1 2 3 4 5 6
Programme ended when ...
... Start/Pause $indicator light goes out and or
(if was selected, without fin al spin) is indicated
on the display panel, the buzzer soun ds. Set volume of
buzzer. apage 6
Change the programme ...
If you have selected the wrong programme b y mistake:
– Reselect the programme.
– Select Start/Pause $.
Pause the programme ...
– Touch the Start/Pause $button.
– Follow the instr uctions in the display field: when lights
up and appears in the display, the door can be
opened. If required, add /remove a laundry item; If
and are displayed alternately, the door cannot be
opened due to a high water level in drum or a high
temperature.
– Touch Start/Pause $b utton to continue the
programme.
... or terminate the programme
Programmes with high t emperature:
– Cool down lau ndry: Select Rinse 2.
– Select Start/P ause $.
Programmes at lower tempe rature:
– Select Empty >or Spin .
– Select Start/Pause $.( Spin speed)
You can change the indicated spin speed. The maximum spin speed which can be sel ected
depends on the chosen programme . If is selected, the load is held in the rinsing water.
((Childproof lock) Programme cannot be changed by accid ental operation.
To activate the childproof lock:
– After the pro gramme starts, press and hold t he (button for 5 seconds;
– Release w hen the #symbol lights up.
When the programme ends, the Start/Pa use $indicator remains on to remind you to
deactivate the childproof lock.
*#symbol flashes if the programme h as been changed while ch ildproof lock is activated.
To deactivate the childproof lock:
– Touch the (button until the #symbol turns off;
– Release the butt on.
If the childproof lock is deactivated while the programme selector is in a different position
from when the childproof lock was activ ated*, the running programme wi ll be halted.
ʑAdditional functio ns see also Programme overview apage 7
7Pre-wash For heavily soiled, hard-wearing textiles . Pre-wash at
max. 30 °C.
=Water plus High water level to achieve bette r rinse result.
SEasy iron Special spin sequence with subs equent fluffing. Gentle
final spin - residual moisture in the laundry increased
slightly.
Intensive Extends the washing time for a more intensi ve washing
of heavily soiled items.
The additional function indicator ligh t is on when the option is selec ted; if the option is not
selectable for the programme, this is indicated by a short flashing of the light and an
accoustic signal.
ʑStart/Pause $For starting or pausing the programme.
ʑSignals
Set to ÂPress and
hold
1 step
clockwise
Button signals Information signals
Set volume* Set volume*1 step
clockwise
Set to Â1. Start signal
mode
2. Set volume for ...
Release
#
*If required, set repeatedly
1 step
clockwise
direct
Sorting and loading the laundry
Observe the care information p rovided by the manufacturer.
Sort according to the information on the c are labels.
Sort according to type, colour, soiling and tempe rature.
Remove any foreign objects - r isk of rusting.
Do not exceed the maximum load. apage 7
Observe the instructions in the Importan t information section. apage 9
Load both large and small items of laundry.
Close the washing machine door. Take care not to trap any items of clothing
between the loading door and rubber seal.
Add detergent and care product
Add the appropriate dose according to :
Amount of laundry, soiling, water hardness (a sk your water supply
company) and manufacturer’s ins tructions.
Models without inse rt for liquid detergen t: pour liquid deterge nt into an
appropriate dispenser and place in the drum.
During operation: close the detergent drawer!
Correct installation ac cording to
separate installation instruc tions.
Check the machine
– Never switch o n a damaged machine!
– Inform your customer service!
Insert mains plug
With dry hands only!
Only hold the plug i tself!
Turn on the tap
Compartment II: Detergent for th e main wash, water soften er,
bleach, stain remover
Your washing machine
Congratulations – You have opted for a modern, high–quality d omestic
appliance manufactured by BOSCH. The washing machine i s
distinguished by its econom ical use of water and energy.
Each appliance which leaves our facto ry has been inspected thoroughly
to ensure that it functions properly and is in perfect condition.
For further information about pro ducts, accessories, spare parts a nd
services visit our web site: www.bosch-home.com or co ntact our after-
sales service centres.
Environmentally friendly waste dispo sal All packaging must be disposed of in accordance with environmental
guidelines. This appliance is certifi ed in accordance with European
Directive 2002/96/EEC on waste electrical and electronic equipm ent
(WEEE).This directive provides the framework for the EU-wide collecti on
and reuse of used a ppliances.
Intended use
Contents Page
ʋIntended use ...................................................................................... 1
ʋProgrammes .. .................................................................................... 1
ʋPreparation ..................................................................................... 2/3
ʋSetting an d adjusting programmes ............................................... 3
ʋWashing .......................................................................................... 3/4
ʋRemoving the laundry ...................................................................... 4
ʋDisplay information, Options, Functions ................................... 5/6
ʋProgramme overview......................................................................... 7
ʋSafety ins tructions ................................... .......................................... 8
ʋConsumption values .......................................................... ............. 8
ʋImportant information ....................................................................... 9
ʋCare ................................................................................................... 10
ʋInformation on the display pane l................................................... 10
ʋMaintenance ..................................................................................... 11
ʋWhat to do if ....................................................................................12
ʋEmergency release.......................................................................... 13
ʋCustomer service ........................................................................ 13
Protection of the e nvironment/Conservatio n tips
–Always fill the washing machin e with a maximum amount of
laundry for the relevant programme.
– Wash normally soiled l aundry without prewash .
– Instead of the Cottons LF90 °C programme, select
Cottons Eco 60 °C and the (Intensive) additional function.
The cleaning result will be comparable, but energy consumption
will be significantly lower.
– Dose the deterge nt according to the manufacturer’s
instructions and water hard ness.
– I f the laundry is to be subsequently drie d in a tumble dryer, select
a spin speed as specified by th e dryer manufacturer.
Preparation Before washing for the first time,
wash once without any laundry apage 9
Setting and adjusting programmes
Display panel/
Option buttons/
Additional functions
Programme selector Start/
Pause
1
2
3
Washing
Compartment ~:Fabric soften er, impregnating ag ent, starch
Compartment I: Detergent for pre–wash
ʋFor domestic use only.
ʋFor washing machine-washable fa brics in a detergent
solution.
ʋTo be operated with cold mains water and
commercially available low foam de tergents and care
products which are suitable for use in was hing
machines.
– Do not leave children unattended near the
washing machine!
– The washing machine is not to be use d by
children or persons not familiar with the
operating instructions.
– Keep pets away from the washing mach ine!
Dilute viscous fabric softe ner and fabric conditioner w ith water.
This prevents blockages.
ʑDisplay symbols
ʑDisplay information
*Before starting a progr amme, the
max. load for the selected
programme is displayed w hen the
door is open. The remaining time o r
finish-in time is displayed when the
door is closed.
Display shown may vary depending
on the model and selected
programme.
ʑOption buttons
You can change the spin speed and temperature beforehand and while the selected
programme is running. The effects dependin g on the progress of the programme.
°C (Temp.)
You can change the indicated wa shing temperature. The maximum washin g temperature
which can be selected depends on the programme that has been chosen .
(Finish in)
When you select a programme, the r espective programme duration is displ ayed. You can
delay the start of the programme before i t begins. The finish-in time indicates whe n the
programme will be finished. It can be set in hou r increments up to a maximum of 24h. Press
and hold the (Finish in) button until the required numbe r of hours is shown (h=hour).
Select Start/Pause $.
þWashing:Not on if Rinse, Spin or Drain is selected.
Rinse:Not on if Spin or Pump is selected.
Spin:Not on if a programme wi th the setting (no
final spin) is selected.
Water tap:Flashing - tap not ope n or no water
supply.
on – low water pressure.
Door:On if door can be o pened.
Overdosage: On if too much detergent us ed.
Automatic load detection: A utomatically
detects the load size a fter water inlet phase and sets
accurate remaining time. Symbols indicat e small, middle
and full loads measured* according to the recommended
max. load of the selected programme.
* Automatic display of the detected load only for washing
programmes with a max. load recommendation > 3.0 kg
except for Rinse, Spin and Drain. Different t ypes of textiles
with different water absor ption rates may influenc e the
load display.
kg, e.g. kg:max. recommanded load for selected
programme apage 7, Programme overview
time, e.g. :remaining tim e
:finish-in time defined by user apage 5
: pause
: door can be opened in Pause status
:end of programme
: end of programme with the setting
set volume of signals apage 6
: error display apage 10
Removing laundry
– Open washing machine door and remove laundry.
If (Rinse stop = wihout final spin) is active: Select the
spin speed or set programme se lector to Empty >or
Spin .
– Select Start/Pause $.
– Remove any foreign object s - risk of rusting.
Turn off the tap
Information on Aquastop.
Installation instructions. apage 7.
Switch off
– Set Programm selector to ÂOff.
Programmes
Detailed programme ov erview. apage 7
The temperature and sp in speed can be select ed
individually, irrespective of the selected programme and
programme progress.
PowerWash 60’ ?Hard–wea ring textiles
Cottons LFCottons Eco Easy-Care easy care textiles
Mix 1mixed types of lau ndry
Delicate/Silk silk and delicate washa ble fabrics
:Wool Ohand–/machine–wa shable wool
Rinse 2extra rinse with spin
Spin extra spin with sele ctable spin speed
Empty >drain the rinising water with (Rinse stop = no final spin)
Super Quick15’ @short progra mme
Sensitive hard–wearing textiles
Jeans dark-coloured textiles
Sports, Fitness $textiles m ade of microfibres
Shirts/Blouses non-iron shirts
Detergent drawer with
compartments I, II, ~Control panel
Door handle
Drum
Display information, Options, Functions Options, Functions
All buttons are sensitive and a
gentle tap is adequate!
If you press and hold the Option
buttons, the setting options
automatically scroll through.
Select Start/Pause $
 Washing
Serviceflap
If the #symbol lights up or
flashes in the display panel, the
childproof lock is active.
adeactivate, page 6
For additional functions and
option buttons, see the Individual
settings section. apage 5/6
Programme selector for
switching the machin e on
and off and for selecti ng the
programme. Can be rotate d
in either direction.
Read these instructions before switch ing on the washing machine.
Also follow the separate i nstallation instructions.
Observe the safety instr uctions on page 8.
7
Programme overview (see also the information on page 5, 6)

