Bosch SMU4HAS48E User manual

dishwasher
SMU4HAS48E
[NL] Instructions
Registeryour
new device on
MyBosch now and
get free benefits:
bosch-home.com/
welcome
Translated from Dutch to English - www.onlinedoctranslator.com

NL
Index
Safety.................................................. 4
General instructions .................. 4
Destination of the device .................. 4
Restriction of users ............ 4
Safe installation................................. 5
Safe use.................................................. 7
Damaged device................................. 9
Dangers for children..................... 9
Knife rack .................................. 24
Cutlery basket heights ......................... 24
Before using for the first time .................. 24
First time use..... 24
Softening System .................. 24
Overview of the water hardness
settings............................ 25
Avoiding material damage .......... 12
Safe installation.................................. 12
Safe use.................................. 12
Set water softening.................. 25
Softening salt ............................. 25
Switching off water softening.......... 26
Softening system regener-
run .................................................. 27
Environmental protection and
saving................................................................... .. 13
Disposal of the packaging .......... 13
Saving energy ................................ 13
Aqua sensor .................................. 13
Rinse System ................................ 27
Rinse aid ......................... 27
Setting the rinse aid
amount ................................................... 28
Set up and connection .................. 14
Scope of delivery .................................. 14
Switch off the rinse system... 28
Detergent .................................. 29
Suitable detergents .......... 29
Unsuitable dishwashing detergent ............ 30
Setting up and connecting the
device................................................................ ..... 14
Waste water connection ................... 14
Drinking water connection .................. 15
Electrical connection.................. 15
Notes on
detergents................................................................... 30
Filling detergent ..................... 31
Getting to know your device.................. 16
Device .................................................. 16
Controls..................... 17
Crockery................................... 31
Damage to glass and crockery
good ................................................ 32
Programs .................................. 19
Notes for test institutes ..... 20
Loading crockery .................. 32
Unloading Crockery ......................... 33
Favorite . † † † † † † † † † † † † † † † † † † † † † † † † † † † † † † † † † † † 20
Additional Features ................................ 21
The Ministry in Essence.............. 33
Switching on the appliance .................. 33
Set program .................. 34
Set additional function .................. 34
Making time setting................................ 34
Start program .................. 34
Activating key lock ............... 34
Deactivate key lock .......... 35
Interrupt program .................. 35
Equipment.................................................. 21
Upper basket ......................... 21
Lower basket ......................... 22
Cutlery basket ................................... 23
Etagère .................................. 23
Folding plate supports .......... 23
2

NL
Cancel program .................. 35
Switching off the appliance.................. 35
Customer Service.................................. 59
Product number (E-Nr.), production
number (FD) and serial number (Z-
Nr.) ................................... ............... 59
Basic settings ................................ 36
Overview of the basic
settings ................................................... ... 36
AQUA-STOP guarantee ................... 59
Change basic settings.................. 37 Technical data.................. 60
Information on Free Software and Open
Source Software ....................... 61
Home Connect ................................ 37
Quick start with Home Connect.... 38
Home Connect settings ............... 38
Remote Start ................................ 38
Remote Diagnosis .................. 39
Software update .................................. 39
Personal data protection
windows .................................. 39
Declaration of Conformity................. 40
Cleaning and maintenance ............... 40
Cleaning the rinse aid dispenser .......... 40
Detergent.............................. 40
Device maintenance tips.......... 40
Machine cleaning . † † † † † † † † † † † † † † † † † † † †
† † † 41 Sieving System ................................... 42
Cleaning Spray Arms................. 43
Troubleshooting ......................... 44
Error code / error indication /
signal................................................... .... 44
Washing result ................................... 46
Home Connect problem................. 53
Indications on the display........... 54
Malfunctions ......................... 54
Mechanical damage ........... 55
Sounds ............................................... 56
Cleaning the drain pump....................... 57
Transport, Storage and
Disposal ................................................ 57
Disassembling the device .................. 57
Making the device frost-resistant .... 58
Transporting the device .................. 58
Disposal of your old device.... 58
3

