[en] Instruction manual
Double oven
MBS533B.0B

en
3
Table of contents
[en]Inst ructi on manual
8Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
(Important safety information . . . . . . . . . . . . . . . 4
General information . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Halogen lamp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
]Causes of damage . . . . . . . . . . . . . . . . . . . . . . . . 6
General information . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
7Environmental protection . . . . . . . . . . . . . . . . . . 6
Saving energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Environmentally-friendly disposal . . . . . . . . . . . . . . . . . 7
*Getting to know your appliance . . . . . . . . . . . . . 8
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Buttons and display . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Types of heating and functions . . . . . . . . . . . . . . . . . . 9
Temperature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Cooking compartment . . . . . . . . . . . . . . . . . . . . . . . . 10
_Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Control accessories . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Inserting accessories . . . . . . . . . . . . . . . . . . . . . . . . . 11
Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . 12
KBefore using for the first time. . . . . . . . . . . . . . 13
Initial use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Cleaning the cooking compartment and accessories 13
1Operating the appliance . . . . . . . . . . . . . . . . . . 13
Switching the appliance on and off . . . . . . . . . . . . . . 13
Setting the heating function and temperature . . . . . . 13
Rapid heating. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
OTime-setting options . . . . . . . . . . . . . . . . . . . . . 14
Setting the cooking time . . . . . . . . . . . . . . . . . . . . . . 14
Setting the end time . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Setting the timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Setting the time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
AChildproof lock. . . . . . . . . . . . . . . . . . . . . . . . . . 16
Activating and deactivating . . . . . . . . . . . . . . . . . . . . 16
DCleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Suitable cleaning agents . . . . . . . . . . . . . . . . . . . . . . 17
Surfaces in the cooking compartment . . . . . . . . . . . . 18
Keeping the appliance clean . . . . . . . . . . . . . . . . . . . 18
pRails. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Detaching and refitting the rails . . . . . . . . . . . . . . . . . 19
Detaching and refitting the rails . . . . . . . . . . . . . . . . . 19
qAppliance door . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Main oven – Fitting and removing the glass panels . .20
Top oven – Fitting and removing the glass panels. . .21
3Trouble shooting . . . . . . . . . . . . . . . . . . . . . . . . 23
Rectifying faults yourself . . . . . . . . . . . . . . . . . . . . . . .23
Replacing the bulb in the top of the cooking
compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
4Customer service . . . . . . . . . . . . . . . . . . . . . . . . 24
E number and FD number . . . . . . . . . . . . . . . . . . . . .24
JTested for you in our cooking studio. . . . . . . . 25
General information . . . . . . . . . . . . . . . . . . . . . . . . . .25
Baking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Roasting, braising and grilling . . . . . . . . . . . . . . . . . .28
Ready meals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Desserts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Acrylamide in foodstuffs . . . . . . . . . . . . . . . . . . . . . . .33
Drying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Preserving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Prove dough . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Defrosting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Keeping warm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Test dishes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Produktinfo
Additional information on products, accessories,
replacement parts and services can be found at
www.bosch-home.com and in the online shop
www.bosch-eshop.com

en Intended use
4
8Intended use
Intended use Read these instructions carefully. Only then
will you be able to operate your appliance
safely and correctly. Retain the instruction
manual and installation instructions for future
use or for subsequent owners.
This appliance is only intended to be fully fitted
in a kitchen. Observe the special installation
instructions.
Check the appliance for damage after
unpacking it. Do not connect the appliance if it
has been damaged in transport.
Only a licensed professional may connect
appliances without plugs. Damage caused by
incorrect connection is not covered under
warranty.
This appliance is intended for domestic use
only. The appliance must only be used for the
preparation of food and drink. The appliance
must be supervised during operation. Only
use this appliance indoors.
This appliance is intended for use up to a
maximum height of 4000 metres above sea
level.
This appliance may be used by children over
the age of 8 years old and by persons with
reduced physical, sensory or mental
capabilities or by persons with a lack of
experience or knowledge if they are
supervised or are instructed by a person
responsible for their safety how to use the
appliance safely and have understood the
associated hazards.
Children must not play with, on, or around the
appliance. Children must not clean the
appliance or carry out general maintenance
unless they are at least 15 years old and are
being supervised.
Keep children below the age of 8 years old at
a safe distance from the appliance and power
cable.
Always slide accessories into the cooking
compartment the right way round.
~"Accessories" on page 11
(Important safety
information
Impor t ant saf et y informat i on General information
:Warning – Risk of fire!
■Combustible items stored in the cooking
compartment may catch fire. Never store
combustible items in the cooking
compartment. Never open the appliance
door if there is smoke inside. Switch off the
appliance and unplug it from the mains or
switch off the circuit breaker in the fuse box.
Risk of fire!
■Loose food remnants, fat and meat juices
may catch fire. Before using the appliance,
remove the worst of the food remnants from
the cooking compartment, heating elements
and accessories.
Risk of fire!
■A draught is created when the appliance
door is opened. Greaseproof paper may
come into contact with the heating element
and catch fire. Do not place greaseproof
paper loosely over accessories during
preheating. Always weight down the
greaseproof paper with a dish or a baking
tin. Only cover the surface required with
greaseproof paper. Greaseproof paper
must not protrude over the accessories.
:Warning – Risk of burns!
■The appliance becomes very hot. Never
touch the interior surfaces of the cooking
compartment or the heating elements.
Always allow the appliance to cool down.
Keep children at a safe distance.
Risk of serious burns!
■Accessories and ovenware become very
hot. Always use oven gloves to remove
accessories or ovenware from the cooking
compartment.
Risk of burns!
■Alcoholic vapours may catch fire in the hot
cooking compartment. Never prepare food
containing large quantities of drinks with a
high alcohol content. Only use small
quantities of drinks with a high alcohol
content. Open the appliance door with care.

