Bosch SMV2ITX23E User manual

dishwasher
SMV2ITX23E
[en] Instructions for use
Translated from German to English - www.onlinedoctranslator.com

Further information and explanations can be
found online:
Table of contents
1 Security ................................... 4
1.1 General information .................... 4
8.2 Lower dish rack................. 21
8.3 Folding spines................................ 22
8.4 Cutlery basket .......................... 22
1.2 Intended
use ........................................... 4
1.3 Restriction of the user
group ........................................... 4
9 Before first use ............23
9.1 Initial
commissioning.................................... 23
1.4 Safe installation .................... 4
1.5 Safe use .................... 6
1.6 Damaged device.................... 8
1.7 Dangers for children................... 8
10 Softening system................... 23
10.1 Overview of the water hardness
settings ........................... 23
2 Avoid material damage .......... 10
2.1 Safe installation .................... 10
2.2 Safe use .................... 10
10.2 Setting the softening
system................................................. 24
10.3 Special salt................................ 24
10.4 Switching off the softening
system ........................... 25
3 Environmental protection and saving ....... 11
3.1 Dispose of packaging............11
3.2 Saving energy ....................... 11
10.5 Regenerating the softening
system .................................... 26
4 Setting up and connecting ..... 11
4.1 Scope of delivery................................. 11
11 Rinse aid system .................... 26
11.1 Rinse aid .......................... 26
4.2 Setting up and connecting the
device ........................... 12
11.2 Setting the amount of rinse aid
added ............................ 27
4.3 Waste water connection................. 12
4.4 Drinking water connection ............. 12
4.5 Electrical connection ............ 13
11.3 Switching off the rinse aid
system................................................. 27
12 Cleaners ................................... 27
12.1 Suitable cleaners ............ 27
12.2 Unsuitable cleaners............ 29
12.3 Notes on cleaners......... 29
12.4 Filling with cleaner.................... 29
5 Getting to know each other .......................... 14
5.1 Device.................................................. 14
5.2 Controls .......................... 16
6 programs ................................ 18
6.1 Information for test institutes......... 19 13 Tableware ................................... 30
6.2 Favorites. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
7 additional functions ...................... 20
13.1 Damage to glass and
dishes................................. 30
13.2 Putting away the dishes.................... 31
13.3 Clearing out the dishes.............. 32
8 Equipment ................................ 20
8.1 Upper dish rack ............21
2

de
14 Basic operation......32
14.1 Switching on the device .................... 32
14.2 Setting the program ............. 32
14.3 Setting additional functions ....... 32
14.4 Setting the time delay1........... 33
14.5 Start program.................... 33
14.6 Interrupting the program ....... 33
14.7 Cancel program ........... 33
14.8 Switching off the device .................... 34
21 Technical data ................... 53
21.1 Information on free and open
source software .......... 53
22 Declaration of Conformity ........... 54
15 Basic settings ................ 35
15.1 Overview of the basic
settings ........................... 35
16 Home Connect .......................... 38
16.1 Home Connect quick start .. 38
16.2 Remote start .......................... 39
16.3 Data protection.......................... 39
17 Cleaning and care ............. 39
17.1 Cleaning the rinsing container ............ 39
17.2 Cleaning agents ................... 40
17.3 Tips for device care.........40
17.4 Machine care. . . . . . . . . . . . . . . 40
17.5 Sieve system ........................... 41
17.6 Cleaning the spray arms................... 43
18 Troubleshooting ................... 44
18.1 Cleaning the waste water pump ..... 50
19 Transport, storage and
Disposal ................................ 50
19.1 Dismantling the device ................ 50
19.2 Making the device frost-proof...... 51
19.3 Transporting the device ................ 51
19.4 Dispose of old device................... 51
20 Customer service .......................... 52
20.1 Product number (E-No.),
production number (FD)
and counting number (Z-No.)........ 52
20.2 AQUA-STOP guarantee............ 52
1Depending on the device equipment
3

