Bosch Programme Table User manual

1 2 3 4 5 6
Cleaning the fluff filter
Clean the fluff filter after each dry ing operation.
1. Open the door, remove fluff from door/door area.
2. Pull out and fold open the fluff filter.
3. Remove the fluff (by wiping the filter with your hand).
If the fluff filter is very dirty or blocked, rinse with warm wa ter and dry
thoroughly.
4. Close and reinsert the fluff filter.
Switching off the dryer
Turn the programme selector to Off.
Do not leave laundry in the dryer.
Removing the laundry
The automatic anti-crease function c auses the drum to move at spec ific intervals, the washing remains
loose and fluffy for an hour (two hou rs if the additional Reduced Ironing function is also s elected-
depending on model).
... and adapt to individual requirements
Never start the dryer if it is damaged!
Inform your after-sales service . Inspecting the
dryer
Sorting and loading laundry
Remove all items from pockets.
Check for cigarette light ers.
The drum must be em pty prior to loading.
See programme overview on page 7.
Your new dryer
Congratulations - You have chos en a modern, high-quality Bosch
domestic appliance.
The vented dryer is distin guished by its economical e nergy
consumption.
Every dryer which leaves our factory is carefully chec ked to ensure
that it functions correctly and is in perfect condition.
Should you have any questions, our after-sales service will be ple ased
to help.
Disposal in an environmentally-respons ible manner
Dispose of packaging in an environmentally-responsible man ner.
This appliance is labelled in accordance with the European
guideline 2002/96/EG on waste ele ctrical and electronic
equipment - WEEE.
The guideline provides a n EU-wide framework fo r the return and
recycling of old appliances.
For further information about our p roducts, accessories, spare parts
and services, please visit: www.bosch-home.com
Intended use Preparing for installation, see P age 8
Selecting and adjusting the programme
Drying
Control panel
ʋfor domestic use only,
ʋonly to be used for drying fabrics that have bee n
washed with water.
Do not leave children
unsupervised near the dryer.
Keep pets away from the dryer.
The dryer can be op erated by children 8 years old
and older, by persons with reduced physical,
sensory or mental abilities and by persons with
insufficient experience or k nowledge if they are
supervised or have been instructed in its use by
a responsible adult.
Select the drying programme ...
Press the ĔStart/Stop button
1
2
3
Make sure your hands are dry.
Hold the plug only. Connecting the
mains plug
Drying
Information on laundry ...
Labelling of fabrics
Follow the manufacturer's care infor mation.
(Drying at normal temp erature.
'cDrying at low temperatu re aalso select &cLow Heat.
)cDo not machine dry.
Observe safety instructions with out fail aPage 11!
Do not tumble-dry the follow ing fabrics for example:
– Impermeable fab rics (e.g. rubber-coated fabr ics).
– Delicate materials (silk or curtains made fro m synthetic material) athey may crease.
– Dripping wet wa shing high aenergy consump tion!
– Laundry contami nated with oil.
Drying tips
– To ensure a consiste nt result, sort the laundry by fabric type a nd drying programme.
– Always dry very small items (e.g. baby socks) together with large items of laundry (e .g.h and
towel).
– Close zips, hooks and eye lets, and button up covers.
Tie fabric belts, apron strings, etc. toge ther
– Do not over-dry ea sy-care laundry arisk of creasing!
Allow laundry to finish drying in th e air.
– Do not dry woolens in the dryer, only use to freshen them up aPa ge 7, Woollens finish
Programme (depending on m odel).
– Do not iron laundry immediately after drying, fold items up and leave for a while athe
remaining moisture will t hen be distributed evenly.
– The drying result depends on the type of water used during washing. aFine adjustme nt
of the drying result aPage 6.
– Machine-knitte d fabrics (e.g. T-shirts or jerseys) often shrink the first time the y are dried a
do not use the Extra Dry programm e.
– Starched laun dry is not always suitable for dryers astarch le aves behind a coating that
adversely affects the drying operation.
– Use the correct dosage of fabric softener as per the man ufacturer's instructions when
washing the laundry to b e dried.
– Use the timer program me for small loads athis improves the drying result.
Environmental protection / Energy-saving tips
– Before drying, spin the la undry thoroughly in the washing machine athe h igher the spin
speed the shorter the drying time wi ll be (consumes less energy), al so spin easy-care
laundry.
– Put in, but do not exceed, the maximu m recommended quantity of laundry a
programme overview aPage 7.
– Make sure the room is well ventilated during drying.
– Clean the fluff filter a fter every drying cycle aPage 4.
– Do not obstruct or seal up the air inlet.
Drum
All buttons are sensitive and only
need to be touched lightly.
Only operate the dryer with
the fluff filter inserted! Air inlet
Fluff filter Programme end as soon as the light come s on
Interrupt programme removing or addi ng laundry.
The drying cycle can be inte rrupted for a brief period so that laundry may be added or r emoved.
The programme selected must then be resumed and completed.
Never switch the dryer off before the drying process has ended.
Drum and door may b e hot!