Important safety information en
5
:Warning – Risk of scalding!
■The accessible parts become hot during
operation. Never touch the hot parts. Keep
children at a safe distance.
Risk of scalding!
■When you open the appliance door, hot
steam can escape. Steam may not be
visible, depending on its temperature. When
opening, do not stand too close to the
appliance. Open the appliance door
carefully. Keep children away.
Risk of scalding!
■Water in a hot cooking compartment may
create hot steam. Never pour water into the
cooking compartment when the cooking
compartment is hot.
:Warning – Risk of injury!
■Scratched glass in the appliance door may
develop into a crack. Do not use a glass
scraper, sharp or abrasive cleaning aids or
detergents.
Risk of injury!
■The hinges on the appliance door move
when opening and closing the door, and
you may be trapped. Keep your hands away
from the hinges.
:Warning – Risk of electric shock!
■Incorrect repairs are dangerous. Repairs
may only be carried out and damaged
power cables replaced by one of our
trained after-sales technicians. If the
appliance is defective, unplug the appliance
from the mains or switch off the circuit
breaker in the fuse box. Contact the after-
sales service.
Risk of electric shock and serious injury!
■The cable insulation on electrical
appliances may melt when touching hot
parts of the appliance. Never bring
electrical appliance cables into contact with
hot parts of the appliance.
Risk of electric shock!
■Do not use any high-pressure cleaners or
steam cleaners, which can result in an
electric shock.
Risk of electric shock!
■A defective appliance may cause electric
shock. Never switch on a defective
appliance. Unplug the appliance from the
mains or switch off the circuit breaker in the
fuse box. Contact the after-sales service.
:Warning – Hazard due to magnetism!
Permanent magnets are used in the control
panel or in the control elements. They may
affect electronic implants, e.g. heart
pacemakers or insulin pumps. Wearers of
electronic implants must stay at least 10 cm
away from the control panel.
Halogen lamp
:Warning – Risk of burns!
The bulbs in the cooking compartment
become very hot. There is still a risk of burning
your skin for some time after they have been
switched off. Do not touch the glass cover.
Avoid contact with your skin when cleaning.
:Warning – Risk of electric shock!
When replacing the cooking compartment
bulb, the bulb socket contacts are live. Before
replacing the bulb, unplug the appliance from
the mains or switch off the circuit breaker in
the fuse box.

en Causes of damage
6
]Causes of damage
Ca u s e s of damage General information
Caution!
■Accessories, foil, greaseproof paper or ovenware on
the cooking compartment floor: do not place
accessories on the cooking compartment floor. Do
not cover the cooking compartment floor with any
sort of foil or greaseproof paper. Do not place
ovenware on the cooking compartment floor if a
temperature of over 50 ºC has been set. This will
cause heat to accumulate. The baking and roasting
times will no longer be correct and the enamel will
be damaged.
■Aluminium foil: Aluminium foil in the cooking
compartment must not come into contact with the
door glass. This could cause permanent
discolouration of the door glass.
■Water in a hot cooking compartment: do not pour
water into the cooking compartment when it is hot.
This will cause steam. The temperature change can
cause damage to the enamel.
■Moisture in the cooking compartment: Over an
extended period of time, moisture in the cooking
compartment may lead to corrosion. Allow the
cooking compartment to dry after use. Do not keep
moist food in the closed cooking compartment for
extended periods of time. Do not store food in the
cooking compartment.
■Cooling with the appliance door open: Following
operation at high temperatures, only allow the
cooking compartment to cool down with the door
closed. Do not trap anything in the appliance door.
Even if the door is only left open a crack, the front of
nearby furniture may become damaged over time.
Only leave the cooking compartment to dry with the
door open if a lot of moisture was produced whilst
the oven was operating.
■Fruit juice: when baking particularly juicy fruit pies,
do not pack the baking tray too generously. Fruit
juice dripping from the baking tray leaves stains that
cannot be removed. If possible, use the deeper
universal pan.
■Extremely dirty seal: If the seal is very dirty, the
appliance door will no longer close properly during
operation. The fronts of adjacent units could be
damaged. Always keep the seal clean. Never
operate the appliance if the seal is damaged or
missing. ~"Cleaning" on page 17
■Appliance door as a seat, shelf or worktop: Do not
sit on the appliance door, or place or hang anything
on it. Do not place any cookware or accessories on
the appliance door.
■Inserting accessories: depending on the appliance
model, accessories can scratch the door panel
when closing the appliance door. Always insert the
accessories into the cooking compartment as far as
they will go.
■Carrying the appliance: do not carry or hold the
appliance by the door handle. The door handle
cannot support the weight of the appliance and
could break.
7Environmental protection
En v i r on ment al pr ot ec t i on Your new appliance is particularly energy-efficient.
Here you can find tips on how to save even more
energy when using the appliance, and how to dispose
of your appliance properly.
Saving energy
■Only preheat the appliance if this is specified in the
recipe or in the tables in the operating instructions.
■Leave frozen food to defrost before placing it in the
cooking compartment.
■Use baking tins that are dark-coloured, painted black
or have an enamel coating. These absorb the heat
particularly well.
■Remove any unnecessary accessories from the
cooking compartment.

