BOMANN KS 261 User manual

1
03/2014
User Manual
HOUSEHOLD-
REFRIGERATOR WITH ICE BOX
KS 261
Please read this manual carefully and keep for future reference!

2
03/2014
T ABLE O F C ONTENT
O VERVIEW
Please read this user manual thoroughly before first time operation. It includes im-
portant information with regard to installation, operation and maintenance of the device.
Improper use may cause hazardous situations, especially for children.
Keep this manual for future reference. Pass it on to any future owner of this product. In
case of any doubt regarding questions or topics which are not extensively described in this manual,
please contact your distributor or a specialist.
D ISPOSAL O F U SED D EVICES
This product is marked in accordance with the European waste regulation
2002 / 96 / EC - WEEE
It regulates the proper disposal of the product. Environmentally friendly disposal will pre-
vent possible negative consequences to health caused by improper disposal.
This symbol on the product or its packaging indicates that this product must not be dis-
posed of with the regular household waste. The user has to return the product to a collection point for
the recycling of electric and electronic equipment.
The disposal must comply with the local regulations in place.
For further information please contact your local authorities or waste collection service.
Disable waste equipment before disposal:
- Disconnect the mains plug from the wall socket.
- Disconnect the plug from the mains cable.
- Remove or disable any existing spring or latch locks.
This will prevent children from locking themselves (risk of suffocation!) or from getting into perilous
situations. Children might not understand the risks that arise from handling household devices.
Therefore, observe children and make sure they do not play with the device.
OVERVIEW
2
DISPOSAL OF USED DEV
ICES
2
IMPORTANT USE AND SA
FETY INSTRUCTIONS
3
General Safety Precautions 3
Coolant 3
Intended Use 3
PRODUT DESCRIPTION
4
Delivery Scope 4
IN
STALLATION
4
Location 4
Electrical Requirements 4
REVERSE THE DOOR OPE
NING
6
STARTUP / OPERA
TION
6
Prior to First Use 6
Operation 6
Turning off 7
TIPS FOR SAVING ENER
GY
7
MAINTENANCE AND CLEA
NING
7
Cleaning and Care 7
Reverse the Bulb 7
Repairs 8

3
03/2014
I MPORTANT U SE A ND S AFETY I NSTRUCTIONS
General Safety Precautions
All safety information in this user manual are marked with a warning symbol. They indicate possible
dangers precociously. It is imperative to read and follow these information.
- Do not touch the plug at the mains cable with wet or moist hands when connecting or disconnect-
ing. Risk of death by electric shock!
- In case of emergency, unplug the device immediately.
- Hold the plug when disconnecting the mains cable; do not pull the cable.
- Disconnect the plug before cleaning or servicing.
- Regularly check the device and cable for signs of damage. Do not continue to operate the device in
case of damage.
- A damaged mains cable must be replaced by a specialist without any delay. Do not use the device
with a damaged cable or plug.
- Do not repair the device by yourself. Please contact authorized personnel. In order to avoid haz-
ards. A damaged mains cable must be replaced with an equivalent cable by a qualified specialist.
- Except for cleaning and maintenance work described in this manual, no other alterations of this
device must be executed.
- Do not place vases or other containers filled with liquids on the device.
Risk of Injury!
- So that you can disconnect the appliance quickly in event of an emergency, do not use extension
cables.
- This device may not be operated by children or persons with physical, sensory or mental abilities or
lack of experience and knowledge, unless they are supervised or guided.
- Children should be supervised to ensure that they do not play with the device.
- Transport the unit never with content.
WARNUNG:
- Packaging materials (e.g. plastic bags, polystyrene) are dangerous for children. Risk of suffocation!
Keep packaging materials out of reach of children.
- Containers with flammable gases or liquids can leak due to cold ambient temperatures. Risk of
explosion! Do not store combustible materials such as aerosol cans or refill cartridges for lighters in
your device.
Coolant
CAUTION: The coolant circuit of this device contains the refrigerant Isobutane (R600a), a natural
gas that is flammable and of high environmental compatibility. Make sure no parts of the Coolant cir-
cuit gets damaged during transport and installation of the device.
If the Coolant Circuit is Damaged:
- it is imperative to avoid any open flames or ignition source.
- thoroughly air the room in which the device is installed.
Intended Use
- This device is intended for private use. It is suitable for cooling food.
- The manufacturer is not reliable for any damage resulting from improper or other then intended
use.
- For safety reasons, alterations or modifications of the device are prohibited.
- Please keep in mind that the manufacturer is not reliable for any damage resulting from commercial
or any other use then cooling food.
Unpacking
The packaging must be undamaged. Check the device for any possible transport damage. Do not
install a damaged device. In case of damage, please contact your distributor.
Packaging Material
The packaging for transportation of the device and individual parts is produced of recyclable materials.
- corrugated cardboard / paperboard (mainly of waste paper)
- form part of PS (foamed, CFC-free polystyrene)
- Films and bags of PE (polyethylene)
- Strapping strips of PP (polypropylene)

