Bose 321 GSX Series III User manual

DVD HOME ENTERTAINMENT SYSTEM
Owner's Guide
Guia de usario
Notice d'utilisation

SAFETY INFORMATION
Please read this owner's guide
Please take the time to follow this owner's guide carefully. It will help you set up
and operate your system properly and enjoy all of its advanced features. Save
this owner's guide for future reference.
,_ WARNING: 7-oreduce the risk of fire or electn'c shock, do not expose the system
to rain or moisture.
,_ WARNING: Do not expose this apparatus to dripping or splashing, and do not
place objects filled with h'quids, such as vases, on or near the apparatus. As with
any electronic product, use care not to spffl h'quids in any part of the system.
Liquids can cause a failure and/or a fire hazard.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER {OR BACK),
NO USER-SERVICABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED PERSONNEL.
ATTENTION : POUR REDUIRE LE RISQUE DE DECHARGE
[_LEO FRIQUE, NE RL [|REZ PAS LE COUVERCLE (OU
L'ARRI_RE), IL RE SE TROUVE A L'INT_RIEUR AiJCUNE
PI_CE POQVANT _TRE R_PAR_E PAR L'USAGER,
S'ADRESSER A UN REPARATEUR COMPETEN [,
A
The CAUTION marks shown here are located on the bottom of your 3.2.1 <_home
entertainment system media center and the rear panel of the
Acoustimass _ module:
The lightning flash with arrowhead symbol within an equilateral triangle
alerts the user to the presence of uninsulated, dangerous voltage within
the system enclosure that may be of sufficient magnitude to constitute a
risk of electric shock.
The exclamation point within an equilateral triangle alerts the user to the
presence of important operating and maintenance instructions in this
owner's guide.
,_ CAUTION: T_ prevent electric shock, match wide blade of plug to wkJe slot,
insert fully,
CAUTION: Do not place any naked flame sources, such as lighted candes, on or
near the apparatus.
Class 1 laser product
['--'i
CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LUOKAN I LASER LAITE
KLASS I LASER APPARAT
This CD player is classified as a CLASS 1 LASER PRODUCT according to
EN 60825-1:1994+A1 +A2, IEC60825-1:1993+A1 +A2.
CAUTION: Use of controls or adjustments or performance of procedures other
than those specified herein may result in hazardous radiation exposure. The DVf)
player shouM not be adjusted or repalTed by anyone except properly qualified
service personneL
Class B emissions limits
This Class B digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations.
Batteries
Please dispose of used batteries properly, following any local regulations. Do not
incinerate.
This product conforms to the EMC Directive 2004/108/EC and to the Low Voltage
Directive 2006/95/EC. The complete Declaration of Conformity can be found at:
www.Bose.com/static/compliance/index.html.
Additional safety information
See the additional instructions on the Important Safety Information sheet
enclosed in the shipping carton.

INTRODUCTION
Before you begin .........................
For your records ........................
Unpacking ..............................
2
2
3
4
CONTENTS
FIRST TIME USE 33
Trying out the DVD ........................ 33
CONTROLS AND INDICATORS 34
SETUP
_ Placing the system components 6
_ Connecting the speakers to the module 8
_ Connecting the module to the media center 10
_ Connecting the system video to your TV 12
_ Connecting a cable box or other component 17
To connect another component .............
To get digital audio from the component .....
To use video pass through ................
6
19
20
21
The remote control ........................ 34
Power and source buttons ................ 35
Menu and movement buttons .............. 36
Play and numeric buttons ................. 37
Record and A,B,C buttons
(not in Europe) .......................... 38
Colored buttons
(in Europe only) .........................
uMusic ®buttons ........................
The media center .........................
Display ................................
Disc tray ...............................
Connecting audio from TV as an option 22
your mmm
_ Installing the FM and AM radio antennas 25
_ Connecting the module to outlet 28
power
_ Setting the remote to control TV
your
and components ......................... 30
Inserting the remote batteries .............. 30
Setting the remote for your TV ............. 31
Controlling another component ............ 32
38
38
39
39
39
OPERATION 40
Playing a video disc or CD .................. 40
Selecting a play option ................... 40
Keeping your discs clean ................. 41
Checking for disc compatibility ............. 42
For DVDs: Setting Parental Control .......... 42
Choosing a password ..................... 42
Setting a restriction level .................. 43
Ratings supplied by the MPAA .............. 43
iii