Programmes °C max.
(kg) *Type of laundry Additional functions; in formation
Cottons LF:90 °C 6,0* * Hard-wearing textiles, hea t-resistant textiles made of
cotton or linen 7Prewash,=Water plus,SEasy iron,Intensive
Cotton Eco :60 °C Sensitive :60 °C 5,5** Hard-wearing textiles madeof c otton or linen 7Prewa sh,=Water plus,SEasy iron,Intensive
For particularly sensitive skin,longer wa sh cycle at selected temperature, higher water level, additional rinse cycle.
PowerWash 60’ ?:- 60 °C 3,0 Hard-wea ring textiles made of cotton or blended fabric Time-controlled programme , 60 minutes.
Short prgrameme for nor mally soiled laundry.
Easy-Care :- 60 °C
3,5
Easy-Care textiles made of cotton, linen, synthe tic fibres or blended fabrics 7Prewash,=Water plus,SEasy iron
Mix 1:40 °C
Textiles made of cotton and easy-ca re textiles 7Prewash,=Water plus,SE asy iron,Intensive
Different types of textiles wh ich can be washed together.
JeanscDark-coloured fabrics made of cotton and dark easycare
fabrics 7Prewash,=Water plus,SEasy iron,Intens ive
Shirts/Blouses :60 °C
2,0
Non-iron shirts made of cotton, linen, synth etic fibres or blended fabrics 7Prewash,=Water plus,SEasy iron,Intensive
Short spin only, drip dr y.
Delicates/Silk :40 °C
For delicate, washable texitiles, e.g.made of si lk,sat in, synthetic fibres or blend ed fabrics 7Prewash,=Water plus ,SEasy iron
Short spin only between t he rinse cycles.
:Wool OHand- or machine- washable wool or wool-rich textiles .
Particulary gentle wash p rogramme to avoid shrinkage, longer programme breaks (laundry rests in the de tergent solution).
Sports, Fitness $Textiles for outdoor wear, ma de from microfibre 7Prewash,=Water plus,SEasy iron,Intensive Super Quick 15’ @Easy-Care text iles made of cotton, linen, synthetic fibres
or blended fabrics
Short programme ap prox. 15 minutes, suitable for lightly soiled laundry.
Additional programmes 6,0 Rinse 2,Spin ,Empty>The programmes are time-controlled for lightly soiled textiles. If textile sa re heavily soiled, reduce the load and select addit ional function, e.g. (Intensive).
Programmes without prew ash - pour deterge nt into dispenser II; programm es with prewash - divide detergent between dispensers Iand II.
* Ma x. load according to IEC 60456 Ed.4. ** Select the (In tensive)addi tional function if washing max. kg of cottons and coloureds.
For further information an d a selection of our products
go to our web site: h ttp://www.bosch-home.com
or contact our customer s ervice centres
Robert Bosch Hausgeräte GmbH
Carl -Wery-Str.34
D-81739 Munich/Germany
WLM20461BY WLM24441BY
9000634969
0211
Downloaded From WashingMachine-Manual.com Manuals