deSecurity
1 Security
Please note the following safety instructions.
1.1 General information
¡Read these instructions carefully.
¡Save the instructions and product information
later use or subsequent ownership.
¡Do not connect the device if it is damaged during transport.
1.2 Intended use
Use the device only: ¡to wash
household dishes.
¡in private households and in closed rooms of the home
chen environment.
¡up to an altitude of 4000 m above sea level.
1.3 Restriction of the user group
This device can be used by children aged 8 years and over and by
people with reduced physical, sensory or mental capabilities or lack
of experience and/or knowledge, if they are supervised or
instructed in the safe use of the device and understand the
resulting dangers have.
Children are not allowed to play with the device.
Cleaning and user maintenance must not be carried out by
children without supervision.
Keep children younger than 8 years away from the device and the connecting
cable.
1.4 Safe Installation
WARNING - Risk of injury!
Improper installations can result in injury.
▶When setting up and connecting the device, follow the instructions in
the operating instructions and assembly instructions.
4

Securityde
WARNING - Risk of electric shock!
Improper installations are dangerous.
▶Only connect and operate the device in accordance with the
information on the nameplate.
▶Always use the power cable supplied with the new device.
▶Only connect the device to an alternating current power supply
via a properly installed earthed socket.
▶The protective conductor system of the electrical house
installation must be installed correctly.
▶Never power the device via an external switching device,
e.g. B. timer or remote control.
▶When the device is installed, the mains plug of the mains
connection cable must be freely accessible, or if free access is not
possible, a disconnecting device must be installed in the fixed
electrical installation in accordance with the installation
regulations.
▶When setting up the device, ensure that the power cable is
not pinched or damaged.
Cutting the inlet hose or submerging the Aquastop valve in
water is dangerous.
▶Never immerse the plastic housing in water. The plastic housing
on the inlet hose contains an electric valve.
▶Never cut the inlet hose. There are electrical connection cables
in the inlet hose.
WARNING - Danger of fire!
Using an extended power cord and unauthorized adapters is
dangerous.
▶Do not use extension cables or multiple socket strips.
▶Only use adapters and power cables approved by the
manufacturer.
▶If the mains connection cable is too short and a longer mains
connection cable is not available, contact a specialist electrician
to adapt the house installation.
5

deSecurity
Contact between the device and installation cables can lead to a
defect in the installation cables, e.g. E.g., gas pipes and power
lines. Gas from a corroded gas line can ignite. A damaged power
line can lead to a short circuit.
▶Make sure that there is at least 5 cm distance between the
device and installation cables.
WARNING - Risk of injury!
Hinges move when the appliance door is opened and closed and
can cause injury.
▶If under-counter devices or devices that can be integrated are
not located in a niche and a side wall is therefore accessible, the
hinge area must be covered on the side. The covers are available
from specialist retailers or from our customer service.
WARNING - Danger of tipping!
Improper installation may cause the device to tip over.
▶Only install under-counter devices or integrable devices under a
continuous worktop that is firmly connected to the neighboring
cabinets.
1.5 Safe use
WARNING - Danger of serious damage to health! Failure to
follow safety instructions and instructions for use on the
packaging of cleaning products and rinse aid products can lead to
serious damage to health.
▶Follow the safety instructions and instructions for use on the
packaging of cleaning products and rinse aid products.
WARNING - Danger of explosion!
Solvents in the device's flushing chamber can cause explosions.
▶Never put solvents in the cleaning compartment of the device.
6

