Bosch WPG23150NL Operating and maintenance instructions

Clothes dryer
WPG23150NL
[NL] User manual and
installation instructions
Translated from Dutch to English - www.onlinedoctranslator.com

NL
Refer to the Digital User's Guide for more
information.
Index
1 Safety................................................ 4
1.1 General instructions .................. 4
9 Programs ................................ 26
9.1 Automatic programs ..... 26
9.2 Time programs................................ 271.2 Destination of the device
rate .................................. 4
1.3 Restriction of users ...... 4
1.4 Secure installation................................. 5
1.5 Safer use ................................... 7
10 Accessories................................ 28
11 Laundry................................ 29
11.1 Preparing the laundry.......... 29
1.6 Safe cleaning and
maintenance ......................................... 10 12 The Ministry in Essence.. 29
12.1 Switching on the device .... 29
12.2 Set program .................. 29
2 Avoiding material damage ...... 11
3 Environmental protection and saving
ring................................................. 11
12.3 Loading the drum with
laundry ....................................... 29
3.1 Disposing of the packaging .... 11
3.2 Saving energy ....................... 11
3.3 Energy Saving Mode ........ 12
12.4 Starting the program ... 29
12.5 Adding laundry .................. 30
12.6 Program cancel.................. 30
12.7 Taking out the laundry .................. 30
12.8 Switching off the device .......... 30
12.9 Fluff filter ......................... 30
12.10 Condensate tank ........ 31
4 Set up and connection .................. 12
4.1 Unpacking the device .................. 12
4.2 Scope of delivery ..................... 12
4.3 Installation site
requirements ................................... 13 13 Child Lock .................................. 32
13.1 Activating child lock ........... 32
13.2 Deactivating the child lock.......... 33
4.4 Water drain hose...................... 13
4.5 Adjusting the device .......... 16
4.6 Connecting the appliance
electrically................................................. 16 14 Basic Settings .................. 34
14.1 Overview of the basic
settings ................................... 34
5 Getting to know your device................ 17
5.1 Device ................................... 17
5.2 Control panel..................... 18
14.2 Changing basic settings....... 35
15 Cleaning and maintenance .......... 35
6 Display ................................... 19
7 Buttons .................................. 22
15.1 Tips for cleaning and
the maintenance.................. 35
15.2 Base unit ................................ 36
15.3 Humidity sensor .................. 38
8 Drying target ................................... 25
8.1 Changing Drying Target................... 25
8.2 Adjust drying target................ 25
2

NL
16 Troubleshooting .................. 39
17 Transporting, Storing and
drain.................................. 43
17.1 Preparing the device for
transport ................................ 43
17.2 Disposal of your old
appliance ....................................... 43
18 Customer Service............................ 44
18.1 Product number (E no.) and
production number (FD) ........... 44
19 Consumption values .................. 45
20 Technical data.............. 46
3

NLSafety
1 Safety
Observe the following safety regulations.
1.1 General instructions
sRead this manual carefully.
sKeep the operating instructions and product information for future reference.
for use or for subsequent owners.
sDo not connect the device in case of transport damage.
1.2 Destination of the device
Only use the device:
sto use dryer-safe and water-washed textiles
dry and refresh.
sfor domestic use and in enclosed spaces within the
sly environment.
sto an altitude of 4000 m above sea level.
1.3 Restriction of users
This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and/or knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe
way and understand the resulting hazards. understood. Children must
not play with the appliance.
Cleaning and user maintenance shall not be made by children
unless they are supervised.
Make sure that children up to 3 years old and pets cannot reach the
device.
4

SafetyNL
1.4 Secure installation
WARNING ‒ Risk of electric shock! Improper
installations are dangerous.
▶Only connect and use the device in accordance with the
information on the type plate.
▶ Only connect the device to a mains supply with alternating
current via a properly installed earthing socket.
▶The protective earth system of the electrical house installation must be
installed in accordance with the electrical engineering regulations. The
installation must have a sufficiently large conductor diameter.
▶ When using an earth leakage circuit breaker, only use a type
marked with .
▶ Never power the device via an external switching device, e.g. a
time switch or remote control.
▶ Never connect the appliance to a circuit that is regularly turned
on and off by the utility company.
▶ When the device is installed, the mains plug of the mains
connection cable must be freely accessible or, if free access is not
possible, an all-pole disconnecting device must be installed in the
permanently installed electrical system in accordance with the
installation instructions.
▶When setting up the device, make sure that the power cord is
not pinched or damaged.
Damaged power cord insulation is dangerous.
▶Never bring the connecting cable into contact with hot
appliance parts or heat sources.
▶Never bring the power cable into contact with sharp points or
edges.
▶Never kink, pinch or alter the power cord.
WARNING ‒ Risk of fire!
Using an extended power cord and unauthorized adapters is
dangerous.
▶Do not use extension cords or multiple sockets.
5