1. Open door, the drying process is interrupted.
2. Load or remove laundry and close door.
3. If required, select a ne w programme and additiona l functions.
4. Press the ĔStart/Stop button.
Contents Page
ʋPreparation . . . . . . . . . . . . . . . . . . . . . . 2
ʋSetting the programmes . . . . . . . . . . . . . 2
ʋDrying . . . . . . . . . . . . . . . . . . . . . . . . 3/4
ʋInformation on laundry . . . . . . . . . . . . . . 5
ʋFine adjustment of the drying re sult. . . . . 6
ʋCare and cleaning . . . . . . . . . . . . . . . . . 6
ʋProgramme overview . . . . . . . . . . . . . . . .7
ʋInstallation . . . . . . . . . . . . . . . . . . . . . . . . 8
ʋFrost protection / Transport . . . . . . . . . . . 8
ʋTechnical data . . . . . . . . . . . . . . . . . . . . 9
ʋOptional accessories . . . . . . . . . . . . . . . . 9
ʋWhat to do if... / After-sales service . . . . 10
ʋSafety instructions . . . . . . . . . . . . . . . . 11
Additional
functions
Programme selector
Display panel
Service displays
Door
Filter/Venting
Hose
Close door.
Clean the fluff filter under running water. Check exhaust air line. aPage 6.
Read these instructions before opera ting the dryer.
Also observe the separate instal lation instructions
for the exhaust air duct!
Observe the safety instr uctions on page 11.
Care and cleaning
Dryer housing, Control panel, Air inlet, M oisture sensors
– Wipe off with a soft, d amp cloth.
– Do not use abrasive cleaners o r solvents.
– Remove deterge nt and cleaning age nt residue immediatel y.
Exhaust air d uct
Check the exhaust air duct. Cl ean the exhaust air duct every six months .
Do not bend the exhaust air duct.
1. Switch off the dryer and allow it to cool dow n.
2. Disconnect the ma ins plug.
3. Remove the exha ust air duct.
4. Clean the exhaust air duct.
5. Refit the exha ust air duct aInstallat ion instructions fo r exhaust air duc t.
Moisture sensors
The dryer is equipped with st ainless steel moisture sensors.
Moisture sensor s measure the m oisture level o f the laundry.
After sustained, repe ated operation, a fine layer of limes cale may form
on the moistur e sensors.
1. Open the door.
2. Clean the moisture s ensors using a slightly dam p sponge with a rough
surface.
Do not use steel wool or abras ive materials.
Only when switched off!
Fine adjustment of the drying result
Adjustment of the levels of dryness
üüüüü
1 x to
the right
Press and hold &L ow Heat and
turn 5 x to the right
Press &Low Heat unti l
the required level is reached
Turn to Off Turn to Off
L:00, L:01, L:02, L:03 are shown in sequence
Short signal when chang ing from L:03 to L:0 0,
otherwise long s ignal.
ˎh:min End of pro gramme in 1*-24 hours (Press button several ti mes if required)
(*depending on the selected pro gramme, e.g. duration 1:54h a2h.
Can always be selecte d to the next full hour .
Time
remaining
Select On/Off for a acoustic signal at end of programme. ʋ&Buzzer
Reduced temperature for del icate fabrics 'that require a longer
drying time; e.g. for polya crylics, polyamide, elastane or acetate.
ˎ&cLow Heat
Reduces creasing and extends th e anti-creasing phase once the
program has ended.
ˎcReduced
Ironing
Fine
adjustment
of the drying
result
The drying result (e.g. Cupb oard Dry) can be adjusted over three levels (1 - max. 3)
for the LCottons,IEasy-Care and ASuper Quick 40’ programmes apresetting = 0.
After one of these programmes ha s been finely adjusted, the setting is r etained for the others.
Further information aPage 6.
0, 1, 2, 3

7
Programme overview also see Page 5
Sort the laundry according to type of textile and fabric. Fabrics must be suitable for tumble drying. After drying...
c
iron laundry

lightly iron laundry
@c
do not iron laundry
c
mangle laundry
PROGRAMMES TEXTILE TYPE AND I NFORMATION **LCottons max. 8 kg Hard-wearing fabrics, boil-re sistant fabrics made of cotton or l inen.
**IEasy-Care max. 3.5 kg Non-ir onl aundry made of synthetic fibres and blended fabric, easy -care cotton.
Iron Dry c÷@c Fa brics suitable for ironing (iron fabrics in or der to avoid creasing). Cupboard Dry @Single-layer fabrics. *Very Dry @Fabrics made of th ick, multilayered items of clothi ng.
*Extra Dry @Fabrics made of very thick, multi-layered items of clothing whic h need to be dried longer.
Woollens finish max. 3 kg Woollen fabrics suitable for washing machine s.F abrics become fluffier but not dry.
Remove fabrics once the programm e hase nded and allow to dry.
ASuper Quick 40’ max. 2 kg
Laundry made of synthetic fibr es, cotton or blended fabrics (for example) that needs t obe d ried quickly. The values may differ from the those specified dep ending on the type of fabric, mixture of laundry to be dried, resi dual moisture in the fabric and loading capacity.
Timed Programme warm 40’ / warm 20’ max. 3 kg Pre-dried, multi-layered, sensit ivefab rics made of acrylic fibres, or separate small items of laundry.
Also for subsequent drying .
*for LCottons and IEasy-Care p rogrammes only
**Dryness levels can be selec ted individually aExtra Dry, Very Dry, Cupboard Dry and Iron Dry (depending on the mo del).
