then remove the AWNING POLES
and secure the AWNING FLAP to avoid possible damage to the tent fabric.
AWNING FLAP
FRONT DOOR/AWNING FLAP
NOTE: See other side for proper staking of tent and guylines.
“Click”
Parts List:
A (1) Integrated Frame with Tent Body H (1)Carry Bag
F (22)Stakes
C (1) Rainfl y w/taped
seams w/8 S-hooks
E (1) Pole Bag
B (2) Fly Steel Canopy Pole
D (2)Divider
G (1) Stake Bag
Before you begin
Read all instructions thoroughly before beginning set up.
• Selectalevel site clear of rocks, branches, and other hard or sharp objects, to set up yourtent.
WARNING: Keep clear of overhead power lines.
• Do not setup your tent undertrees because of potential lightning strikes or falling tree limbs
in inclementweather.
• For best results in windy conditions, position narrow end of tent into the wind.
• Secure with all stakes and guylines provided to prevent property damage or personal injury.
• Two people can easily setup this tent in 60 seconds or less. Scan QR code to view our
setup video.

Storing the Tent
• Remove guylines and stakes and place in their storage bag.
• All stakes must be placed in their own storage bag before placing in tent carrying case to prevent damage to the
tent fabric.
• Store in a clean, dry area.
Things You Should Know
• Under certain conditions (cold weather, high humidity, etc.) condensation will form on the inside of your tent. Condensation is caused
by water vapor from your breath, perspiration, or any wet clothing inside the tent. It is NOT LEAKAGE through the tent fabric. It can be
minimized by removing wet clothing from your tent and by providing good ventilation through the tent.
• Never store tent, even for a short period of time, without drying it thoroughly and brushing off caked dirt. Do not pack stakes inside your
tent. Use a separate storage bag.
• STAKES SHOULD BE REMOVED BY PULLING ON THE STAKE ITSELF. NEVER PULL ON THE TENT TO REMOVE STAKE.
• Do not leave your tent set-up for weeks at a time. Be aware that exposure to ultraviolet rays from the sun can seriously damage material
and/or cause it to become discolored.
WARNING: Keep all flame and heat sources away from this tent fabric.
This tent meets the flammability requirements of CPAI-84. The fabric may burn if left in continuous contact with any flame source.
The application of any foreign substance to the tent fabric may render the flame-resistant properties ineffective.
Take Down & Storage Instructions:
To Take Down Tent
Follow the previous steps in the reverse order:
• Remember to push the silver LOCKING BUTTON and telescope the 4 ROOF
EAVE POLES.
• Push down on the ARM JOINTS where the legs meet the ROOF POLES starting with
the two middle poles first, then the corner poles. The roof will collapse in and
then pull all the poles inward under the central hub and then fold up the leg poles.
• Lay the tent down on it’s side and roll out the excess air and put back into the bag.
IMPORTANT:
THE ORIGINAL FIRE RETARDENT AND WATER REPELLENT PROTEC-
TIVE COATINGS MAY BE COMPROMISED IF SPRAYS OR OTHER
CHEMICAL TREATMENTS ARE USED ON THE TENT. FABRIC HAS BEEN
FACTORY TREATED. IT IS HIGHLY WATER-REPELLANT; HOWEVER, IT
IS NOT WATERPROOF. ALL TENTS CAN EXPERIENCE SEAM LEAK-
AGE DURING WET WEATHER. IF YOU WANT ADDITIONAL MOISTURE
PROTECTION, TRY A SEAM SEALING COMPOUND ONLY; STRICTLY
FOLLOW THE MANUFACTURER’S DIRECTIONS. IT IS RECOMMENDED
THAT YOU SEAL THE TENT DURING THE INITIAL SETUP AS WELL AS
PRIOR TO EACH CAMPING SEASON. SEAM SEALER COMPOUNDS
CAN BE PURCHASED AT YOUR LOCAL CAMPING PRODUCTS OUTLET.