REFERENCE 60
Playing a cable box or other component ....... 44
Adjusting for audio delay ................. 44
Getting digital audio from a source ......... 45
Choosing other options .................. 45
Listening to the radio ...................... 46
Creating a preset ....................... 46
Removing a station from a preset ........... 46
ADJUSTMENTS TO THE PERFORMANCE 47
Changing system features .................. 47
To get to the System menu ................ 47
Selecting a new option ................... 48
Audio options .......................... 49
Video options .......................... 50
Media center options .................... 52
Stored CDs options ..................... 54
Choosing new settings .................... 56
To get to the Settings menu ............... 56
Settings options ....................... 57
Replacing remote batteries .................. 60
Protecting the system ...................... 60
Cleaning the media center ................. 60
Cleaning the speakers .................... 60
Troubleshooting .......................... 61
For Customer Service ...................... 65
Limited warranty .......................... 65
Technical Information ...................... 65
END USER LICENSE AGREEMENT 70
COPYRIGHT AND LICENSE PROTECTIONS 71
DEVICE CODES A-1
iv

INTRODUCTION
Before you begin
Thank you for purchasing the 3.2.1 ®DVD home
entertainment system. Using Bose®proprietary signal
processing technology, the 3.2.1 system provides
improved spaciousness from stereo recordings and
bold movie effects for surround-sound sources.
System features include:
* Small, easy-to-place shelf speakers
* Easy-to-hide Acoustimass ®module
° Integrated DVD/CD player and AM/FM tuner
* Remote and media center controls
* HDMI video connection to your TV
* Audio In connectors for three components
* Your choice of language for text displays
* New ways to enjoy your favorite CD tracks
with the uMusic ®intelligent playback system
What is a uMusic system?
This system features breakthrough Bose technology
that enables you to:
•Store your favorite music in a library with capacity for
approximately 200 hours of music (about 200 CDs).
•Teach the system which tracks you like or dislike, so it
automatically plays the music you want to hear most.
2

INTRODUCTION
For your records
As you unpack the system, look for the serial numbers
on the rear of the Acoustimass ®module and the bottom
of the media center.
This is a good time to record the serial numbers on the
lines below and on your product registration card. You
may need them if you ever contact Bose®Customer
Service.
Acoustimass module serial number:
Media center serial number:
Dealer name:
Acoustimass module serial number Dealer phone:
Purchase date:
Media Center serial number
We suggest you keep your sales receipt and the
warranty information (on the product registration card)
together with this owner's guide.

INTRODUCTION
Carefully unpack your system. Save all packing
materials, which provide the safest way to transport your
system. Make sure your system includes the
parts shown.
WARNING: To avoid danger of suffocation, keep the
plastic bags out of the reach of children.
As you identify them, you may want to place a check
mark in the box next to the name of each part.
If any part of the system appears damaged, do not try to
use it. Notify Bose or your authorized Bose®dealer right
away. For contact information, refer to the address sheet
included in the carton.
[3 Media center [3 Speakers [3 Acoustimass ®module
4

INTRODUCTION
[3 Remote control and batteries [3 Rubber feet for
Acoustimass ®module [3 Rubber feet for speakers [3 Setup disc
[3 Speaker cable [3 Acoustimass module
cable [3 Acoustimass module
power cord [3 Stereo audio cable
[3 HDMI video cable [3 Composite video cable [3 AM antenna and stand [3 FM antenna

SETUP
The image below shows one of the many ways you can
position your new 3o2.1 ®system.
What you need to use:
Media center
Speakers
Acoustimass ®module
See Steps 1-6 for details.
6

=On the bottom of each speaker, attach one set of
small rubber feet.
2. Place the left and right speakers:
* at least 3 feet (1 meter) apart
* within 3 feet (1 meter) of the TV screen
* near the front edge of any shelf
* aimed straight ahead (not angled) to face the
listening area
3. On the legs of the Acoustimass ®module, attach the
large rubber feet.
SETUP
4. Place the Acoustimass module:
* at the same end of the room as the speakers and
your TV
* at least 3 feet (1 meter) from the TV to prevent
interference with the screen
* several feet (.8 meters) from audio or video tapes
to prevent magnetic damage to them
* standing upright, not lying on a side, the front, or
the back
* with the front port aimed out from or along a wall
for balanced performance
* hidden under a table, behind a sofa or chair, or
behind drapes as preferred
* NOT in an enclosure, on a bed, on a sofa, or on a
surface that can block the ventilation openings.
CAUTION: Do not block ventilation openings on the
bottom and rear of the module.
5. Place the media center:
* where nothing obstructs
the front panel
* near any components you
will connect
6. Continue with _ on the
next page.
7