8
Safety instructions
– Read and fol low the operating and installa tion instructions and all other info rmation enclosed
with the washing machi ne.
– Retain doc uments for subseque nt use.
Risk of electric shock – Never pull out the mains plug by tug ging the power cord.
– Never in sert/pull out the mains p lug with damp hands.
Risk of death For wor n-out appliances :
– Pul l out the mains plug .
– Sever the p ower cord and discard t ogether with the plug.
– Destroy the lock on the w ashing machine door.
This will prevent children f rom locking themselves an d risking their
lives.
Risk of suffocation – K eep packaging, plastic film and packaging p arts out of the reach of
children.
Risk of poisioning – Keep detergents an d care products out of the rea ch of children.
Risk of explosion – I tems of laundry pretreated with cleaning agents containing solv ents,
e.g. stain remover /cleaning solvents m ay lead to an e xplosion after
being loaded into the was hing machine.
Rinse items of laundry thoroughly by hand b eforehand.
Risk of injury – W ashing machine door ma y become very hot.
– Take care when draining hot deterge nt solution.
– Do not climb onto the wash ing machine.
– Do not lean on the ope n washing machine door.
– Do not touc h the drum in case it is still spinning.
– Be caref ul when opening the de tergent drawer while the mac hine is
in operation.
Consumption values
Programme Additional
function Load Electricity
consumption
***
Water ***
Programme
duration
***
Cottons LF 30 °C —- 6.0kg 0.29kW h 57 l 1:33 h
Cottons LF 30 °C* Intensive 6.0 kg 0.31 kWh 57l 2:03 h
Cottons LF 40 °C —- 6.0kg 0.50kW h 57 l 1:38h
Cottons LF 40 °C* Intensive 6.0 kg 0.52 kWh 5 7 l 2:03 h
Cottons LF 60 °C —- 6.0kg 0.85kW h 57 l 1:43 h
Cottons LF 60 °C* Intensive 6.0 kg 0.89 kWh 57 l 2:03 h
Cottons LF 90 °C —- 6.0kg 1.81kW h 66 l 1:58h
Easy-Care 40 °C —- 3.5kg 0.45kW h 54 l 1:00h
Easy-Care 40 °C* Intensive 3.5 kg 0.49 kWh 54 l 1:20 h
Mix 140 °C —- 3.5kg 0.53kW h 50 l 1:03h
Delicate/Silk 30 °C —- 2.0kg 0.18kW h 26 l 0:39 h
:Wool O30 °C —- 2.0kg 0.14kW h 40 l 0:36h
* Programme setting for testing according to the currently valid version of EN604 56.
Note for comparative testing: for testing the test programmes, wash the specifi ed load using the maximum spin speed.
Programme Additional
function Load Annual energy
consumption Annual water consumpt ion
CottonsEco  40/60°C Intensive** 6/3kg 196kW h 8650 l
** Programmesetti ngfo rt esting and energy labelling in accordance with directive 2010/30/EU and cold water (15°C) .
*** The values deviate from the indicated values depending on water pressure, hardness , and inlet temperature, ambient
temperature, type, amount and soiling of th e laundry, detergent used, fluctuations in the power su pply and selected
additional functions.
9
Important information
Preparing/Protect ing the laundry and the mach ine
– Empty pockets.
– Look out for metal items (paperclips , etc.).
– Wash delicates in a net/bag (tights, curtains, under wired bras).
– Fasten zips, do up a ny buttons.
– Brush sand out of pockets and collars.
– Remove curtain fittings or in a l aundry bag.
Before washing for the first time
Do not load any laundry in to the machine. Turn on the tap. Add the following to compartme nt
II:
– approx. 1 litre water
– detergent (dosage according to th e manufacturer's instructions for light soiling and the
appropriate degree of water hardness )
Set the programme sele ctor to Easy-Care 60 °C and select Start/Pause $. At the end of
the programme, turn the programm e selector to ÂOff.
Laundry with diffe rent degrees of soiling
Wash new items separately.
Light Do not prewash.
If required, pretreat stains. Select (Intensive) additiona l function.
Heavy Load less laundry. Prewash.
If required, pretreat stains. Select (Intensive) additiona l function.
Soaking Load laundry of the same colour
Pour soaking agent/d etergent into dis penser II according to the manufcturer’s instructions.
Set Cottons LF30 °C programme and select Start/Pause $. A fter approx. 10 minutes,
select Start/Pause $. After the required soaking t ime, reselect Start/Pause uif the
programme is to be continued or change the programme.
Starching Laundry m ust not be treated with fa bric softener
Starching is possible in all washing programmes if liquid starch is used. Add starch to the
fabric softener dispenser ~in acco rdance with the manufacturer’s i nstructions.
Dyeing/bleaching
Dye in small quantities only. Sa lt can corrode stainless steel.
Observe the dye manufacturer’s instru ctions.
Do not bleach laundry in the wa shing machine.
10
Care
Machine housin g, control panel
– Wipe with a soft, damp cloth.
– Do not use a ny abrasive cloths, scourers or clea ning agents (stainless steel clea ners).
– Immediately remove laun dry and cleaning agent residues.
– Do not clean the app liance with a water jet.
Clean the deterg ent drawer .. .
... if it contains detergent or fabric softener residu es.
1. Pull out the drawer up to t he stop position, press down th e latch on the
insert and remove th e drawer completely .
2. Remove insert: pull in sert upwards with fing er.
3. Clean the detergent dispenser a nd the insert with water and a brush.
4. Refit the insert and secure in place (the cylinder should fit over the
guide pin).
5. Insert the detergent drawe r.
6. Leave the detergent drawer open s o that residual water can evaporate.
Drum
Leave the washing machine door open after washing so that the drum can dry.
Rust stains – use chlorine–fre e cleaning agent, not steel wo ol.
Descaling No laundry in the machine!
This is not necessary if the detergent is dosed correctly. However, if it is necessary, follow the
instructions of the descaler manufacturer. Suitable descaling products can be purchased
from our website or a fter-sales service. apage 13
Information on the display
Please close the door immediately becaus e of rising water level. In pause
status and are displayed alternately.
Door is locked due to safety reasons (water level and/or te mperature are too
high); in pause status, and are displayed alternately. If yo u need
to open the door, wait for the temperature to drop or drain the water (e.g. select
Emptyc>programme).
Door cannot be locked/unlocked due to high temperature of the door lock.
Wait a moment and try again.
Flashing (no water supply):
Tap turned on?
Inlet filter blocked ? Clean filte r. apage 11
Supply hose kinked or blocked ?
On (low water pressure):
Only information. No influence
on the programme process.
Clean drain pump; apage 11
outlet pipe/drainage hose blo cked.
other displays Switch off the appliance, wait 5 se conds and switch it back on.
If the display appears again , call the customer service apage 1 3
– Risk of electric shock!
Pull out the mains plug!
– Risk of explosion! No solvents!
11
Maintenance
Drain pump
– Set the programme selector to ÂOff, disconnect the mains plu g.
1. Open and remove the ser vice flap.
2. Release the drainage hose from the clip.
Remove the sealing plug from the d rainage hose, allow the detergent
solution to flow out. P ush the sealing cap back in.
3. Remove the pump cap . Remove foreign objects/loose debri s/fluff from
inside and clean the pump. (impelle rin the pump must be able to rotate) .
4. Clean any residual lye or fluff from the thread of the pump cap and
pump housing.
5. Attach the pump cap and screw it on tig ht until the stop, handle is upright.
Place the drainage hose back in the retainer.
6. Place the service flap back o n and close.
To prevent unused detergent from flowing straig ht into the drain during
the next wash cycle: pour 1 litre of wa ter into compartment II and start
the Empty >programme. Then s elect and start a ne w washing
programme with detergent as usual.
Filter in the wa ter inlet hose
Risk of electric shock
Do not immerse the Aqua-Stop safety device in water (it contains an electric valve).
Reduce the water pressure in the supply h ose:
1. Turn off the tap.
2. Select any p rogramme (except Spin /Empty >).
3. Touch Start/Pause $button and allow the programme to run for approx. 40 seconds.
4. Set the programm e selector to ÂOff.Disconnect the mains plug.
Clean the filter:
Standard
Aqua-Stop
Aqua-Secure
1. Remove the supply hose fro m the tap.
Clean the filter with a small brush.
or
on standard and Aqua-Secu re models:
Remove the hose from the rear, remove the filter
using pliers and clean t he filter.
2. Reconnect the supply hose and check if it is tight.
– Risk of scalding!
Allow detergent solution t o cool down!
– Turn off the tap!
12
What to do if ...
ʑWater is leaking out. – Fit/refit dr ainage hose correctly.
– Tighten the screw conne ction of the supply hose.
ʑNo water supply.
Detergent not dispensed.
–Start/Pause $not selected?
– Water tap not turne d on?
– Supply hose filter blocked? Clean the filter. apage 11
– Supply hose kinked or trap ped?
ʑWashing machine door cannot be
opened.
– Safety function ac tive. Programme stopped? apage 4
–(Rinse stop = no final spin) s elected? apage 6
– Can be opened by emergency r elease only. apage13
ʑProgramme does not start. – Start/Pause $or Finish-in time se lected?
– Washing machine door closed?
ʑDetergent solution is not drained. – Clean the drain pump. ap age 11
– Clean waste pipe and/or d rainage hose.
ʑWater not visible in the drum. – Not a fault - water below the visible area.
ʑSpin result not satisfactory. – Wash small and large items of laundry together.
–SEasy iron selected? apage 6
– Speed selected too lo w? apage 6
ʑSpin cycle performed several
times.
– Not a fault - unbalanced lo ad detection system adjusts
the imbalance.
ʑCompartment ~not rinsed out
completely.
– Remove th e insert. Clean detergent drawer and insert.
apage 10
ʑOdour formation in the washing
machine.
– Run the Cottons LF90 °C program me without
laundry.
– Use standard detergen t.
ʑFoam escapes from the detergent
drawer.
– Too much detergent used?
Mix 1 tablespoon of fabric softener with ½ litre of water
and pour into compartment II in the detergent drawer.
– Reduce detergent dosage for the next wash cycle.
ʑExcessive noise, vibrations and
“wandering” during spin cycle.
– Are the appliance feet fixed ?
Secure the appliance feet. aI nstallation instructions,
page 5
– Transport bolts remove d?
Remove transport bolts.
Installation instructions, page 3
ʑDisplay panel/indicator lamps do
not light up while the appliance is
running.
– Power failure/off? Interrupted programme will be
resumed when power returns.
– Circuit breaker tripped? Reset the circu it breaker/
change the fuse.
– If the fault occurs repeat edly, call the customer service.
ʑProgramme sequence longer than
usual.
– Not a fault - unbalanced lo ad detection system adjusts
imbalance by repeatedly distribu ting the laundry.
– Not a fault - foam detection system active - add s an
additional rinse cycle.
ʑDetergent residues on the la undry. – Occasional ly, phosphate-free detergents contain water-
insoluble residues.
– Select Rinse 2or brush the laundry after washing.
ʑIf you cannot correct a fault yourself or a repair is required:
– Turn the programme selec tor to ÂOff and pull the mains p lug out of the socket.
– Turn off the tap and call the c ustomer services. apage 13
13
Emergency release e.g. in t he event of powe r failure
Interrupted programme will be re sumed when power returns.
However, if the laundry has to be remo ved, the washing
machine door can be opened as follows:
Risk of scalding.
The detergent solutio n and laundry may b e hot.
If possible, leave it to cool down.
Do not reach into t he drum if it i s still rotating.
Do not open the washing machine door if water can be seen
through the glass.
– Set the pro gramme selector to ÂOff and disconnect the mains plug.
– Drain th e detergent solution. apage 11
– Pull the emergency release with a tool and release. The washing
machine door can then be open ed.
Customer service
ʑIf you cannot rectify t he fault yourself apage 1 2: What to do if ..., please contact our after-
sales service. We will always find a suitable solution and will avoid a visit from a service
technician wherever possible.
ʑThe contact details for all countries can be found in the en closed after-sales service directory.
ʑPlease give the customer service the product number (E-Nr.) and the producti on number
(FD) of the appliance.
Product number Production n umber
You will find the identificat ion plate containing
this information on the frame of the open door ,
and of the rating plate on the back of the
appliance.
Rely on the professionalism of the manufacturer. Please contact us.
This will ensure that t he repair is carried o ut by trained service tec hnicians who arrive
equipped with genuine spare p arts for your appliance.
Washing machine WLM20461BY
WLM24441BY
en Instruction manual
Downloaded From WashingMachine-Manual.com Manuals