4
03/2014
IMPORTANT: Make sure you dispose of packaging materials environmentally friendly.
Removing the Transport Protection
The device and parts of the interior are protected for transport. Remove all adhesive tapes from the
right and left side of the door. You may remove adhesive residue with a cleaning solvent. Also remove
any adhesive tapes and packaging materials from the inside of the device.
P RODUCT D ESCRIPTION
Delivery Scope
Height-adjustable glass shelf, vegetable box with glass cover, ice-cube tray
User manual
I NSTALLATION
Location
Sufficient ventilation around the device is necessary in order for the heat to dissipate properly and to
guarantee efficient cooling operation at low power consumption. For this purpose, leave sufficient
space around the device.
- Minimum clearance of 5 cm between rear side and wall,
- at least also 5 cm at both sides and on top of the device.
- Leave proper space in front of the device in order to open the door at an angle of 160°.
IMPORTANT:
- Do not expose the device to direct sunlight.
- Do not place near heaters, next to a stove or any other heat sources.
- Do not use the device outdoors.
- Only install at a location with an ambient temperature suitable for the climate class of the device.
For information on the climate class, please refer to chapter ‘Specifications’ or to the rating label lo-
cated in the interior or on the rear side of the device.
- Avoid installation at locations with high humidity (e.g. outdoors, bathroom), as metal parts would be
susceptible to corrosion under such circumstances.
- Do not place the device near volatile or combustible materials (e.g. gas, fuel, alcohol, paint, etc.)
and in rooms which may have poor air circulation (e.g. garages).
- Only place on a steady and safe surface.
- If the device is not horizontally leveled, adjust the feet accordingly.
Electrical Requirements
Please look at the rating label to know the rating voltage and connect the appliance to the appropriate
power supply. The voltage is 220-240V.
Electrical Connection
Ensure the voltage and frequency of the power being corresponds to those on the rating plate.
1 Working top cover
2 Screw cover
3 Cabinet
4 Ice box
5 Interior lamp / temperature control
6 Height adjustable glass shelf
7 Glass shelf on top of vegetable box
8 Vegetable box
9 Adjustable feet
10 Door
11+12 Door storage racks