Securityde
Strongly caustic-alkaline or highly acidic cleaning agents in conjunction
with aluminum parts in the washing compartment of the device can lead
to explosions.
▶Never use highly caustic-alkaline or highly acidic cleaning agents,
especially from the commercial or industrial sector, in conjunction
with aluminum parts (e.g. grease filters from extractor hoods or
aluminum pots), e.g. B. for machine care.
WARNING - Risk of injury! An open device door
can lead to injuries.
▶Only open the appliance door when loading and unloading
dishes to prevent accidents, e.g. B. by stumbling.
▶Do not sit or stand on the open appliance door. Knives and
utensils with sharp points can cause injuries.
▶Place knives and utensils with sharp tips with the pointed side
facing down in the cutlery basket, knife rack or cutlery drawer.
WARNING - Danger of scalding!
Hot water can spray out of the appliance when the appliance door is
opened while the program is running.
▶Open the device door carefully while the program is running.
WARNING - Risk of electric shock!
Penetrating moisture can cause an electric shock.
▶Only use the device in closed rooms.
▶Never expose the device to extreme heat or moisture.
▶Do not use a steam cleaner or high-pressure cleaner to clean
the device.
Damaged insulation of the mains connection cable is dangerous.
▶Never bring the power cord into contact with hot parts of the
device or heat sources.
▶Never bring the power cord into contact with sharp points or
edges.
7

deSecurity
▶Never bend, squeeze or change the power cable.
1.6 Damaged device
WARNING - Risk of electric shock!
A damaged device or a damaged power cable is dangerous.
▶Never operate a damaged device.
▶Never operate a device with a cracked or broken surface.
▶Never pull on the power cord to disconnect the device from the
power supply. Always pull on the mains plug of the mains
connection cable.
▶If the device or the mains connection cable is damaged,
immediately pull out the mains plug of the mains connection
cable or switch off the fuse in the fuse box and close the tap.
▶Call customer service. → Page 52 Improper
repairs are dangerous.
▶Only trained specialist personnel may carry out repairs on the
device.
▶Only original spare parts may be used to repair the device.
▶If the mains connection cable or the device connection cable of
this device is damaged, it must be replaced with a special power
connection cable or special device connection cable, which is
available from the manufacturer or its customer service.
1.7 Dangers for children
WARNING - Danger of suffocation!
Children can pull packaging material over their heads or wrap
themselves in it and suffocate.
▶Keep packaging material away from children.
▶Do not let children play with packaging materials.
8th

Securityde
Children can inhale or swallow small parts and thereby
suffocate.
▶Keep small parts away from children.
▶Do not let children play with small parts.
Children can become trapped in the device and suffocate.
▶If available, use parental controls.
▶Never let children play with or operate the device.
WARNING - Danger of damage to health!
Children can become trapped in the device and endanger their
lives.
▶For old devices, pull the power plug of the power connection
cable, then cut the power connection cable and destroy the lock
on the device door to such an extent that the device door no
longer closes.
WARNING - Danger of crushing!
With high-mounted appliances, children can squeeze between the
appliance door and the cupboard doors underneath.
▶Pay attention to children when opening and closing the appliance door.
WARNING - Danger of chemical burns!
Rinse aid and cleaners can cause burns to the mouth, throat and
eyes.
▶Keep children away from rinse aid products and cleaning products.
▶Keep children away from the open device. The water in the
dishwashing room is not drinking water. There may still be
residues of cleaner and rinse aid in it.
WARNING - Risk of injury!
Children can get their little fingers caught in the slots in the tab
tray and injure themselves.
▶Keep children away from the open device.
9

deAvoid property damage
S2 property damage
avoid
avoid damage to the vehicle Contact between the device and
water pipes may cause corrosion of
the water pipe and the water pipe
may leak.
▶Make sure there is at least 5 cm
distance between the device and
the water pipe. The supplied lines
for the drinking water connection
and the waste water connection are
not affected.
Modified or damaged water hoses
can lead to property damage and
equipment damage.
▶Never bend, squeeze, alter or cut
water hoses.
▶Only use the water hoses supplied
or original replacement hoses.
▶Never reuse used water hoses.
If the water pressure is too low or too
high, the device function can be
impaired.
▶Ensure that the water pressure at
the water supply system is at least
50 kPa (0.5 bar) and maximum
1000 kPa (10 bar).
▶If the water pressure exceeds the
specified maximum value, a
pressure reducing valve must be
installed between the drinking
water connection and the hose set
of the device.
Avoid property damage
2.1 Safe Installation
DANGER!
Improper installation of the device
can result in damage.
▶If the dishwasher is installed under
or above other household
appliances, information on
installation in combination with the
dishwasher in the
Follow the installation instructions for the
respective household appliances.
▶If no information is available or the
installation instructions do not
contain any relevant instructions,
you must contact the manufacturer
of these household appliances to
ensure that the dishwasher can be
installed above or below other
household appliances.
▶If information is not available from
the manufacturer, the dishwasher
must not be installed above or
below these household appliances.
▶To ensure the safe operation of all
household appliances, continue to
follow the dishwasher installation
instructions.
▶Do not install the dishwasher
under a hob.
▶Do not install the dishwasher near
heat sources such as radiators, heat
accumulators, ovens or other
devices that generate heat.
2.2 Safe use
DANGER!
Escaping steam can damage built-in
furniture.
▶After the end of the program, allow the
device to cool down slightly before
opening the device door.
10