1 2 $a$$$2$>$((#$#(#ʑa7=Sʑ$ʑ
ÂÂ#
aa
Clo
M
Correct installation according to
separate installation instructions.
Check the machine
– Never switch on a damaged machine!
– Inform your customer service!
Insert mains plug
With dry hands only!
Only hold the plug itself!
Turn on the tap
Compartment II: Detergent for the main wash, water softener,
bleach, stain remover
Your washing machine
Congratulations – You have opted for a modern, high–quality domestic
appliance manufactured by BOSCH. The washing machine is
distinguished by its economical use of water and energy.
Each appliance which leaves our factory has been inspected thoroughly
to ensure that it functions properly and is in perfect condition.
For further information about products, accessories, spare parts and
services visit our web site: www.bosch-home.com or contact our after-
sales service centres.
Environmentally friendly waste disposal All packaging must be disposed of in accordance with environmental
guidelines. This appliance is certified in accordance with European
Directive 2002/96/EEC on waste electrical and electronic equipment
(WEEE).This directive provides the framework for the EU-wide collection
and reuse of used appliances.
Intended use
Contents Page
ʋIntended use ...................................................................................... 1
ʋProgrammes ...................................................................................... 1
ʋPreparation ..................................................................................... 2/3
ʋSetting and adjusting programmes ............................................... 3
ʋWashing .......................................................................................... 3/4
ʋRemoving the laundry ...................................................................... 4
ʋDisplay information, Options, Functions ................................... 5/6
ʋProgramme overview......................................................................... 7
ʋSafety instructions ............................................................................. 8
ʋConsumption values ....................................................................... 8
ʋImportant information ....................................................................... 9
ʋCare ................................................................................................... 10
ʋInformation on the display panel...................................................10
ʋMaintenance .....................................................................................11
ʋWhat to do if ....................................................................................12
ʋEmergency release .......................................................................... 13
ʋCustomer service ........................................................................13
Protection of the environment/Conservation tips
–Always fill the washing machine with a maximum amount of
laundry for the relevant programme.
– Wash normally soiled laundry without prewash.
– Instead of the Cottons LF90 °C programme, select
Cottons Eco 60 °C and the (Intensive) additional function.
The cleaning result will be comparable, but energy consumption
will be significantly lower.
– Dose the detergent according to the manufacturer’s
instructions and water hardness.
– If the laundry is to be subsequently dried in a tumble dryer, select
a spin speed as specified by the dryer manufacturer.
Preparation a
Display panel/
Option buttons/
Additional functions
Programme selector
Compartment ~:Fabric softener, impregnating agent, starch
Compartment I: Detergent for pre–wash
ʋFor domestic use only.
ʋFor washing machine-washable fabrics in a detergent
solution.
ʋTo be operated with cold mains water and
commercially available low foam detergents and care
products which are suitable for use in washing
machines.
– Do not leave children unattended near the
washing machine!
– The washing machine is not to be used by
children or persons not familiar with the
operating instructions.
– Keep pets away from the washing machine!
ʑʑʑ$
þaaaa
>$aÂ
Programmes
Detailed programme overview. apage 7
The temperature and spin speed can be selected
individually, irrespective of the selected programme and
programme progress.
PowerWash 60’ ?Hard–wearing textiles
Cottons LFCottons Eco Easy-Care easy care textiles
Mix 1mixed types of laundry
Delicate/Silk silk and delicate washable fabrics
:Wool Ohand–/machine–washable wool
Rinse 2extra rinse with spin
Spin extra spin with selectable spin speed
Empty >drain the rinising water with (Rinse stop = no final spin)
Super Quick15’ @short programme
Sensitive hard–wearing textiles
Jeans dark-coloured textiles
Sports, Fitness $textiles made of microfibres
Shirts/Blouses non-iron shirts ~$