Degree of dryness can be finely adjusted; multi-layered textile s require a longer drying time than single-layered items of clothing. Recommendation: Dry separa tely.
9204 / 9000773722 *773722* Robert Bosch Hausgeräte GmbH
Carl-Wery-Str. 34
D-81739 Munich/Germany
WTV74309GB
8
Installation
– Delivery specification : dryer, instructions for insta llation and use.
– Check dryer for transpo rt damage.
– The dryer is very heavy. Do not attempt to lift it on your own.
– Be careful to avoid sharp edges.
– Do not lift the dryer by any of the protruding parts (e.g. th e door) as they may break off.
– Do not set up in a roo m that is susceptible to frost.
Freezing water may cause damage.
– If in doubt, have t he appliance connected b y an expert.
Setting up the dryer
– The appliance plug must always be accessible.
– Ensure that the appliance is instal led on a clean, lev el
and solid surface.
– Keep the coolin g grille at the front of the dryer
unobstructed.
– Keep the area ar ound the dryer clean.
– Make the dryer level using the thread ed feet
and a spirit level.
Do not remove the threaded feet under any
circumstances.
Mains conn ection see safety instru ctions a Page 11.
– Connect to an AC earthed socket. If in doubt ha ve the socket checked by an expert.
– T he mains voltage and th e voltage shown on the rating plate (
a Page 9) must correspond.
– The connected load and necessary fuse pro tection are specified on the rating plate.
Frost protection / Transport
Preparation
1. Select any p rogramme using the programme selector.
2. Press the ĔStart/Stop button.
3. Turn the programme selector to Off.
1.
Take all accessory parts
out of the drum.
The drum must be em pty.
Make sure that the air
inlet remains unobstru cted
Clean and level
2.
Do not operate the d ryer if
there is a danger of frost .
Do not set up the d ryer behind a door or sliding
door as this may obstruct or pr event the dryer door
from opening. This will prevent a potentially fatal
danger to children from locki ng themselves in.
9
Technical data
ʠDimensions (DxWxH) 60 x 60 x 85 cm (height adjusta ble)
Weight approximately 36 kg
Max. capacity 8 kg
Ambient temperature 5 - 35 °C
Connection voltage
Connected load
Fuse protection see appliance rating plate
Ambient temperature
Product number/
Production number
You can find the rating plate on the back of the dryer.
ʠConsumption ra tes These are guide values determine d under standard
conditions. Fluctuations up to 10% a re possible.
Spin speed in rpm
(residual moisture)
Drying time
in min.**
Energy
consumption
in kWh**
LCottons 8 kg 13 A 13 A
Cupboard Dry* 1400 (app rox. 50 %) 95 3.50
1000 (approx. 60 %) 118 4.20
800 (approx. 70 %) 135 4.79
Iron Dry* 1400 (approx. 50 %) 67 2.37
1000 (approx. 60 %) 90 3.15
800 (approx. 70 %) 107 3.84
IEasy-Care 3.5 kg
Cupboard Dry* 800 (approx. 40 %) 37 1.18
600 (approx. 50 %) 44 1.48
*Test program according to DIN EN 61121.
**The values may differ from the t hose specified depending on the typ e of fabric, mixture
of laundry to be dried, re sidual moisture in the fabric and loading capacity.
ʠDrum interior light (depending on model) (bulb E14, 25 W)
The drum is illuminated after the d oor is opened or closed, and also afte r the programme
is started. It goes out automatically. Replaci ng the bulb
a Page 10.
Optional accessories (or der from the after-sales service using the o rder number)
Exhaust air set (depending on m odel)
The exhaust air is conveyed direc tly via a hose.
Washer-dryer stack connec tion set
The dryer can be placed o n top of a suitable washin g machine with the same width a nd depth
to save space. This connect ion set must always be used to secure the dryer to the washing
machine. With pull-out worktop: WT Z 11300
Installation underneath the worktop
Risk of electric shock!
Instead of the appliance covering plate, you must have a m etal cover fitted by an expert.
WTZ
1130
WTZ
11310
WTZ
10290
10
What to do if ...
If you cannot rectify a f ault yourself (e.g. switching off/on), please conta ct our after-sales service.
We will always find a n appropriate solution and w ill avoid unnecessary visi ts by engineers.
Trust the expertise of the manufacturer and rest assured that the repair wi ll be carried out by
trained service technicians using original spare parts. The contac t details of your local after-
sales service ca n be found in th e enclosed after-sales service directory, or by calling one of
these numbers:
–GB 0844 8928979 (Calls from BT landlin e will be charged at up to 3 penc e per minute.
A call set-up fee of up to 6 penc e may apply.)
–IE 01450 2655
When contacting the afte r-sales service, please quote the a ppliance's product number (E no.)
and production number (FD) (see the inside of the door).
Set the prog ramme selector to Off a nd remove the appliance plug from the socket.
ʠThe ĔStart/Stop indicator l amp
does not light up.
Mains plug plugged in?
Programme selected?
ʠThe Filter/Venting Hose
and ĔStart/Stop indicator li ghts
are flashing.
Clean the fluff filter und er running water aPage 4
Exhaust air duct blocked o r knicked? a
Clean the exhaust air duct aPage 6.
If necessary, clean the insect screen on the exhaust air pipe.
ʠDryer does not start. ĔStart/Stop button selecte d?
