Bosch GBH 2-20 D Professional User manual

Robert Bosch GmbH
Power Tools Division
70745 Leinfelden-Echterdingen
Germany
www.bosch-pt.com
1 619 92A 06H (2013.12) PS / 168 EURO
GBH 2-20 D Professional
de Originalbetriebsanleitung
en Original instructions
fr Notice originale
es Manual original
pt Manual original
it Istruzioni originali
nl Oorspronkelijke
gebruiksaanwijzing
da Original brugsanvisning
sv Bruksanvisning i original
no Original driftsinstruks
fi Alkuperäiset ohjeet
el Πρωτότυπο οδηγιών χρήσης
tr Orijinal işletme talimatı
pl Instrukcja oryginalna
cs Původní návod k používání
sk Pôvodný návod napoužitie
hu Eredeti használati utasítás
ru Оригинальное руководство
по эксплуатации
uk Оригінальна інструкція з
експлуатації
kk Пайдалану нұсқаулығының
түпнұсқасы
ro Instrucţiuni originale
bg Оригинална инструкция
mk Оригинално упатство за работа
sr Originalno uputstvo za rad
sl Izvirna navodila
hr Originalne upute za rad
et Algupärane kasutusjuhend
lv Instrukcijas oriģinālvalodā
lt Originali instrukcija
ar
fa
ςТЎϩХʉ ЌТϾϦφЍʉ ʌμВТЎϺυ
ΖЎϩʉ ˒μВЖЙʉʓ ИͳϞφЁʑ
OBJ_BUCH-1110-004.book Page 1 Monday, December 9, 2013 2:22 PM

8| English
1 619 92A 06H | (9.12.13) Bosch Power Tools
Luxemburg
Tel.: [phone]
Fax: [phone]
E-Mail: [e-mail]
Entsorgung
Elektrowerkzeuge, Zubehör und Verpackungen sollen einer
umweltgerechten Wiederverwertung zugeführt werden.
Werfen Sie Elektrowerkzeuge nicht in den Hausmüll!
Nur für EU-Länder:
Gemäß der Europäischen Richtlinie
2012/19/EU über Elektro- und Elektronik-
Altgeräte undihrerUmsetzunginnationales
Recht müssen nicht mehr gebrauchsfähige
Elektrowerkzeuge getrennt gesammelt und
einer umweltgerechten Wiederverwertung
zugeführt werden.
Änderungen vorbehalten.
English
General Power Tool Safety Warnings
Read all safety warnings and all in-
structions.Failure to follow thewarnings
and instructions may result in electric shock, fire and/or seri-
ous injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
power tool.
Work area safety
Keepworkareacleanandwelllit.Clutteredordarkareas
invite accidents.
Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases or
dust. Power tools create sparks which may ignite the dust
or fumes.
Keep children and bystanders away while operating a
power tool. Distractions can cause you to lose control.
Electrical safety
Power tool plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
earthed (grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electric shock.
Avoidbodycontactwithearthedorgroundedsurfaces,
such as pipes, radiators, ranges and refrigerators.
There is an increased risk of electric shock if your body is
earthed or grounded.
Do not expose power tools to rain or wet conditions.
Waterenteringapowertoolwillincrease theriskofelectric
shock.
Do not abuse the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep cord away
from heat, oil, sharp edges and movingparts. Damaged
or entangled cords increase the risk of electric shock.
When operating a power tool outdoors, use an exten-
sion cord suitable for outdoor use. Use of a cord suitable
for outdoor use reduces the risk of electric shock.
If operating a power tool in a damp location is unavoid-
able, use a residual current device (RCD) protected
supply. Use of an RCD reduces the risk of electric shock.
Personal safety
Stay alert, watch what you are doing and use common
sense when operating a power tool. Do not use a power
toolwhileyouaretired or undertheinfluenceofdrugs,
alcohol or medication. A moment of inattention while op-
erating power tools may result in serious personal injury.
Use personal protective equipment. Always wear eye
protection. Protective equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection used
for appropriate conditions will reduce personal injuries.
Prevent unintentional starting. Ensure the switch is in
the off-position before connecting to power source
and/or battery pack, picking up or carrying the tool. Car-
rying power tools with your finger on the switch or energis-
ing power tools that have the switch on invites accidents.
Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to a ro-
tating part of the power tool may result in personal injury.
Do not overreach. Keep proper footing and balance at
all times. This enables better control of the power tool in
unexpected situations.
Dress properly. Do not wear loose clothing or jewel-
lery. Keep your hair, clothing and gloves away from
moving parts. Loose clothes, jewellery or long hair can be
caught in moving parts.
If devices are provided for the connection of dust ex-
traction and collection facilities, ensure these are con-
nected and properly used. Use of dust collection can re-
duce dust-related hazards.
Power tool use and care
Donotforcethepower tool. Use thecorrectpowertool
for your application. The correct power tool will do the
job better and safer at the rate for which it was designed.
Do not use the power tool if the switch does not turn it
on and off.Any power tool that cannot be controlled with
the switch is dangerous and must be repaired.
Disconnect the plug from the power source and/or the
battery pack from the power tool before making any
adjustments, changing accessories, or storing power
tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
Store idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool or
these instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.
WARNING
OBJ_BUCH-1110-004.book Page 8 Monday, December 9, 2013 2:22 PM