#aa
Programme selector for
switching the machine on
and off and for selecting the
programme. Can be rotated
in either direction.
Read these instructions before switching on the washing machine.
Also follow the separate installation instructions.
Observe the safety instructions on page 8.

LF:7=S::7=S?::7=S1:7=Sc7=S:7=S:7=S:O$7=S@2>
Downloaded From WashingMachine-Manual.com Manuals

3 4
Programme ended when ...
... Start/Pause $indicator light goes out and or
(if was selected, without final spin) is indicated
on the display panel, the buzzer sounds. Set volume of
buzzer. apage 6
Change the programme ...
If you have selected the wrong programme by mistake:
– Reselect the programme.
– Select Start/Pause $.
Pause the programme ...
– Touch the Start/Pause $button.
– Follow the instructions in the display field: when lights
up and appears in the display, the door can be
opened. If required, add /remove a laundry item; If
and are displayed alternately, the door cannot be
opened due to a high water level in drum or a high
temperature.
– Touch Start/Pause $button to continue the
programme.
... or terminate the programme
Programmes with high temperature:
– Cool down laundry: Select Rinse 2.
– Select Start/Pause $.
Programmes at lower temperature:
– Select Empty >or Spin .
– Select Start/Pause $.((#$#(#ʑa7=Sʑ$ʑ
ÂÂ#
Sorting and loading the laundry
Observe the care information provided by the manufacturer.
Sort according to the information on the care labels.
Sort according to type, colour, soiling and temperature.
Remove any foreign objects - risk of rusting.
Do not exceed the maximum load. apage 7
Observe the instructions in the Important information section. apage 9
Load both large and small items of laundry.
lose the washing machine door. Take care not to trap any items of clothing
between the loading door and rubber seal.
Add detergent and care product
Add the appropriate dose according to:
Amount of laundry, soiling, water hardness (ask your water supply
company) and manufacturer’s instructions.
Models without insert for liquid detergent: pour liquid detergent into an
appropriate dispenser and place in the drum.
During operation: close the detergent drawer!
ʋʋʋʋʋʋʋʋʋʋʋʋʋʋʋʋʋLFBefore washing for the first time,
wash once without any laundry apage 9
Setting and adjusting programmes
Start/
Pause
1
2
3
Washing
~ʋʋʋ
Dilute viscous fabric softener and fabric conditioner with water.
This prevents blockages.
ʑʑʑ$
þaaaa
Removing laundry
– Open washing machine door and remove laundry.
If (Rinse stop = wihout final spin) is active: Select the
spin speed or set programme selector to Empty >or
Spin .
– Select Start/Pause $.
– Remove any foreign objects - risk of rusting.
Turn off the tap
Information on Aquastop.
Installation instructions. apage 7.
Switch off
– Set Programm selector to ÂOff.
a?LF1:O2>@$Detergent drawer with
compartments I, II, ~Control panel
Door handle
Drum
All buttons are sensitive and a
gentle tap is adequate!
If you press and hold the Option
buttons, the setting options
automatically scroll through.
Select Start/Pause $
 Washing
Serviceflap
If the #symbol lights up or
flashes in the display panel, the
childproof lock is active.
adeactivate, page 6
For additional functions and
option buttons, see the Individual
settings section. apage 5/6

LF:7=S::7=S?::7=S1:7=Sc7=S:7=S:7=S:O$7=S@2>
Downloaded From WashingMachine-Manual.com Manuals