Environmental protection en
7
■Open the appliance door as infrequently as possible
when the appliance is in use.
■It is best to bake several cakes one after the other.
The cooking compartment stays warm. This reduces
the baking time for the second cake. You can place
two cake tins next to each other in the cooking
compartment.
■For longer cooking times, you can switch the
appliance off 10 minutes before the end of the
cooking time and use the residual heat to finish
cooking.
Environmentally-friendly disposal
Dispose of packaging in an environmentally-friendly
manner.
This appliance is labelled in accordance with
European Directive 2012/19/EU concerning
used electrical and electronic appliances
(waste electrical and electronic equipment -
WEEE). The guideline determines the
framework for the return and recycling of used
appliances as applicable throughout the EU.

en Getting to know your appliance
8
*Getting to know your
appliance
Get t i ng to know your appl i ance In this section, we will explain the indicators and
controls. You will also find out about the various
functions of your appliance.
Note: Depending on the appliance model, individual
details and colours may differ.
Control panel
You can set your appliance's various functions on the
control panel. Below, you will see an overview of the
control panel and the layout of the controls.
Note: On some appliances, the control knobs can be
pushed in. To push the control knob in and engage it or
to release it again, turn it to the "Off" position.
Buttons and display
You can use the buttons to set various additional
functions on your appliance. You will be able to see the
values for these on the display.
--------
Display
The value that can be set at the present time or that is
elapsing will be shown in large digits on the display.
To use the individual time-setting options, tap the
vbutton several times. The symbol that lights up
corresponds to the value currently shown in large digits
on the display.

+
#
3
;C
K










(Buttons and display
The buttons are touch keys with sensors
underneath. Simply touch a symbol to select the
function.
The display shows symbols for active functions
and the time-setting options.
0Main oven ó
Controls for the main oven
8Function selector ó
Use the function selector to set the heating
function or other functions for the main oven.
You can turn the function selector clockwise or
anti-clockwise from the "Off" position.
@Temperature selector ó
Use the temperature selector to set the
temperature for the heating function or select the
setting for other functions for the main oven.
You can only turn the temperature selector
clockwise from the "Off" position, until it offers
resistance. Do not turn the selector beyond this
point.
HHeating-up indicator ó
The heating-up indicator for the main oven
remains lit while the appliance is heating.
PTop oven ò
Controls for the top oven
XFunction selector ò
Use the function selector to set the heating
function or other functions for the top oven.
You can turn the function selector clockwise or
anti-clockwise from the "Off" position.
`Temperature selector ò
Use the temperature selector to set the
temperature for the heating function or select the
setting for other functions for the top oven.
You can only turn the temperature selector
clockwise from the "Off" position, until it offers
resistance. Do not turn the selector beyond this
point.
hHeating-up indicator ò
The heating-up indicator for the top oven remains
lit while the appliance is heating.
Symbol Meaning
\Time-setting options Tap the symbol repeatedly to select
the timer Q, duration x, end
time yand time.
Childproof lock Lock and unlock the oven functions
on the control panel by pressing and
holding the button for approx. 4 sec-
onds.
A
@
Minus
Plus
Reduce setting values.
Increase setting values.

Getting to know your appliance en
9
Types of heating and functions
Use the function selector to set the types of heating and
other functions.
To make sure you always use the right type of heating
to cook your food, we have explained the differences
and applications below.
Note: Not all heating functions and other functions are
available for both ovens. To find out which ones are
available, see the symbols on the controls.
--------
Other functions
Your new oven has yet more functions; see below for a
brief description of these.
Heating function Use
óMain oven
<3D hot air For baking and roasting on one or more levels.
The fan distributes the heat from the ring-shaped heating element in the back panel
evenly around the cooking compartment.
6Gentle hot air For gently cooking selected types of food on one level without preheating.
The fan distributes the heat from the ring-shaped heating element in the back panel
around the cooking compartment.
This heating function is used to measure both the energy consumption in air recirculation
mode and the energy efficiency class.
(Grill, large area For grilling flat items, such as steaks or sausages, for making toast, and for browning
food.
The whole area below the grill element becomes hot.
7Circulated air grilling For roasting poultry, whole fish and larger pieces of meat.
The grill element and the fan switch on and off alternately. The fan circulates the hot air
around the food.
%Top/bottom heating For traditional baking and roasting on one level. Especially suitable for cakes with moist
toppings.
Heat is emitted evenly from above and below.
This heating function is used to measure the energy consumption in the conventional
mode.
òTop oven
%Top/bottom heating For baking on one level.
Heat is emitted evenly from above and below.
This heating function is used to determine the energy efficiency class in conventional
mode.
*Grill, small area For grilling small amounts of steaks or sausages, for making toast, and for cooking au gra-
tin.
The centre area under the grill heating element becomes hot.
(Grill, large area For grilling flat items, such as steaks or sausages, for making toast, and for browning
food.
The whole area below the grill element becomes hot.
Function Use
óMain oven
FRapid heating Preheats the cooking compartment rapidly without accessories inside it.
^Interior lighting Switches on the interior lighting; all other functions remain off.
Makes it easier to clean the cooking compartment, for example.

