Bosch HIJN17EW0R User manual

Register your
new device on
MyBosch now and
get free benefits:
bosch-home.com/
welcome
Oven
HIJN17EW0R,
HIJN17EB0R
[en] User manual and installation instructions

en Safety
2
Table of contents
USER MANUAL
1 Safety ....................................................................2
2 Preventing material damage ...............................4
3 Environmental protection and saving en-
ergy .......................................................................4
4 Familiarising yourself with your appliance ........6
5 Before using for the first time ...........................10
6 Basic operation ..................................................10
7 Rapid heating .....................................................10
8 Time-setting options..........................................11
9 Steam-assisted cooking ....................................12
10 Programmes .......................................................13
11 Childproof lock...................................................15
12 Basic settings.....................................................15
13 Cleaning and servicing......................................16
14 Cleaning assistant for wet-cleaning .................16
15 Rails ....................................................................17
16 Appliance door...................................................17
17 Troubleshooting.................................................20
18 Transportation and disposal .............................21
19 Customer Service...............................................21
20 How it works.......................................................22
21 INSTALLATION INSTRUCTIONS .......................38
1 Safety
Observe the following safety instructions.
1.1 General information
¡Read this instruction manual carefully.
¡Keep the instruction manual and the
product information safe for future refer-
ence or for the next owner.
¡Do not connect the appliance if it has been
damaged in transit.
1.2 Intended use
This appliance is designed only to be built
into kitchen units. Read the special installation
instructions.
Only a licensed professional may connect ap-
pliances without plugs. Damage caused by in-
correct connection is not covered under the
warranty.
Only use this appliance:
¡To prepare meals and drinks.
¡In private households and in enclosed
spaces in a domestic environment.
¡Up to an altitude of max. 4000m above
sea level.
Do not use the appliance:
¡with an external timer or a remote control.
1.3 Restriction on user group
This appliance may be used by children aged
8 or over and by people who have reduced
physical, sensory or mental abilities or inad-
equate experience and/or knowledge,
provided that they are supervised or have
been instructed on how to use the appliance
safely and have understood the resulting
dangers.
Do not let children play with the appliance.
Children must not perform cleaning or user
maintenance unless they are at least 15 years
old and are being supervised.
Keep children under the age of 8 years away
from the appliance and power cable.
1.4 Safe use
Always place accessories in the cooking com-
partment the right way round.
WARNING‒Risk of fire!
Combustible objects that are left in the cook-
ing compartment may catch fire.
▶Never store combustible objects in the
cooking compartment.
▶If smoke is emitted, the appliance must be
switched off or the plug must be pulled out
and the door must be held closed in order
to stifle any flames.
Loose food remnants, fat and meat juices
may catch fire.
▶Before using the appliance, remove the
worst of the food residues and remnants
from the cooking compartment, heating ele-
ments and accessories.

Safety en
3
Opening the appliance door creates a
draught. Greaseproof paper may come into
contact with the heating element and catch
fire.
▶Never place greaseproof paper loosely
over accessories when preheating the ap-
pliance and while cooking.
▶Always cut greaseproof paper to size and
use a plate or baking tin to hold it down.
WARNING‒Risk of burns!
The appliance and its parts that can be
touched become hot during use.
▶Caution should be exercised here in order
to avoid touching heating elements.
▶Young children under 8 years of age must
be kept away from the appliance.
Accessories and cookware get very hot.
▶Always use oven gloves to remove ac-
cessories or cookware from the cooking
compartment.
When the cooking compartment is hot, any al-
coholic vapours inside may catch fire.
▶Only use small quantities of drinks with a
high alcohol content in food.
▶Open the appliance door carefully.
WARNING‒Risk of scalding!
The accessible parts of the appliance become
hot during operation.
▶Never touch these hot parts.
▶Keep children at a safe distance.
Hot steam may escape when you open the
appliance door. Steam may not be visible, de-
pending on the temperature.
▶Open the appliance door carefully.
▶Keep children at a safe distance.
If there is water in the cooking compartment
when it is hot, this may create hot steam.
▶Never pour water into the cooking compart-
ment when the cooking compartment is
hot.
WARNING‒Risk of injury!
Scratched glass in the appliance door may
develop into a crack.
▶Do not use any harsh or abrasive cleaners
or sharp metal scrapers to clean the glass
on the oven door, as they may scratch the
surface.
The hinges on the appliance door move when
the door is opened and closed, which could
trap your fingers.
▶Keep your hands away from the hinges.
WARNING‒Risk of electric shock!
If the insulation of the power cord is dam-
aged, this is dangerous.
▶Never let the power cord come into contact
with hot appliance parts or heat sources.
▶Never let the power cord come into contact
with sharp points or edges.
▶Never kink, crush or modify the power
cord.
WARNING‒Risk of suffocation!
Children may put packaging material over
their heads or wrap themselves up in it and
suffocate.
▶Keep packaging material away from chil-
dren.
▶Do not let children play with packaging ma-
terial.
Children may breathe in or swallow small
parts, causing them to suffocate.
▶Keep small parts away from children.
▶Do not let children play with small parts.
1.5 Halogen bulb
WARNING‒Risk of burns!
The bulbs in the cooking compartment get
very hot. There is still a risk of burning for
some time after they have been switched off.
▶Do not touch the glass cover.
▶Avoid contact with your skin when cleaning.
WARNING‒Risk of electric shock!
When changing the bulb, the bulb socket con-
tacts are live.
▶Before replacing the bulb, ensure that the
appliance is switched off in order to pre-
vent a potential electric shock.
▶Also unplug the appliance from the mains
or switch off the circuit breaker in the fuse
box.

