BOSCH
Installation Instruction.=°-
Models
WTA 3500
Electric Vented Dryer
WTL 5400
Electric Condensation Dryer
J \
Quick Reference Index
INTRODUCTION 2
TOOLS NEEDED FOR INSTALL. 2
PARTS SUPPLIED FOR INSTALL. 2
PARTS NEEDED FOR INSTALL. 2
DRYER ELECTRICAL CORD 2
GROUNDING INSTRUCTIONS 2
ADDITIONAL GROUNDING
PROCEDURE 3
ELECTRICAL RECEPTACLE
VENTING 3
DUCTWORK 3
EXHAUST VENT HOOD 3
CONDENSATE DRAIN 3
TECHNICAL DATA
ELECTRICAL REQUIREMENTS 4
MINIMUM INSTALL. CLEARANCES 4
CHOOSING THE LOCATION 4-5
INSTALLATION
STEP 1, UNPACK THE DRYER 5
STEP 2, INSPECT THE DRYER 5
STEP 3, POSITION DRYER NEAR
INSTALLATION AREA 5
STEP 4, EXHAUST DUCT 5-6
STEP 5, CONDENSATE HOSE
CONNECTION 6-7
STEP 6, ELECTRICAL 7-8
STEP 7, POSITION AND LEVEL
THE DRYER 8
STEP 8, CONNECT DUCT SYSTEM
TO DRYER 9
STEP 9, FINAL CHECK LIST 9
I IMPORTANT: Before you begin read these instructions completely and carefully. ]
I
INSTALLER: Remove the door from all discarded appliances to avoid the danger of a
child suffocating.
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
(In case of change of ownership, manual should be conveyed with the dryer.)

Introduction
Read these installation instructions completely and
carefully. They will save you time and effort and help
to ensure optimum dryer performance. Be sure to
observe all listed warnings and cautions.
These installation instructions are intended for use by
qualified installers. In addition to these instructions
the dryer shall be installed:
• In the United States, in accordance with the
National Electric Code, ANSI/NFPA70 ~ latest
edition/State and Municipal codes and/or local
codes.
• In Canada, in accordance with the Canadian
Electric Code C22.1 - latest edition/Provincial
and Municipal codes and/or local codes.
Tools Needed for Installation
The following tools are needed far installationof this
dryer:
• Box cutter
• Flat blade screwdriver
•#2 Phillips head screwdriver
• Duct tape
• Caulking gun and compound
• Level
• Safety goggles
• Gloves
Parts Supplied for Installation
Condensation water drain hose (WTL 5400 only)
Stacking kit
Parts Needed for Installation
(Model WTA 3500 Only!)
Four inch (approx. 100 mm) diameter metal exhaust
duct (rigid or flexible) of properlength and with
elbows and exhaust vent hood required to vent to
outdoors.
Dryer Electrical Cord
The Bosch dryer comes with a 4-wire power supply
cord pre-installed. This cord fits a 4-wire receptacle
as shown in the upper section of Figure 1.
If your receptacle is a 3-wire receptacle, as shown in
the lower section of Figure 1, a 3-wire "Dryer Cord"
must be purchased locally. The 4-wire cord must then
be removed and the 3-wire cord installed in its place,
as instructed in following section titled,
To Change Cord.
When purchasing a 3-wire power supply cord make
sure the cord meets following requirements:
• U.L listed in the USA, CSA listed in Canada
• 240 volt rated (minimum)
• 30 ampere
• Type SRD or SRDT
• Five feet long (minimum)
4-wire receptacle
(14-30R)
3-wire receptacle
(10-30R)
Dryer shipped with
cord to fit this type
4-wire receptacle.
If you have 3-wire
receptacle, like this,
a 3-wire dryer cord
must be purchased
locally.
Figure 1.
Grounding Instructions
This appliance must be grounded. In the event of
malfunction or breakdown, grounding will reduce the
risk of electric shock by providing a path of least
resistance for the electric current. This appliance is
equipped with a cord having an equipment-grounding
conductor and a grounding plug. The plug must be
plugged into an appropriate outlet that is properly
installed and grounded in accordance with all local
codes and ordinances.
Improper connection of the equipment-
grounding conductor can result in a risk of
electric shock. Check with a qualified
electrician or serviceman if you are in
doubt as to whether the dryer is properly
grounded.