NLSafety
Safety
Observe the safety information so that you can use the device
safely.
General instructions
Here you will find general information about this manual. †Please
read this manual carefully. Only then can you
you can use the device safely and efficiently.
†These operating instructions are intended for the user of the
device.
†Observe the safety instructions and warnings. †Keep the operating
instructions and product information for future reference.
for use or for subsequent owners.
†Check the device after unpacking. Plug in the device
case of transport damage.
Destination of the device
In order to use the appliance safely and correctly, please observe
the instructions for its intended use. Only use the device:
†according to this manual. †to wash
dishes.
†for domestic use and in enclosed spaces within the
sly environment.
†to an altitude of 4000 m above sea level.
Restriction of the users
Prevent risks for children and vulnerable persons.
This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and/or knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe
way and understand the resulting hazards. understood. Children must
not play with the appliance.
4

SafetyNL
Cleaning and user maintenance shall not be made by children
unless they are supervised.
Make sure that children under 8 years old cannot reach the device
or the connecting cable.
Safe installation
Observe the safety instructions when installing the device.
WARNING ‒ Risk of injury! Improper installations can
cause injury.
▶When setting up and connecting the device, follow the
instructions in the operating and installation instructions.
WARNING ‒ Danger of electric shock! †Improper
installations are dangerous.
▶Connect and operate the device only in accordance with the
information on the type plate.
▶
Only connect the device to a mains supply with alternating
current via a properly installed earthing socket.
▶
The protective earth system of the electrical house installation must
be installed in accordance with the electrical engineering
regulations.
▶
Never power the device via an external switching device,
e.g. a time switch or remote control.
▶
When the device is installed, the mains plug of the mains
connection cable must be freely accessible or, if free access
is not possible, an all-pole disconnecting device must be
installed in the permanently installed electrical system in
accordance with the installation instructions.
▶When setting up the device, make sure that the power
cord is not pinched or damaged.
5

NLSafety
†Cutting the inlet hose or immersing it in water
peeling the AquaStop valve is dangerous.
▶
Never immerse the plastic housing in water. An electric valve
is located in the plastic housing on the supply hose.
▶
Never cut the supply hose. There are electrical connection
lines in the supply hose.
WARNING ‒ Risk of fire!
Using an extended power cord and unauthorized adapters
is dangerous.
▶
Do not use extension cords or multiple sockets.
▶If the power cord is too short, contact customer service.
▶
Only use adapters approved by the manufacturer.
WARNING ‒ Risk of injury!
The hinges move when opening and closing the appliance door
and can cause injuries.
▶
If underfloor or built-in appliances are not located in a niche
and a side wall is therefore accessible, the side hinge area
must be covered. The covers are available from specialist
dealers or from our after-sales service.
WARNING ‒ Danger of tipping over!
Improper installation can lead to the device tipping over.
▶
Only install underfloor or built-in appliances under a
continuous worktop that is firmly connected to the
adjacent cupboards.
6

SafetyNL
Safe use
Observe the safety instructions when using the device.
WARNING ‒ Serious health risk! Failure to observe the safety
instructions and instructions for use on the packaging of
dishwasher detergents and rinse aids can lead to serious
health damage.
▶Observe the safety instructions and instructions for use on
the packaging of detergents and rinse aids.
WARNING ‒ Explosion hazard!
†Solvents in the washing area of the appliance can cause up to
lead to explosions.
▶
Never put solvents in the washing area of the appliance.
†Highly corrosive alkaline or strongly acidic cleaning agents
parts in combination with aluminum objects in the washing
area of the appliance can lead to explosions.
▶
Never use highly corrosive alkaline or strongly acidic
cleaning agents, especially those for professional or
industrial use, in combination with aluminum objects (e.g.
grease filters from extractor hoods or aluminum pans) in the
dishwasher, e.g. for machine maintenance.
WARNING ‒ Risk of injury!
†An open appliance door can lead to injuries.
▶Only open the appliance door for loading and unloading
dishes to avoid accidents such as tripping.
▶
Do not sit or stand on the open appliance door.
7