en Preventing material damage
4
2 Preventing material damage
2.1 General
ATTENTION!
Objects on the cooking compartment floor at over
50°C will cause heat to build up. The baking and
roasting times will no longer be correct and the enamel
will be damaged.
▶Do not place any accessories, greaseproof paper or
foil of any kind on the cooking compartment floor.
▶Only place cookware on the cooking compartment
floor if a temperature above 50°C has been set.
When the cooking compartment is hot, any water in-
side it will create steam. The change in temperature
may cause damage.
▶Never pour water into the cooking compartment
when it is still hot.
▶Never place cookware containing water on the
cooking compartment floor.
The prolonged presence of moisture in the cooking
compartment leads to corrosion.
▶Allow the cooking compartment to dry after use.
▶Do not keep moist food in the cooking compartment
for a long time with the door closed.
▶Do not store food in the cooking compartment.
Leaving the appliance to cool down with the door open
will damage the front of neighbouring kitchen units over
time.
▶Always allow the cooking compartment to cool
down with the door closed after cooking at high
temperatures.
▶Take care not to trap anything in the appliance
door.
▶Only leave the cooking compartment to dry with the
door open if a lot of moisture was produced during
operation.
Fruit juice dripping from the baking tray leaves stains
that cannot be removed.
▶When baking very juicy fruit flans, do not pack too
much on the baking tray.
▶If possible, use the deeper universal pan.
Using oven cleaner in a hot cooking compartment
damages the enamel.
▶Never use oven cleaner in the cooking compartment
when it is still warm.
▶Remove all food remnants from the cooking com-
partment and the appliance door before you next
heat up the appliance.
If the seal is very dirty, the appliance door will no
longer close properly during operation. This may dam-
age the front of adjacent kitchen units.
▶Keep the seal clean at all times.
▶Never operate the appliance if the seal is damaged
or missing.
Sitting or placing objects on the appliance door may
damage it.
▶Do not place, hang or support objects on the appli-
ance door.
▶Do not place cookware or accessories on the appli-
ance door.
3 Environmental protection and saving energy
3.1 Disposing of packaging
The packaging materials are environmentally compat-
ible and can be recycled.
▶Sort the individual components by type and dispose
of them separately.
3.2 Saving energy
If you follow these instructions, your appliance will use
less power.
Only preheat the appliance if the recipe or the recom-
mended settings tell you to do so.
¡Not preheating the appliance can reduce the en-
ergy used by up to 20%.
Use dark-coloured, black-coated or enamelled baking
tins.
¡These types of baking tin absorb the heat particu-
larly well.
Open the appliance door as little as possible during
operation.
¡This maintains the temperature in the cooking com-
partment and eliminates the need for the appliance
to reheat.
When baking multiple dishes, do so in succession or
in parallel.
¡The cooking compartment is heated after baking
the first dish. This reduces the baking time for the
second cake.
If the cooking time is relatively long, you can switch
the appliance off 10minutes before the cooking time
ends.
¡There will be enough residual heat to finish cooking
the dish.
Remove any accessories that are not being used from
the cooking compartment.
¡Accessories that are not being used do not need to
be heated.

Environmental protection and saving energy en
5
Allow frozen food to defrost before cooking.
¡This saves the energy that would otherwise be re-
quired to defrost it.

en Familiarising yourself with your appliance
6
4 Familiarising yourself with your appliance
4.1 Control panels
You can use the control panel to configure all functions
of your appliance and to obtain information about the
operating status.
Controls
You can use the controls to configure all functions of
your appliance and to obtain information about the op-
erating status.
On certain models, specific details such as colour and
shape may differ from those pictured.
1
2 3
1
Buttons and display
The buttons are touch-sensitive surfaces. To se-
lect a function, simply press lightly on the relev-
ant field.
The display shows symbols for active functions
and the time-setting options.
→"Buttons and display", Page6
2
Function selector
Use the function selector to set the types of
heating and other functions.
You can turn the function selector clockwise or
anti-clockwise from the zero setting.
Depending on the appliance, the function se-
lector can be pushed in. Press on the function
selector to click it into or out of the zero set-
ting.
→"Types of heating and functions", Page6
3
Temperature selector
Use the temperature selector to set the temper-
ature for the type of heating and select settings
for other functions.
You can only turn the temperature selector
clockwise from the zero setting until it offers
resistance. You cannot turn it any further than
this.
Depending on the appliance, the temperature
selector can be pushed in. Press on the tem-
perature selector to click it into or out of the
zero setting.
→"Temperature and setting levels", Page7
Buttons and display
You can use the buttons to set various functions for your appliance. The display shows the settings.
If a function is active, the corresponding symbol lights up on the display. ⁠ only lights up when you change the time.
Symbol Function Use
Childproof lock Activate or deactivate the childproof lock.
Time-setting options Select the time ⁠, timer ⁠, cooking time ⁠ and the end time ⁠.
To select the individual time-setting options, press ⁠several times.
The red bar above or below the respective symbol indicates the
function to which the setting in the display corresponds.
Weight Select a weight for the programmes.
⁠
⁠
Minus
Plus
Decrease the setting values.
Increase the setting values.
Types of heating and functions
To ensure that you always find the right type of heating to cook your food, we explain the differences and applica-
tions below.
Symbol Type of heating What it's used for and how it works
3Dhot air Bake or roast on one or more levels.
The fan distributes the heat from the ring-shaped heating element in the back
wall evenly around the cooking compartment.

