Borg W2100R User manual

CLEANING/MAINTENANCE
INSTRUCTIONS
Follow these instructions to correctly and safely care for
your fan. Please remember:
• Always unplug the fan before cleaning.
• Do not allow water to drip on or enter into fan
housing.
• Be sure to use a soft cloth moistened with a mild
soap solution.
• Do not use gasoline, thinner or benzene as a cleaner.
FAN CLEANING
Turn the fan off prior to cleaning. Clean the fan grills,
extender screen, and extender panels with a soft, damp
cloth. Please use caution around the motor housing area.
Do not allow the motor or other electrical components to
be exposed to water. Also, using a soft bristle brush
attachment, a vacuum cleaner may be used to extract
dust buildup on the grill areas.
FAN STORAGE INSTRUCTIONS
When storing your fan in the off season, it is important
to keep it in a safe dry location. It is important to protect
the fan head from dust. We strongly recommend using
the original box from purchase.
• We recommend using the original (or appropriately
sized) box.
• Please remember to protect the fan from dust or
moisture.
WINDOW FAN ACCESSORIES
CLEANING AND MAINTENANCE WARRANTY INFORMATION
5 YEAR LIMITED WARRANTY
Sunbeam Products, Inc. doing business as Jarden Consumer Solutions or if in Canada, Sunbeam Corporation (Canada)
Limited doing business as Jarden Consumer Solutions (collectively “JCS”) warrants that for a period of five years from
the date of purchase, this product will be free from defects in material and workmanship. JCS, at its option, will repair
or replace this product or any component of the product found to be defective during the warranty period.
Replacement will be made with a new or remanufactured product or component. If the product is no longer available,
replacement may be made with a similar product of equal or greater value. This is your exclusive warranty. Do NOT
attempt to repair or adjust any electrical or mechanical functions on this product. Doing so will void this warranty.
This warranty is valid for the original retail purchaser from the date of initial retail purchase and is not transferable.
Keep the original sales receipt. Proof of purchase is required to obtain warranty performance. JCS dealers, service
centers, or retail stores selling JCS products do not have the right to alter, modify or any way change the terms and
conditions of this warranty.
This warranty does not cover normal wear of parts or damage resulting from any of the following: negligent use or
misuse of the product, use on improper voltage or current, use contrary to the operating instructions, disassembly,
repair or alteration by anyone other than JCS or an authorized JCS service center. Further, the warranty does not
cover: Acts of God, such as fire, flood, hurricanes and tornadoes.
What are the limits on JCS’s Liability?
JCS shall not be liable for any incidental or consequential damages caused by the breach of any express, implied or
statutory warranty or condition.
Except to the extent prohibited by applicable law, any implied warranty or condition of merchantability or fitness for
a particular purpose is limited in duration to the duration of the above warranty.
JCS disclaims all other warranties, conditions or representations, express, implied, statutory or otherwise.
JCS shall not be liable for any damages of any kind resulting from the purchase, use or misuse of, or inability to use
the product including incidental, special, consequential or similar damages or loss of profits, or for any breach of
contract, fundamental or otherwise, or for any claim brought against purchaser by any other party.
Some provinces, states or jurisdictions do not allow the exclusion or limitation of incidental or consequential damages
or limitations on how long an implied warranty lasts, so the above limitations or exclusion may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights that vary from province to province,
state to state or jurisdiction to jurisdiction.
How to Obtain Warranty Service
In the U.S.A.
If you have any question regarding this warranty or would like to obtain warranty service, please call
1-800-397-5964 and a convenient service center address will be provided to you.
In Canada
If you have any question regarding this warranty or would like to obtain warranty service, please call
1-800-397-5964 and a convenient service center address will be provided to you.
In the U.S.A., this warranty is offered by Sunbeam Products, Inc. doing business as Jarden Consumer Solutions located
in Boca Raton, Florida 33431. In Canada, this warranty is offered by Sunbeam Corporation (Canada) Limited doing
business as Jarden Consumer Solutions, located at 20 B Hereford Street, Brampton, Ontario L6Y 0M1. If you have
any other problem or claim in connection with this product, please write our Consumer Service Department. PLEASE
DO NOT RETURN THIS PRODUCT TO ANY OF THESE ADDRESSES OR TO THE PLACE OF PURCHASE.