Environmental protection and savingde
Special salt for dishwashers can
damage the washing container
through corrosion.
▶To ensure that overflowed special
salt is rinsed out of the rinsing
container, fill the special salt into the
special salt storage container
immediately before the program
starts.
Cleaner can damage the softening
system.
▶Only fill the storage container of
the softening system with special
salt for dishwashers.
Unsuitable cleaning agents can
damage the device.
▶Do not use a steam cleaner.
▶To avoid scratching the device
surface, do not use sponges with a
rough surface or abrasive cleaning
agents.
▶To avoid corrosion, do not use
sponge cloths on dishwashers with
stainless steel fronts or rinse them
thoroughly several times before
first use.
3.2 Save energy
If you follow these instructions, your
device will use less electricity and
water.
Use the Eco 50° program.
aThe Eco 50° program is energy-
energy-saving and environmentally friendly.
→ "Programs", page 18
If you only have a few dishes to wash,
use the additional half load function.1
aThe program adapts to the
lower load and the consumption
values are reduced.
→ "Additional functions", page 20
A4
set up and
Set up and
Connect
Connect
ASset up and connect To ensure proper operation,
connect the device to electricity and
water properly. Please note the
required criteria and the assembly
instructions.
U3 environmental protection and
Save
environmental protection and saving
4.1 Scope of delivery
After unpacking, check all parts for
transport damage and that the
delivery is complete.
If you have any complaints, please
contact the retailer where you
purchased the device or our customer
service.
Environmental protection and saving
3.1 Dispose of packaging
The packaging materials are
environmentally friendly and recyclable.
▶Dispose of the individual components
separately according to type. A notice:The device was checked at the
factory to ensure that it functions
properly. This may leave water stains
on the device. The water stains
disappear after the first rinse.
1Depending on the device equipment
11

deSetting up and connecting
The delivery consists of: ¡
dishwasher
¡Instructions for use
¡assembly Instructions
¡Further information documents ¡
Mounting material
¡Vapor protection
¡Power cord
¡quick start Guide
4.3 Waste water connection
Connect your device to a wastewater
connection so that water
contaminated by the rinse cycle can
drain away.
Install waste water connection
1.Please refer to the assembly
instructions provided for the
necessary steps.
4.2 Set up and connect the
device 2.Connect the waste water hose to
the drain connection of the siphon
using the included parts.
You can install your under-counter
device or integrated device in the
kitchen unit between wooden walls
and plastic walls. If you subsequently
set up your device as a free-standing
device, you must secure your device
against tipping over, e.g. B. by
screwing on the wall or by installing it
under a continuous worktop that is
firmly connected to the neighboring
cabinets.
1.Follow the safety instructions.
→ page 4
3.Make sure that the drain hose is not
kinked, crushed or twisted.
4.Make sure that there is no cover in
the drain that prevents the waste
water from flowing out.
4.4 Drinking water connection
Connect your device to a drinking
water connection.
2.Follow the instructions for electrical
connection. Install drinking water connection
Hints
¡Make sure you do that
Connect the device to a water inlet
with a safety device to prevent
drinking water contamination
through backflow (according to DIN
EN 1717). The connection valves/
water taps provided for this purpose
are equipped with this safety device
if the house is installed correctly.
¡If you replace the device,
you must use a new water inlet
hose.
3.Check the scope of delivery and
the condition of the device.
4.Take the required installation dimensions
from the assembly instructions.
5.Set up the device horizontally using
the adjustable feet.
Make sure you have a secure footing.
6.Install the waste water connection.
→ page 12
7.Install the drinking water
connection. → page 12
8th.Connect the device to power.
1.Please refer to the assembly
instructions provided for the
necessary steps.
12