NLSafety
▶Use only manufacturer-approved adapters and power cords.
▶If the power cord is too short and a longer power cord is not
available, contact an electrical retailer to adjust the home
installation.
WARNING ‒ Risk of injury!
The heavy weight of the device can cause injuries when lifted.
▶ Do not lift the device alone.
If this appliance is installed incorrectly in a washer-dryer column,
the installed appliance may fall.
▶ Only stack the dryer on top of a washing machine with the dryer
manufacturer's connection kit
→ "Accessories", Page 28 Any other placement method is not
allowed.
▶ Do not install the appliance in a washer-dryer column if the dryer
manufacturer does not offer a suitable connection set.
▶ Do not install appliances from different manufacturers and with
different depths and widths in a washer-dryer column.
▶Do not set up a washer-dryer column on a platform, the
devices can tilt.
WARNING ‒ Risk of suffocation!
Children can pull packing material over their head and become
entangled and suffocate.
▶Keep packaging material away from children.
▶Do not let children play with packaging material.
CAUTION ‒ Risk of injury!
The device may vibrate or move during operation.
▶Set up the device on a clean, flat and solid surface.
▶Level the appliance using the appliance feet and a spirit level.
6

SafetyNL
There is a tripping hazard with incorrectly laid hoses and mains
connection cables.
▶Lay the hoses and connection cables in such a way that they cannot
be tripped over.
If the appliance is moved by protruding parts, such as the loading
door, the parts can break off.
▶Do not move the appliance by protruding parts.
CAUTION ‒ Risk of cutting!
Sharp edges on the device can cause cuts if touched.
▶ Do not touch the device on sharp edges.
▶ Use protective gloves when installing and transporting the
device.
1.5 Safer use
WARNING ‒ Risk of electric shock!
A damaged appliance or damaged power cord is dangerous.
▶ Never use a damaged device.
▶ Never pull on the power cord to disconnect the device from the
power supply. Always pull the plug on the power cord.
▶ If the appliance or the mains cable is damaged, immediately
unplug the mains cable from the socket or switch off the fuse in
the fuse box.
▶Contact customer service. → Page 44 Penetrating moisture
can cause an electric shock.
▶Only use the device in closed rooms.
▶Never expose the device to excessive heat and humidity.
▶Do not use a steam cleaner, pressure washer, hoses or nozzles
to clean the appliance.
7

NLSafety
WARNING ‒ Risk of health hazard! Children can lock
themselves in the appliance and endanger their lives.
▶Do not install the appliance behind a door that blocks or
prevents the opening of the appliance door.
▶In the case of discarded appliances, remove the plug of the
mains cable from the socket, then cut the mains cable and
damage the lock of the appliance door so that the appliance door
no longer closes.
WARNING ‒ Risk of suffocation!
Children can inhale or swallow small parts and choke.
▶Keep small parts away from children.
▶ Do not allow children to play with small parts.
WARNING ‒ Risk of explosion!
Coal dust or flour in the vicinity of the device can cause explosions.
▶ Keep the area around the device clean during use.
WARNING ‒ Risk of poisoning!
The condensed water from this appliance is not drinking water and may be
contaminated with fluff.
▶ Do not drink or continue to use the condensed water from the
device.
Detergents and care products can lead to poisoning if ingested.
▶ Consult a doctor in case of accidental ingestion.
▶Keep detergents and care products out of the reach of children.
WARNING ‒ Risk of explosion!
Residues in the fluff filter can ignite during drying.
▶Clean the fluff filter regularly.
8

