Boundless Technology TERA User manual

TERA
MANUAL

Table of Contents
Page #
3 - What is Included
4 - About the Tera
6 - Key Features
8 - What is in a Tera device?
9 - How the Tera Works
10 - How to Turn the Tera ‘ON’
11 - Using the Temperature
12 - Mouthpiece Components
13 - How to remove the
Mouthpiece
15 - How to Load Herb and
Concentrate
16 - How to Use the WPA
18 - How to Clean the Tera
20 - Battery and Charging
23 - Warranty
26 - Safety Disclaimers
30 - Contact Information
2

What Is Included
—(1) Tera Unit
— (1) Swivel Mouthpiece
—(1) Glass Mouthpiece
—(2) LG 18650 2500 mAh
Batteries
— (1) Water Pipe Adapter
—(5) Stainless Steel
Chamber Screens
—(1) Stainless Steel Mesh
Concentrate Pads
—(2) Mouthpiece Screens
—(1) Cleaning Brush
—(1) Packing Tool
—(1) USB Charger
— (1) User Manual
3

About the Tera
The Tera is the newest aromatherapy
device addition to the Boundless
line. Small enough to comfortably t
in the palm of your hand, the Tera
delivers truly powerful smooth
clouds from the rst draw. Featuring
two removable 18650 batteries, the
unit can also be charged via USB. The
Tera is perfect for on the go use and
can also be attached to a glass water
pipe using the Boundless water pipe
adapter. This portable aromatherapy
device uses convection heated air
and radiative heat transfer to
eciently vaporize your materials.
This means that
there is a complete
separation between
the heating element
and the herb
chamber.
4

Answering to the demands of our
customers we have included a
chamber which produces full and
thick clouds in less than sixty
seconds. The Tera encompasses an
stainless steel convection chamber
which is designed to heat up quickly
to the desired temperature while
evenly vaporizing terpenes and
cannabinoids. The unit comes
equipped with full temperature
control ranging from 104°F-428°F
(40°C-220°C). Also, featuring a fully
rotatable mouthpiece with an
improved airow, there is also the
option to interchange with a sleek
glass mouthpiece for an improved
taste.
5

Key Features
Dimensions
• Height: 107mm
• Width: 44.5mm
• Depth: 59mm
• Weight: 0.7 lbs
Temperature levels
104-428 F // 40-220 C
Screen: Digital OLED screen
Battery Capacity:
2x18650 (removable)
Unit can be charged via USB
Airow
Redesigned mouthpiece produce
bigger clouds with less irritation
Chamber: Stainless Steel
Convection
6

Heaiting System
Convection heating system with an
isolated heating path
Heating Element
Ceramic heating rod located below
completely separated from herb
chamber.
Haptic Feedback operation
Compact and rugged design with
textured grooves for comfortable
hand placement
Built with medical and food grade
material
Non combustion aromatherapy
device
7

Power Button
Temperature Control
Swivel
Mouthpiece
Micro USB
Charge Port/Cable
Battery Cover Plate
What’s in a Tera
aromatherapy device?
8
Water Pipe
Adapter
Glass
Mouthpiece

How it works:
Powered by two 18650 removable
batteries the ceramic heating rod
element generates heat working as
radiative heat which moves towards
the separate stainless steel convec-
tion chamber. Once the stainless
steel chamber is heated it quickly
and eciently vaporizes the materi-
al and extracts terpenes and canna-
binoids. The Tera has an isolated
airpath away from any interfering
internal wiring which ensures a pure
and clean tasting vaping experience
each time.
9

How to power
the Tera on
To power the Tera 'ON’ click the
rectangular button ve times in
rapid succession. Please note unit
will not power up if the clicks are too
slow. Once in the 'ON’ mode the
screen will illuminate and it will
automatically heat up to the last
previously used temperature. The
unit will stay on for a period of ve
minutes.*The unit will not heat up
until directed. To heat the chamber
hold down the power ‘ON’button for
three seconds; it will automatically
heat to the last previously used
temperature. Once the ve minute
timer ends, the unit will vibrate and
enter sleep mode until turned back
on. To restart the heating process
hold the button button
on for 3 seconds.
10
Power Button