56
$a$$
$2$>$(Spin speed)
You can change the indicated spin speed. The maximum spin speed which can be selected
depends on the chosen programme. If is selected, the load is held in the rinsing water.
((Childproof lock) Programme cannot be changed by accidental operation.
To activate the childproof lock:
– After the programme starts, press and hold the (button for 5 seconds;
– Release when the #symbol lights up.
When the programme ends, the Start/Pause $indicator remains on to remind you to
deactivate the childproof lock.
*#symbol flashes if the programme has been changed while childproof lock is activated.
To deactivate the childproof lock:
– Touch the (button until the #symbol turns off;
– Release the button.
If the childproof lock is deactivated while the programme selector is in a different position
from when the childproof lock was activated*, the running programme will be halted.
ʑAdditional functions see also Programme overview apage 7
7Pre-wash For heavily soiled, hard-wearing textiles. Pre-wash at
max. 30 °C.
=Water plus High water level to achieve better rinse result.
SEasy iron Special spin sequence with subsequent fluffing. Gentle
final spin - residual moisture in the laundry increased
slightly.
Intensive Extends the washing time for a more intensive washing
of heavily soiled items.
The additional function indicator light is on when the option is selected; if the option is not
selectable for the programme, this is indicated by a short flashing of the light and an
accoustic signal.
ʑStart/Pause $For starting or pausing the programme.
ʑSignals
Set to ÂPress and
hold
1 step
clockwise
Button signals Information signals
Set volume* Set volume*1 step
clockwise
Set to Â1. Start signal
mode
2. Set volume for ...
Release
#
*If required, set repeatedly
1 step
clockwise
direct
aa
ʋʋʋʋʋʋʋʋʋʋʋʋʋʋʋʋʋLFa~ʋʋʋʑDisplay symbols
ʑDisplay information
*Before starting a programme, the
max. load for the selected
programme is displayed when the
door is open. The remaining time or
finish-in time is displayed when the
door is closed.
Display shown may vary depending
on the model and selected
programme.
ʑOption buttons
You can change the spin speed and temperature beforehand and while the selected
programme is running. The effects depending on the progress of the programme.
°C (Temp.)
You can change the indicated washing temperature. The maximum washing temperature
which can be selected depends on the programme that has been chosen.
(Finish in)
When you select a programme, the respective programme duration is displayed. You can
delay the start of the programme before it begins. The finish-in time indicates when the
programme will be finished. It can be set in hour increments up to a maximum of 24h. Press
and hold the (Finish in) button until the required number of hours is shown (h=hour).
Select Start/Pause $.
þWashing:Not on if Rinse, Spin or Drain is selected.
Rinse:Not on if Spin or Pump is selected.
Spin:Not on if a programme with the setting (no
final spin) is selected.
Water tap:Flashing - tap not open or no water
supply.
on – low water pressure.
Door:On if door can be opened.
Overdosage: On if too much detergent used.
Automatic load detection: Automatically
detects the load size after water inlet phase and sets
accurate remaining time. Symbols indicate small, middle
and full loads measured* according to the recommended
max. load of the selected programme.
* Automatic display of the detected load only for washing
programmes with a max. load recommendation > 3.0 kg
except for Rinse, Spin and Drain. Different types of textiles
with different water absorption rates may influence the
load display.
kg, e.g. kg:max. recommanded load for selected
programme apage 7, Programme overview
time, e.g. :remaining time
:finish-in time defined by user apage 5
: pause
: door can be opened in Pause status
:end of programme
: end of programme with the setting
set volume of signals apage 6
: error display apage 10

>$aÂ
a?LF1:O2>@$~Display information, Options, Functions Options, Functions
$

#aa

LF:7=S::7=S?::7=S1:7=Sc7=S:7=S:7=S:O$7=S@2>
Downloaded From WashingMachine-Manual.com Manuals

$a$$$2$>$((#$#(#ʑa7=Sʑ$ʑÂÂ#
aa
ʋʋʋʋʋʋʋʋʋʋʋʋʋʋʋʋʋLFa~ʋʋʋʑʑʑ$þaaaa>$aÂ
a?LF1:O2>@$~$

#aa
7
Programme overview (see also the information on page 5, 6)

Programmes °C max.
(kg) *Type of laundry Additional functions; information
Cottons LF:90 °C 6,0** Hard-wearing textiles, heat-resistant textiles made of
cotton or linen 7Prewash,=Water plus,SEasy iron,Intensive
Cotton Eco :60 °C Sensitive :60 °C 5,5** Hard-wearing textiles made of cotton or linen 7Prewash,=Water plus,SEasy iron,Intensive
For particularly sensitive skin, longer wash cycle at selected temperature, higher water level, additional rinse cycle.
PowerWash 60’ ?:- 60 °C 3,0 Hard-wearing textiles made of cotton or blended fabric Time-controlled programme, 60 minutes.
Short prgrameme for normally soiled laundry.
Easy-Care :- 60 °C
3,5
Easy-Care textiles made of cotton, linen, synthetic fibres or blended fabrics 7Prewash,=Water plus,SEasy iron
Mix 1:40 °C
Textiles made of cotton and easy-care textiles 7Prewash,=Water plus,SEasy iron,Intensive
Different types of textiles which can be washed together.
JeanscDark-coloured fabrics made of cotton and dark easycare
fabrics 7Prewash,=Water plus,SEasy iron,Intensive
Shirts/Blouses :60 °C
2,0
Non-iron shirts made of cotton, linen, synthetic fibres or blended fabrics 7Prewash,=Water plus,SEasy iron,Intensive
Short spin only, drip dry.
Delicates/Silk :40 °C
For delicate, washable texitiles, e.g.made of silk, satin, synthetic fibres or blended fabrics 7Prewash,=Water plus,SEasy iron
Short spin only between the rinse cycles.
:Wool OHand- or machine- washable wool or wool-rich textiles.
Particulary gentle wash programme to avoid shrinkage, longer programme breaks (laundry rests in the detergent solution).
Sports, Fitness $Textiles for outdoor wear, made from microfibre 7Prewash,=Water plus,SEasy iron,Intensive Super Quick 15’ @Easy-Care textiles made of cotton, linen, synthetic fibres
or blended fabrics
Short programme approx. 15 minutes, suitable for lightly soiled laundry.
Additional programmes 6,0 Rinse 2,Spin ,Empty>The programmes are time-controlled for lightly soiled textiles. If textiles are heavily soiled, reduce the load and select additional function, e.g. (Intensive).
Programmes without prewash - pour detergent into dispenser II; programmes with prewash - divide detergent between dispensers Iand II.
* Max. load according to IEC 60456 Ed.4. ** Select the (Intensive) additional function if washing max. kg of cottons and coloureds.
For further information and a selection of our products
go to our web site: http://www.bosch-home.com
or contact our customer service centres
Robert Bosch Hausgeräte GmbH
Carl -Wery-Str.34
D-81739 Munich/Germany
WLM20461BY WLM24441BY
9000634969
0211
Downloaded From WashingMachine-Manual.com Manuals