Familiarising yourself with your appliance en
7
Symbol Type of heating What it's used for and how it works
Hot air gentle Cook selected dishes gently on one level without preheating.
The fan distributes the heat from the ring-shaped heating element in the back
wall evenly around the cooking compartment. The food is cooked in phases us-
ing residual heat.
Select a temperature between 120°C and 230°C.
Always keep the appliance door closed when cooking.
This type of heating is used to determine the energy consumption in air recircu-
lation mode and the energy efficiency class.
Pizza setting Cook pizza or food that requires a lot of heat from below.
The bottom heating element and the ring-shaped heating element in the back
wall heat the cooking compartment.
Bottom heating Final baking or cooking food in a bain marie.
The heat is emitted from below.
Full-surface grill Grill flat items such as steak, sausages, or toast. Gratinate food.
The entire area below the grill element becomes hot.
Hot air grilling Roast poultry, whole fish or large pieces of meat.
The grill element and the fan switch on and off alternately. The fan circulates the
hot air around the food.
Top/bottom heating Traditionally bake or roast on one level. This type of heating is especially suit-
able for cakes with moist toppings.
The heat is emitted evenly from above and below.
This type of heating is used to determine the energy consumption in the conven-
tional mode.
Steam-assisted cook-
ing
Steam-assisted baking on one level.
Additional functions
Here, you can find an overview of other functions of your appliance.
Symbol Function Use
Rapid heating Rapidly preheat the cooking compartment without accessories.
→"Rapid heating", Page10
Programmes Use programmed setting values for various types of food.
→"Programmes", Page13
Cleaning assistant for
wet-cleaning
Set the cleaning function in order to make it easier to clean the cooking area.
→"Cleaning assistant for wet-cleaning", Page16
Oven light Light up the cooking compartment without heating.
→"Lighting", Page8
Temperature and setting levels
There are different settings for the types of heating and functions.
Note:For temperature settings above 250°C, the appliance reduces the temperature to approx. 240°C after ap-
prox. 10minutes. If your appliance has the top/bottom heating or bottom heating types, this temperature reduction
does not take place.
Symbol Function Use
⁠ Zero setting The appliance does not heat up.
50–275 Temperature range Set the temperature in the cooking compartment in°C.
1, 2, 3
or
I, II, III
Grill settings Depending on the appliance type, set the grill settings for the grill, for the large
area and grill, or for the small area.
1 = low
2 = medium
3 = high
⁠ Programmes Set the programme function.
⁠ Cleaning assistant for
wet-cleaning
Set the cleaning function.

en Familiarising yourself with your appliance
8
Heat-up indicator
The appliance indicates when it is heating up.
The line at the bottom of the display turns red in three
increments, from left to right, as the cooking compart-
ment heats up. When the appliance is in operation, one
of the red sections of the line goes out during the heat-
ing phases.
When you preheat the appliance, the optimal time to
place your food in the cooking compartment is as soon
as all three sections of the line have turned red.
Note:Due to thermal inertia, the temperature that is
displayed may differ slightly from the actual temperat-
ure inside the cooking compartment.
4.2 Cooking compartment
The functions in the cooking compartment make your
appliance easier to use.
Rails
The rails in the cooking compartment enable you to
place accessories at different heights.
The cooking compartment has five shelf positions. The
shelf positions are numbered from bottom to top.
You can remove the rails, e.g. for cleaning.
→"Rails", Page17
Lighting
The oven light lights up the cooking compartment.
With most types of heating and functions, the lighting
lights up during operation. If you use the function se-
lector to end the operation, the lighting switches off.
The oven light setting on the function selector can be
used to switch on the light without heating.
Appliance door
If you open the appliance door during operation, the
operation continues.
Cooling fan
The cooling fan switches on and off depending on the
appliance's temperature. The hot air escapes above
the door.
ATTENTION!
Do not cover the ventilation slot above the appliance
door. The appliance overheats.
▶Ensure that the ventilation slots are unobstructed.
To ensure that the appliance cools down more quickly
after operation, the cooling fan continues to run for a
certain period afterwards.
Condensation
Condensation can occur in the cooking compartment
and on the appliance door when cooking. Condensa-
tion is normal and does not adversely affect appliance
operation. Wipe away the condensation after cooking.
4.3 Accessories
Use original accessories. These have been made espe-
cially for your appliance.
Note:Heat may deform the accessory. This deforma-
tion has no effect on the function. When the accessory
cools down, it will regain its original shape.
The accessories supplied may differ depending on the
appliance model.

Familiarising yourself with your appliance en
9
Accessories Use
Wire rack ¡Baking tins
¡Ovenproof dishes
¡Cookware
¡Meat, e.g. roasting joints or steak
¡Frozen meals
Universal pan ¡Moist cakes
¡Biscuits
¡Bread
¡Large roasts
¡Frozen meals
¡Catching dripping liquids, e.g. fat when
grilling food on the wire rack.
Narrow universal pans ¡Moist cakes
¡Biscuits
¡Frozen meals
Slide the narrow universal pans into the
cooking compartment individually or at the
same time as shown in the image. Do not
place them on the wire rack.
Using the accessory
Always slide the accessory into the cooking compart-
ment correctly. This is the only way that you can re-
move the accessory halfway without it tipping.
1. Insert the accessory between the two guide rods for
a shelf position.
Wire rack Insert the wire rack with the open
side facing the appliance door and
the curved lip ⁠ facing downwards.
Baking tray
E.g. univer-
sal pan or
baking tray
Slide the tray in with the sloping
edgefacing the appliance door.
2. To place the accessory at the shelf positions with
the pull-out rails, pull out the pull-out rails.
Wire rack
or baking
tray
Position the accessory so that its
edge is behind the lug ⁠ on the pull-
out rail.
Narrow uni-
versal pans
Hook the front narrow universal pan
into the lug.
Do not place narrow universal pans
onto the pull-out rails.
Note:The pull-out rails lock in place when they are
fully pulled out. Gently push the pull-out rails back
into the cooking compartment.
3. Slide the accessory all the way in, making sure that
the accessory does not touch the appliance door.
Note:Take any accessories that you will not be using
out of the cooking compartment while the appliance is
in operation.
Other accessories
You can purchase other accessories from our after-
sales service, specialist retailers or online.
You will find a comprehensive range of products for
your appliance in our brochures and online:
www.bosch-home.com
Accessories vary from one appliance to another. When
purchasing accessories, always quote the exact
product number (E no.) of your appliance.
You can find out which accessories are available for
your appliance in our online shop or from our after-
sales service.