Door closed?
Programme set?
ʠThe door opens by itself and/or
the Door indicator light is lit.
Push the door clos ed until you hear it engage.
ʠProgramme terminated s hortly
after starting.
Ambient temperature h igher than 5 °C?
ʠWater is running out. Align dryer h orizontally.
ʠCreasing. Laundry load excee ded?
Remove articles o f clothing immediatel y after
the end of the programme, hang up and pull into shape.
Unsuitable programme selected aPage 7.
ʠDrying result is not satisfacto ry
(laundry feels too damp).
Warm laundry feels dampe r than it actually is.
The selected programm e does not suit t he load. Use another
drying programme or, in addition, se lect the time programme a
Page 7.
Use fine adjustment for the drying result aPage1/2 and 6.
Fine layer of limescale on the humidity sensors
aClean the humidity sensors aPa ge6 .
Programme termination, e.g. tank full, mains power supply failure,
door open or maxim um drying time reache d.
ʠDrying time too long. Rinse the fluff filters under running water aPage 4.
Insufficient supply of air ae nsure that air can c irculate.
Air inlet possibly blocked aClear inlet aPage 8.
Ambient temperature h igher than 35 °C aventilate the room.
ʠThe humidity in th e room
increases significantly.
Make sure the room is sufficiently ventilated.
ʠOne or more indic ator lights for
programme status are flashing.
Clean the fl uff filter u nder running water a Page 4.
Check installation con ditions
a Page 8.
Exhaust air duct blocked o r knicked? a
Clean the exhaust air duct aPage 6.
If necessary, clean the insect screen on the exhaust air pipe.
Switch off, leave to co ol down, switch on again , restart
programme.
ʠMains failure. Remove laundry from the dryer im mediately and spread out.
This allows the heat to dissipa te.
ʠThe interior light is n ot working
(depending on model).
Pull out the appliance plug, remove the cover cap in the interior
above the door (use Torx 20 screw driver) and replace the bulb.
Close the cover cap .
Never operate the dryer without a cover cap.
ʠCondensation in the exhaust air
duct.
Exhaust air duct too long? Che ck the maximum exhaust air d uct
length. Further information aInstal lation instructions for exhaust
air duct.
11
Safety instructions
Emergency – Pull the appliance plug out of the socket immedia tely or disconnect the fuse.
ONLY use the
dryer...
– in rooms inside the hou se.
– to dry fabrics.
The dryer must
NEVER...
– be used for other purposes than those de scribed above.
– be modified in terms of its technology o r attributes.
Dangers – The dryer must not be used by children or persons who hav e not been
instructed in its use.
– Do not l eave children unsup ervised near the dryer.
– Keep pets away f rom the dryer.
– Remove all objects f rom pockets.
Make especially sure that cigarette lighters are removed as they constitute
an
a explosion hazard.
– Do no t lean or sit on the door
a risk of tipping.
– Open the door w ith care. Hot steam may esc ape.
Installation – Secure loose cables a tripping hazard.
– Do not operate the dryer if there is a risk of frost.
– The safety informatio n in the separate installation instructions for the exhaust
air duct must be observed without fail.
Mains
connection
– Connect the dryer according to specific ations to an AC ear thed socket,
as otherwise it cannot be guaranteed that the appliance is completely safe.
– The cable cross-secti on must be sufficient.
– Only use earth-leakage circuit breakers with the following symbol:
– The appliance plug a nd socket must be compatible.
– Do not u se multiple plugs/cou plings and/or extension cables.
– Do no t hold the applianc e plug with wet hands
a risk of electric shock.
– Never pull the appli ance plug out of the socket by its cable .
– Do no t damage the main s lead
a risk of electric shock.
Operation – Only load the drum with laundry.
Check the contents befo re you switch the dryer on.
– Do no t use the dryer if the laundry has been in contact with solvents, oil, wax,
grease or paint (e.g. hair setting spr ay, nail polish remover, stain remover,
cleaning solvent, etc.)
a fire/explosion hazard.
– Dust (e.g. coal dust, flour) poses a danger: do not use the dryer
a explosion hazard.
– Do n ot put laundry containing foamed m aterial/rubber in the dryer
a elastic
material may be destroyed and th e dryer may be damaged due to p ossible
deformation of the foamed material.
– Switch off the dryer once the programme has ended.
Defect – Do not use the dryer if it is d efective or if you suspect it is.
Repairs must only be carrie d out by the after-sales service.
– Do not use the drye r if the mains cable is defective. To avoid danger, only
have the defective mains cabl e replaced by the after-sales service.
– Always pull the mains p lug out of the socket before ch anging the bulb
for the interior light
a risk of electric shock.
Spare parts – Only use genuine spare parts and accessories for safety reasons.
Disposal – Dryer: pull out the appliance plug, then cut off the mains cab le
from the appliance.
Dispose of at municipal was te disposal facility.
– Packaging: do not lea ve children alone with packing pa rts
a risk of suffocation.
– All materials are e nvironmentally sound and can be reused.
Dispose of in an environmentally -responsible manner.
Dryer
en Instruction manu al

1 2 ... and adapt to individual requirements
Never start the dryer if it is damaged!
Inform your after-sales service. Inspecting the
Sorting and loading laundry
Remove all items from pockets.
Check for cigarette lighters.