en Getting to know your appliance
10
--------
Temperature
Use the temperature selector to set the temperature in
the cooking compartment. You can also use it to select
the settings for other functions.
For temperature settings above 250 °C, the appliance
reduces the temperature to approx. 240 °C after
approx. 10 minutes. If your appliance has the top/
bottom heating or bottom heating types, this reduction
does not take place.
--------
Temperature indicator
The heating-up indicator remains lit while the appliance
is heating.
When you are preheating the appliance, the optimal
time to place your food in the cooking compartment is
when the heating-up indicator first goes out.
Note: Due to thermal inertia, the actual temperature
inside the cooking compartment may differ slightly from
the temperature that is displayed.
Cooking compartment
Various functions in the cooking compartment make
your appliance easier to use. For example, the cooking
compartment is well lit and a cooling fan prevents the
appliance from overheating.
Opening the appliance door
If you open the appliance door when the appliance is in
operation, the appliance will continue to operate as
before.
Interior lighting
With most heating functions and other functions, the
interior lighting in the cooking compartment will remain
lit while the oven is in operation. When the function
selector is turned to bring operation to an end, the
lighting will go out.
By turning the function selector to the interior lighting
setting, you can switch on the lighting without heating
the oven. This makes it easier to clean your appliance,
for example.
Cooling fan
The cooling fan switches on and off as required. The
hot air escapes above the door.
Caution!
Do not cover the ventilation slots. Otherwise, the
appliance may overheat.
So that the cooking compartment cools down more
quickly after operation, the cooling fan continues to run
for a certain period afterwards.
òTop oven
^Interior lighting Switches on the interior lighting; all other functions remain off.
Makes it easier to clean the cooking compartment, for example.
Position Meaning
Ú"Off" position The appliance is not heating.
50-275 Temperature
range
The temperature that can be set in the
cooking compartment in °C.
1, 2, 3
or
I, II, III
Grill settings The configurable settings for the grill,
large area (and small area *
(depending on the appliance model).
Setting 1 = low
Setting 2 = medium
Setting 3 = high

Accessories en
11
_Accessories
Accessor i es Your appliance is accompanied by a range of
accessories. Here, you can find an overview of the
accessories included and information on how to use
them correctly.
Control accessories
The accessories supplied may differ depending on the
appliance model.
--------
Only use original accessories. They are specially
adapted for your appliance.
You can buy accessories from the after-sales service,
from specialist retailers or online.
Note: The accessories may deform when they become
hot. This does not affect their function. Once they have
cooled down again, they regain their original shape.
Inserting accessories
The shelf positions are counted from the bottom up.
The main cooking compartment
The main cooking compartment has five shelf positions.
Always insert accessories between the two guide rods
for the shelf position.
Accessories can be pulled out approximately halfway
without tipping.
Notes
■Make sure that you always insert the accessories
into the cooking compartment the right way round.
■Always insert the accessories fully into the cooking
compartment so that they do not touch the appliance
door.
■Take any accessories that you will not be using out
of the cooking compartment.
■The shelf supports can be taken out of the cooking
compartment for cleaning. ~Page 19
The top cooking compartment
The top cooking compartment has three shelf positions.
Always insert accessories between the two guide rods
for the shelf position.
Accessories can be pulled out approximately halfway
without tipping.
Notes
■Make sure that you always insert the accessories
into the cooking compartment the right way round.
■Always insert the accessories fully into the cooking
compartment so that they do not touch the appliance
door.
■Take any accessories that you will not be using out
of the cooking compartment.
Locking function
The accessories can be pulled out approximately
halfway until they lock in place. The locking function
prevents the accessories from tilting when they are
pulled out. The accessories must be inserted into the
cooking compartment correctly for the tilt protection to
work properly.
When inserting the wire rack, ensure that lug ‚is at the
rear and is facing downwards. The open side must be
facing the appliance door and the outer rail must be
facing downwards ¾.
Wire rack
For ovenware, cake tins and ovenproof
dishes.
For roasts, grilled items and frozen
meals.
Universal pan
For moist cakes, pastries, frozen meals
and large roasts.
It can be used to catch dripping fat when
you are grilling directly on the wire rack.
Two universal pans, narrow style
For smaller amounts, fish, meat, vegeta-
bles an small baked products.
Slide the two trays (or only one) into the
cooking compartment as shown in the
image.
Do not use the universal pans in con-
junction with the clip-rails.