5
03/2014
Only insert the plug into an electrical socket which is earthed properly. If the electrical socket to
which the appliance must be connected is not appropriate for the plug, let replace the socket by a
specialist, rather than using a adaptors or the like as they could cause overheating and burns.
Grounding Instructions
This appliance must be earthed. In the event of a malfunction or breakdown, earthing will reduce the
risk of electric shock by providing a path of least resistance for the electric current. This appliance is
equipped with a cord having an equipment-earthing conductor and an earthing plug. The plug must be
plugged into an appropriate outlet that is installed and earthed in accordance with all local standards
and requirements.
WARNING:
- Improper connection of the equipment earthing conductor can result in the risk of an electric shock.
- Check with a qualified electrician if you are in doubt whether the appliance is properly earthed.
- Do not modify the plug provided with the appliance. If the plug does not fit properly to the outlet,
please have a qualified electrician to install a proper outlet.
- If power cord is damaged or has any sign of being broken, special power cord must be selected or
purchased from its manufacturer or service for replacement.
- Protect the mains cable. Ensure that it does not turn into a trip hazard. The wall outlet must be
freely accessible at all times.
- Do not overload the wall outlet; do not use an extension cable. Overloaded cables can cause fire
and electric shock.
- Do not touch the plug with wet hands..
R EVERSE T HE D OOR O PENING
If required, the door opening can be moved from the right (supplied condition) to the left side.
WARNING
When replacing the door stop, the device must be disconnect-
ed from the power supply. Always unplug the device first.
1. Use a small flat screwdriver to lift up the two screw covers
(1) on the top cover (3).
2. Use a cross screwdriver to remove the two screws (2) on
the top cover and the other two screws (11) on the back-
side of top cover.
3. Lift up the top cover (3) and pull out the door hinge pin (4)
from the door, and put them on a safety place for later use.
Lift up the door (6) and put it on a safety place for later use.
4. Remove the left adjustable foot (7) and the right adjustable
foot (8) and screws (9) and keep them for later use.
5. Move the lower hinge (10) from the right side to the left
side, then fix it with the screws (9). Then install the right ad-
justable foot (8) on the left and the left adjustable foot (7) on
the right.
6. According to the reversible way of above procedure to install the door (6), then put the door hinge
pin (4) into the left hole of the door, then put the top cover (3) on it, please make sure the door
hinge pin (4) to be placed into the hole of the top cover (3), then use the cross screw drive to fix the
screws (2) and the screws (11), finally put the screw covers (1) on it.
Check if the door is arranged vertical as well as horizontal, so that a smooth opening and closing of
door is ensured.
S TARTUP / O PERATION
Prior to First Use
ATTENTION: After transport, the device should be left standing for 4 hours in order for the oil to
be collected in the compressor. Nonobservance could cause damage to the compressor and hence
result in failure of the device. This would void your warranty claim.

6
03/2014
- Clean the interior of the device including all accessory parts located inside.
Connect the Device to the Mains Supply
IMPORTANT
- The device must be earthed properly. For this purpose the plug of the mains cable has been fitted
with the intended lead.
- Contact an electrician if the plug does not fit in the wall socket.
- In case you disconnect the device or in case of power failure: Wait for 5 minutes before restarting
the device.
Operation
Turn on the device by connecting the plug to a wall socket and turning the temperature control, which
is located at the right side of the fridge interior. Please also refer to chapter ‘Settings’.
Settings
Setting 0 – OFF indicates the device is turned off.
Turn the temperature control clockwise, starting from this setting; the device will turn on automatically.
The Settings 1 MIN – 7 MAX regulate the inside temperature. When opening the door, the interior
lamp will turn on.
Setting 0 (or OFF) = Off
Setting 1 (or MIN) = lowest setting (warmest inside temperature)
Setting 7 (or MAX) = highest setting (coldest inside temperature)
Turning the temperature control clockwise will lower the inside temperature. Please keep in mind that
the temperature changes with the ambient temperature (of the location), with the frequency of opening
the door and the amount of food in the device.
During initial operation, turn the temperature control to the highest setting first, until the device has
reached the desired operating temperature. Afterwards It is recommended to turn the control back to a
medium setting, correcting the temperature at a later point would then be easier.
Storing Food
Note: Always store food covered or packed in order to prevent drying-out and transfer of odor or taste
onto other food items.
You may pack the food with:
- Polyethylene plastic bags or foil
- Plastic containers with a lid
- Special elasticated plastic covers
- Aluminum foil
The following Safety Precautions are recommended
- The device is suitable for storing fresh food and drinks.
- Store fresh packed items on the glass shelves and fresh fruits and vegetables in the vegetable box.
- Place bottles in the door storage rack.
- Store meat well packed and only for 2 to 3 days. Avoid contact with cooked dishes.
- Let warm food cool down before putting it in the device.
Ice Box
The ice box allows you to store already frozen food at a temperature up to -4°C short term.
Pls. also refer to the recommended storage data on the packaging of the frozen food.
But the freezing box is especially provided for the preparation of ice cubes.
Defrosting
To achieve better cooling and to save energy, defrost the device regularly. To start the defrosting pro-
cess turn the temperature control to the position 0 - OFF and disconnect the plug. Remove the food
items and keep covered at a cool location.
When the ice has melted, pour the condensate away and dry the interior of the device.
You may then restart the device by connecting the plug and turning the temperature control.
WARNING: Never use metal objects (e.g. knives) for removing ice from the vaporizer. The vapor-
izer could be damaged. A defect vaporizer could cause serious damages.