The drum must be empty prior to loading.
See programme overview on page 7.
Your new dryer
Congratulations - You have chosen a modern, high-quality Bosch
domestic appliance.
The vented dryer is distinguished by its economical energy
consumption.
Every dryer which leaves our factory is carefully checked to ensure
that it functions correctly and is in perfect condition.
Should you have any questions, our after-sales service will be pleased
to help.
Disposal in an environmentally-responsible manner
Dispose of packaging in an environmentally-responsible manner.
This appliance is labelled in accordance with the European
guideline 2002/96/EG on waste electrical and electronic
equipment - WEEE.
The guideline provides an EU-wide framework for the return and
recycling of old appliances.
For further information about our products, accessories, spare parts
and services, please visit: www.bosch-home.com
Intended use Preparing for installation, see Page 8
Selecting and adjusting the programme
ʋfor domestic use only,
ʋonly to be used for drying fabrics that have been
washed with water.
Do not leave children
unsupervised near the dryer.
Keep pets away from the dryer.
The dryer can be operated by children 8 years old
and older, by persons with reduced physical,
sensory or mental abilities and by persons with
insufficient experience or knowledge if they are
supervised or have been instructed in its use by
a responsible adult.
Select the drying programme ...
Press the ĔMake sure your hands are dry.
Hold the plug only. Connecting the
mains plug ('ca&c)caaaaaaaaaaaaaaa
All buttons are sensitive and only
need to be touched lightly.
Only operate the dryer with
the fluff filter inserted! Ĕ
Contents Page
ʋPreparation . . . . . . . . . . . . . . . . . . . . . . 2
ʋSetting the programmes . . . . . . . . . . . . . 2
ʋDrying . . . . . . . . . . . . . . . . . . . . . . . . 3/4
ʋInformation on laundry . . . . . . . . . . . . . . 5
ʋFine adjustment of the drying result. . . . . 6
ʋCare and cleaning . . . . . . . . . . . . . . . . . 6
ʋProgramme overview . . . . . . . . . . . . . . . . 7
ʋInstallation . . . . . . . . . . . . . . . . . . . . . . . . 8
ʋFrost protection / Transport. . . . . . . . . . . 8
ʋTechnical data . . . . . . . . . . . . . . . . . . . . 9
ʋOptional accessories . . . . . . . . . . . . . . . . 9
ʋWhat to do if... / After-sales service . . . . 10
ʋSafety instructions . . . . . . . . . . . . . . . . 11
Additional
functions
Programme selector
Display panel
Service displays
Door
Filter/Venting
Hose
Close door.
Clean the fluff filter under running water. Check exhaust air line. aPage 6.
Read these instructions before operating the dryer.
Also observe the separate installation instructions
for the exhaust air duct!
Observe the safety instructions on page 11. aüüüüü
&&
ˎh:min End of programme in 1*-24 hours (Press button several times if required)
(*depending on the selected programme, e.g. duration 1:54h a2h.
Can always be selected to the next full hour.
Time
remaining
Select On/Off for a acoustic signal at end of programme. ʋ&Buzzer
Reduced temperature for delicate fabrics 'that require a longer
drying time; e.g. for polyacrylics, polyamide, elastane or acetate.
ˎ&cLow Heat
Reduces creasing and extends the anti-creasing phase once the
program has ended.
ˎcReduced
Ironing
Fine
adjustment
of the drying
result
The drying result (e.g. Cupboard Dry) can be adjusted over three levels (1 - max. 3)
for the LCottons,IEasy-Care and ASuper Quick 40’ programmes apresetting = 0.
After one of these programmes has been finely adjusted, the setting is retained for the others.
Further information aPage 6.

3 4
Cleaning the fluff filter
Clean the fluff filter after each drying operation.
1. Open the door, remove fluff from door/door area.
2. Pull out and fold open the fluff filter.
3. Remove the fluff (by wiping the filter with your hand).
If the fluff filter is very dirty or blocked, rinse with warm water and dry
thoroughly.
4. Close and reinsert the fluff filter.
Switching off the dryer
Turn the programme selector to Off.
Do not leave laundry in the dryer.
Removing the laundry
The automatic anti-crease function causes the drum to move at specific intervals, the washing remains
loose and fluffy for an hour (two hours if the additional Reduced Ironing function is also selected-
depending on model).
... and adapt to individual requirements
Inspecting the
dryer
Sorting and loading laundry
Selecting and adjusting the programme
Drying
Control panel
ʋʋ
Select the drying programme ...
Press the ĔStart/Stop button
1
2
3
Connecting the
mains plug
Drying ('ca&c)caaaaaaaaaaaaaaa
Drum
All buttons are sensitive and only
need to be touched lightly.
Only operate the dryer with
the fluff filter inserted! Air inlet
Fluff filter Programme end as soon as the light comes on
Interrupt programme removing or adding laundry.
The drying cycle can be interrupted for a brief period so that laundry may be added or removed.
The programme selected must then be resumed and completed.
Never switch the dryer off before the drying process has ended.
Drum and door may be hot!
1. Open door, the drying process is interrupted.
2. Load or remove laundry and close door.
3. If required, select a new programme and additional functions.
4. Press the ĔStart/Stop button.
ʋʋʋʋʋʋʋʋʋʋʋʋʋaaüüüüü
&&
ˎaʋ&'ˎ&cˎcLIAapresetting = 0.
ted, the setting is retained for the others.
a0, 1, 2, 3

56

ʋʋĔ
1
2
3
Information on laundry ...