en Before using for the first time
10
5 Before using for the first time
Configure the settings for initial start-up. Clean the ap-
pliance and accessories.
5.1 Initial configuration
You have to implement settings for the initial configura-
tion before you can use your appliance.
5.2 Cleaning the appliance before using it
for the first time
Clean the cooking compartment and accessories be-
fore using the appliance to prepare food for the first
time.
1. Remove the accessory and the leftover packaging,
such as polystyrene pellets, from the cooking com-
partment.
2. Before heating, wipe the smooth surfaces in the
cooking compartment with a soft, damp cloth.
3. Ventilate the room while the appliance is heating.
4. Set the type of heating and the temperature.
→"Basic operation", Page10
Type of heat-
ing
3D hot air ⁠
Temperature Maximum
Cooking time 1hour
5. Switch off the appliance after the specified cooking
time.
6. Wait until the cooking compartment has cooled
down.
7. Clean the smooth surfaces with soapy water and a
dish cloth.
8. Clean the accessory with soapy water and a dish
cloth or a soft brush.
6 Basic operation
6.1 Switching on the appliance
▶Turn the function selector to any position other than
the "Off" position ⁠.
aThe appliance is switched on.
6.2 Switching off the appliance
▶Turn the function selector to the "Off" position ⁠.
aThe appliance is switched off.
6.3 Types of heating and temperature
1. Use the function selector to set the type of heating.
2. Use the temperature selector to set the temperature
or grill setting.
aThe appliance starts heating after a few seconds.
3. When the dish is ready, switch off the appliance.
Tips
¡The most suitable type of heating for your food can
be found in the description of the types of heating.
¡You can also set a cooking time and an end time
on the appliance.
→"Time-setting options", Page11
Changing the type of heating
You can change the type of heating at any time.
▶Use the function selector to set the required type of
heating.
Changing the temperature
You can change the temperature at any time.
▶Turn the temperature selector to set the desired
temperature.
7 Rapid heating
To save time, you can use the rapid heating to shorten
the preheat time.
Only use rapid heat-up when a temperature of over
100°C has been set.
After rapid heating, it is best to use the following types
of heating:
¡3D hot air ⁠
¡Top/bottom heating ⁠
7.1 Setting rapid heating
To ensure an even cooking result, do not place the
food in the cooking compartment until rapid heating
has come to an end.
1. Use the function selector to select rapid heating ⁠.
2. Use the temperature selector to set the required
temperature.
aRapid heating starts after a few seconds.
aWhen the rapid heating process ends, an audible
signal sounds and the heating indicator goes out.
3. Use the function selector to set a suitable type of
heating.
4. Place the food in the cooking compartment.

Time-setting options en
11
8 Time-setting options
Your appliance has different time-setting options which
ensure that operation can be controlled.
8.1 Overview of the time-setting options
You can use the ⁠ button to select the different time-
setting options.
Time-setting
option
Use
Timer ⁠ The timer can be set independently
of the operation. It does not affect
the appliance.
Cooking time
⁠
If a cooking time has been set for
the operation, the appliance stops
heating automatically once this time
has elapsed.
End ⁠ A time at which the operation ends
can be set for the cooking time. The
appliance starts up automatically so
that it finishes cooking at the re-
quired time.
Time ⁠ Set the time.
8.2 Setting the timer
The timer runs independently of the appliance when it
is in operation. The timer can be set up to 23 hours
and 59 minutes regardless of whether the appliance is
on or off. The timer has its own audible signal so that
you can tell whether it is the timer or a cooking time
which has elapsed.
1. Press ⁠ repeatedly until ⁠ is selected in the display.
2. Use the ⁠ or ⁠button to set the timer duration.
Button Recommended value
⁠ 5 minutes
⁠ 10 minutes
Up to 10 minutes, the timer duration can be set in
30-second increments. The time increments be-
come bigger as the value increases.
aThe timer starts and the timer duration begins to
count down after a few seconds.
aAn audible signal sounds and the timer duration is
zero in the display when the timer duration has
elapsed.
3. Once the timer duration has elapsed
‒Press any button to switch off the timer.
Changing the timer
The timer duration can be changed at any time.
Requirement: ⁠ is highlighted in the display.
▶Use the ⁠ or ⁠ button to change the timer duration.
aThe appliance applies the change after a few
seconds.
Cancelling the timer
The timer duration can be cancelled at any time.
Requirement: ⁠ is highlighted in the display.
▶Use the ⁠ button to reset the timer duration to zero.
aAfter a few seconds, the appliance applies the
change and ⁠ goes out.
8.3 Setting the cooking time
The cooking time can be set to up to 23 hours and 59
minutes for the operation.
Requirement:The type of heating and temperature or
setting have been set.
1. Press ⁠ repeatedly until ⁠ is selected in the display.
2. Use the ⁠ or ⁠ button to set the cooking time.
Additional
pro-
gramme
Recommended value
⁠ 10 minutes
⁠ 30 minutes
The cooking time can be set in one-minute incre-
ments up to one hour, and then in five-minute incre-
ments.
aAfter a few seconds, the appliance starts heating
and the cooking time counts down.
aWhen the cooking time has elapsed, a signal
sounds and the duration is at zero in the display.
3. When the cooking time has elapsed:
‒Press any button to end the signal prematurely.
‒To set another cooking time, press the ⁠button.
‒When the dish is ready, switch off the appliance.
Changing the cooking time
The cooking time can be changed at any time.
Requirement: ⁠ is highlighted in the display.
▶Change the cooking time using the ⁠ or ⁠ button.
aThe appliance applies the change after a few
seconds.
Cancelling the cooking time
The cooking time can be cancelled at any time.
Requirement: ⁠ is highlighted in the display.
▶Reset the cooking time to zero using the ⁠ button.
aAfter a few seconds, the appliance applies the
change and continues to heat without a cooking
time.
8.4 Setting the end time
You can delay the time at which the cooking time is
due to end by up to 23 hours and 59 minutes.
Notes
¡The end time cannot be set for types of heating with
grill function.
¡In order to achieve a good cooking result, do not
delay the end time once the appliance is already op-
erating.
¡Food will spoil if you leave it in the cooking com-
partment for too long.