8
Safety instructions
– Read and follow the operating and installation instructions and all other information enclosed
with the washing machine.
– Retain documents for subsequent use.
Risk of electric shock – Never pull out the mains plug by tugging the power cord.
– Never insert/pull out the mains plug with damp hands.
Risk of death For worn-out appliances:
– Pull out the mains plug.
– Sever the power cord and discard together with the plug.
– Destroy the lock on the washing machine door.
This will prevent children from locking themselves and risking their
lives.
Risk of suffocation – Keep packaging, plastic film and packaging parts out of the reach of
children.
Risk of poisioning – Keep detergents and care products out of the reach of children.
Risk of explosion – Items of laundry pretreated with cleaning agents containing solvents,
e.g. stain remover/cleaning solvents may lead to an explosion after
being loaded into the washing machine.
Rinse items of laundry thoroughly by hand beforehand.
Risk of injury – Washing machine door may become very hot.
– Take care when draining hot detergent solution.
– Do not climb onto the washing machine.
– Do not lean on the open washing machine door.
– Do not touch the drum in case it is still spinning.
– Be careful when opening the detergent drawer while the machine is
in operation.
Consumption values
Programme Additional
function Load Electricity
consumption
***
Water ***
Programme
duration
***
Cottons LF 30 °C —- 6.0 kg 0.29 kWh 57 l 1:33 h
Cottons LF 30 °C* Intensive 6.0 kg 0.31 kWh 57 l 2:03 h
Cottons LF 40 °C —- 6.0 kg 0.50 kWh 57 l 1:38 h
Cottons LF 40 °C* Intensive 6.0 kg 0.52 kWh 57 l 2:03 h
Cottons LF 60 °C —- 6.0 kg 0.85 kWh 57 l 1:43 h
Cottons LF 60 °C* Intensive 6.0 kg 0.89 kWh 57 l 2:03 h
Cottons LF 90 °C —- 6.0 kg 1.81 kWh 66 l 1:58 h
Easy-Care 40 °C —- 3.5 kg 0.45 kWh 54 l 1:00 h
Easy-Care 40 °C* Intensive 3.5 kg 0.49 kWh 54 l 1:20 h
Mix 140 °C —- 3.5 kg 0.53 kWh 50 l 1:03 h
Delicate/Silk 30 °C —- 2.0 kg 0.18 kWh 26 l 0:39 h
:Wool O30 °C —- 2.0 kg 0.14 kWh 40 l 0:36 h
* Programme setting for testing according to the currently valid version of EN60456.
Note for comparative testing: for testing the test programmes, wash the specified load using the maximum spin speed.
Programme Additional
function Load Annual energy
consumption Annual water consumption
Cottons Eco  40/60°C Intensive** 6/3 kg 196 kWh 8650 l
** Programme setting for testing and energy labelling in accordance with directive 2010/30/EU and cold water (15°C).
*** The values deviate from the indicated values depending on water pressure, hardness, and inlet temperature, ambient
temperature, type, amount and soiling of the laundry, detergent used, fluctuations in the power supply and selected
additional functions.
9
Important information
Preparing/Protecting the laundry and the machine
– Empty pockets.
– Look out for metal items (paperclips, etc.).
– Wash delicates in a net/bag (tights, curtains, underwired bras).
– Fasten zips, do up any buttons.
– Brush sand out of pockets and collars.
– Remove curtain fittings or in a laundry bag.
Before washing for the first time
Do not load any laundry into the machine. Turn on the tap. Add the following to compartment
II:
– approx. 1 litre water
– detergent (dosage according to the manufacturer's instructions for light soiling and the
appropriate degree of water hardness)
Set the programme selector to Easy-Care 60 °C and select Start/Pause $. At the end of
the programme, turn the programme selector to ÂOff.
Laundry with different degrees of soiling
Wash new items separately.
Light Do not prewash.
If required, pretreat stains. Select (Intensive) additional function.
Heavy Load less laundry. Prewash.
If required, pretreat stains. Select (Intensive) additional function.
Soaking Load laundry of the same colour
Pour soaking agent/detergent into dispenser II according to the manufcturer’s instructions.
Set Cottons LF30 °C programme and select Start/Pause $. After approx. 10 minutes,
select Start/Pause $. After the required soaking time, reselect Start/Pause uif the
programme is to be continued or change the programme.
Starching Laundry must not be treated with fabric softener
Starching is possible in all washing programmes if liquid starch is used. Add starch to the
fabric softener dispenser ~in accordance with the manufacturer’s instructions.
Dyeing/bleaching
Dye in small quantities only. Salt can corrode stainless steel.
Observe the dye manufacturer’s instructions.
Do not bleach laundry in the washing machine.
ac>aaa
Â>>$Âʑʑ$aʑaaaʑ$ʑaʑʑSaaʑʑ~aʑLFʑʑaʑʑʑ2ʑÂaÂaʑaʑʑ
Downloaded From WashingMachine-Manual.com Manuals

