bora PM6700 User manual

OPERATORS MANUAL
Assembly • Operation • Parts List • Warnings • Warranty
Caution: Read all instructions carefully.
SAVE THESE INSTRUCTIONS. Refer to them often and use them to instruct others.
PM6700
Portable
Miter Saw
Stand
Date Purchased/Date d’achat /Fecha de compra:
Where Purchased/Lieu d’achat /Dónde se compró:
Address/Adresse /Dirección:
MANUEL DE L’UTILISATEUR
Assemblage • Fonctionnement • Liste de pièces • Avertissements • Garantie
Mise en garde : Lire attentivement l’ensemble des instructions.
CONSERVER CES INSTRUCTIONS. Les consulter souvent et les utiliser pour éduquer les autres.
MANUAL DEL OPERADOR
Ensamble • Operación • Lista de Partes • Advertencias • Garantía
Precaución: Lea cuidadosamente todas las instrucciones.
GUARDE ESTAS INSTRUCCIONES. Refiérase a las instrucciones y úselas para enseñarle a otras personas.
Patents Pending
En instance de brevet
Patentes Pendientes
Miter Saw Not Included

2
Figure 1
Description Part No. Qty
1Tool Mount M101 2
2Tool Mount Handle M102 2
3Tool Mount Plastic Foot M103 4
4Locking Lever M104 2
5Top Frame M105 1
6Extrusion Endcap M106 2
7Extension Knob M107 2
8M8 Nyloc Nut M108 4
9M8 Washer M109 4
q0 Bar Lock M110 1
qa Latch Pin M111 1
qs Latch Bar w/ Bolt M112 1
qd Left Folding Arm M113 1
qf Right Folding Arm M114 1
qg Top Frame Support w/ rod M115 1
qh Handle w/ grip M116 1
qj Handle Screw M117 2
qk Main Frame M118 1
ql M10 x 75 Bolt M119 2
w0 M10 Washer M120 8
wa M10 Nyloc Nut M121 4
ws M10 x 65 Bolt M122 2
Description Part No. Qty
wd Cross Bar M123 1
wf Endcap for folding frame M124 2
wg Endcap for cross bar M125 2
wh M6 x 65 Bolt M126 2
wj M6 Washer M127 2
wk M6 Nut M128 2
wl Foot for main frame M129 2
e0 Folding Frame M130 1
ea Wheel M131 2
es M12 x 145 Bolt M132 2
ed M12 Washer M133 4
ef M12 Nyloc Nut M134 2
eg Axle Sleeve M135 2
eh Extension M136 2
ej T-support knob M137 4
ek T-support holder M138 2
el Flip Stop M139 2
r0 Roller M140 2
ra T-support M141 2
rs Extension support leg M142 2
rd Foot for extension leg M143 2
Congratulations
You have just purchased a PM6700 Portable Miter Saw Stand. This product has been specifically designed to assist
you in the use of your 10-12" miter saw, as well as increasing efficiency with other benchtop tools such as table
saws, band saws, scroll saws, planers, etc.
Parts
rd
rs
el
r0
wl
ra
ek
ej
eh
es ed ef eg
ea
e0
qd
ql w0 wa
wg
ws
wh wj wk
wd
qk
qh
qj
qg
4
6
2
3
1
5
qs
7
q0
qf
8 9
qa
wf

3
Features and Accessories
Your PM6700 Portable Miter Saw Stand is loaded with standard features
all designed and engineered to maximize the functionality and flexibility of
your miter saw.
Standard Features
• (2) 9" T-Supports with Flip Stops
• (2) 8" Heavy Duty Wheels for Jobsite Maneuverability
• (2) Sturdy Rubber Feet for Added Stability
• Large Adjustment Knobs
• Handy Extension Support Legs Improve Accuracy
• (2) 20" Quick-Mount Machine Attachment Arms
• Quick Latch for Easy Set-Up
• Bonus Cord Storage Bracket
Large Adjustment Knobs Extension Legs
Quick Latch
Cord Storage Bracket
9" T-Supports
8" Wheels
Sturdy Rubber Feet
Quick-Mount Machine Attachment Arms