NLSafety
†Knives and objects with sharp points can injure
cause things.
▶
Place knives and objects with sharp points pointing
downwards in the cutlery basket, knife holder or cutlery
drawer.
WARNING ‒ Risk of burns!
If the appliance door is opened during the program run, hot
water may splash out of the appliance.
▶Only open the appliance door carefully while the program is
running.
WARNING ‒ Danger of tipping over!
Overloaded crockery baskets can lead to the appliance tipping
over.
▶
Never overload the crockery baskets on free-standing
appliances.
WARNING ‒ Danger of electric shock! †Penetrating moisture
can cause an electric shock.
▶
Only use the device in closed rooms.
▶
Never expose the device to excessive heat and humidity.
▶
Do not use a steam cleaner or high-pressure cleaner to
clean the appliance.
†Damaged power cord insulation is dangerous.
▶
Never bring the connecting cable into contact with hot
appliance parts or heat sources.
▶
Never bring the power cable into contact with sharp
points or edges.
▶
Never kink, pinch or alter the power cord.
8

SafetyNL
Damaged device
Observe the safety instructions if the device is damaged.
WARNING ‒ Danger of electric shock! †A damaged appliance
or power cord has been
good.
▶Never use a damaged device.
▶
Never use a device with a cracked or broken surface.
▶
Never pull on the power cord to disconnect the device
from the power supply. Always pull the plug on the power
cord.
▶
If the appliance or the mains cable is damaged, immediately
unplug the mains cable from the socket or switch off the
fuse in the fuse box and close the tap.
▶
†Please contact customer service." → Page 59
▶
Only qualified personnel may carry out repairs on the
device.
†Improper repairs are dangerous.
▶Only qualified personnel may carry out repairs on the
device.
▶
Only original spare parts may be used for repair of the
device.
▶
If the power cord of this appliance is damaged, it must be
replaced with a special cord available from the
manufacturer or its service agent.
Dangers for children
Please observe the safety regulations if there are children in your
household.
WARNING ‒ Choking hazard!
†Children can pull packing material over the head
and get entangled in it and suffocate.
▶
Keep packaging material away from children.
9

NLSafety
▶
Do not let children play with packaging material.
†Children can inhale or swallow small parts and
suffocate because of this.
▶
Keep small parts away from children.
▶Do not allow children to play with small parts.
WARNING ‒ Health risk!
Children can lock themselves in the appliance and endanger
their lives.
▶
In the case of discarded appliances, remove the mains plug
from the socket, then cut the mains cable and damage the
lock of the appliance door so that the appliance door no
longer closes.
WARNING ‒ Danger of crushing!
Children can become trapped between the appliance door and
the cupboard doors below with appliances built high.
▶
Watch out for children when opening and closing the appliance
door.
WARNING ‒ Risk of corrosion!
Dishwasher and rinse aids can cause burns to the mouth,
throat and eyes.
▶
Keep children away from detergents and rinse aids.
▶
Keep children away from the opened appliance. The water in
the washroom is not drinking water. Residual detergent and
rinse aid may still be left in this.
WARNING ‒ Risk of injury!
Children can get their little fingers caught in the slots of the
tablet tray and injure themselves.
▶Keep children away from the opened appliance.
10

SafetyNL
WARNING ‒ Choking hazard!
Children can lock themselves in the appliance and suffocate.
▶
If present, use the child lock.
▶
Never allow children to play with or operate the appliance.
11