Setting up and connectingde
2.Connect the device to the drinking
water connection using the
included parts.
Observe the technical data.
3.Make sure that the drinking water
connection is not kinked, crushed or
twisted.
4.5 Electrical connection
Connect the device electrically
Hints
¡Observe the safety instructions
wise → page 4 .
¡Please note that the water
Safety system only works when
there is power supply.
1.Insert the cold appliance plug of the
mains connection cable into the
device.
2.Plug the power plug of the device's
power cord into a socket near the
device.
The connection data of the
device is on the nameplate.
3.Check that the power plug is firmly
seated.
13

de Get to know
K5
learn to name
Get to know
Get to know
5.1 Device
Here you will find an overview of the components of your device.
7 8th
69
5
410
311
2
1
12
1type label Type plate with E number and FD number
→ Page 52 .
You need the data for customer service →
Page 52 .
1Depending on the device equipment
14

Get to knowde
2Cleaner chamber Fill the cleaner chamber with cleaner.
→ "Cleaner", page 27
3Lower dish rack Lower dish rack →
Page 21
4Storage container for special
salt
Fill the special salt storage container with
special salt.
→ "Softening system", page 23
5Lower spray arm The lower spray arm cleans the dishes in
the lower basket.
If the dishes are not being cleaned
optimally, clean the spray arms.
→ "Cleaning spray arms", page 43
6Tab drip tray During the rinsing cycle, tabs automatically
fall from the detergent chamber into the
tab collecting tray, where they can dissolve
optimally.
7Upper dish rack
Cake stand1
Upper spray arm
Upper dish rack → Page 21
Cake stand
8th
9The upper spray arm cleans the dishes in
the upper basket.
If the dishes are not being cleaned
optimally, clean the spray arms.
→ "Cleaning spray arms", page 43
10 Sieve system
Cutlery basket
Sieve system → Page 41
Cutlery basket → Page 22
11
12 Rinse aid reservoir Fill the rinse aid reservoir with rinse aid.
→ "Rinse aid system", page 26
1Depending on the device equipment
15

deGet to know
5.2 Controls
You can use the control panel to set all of your device's functions and receive
information about its operating status.
Some buttons allow you to perform various functions.
12 3 4 5 6 7 8 9
ABC
141312 11 10
1ON/OFF button
button
and reset Switch on device →
Page 32 Switch
off device → Page 34 Cancel
program → Page 33
2Program button
programs
Water inlet indicator
Program progress display
Programs → Page 18
programs
Water inlet indicator
3
4
5The program sequence display shows
which program sequence the device is
in, e.g. B. Cleaning.
6Time delay1
me Sta
e
Set time delay → Page 33
R o Start ", page 39
7re ot rt →
" em te
8th Tbranch W
t
enn
back
ell
She
n, ö
gene.
approx. 3 seconds
Open the basic settingsd
s
e
n
9Start a
1Depending on the device equipment
T ste Progr amm start →
Page 33
16