Labelling of fabrics
Follow the manufacturer's care information.
(Drying at normal temperature.
'cDrying at low temperature aalso select &cLow Heat.
)cDo not machine dry.
Observe safety instructions without fail aPage 11!
Do not tumble-dry the following fabrics for example:
– Impermeable fabrics (e.g. rubber-coated fabrics).
– Delicate materials (silk or curtains made from synthetic material) athey may crease.
– Dripping wet washing high aenergy consumption!
– Laundry contaminated with oil.
Drying tips
– To ensure a consistent result, sort the laundry by fabric type and drying programme.
– Always dry very small items (e.g. baby socks) together with large items of laundry (e.g. hand
towel).
– Close zips, hooks and eyelets, and button up covers.
Tie fabric belts, apron strings, etc. together
– Do not over-dry easy-care laundry arisk of creasing!
Allow laundry to finish drying in the air.
– Do not dry woolens in the dryer, only use to freshen them up aPage 7, Woollens finish
Programme (depending on model).
– Do not iron laundry immediately after drying, fold items up and leave for a while athe
remaining moisture will then be distributed evenly.
– The drying result depends on the type of water used during washing. aFine adjustment
of the drying result aPage 6.
– Machine-knitted fabrics (e.g. T-shirts or jerseys) often shrink the first time they are dried a
do not use the Extra Dry programme.
– Starched laundry is not always suitable for dryers astarch leaves behind a coating that
adversely affects the drying operation.
– Use the correct dosage of fabric softener as per the manufacturer's instructions when
washing the laundry to be dried.
– Use the timer programme for small loads athis improves the drying result.
Environmental protection / Energy-saving tips
– Before drying, spin the laundry thoroughly in the washing machine athe higher the spin
speed the shorter the drying time will be (consumes less energy), also spin easy-care
laundry.
– Put in, but do not exceed, the maximum recommended quantity of laundry a
programme overview aPage 7.
– Make sure the room is well ventilated during drying.
– Clean the fluff filter after every drying cycle aPage 4.
– Do not obstruct or seal up the air inlet.
Ĕ
ʋʋʋʋʋʋʋʋʋʋʋʋʋaCare and cleaning
Dryer housing, Control panel, Air inlet, Moisture sensors
– Wipe off with a soft, damp cloth.
– Do not use abrasive cleaners or solvents.
– Remove detergent and cleaning agent residue immediately.
Exhaust air duct
Check the exhaust air duct. Clean the exhaust air duct every six months.
Do not bend the exhaust air duct.
1. Switch off the dryer and allow it to cool down.
2. Disconnect the mains plug.
3. Remove the exhaust air duct.
4. Clean the exhaust air duct.
5. Refit the exhaust air duct aInstallation instructions for exhaust air duct.
Moisture sensors
The dryer is equipped with stainless steel moisture sensors.
Moisture sensors measure the moisture level of the laundry.
After sustained, repeated operation, a fine layer of limescale may form
on the moisture sensors.
1. Open the door.
2. Clean the moisture sensors using a slightly damp sponge with a rough
surface.
Do not use steel wool or abrasive materials.
Only when switched off!
Fine adjustment of the drying result
Adjustment of the levels of dryness
üüüüü
1 x to
the right
Press and hold &Low Heat and
turn 5 x to the right
Press &Low Heat until
the required level is reached
Turn to Off Turn to Off
L:00, L:01, L:02, L:03 are shown in sequence
Short signal when changing from L:03 to L:00,
otherwise long signal.
ˎaʋ&'ˎ&cˎcLIAaa

7
Programme overview also see Page 5
Sort the laundry according to type of textile and fabric. Fabrics must be suitable for tumble drying. After drying...
c
iron laundry

lightly iron laundry
@c
do not iron laundry
c
mangle laundry
PROGRAMMES TEXTILE TYPE AND INFORMATION **LCottons max. 8 kg Hard-wearing fabrics, boil-resistant fabrics made of cotton or linen.
**IEasy-Care max. 3.5 kg Non-iron laundry made of synthetic fibres and blended fabric, easy-care cotton.
Iron Dry c÷@c Fabrics suitable for ironing (iron fabrics in order to avoid creasing). Cupboard Dry @Single-layer fabrics. *Very Dry @Fabrics made of thick, multilayered items of clothing.
*Extra Dry @Fabrics made of very thick, multi-layered items of clothing which need to be dried longer.
Woollens finish max. 3 kg Woollen fabrics suitable for washing machines. Fabrics become fluffier but not dry.
Remove fabrics once the programme has ended and allow to dry.
ASuper Quick 40’ max. 2 kg
Laundry made of synthetic fibres, cotton or blended fabrics (for example) that needs to be dried quickly. The values may differ from the those specified depending on the type of fabric, mixture of laundry to be dried, residual moisture in the fabric and loading capacity.
Timed Programme warm 40’ / warm 20’ max. 3 kg Pre-dried, multi-layered, sensitive fabrics made of acrylic fibres, or separate small items of laundry.
Also for subsequent drying.