SafetyNL
Highly flammable items, such as lighters or matches, can ignite
during drying.
▶Before drying, remove all highly flammable objects from the
pockets of the laundry.
If unwashed laundry has come into contact with solvents, oil, wax,
wax remover, paint, grease or stain remover, it can ignite during
drying.
▶Do not dry unwashed laundry in this appliance.
▶Rinse the laundry thoroughly with hot water and detergent
before drying.
▶Do not use the appliance if the laundry is previously cleaned
with industrial chemicals.
WARNING ‒ Risk of fire!
The laundry was not cooled sufficiently if drying was interrupted
prematurely and could ignite.
▶Do not interrupt the drying program prematurely.
▶ Remove and spread out the laundry immediately if drying is
interrupted prematurely.
CAUTION ‒ Risk of injury!
The cover plate may break when climbing or clambering on the
device.
▶ Do not climb or scramble on the device.
The appliance may tip over when sitting or leaning on the open
door.
▶ Do not sit or lean on the appliance door.
▶ Do not place any objects on the appliance door.
Reaching into the rotating drum can cause injury to hands.
▶ Wait for the drum to come to a complete stop before reaching inside the
drum with your hand.
CAUTION ‒ Risk of burns!
The rear wall of the appliance becomes hot during operation.
▶ Do not touch the hot back wall.
▶ Keep children away from the hot back wall.
9

NLSafety
▶Set up the appliance with the rear wall close to a wall.
1.6 Safe cleaning and maintenance
WARNING ‒ Risk of electric shock! Improper
repairs are dangerous.
▶Only trained specialist personnel may carry out repairs on the
device.
▶Only original spare parts may be used for repair of the device.
▶If the power cord of this appliance is damaged, it must be
replaced by the manufacturer, its service agent or a similarly
qualified person in order to avoid a hazard. Penetrating
moisture can cause a shock.
▶Do not use a steam cleaner, pressure washer, hoses or nozzles
to clean the appliance.
WARNING ‒ Risk of injury!
The use of non-original spare parts and non-original accessories
is dangerous.
▶Only use original spare parts and original accessories from the
manufacturer.
WARNING ‒ Risk of poisoning!
Toxic fumes can be generated when cleaning agents containing
solvents are used.
▶Do not use solvent-based cleaning agents.
10

Avoid material damageNL
▶ Do not use hard scouring or
dishwashing sponges.
▶ Clean the device only with water
and a soft, damp cloth.
▶ Remove all detergent residues, spray
mist residues or residues immediately
upon contact with the appliance.
2 Material damage
avoid
PAY ATTENTION!
Incorrect dosage of fabric softeners,
detergents, care products and
cleaning agents can affect the
functioning of the appliance.
▶ Follow the manufacturer's dosing
recommendations.
Exceeding the maximum load
quantity affects the operation of the
appliance.
▶ Observe and do not exceed the
maximum load for each
programme.
→ "Programs", Page 26
Overheating of the device can affect
the operation of the device.
▶Keep the ventilation opening on
the device free during use.
▶Ensure adequate ventilation in
the room.
Light objects, such as hair and fluff,
can be drawn into the ventilation
opening of the device during
operation and affect the function of
the device.
▶Keep the environment clean while
using the device.
▶Keep light objects away from the
device.
Foam or foam rubber may deform
or melt when dried.
▶Do not dry foam or foam rubber
laundry.
Unsuitable cleaning agents can
damage the surfaces of the device.
▶Do not use sharp or abrasive
cleaning agents.
▶Do not use strong alcohol-based
cleaning agents.
3 Environmental protection and
savings
3.1 Disposing of the
packaging
The packaging materials are
environmentally friendly and can be
reused.
▶Dispose of the individual components
separately according to type.
3.2 Saving energy
If you follow these directions, your
device will use less power.
Use the device in a well-ventilated
area and keep the ventilation
opening of the device clear.
aA hindered air exchange
extends the program duration and
increases energy consumption.
Before drying, spin the laundry in
the washing machine.
aWetter laundry extends the
program duration and increases
energy consumption.
11