NLAvoid material damage
mMaterial damage
to avoid
avoid material damage ▶ Do not install the dishwasher
near heat sources such as a
radiator, water heater, stove or
other appliances that give off
heat.
†Altered or damaged water
hoses can lead to material damage
and damage to the device.
▶Never kink, pinch, alter or cut
water hoses.
▶ Only use supplied water hoses or
original spare hoses.
▶ Reuse never used water
hoses.
†Too low or too high water pressure
may interfere with the device function.
▶ Make sure that the water
pressure at the water supply
system is a minimum of 50 kPa
(0.5 bar) and a maximum of 1000
kPa (10 bar).
▶ If the water pressure exceeds the
specified maximum value, a
pressure reducing valve must be
installed between the drinking
water connection and the hose
set of the device.
mtavoid material damage To prevent material damage to the
appliance, accessories or kitchen
utensils, please observe the
instructions.
Safe installation
Follow the instructions when
installing the device.
PAY ATTENTION!
†An improper installation of
the device may cause damage.
▶If the dishwasher is installed
below or above other household
appliances, the information on
installation in conjunction with
the dishwasher in the installation
instructions for the respective
household appliance must be
observed.
▶ If no information is available or
if the installation manual does
not contain any instructions on
this subject, please check with
the manufacturer of these
household appliances whether
the dishwasher can be built in
above or below other household
appliances.
▶ If no information from the
manufacturer is available, the
dishwasher should not be
installed above or below these
household appliances.
▶ To ensure safe operation of all
household appliances, you must
also continue to follow the
installation instructions for the
dishwasher.
▶Do not install the dishwasher
under a hob.
Safe use
Follow the instructions when using
the device.
PAY ATTENTION!
†Emerging water vapor
can damage built-in furniture.
▶ After the program has ended,
allow the appliance to cool down
for a while before opening the
appliance door.
†The rinse aid container can be
corrode softening salt.
▶ To ensure that spilled
softening salt is removed
from the rinse aid container,
12

Environmental protection and savingNL
rinsed, the water softening salt can
be filled into the water softening salt
container immediately before the
program starts. †Dishwasher
detergent can damage the water
damage hardening.
▶ Only fill the water softener
reservoir with dishwasher
softening salt.
†Unsuitable dishwasher detergents
can damage the device.
▶Do not use a steam cleaner.
▶ To avoid scratching, do not use
sponges with a rough surface or
abrasive cleaning agents on the
surface of the device.
▶ To prevent corrosion on
dishwashers with a stainless
steel front, do not use sponge
cloths or rinse them thoroughly
several times before using them
for the first time.
You can obtain information about the
current disposal methods from your
dealer and your municipal or district
council office.
Save energy
If you follow these directions, your
device will use less power and water.
Use the Eco 50° program.
The Eco 50° program is energy-
saving and environmentally friendly.
→ †Programs", Page 19
If you only need to wash a few
dishes, you can use the Half load
option.1
The program is adapted to the
smaller load and the consumption
values are reduced.
→ †Additional functions", page 21
mm
environmental protection and savings
environmental protection and Aquasensor
savings The aquasensor is an optical
measuring device (photocell) with
which the turbidity of the washing
water is measured. Water can be
saved with the aqua sensor.
The use of the aquasensor depends on
the specific program. In case of heavy
pollution, the washing-up water is
pumped out and replaced with fresh
water. In the case of light soiling, the
washing water is also used during the
next washing phase and the water
consumption can be reduced by 3-6
liters. In the automatic programs, the
temperature and running time are also
adapted to the degree of soiling.
mProtect the environment by using the
device in a resource-saving manner
and properly disposing of reusable
materials.
environmental protection and savings
Disposal of the packaging
The packaging materials are
environmentally friendly and can be
reused.
▶Dispose of the individual components
separately according to type.
1Depending on the device version
13

NLSet up and connect
OSet up and connect
set up and connect a continuous worktop that is
permanently connected to the adjacent
cabinets.
Osset up and connect For correct use, connect the
appliance to electricity and water in a
professional manner. Observe the
required criteria and the installation
instructions.
1. "Observe the safety instructions." →
Page 4
2. "Observe the instructions for the
electrical connection."
→ Page 15
Scope of supply 3.Check the contents of the package
and the condition of the device.
After unpacking, check all parts for
transport damage and the
completeness of the delivery.
For complaints, please contact the
store where you purchased the
device or our customer service.
4.The required installation dimensions can be found
in the installation instructions.
5.Level the appliance using the
adjustable feet.
NoteThe device has been checked at
the factory for correct operation.
Water stains may remain on the
device. The water stains disappear
after the first wash cycle.
Pay attention to a firm position.
6. "Install the drain water connection."
→ Page 14
7. "Install the drinking water
connection." → Page 15
The delivery consists of:
†Dishwasher
†Instructions
†Assembly instructions
†Guarantee
†mounting material
†Steam protection plate †
Power cord
†Quick guide
8.Connect the device to the
power.
Waste water connection
Connect the appliance to a waste water
connection so that the contaminated
washing water can be drained.
Install waste water connection
1.The necessary steps can be found in
the supplied installation instructions.
Set up and connect the
device
2.Connect the drain hose to the
connection nipple of the siphon
using the supplied parts.
You can install your undercounter or
built-in appliance in the kitchen unit
between wooden and plastic walls. If
you subsequently install the device as
a free-standing device, you must
secure the device against tipping over,
e.g. by screwing it to the wall or
installing it under
3.Make sure that the drain hose is not
kinked, crushed or tangled.
4.Make sure that the water does not
flow out by a plug in the waste
water connection.
14

