Bosch 3727DEVS - 6" Random Orbit VS Sander User manual

S-B Power Tool Company Chicago IL 60646-5999
6" RANDOM ORBIT SANDER
Model 0601372639
INDUSTRIAL
January 2003
3727DEVS
+ = Not Illustrated * = As Required F/C = Failure Code AW = Refer to AW Labor Time Chart
35 2 910 130 244 Screw 85
36 2 605 500 124 Motor Housing Cover 70
37 2 915 011 007 Nut 89
38 2 600 206 010 Dam ening Ring 79
43 2 603 435 042 Screw {4} 89
44 2 600 282 015 Dust Fan Housing 73
45 2 601 328 047 Baffle 24
46 2 601 328 048 Lower Dust Shroud 38
47 2 601 328 049 U er Dust Shroud 38
48 2 601 035 002 Bag Su ort Bar 9
50 1 907 950 006 Allen Wrench 5mm 9
56 2 607 233 018 S eed Control 17
241 2 604 448 100 Cable 68mm {2} 10
655 2 602 026 069 Handle 74
733 2 610 917 410 Backing Pad - extra soft 88
733 2 610 917 411 Backing Pad - soft 88
733 2 610 917 412 Backing Pad - hard 88
753 2 610 917 259 Dust Cannister 9
808 2 601 117 730 Name late 9
811 1 607 014 117 Brush Set 26
826 2 606 610 903 Fan Assembly 51
w/Pos. 27, 28, 29
1 2 605 104 410 Motor Housing 71
2 2 604 220 663 Field 120V 22
3 2 604 011 240 Armature w/Fan 120V AW
4 2 607 200 260 Switch On/Off 15
5 3 604 460 555 Cord 11
5/1 1 900 452 012 Terminal Sleeve {2} 11
6 2 600 703 018 Strain Relief 11
7 2 601 035 001 Cord Clam 89
9 2 601 117 729 Label 9
13 2 600 905 051 Ball Bearing 60
14 2 600 905 034 Ball Bearing 61
16 2 604 337 016 Brush Holder {2} 25
17 2 603 435 041 Screw {3} 89
18 2 603 410 001 Screw {2} 89
19 2 914 201 705 Screw {6} 89
20 2 603 435 043 Screw {2} 89
21 2 914 201 664 Screw {4} 89
25 2 600 100 041 Washer 65
27 2 600 328 026 Drive Cou ling 40
28 2 600 190 060 Retaining Plate 65
29 3 603 391 003 Screw {2} 89
32 2 601 329 053 S ring Cli 27
Pos. Part Number Description {Qty.} F/C Pos. Part Number Description {Qty.} F/C
35
27
28
29
Z
47
17
46
38
733
826 13
Z
14
25
44
20 32
45
2
EBC
A
G
9
808
48
50
37
1655
43
19
36
21
16
811
B
A
16
241
241
7
19
6
5/1
F
short gray
G
clear
D
E
Clong gray
brown
purple
4
18
DF
5
3
753
Y
Y
56