English | 9
Bosch Power Tools 1 619 92A 06H | (9.12.13)
Maintain power tools. Check for misalignment or bind-
ing of moving parts, breakage of parts and any other
condition that may affect the power tool’s operation. If
damaged,havethepowertoolrepairedbeforeuse.Many
accidents are caused by poorly maintained power tools.
Keepcuttingtoolssharpandclean.Properly maintained
cutting tools with sharpcutting edgesarelesslikelytobind
and are easier to control.
Use the power tool, accessories and tool bits etc. in ac-
cordance with these instructions, taking into account
the working conditions and the work to be performed.
Use of the power tool for operations different from those
intended could result in a hazardous situation.
Service
Haveyourpowertoolservicedbya qualifiedrepair per-
son using only identical replacement parts. This will en-
sure that the safety of the power tool is maintained.
Hammer Safety Warnings
Wear ear protectors. Exposure to noise can cause hear-
ing loss.
Use auxiliary handle(s), if supplied with the tool. Loss
of control can cause personal injury.
Hold the tool by the insulated gripping surfaces when
performing operations where the application tool or
thescrew could contact hiddenwiringor its own power
cord. Contact with a “live” wire will also make exposed
metalparts of thepower tool “live” andshockthe operator.
Products sold in GB only: Your product is fitted with a
BS 1363/A approved electric plug with internal fuse (ASTA
approved to BS 1362).
If the plug is not suitable for your socket outlets, it should be
cut off and an appropriate plug fitted in its place by an author-
ised customer service agent. The replacement plug should
have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains sock-
et elsewhere.
Productssoldin AUS and NZ only: Use a residual current de-
vice (RCD) with a rated residual current of 30 mA or less.
Additional Safety and Working
Instructions
Observe correct mains voltage! The voltage of the pow-
er source must agree with the voltage specified on the
nameplate of the machine. Power tools marked with
230 V can also be operated with 220 V.
Use appropriate detectors to determine if utility lines
arehiddenintheworkareaorcallthelocalutilitycompa-
nyforassistance.Contactwithelectriclinescanleadtofire
and electric shock. Damaging a gas line can lead to explo-
sion. Penetrating a water line causes propertydamage.
Firmly tighten the auxiliary handle, hold the machine
firmly with both hands while working and keep proper
footing and balance at all times. The machine is securely
guided with both hands.
Secure the workpiece. A workpiece clamped with clamp-
ing devices or in a vice is held more secure than by hand.
Fordrillingwithoutimpact inwood, metal,ceramicand plas-
tic as well as for screwdriving, tools without SDS-plus are
used (e.g., drills with cylindrical shank). For these tools, a
keyless chuck or a key type drill chuck are required.
Thequick change chuckis automaticallylocked.Check the
locking effect by pulling the quick change chuck.
Inserting SDS-plus Drilling Tools: Check the latching by
pulling the tool.
Replace a damaged dust protection cap immediately.
Thedustprotectioncaplargelypreventsthepenetrationof
drilling dust into thetool holder during operation. When in-
serting the tool, pay attentionthat the dust protection cap
is not damaged.
Dustsfrommaterialssuchas lead-containingcoatings,
somewoodtypes,mineralsandmetalcanbeharmfulto
one’s health and cause allergic reactions, lead to res-
piratory infections and/or cancer. Materials containing
asbestos may only be worked by specialists.
–As far as possible, use a dust extraction system suita-
ble for the material.
–Provide for good ventilation of the working place.
–It is recommended to wear a P2 filter-class respirator.
Observe the relevant regulations in your country for the
materials to be worked.
Prevent dust accumulation at the workplace. Dusts can
easily ignite.
If the application tool should become blocked, switch
the machine off. Loosen the application tool.
Before switching on the powertool, make sure that the
application tool moves freely. When switching on with a
blocked drilling tool, high torque reaction can occur.
To save energy, only switch the power tool on when using it.
Always wait until the machine has come to a complete
stop before placing it down. The tool insert can jam and
lead to loss of control over the power tool.
Symbols
The following symbols are important for reading and under-
standing the operating instructions. Please take note of the
symbols and their meaning. The correct interpretation of the
symbols will help you touse the machine in a better and safer
manner.
Symbol Meaning
GBH 2-20 D: Rotary Hammer
Grey-marked area: Handle
(insulated gripping surface)
Article number
OBJ_BUCH-1110-004.book Page 9 Monday, December 9, 2013 2:22 PM