© 2009 Sunbeam Products, Inc. doing business as Jarden Consumer Solutions. All Rights Reserved.
Distributed by Sunbeam Products, Inc. doing business as Jarden Consumer Solutions, Boca Raton, Florida 33431.
138957/9100010011463 BORGW2100R09EM1 Printed In China
GCDS-BOR15479-JC
If you have any questions regarding your product
please contact our Consumer Service Department at
1-800-397-5964 or visit our website at
www.borghomeproducts.com.
Window Fan
Extender Panel
(2310010000433)
To order please go to
www.borghomeproducts.com
or call 1-800-397-5964
PLEASE READ AND SAVE THESE IMPORTANT INSTRUCTIONS
Owner’s Guide
BORGW2100R
Remote Control
Window Fan
TM
BORGW2100R_09EM1.indd 1BORGW2100R_09EM1.indd 1 11/17/09 11:07:05 AM11/17/09 11:07:05 AM

PLEASE READ AND SAVE THESE
IMPORTANT SAFETY INSTRUCTIONS FEATURES - OPERATIONS FEATURES - OPERATIONS
When using electrical appliances, basic safety precautions
should always be taken including the following:
1. Read all instructions before using this appliance.
2. Use fan only for purposes described in the instruction
manual.
3. To protect against electrical shock do not immerse unit,
plug or cord in water or spray with liquids. Plug the
appliance directly into a 120V AC electrical outlet.
4. Close supervision is necessary when any appliance is
used by or near children.
5. Unplug from outlet when not in use, when moving
fan from one location to another, before putting on
or taking off parts and before cleaning.
6. Avoid contact with moving parts.
7. Do not operate in the presence of explosive and/or
flammable fumes.
8. To avoid fire hazard, NEVER place the cord under
rugs or any parts near an open flame, cooking or
other heating appliance.
9. Do not operate any appliance with a damaged cord
or plug after the appliance malfunctions, or has been
dropped/damaged in any manner. Discard fan or
return to an authorized service facility for
examination and/or repair.
10. The use of attachments not recommended or sold by
the appliance manufacturer may cause hazards.
11. Do not use outdoors.
12. Do not let the cord hang over the edge of a table,
counter or come in contact with hot surfaces or leave
exposed to high traffic areas.
13. To disconnect, grip plug and pull from wall outlet.
Never yank on cord.
14. Always use on a dry, level surface.
15. Do not operate fan until fully assembled with all
parts properly in place.
16. This product is intended for household use ONLY and
not for commercial or industrial applications.
17. WARNING: To reduce the risk of fire or electric
shock, do not use this fan with any solid-state speed
control device.
PLEASE READ AND SAVE
THESE IMPORTANT
SAFETY INSTRUCTIONS
INSTALLATION INSTRUCTIONS
Carefully unpack contents from carton.
FOR DOUBLE-HUNG AND SLIDER
WINDOWS
1. Set the fan into your window opening (note that the
window screen does not have to be removed or left open.)
2. If the fan does not fit snugly to the top and bottom of
the window casing, attach the Extender Panel(s) and
adjust the built in extender screen until the fan fits
safely in your window. (See Figure 2)
3. To keep the fan in place, carefully close the window
so that the bottom edge of the window rests on the
flat surface on top of the fan.
NOTE: FOR SLIDER WINDOWS, SET THE FAN VERTICALLY
IN YOUR WINDOW OPENING WITH THE LEFT SIDE OF THE
FAN SITUATED ON THE BOTTOM AND THE BUILT-IN
EXTENDER SCREEN FACING UPWARDS.
WARNING: BE SURE FAN IS SECURELY INSTALLED IN
YOUR WINDOW AT ALL TIMES. DO NOT LEAN OR PUSH
ON FAN WHILE IT IS IN THE WINDOW.
OPERATING INSTRUCTIONS
1. Plug cord into any standard 120 volt AC outlet.
2. To turn the fan on and control the speed, press the
mode button. Note that pressing the mode button will
allow you to cycle through the speed setting (High=3,
Med=2, Low=1) as well as the Automatic Thermostat
Temperature settings (Auto High = A3, Auto Medium =
A2, Auto Low = A1). 0 indicates the Off position.