SETUP
What you need to use:
_Speaker cable
Speakers
Acoustimass ®module
8
1. Notice the two plugs at one end of the speaker
cable.
2. Separate the two plugs so each one reaches a
speaker.
(Refer to _ for placement guidelines.)

SETUP
=Insert each plug into the connector on the proper
speaker.
The plug marked RIGHT goes into the speaker
placed to the right of your TV.
=Insert the remaining single plug into the connector
labeled SPEAKERS on the back of the Acousti-
mass ®module.
Fastener screws
5. Tighten each fastener screw by hand to secure
the plug.
CAUTION: Do not plug theAcoustimass module into an
AC power (mains) outlet until all other components are
connected.
6. Continue with _ on the next page.

SETUP
Connecting
the _odu[÷ to
the _÷dia center
What you need to use:
_Acoustimass ®module cable
Media center
1. Notice the arrow on the top of the multi-pin plug at
each end of the Acoustimass module cable.
2. Make sure you can see the arrow on top before you
insert either end of the cable.
Acoustimass module
10

SETUP
=Insert this plug into the connector labeled -4_
the back of the Acoustimass ®module. on =
=
On the other end of the cable, make sure you can
see the arrow on top of the plug.
Insert this plug into the connector labeled
Acoustimass Module on the back of the
media center.
6. Continue with _ on the next page.
Make sure the arrow on the plug faces up as you
insert it.
11

SETUP
,our TV
What you may need to use:
__cable OR
This connection allows you to see DVDs and other
video from the 3.2.1 ®system on your TV.
1. Select the HDMI video cable.
Media center
Your TV
12

SETUP
=Check to see if your TV has an unused HDMI
connector for VIDEO IN.
This may be located on the side or rear connector
panel of the TV.
HDMI
=Follow the directions that are appropriate
for your TV:
on page 14
or
on page 15
13

SETUP
=Insert one end of the HDMI cable into the HDMI
connector on your TV.
HDMI
=Insert the other end of this cable into the HDMI
connector on the media center.
Make sure the Bose ®logo shows as you insert the
plug.
Bose
logo
Match the wide side of the plug to the wide side
of the connector. =
HDMI
on page 17.
Continue with
Note: If you make this HDMI connection, you do not
need the suppfied yellow Composite video cable to make
any connections.
DO NOT use either of the two ONLY PASS-THROUGH
connectors on the back of the media center for video from
a component.Neither S-Video nor Composite signals can
pass through the HDMI cable to the -i3Z.
14

SETUP
1. Notice the yellow plug at each end of the
Composite video cable.
Yellow
Yellow
Note: There may be other kinds of video connectors on
your TV that offer higher resolution than Composite.
To use either S-Video or Component connectors, you
need the appropriate cables. These cables are available
at most electronics stores.
2. Plug the Composite video cable into the yellow
VIDEO IN connector on your TV.
Yellow
(Composite)
l
Yellow
(Composite)
Note: If there isjust one Composite Video In connector
on your T!4,it may be in use already for another video
component. You can disconnect that component from
the -i%,and see "Touse video pass through" on page 21.
15

SETUP
=Insert the other end into the yellow Composite
VIDEO OUT connector on the back of the
media center.
.a
Note:/fyou make this Composite connection, you can
use the ONLY PASS-THROUGH connector on the media
center for video from another component. See "To use
video pass through" on page 21 for further information.
4. Continue with _ on the next page.
16

SETUP
Connecting
a cable box
What you need to use:
_Stereo audio cable
Or
You can listen to another sound source -- like a cable
or satellite box -- through the 3,2,1 ®speakers instead
of your TV.
This requires an audio connection only. Leave the video
from your component connected to your TV.
C2D
5. Select the audio cable that has red and white plugs
at each end.
Media center
Your cable box, satellite box,
or other component
-- White plug
Red plug
17