*for LCottons and IEasy-Care programmes only
**Dryness levels can be selected individually aExtra Dry, Very Dry, Cupboard Dry and Iron Dry (depending on the model). Degree of dryness can be finely adjusted; multi-layered textiles require a longer drying time than single-layered items of clothing. Recommendation: Dry separately.
9204 / 9000773722 *773722* Robert Bosch Hausgeräte GmbH
Carl-Wery-Str. 34
D-81739 Munich/Germany
WTV74309GB
8
Installation
– Delivery specification: dryer, instructions for installation and use.
– Check dryer for transport damage.
– The dryer is very heavy. Do not attempt to lift it on your own.
– Be careful to avoid sharp edges.
– Do not lift the dryer by any of the protruding parts (e.g. the door) as they may break off.
– Do not set up in a room that is susceptible to frost.
Freezing water may cause damage.
– If in doubt, have the appliance connected by an expert.
Setting up the dryer
– The appliance plug must always be accessible.
– Ensure that the appliance is installed on a clean, level
and solid surface.
– Keep the cooling grille at the front of the dryer
unobstructed.
– Keep the area around the dryer clean.
– Make the dryer level using the threaded feet
and a spirit level.
Do not remove the threaded feet under any
circumstances.
Mains connection see safety instructions a Page 11.
– Connect to an AC earthed socket. If in doubt have the socket checked by an expert.
– The mains voltage and the voltage shown on the rating plate ( a Page 9) must correspond.
– The connected load and necessary fuse protection are specified on the rating plate.
Frost protection / Transport
Preparation
1. Select any programme using the programme selector.
2. Press the ĔStart/Stop button.
3. Turn the programme selector to Off.
1.
Take all accessory parts
out of the drum.
The drum must be empty.
Make sure that the air
inlet remains unobstructed
Clean and level
2.
Do not operate the dryer if
there is a danger of frost.
Do not set up the dryer behind a door or sliding
door as this may obstruct or prevent the dryer door
from opening. This will prevent a potentially fatal
danger to children from locking themselves in.
ʠʠLIʠ
a
ʠĔʠĔaaaʠĔʠʠʠʠaʠaaaaʠaaaaaʠʠ
aa
aaʠʠʠa
aaaaaaaaaa

c@c c
LIc÷@c @@@ALIa
aa
Ĕ1.
2.
Do not operate the dryer if
9
Technical data
ʠDimensions (DxWxH) 60 x 60 x 85 cm (height adjustable)
Weight approximately 36 kg
Max. capacity 8 kg
Ambient temperature 5 - 35 °C
Connection voltage
Connected load
Fuse protection see appliance rating plate
Ambient temperature
Product number/
Production number
You can find the rating plate on the back of the dryer.
ʠConsumption rates These are guide values determined under standard
conditions. Fluctuations up to 10% are possible.
Spin speed in rpm
(residual moisture)
Drying time
in min.**
Energy
consumption
in kWh**
LCottons 8 kg 13 A 13 A
Cupboard Dry* 1400 (approx. 50 %) 95 3.50
1000 (approx. 60 %) 118 4.20
800 (approx. 70 %) 135 4.79
Iron Dry* 1400 (approx. 50 %) 67 2.37
1000 (approx. 60 %) 90 3.15
800 (approx. 70 %) 107 3.84
IEasy-Care 3.5 kg
Cupboard Dry* 800 (approx. 40 %) 37 1.18
600 (approx. 50 %) 44 1.48
*Test program according to DIN EN 61121.
**The values may differ from the those specified depending on the type of fabric, mixture
of laundry to be dried, residual moisture in the fabric and loading capacity.
ʠDrum interior light (depending on model) (bulb E14, 25 W)
The drum is illuminated after the door is opened or closed, and also after the programme
is started. It goes out automatically. Replacing the bulb
a Page 10.
Optional accessories (order from the after-sales service using the order number)
Exhaust air set (depending on model)
The exhaust air is conveyed directly via a hose.
Washer-dryer stack connection set
The dryer can be placed on top of a suitable washing machine with the same width and depth
to save space. This connection set must always be used to secure the dryer to the washing
machine. With pull-out worktop: WTZ 11300
Installation underneath the worktop
Risk of electric shock!
Instead of the appliance covering plate, you must have a metal cover fitted by an expert.
WTZ
1130
WTZ
11310
WTZ
10290
10
What to do if ...
If you cannot rectify a fault yourself (e.g. switching off/on), please contact our after-sales service.
We will always find an appropriate solution and will avoid unnecessary visits by engineers.
Trust the expertise of the manufacturer and rest assured that the repair will be carried out by
trained service technicians using original spare parts. The contact details of your local after-
sales service can be found in the enclosed after-sales service directory, or by calling one of
these numbers:
–GB 0844 8928979 (Calls from BT landline will be charged at up to 3 pence per minute.
A call set-up fee of up to 6 pence may apply.)
–IE 01450 2655
When contacting the after-sales service, please quote the appliance's product number (E no.)
and production number (FD) (see the inside of the door).
Set the programme selector to Off and remove the appliance plug from the socket.
ʠThe ĔStart/Stop indicator lamp
does not light up.
Mains plug plugged in?
Programme selected?
ʠThe Filter/Venting Hose
and ĔStart/Stop indicator lights
are flashing.
Clean the fluff filter under running water aPage 4
Exhaust air duct blocked or knicked? a
Clean the exhaust air duct aPage 6.