General Safety Instructions for Power Tools
Using power tools of any kind can be dangerous if safe operating procedures are not followed. Recognizing the
hazards of each tool and using them with respect and caution will considerably limit the possibility of personal
injury. However, if safety precautions are ignored, personal injury will likely result. Always use common sense – your
personal safety is your responsibility.
1. Know your power tool. Read and understand the Operator’s Manual and observe the warnings and instruction
labels affixed to the tool.
2. Properly ground all tools.
3. Keep guards in place.
4. Remove adjusting keys and wrenches.
5. Keep work area clean and dry.
6. Keep children away.
7. Never leave running machines/tools unattended.
8. Disconnect tools from service.
9. Use correct tools for the job.
10. Never force a tool.
11. Wear safety apparel.
12. Wear safety glasses/goggles.
13. Never stand or sit on tools.
14. Replace damaged components immediately.
15. Make sure your work platform is sufficiently sturdy to do the specific job at hand.
16. Properly anchor power tools to work stands.
17. Use correct blade for job being done.
18. Think Safety. Safety is a combination of operator awareness, common sense and alertness at all times.
Safety Instructions for
Miter Saw Stands
1. Use caution when folding or unfolding legs to limit any finger pinch points.
2. Place stand on flat and level surface to keep tool from rocking or tipping.
3. Make certain that work support extensions are within safe operating limits, and are properly locked in place before
using tool. Do not exceed 500 lbs. on main frame table.
4. Test the setup for stability before proceeding with work.
5. Be sure the miter saw is tightened securely at all mountings before use or folding the stand for transport.
4

Assembly Instructions
Read all assembly instructions completely before attempting assembly. See
parts list for names and pictures of parts.
What’s in the box?
The main components of your stand are as follows: (Figure 2)
1. Main Folding Frame w/ wheels
2. Top Frame and Extensions
3. T-supports
4. Machine mounts
Assembling the Main Folding Frame
1. Install the handle on the end of the main frame using the two handle
screws included. (Figure 3)
2. Connect the folding frame to the main frame using parts ql, w0, and wa –
M10 x 75 bolts, washers, and nuts. Ensure that the stand folds correctly
before proceeding to the next step. (Figure 4)
3. Insert axle sleeve into the wheel and install the wheels on the folding
frame using parts es, ed, and ef – M12 x 145 bolts, washers, and nuts.
(Figure 5)
Installing the Top Frame on the Main Folding Frame
1. Unfold the main frame and position upright on the ground.
2. Connect the top frame 5 to the top frame support bar qg using the bolts
already positioned on the underside of the top frame. Thread on the M8
nyloc nuts 8 and washers 9. Do not tighten the nuts at this time.
(Figure 6)
3. Connect the latch qa to the latch bar qs.
4. Level the top frame by rotating the folding arms upward. Tighten the
bolts on the top frame support bar once the top frame is completely
level. (Figure 7)
5. Install the T-supports in the T-support holders ek and lock into place
using the T-support knobs ej.
6. Bar lock q0 shown in figure 7 is preinstalled. Nyloc fasteners should
be snug, while allowing the assembly to slide within the slot on the
underside of the top. The bar lock is used for transporting and storage.
Figure 2
Figure 3
Figure 4
Figure 6
5
Figure 5

Figure 11
6
Attaching Your Miter Saw or
Other Benchtop Power Tool
Various benchtop tools can be used with your PM6700 Portable Miter Saw
Stand by attaching them to the quick-mount machine supports.
1. Install (4) carriage bolts into machine and attach flat washers, lock washers
and nuts as shown in Figure 8. Only install the nuts a few turns. DO NOT
TIGHTEN.
2. Lift one end of the machine off floor and insert heads of carriage bolt into
round end of slots on quick-mount machine supports as shown in Figures 9
and 10. Slide to desired location on support. Tighten nuts by hand.
3. Repeat process in Step 2 on other end of machine. Tighten all (4) nuts with
wrench.
4. Carefully lift machine and attach it to stand.
Using the Material Stops
1. The T-supports have built-in flip stops that can be used for repetitive cuts or
the same length. Simply flip the stops into the up position and adjust to the
desired length. Figure 11.
Figure 7
Figure 8
Figure 9
Figure 10
Figure 12