10 | English
1 619 92A 06H | (9.12.13) Bosch Power Tools
Delivery Scope
Rotary hammer, auxiliary handle and depth stop.
Application tools and other accessories shown or described
are not part of the standard delivery scope.
A complete overview of accessories can be found in our ac-
cessories program.
Intended Use
The machine is intended for hammer drilling in concrete,
bricks and masonry, as well as for light chiselling work. It is al-
so suitable for drilling without impact in wood, metal, ceram-
ics and plastic, as well as for screwdriving.
Technical Data
The technical data of the machine are listed in the table on
page 161.
The values given are valid for a nominal voltage [U] of 230 V.
For different voltages and models for specific countries,
these values can vary.
Read all safety warnings and all
instructions
Before any work on the machine itself,
pull the mains plug from the socket
outlet
Wear protective gloves
Always wear ear protection.
Wear safety glasses/goggles
Movement direction
Reaction direction
Next step of action
Drilling without impact
Hammer Drilling
Chiselling
Screwdriving
Right/left rotation
Vario-Lock
Switching On
Switching Off
On/Off switch lock-on
Releasing the On/Off switch
Low speed/impact rate
High speed/impact rate
Symbol Meaning
Extraction
Tool holder
P1Rated power input
E Impact energy per stroke according to
EPTA-Procedure 05/2009
n0No-load speed
Ø Drilling diameter, max.
Concrete
Steel
Wood
Brickwork
Core bit
Weight according to
EPTA-Procedure 01/2003
Protection class
LwA Sound power level
LpA Sound pressure level
ahVibration total value
KUncertainty
Symbol Meaning
OBJ_BUCH-1110-004.book Page 10 Monday, December 9, 2013 2:22 PM

English | 11
Bosch Power Tools 1 619 92A 06H | (9.12.13)
Noise/Vibration Information
The measured values of the machine are listed in the table on
page 161.
Noise and vibrational values (vector sum of three directions)
determined according to EN 60745.
The vibration level given in this information sheet has been
measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with another.
It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or insertion tools or is
poorly maintained, the vibration emission may differ. This may
significantly increase the exposure level over the total working
period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when itis running butnot actually doingthe job.This maysignif-
icantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.
Declaration of Conformity
We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with the fol-
lowing standards or standardization documents: EN 60745
according to the provisions of the directives 2011/65/EU,
2004/108/EC, 2006/42/EC.
Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ETM9,
D-70745 Leinfelden-Echterdingen
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
Leinfelden, 10.12.2013
Mounting and Operation
The following table indicates the actionobjectivesformountingand operationof thepower tool. The instructions for each action
objective are shown aside. Depending on the type of application, various instruction combinations are required. Observe the
safety instructions.
Henk Becker
Executive Vice President
Engineering
Helmut Heinzelmann
Head of Product Certification
PT/ETM9
Action Figure Please observe Page
Inserting SDS-plus Drilling Tools 1162
Removing SDS-plus Drilling Tools 2162
Selecting the operating mode and
rotation direction 3163 –164
Changing the chisel position
(Vario-Lock) 4164
Changing the position of the
auxiliary handle 5164
OBJ_BUCH-1110-004.book Page 11 Monday, December 9, 2013 2:22 PM