en Steam-assisted cooking
12
Requirements
¡The type of heating and temperature or setting have
been set.
¡A cooking time must be set.
1. Press ⁠ repeatedly until ⁠ is selected in the dis-
play.
2. Press the ⁠ or ⁠button.
aThe display shows the calculated end time.
3. Use the ⁠ or ⁠button to delay the end time.
aAfter a few seconds, the appliance applies the set-
ting and the display shows the set end time.
aOnce the calculated start time has been reached,
the appliance starts heating up and the cooking
time starts counting down.
aWhen the cooking time has elapsed, a signal
sounds and the duration is at zero in the display.
4. When the cooking time has elapsed:
‒Press any button to end the signal prematurely.
‒To set another cooking time, press the ⁠button.
‒When the dish is ready, switch off the appliance.
Changing the end time
In order to achieve a good cooking result, you can only
change the set end time before operation starts and
the cooking time starts counting down.
Requirement: ⁠ is highlighted in the display.
▶Use the ⁠ or ⁠button to delay the end time.
aThe appliance applies the change after a few
seconds.
Cancelling the end time
You can delete the set end time at any time.
Requirement: ⁠ is highlighted in the display.
▶Reset the end time to the current time plus the set
cooking time using the ⁠ button.
aAfter a few seconds, the appliance applies the
change and starts heating up. The cooking time
counts down.
8.5 Setting the time
Once the appliance has been connected to the mains
or after a power cut, the time flashes in the display. The
time starts at "12:00". Set the current time.
Requirement:The function selector must be set to the
off ⁠ position.
1. Use ⁠or ⁠ to set the time.
2. Press ⁠.
aThe time that is set appears in the display.
Tip:You can define whether the time is shown in the
display in the basic settings.
9 Steam-assisted cooking
You can cook food with steam assistance.
When you cook with steam assistance, steam is gener-
ated in the cooking compartment. This gives you a bet-
ter cooking result.
9.1 Setting steam-assisted cooking
1. Fill the water tank. The recommended volume of wa-
ter for cooking is specified. Use the specifications in
the table.
→"Steam-assisted cooking", Page35
150 ml
100 ml
200 ml
2. Insert the water tank into the slot in the appliance.
3. ATTENTION!
Using unsuitable liquids may damage the appliance.
▶Use only drinking water at room temperature. Do
not use tap water.
▶The water tank must only be topped up before
cooking, when the appliance is cold. Water must
not be added to the tank during cooking.
▶Only use the water tank that is supplied with the
appliance. Only use the water tank for steam-as-
sisted cooking. Remove the water tank from the
appliance when using other functions.
WARNING‒Risk of fire!
The vapours from flammable liquids may catch fire
due to the hot surfaces in the cooking compartment
and may cause an explosion. The appliance cover
may open automatically. Hot steam and jets of
flame may escape.
▶Do not fill the water tank with any flammable flu-
ids (e.g. alcoholic drinks).

