Bond Audio Supro Drive User manual
All Contents © Bond Audio LLC 2021
DRIVE
User Manual
2
3
3
5
CONTENTS
1) Introduction
2) Explanation of Controls
3) Warranty
3
1. INTRODUCTION
2. EXPLANATION OF CONTROLS
The Supro Drive captures the unmistakable sound of our vintage tube amplifiers in an effects pedal. By
recreating every aspect of the circuitry of a 1960s Supro tube amp, including an actual output transformer,
the Supro Drive achieves the magnetic saturation that gives Supro amps their iconic deep, warm, and gritty
rock & roll tones. The most realistic-sounding overdrive pedal ever made, the Supro Drive features a toggle
switch between the different windings of our custom transformer, offering high-headroom Bold sounds or
high-gain Rich tones. The pedal also features an assignable Expression pedal control for adjusting gain with
Volume: Sets the overall output level of the effect.
4
Tone: Sets the cutoff frequency of a passive low pass filter at the output of the “preamp”. When the
knob is fully clockwise, there is no effect from the filter. As you turn the knob counter-clockwise, the
filter will cut more treble frequencies.
Transformer: Controls the amount of dynamic range of the “power amp” circuit. It switches between
two secondary coils of the output transformer. The Rich mode gives you a more compressed and
gained up sound, while Bold mode provides more headroom and punch to your tone.
Expression Jack: Accepts a 1/4” TRS cable from a standard expression pedal. This controls the gain
of the “preamp”. The heel-down minimum gain can be set with an internal trimmer.
Gain: Sets the maximum gain. Best paired with expression.
5
3. SUPRO LIMITED WARRANTY
Your new Supro product is warranted to be free from defects in materials and workmanship for 1 year from
the original date of purchase. If the product is registered at http://suprousa.com/warranty, coverage is
extended to two years. Tubes and speakers are covered for 90 days. Warranty applies only to the original
retail purchaser of a registered Supro product, subject to the limitations contained in this warranty.
THIS WARRANTY IS EXTENDED TO THE ORIGINAL RETAIL PURCHASER OF SUPRO PRODUCTS BOUGHT
ON OR AFTER JANUARY 1, 2020 ONLY AND MAY NOT BE TRANSFERRED OR ASSIGNED TO SUBSEQUENT
ORIGINAL DATE OF PURCHASE. YOUR PROOF OF PURCHASE OR SALES RECEIPT MUST ACCOMPANY ALL
IF YOU DO NOT REGISTER THE PRODUCT WITHIN 60 DAYS OF PURCHASE, YOUR PRODUCT WILL NOT BE
If your Supro product is destroyed, lost or damaged beyond repair while in the possession of Supro for
repair, Supro will replace that product with one of the same or most similar style of a value not in excess of
the original purchase price of your product. Any insurance covering the product, including but not limited to
collector’s value insurance, must be carried by you at your expense.
This warranty covers the cost of both labor and materials on repairs deemed necessary by our Customer
Service Representative which includes:
tampered with or altered.
service has been performed.
6
Product manuals are offered digitally in an attempt to be mindful of our environment.
We ask that you consider the same before printing at home. Thank you!
INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, EXCEEDING
WARRANTY. SOME STATES AND/OR COUNTRIES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF
ANY SPECIAL, INDIRECT CONSEQUENTIAL, INCIDENTAL OR OTHER SIMILAR DAMAGES SUFFERED BY THE
PURCHASER OR ANY THIRD PARTY, INCLUDING, WITHOUT LIMITATION. DAMAGES FOR LOSS OF PROFITS
OR BUSINESS OR DAMAGES RESULTING FROM USE OR PERFORMANCE OF THE PRODUCT, WHETHER IN
THE POSSIBILITY OF SUCH DAMAGES, AND SUPRO SHALL NOT BE LIABLE FOR ANY EXPENSES, CLAIMS,
OR SUITS ARISING OUT OF OR RELATING TO ANY OF THE FOREGOING.
Steps To File for Warranty Coverage:
Register your new product at http://suprousa.com/warranty
Complete the warranty request form available at http://suprousa.com/support and we will handle it from there!