D
D

en Accessories
12
When inserting baking trays, make sure that the recess
‚is at the rear and is facing downwards. The sloping
edge of the accessory ƒmust be facing towards the
appliance door.
Example in the picture: Universal pan
Combining accessories
You can insert the wire rack and the universal pan at
the same time to catch drops of liquid.
When inserting the wire rack, ensure that both spacers
‚are at the rear edge. When inserting the universal
pan, the wire rack is on top of the upper guide rod of
the shelf position.
Example in the picture: Universal pan
Optional accessories
You can buy optional accessories from the after-sales
service, from specialist retailers or online. *You will find
a comprehensive range of products for your appliance
in our brochures and online.
Both availability and whether it is possible to order
online differ between countries. Please see your sales
brochures for more details.
Note: Not all optional accessories are suitable for every
appliance. When purchasing, please always quote the
exact identification number (E-no.) of your appliance.
~"Customer service" on page 24
--------
Optional accessories
Wire rack
For cookware, cake tins and ovenproof dishes, and for roasts and
grilled food.
Baking tray
For tray bakes and small baked items.
Universal pan
For moist cakes, baked items, frozen food and large roasts.
It can be used to catch dripping fat when you are grilling directly on
the wire rack.
D
D
E
D
D
D
Wire insert
For meat, poultry and fish.
For inserting into the universal pan to catch dripping fat and meat
juices.
Universal pan, non-stick
For moist cakes, baked items, frozen food and large roasts.
Allows baked items and roasts to be removed more easily from the
universal pan.
Baking tray, non-stick
For tray bakes and small baked items.
Allows baked items to be removed more easily from the baking tray.
Two universal pans, narrow style
For moist cakes, baked items and frozen food.
Do not use the universal pans in conjunction with the clip-on pull-out
rails or place them on the wire rack.
Professional pan
For preparing large quantities of food. Also ideal for moussaka, for
example.
Professional pan with wire insert
For preparing large quantities of food.
Lid for the professional pan
The lid turns the professional pan into a professional roasting dish.
Pizza tray
For pizzas and large round cakes.
Grill tray
Use for grilling in place of the wire rack or as a splatter guard. Use in
the universal pan only.
Baking stone
For home-made bread, bread rolls and pizzas that you wish to have a
crispy base.
The baking stone must be preheated to the recommended tempera-
ture.
Glass roasting dish
For stews and bakes.
Glass pan
For bakes, vegetable dishes and baked items.
Clip-on rail
The pull-out rails can be used at any level. Rails can be fitted on any
and all free levels.
Pull-out system, one level
Fitting pull-out rails at position 2 will allow you to pull accessories out
further without them tipping.
Pull-out system, two levels
Fitting pull-out rails at positions 2 and 3 will allow you to pull accesso-
ries out further without them tipping.
Pull-out system, three levels
Fitting pull-out rails at positions 1, 2 and 3 will allow you to pull acces-
sories out further without them tipping.

Before using for the first time en
13
KBefore using for the first
time
Be f o r e usi ng for the fi rst ti me Before you can use your new appliance, you must
make some settings. You must also clean the cooking
compartment and accessories.
Initial use
The time will appear on the display once the appliance
is connected to the power supply. Set the current time.
Setting the time
Make sure that the function selector is set to the "Off"
position.
The time starts at "12:00".
1. Use the Aor @button to set the time.
2. Touch the vbutton to confirm.
The current time will be shown on the display.
Cleaning the cooking compartment and
accessories
Before using the appliance to prepare food for the first
time, you must clean the cooking compartment and
accessories.
Cleaning the cooking compartment
To eliminate the new-appliance smell, heat up the
cooking compartment when it is empty and with the
oven door closed.
Ensure that there is no leftover packaging, such as
polystyrene pellets, in the cooking compartment and
remove the adhesive tape that is in or on the appliance.
Before heating the appliance, wipe the smooth surfaces
in the cooking compartment with a soft, damp cloth.
Keep the kitchen ventilated while the appliance is
heating.
Apply the settings indicated below. You can find out
how to set the type of heating and the temperature in
the next section. ~"Operating the appliance"
on page 13
Switch off the appliance after the time indicated.
Once the cooking compartment has cooled down,
clean the smooth surfaces with soapy water and a dish
cloth.
Cleaning the accessories
Clean the accessories thoroughly using soapy water
and a dish cloth or soft brush.
1Operating the appliance
Oper at i ng the appl i ance You have already learnt about the controls and how
they work. Now we will explain how to apply settings on
your appliance.
Switching the appliance on and off
Use the function selector to switch the appliance on or
off. Turning the function selector to any position other
than the "Off" position switches on the appliance. To
switch off the appliance, always turn the function
selector to the "Off" position.
Setting the heating function and temperature
The function selector and temperature selector make it
very easy to apply the settings you require to your
appliance. To find out which heating function is best for
which type of food, please refer to the beginning of the
instruction manual. ~"Getting to know your
appliance" on page 8
Example in the picture: Top/bottom heating %at
190 °C.
1. Use the function selector to set the heating function.
2. Use the temperature selector to set the temperature
or grill setting.
The appliance starts heating after a few seconds.
Once your food is cooked, turn the function selector to
the "Off" position to switch the appliance off.
Note: You can also set a cooking time and end time on
the appliance. ~"Time-setting options" on page 14
Changing
The heating function and temperature can be changed
at any time using the relevant selector.
Settings Bottom oven óTop oven ò
Type of heating 3D hot air <Top/bottom heating %
Temperature Maximum 240 °C
Cooking time 1 hour 1 hour