Programmes en
13
4. Use the function selector to set ⁠.
aThe warning lamp lights up on the front panel.
5. Use the temperature selector to set the temperature.
aThe appliance starts.
9.2 Switching off the appliance
▶Turn the function and temperature selector to the off
position.
aThe appliance is switched off.
9.3 After using the steam function
WARNING‒Risk of scalding!
Hot steam may escape when you open the appliance
door. Steam may not be visible, depending on the tem-
perature.
▶Open the appliance door carefully.
▶Keep children at a safe distance.
WARNING‒Risk of burns!
The appliance becomes hot during operation.
▶Allow the appliance to cool down before cleaning.
WARNING‒Risk of fire!
The water tank may heat up while the appliance is in
operation.
▶Leave the water tank to cool down before emptying
it.
Note:After every steam operation, clean the water tank
with hot, soapy water and a soft sponge, and dry it with
a soft cloth. The water tank can be cleaned in the dish-
washer.
1. Depending on the usage frequency and the water
hardness, limescale stains may be left in the water
tank. For tough limescale stains, dissolve 5 g so-
dium citrate in 200 ml lukewarm water, and pour
this into the container. Wash this off after a while
and wipe it with a soft cloth.
2. Do not use any hard objects (e.g. steel wool) to re-
move limescale stains from the water tank.
10 Programmes
The programmes help you to use your appliance to
prepare different dishes by selecting the optimum set-
tings automatically.
10.1 Suitable cookware for programmes
You should therefore use heat-resistant cookware that
is suitable for temperatures up to 300°C.
Glass or glass ceramic cookware is best. The joint
should cover approx. two thirds of the cookware base.
Cookware made from the following material is not
suitable:
¡Bright, shiny aluminium
¡Unglazed clay
¡Plastic or plastic wire rack
10.2 Programme table
The programme numbers are assigned to specific foods.
You can set the weight in the range of 0.5kg and 2.5kg.
No. Meal Cookware Adjustment
weight
Add liquid Shelf
posi-
tion
Information
01 Chicken, unstuffed
Ready to cook,
seasoned
Roasting dish with
glass lid
Chicken weight No 2 Place in the cook-
ware with the breast
facing up.
02 Turkey breast
Whole, seasoned
Roasting dish with
glass lid
Turkey breast
weight
Cover the
bottom of the
roasting dish,
and add up
to 250g ve-
getables, if
required.
2 Do not sear the meat
beforehand.
03 Vegetable stew
Vegetarian
Deep roasting dish
with lid
Total weight As per recipe 2 Cut vegetables that
take longer to cook
(e.g. carrots) into
smaller pieces than
vegetables that take
less time to cook
(e.g. tomatoes).

en Programmes
14
No. Meal Cookware Adjustment
weight
Add liquid Shelf
posi-
tion
Information
04 Goulash
Diced beef or pork,
with vegetables
Deep roasting dish
with lid
Total weight As per recipe 2 Place the meat at the
bottom and cover
with vegetables.
Do not sear the meat
beforehand.
05 Meat loaf, fresh
Minced beef, pork or
lamb
Roasting dish with
lid
Roast weight No 2 -
06 Pot-roasted beef
E.g. prime rib,
shoulder, rump or mar-
inated beef roast
Roasting dish with
lid
Weight of meat Almost cover
the meat with
liquid.
2 Do not sear the meat
beforehand.
07 Beef roulades
Stuffed with vegetables
or meat
Roasting dish with
lid
Total weight of all
the stuffed roul-
ades
Roulades,
e.g. with
stock or wa-
ter
2 Do not sear the meat
beforehand.
08 Leg of lamb, well
done
Boned, seasoned
Roasting dish with
lid
Weight of meat Cover the
bottom of the
roasting dish,
and add up
to 250g ve-
getables, if
required.
2 Do not sear the meat
beforehand.
09 Joint of veal, lean
E.g. tenderloin or eye
Roasting dish with
lid
Weight of meat Cover the
bottom of the
roasting dish,
and add up
to 250g ve-
getables, if
required.
2 Do not sear the meat
beforehand.
10 Pork neck joint
Boned, seasoned
Roasting dish with
glass lid
Weight of meat Cover the
bottom of the
roasting dish,
and add up
to 250g ve-
getables, if
required.
2 Do not sear the meat
beforehand.
10.3 Preparing food for the programme
Use fresh and, ideally, chilled food.
1. Weigh the food.
The weight of the food is required in order to cor-
rectly set the programme.
2. Add the food to the cookware.
3. Place the cookware onto the wire rack.
Always place the ovenware into the cooking com-
partment without preheating it.
10.4 Setting a programme
The appliance selects the optimal type of heating, tem-
perature and cooking time. All you need to do is set
the weight.
Notes
¡You can set the weight only in the intended range.
¡After the programme starts, you can no longer
change the programme and the weight.
1. Use the function selector to set ⁠.
2. Use the temperature selector to set ⁠.
3. Use ⁠or ⁠ to set the required programme.
4. Press ⁠.
5. Use ⁠or ⁠ to set the weight of your food. Always
set the next higher weight.
‒The display shows the calculated cooking time.
You cannot change the cooking time.
‒On some programmes, you can delay the end
time using ⁠.
→"Setting the end time", Page11
‒To change the programme, press ⁠.
aAfter a few seconds, the programme starts and the
cooking time counts down.
aIf the programme has ended, an audible signal
sounds and the display shows the cooking time as
zero.
6. When the programme ends:
‒Press any button to end the signal prematurely.
‒To set a cooking time for further cooking,
press ⁠. The appliance will resume heating us-
ing the programme settings.
‒When the dish is ready, switch off the appliance.

