USER MANUAL
ENGLISH • ESPAÑOL

01
VAPORFI REBEL USER MANUAL
Thank you for purchasing the VaporFi Rebel Electronic Cigarette.
In order to use your electronic cigarette correctly, efficiently and
safely, please follow the instructions in this manual.

THE VAPORFI REBEL STARTER KIT INCLUDES:
» 1 Telescopic Variable Voltage Vaporizer
» 1 Rechargeable High Capacity Battery
» 1 Rechargeable Standard Capacity Battery
» 1 Titan Dual Head Tank Cartomizer
» 1 Wall Charger
» 1 User Manual

03
REBEL FEATURES
» Adjustable from 3.0-6.0 Volts in 0.1 Volt increments.
» Built-in three digit display allows you to visually adjust voltage and wattage settings.
» Works with either one (1) 18650 battery or two (2) specially designed 18350 high-power
batteries, and reverse connect protection.
» Available in stainless steel finish.
» 510 and Ego thread compatible.
» 15 Watt maximum output.
» Adjustable power from 3.0-6.0 Watts in 0.5 increments
» Rebel PCB allows up to 4 AMPS of output.
» Non-stick 360 degree rotating button.

1. (UU) ADJUSTING THE VOLTAGE UP
The Rebel’s built-in LED display allows you to dial in your preferred voltage level.
1. Press the button 3 times until “1.Uu” is shown on the display.
2. When “Uu” is shown on the display, leave the button idle for 2 seconds.
3. The display will now show the factory default setting of 3.0 Volts. To adjust, simply
depress the button to advance to the next higher voltage setting (3.0, 3.1, 3.2, 3.3, etc.).
When you reach 6.0, the Rebel will reset back to 3.0 volts.
4. Once you have reached your desired voltage level, leave the button idle for 2 seconds to
lock in your selection, and resume to normal operation.
NOTE: The heating element gets hotter as the voltage level increases. Always start at
a lower voltage setting and increase the power until you are satisfied with the vapor
production. If you are unhappy with your selection, press button 3 times to make another
change.

05
2. (UD) ADJUSTING THE VOLTAGE DOWN
ADJUST VOLTAGE DOWN
This mode allows you to turn the voltage down without having to click through an entire
rotation before reaching a lower voltage setting.
1. Press the button 4 times until “2.Ud” is shown on the display.
2. When “Ud” is shown on the display, leave the button idle for 2 seconds.
3. The display will now show the current voltage setting. To adjust, simply depress the
button to advance to the next lowest voltage setting (6.0, 5.9, 5.8, 5.7, etc.). After you
reach 3.0, the Rebel will reset back to 6.0 volts.
4. Once you have reached your desired voltage level, leave the button idle for 2 seconds to
lock in your selection, and resume to normal operation.
NOTE: If you are unhappy with your selection, simply press the button 4 times to
make another change.

3. (SO) ON/OFF & STANDBY MODE
The Rebel has 2 modes of operation—On or Standby/Off. Standby/Off mode will disable
the atomizer/cartomizer and the adjustment settings even if the button is depressed.
This mode is convenient for storing in a bag or pocket, where it otherwise could be
accidentally turned on.
1. The factory default setting is ON. To change to OFF/Standby, press the button 5 times
in a row until “3.So” is shown on the display.
2. When “So” is shown on the display, leave the button idle for 2 seconds and the display
will then show the last setting selected “On” or “Of”
3. The device will toggle between On or Of each time the button is depressed.
4. Once you have reached your desired setting, leave the button idle for 2 seconds to lock
in your selection. If you have selected “Of” the Rebel will go into Standby mode.
5. To turn the device back on and access the menu function, depress the button 5 times in a
row or simply remove the battery and re-insert.

07
4. (UC) CHECK THE BATTERY VOLTAGE
This mode allows you to check the voltage level of the battery.
1. Press the button 6 times in a row until “4.Uc” is shown on the display.
2. When UC is shown on the display, leave the button idle for 2 seconds.
3. The display will show the current battery voltage measurement (range between 3.2-8.4)
for 2 seconds before turning off.
NOTE: It is normal for your atomizer/cartomizer to activate at a very low voltage while in
battery check mode.