7
03/2014
Operating Noise
NORMAL NOISE
TYPE OF SOUND CAUSE/ SOLUTION
Mumbling Caused by the compressor during its operation.
This is stronger when it turns on or off.
Liquid sounds Caused by the circulation of the refrigerant in the device.
Click sounds The temperature control turns the compressor on or off.
Disturbing noises Vibration of the shelves or cooling coils – check if those are
securely fastened.
Turning off
Turn the temperature to setting 0 – OFF in order to turn off the device.
If the device will not be operated for a longer period of time:
- Remove the entire food from the device.
- Turn the temperature control to setting 0 - OFF.
- Disconnect the plug or turn off / unscrew the fuse.
- Thoroughly clean the device (refer to ‘Cleaning and Care’).
- Keep the door open in order to prevent bad odors.
T IPS F OR E NERGY S AVING
- Disconnect the plug if you do not use the device.
- Do not install the device near stoves, heaters or other heat sources. In case of higher ambient
temperatures, the compressor will run more frequently and longer.
- Ensure sufficient ventilation at the bottom and rear side of the device.
Never block any ventilation openings.
- Allow warm dishes to cool down before putting them in the device.
- Do not open the door longer then necessary.
- Only set the temperature as low as needed. The ideal temperature in the fridge is 7°C.
It should be measured in the upper shelf, as far as possible in the front.
- The device should be defrosted regularly.
- Make sure the door sealing is in good order for the door to close properly.
M AINTENANCE A ND C LEANING
Cleaning and Care
For hygienic reasons, clean the interior and accessory parts regularly.
WARNING:
- Always disconnect the plug or turn off/ unscrew the fuse before cleaning. Pull the plug and not the
cable.
- Do not use steam cleaners for cleaning the device; moisture could enter electrical components.
Risk of electric shock! Hot steam could damage the plastic parts. The device must be dry before
restarting operation.
- Essential oils and organic solvents, such as the juice of lemon or orange skin, butanoic acid or
cleaning agents containing acetic acid can damage plastic parts. Prevent contact of any part with
such substances. Do not use abrasive cleaning agents.
Pls. do as follows:
- Remove all food and keep covered at a cool location.
- Use warm water and a mild detergent for cleaning the interior (including rear side and bottom).
- After thorough drying, restart operation.
WARNING:
- Do not bend the cooling coils.
- Do not use arenaceous abrasives.
Reverse the Bulb
Lamp specifications: 220-240V, max. 10W
To turn off the device, set the temperature control to setting 0 - OFF.