Set up and connectNL
Drinking water connection
Connect the device to a drinking
water connection.
Install drinking water connection
NoteWhen you replace the
appliance, you must use a new water
supply hose.
1.The necessary steps can be found in
the supplied installation instructions.
2.Connect the device to the drinking
water connection using the
enclosed parts.
The "technical data"
→ Page 60 consider.
3.Make sure that the drinking water
connection is not kinked, crushed
or entangled.
Electrical connection
Connect the device to the mains.
Connecting the appliance electrically
Clues
†Take the "safety rules"
→ Page 5 heed.
†Only connect the device
on an AC voltage of 220 - 240 V
and 50 Hz or 60 Hz.
†Please note that the wa-
The protection system only works
when the device is supplied with
power.
1.Connect the appliance plug of the
connecting cable to the appliance.
2.Plug the appliance into a mains
socket in the vicinity of the
appliance.
The connection data of the device
can be found on the type plate.
3.Check the plug for tightness.
15

NL Getting to know your device
YOUYOU
get to know your device
get to know your device
YOUl
get to know your device
Learn more about the components of your device.
Device
Here you will find an overview of the components of your device.
7 8
69
5
410
311
2
1
12
1Nameplate Type plate with "E number and FD number"
→Page 59.
You need this information for the "service"
→Page 59.
1Depending on the device version
16

Getting to know your deviceNL
2Detergent dispenser Put the "dishwasher detergent" in the detergent dispenser
→Page 29.
3Lower crockery basket
Reservoir for softening salt
"Lower crockery basket"→Page 22
4Add softening salt to the water softening salt
reservoir.
"Softening System", page 24
5Lower spray arm The lower spray arm cleans the dishes in the
lower basket.
If the dishes do not get optimally clean, clean
the spray arms.
"Cleaning the spray arms", Page 43
6Tablet tray During the wash cycle, tabs automatically fall from the
detergent dispenser into the tablet compartment where
the tabs can dissolve optimally.
7Upper crockery basket
Etagère1
Upper spray arm
"Top crockery basket"→Page 21
"Etagère"→Page 23
8
9The upper spray arm cleans the dishes in
the upper basket.
If the dishes do not get optimally clean, clean
the spray arms.
"Cleaning the spray arms", Page 43
10 Sieving System
cutlery basket
Rinse aid reservoir
"Sieve system"→Page 42
"cutlery basket"→Page 23
11
12 Add rinse aid to the rinse aid reservoir.
"Rinse System", page 27
1Depending on the device version
Controls
You can use the control elements to set all the functions of your device and obtain
information about the operating status.
You can perform various functions with a few keys.
17

NLGetting to know your device
1 2 3 4 5 6 7 8
13 12 11 10 9
1ON/OFF button and Reset button "Turn on device"→Page 33
"Turn off device"→ Page 35
"Abort program"→ Page 35
2Program keys
Refill softening salt indicator
Rinse aid refill indicator
WLAN indication
Water supply indication
Key
"Programs"→ Page 19
"water softening"→ Page 24
"rinse system"→ Page 27
"Home Connect"→ Page 37
Water supply indication
3
4
5
6
7If you pressed for approx. 3 seconds,
open the basic settings.
8Start button
Program keys and additional functions
"Start program"→ Page 34
9"Programs"→ Page 19
"Additional Features"→ Page 21
10 Route Start
Sta
Display
em →"Remote rt", Page 38
to make"→ Page 34
Sta
11 choose rttime "Time setting
12 The display shows information about the time
remaining or basic settings. You can change the
basic settings via the display and the setting
buttons.
13 door opener1
Depending on the app
Device door o carrots.
1raatui performance
18