7
Transporting and Storing
1. Before storing or transporting, make sure all
attachments are secured. Collapse outrigger
supports. And it is recommended that benchtop
tools are removed. (Figure 13)
2. To fold the stand, unlatch the top frame and rotate
it downwards. Lock the top frame to the cross bar
using the bar lock.
Kit No. J-104
Mounting Kit for Miter Saws and/or Other Power
Tools with an Inset Mounting Hole Pattern
Kit No. J-210
Mounting Kit for Miter Saws and/or Other Power Tools
with 3-Hole Mounting Pattern
Comes with everything above and adds bracket (Part #J105)
which connects both #3040 Offset Mounting Brackets.
Instructions
Secure Offset Mounting Brackets as shown above.
Note: Brackets can be used on the front or rear of the Machine Mounts.
To Order (if not included) Call:
1-800-624-2027
Parts List
#3040 Offset Mounting Bracket
A5/16"-18 X 3/4” Carriage Bolt
B5/16" Flat Washer
C 5/16" Spring Type Lock Washer
D5/16"-18 Hex Nut
B
C
D
#3040
A
Figure 14 Figure 15
Figure 13
3. Lift up on the end of the stand with the handle and
pivot the folding frame until it contacts the main
frame. (Figure 14)
4. Lower the stand, the handle and wheels should
contact when it is resting on the ground. (Figure 15)
Using The Extension Support Legs
1. Extension support legs rs are pre-installed. To
extend the leg depress the detent button located
on the underside of the extension eh . Slide the
extension support leg out of the extension tube eh
until it is fully extended to the pivot point. Rotate
down toward the floor, until the vertical lock detent
button on the side of the pivot assembly engages,
to lock the leg vertically. (Figure 12)
2. The length of the leg can be adjusted by releasing the
leg length lock show on page 3. Adjust as needed to
support extension.
3. For storage the leg length should be reduced to
minimum size using the length lock. Release the vertical
lock by depressing the pivot point detent and rotate
the leg into the horizontal position. Now slide the leg
assembly back into the extension tube until the detent
engages on the underside of the extension tube.