Get to knowde
10 Program buttons and additional
functions
programs
→ "Programs", page 18
Additional functions
→ "Additional functions", page 20
11 Door handle1
WiFi display
Rinse aid refill indicator
Open the device door.
Home Connect → Page 38
12
13 Rinse aid system
→ "Filling with rinse aid", page 26
14 Special salt refill indicator Softening system
→ "Fill in special salt", page 24
1Depending on the device equipment
17

de programs
P6
rograms
programs
PH
rograms
Here you will find an overview of If the rinse aid system is switched on or if
there is a lack of rinse aid, the running time
changes.
You can find the consumption values
in the quick guide. The consumption
values refer to normal conditions and
a water hardness value of 7 - 16 °dH.
Different influencing factors can lead
to deviations, e.g. B. Water
temperature or line pressure.
the adjustable programs. Depending
on the device configuration, various
programs are available, which you
can find on the control panel of your
device.
Depending on the program you choose,
the duration may vary. The running time
depends on the water temperature, the
amount of dishes, the degree of soiling
and the additional function selected →
Page 20 away. When off
program use Program Sequence
Dishes:
¡Pots, pans, insensitive
ches crockery and cutlery
Degree of soiling:
¡strongly sticking, burned-in,
Dried, starchy and protein-
containing leftover food
Intensive:
¡Pre-rinse
¡Clean 70°C ¡
Intermediate rinsing
¡Rinse 69 °C ¡dry
Intense 70°
Dishes:
¡mixed dishes and dishes
plug
Degree of pollution:
¡slightly dried, household
usual leftovers
Sensor-optimized:
¡Becomes dependent on
of pollution
of the rinse water
optimized by sensors
mingled.
Auto 45-65°
Dishes:
¡mixed dishes and dishes
plug
Degree of pollution:
¡slightly dried, household
usual leftovers
Most economical pro
gram:
¡Pre-rinse
¡Clean 50°C ¡
Intermediate rinsing
¡Rinse 68 °C ¡dry
Eco 50°
Dishes:
¡mixed dishes and dishes
plug
Degree of pollution:
¡slightly dried, household
usual leftovers
Time optimized:
¡Clean 65°C ¡
Intermediate rinsing
¡Rinse 69 °C ¡dry
Express 65° - 1h
Only use when the device has been
cleared out.
Machine care
70°C
Machine care
18

programsde
program use Program Sequence
--
→ "Favorite ", page 19
Favorite
A notice:The comparatively longer
running time in the Eco 50° program
results from longer soaking and drying
times. This enables optimal
consumption values.
¡To set the program to the factory
To reset the pre-rinse program
stored on the page, use the Home
Connect app1or reset your device to
factory settings.
6.1 Information for test institutes
Test institutes receive the information for
comparative tests, for example according
to EN60436.
These are the conditions for carrying
out the tests, but not the results or
consumption values.
Inquiries by email to:
[email protected]
The product number (E-No.) and the
production number (FD), which can
be found on the type plate on the
appliance door, are required.
6.2 Favorites
You can save a combination of
program and additional function
on the button.
Save the program via the Home
Connect app.
The pre-rinse program is stored on
this button at the factory. Pre-rinsing
is suitable for all types of dishes. The
dishes are cleaned by rinsing them in
cold water.
Tips
¡You can use the Home Connect app to
You can download additional
programs and save them to the
button.1
1Depending on the device equipment
19

de Additional functions
Z7
Usage functions
Additional functions
ZH
Usage functions
Here you will find an overview of the additional functions that can be set. Depending on
Device configuration, various additional functions are available, which you can find
on the control panel of your device. Depending on the program, you can choose
certain additional functions.
symbol Additional function
Dry separately
use
¡For improved drying results
The rinse temperature is increased and the
drying phase is extended.
¡Particularly suitable for drying
plastic parts.
¡Energy consumption is slightly increased and
the term is extended.
Half load ¡Switch on when there are few dishes.
¡Less cleaner in the cleaning chamber
than is recommended for a complete
machine load.
¡The running time is shortened.
¡Water consumption and energy consumption
usage is reduced.
Hygiene+ ¡In order to ensure an increased hygiene status of
advises and dishes, the temperature is
increased and kept for an extra long time. ¡
Particularly suitable for cleaning
cutting boards or baby bottles. ¡By
continuously using this
function, an increased hygiene status is
achieved.
¡This increases the running time and the
Energy consumption increases.
A8th
equipment
Furnishing
AH
equipment
Here you will get an overview
about the possible features of your
device and its use. The equipment
depends on your device variant.
20