LFLFLFLFLFLFLF1:O
 $ÂLF$$u~
10
Care
Machine housing, control panel
– Wipe with a soft, damp cloth.
– Do not use any abrasive cloths, scourers or cleaning agents (stainless steel cleaners).
– Immediately remove laundry and cleaning agent residues.
– Do not clean the appliance with a water jet.
Clean the detergent drawer ...
... if it contains detergent or fabric softener residues.
1. Pull out the drawer up to the stop position, press down the latch on the
insert and remove the drawer completely .
2. Remove insert: pull insert upwards with finger.
3. Clean the detergent dispenser and the insert with water and a brush.
4. Refit the insert and secure in place (the cylinder should fit over the
guide pin).
5. Insert the detergent drawer.
6. Leave the detergent drawer open so that residual water can evaporate.
Drum
Leave the washing machine door open after washing so that the drum can dry.
Rust stains – use chlorine–free cleaning agent, not steel wool.
Descaling No laundry in the machine!
This is not necessary if the detergent is dosed correctly. However, if it is necessary, follow the
instructions of the descaler manufacturer. Suitable descaling products can be purchased
from our website or after-sales service. apage 13
Information on the display
Please close the door immediately because of rising water level. In pause
status and are displayed alternately.
Door is locked due to safety reasons (water level and/or temperature are too
high); in pause status, and are displayed alternately. If you need
to open the door, wait for the temperature to drop or drain the water (e.g. select
Emptyc>programme).
Door cannot be locked/unlocked due to high temperature of the door lock.
Wait a moment and try again.
Flashing (no water supply):
Tap turned on?
Inlet filter blocked ? Clean filter. apage 11
Supply hose kinked or blocked ?
On (low water pressure):
Only information. No influence
on the programme process.
Clean drain pump; apage 11
outlet pipe/drainage hose blocked.
other displays Switch off the appliance, wait 5 seconds and switch it back on.
If the display appears again, call the customer service apage 13
– Risk of electric shock!
Pull out the mains plug!
– Risk of explosion! No solvents!
11
Maintenance
Drain pump
– Set the programme selector to ÂOff, disconnect the mains plug.
1. Open and remove the service flap.
2. Release the drainage hose from the clip.
Remove the sealing plug from the drainage hose, allow the detergent
solution to flow out. Push the sealing cap back in.
3. Remove the pump cap. Remove foreign objects/loose debris/fluff from
inside and clean the pump. (impeller in the pump must be able to rotate).
4. Clean any residual lye or fluff from the thread of the pump cap and
pump housing.
5. Attach the pump cap and screw it on tight until the stop, handle is upright.
Place the drainage hose back in the retainer.
6. Place the service flap back on and close.
To prevent unused detergent from flowing straight into the drain during
the next wash cycle: pour 1 litre of water into compartment II and start
the Empty >programme. Then select and start a new washing
programme with detergent as usual.
Filter in the water inlet hose
Risk of electric shock
Do not immerse the Aqua-Stop safety device in water (it contains an electric valve).
Reduce the water pressure in the supply hose:
1. Turn off the tap.
2. Select any programme (except Spin /Empty >).
3. Touch Start/Pause $button and allow the programme to run for approx. 40 seconds.
4. Set the programme selector to ÂOff.Disconnect the mains plug.
Clean the filter:
Standard
Aqua-Stop
Aqua-Secure
1. Remove the supply hose from the tap.
Clean the filter with a small brush.
or
on standard and Aqua-Secure models:
Remove the hose from the rear, remove the filter
using pliers and clean the filter.
2. Reconnect the supply hose and check if it is tight.
– Risk of scalding!
Allow detergent solution to cool down!
– Turn off the tap!
ʑʑ$aʑaaaʑ$ʑaʑʑSaaʑʑ~aʑLFʑʑaʑʑʑ2ʑÂa
Âaʑaʑʑ
Downloaded From WashingMachine-Manual.com Manuals

LFLFLFLFLFLFLF1:O
 $ÂLF$$u~ac>aaaÂ>>$Â
12
What to do if ...
ʑWater is leaking out. – Fit/refit drainage hose correctly.
– Tighten the screw connection of the supply hose.
ʑNo water supply.
Detergent not dispensed.
–Start/Pause $not selected?
– Water tap not turned on?
– Supply hose filter blocked? Clean the filter. apage 11
– Supply hose kinked or trapped?
ʑWashing machine door cannot be
opened.
– Safety function active. Programme stopped? apage 4
–(Rinse stop = no final spin) selected? apage 6
– Can be opened by emergency release only. apage13
ʑProgramme does not start. – Start/Pause $or Finish-in time selected?
– Washing machine door closed?
ʑDetergent solution is not drained. – Clean the drain pump. apage 11
– Clean waste pipe and/or drainage hose.
ʑWater not visible in the drum. – Not a fault - water below the visible area.
ʑSpin result not satisfactory. – Wash small and large items of laundry together.
–SEasy iron selected? apage 6
– Speed selected too low? apage 6
ʑSpin cycle performed several
times.
– Not a fault - unbalanced load detection system adjusts
the imbalance.
ʑCompartment ~not rinsed out
completely.
– Remove the insert. Clean detergent drawer and insert.
apage 10
ʑOdour formation in the washing
machine.
– Run the Cottons LF90 °C programme without
laundry.
– Use standard detergent.
ʑFoam escapes from the detergent
drawer.
– Too much detergent used?
Mix 1 tablespoon of fabric softener with ½ litre of water
and pour into compartment II in the detergent drawer.
– Reduce detergent dosage for the next wash cycle.
ʑExcessive noise, vibrations and
“wandering” during spin cycle.
– Are the appliance feet fixed?
Secure the appliance feet. aInstallation instructions,
page 5
– Transport bolts removed?
Remove transport bolts.
Installation instructions, page 3
ʑDisplay panel/indicator lamps do
not light up while the appliance is
running.
– Power failure/off? Interrupted programme will be
resumed when power returns.
– Circuit breaker tripped? Reset the circuit breaker/
change the fuse.
– If the fault occurs repeatedly, call the customer service.
ʑProgramme sequence longer than
usual.
– Not a fault - unbalanced load detection system adjusts
imbalance by repeatedly distributing the laundry.
– Not a fault - foam detection system active - adds an
additional rinse cycle.
ʑDetergent residues on the laundry. – Occasionally, phosphate-free detergents contain water-
insoluble residues.
– Select Rinse 2or brush the laundry after washing.
ʑIf you cannot correct a fault yourself or a repair is required:
– Turn the programme selector to ÂOff and pull the mains plug out of the socket.
– Turn off the tap and call the customer services. apage 13
13
Emergency release e.g. in the event of power failure
Interrupted programme will be resumed when power returns.
However, if the laundry has to be removed, the washing
machine door can be opened as follows:
Risk of scalding.
The detergent solution and laundry may be hot.
If possible, leave it to cool down.
Do not reach into the drum if it is still rotating.
Do not open the washing machine door if water can be seen
through the glass.
– Set the programme selector to ÂOff and disconnect the mains plug.
– Drain the detergent solution. apage 11
– Pull the emergency release with a tool and release. The washing
machine door can then be opened.
Customer service
ʑIf you cannot rectify the fault yourself apage 12: What to do if ..., please contact our after-
sales service. We will always find a suitable solution and will avoid a visit from a service
technician wherever possible.
ʑThe contact details for all countries can be found in the enclosed after-sales service directory.
ʑPlease give the customer service the product number (E-Nr.) and the production number
(FD) of the appliance.
Product number Production number
You will find the identification plate containing
this information on the frame of the open door ,
and of the rating plate on the back of the
appliance.
Rely on the professionalism of the manufacturer. Please contact us.
This will ensure that the repair is carried out by trained service technicians who arrive
equipped with genuine spare parts for your appliance.
Downloaded From WashingMachine-Manual.com Manuals

LFLFLFLFLFLFLF1:O
 $ÂLF$$u~ac>aaaÂ>>$Âʑʑ$aʑaaaʑ$ʑaʑʑSaaʑʑ~aʑLFʑʑaʑʑʑ2ʑÂaÂaʑaʑʑ
Washing machine WLM20461BY
WLM24441BY
en Instruction manual
Downloaded From WashingMachine-Manual.com Manuals