Additional Grounding Procedure
Some local codes may require a separate ground. In
such cases, the required accessory ground wire,
clamp and screw must be purchased separately.
Never ground the dryer to plastic plumbing lines,
gas lines or hot water pipes,
Electrical Receptacle
The receptacle for the dryer cord must be located so
that the power supply cordwill be accessible when
the dryer is in the installed position.
Venting
The WTA 3500, electric vented dryer, is intended to
be vented to the outdoors.To prevent build-up of
moisture and accumulation of lint indoors, as well as
to maintain maximum dryingefficiency, it is
recommended that the Bosch WTA 3500 be vented to
the outdoors.
Ductwork
Four-inch (approx. 100 mm) diameter ducting should
be used. Use either rigid metal or flexible metal
ducting material. DO NOT use non-metal duct with
this dryer.
Exhaust ducts should be as straight as possible.
Exhaust ducting longer than recommended Can
extend drying time, can collect lint and may effect
dryer performance. Joints should be secured with
duct tape. DO NOT use screws to secure joints as lint
can collect on the screws. See Step 4, Exhaust
Duct, in following section titled INSTALLATION for
recommended routing and duct length calculations.
Exhaust Vent Hood
The exhaust duct must end with an approved exhaust
vent hood with swing out damper(s). DO NOT use an
exhaust vent hood with magnetic latches. To avoid
restriction of exhaust the outlet must be a minimum of
12 inches (30 cm) above ground level, or any other
obstructing surface. See Figure 7.
Condensate Drain
The WTL 5400, electric condensation dryer, dries by
condensing the moisture from the dryer air and then
pumping this condensate out of the dryer.
The WTL 5400 must have itscondensate hose
connected to a suitable drain. See Step 5,
Condensate Hose Connection, in the following
section titled INSTALLATION.

Technical Data
Figure 2.
Electrical Requirements
WTA 3500:88 Ibs.(40 kg)
W]'. 5400:99 Ibs.(45 kg)
The Bosch dryers should be CONNECTED TO AN
30A INDIVIDUAL BRANCH CIRCUIT. North American
models have the following electrical rating:
Model Volts Hertz Amperes Watts
WrA 3500 208/240 60 13 3,100
WTL 5400 208/240 60 13 3,100
Minimum Installation Clearances
Alcove or Under Closet
Counter
Sides 0" (0 mm) 0" (0 mm)
Top 0" (0 mm) 10" (250 mm)
Rear 1" (25 mm) 5" (125 ram)
Ventilation Requirements
Alcove or Closet
Under Counter
Ensure air flow Closet door must have 2
of 6,700 cu.ff./hr (Iouvered) openings,
WTA (190 cu.m./hr) each having a minimum
3500 through dryer area of 60 sq. inches
(387 sq. cm.), located 3
inches (8 cm) from
bottom and top of door. *
Ensure air flow Closet door must remain
WTL of 7,100 cu.ft./hr open during dryer
5400 (200 cu.m./hr) operation.
through dryer
*-A Iouvered door with equivalent air opening is
acceptable.
Flooring
The dryer should be installed on a level, solidly
constructedfloor. DO NOT install the dryer on a
carpeted floor.
Check the rating plate on the dryer to make sure your
machine has this rating.
Choosing the Location
The dryer should bot be installed:
•in an area exposed to drippingwater or outside
weather conditions
•in an area where it (and imthe case of the WTA
3500, its exhaust duct) willcome in contact with
combustible materials, such as, curtains, drapes
or paper.
•in areas where water may freeze
• in an area where gasoline or other flammables
are kept or stored (includinggasoline powered
vehicles or equipment).
Check local codes before choosing a location. Some
codes do not permit installationof a clothes dryer in a
garage, closet, mobile home or sleeping area. Your
local building inspector shouldbe able to advise you
of the codes in your area.
Figure 3.
Built-in Installation
The Bosch dryer can be built-in: that is, you can
install the Bosch dryer under-countar in a kitchen
cabinet opening. The cabinet opening should be
square and have the dimensions as shown in
Figure 3.
4

Note: If installed under a countertop, the countertop
must be continuous and securely attached to
neighboring cabinets.
DO NOT install the dryer in an area where
gasoline or other flammable materials are
kept or stored (including automobiles or
other motorized vehicles).
The dryer must be installed in a room that is
adequately ventilated. Make sure there is an
adequate supply of fresh air. Both the WTA 3500,
electric vented dryer, and the WTL 5400, electric
condensation dryer need an adequate supply of fresh
air for optimum performance
ICAUTION:
DO NOT install the dryer in a closet with a
solid door.