&

en Time-setting options
14
Rapid heating
With Rapid heating, you can shorten the heat-up time.
Then, for best results, use:
■<3D hot air
Only use Rapid heating when a temperature of over
100 °C has been selected.
To achieve an even cooking result, do not place your
food into the cooking compartment until Rapid heating
is complete.
1. Set the function selector to F.
2. Use the temperature selector to set the temperature.
The oven will start heating after a few seconds.
Once Rapid heating is complete, an audible signal will
sound. Place your food in the cooking compartment.
OTime-setting options
Ti me- s et t i ng opt i ons Your appliance has different time-setting options.
You must set a heating function before you can call up
the cooking time using the vbutton. Once you have
set a cooking time, the end time can be called up.
An audible signal sounds once the cooking time or
timer duration has elapsed. You can cancel the audible
signal early by touching the vbutton.
Setting the cooking time
You can set the cooking time for your food on the
appliance. This prevents the food from accidentally
being cooked for too long, and means that you do not
have to stop what you are doing to switch off the oven.
The maximum time that can be set is 23 hours 59
minutes. The cooking time can be set in one-minute
increments up to one hour, and then in five-minute
increments.
The cooking time starts at a different default value,
depending on which button you touch first:
10 minutes if you touch the Abutton and 30 minutes if
you touch the @button.
Example in the picture: Cooking time of 45 minutes.
1. Set the heating function and temperature or setting
for the main oven ó.
2. Touch the vbutton twice.
The cooking time xis highlighted in the display.
Time-setting option Use
xCooking time Main oven ó: Once the set cooking time has
elapsed, the appliance automatically stops
heating.
yEnd Main oven ó: Enter a cooking time and the
required end time. The appliance starts up
automatically so that it finishes cooking at the
required time.
QTimer The timer functions like an egg timer. It runs
independently of the appliance when it is
heating and does not affect the appliance.
vTime When no other function is running in the fore-
ground, the appliance shows you the time of
day in the display.
[

Time-setting options en
15
3. Use the Aor @button to set the cooking time.
The appliance starts to heat after a few seconds. The
cooking time counts down in the display.
The cooking time has elapsed
An audible signal will sound. The appliance will stop
heating. The cooking time will be zero on the display.
Once the signal stops, you can touch the @button to
set a new cooking time.
Once your food is cooked, turn the function selector to
the "Off" position to switch the appliance off.
Changing and cancelling
You can use the Aor @button to change the cooking
time at any time.After a few seconds, the change will be
applied.
To cancel, use the Abutton to reset the cooking time all
the way to zero. The appliance will continue heating
without a cooking time.
Setting the end time
You can delay the time at which cooking is due to
finish. You can, for example, put your food in the
cooking compartment in the morning and set the
cooking time so that it is ready at lunch time.
Notes
■Make sure that food is not left in the cooking
compartment for too long as it may spoil.
■Do not adjust the end time once the appliance is
already in operation. Otherwise the cooking result
may no longer be satisfactory.
The end of the cooking time can be delayed by up to
23 hours and 59 minutes.
Example in the picture: The time is 10.30 a.m., a
cooking time of 45 minutes has been set and you want
the food to be ready at 12.30 p.m.
1. Set the heating function and temperature or setting
for the main oven ó.
2. Touch the vbutton twice and use the Aor @button
to set the cooking time.
3. Touch the vbutton again.
The end time yis highlighted in the display.
4. Use the @or Abutton to delay the end time.
The appliance applies the settings after a few seconds.
The end time is shown in the display. Once the
appliance starts, the time begins counting down.
The cooking time has elapsed
An audible signal will sound. The appliance will stop
heating. The cooking time will be zero on the display.
Once the signal stops, you can touch the @button to
set a new cooking time.
Once your food is cooked, turn the function selector to
the "Off" position to switch the appliance off.
Changing and cancelling
You can use the Aor @button to change the end time.
After a few seconds, the change will be applied. The
end time cannot be changed once the cooking time has
already started to count down. Otherwise the cooking
result would no longer be satisfactory.
To cancel, use the Abutton to set the end time all the
way back to the current time plus the cooking time. The
appliance will start to heat and the cooking time will
start to count down.

en Childproof lock
16
Setting the timer
You can use the timer whether or not the appliance
itself is in use. However, it is not possible to set a
cooking time or end time.
The maximum time that can be set is 23 hours and 59
minutes. Up to 10 minutes, the timer duration can be
set in 30-second increments. Above 10 minutes, the
time increments become longer the higher the value.
The timer duration will start at a different default value,
depending on which button you touch first:
5 minutes if you touch the Abutton and 10 minutes if
you touch the @button.
1. Touch the vbutton until the timer symbol Qis
highlighted.
2. Use the Aor @button to set the timer duration.
After a few seconds, the timer duration will start to
count down.
Tip: If the set timer duration is the duration for which
you wish to cook your food, use the cooking time. The
appliance will then switch off automatically when it has
finished cooking.
The timer duration has elapsed
An audible signal will sound. The timer duration will be
zero on the display.
Touch any button to switch off the timer.
Changing and cancelling
You can use the Aor @button to change the timer
duration at any time. After a few seconds, the change
will be applied.
To cancel, use the Abutton to reset the timer duration
all the way to zero. The timer is now switched off.
Setting the time
Once the appliance has been connected to the mains
or following a power failure, the clock will flash on the
display. Set the time.
The function selector must be set to the "Off" position.
1. Use the Aor @button to set the time.
The time will stop flashing.
2. Confirm by pressing the vbutton.
The appliance will apply the time you have set.
Changing the time
You can change the time again when you need to, e.g.
from summer to winter time.
To do this, when the appliance is switched off, touch the
vbutton until the time flashes, and use the Aor
@button to change the time.
AChildproof lock
Ch i l d p r o o f lock The bottom oven has a childproof lock to prevent
children from switching it on or changing settings by
accident.
Notes
■If a hob is connected, it will not be affected by the
childproof lock on the oven.
■After a power cut, the childproof lock will no longer
be active.
Activating and deactivating
To activate the childproof lock for the main oven, the
function selector must be set to the "Off" position.
Press and hold the Dbutton for approx. four seconds.
†‘”“ appears in the display. The childproof lock is
now active for the main oven.
Note: If a timer duration Qhas been set, this continues
to count down. While the childproof lock is active, the
timer duration cannot be changed.
To deactivate the childproof lock, press and hold the
Dbutton again for approx. four seconds until †‘”“
goes out in the display.