8
03/2014
Disconnect the plug or turn off the fuse!
- Remove the screw from the lamp cover.
- Press on the lamp cover and remove to the back.
- Replace defect illuminant.
- Reattach the lamp cover and fasten the screw.
- Reconnect the device and turn on.
Repairs
WARNING
Servicing of electric devices must be conducted by qualified experts only. Incorrect or improper repairs
constitute a risk for the user and will void the warranty!
What if . . . Troubleshooting
The design of the device ensures a trouble-free operation as well as a long life cycle. Nevertheless, if
any defect occurs during operation, please check if it is caused by improper operation.
The following problems can be solved by you by checking for the possible cause.
PROBLEM
POSSIBLE CAUSE
SOL
U
TION
The device is
not working
prop
erly or at
all
Is the plug securely connected to the mains?
Has the safety mechanism of the wall socket
been triggered?
Is the temperature control properly set?
Is the place unqualified?
Do food items or shelves and/or drawers
prevent
the door from closing properly?
Is the ventilation of the device hedged?
Connect the plug properly to the sock
et, turn on
the fuse, and contact a technician if necessary.
Check the settings.
Check the ambient temperature.
Arrange the food or shelves and/or drawers
properly.
Clear the ventilation slits, install the device freely
Loud noise
during opera-
tion
Does the device not stand vertical or horizontal? Adjust the feet accordingly.
Liquid flow sounds in the cooling circuit are
normal.
Water on the
bottom
Is the temperature control set properly? Check the temperature settings.
Interior lamp
does not work
Is the plug not connected to the mains?
Has the safety mechanis
m of the wall socket
been triggered?
Is the illuminant defect?
Connect the plug properly to the sock
et, turn on
the fuse, and contact a technician if necessary.
Disconnect the plug and replace the illumi
nant
(refer to ‘Replacing the bulb’).
Note: On days of high humidity, condensation might occur on the outer surface of the device. This is
no malfunction; you may simply wipe the water off.
If a problem still persists after following the steps above, please contact your distributor or a techni-
cian.

9
03/2014
PRODUCT FICHE OF HOUSEHOLD REFRIGERATORS
ACCORDING EU D IRECTIVE (EU) 1060/2010
Brand
Bomann
Model
KS 263
Category
1)
3
Energy efficiency class
2)
A+
A+++ (highest efficiency) to G (lowest efficiency).
Consumption data
Annual energy consumption
3)
kWh 112
Net capacity cooling total l 71
Net capacity freezing l 11
Star rating
4)
-
Frost-free -
Temperature rise time h -
Freezing capacity kg/24h -
Climate class
5)
SN-ST
Noise level dB(A) re 1pW 39
Design freestanding
Measures and weights
Height cm 84.0
Width cm 47.0
Depth cm 45.5
Net weight kg 22.0
Electrical connection
Compressor 70 W
Connection voltage 220-240V~ / 50Hz
1) Category: 1 = Refrigerator with one or more fresh-food storage compartments, 2 = Refrigerator-cellar, Cellar and
Wine storage appliances, 3 = Refrigerator-chiller and Refrigerator with a 0-star compartment, 4 = Refrigerator with a
one-star compartment, 5 = Refrigerator with a two-star compartment, 6 = Refrigerator with a three-star compartment ,
7 = Refrigerator-freezer, 8 = Upright freezer, 9 = Chest freezer, 10 = Multi-use and other refrigerating appliances
2) A+++ (highest efficiency) to G (lowest efficiency).
3) Annual energy consumption „XYZ“ kWh per year based on standard test results for 24 h.
Actual energy consumption will depend on how the appliance is used and where is located.
4) * = compartment: a frozen-food storage compartment in which the temperature is not warmer than -6°C.
** = compartment: a frozen-food storage compartment in which the temperature is not warmer than -12°C.
*** = compartment: a frozen-food storage compartment in which the temperature is not warmer than -18°C.
*(***) = food freezer compartment in which the temperature is not warmer than -18°C and a minimum freezing
capacity in 24 h.
5) Climate class SN: ambient temperature of +10°C up to +32°C.
Climate class N: ambient temperature of +16°C up to +32°C.
Climate class ST: ambient temperature of +16°C up to +38°C.
Climate class T: ambient temperature of +16°C up to +43°C.
The right to make technical and design modifications in the course of continuous product development
remains reserved.
All device-specific data of the energy label have been determined by the manufacturer under laborato-
ry conditions in accordance with pan-European standardized measuring methods. These are regulated
by ISO EN 15502. The actual energy consumption depends on the usage and might therefore also
be above the values determined by the manufacturer under standard conditions. An expert knows
these relations and will execute the tests with special measurement instruments in accordance with
the regulations in place.

10
03/2014
C. Bomann GmbH
Internet: www.bomann.de