Childproof lock en
15
11 Childproof lock
Secure the appliance to prevent children from accident-
ally switching it on or changing the settings.
Notes
¡The option to set the childproof lock can be activ-
ated in the Basic settings .
¡After a power cut, the childproof lock will no longer
be active.
11.1 Activating and deactivating the
childproof lock
Requirement:The function selector must be set to the
off ⁠ position.
▶To activate the childproof lock, press and hold the
⁠button until ⁠appears in the display.
‒To deactivate the childproof lock, press and hold
the ⁠button until ⁠goes out in the display.
12 Basic settings
You can configure the appliance to meet your needs.
12.1 Overview of the basic settings
Here you can find an overview of the basic settings and factory settings. The basic settings depend on the features
of your appliance.
Display Basic setting Selection
⁠ ⁠ Clock display ⁠ = hide the time
⁠ = display the time1
⁠ ⁠ Signal duration upon completion of a
cooking time or timer period
⁠ = 10 seconds
⁠ = 30 seconds1
⁠ = 2 minutes
⁠ ⁠ Acoustic signal when a button is
pressed
⁠ = off
⁠ = on1
⁠ ⁠ Cooling fan run-on time ⁠ = short
⁠ = medium
⁠ = long1
⁠ = extra long
⁠ ⁠ Waiting time until a setting is adop-
ted
⁠ = 3 seconds1
⁠ = 6 seconds
⁠ = 10 seconds
⁠ ⁠ Childproof lock can be adjusted
→"Childproof lock", Page15
⁠ = no
⁠ = yes 1
1Factory setting (may vary according to model)
12.2 Changing basic settings
Requirement:The appliance is switched off.
1. Press and hold the ⁠button for approx.
fourseconds.
aThe first basic setting appears in the display,
e.g. ⁠ ⁠ ⁠.
2. Use the ⁠ or ⁠button to change the setting.
3. Use the ⁠button to switch to the next basic setting.
4. To save the changes, press and hold ⁠ for approx.
fourseconds.
Note:Following a power failure, the factory basic set-
tings are restored.
12.3 Discarding changes to the basic
settings
▶Turn the function selector.
aAll changes are discarded and not saved.

en Cleaning and servicing
16
13 Cleaning and servicing
To keep your appliance working efficiently for a long
time, it is important to clean and maintain it carefully.
13.1 Cleaning agent
To avoid damaging the different surfaces of the appli-
ance, do not use unsuitable cleaning agents.
ATTENTION!
Unsuitable cleaning agents damage the surfaces of the
appliance.
▶Do not use aggressive or abrasive cleaning agents.
▶Do not use cleaning products with a high alcohol
content.
▶Do not use hard scouring pads or cleaning
sponges.
▶Do not use any special cleaners if the appliance is
still warm.
Using oven cleaner in a hot cooking compartment
damages the enamel.
▶Do not use oven cleaner in the cooking compart-
ment when it is still warm.
▶Remove all food remnants from the cooking com-
partment and the appliance door before you next
heat up the appliance.
New sponge cloths contain residues from production.
▶Wash new sponge cloths thoroughly before use.
13.2 Cleaning the appliance
In order to avoid damaging the appliance, clean your
appliance only as specified, and using suitable clean-
ing products.
WARNING‒Risk of burns!
The appliance and its parts that can be touched be-
come hot during use.
▶Caution should be exercised here in order to avoid
touching heating elements.
▶Young children under 8 years of age must be kept
away from the appliance.
WARNING‒Risk of fire!
Loose food remnants, fat and meat juices may catch
fire.
▶Before using the appliance, remove the worst of the
food residues and remnants from the cooking com-
partment, heating elements and accessories.
Requirement:Read the information on cleaning
agents.
→"Cleaning agent", Page16
1. Clean the appliance using hot soapy water and a
dish cloth.
‒For some surfaces, you can use alternative
cleaning agents.
2. Dry with a soft cloth.
14 Cleaning assistant for wet-cleaning
The cleaning assistant is a fast alternative for occasion-
ally cleaning the cooking compartment. The cleaning
assistant softens dirt by evaporating soapy water. This
means that dirt can be removed more easily.
14.1 Setting the cleaning assistant
WARNING‒Risk of scalding!
If there is water in the cooking compartment when it is
hot, this may create hot steam.
▶Never pour water into the cooking compartment
when the cooking compartment is hot.
Requirement:The cooking compartment must be
cooled down completely.
1. Remove the accessories from the cooking compart-
ment.
2. Add one drop of detergent to 0.4l water and pour it
onto the centre of the cooking compartment floor.
Do not use distilled water.
3. Use the function and temperature selector to set the
⁠ function.
aAfter a few seconds, the appliance starts heating
and the duration counts down.
aWhen the cooking time has counted down, a signal
sounds and the duration is at zero in the display.
4. Note:The duration is preset and cannot be
changed.
The end time cannot be delayed.
If the cooking compartment is not completely
cooled down, ⁠ flashes in the display panel.
14.2 Cleaning the cooking compartment
after using it
ATTENTION!
If the cooking compartment remains damp for too long,
this results in corrosion.
▶After using the cleaning aid, wipe the cooking com-
partment and allow it to dry completely.
Requirement:The cooking compartment has cooled
down.
1. Open the appliance door and absorb the residual
water with an absorbent sponge cloth.
2. Clean smooth surfaces in the cooking compartment
with a dish cloth or a soft brush. Remove stubborn
residues with a stainless steel spiral scourer.
3. Remove limescale deposits using a vinegar-soaked
cloth. Wipe this away with clear water and use a soft
cloth to also rub underneath the door seal dry.
4. Once the cooking compartment is sufficiently clean:
‒In order to cool the cooking compartment, leave
the appliance door open in the detent position
for approx.one hour.
‒To dry the cooking compartment more quickly,
heat up the appliance with the door open with 3D
hot air ⁠ and 50°C for approx.five minutes.