INSTALLATION
Step 1
Unpack the Dryer
Carefully remove the packing material from the
outside of the dryer.
Step 2
Inspect the Dryer
Thoroughly inspect the dryer, prior to installation, for
possible freight or cosmetic=damage. Report any
damage immediately. Cosmetic damage must be
reported within 5 days of installation.
Be sure to install the exhaust according to all
governing codes and ordinances. Rigid metal duct is
recommended for venting this dryer. If flexible metal
duct is used, be sure it is fully supported when the
dryer is in its final position. Excess ducting should be
trimmed off to avoid sagging or kinking of the
ductwork.
Step 3
Position Dryer near Installation Area
Move the dryer so that it is within four feet of the
desired position.
Note: Corrugated packing materia, may be used to
protect the floor. Do not use corrugated
material with staples.
Step 4
Exhaust Duct
(Model W-FA 3500 Only!)
The WTA 3500 must be exhausted to the outdoors.
The duct may be connected to the left, right or back
of the WTA 3500, electric vented dryer. If connecting
to the left or right hand side of the dryer, remove the
sealing cover from the side to be used, as shown in
Figure 4.
1. To reduce the risk of fire, this dryer
MUST BE EXHAUSTED OUTDOORS,
when installed in an alcove or closet.
2. DO NOT use non-metal duct with this
dryer.
3. DO NOT use duct smaller than 4
inches in diameter.
4. DO NOT use exhau=t hoods with
magnetic latches.
5. DO NOT exhaust the dryer into a
chimney, furnace cold air duct, attic,
crawl space, or any other ductwork
used for venting.
6. DO NOT install flexible duct in an
enclosed wall, ceiling or floor.
7. DO NOT crush or kink the duct.
8. Do clean and inspect the exhaust
system on a regular basis; once a
year, at a minimum.
9. The exhaust duct must end with
swing out damper(s).
Figure 4.
The sealing cover should then be placed over the
open vent opening at the back of the dryer, as shown
in Figure 5.
6
Figure 5.
The connecting piece supplied with your WTA 3500
dryer must then be inserted in the vent opening that
will be used. See Figure 6.

Figure 6.
Checking/Installing Exhaust Ducting
The ducting system of the dryer, for optimum
performance, should be as short as possible with a
minimum number of elbows. Your WTA 3500 electric
vented dryer will work best when the venting system
has as few restrictions to the flow of air as possible.
Whether installingto an existing venting system or a
new venting system, make sure that all ducting is
clean and free of lint and does not exceed the length
per elbows as shown in Table 1, below:
Maximum length of duct
Number Rigid Flexible
of Elbows Duct Duct
030 ft. (914 cm) 20 ft. (610 cm)
1 22 ft. (670 cm) 15 ft. (457 cm)
2 14 ft. (427 cm) 9 ft. (274 cm)
3 6 ft. (183 cm) 4 ft. (122 cm)
Table 1.
Every elbow must have a minimum diameter of 4
inches (10 cm).
The above table assumes the use of an approved
exhaust vent hood with a swing out damper. DO
NOT use an exhaust vent hood with magnetic
latches. To avoid restriction of exhaust the outlet must
be a minimum of 12 inches (30 cm) above ground
level, or any other obstructing surface, as shown
below, in Figure 7.
12" (30 cm) min.
f
Figure 7.
Step 5
Condensate Hose Connection
(Model WTL 5400 Onlyl)
The WTL 5400 must have its condensate drain line
installed and run to a suitable drain. The connection
for the condensate hose is located on the back of the
WTL 5400, see Figure 8.
Figure 8.
The condensate drain hose should already be
connected to the dryer. The other end should then be
placed and secured at a nearby sink or drain, or if
installed with a washer it may, room permitting, be
installed next to the washer drain hose and drained to
the same drain used by the washer.
Be sure to follow all local codes and regulations in
running the condensate to a suitable drain.