Cleaning en
17
DCleaning
Cl eani ng With good care and cleaning, your appliance will retain
its appearance and remain fully functioning for a long
time to come. We will explain here how you should
correctly care for and clean your appliance.
Suitable cleaning agents
To ensure that the different surfaces are not damaged
by using the wrong cleaning agent, observe the
information in the table. Depending on the appliance
model, not all of the areas listed may be on/in your
appliance.
Caution!
Risk of surface damage
Do not use:
■Harsh or abrasive cleaning agents,
■Cleaning agents with a high alcohol content,
■Hard scouring pads or cleaning sponges,
■High-pressure cleaners or steam cleaners,
■Special cleaners for cleaning the appliance while it is
hot.
Wash new sponge cloths thoroughly before use.
Tip: Highly recommended cleaning and care products
can be purchased through the after-sales service.
Observe the respective manufacturer's instructions.
:Warning – Risk of burns!
The appliance becomes very hot. Never touch the
interior surfaces of the cooking compartment or the
heating elements. Always allow the appliance to cool
down. Keep children at a safe distance.
--------
Notes
■Slight differences in colour on the front of the
appliance are caused by the use of different
materials, such as glass, plastic and metal.
■Shadows on the door panels, which look like
streaks, are caused by reflections made by the
interior lighting.
■Enamel is baked on at very high temperatures.This
can cause some slight colour variation. This is
normal and does not affect operation.
The edges of thin trays cannot be completely
enamelled. As a result, these edges can be rough.
This does not impair the anti-corrosion protection.
Area Cleaning
Appliance exterior
Stainless steel
front
Hot soapy water:
Clean with a dish cloth and then dry with a soft
cloth.
Remove flecks of limescale, grease, starch and
albumin (e.g. egg white) immediately. Corrosion
can form under such flecks.
Special stainless steel cleaning products suitable
for hot surfaces are available from our after-sales
service or from specialist retailers. Apply a very
thin layer of the cleaning product with a soft cloth.
Plastic Hot soapy water:
Clean with a dish cloth and then dry with a soft
cloth.
Do not use glass cleaner or a glass scraper.
Painted surfaces Hot soapy water:
Clean with a dish cloth and then dry with a soft
cloth.
Control panel Hot soapy water:
Clean with a dish cloth and then dry with a soft
cloth.
Do not use glass cleaner or a glass scraper.
Door panels Hot soapy water:
Clean with a dish cloth and then dry with a soft
cloth.
Do not use a glass scraper or a stainless steel
scouring pad.
Door handle Hot soapy water:
Clean with a dish cloth and then dry with a soft
cloth.
If descaler comes into contact with the door han-
dle, wipe it off immediately. Otherwise, any stains
will not be able to be removed.
Appliance interior
Enamel surfaces
and self-cleaning
surfaces
Observe the instructions for the surfaces of the
cooking compartment that follow the table.
Glass cover for
the interior light-
ing
Hot soapy water:
Clean with a dish cloth and then dry with a soft
cloth.
If the cooking compartment is heavily soiled, use
oven cleaner.
Door seal
Do not remove.
Hot soapy water:
Clean with a dish cloth.
Do not scour.
Door cover made from stainless steel:
Use stainless steel cleaner. Follow the manufac-
turers' instructions. Do not use stainless steel
care products.
made from plastic:
Clean using hot soapy water and a dish cloth. Dry
with a soft cloth. Do not use glass cleaner or a
glass scraper.
Remove the door cover for cleaning.
Rails Hot soapy water:
Soak and clean with a dish cloth or brush.
Pull-out system Hot soapy water:
Clean with a dish cloth or a brush.
Do not remove the lubricant while the pull-out rails
are pulled out – it is best to clean them when they
are pushed in. Do not clean in the dishwasher.
Accessories Hot soapy water:
Soak and clean with a dish cloth or brush.
If there are heavy deposits of dirt, use a stainless
steel scouring pad.