Rails en
17
15 Rails
To clean the rails and cooking compartment thor-
oughly, you can remove the shelf supports.
15.1 Unhooking the rails
WARNING‒Risk of burns!
The rails can be very hot.
▶Never touch the rails when they are hot.
▶Allow the appliance to cool down.
▶Keep children at a safe distance.
1. Lift the front rail upwards and unhook it.
2. Then push the entire rail to the front and remove it.
15.2 Attaching the rails
1. First insert the rail into the rear socket, press it to
the back slightly
2. and insert it into the socket at the front.
The rails fit both on the left and right sides. Shelf po-
sitions 1 and 2 are located at the bottom and shelf
positions 3, 4 and 5 are located at the top. Pull out
the telescopic rail towards the front.
16 Appliance door
It is normally sufficient if you clean the outside of the
appliance door. If the appliance door is very dirty on
the inside and outside, you can remove the appliance
door and clean it.
16.1 Door hinges
WARNING‒Risk of injury!
When the hinges are not secured, they can snap shut
with great force.
▶If you open the appliance door, ensure that the lock-
ing levers are fully open or fully closed.
1. The oven door hinges each have a locking lever.
When the locking levers are closed, the oven door
is secured in place.
It cannot be detached.

en Appliance door
18
2. When the locking levers are open in order to detach
the oven door, the hinges are secured.
The hinges cannot snap shut.
16.2 Removing the appliance door
1. Open the oven door fully.
2. Open the locking levers on the left- and right-hand
hinges.
3. Close the oven door as far as the limit stop. Grip
the left and right hand sides of the door with both
hands. Close the door slightly more and remove it.
16.3 Removing the door panes
The glass panes of the oven door can be removed to
make cleaning easier.
WARNING‒Risk of injury!
Scratched glass in the appliance door may develop
into a crack.
▶Do not use any harsh or abrasive cleaners or sharp
metal scrapers to clean the glass on the oven door,
as they may scratch the surface.
The components in the appliance door may have sharp
edges.
▶Wear gloves.
1. Detach the oven door.
→"Removing the appliance door", Page18
2. Position it on a cloth with its handle pointing down-
wards.
3. To remove the upper cover of the oven door, press
in the tabs on the left and right using your fingers.
Pull out and remove the cover.
4. Lift the top pane up and out.
5. Lift the panel up and out.

Appliance door en
19
16.4 Fitting the door panes
When fitting the panes, ensure that the lettering "top
right" is not upside down at the bottom left.
1. Insert the pane diagonally towards the back.
2. Hold the top pane in both brackets and insert it at
an angle towards the back.
Push the pane into both openings on the underside.
The smooth surface of the pane must face out-
wards.
3. Place the cover at the top of the oven door and
press it on.
The mounting brackets must lock in place on both
sides.
4. Attach the oven door.
→"Attaching the appliance door", Page19
Note:Only use the oven once the glass panes have
been correctly fitted.
16.5 Attaching the appliance door
Reattach the oven door in the reverse sequence to re-
moval.
WARNING‒Risk of injury!
The oven door might accidentally fall or a hinge may
suddenly snap shut.
▶In this case, do not hold onto the hinge. Call cus-
tomer service.
1. When attaching the oven door, ensure that both
hinges are inserted in the opening direction.
2. The notch on the hinge must engage on both sides.
3. Close both locking levers again.
4. Close the appliance door.
16.6 Additional door safety
Additional safety devices have been fitted to prevent
contact with the oven doors. Always attach these safety
devices when children could come near the oven. You
can purchase this special accessory from after-sales
service. 11023590
WARNING‒Risk of burns!
During long cooking times, the oven door may become
very hot.
▶Supervise small children when the oven is in opera-
tion.

en Troubleshooting
20
17 Troubleshooting
You can rectify minor faults on your appliance yourself.
Read the troubleshooting information before contacting
after-sales service. This will avoid unnecessary costs.
WARNING‒Risk of injury!
Improper repairs are dangerous.
▶Repairs to the appliance should only be carried out
by trained specialist staff.
▶If the appliance is defective, call Customer Service.
17.1 Malfunctions
Fault Cause and troubleshooting
The appliance is not
working.
The mains plug of the power cord is not plugged in.
▶Connect the appliance to the power supply.
The circuit breaker in the fuse box has tripped.
▶Check the circuit breaker in the fuse box.
There has been a power cut.
▶Check whether the lighting in your kitchen or other appliances are working.
The appliance does
not switch off fully at
the end of a cooking
time.
At the end of a cooking time, the appliance stops heating up. The oven light and cooling fan
do not switch off. For types of heating with air recirculation, the fan continues to run in the
back wall of the cooking compartment.
▶Turn the function selector to the off position.
aThe appliance is switched off.
aThe oven light and the fan in the back wall are switched off.
aThe cooling fan switches off automatically as soon as the appliance has cooled down.
The time flashes in
the display.
There has been a power cut.
▶Reset the time.
→"Setting the time", Page12
The time does not ap-
pear in the display
when the appliance is
switched off.
The basic setting has been changed.
▶Change the basic setting for the time display.
⁠ lights up in the dis-
play and no settings
can be made on the
appliance.
Childproof lock is activated.
▶Use the ⁠button to deactivate the childproof lock.
A message with ⁠
appears in the dis-
play, e.g. ⁠ ⁠ ⁠- ⁠ ⁠.
Electronics fault
1. Press ⁠.
‒If necessary, reset the time on the clock.
aIf the fault was a one-off, the error message disappears.
2. If the error message appears again, call the after-sales service. State the exact error
message and the E no. for your appliance in full.
→"Customer Service", Page21
Replacing the oven light bulb
If the light in the cooking compartment fails, change
the oven light bulb.
Note:Heat-resistant, 25-watt, 230V halogen bulbs are
available from the after-sales service or specialist retail-
ers. Only use these bulbs. Hold the new halogen bulbs
only with a clean, dry towel. This increases the service
life of the bulb.
WARNING‒Risk of burns!
The appliance and its parts that can be
touched become hot during use.
▶Caution should be exercised here in order to
avoid touching heating elements.
▶Young children under 8 years of age must be
kept away from the appliance.