Step6
Electrical
TheBoschdryercomeswith4-wirepowersupply
cordpre-installed.Thiscordfitsa4-wirereceptacle
asshownintheuppersectionofFigure1.
If your receptacle is a 3-wire receptacle, as shown in
the lower section of Figure 1, a 3-wire "Dryer Cord"
must be purchased locally. The 4-wire cord must then
be removed and the 3-wire cord installed in its place,
Electrical Connection, 4-Wire
For a 4-wire system, all that isnecessary is to plug
the 4-wire power supply cord into the 4-wire
receptacle of the proper rating.
Note: The receptacle should be located so that the
plug and receptacle will be accessible when
the dryer is in its final installed position.
Electrical Connection, 3oWire
If your receptacle is a 3-wire receptacle as shown
below, Figure 9, you must obtain a 3-wire dryer cord.
Dryer cord can usually be found at your local
hardware supply, electrical supply or home center.
Cord should have closed loop or upturned end wire
terminating connectors.
3- wire receptacle
__. (10-30R) _'_
Typical 3-wire Dryer Cord
240V/30 amp NEMA 10-30 Type SRDT
Figure 9.
Note: If the dryer is installed in a mobile home or in
areas where local codes do not permit
grounding, only a 4-wire power supply cord
shall be used.
To Change Cord:
1. Make sure that the dryer is not plugged into any
power outlet.
DO NOT plug end of dryer power cord into
a live receptacle before connecting dryer
power cord to dryer terminals and closing
junction/splitter box as described below.
DO NOT reuse old power supply cord.
Power cord must be changed only be a
qualified person.
2. Remove the screw from the cover of the
junction/splitter box located at the top rear of the
dryer
3. Remove the green ground wire from the ground
terminal.
4. Remove the red, white and black wire from the
terminal block.
5. Loosen the 2 screws in the U.L. strain relief
clamp, holding the 4-wire cable.
6. Thread the 4-wire cable out through the U.L.
strain relief clamp and throw away.
7. Thread the new 3-wire dryer cord through the
U.L. strain relief clamp.
8. Attach the power cord Ground conductor (the
center wire) to the Ground terminal. Tighten the
terminal so that it securely holds the Ground
conductor.
9. Attach the two remaining power cord outer
conductors to the 2 terminals labeled L. Tighten
both screws so that the power conductors are
securely held in place. See
Figure 10.
10. Tighten the screws on the U.L. strain relief so
that the power cord cannot be moved.

L Ground
Figure 10,
11. Check the nut on the U.L. strain relief clamp to
make sure that it is tight and the strain relief
clamp cannot turn.
12. Replace the cover on the junction/splitter box and
fasten in place.
The dryer is now ready to be plugged into the 3-wire
receptacle, of the proper rating.
Note: The receptacle should be located so that the
plug and receptacle will be accessible with the
dryer in its installed position.
Additional Grounding Procedure
Some local codes may require aseparate ground. In
such cases, the required accessory ground wire,
clamp and screw must be purchased separately.
Never ground the dryer to plastic plumbing lines,
gas lines or hot water pipes.
Step 7
Position and Level the Dryer
Place the dryer in position on a clean, level, solidly
constructed floor. Installation on any type of carpeting
is not recommended.
With dryer in position, it must then be leveled.
Check dryer, using level as shown in Figure 11.
CAUTION:
Do not slide dryer across the floor ifleveling
legs have been extended. Legs and/or dryer
base may be damaged ifdryer is slid across
floorwith levelinglegs extended.
Figure tl.
The dryer should be level with all four feet firmly on
the ground. The dryer must not wobble.
If the dryer is not level or if it does wobble, the legs
must be adjusted. Refer to Figure 12. Adjust the
leveling legs until the dryer does not rock and is level,
both front-to-back and side-to-side.
Figure 12.

Step8
ConnectDuctSystemtoDryer.
(ModelWTA3500Onlyl)
Connect the exhaust ducting system to the dryer
exhaust outlet.
Step 9
Final Check List
1. Review the electrical requirements (and for WTL
model the exhaust requirements) and steps 1
through 8 to make sure they were performed
properly.
2. Make sure the electricalsupply is on.
3. Read the Use & Care manual to fully understand
how your dryer operates. Turn on the dryer.
Select the "Heated Dry"cycleand let the dryer
run for 2-5 minutes.
4. After 2-5 minutes stop the dryer and open the
door. You shouldfeel heat inside the dryer.
5. If the dryer does not operate, refer to the SELF-
HELP and the SERVICE and REPAIR sections of
the Use and Care Manual.
6. Upon completing check, turn dryer off.
7. LEAVE INSTALLATION INSTRUCTIONS AND
USE and CARE MANUAL WITH OWNER.
10

II

508 0108 AB8
12