One Year Limited Warranty
Warrantor warrants to the original purchaser that the PortaMate PM6700 will be free from defects in materials and workmanship under normal use and
service for a period of one (1) year from the date of original purchase.
The obligation of this Warranty is limited to repair or replacement, at our option, of components which prove defective under normal use.
Any product or component claimed to be defective should be sent during Warranty period, postage prepaid to PortaMate, 1161 Rankin Drive,
Troy, MI 48083, Attn: Warranty Department, together with a copy of your original dated sales receipt. Call for authorization number before sending.
This warranty is in lieu of all other express warranties, obligations or liabilities. ANY IMPLIED WARRANTIES, OBLIGATIONS OR LIABILITIES, SHALL BE
LIMITED IN DURATION TO THE ONE YEAR PERIOD OF THIS LIMITED WARRANTY. NO AGENT, REPRESENTATIVE, DEALER, OR EMPLOYEE OF THE
COMPANY HAS THE AUTHORITY TO INCREASE OR ALTER THE OBLIGATIONS OF THIS WARRANTY.
This Warranty shall not apply to any product or component which in the opinion of the Warrantor has been modified or altered in any way, damaged as
a result of an accident, misuse or abuse, or loss of parts. In no case shall the Warrantor be liable for any special or consequential damages, or any other
costs or warranty, expressed or implied, whatsoever. This Warranty gives you specific legal rights, and you may also have other rights which vary from
state to state.
Customer Service Department • Service clientèle • Departamento de Atención al Cliente
800-624-2027
www.portamate.com • www.htcproductsinc.com
© 2014 Portamate, 1161 Rankin Drive, Troy MI 48083 Part # PM6700
Garantie limitée de un an
Le garant garantit à l’acheteur d’origine que le PortaMate PM6700 sera exempt de défaut de matériaux et de fabrication dans des conditions d’usage et
d’entretien normal pendant une période de un (1) an à partir de la date de l’achat d’origine.
Les obligations de cette garantie sont limitées à la réparation ou au remplacement, à notre discrétion, des composants dont il a été déterminé qu’ils sont
défectueux suite à une utilisation normale.
Tout produit ou composant considéré défectueux doit être envoyé pendant la période de garantie, dans un colis affranchi à PortaMate,
1161 Rankin Drive, Troy, MI 48083, Attn: Warranty Department, avec une copie du reçu orignal de vente daté. Appeler pour obtenir un numéro
d’autorisation avant d’envoyer.
Cette garantie remplace toute autre garantie expresse, obligation ou responsabilité. TOUTE GARANTIE IMPLICITE, OBLIGATION OU RESPONSABILITÉ
EST LIMITÉE À LA PÉRIODE DE UN AN DE CETTE GARANTIE LIMITÉE. AUCUN AGENT, REPRÉSENTANT, DÉTAILLANT OU EMPLOYÉ DE
L’ENTREPRISE N’EST AUTORISÉ À AUGMENTER OU MODIFIER LES OBLIGATIONS DE CETTE GARANTIE.
Cette garantie ne peut s’appliquer à aucun autre produit ou composant qui, selon l’opinion du garant, a été modifié ou altéré en quelque manière,
endommagé suite à un accident, mal utilisé ou abusé, ou encore perdu. En aucun cas le garant ne peut être responsable de dommages spéciaux ou
consécutifs ou de tout autre coût ou garantie, explicite ou implicite. Cette garantie donne à l’acheteur des droits juridiques spécifiques ainsi que certains
autres droits qui peuvent varier d’une juridiction à l’autre.
Garantía Limitada de Un Año
El fiador le garantiza al comprador original que el PortaMate PM6700 estará libre de defectos de materiales y mano de obra bajo uso y servicio normales
durante un período de un (1) año a partir de la fecha de la compra original.
La obligación de esta Garantía está limitada a reparación o reemplazo, a nuestra opción, de los componentes que se comprueben defectuosos bajo
uso normal.
Cualquier producto o componente que se reclame defectuoso debe ser enviado durante el periodo de Garantía, franqueo prepago a PortaMate,
1161 Rankin Drive, Troy, MI 48083, Attn: Warranty Department, junto con una copia de su recibo de compra original fechado. Llámenos antes de
enviarlo para obtener un número de autorización.
Esta Garantía precede a todas las demás garantías expresas, obligaciones o responsabilidades. CUALQUIER GARANTÍA IMPLÍCITA, OBLIGACIÓN O
RESPONSABILIDAD, ESTARÁ LIMITADA EN CUANTO A DURACIÓN AL PERIODO DE UN AÑO DE ESTA GARANTÍA LIMITADA. NINGÚN AGENTE,
REPRESENTANTE, COMERCIANTE NI EMPLEADO DE LA COMPAÑÍA TIENE LA AUTORIDAD DE AUMENTAR O ALTERAR LAS OBLIGACIONES DE
ESTA GARANTÍA.
Esta Garantía no aplicará a ningún producto ni componente que en la opinión del Fiador haya sido modificada o alterada de manera alguna, dañada
como resultado de un accidente, mal uso o abuso, o pérdida de partes. Bajo ninguna circunstancia el Fiador será responsable por daños especiales ni
consecuentes, ni por cualquier otro costo o garantía, expresada o implícita, pase lo que pase. Esta Garantía le brinda derechos legales específicos y
usted puede además contar con otros derechos que pueden variar de estado a estado.