3. Set the airflow direction by sliding the fan directional
switches located above each fan blade. Note that the
fan blades work independently from one another
and can be used for air intake (bring fresh air in
from outside), exhaust (push air out from within the
room) or exchange (cycles air in and out of the room
simultaneously).
AUTO MODE
Your fan is equipped with a Programmable Digital
Thermostat that will automatically turn the fan ON and
OFF depending upon the preset comfort temperature.
This is ideal for night time operation when temperatures
can drop below comfort levels.
For example, if you set your fan to 75 degrees and the
temperature drops to 74 degrees, the fan will
automatically turn off. The fan will automatically turn on
again when the room temperature exceeds the set
temperature.
SETTING AUTO MODE
1. Press the Mode button to scroll to the desired auto
speed setting (A3, A2, or A1).
2. Choose the desired temperature setting by pressing
the Temp Up (+) or Temp Down (-) buttons. You may
select a temperature between 60 and 80 degrees
Fahrenheit. Once the desired temperature is set, the
digital display will return to show the ambient room
temperature. View the set temperature by pressing
either the Temp Up (+) or Temp Down (-) buttons.
IMPORTANT: If the fan does not start in the Auto
mode, please be sure that the set temperature is below
the current room temperature. Lower the set temperature
if you would like the fan to start or switch over to the
manual speed modes.
SETTING THE TIMER
1. Hold both the Temp Up (+) and Temp Down (-)
buttons down until the digital display flashes “00”.
2. Press the (+) or (-) buttons to change time in 1 hour
increments. Note selection ranges from 1 to 16
hours. When in the timer mode, the time remaining
will be displayed.
NOTE: If Timer is set when fan is ON, the time displayed
will turn the fan OFF once elapsed. If Timer is set when
fan is OFF, the time displayed will turn the fan ON. (The
default ON speed setting is Manual Low).
NOTE: Timer function can be turned off by pressing the
MODE key at any time.
REMOTE CONTROL
This unit includes two (2) AAA batteries, 1.5V.
Battery Replacement
a) Locate the battery cover on the back of the remote
control handset. Slide the battery cover off with your
thumb.
b) Remove old batteries.
c) Insert two new batteries, pressing them firmly into
their slot.
d) Replace the battery cover.
NOTES:
• Do not mix old and new batteries.
• Do not mix alkaline, standard (carbon-zinc), or
rechargeable (nickel-cadmium) batteries.
• Replace all batteries of a set at the same time.
• Clean the battery contacts and the devices’ contacts
prior to installing the batteries.
• Remove the batteries from the equipment when it is
not being used for an extended period of time.
• Remove the used batteries promptly.
FCC STATEMENT
Potential for Radio/Television interference
This product has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15
of the FCC rules.
These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. The product generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that the interference will not occur in a
particular installation. If the product does cause harmful
interference to radio or television reception, which can be
determined by turning the product on or off, the user is
encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the product and the
receiver.
• Connect the product into an outlet on a circuit
different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than the
other). To reduce the risk of electric shock, this plug is intended to fit in
a polarized outlet only one way. If the plug does not fit fully in the
outlet, reverse the plug. If it still does not fit, contact a qualified
electrician to install the proper outlet.
DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS
SAFETY FEATURE IN ANY WAY.
Figure 2 FRONT VIEW
LEFT
Extra Extender Panels 4.25
inches (10cm) - 2 pieces
included in your box
RIGHT
Built-in Extender, pull
out up to 7 inches
(17cm)
UNIT’S LENGTH
A. Front Grill
B. Control Panel
C. Mode Button
D. LED Display
E. Temp Up (+)
F. Temp Down (-)
G. Fan Directional
Switches (2)
H. Built-in Extender
Screen
I. Extender Locks (2)
J. Extender Panels
(2) (not shown)
K. Remote Control
A
B
GCDGH
J
EF
Figure 1
I
I
K
BORGW2100R_09EM1.indd 2BORGW2100R_09EM1.indd 2 11/17/09 11:07:06 AM11/17/09 11:07:06 AM