NLSet up and connect
Observe the maximum load for the
programmes.
→ "Programs", Page 26
4 Set up and connect
aExceeding the maximum
male load quantity extends the
program duration and increases
energy consumption.
4.1 Unpacking device
PAY ATTENTION!
Objects that remain in the drum and
that are not intended for use with the
device can lead to material and device
damage.
▶Before use, remove all these items
and the supplied accessories from
the drum.
Clean the fluff filter after drying →
Page 30 .
aA contaminated fluff filter
reduces the airflow in the
appliance, extends the program
duration and increases energy
consumption. 1.Completely remove packaging
material and protection from the
device.
Regularly clean the bottom unit →
Page 36 .
aA contaminated heat exchanger
ly extends the program duration and
increases energy consumption.
→ "Disposal of the packaging",
Page 11
2.Check the device for visible
damage.
3.3 Energy Saving Mode 3.Open the door.
4.Remove the accessories from the
drum.
If you do not operate the device for a
longer period of time, the device
automatically switches to energy-
saving mode. All clues disappear and
Start/ Pauseflashes.
The energy saving mode is exited
when you operate the device again.
5.Close the door.
4.2 Scope of delivery
After unpacking, check all parts for
transport damage and the
completeness of the delivery.
PAY ATTENTION!
Use with incomplete or defective
accessories may impair the operation
of the device or cause material
damage and damage to the device.
▶Do not use the device with
incomplete or defective accessories.
▶ Replace the accessories before
using the device.
→ "Accessories", Page 28
12

Set up and connectNL
delivery amount
catch
Description installation site To demand
in a laundry
drying column
The device al-
borrow with the
original connection
set of the drug
ger manufacturer in
a washer-dryer
to set up a column.
sConnection set
with pull-out
work schedule
→ Page 28
sConnection set
→ Page 28
Clothes dryer
Accompanying
documents
Water drain hose
with connection
brave, confirm
going material
and bend.
→ "water drainage
feeding hose",
Page 13
This device al-
borrow a washing
machine from the-
same manufacturer
place. The
depth and width
use of this
appliance with
the measurements
of the washing machine
china match
man.
The washer-dryer column
do not place on
a platform.
4.3 Installation site
requirements
PAY ATTENTION!
If the device is tilted more than 40°,
residual water can run out of the
device and cause material damage.
▶Carefully tilt the device.
▶ Transport the device upright.
Freezing residual water in the device
can damage the device.
▶Do not place and use the device in
frost-sensitive places or outdoors.
on a wall No snakes and
mains connection
between wall and
device clamping
man.
installation site
On the floor
To demand 4.4 Water drain hose
The device on
a clean, ef-
fen and fixed on-
place surface.
The device
e
During drying, condensation is
created that your appliance uses for
automatic cleaning. Use the
st
→
llen
Page 16 .
13

NLSet up and connect
water drain hose to direct excess
condensation water into the
wastewater.
1.Pull the condensate hose from
the connection.
Comments
sUse this appliance with the
supplied water drain hose. When you
connect the water drain hose
→ Page 14 , you do not need to empty
the condensed water container regularly
→ Page 32 . sYou can use this optional
→ "Accessories", Page 28 order from
the service department.
Connect water drain hose The condensate hose is connected to
the connection at the factory.
If you do not want to empty the
condensed water container of the device
regularly, connect the water drain hose.
Remark:When removing the
condensed water hose, liquid
may escape from the
connection.
PAY ATTENTION!
If the device is used without a
properly connected condensation
water hose or water drain hose, liquid
may leak from the connection piece.
▶Before using the device, connect the
condensate hose or the drain hose
in a professional manner.
2.Push the condensate hose onto the
holder.
Requirements
sThe device and its accessories
are unpacked.
→ "Unpacking device", Page 12
sThe appliance is on the installation
place set up.
→ "Installation site
requirements", page 13
14

Set up and connectNL
3.Push the water drain hose onto
the connection as far as it will go.
Water drainage connection types
PAY ATTENTION!
A clogged or closed drain can allow
accumulated waste water to flow back
into the unit.
▶Before using the device, ensure
that the waste water drains quickly
and clears blockages.
Drain in a
siphon.
The connection position
tie with a
hose clamp
(12-22 mm) bore
gene.
the water drainage
feeding hose with
a hose guide
thing on minimum
80 cm and maximum
times 100 cm
height confirmation
gene.
4.Insert the water drain hose into
the hose guide.
Remark:Of
the Y-divider
→ Page 28
can you replace the
water drain hose from
an additional device
rate like e.g.
a washing machine
on the same
Connect feed from
the siphon.
Make sure that the water
drain hose is not kinked.
5.Connect the appliance to the
water outlet.
→ "Drainage connection types",
page 15
Tip:To collect the condensed water
again in the condensed water
container, e.g. if the location of the
device is changed, undo these steps
in reverse order.
Drain in a
sink.
the water drainage
feed hose com-
crack through the
slide and with
the confirmation
securing material
at.
Up the bend
maximum 100
cm height
settle.
2
1
15