FOR MISSING PARTS CALL 1-888-774-5840.
PLEASE DO NOT RETURN THIS PRODUCT TO THE RETAIL STORE.
WARNING: KEEP ALL FLAME AND HEAT SOURCES AWAY FROM THIS
SHELTER FABRIC
This shelter is made of flame-resistant fabric which meets CPAI-84 specifications. IT IS NOT FIRE-PROOF. The
fabric will burn if left in continuous contact with any flame source. The application of any foreign substance to the
product fabric may render the flame-resistant properties ineffective.
DO NOT use fuel burning devices inside or near tent materials.
DO NOT permit children to light matches, operate burning appliances, or handle any flame sources in or near the
shelter.
• Do not smoke, use matches, candles or open flames of any kind in or near the shelter.
• Do not refuel lanterns, stoves or heaters inside shelter.
• Do not cook inside shelter.
• Do not store flammable liquids inside shelter.
Part Number Description
90105 Rainfly
90106 Corner Joint (Plastic)
90107 Fiberglass End Pole (Shock corded)
90108 Steel Roof Pole
90109 Extendable Leg Pole
90110 Steel Side Pole (2 per tent)
90111 Awning Poles (2 per tent)
90112 Room Divider (2 per tent)
90113 Pole Joint Hub
90114 Pole Joint Hub Green Fabric Cover
90115 Green Fabric Corner Joint Cover
REPAIR PARTS LIST
To Secure Tent:
Stake Tent
• Locate WEBBING LOOPS sewn into the corners at the base of your tent.
• Slide STAKE through WEBBING LOOP at each location; then extend out before securing.
NOTE: Floor of tent should be taut when staked properly.
Secure Tent & Vent Flap Guylines
• Locate GUYLINES attached to the tent and side vent flap.
• Slide STAKE through loop at each location, extend out and drive in to secure.
NOTE: GUYLINES should extend out at a 45º angle from tent & awning.
• Tighten GUYLINES as needed by adjusting the SLIDER up the cord.
WEB
LOOP
SLIDER
STITCH LINE
Room Dividers
• Insert BLACK TOGGLES through the top and bottom FABRIC LOOPS, located at the center portion of the sides of
your tent, as needed.
6 Month Limited Warranty
Bohemian Travel Gear Limited warrants for a period of
6 months from the original date of purchase, this product
against any defects in materials or workmanship. At its
discretion, Bohemian Travel Gear may provide replacement
parts to original purchaser. Original receipt or proof of
purchase as well as proof of defect is required. Bohemian
Travel Gear will not be responsible for shipping costs
incurred outside the continental USA. Warranty is valid for
the original purchaser six months from the date of purchase
and is not transferable. This Warranty does not cover any
product purchased through non-authorized dealers and/or
online auction websites.
This Warranty Does Not Cover This
This 6 Month Limited Warranty does NOT cover normal
wear and tear, abuse or misuse of this product including
damage from inclement weather conditions, such as wind,
rain, or hail. In case of inclement weather remove all valu-
ables and persons and seek appropriate shelter. Under no
circumstances will Bohemian Travel Gear Limited be liable or
responsible for any incidental or consequential damages.
This product is designed and intended for Recreational
use only. Prolonged exposure to UV rays will cause any
fabric to fade and deteriorate and is NOT covered by this
6 Month Limited Warranty.
All replacement products or parts will assume the re-
maining warranty of the original product. This warranty gives
you specific legal rights. You may also have other rights
which vary from state to state.
To Obtain Warranty Service
Call Toll Free 1-888-774-5840 for warranty service, repair
parts, or product questions. Mon-Fri, 8:00 a.m. –
5:00 p.m.
Central Time.
NOTICE: DO NOT RETURN PRODUCT TO RETAIL STORE.
Bohemian Travel Gear Limited
Plot # 30-32, Sector-3, Karnaphuli, Chittagong 4204, Bangladesh
Made in Bangladesh • Printed in Bangladesh