ProgramsNL
pp
programs
programs
phuh
programs
Here you will find an overview of the a switched off rinse system or lack of
rinse aid affects the run time. The
consumption values can be found in
the quick guide. The consumption
values apply under normal
conditions and a water hardness of 13
- 16 °dH. Various factors, such as
water temperature or pipe pressure,
can lead to deviations.
adjustable programs. Depending on
the configuration, different programs
are offered on the control panel of the
device. The running time depends on
the selected program. In addition, the
running time depends on the water
temperature, amount of dishes,
degree of soiling and selected "extra
function" → Page 21 † Also
Program Usage Program sequence Additional Features
China:
†Pots, pans, non-
clean delicate crockery
and cutlery.
Degree of pollution:
†Very caked, in-
burnt or dried up
remove food residues
containing starch or
protein.
Intensive:
†Pre-rinse
†Cleaning 70 °C †
Intermediate rinse
†Rinse aid 69 °C †
To dry
All
"Additional
functions", page 21
Intensive 70°
China:
†Mixed crockery and
clean cutlery.
Degree of pollution:
†Slightly dried up, in the
household to remove
usual food residues.
Sensor-optimized: †Becomes
dependent on the
degree of contamination
of the washing water
optimized by the sensor
system.
All
"Additional
functions", page 21
Auto 45-65°
China:
†Mixed crockery and
clean cutlery.
Degree of pollution:
†Slightly dried up, in the
household to remove
usual food residues.
Most economical program:
†Pre-rinse
†Cleaning 50 °C †
Intermediate rinse
†Rinse aid 61 °C †
To dry
All
"Additional
functions", page 21
Eco 50°
China:
†Mixed crockery and
clean cutlery.
Degree of pollution:
†Slightly dried up, in the
household to remove
usual food residues.
Sound-optimized: †
Pre-rinse
†Cleaning 50 °C †
Intermediate rinse
†Final rinse 63 °C †
To dry
All
"Additional
functions", page 21
Silent 50
19

NLPrograms
Program Usage Program sequence Additional Features
China:
†Mixed crockery and
clean cutlery.
Degree of pollution:
†Slightly dried up, in the
household to remove
usual food residues.
Time-optimized:
†Cleaning 65 °C †
Intermediate rinse
†Rinse aid 69 °C †
To dry
Extra Dry
"Additional
functions", page 21
Express 65° - 1h
Only use with the
device cleaned up.
Machine cleaning 70 °C No
Machine cleaning
† † †
Favorite
NoteThe relatively longer run time of
the Eco 50° program is due to longer
soaking and drying times. These
enable optimum consumption values.
The Pre-rinse program is stored under
this button at the factory. Pre-rinsing
is suitable for all types of crockery.
The dishes are pre-cleaned by cold
rinse.
Notes for test institutes Tip:You can download additional
programs via the Home Connect app
and store them under the button.1
Test institutes receive instructions for
comparison tests, e.g. according to
EN60436.
These are the conditions for
conducting the tests, not the results
or consumption values.
Inquiry by email to:
[email protected]
The product number (E-Nr.) and the
production number (FD) are required,
which you will find on the type plate on the
appliance door.
Save favorite to the device.
1.Press.
2.Press the program button.
→ †Programs", Page 19
3.Press the button for the desired
additional function.
→ †Additional functions", page 21
4.Press for 3 seconds.
aThe selected program and
the additional function will flash.
aflashes.
Favorite aThe program and the extra function
are stored.
Under the key
nation of a program and additional
function.
Save the program via the Home
Connect app or on the appliance.
can you make a combi Tip:To reset the program you can use
the Home Connect app or reset the
appliance.
1Depending on the device version
20