12 | English
1 619 92A 06H | (9.12.13) Bosch Power Tools
Maintenance and Cleaning
For safe and properworking, always keep the machine
and ventilation slots clean.
If the replacement of the supply cord is necessary, this has to
be done by Bosch or an authorized Bosch service agent in or-
der to avoid a safety hazard.
After-sales Service and Application
Service
Inallcorrespondence and spare partsorder,pleasealwaysin-
clude the 10-digit article number given on the type plate of
the machine.
Our after-sales service responds to your questions concern-
ing maintenance and repair of your product as well as spare
parts. Exploded views and information on spare parts can al-
so be found under:
www.bosch-pt.com
Bosch’s application service team will gladly answer questions
concerning our products and their accessories.
Great Britain
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
At www.bosch-pt.co.uk you can order spare parts or arrange
the collection of a product in need of servicing or repair.
Tel. Service: [phone]
E-Mail: [e-mail]
Ireland
Origo Ltd.
Unit 23 Magna Drive
Magna Business Park
City West
Dublin 24
Tel. Service: [phone]
Fax: [phone]
Australia, New Zealand and Pacific Islands
Robert Bosch Australia Pty. Ltd.
Power Tools
Locked Bag 66
Clayton South VIC 3169
Customer Contact Center
Inside Australia:
Phone: [phone]
Fax: [phone]
Inside New Zealand:
Phone: [phone]
Fax: [phone]
Outside AU and NZ:
Phone: [phone]
www.bosch.com.au
Republic of South Africa
Customer service
Hotline: [phone]
Gauteng – BSC Service Centre
35 Roper Street, New Centre
Johannesburg
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]
Adjusting the drilling depth X6165
Mounting the extraction system
(Saugfix) 7165
Switching on and off and setting
the speed 8166
Locking-on the On/Off switch 9166
Releasing the On/Off switch 10 166
Selecting Accessories –167
Action Figure Please observe Page
X
OBJ_BUCH-1110-004.book Page 12 Monday, December 9, 2013 2:22 PM

| 161
Bosch Power Tools 1 609 92A 03Y | (9.12.13)
GBH 2-20 D
3 611 B5A 4..
P1W 650
EJ0–1,7
n0min-1 2030
Ø max.
mm
mm
mm
mm
20
13
30
68
kg 2,3
II
LwA dB(A) 102
LpA dB(A) 91
KdB 3
ahm/s213,5
ahm/s2<2,5
ahm/s29,5
ahm/s2<2,5
Km/s21,5
OBJ_BUCH-1110-004.book Page 161 Monday, December 9, 2013 2:22 PM

162 |
1 609 92A 03Y | (9.12.13) Bosch Power Tools
1
2
3
2
4
5
1
2
1
OBJ_BUCH-1110-004.book Page 162 Monday, December 9, 2013 2:22 PM

| 163
Bosch Power Tools 1 609 92A 03Y | (9.12.13)
3
3
2
1
3
OBJ_BUCH-1110-004.book Page 163 Monday, December 9, 2013 2:22 PM

164 |
1 609 92A 03Y | (9.12.13) Bosch Power Tools
2
1
3
1
2
3
4
5
OBJ_BUCH-1110-004.book Page 164 Monday, December 9, 2013 2:22 PM

| 165
Bosch Power Tools 1 609 92A 03Y | (9.12.13)
X
3
2
X
1
2
1
6
7
OBJ_BUCH-1110-004.book Page 165 Monday, December 9, 2013 2:22 PM

166 |
1 609 92A 03Y | (9.12.13) Bosch Power Tools
2
1
1
8
9
10
OBJ_BUCH-1110-004.book Page 166 Monday, December 9, 2013 2:22 PM

| 167
Bosch Power Tools 1 609 92A 03Y | (9.12.13)
2 607 000 207
2 603 001 009
2 602 025 141
1 607 000 173
1 617 000 132
SDS-plus
1 608 571 062
Ø 1,5 – 13 mm
1 607 950 045
2 605 438 524
OBJ_BUCH-1110-004.book Page 167 Monday, December 9, 2013 2:22 PM