NLSet up and connect
Drain in a
ditch.
the water drainage
feed hose com-
crack through the
slide and with
the confirmation
securing material
at.
The bend on the
gutter.
4.5 Adjusting the device
To reduce noise and vibration, level
the device.
▶To adjust the appliance, turn the
appliance feet. Check the horizontal
adjustment of the appliance with a
spirit level.
All appliance feet must be firmly
planted on the floor.
4.6 Connecting the appliance
electrically
1.Insert the mains plug of the
appliance's connecting cable into
a socket in the vicinity of the
appliance.
The connection data for the device
can be found in the technical
data → Page 46 .
2.The mains plug on v
to learn.
asthma control
16

Getting to know your deviceNL
5 Getting to know your device
5.1 Device
Here you will find an overview of the components of your device.
6
5
4
3
2
1
Depending on the device type, details in the picture may differ,
e.g. the color and the shape.
an
1Vent 4Door
2Service valve of the bottom
unity → Page 36
5Condensate tank
→ Page 31
3Fluff filter →
Page 30
6Control panel
→ Page 18
17

NLGetting to know your device
5.2 Control panel
You can set all functions of your device and obtain information about the
operating status via the control panel.
2 3 4
1 1
4
1Programs →
Page 26
2Program selector
→ Page 29
3Display →
Page 19
Buttons → Page 22
4
18

DisplayNL
6 Display
The display shows the current setting values, options or information texts.
Example display indication
Indication
0:401
name Description
Program duration /
remaining time of
the program
Expected program duration or remaining
time of the program in hours and minutes.
1:25
8.01
0:45
Time program Time program is set.
→ "Time programs", page 27
Recommended load Maximum load amount for the
set program in kg.
1Ready in time
Child lock
→ "Buttons", Page 24
slights up: the child lock is activated. s
flashes: the child lock is activated
and the device was operated.
→ "Deactivate child lock", page 33
(
Pause)
Start/ Start / Pause Start, cancel or pause
slights up: the program is running and can
smoking or taking a break.
program can be
barrel.
be depicted
sflashes: it
started or restarted
(Iron
dry)
Drying purpose iron
dry
The drying target is
→ "Buttons", Pa
activated.
gina 23
1Example
19

NLDisplay
Indication name Description
(Closet-
dry)
Drying purpose cabinet-
dry
The drying target is activated.
→ "Buttons", Page 23
(cupboard dry
Plus)
Drying purpose cabinet-
dry Plus
The drying target is activated.
→ "Buttons", Page 22
+ 1
+ 2
+ 3
Drying target
suits
The custom drying target is activated.
→ "Drying target", Page 25
(Anti wrinkle) Anti-crease function The anti-crease function is activated.
→ "Buttons", Page 23
(Low temp
temperature)
Gentle drying Gentle drying for sensitive textiles is
activated.
→ "Buttons", Page 24
4kg
load)
(Half half load
quantity
Half the load quantity is activated.
→ "Buttons", Page 24
(Signal Silent drying Silent drying without beeps is activated.
→ "Buttons", Page 24
from)
Condensate tank
server
Emptying the condensed water container
→ Page 32 .
Push in the condensed water container
→ Page 32 .
fluff filter
bottom unit
Clean the fluff filter.
→ "Cleaning the fluff filter", page 30
Clean bottom unit.
→ "Base unit", page 36
hot cooling process The laundry is cooled with a rotating drum
to avoid damage to the laundry. The
process can be interrupted by opening the
door.
Remark:Do not change the program.
Program status
Program status
To dry
Drying purpose iron
dry
Drying purpose cabinet-
dry
Program status
Anti wrinkle
Pause
Program status
Program status(
Pause)
Start/
1Example
20