Adusting the
Temperature
The temperature controls are easy to
use on the Tera. *Please note, the
unit will not heat up until directed.
To heat the chamber hold down the
power ‘ON’ button for three seconds;
it will automatically heat to the last
previously used temperature. The
buttons are located on both sides of
the unit. With the power ‘ON’ button
facing the user the button to
increase the temperature is located
to the left. Each click will raise the
temperature by one degree. To
decrease the temperature use the
button located to the right of the
power button.
Decrease
Tempature
Increase
Tempature 11

12
As before each single click will
change the temperature, it will
decrease the temperature by one
degree. Temperature ranges from
104°F-428°F and 40°C-220°C. To
switch between Fahrenheit and
Celsius click the two side buttons at
the same time once.
Mouthpiece Components
• Tip
• Silicon bowl
• Stainless steel mouthpiece screen
• Mouthpiece base with embedded
magnets
• Clear mouthpiece tip o-ring

How to Remove the
Mouthpiece
The Tera has two small magnets
which help the mouthpiece adhere
to the rest of the unit. To remove
simply pull the mouthpiece
upwards to pull away from the
magnets. Once removed the
chamber should be visible.
To put the mouthpiece back into
place line up the piece to the body
so it should click into place. The
magnets will help it stay in position.
Rotate the mouth tip towards user
to begin use.
13

How To Load Herb
1. To load herb make sure the unit is
turned o.
2. The material should be properly
broken up. A grinder is recom-
mended to use.
3. Remove the mouthpiece from the
Tera. The bowl will be visible and
will be ready to pack.
4. Insert however much material is
desired to be vaped. The bowl can
hold up to 0.6 of a gram. Do not
overll the bowl.
5. Once the herb is loaded you are
ready to attach the mouthpiece.
14

How to Load Concentrate
1. Use the loading mesh concentrate
pad that comes included to place
concentrate on top.
2. We recommend using enough
concentrate for single doses.
3. Drop the mesh pad with the
concentrate on top.
4. Once your concentrate is loaded
click the power ‘ON’ button three
times consecutively to switch to
concentrate mode. There is only one
temperature in concentrate mode
which is automatically set to 500°F or
260°C.To heat the chamber hold
down the power ’ON‘ button for 3
seconds.
15

How to use the
Water Pipe Adapter
The WPA (water pipe adapter) is
intended to be used for units from
the Boundless Technology line. The
Tera has a specic WPA that can only
be used for the Tera unit. The adapter
is to be used with a glass water pipe
as it helps lter the vaporized
product. It is designed to t male
and female stems ranging from
10mm-18mm. Using the water pipe
adapter not only helps alleviate any
irritation caused by the vapor but it
also enhances the overall taste of
your vaporized product.
16

1. To use the WPA simply remove
the mouthpiece from the Tera. Once
the mouthpiece is removed you can
insert the adapter.
2. To insert the WPA simply, insert it
into the chamber. The wider base
should be the side that is inserted
into the Tera. Be sure the WPA is
evenly leveled onto the unit.
3. When removing the WPA after
use please use extreme caution as
the stainless steel does get hot.
4. The WPA can be disassembled
into three separate pieces for an
easier clean. To disassemble twist
the small circular notch o to the
left.
17

How to clean
the Tera
Cleaning the unit right after use is
key to keeping your Tera clean and
working properly. The rotating
mouthpiece can be disassembled
making it easier to maintain.
To clean the mouthpiece you may
use isopropyl alcohol, we
recom-mend 91%. If leaving the
mouth-piece in isopropyl to soak do
not submerge for longer than ten
minutes. The screen can be removed
and individually clean for an easier
experience. Please be advised only
the mouthpiece may be submerged
in isopropyl alcohol and NOT the
body of the unit.
18

If isopropyl is applied to the body it
WILL cause cosmetic damage and
this will not be covered by the
warranty. The inside chamber can be
cleaned with a cleaning brush. If
needed the bottom chamber screen
can be removed and cleaned o as
well. Please use caution when
cleaning the device.
Tips
1. Cleaning the unit while still
relatively warm makes it easier to
remove residue.
2. You may also use coarse salt
paired with isopropyl alcohol to
help remove residue from the
mouthpiece.
3. Cleaning daily right after use is
the best method to keeping your
unit clean.
19

Battery and Charging
The Tera is equipped with two
removable 18650 batteries which
are located right underneath the
power 'ON' button.
To remove the batteries gently tug
the cover plate away from the body
of the device. Once removed the
batteries will be visible and can be
replaced when necessary.
(*Please noted to use High Drain
Battery for better vaping experi-
ence)
20
Battery
Cover Plate