If necessary, clean the insect screen on the exhaust air pipe.
ʠDryer does not start. ĔStart/Stop button selected?
Door closed?
Programme set?
ʠThe door opens by itself and/or
the Door indicator light is lit.
Push the door closed until you hear it engage.
ʠProgramme terminated shortly
after starting.
Ambient temperature higher than 5 °C?
ʠWater is running out. Align dryer horizontally.
ʠCreasing. Laundry load exceeded?
Remove articles of clothing immediately after
the end of the programme, hang up and pull into shape.
Unsuitable programme selected aPage 7.
ʠDrying result is not satisfactory
(laundry feels too damp).
Warm laundry feels damper than it actually is.
The selected programme does not suit the load. Use another
drying programme or, in addition, select the time programme a
Page 7.
Use fine adjustment for the drying result aPage1/2 and 6.
Fine layer of limescale on the humidity sensors
aClean the humidity sensors aPage 6.
Programme termination, e.g. tank full, mains power supply failure,
door open or maximum drying time reached.
ʠDrying time too long. Rinse the fluff filters under running water aPage 4.
Insufficient supply of air aensure that air can circulate.
Air inlet possibly blocked aClear inlet aPage 8.
Ambient temperature higher than 35 °C aventilate the room.
ʠThe humidity in the room
increases significantly.
Make sure the room is sufficiently ventilated.
ʠOne or more indicator lights for
programme status are flashing.
Clean the fluff filter under running water a Page 4.
Check installation conditions
a Page 8.
Exhaust air duct blocked or knicked? a
Clean the exhaust air duct aPage 6.
If necessary, clean the insect screen on the exhaust air pipe.
Switch off, leave to cool down, switch on again, restart
programme.
ʠMains failure. Remove laundry from the dryer immediately and spread out.
This allows the heat to dissipate.
ʠThe interior light is not working
(depending on model).
Pull out the appliance plug, remove the cover cap in the interior
above the door (use Torx 20 screw driver) and replace the bulb.
Close the cover cap.
Never operate the dryer without a cover cap.
ʠCondensation in the exhaust air
duct.
Exhaust air duct too long? Check the maximum exhaust air duct
length. Further information aInstallation instructions for exhaust
air duct.
aaaaaaaaaa

c@c c
LIc÷@c @@@ALIa
aa
Ĕ1.
2.
Do not operate the dryer if
ʠʠLIʠ
a
ʠĔʠĔaaaʠĔʠʠʠʠaʠaaaaʠaaaaaʠʠ
aa
aaʠʠʠa
11
Safety instructions
Emergency – Pull the appliance plug out of the socket immediately or disconnect the fuse.
ONLY use the
dryer...
– in rooms inside the house.
– to dry fabrics.
The dryer must
NEVER...
– be used for other purposes than those described above.
– be modified in terms of its technology or attributes.
Dangers – The dryer must not be used by children or persons who have not been
instructed in its use.
– Do not leave children unsupervised near the dryer.
– Keep pets away from the dryer.
– Remove all objects from pockets.
Make especially sure that cigarette lighters are removed as they constitute
an
a explosion hazard.
– Do not lean or sit on the door a risk of tipping.
– Open the door with care. Hot steam may escape.
Installation – Secure loose cables a tripping hazard.
– Do not operate the dryer if there is a risk of frost.
– The safety information in the separate installation instructions for the exhaust
air duct must be observed without fail.
Mains
connection
– Connect the dryer according to specifications to an AC earthed socket,
as otherwise it cannot be guaranteed that the appliance is completely safe.
– The cable cross-section must be sufficient.
– Only use earth-leakage circuit breakers with the following symbol:
– The appliance plug and socket must be compatible.
– Do not use multiple plugs/couplings and/or extension cables.
– Do not hold the appliance plug with wet hands a risk of electric shock.
– Never pull the appliance plug out of the socket by its cable.
– Do not damage the mains lead a risk of electric shock.
Operation – Only load the drum with laundry.
Check the contents before you switch the dryer on.
– Do not use the dryer if the laundry has been in contact with solvents, oil, wax,
grease or paint (e.g. hair setting spray, nail polish remover, stain remover,
cleaning solvent, etc.) a fire/explosion hazard.
– Dust (e.g. coal dust, flour) poses a danger: do not use the dryer
a explosion hazard.
– Do not put laundry containing foamed material/rubber in the dryer a elastic
material may be destroyed and the dryer may be damaged due to possible
deformation of the foamed material.
– Switch off the dryer once the programme has ended.
Defect – Do not use the dryer if it is defective or if you suspect it is.
Repairs must only be carried out by the after-sales service.
– Do not use the dryer if the mains cable is defective. To avoid danger, only
have the defective mains cable replaced by the after-sales service.
– Always pull the mains plug out of the socket before changing the bulb
for the interior light
a risk of electric shock.
Spare parts – Only use genuine spare parts and accessories for safety reasons.
Disposal – Dryer: pull out the appliance plug, then cut off the mains cable
from the appliance.
Dispose of at municipal waste disposal facility.
– Packaging: do not leave children alone with packing parts
a risk of suffocation.
– All materials are environmentally sound and can be reused.
Dispose of in an environmentally-responsible manner.
Dryer
en Instruction manual