en Cleaning
18
Surfaces in the cooking compartment
The back wall in the cooking compartment is self-
cleaning.You can tell this from the rough surface.
The base, ceiling and side panel are enamelled and
have smooth surfaces.
Cleaning enamel surfaces
Clean the smooth enamel surfaces with a dish cloth
and hot soapy water or a vinegar solution. Then dry
them with a soft cloth.
Soften baked-on food remnants with a damp cloth and
soapy water. Use stainless steel wire wool or oven
cleaner to remove stubborn dirt.
Caution!
Never use oven cleaner in the cooking compartment
when it is still warm. This may damage the enamel.
Remove all food remnants from the cooking
compartment and the appliance door before you next
heat up the appliance.
Leave the cooking compartment open to dry after
cleaning it.
Note: Food residues can cause white deposits to form.
These are harmless and do not affect how the
appliance works. You can remove these residues using
lemon juice if required.
Cleaning self-cleaning surfaces
The self-cleaning surfaces are coated with a porous,
matte ceramic layer. This coating absorbs and dispels
splashes from baking and roasting while the appliance
is in operation.
If the self-cleaning surfaces no longer clean themselves
sufficiently and dark stains appear, they can be cleaned
using targeted heating.
Making settings
Remove the rails, pull-out shelves, accessories and
ovenware from the cooking compartment beforehand.
Thoroughly clean the smooth enamel surfaces in the
cooking compartment, the inside of the appliance door
and the glass cover on the interior lighting.
1. Set the 3D hot air type of heating.
2. Set the maximum temperature.
3. Start the mode and leave it to run for at least one
hour.
The ceramic coating is regenerated.
When the cooking compartment has cooled down,
remove the brown or white residue with water and a soft
sponge.
Note: During operation, reddish spots form on the
surfaces. This is not rust, but residues from food. These
spots are not harmful and do not restrict the cleaning
ability of the self-cleaning surfaces.
Caution!
Do not use oven cleaner on the self-cleaning surfaces.
This will damage the surfaces.If oven cleaner does get
onto these surfaces, dab it off immediately using water
and a sponge cloth. Do not rub the surface and do not
use abrasive cleaning aids.
Keeping the appliance clean
Always keep the appliance clean and remove dirt
immediately so that stubborn deposits of dirt do not
build up.
:Warning – Risk of fire!
Loose food remnants, fat and meat juices may catch
fire. Before using the appliance, remove the worst of the
food remnants from the cooking compartment, heating
elements and accessories.
Tips
■Clean the cooking compartment after each use. This
will ensure that dirt cannot be baked on.
■Always remove flecks of limescale, grease, starch
and albumin (e.g. egg white) immediately.
■Use the universal pan for baking very moist cakes.
■Use suitable ovenware for roasting, e.g. a roasting
dish.

Rails en
19
pRails
Rails With good care and cleaning, your appliance will retain
its appearance and remain fully functional for a long
time to come. This will tell you how to remove the
shelves and clean them.
Detaching and refitting the rails
:Warning – Risk of burns!
The rails become very hot. Never touch the hot rails.
Always allow the appliance to cool down. Keep children
away from the appliance.
Detaching the rails
1. Lift the rail slightly at the front ‚and detach it ƒ
(figure !).
2. Then pull the whole rail towards you and take it out
(figure ").
Clean the rails with cleaning agent and a sponge. For
stubborn deposits of dirt, use a brush.
Attaching the rails
The rails only fit on the right or the left side. For both
rails, ensure that the curved rods are at the front.
1. First, insert the rail in the middle of the rear socket ‚,
until the rail rests against the cooking compartment
wall, and push it back ƒ(figure !).
2. Then insert the rail into the front socket „, until the
rail also rests against the cooking compartment wall
here, and press it downwards …(figure ").
Detaching and refitting the rails
:Warning – Risk of burns!
The rails become very hot. Never touch the hot rails.
Always allow the appliance to cool down. Keep children
away from the appliance.
Detaching the shelf supports
1. Lift the shelf support slightly at the front ‚and
detach it ƒ(fig. !).
2. Then pull the whole shelf support towards you and
remove it (fig. ").
Clean the shelf supports with washing-up liquid and a
sponge. For stubborn dirt deposits, use a brush.
21
D
E
2
F
G
1
D
E
F
G
2
E
D
1

en Appliance door
20
Refitting the shelf supports
The shelf supports are designed to fit on either the right-
or the left-hand side (not both).For each of the shelf
supports, make sure that the hooks at the back are at
the top.
1. First, push the shelf support into the middle of the
rear socket ‚until the shelf support rests against the
cooking compartment wall, and then push it back ƒ
(fig. !).
2. Then push the shelf support into the front socket „
until the shelf support also rests against the cooking
compartment wall, and then press it downwards …
(fig. ").
qAppliance door
Ap p l i a n c e door With good care and cleaning, your appliance will retain
its appearance and remain fully functional for a long
time to come. This will tell you how to clean the
appliance door.
Main oven – Fitting and removing the glass
panels
To facilitate cleaning, you can remove the glass panels
from the appliance door.
Locking the appliance door
1. Open the appliance door fully.
2. Open the two locking levers on the left and right
(fig. !).
3. Close the appliance door as far as it goes (fig. ").
Removing panels
1. Press the left- and right-hand sides of the cover
(fig. !).
2. Remove the cover (fig. ").
3. Lift out each panel (fig. #) and set them down
carefully on a flat surface.
4. If necessary, you can remove the condensate trough
for cleaning. To do this, open the appliance door
fully (fig. $).
G
F
2
E
D
1
2
1
2
1