5. (DS) DISPLAY CHANGE
This mode allows you to view the Atomizer/Cartomizer ohms measurement, battery
voltage, and your atomizer/cartomizer output voltage. This feature is useful if you want
to double-check which type of atomizer/cartomizer you have installed, as well as the
atomizer/cartomizer voltage when the battery is working.
1. The factory default setting is OFF.
2. Press the button 7 times in a row until “5.Ds” is shown on the display.
3. When Ds is shown on the display, you can choose between Do (for atomizer/cartomizer
output voltage), Du (for battery voltage), or Dr (for atomizer/cartomizer resistance).
This will display a range from 2.9-2.2 Volts.
4. Voltage will be displayed for 2 seconds before turning off.
NOTE: It is normal for your atomizer/cartomizer to activate at a very low voltage while in
Ohms mode. This allows the Rebel to check the resistance.

09
6. (LO) LED LIGHT ON/OFF
LED ON: This mode allows the LED to light up every time the button is pressed during
normal use. The low battery function will also alert you when the LED On mode is in use.
LED OFF: This mode disables the LED to light up when the button is pressed during
normal operation. The low battery alert will not flash when the LED Off mode is in use.
1. Factory default setting is LED On. Press the button 8 times in a row until “6.Lo” is shown
on the display.
2. When “Lo” is shown on the display, leave the button idle for 2 seconds.
3. The display will now show the current setting: On or Of. To adjust, simply depress the
button to toggle between On or Of. When you have reached your desired selection,
leave the button idle for 2 seconds. This will lock in your selection and resume normal
operation.
NOTE: if you are unhappy with your selection, simply press the button 8 times to

7. (UP) VOLTAGE POWER
This mode allows you to adjust the device’s power up.
1. The factory default setting is “Auto Check”. To adjust, press the button 9 times in a row
until “7.Up” is shown on the display.
2. When “Po” is shown on the display, it reads the constant power operation (range of
3-15W)
3. When “Up” is shown on the display, it will read your constant voltage operation
4. Once your “Po” level is displayed, depress the button to advance to the next higher
setting.
5. If your variable power is 10 (watts), the display will show 100. If the variable power is 15W,
the display will show 150.
6. When you reach 150, the device will rotate back around to 3.0 and back up again.
7. Once you have reached your desired setting, leave the button idle for 2 seconds to lock
in your selection. the device will then resume normal operation. Note: If you are unhappy

8. (NR) MEAN & RMS
This mode allows you to switch between RMS and Mean Value Voltage monitoring. The
RMS mode is more accurate because it samples the output Voltage repeatedly while it is
powering an atomizer or cartomizer. It is with these measurements that it is able to adjust
for heat related Voltage drift.
1. Default setting is RMS. Press the button 10 times in a row until “8.NR” is shown on the
display.
2. RMS (More accurate and preferred) will be shown as “ANS” on the display. MEA (a
“hotter” older method used by prior models), will be shown as “NEA” on the display.
3. When you have reached your preferred setting, leave the button idle for 2 seconds.
The setting will be locked in and the Rebel will resume normal operation.

ERROR CODES
»If display is showing the error code “LOR” or Low Road, this indicates a
“Low Resistance Indication” where the resistance is below 1.2ohm.
»If display is showing the error code “LOU” or Low Voltage, this indicates a “Low Voltage
Indication” where either one of the 18650 batteries has a remaining voltage below 3.4V,
or 2 of the 18350 batteries Superposition voltage is below 6.4V.

13

MANUAL DE USUARIO

15
MANUAL DE USUARIO DE VAPORFI REBEL
Gracias por comprar el cigarrillo electrónico VaporFi Rebel.
Para poder usar su cigarrillo electrónico en forma correcta, eficiente
y segura, siga las instrucciones de este manual.

EL KIT INICIAL DE VAPORFI REBEL INCLUYE:
» 1 vaporizador telescópico de voltaje variable
» 1 batería recargable de gran capacidad
» 1 batería recargable de capacidad estándar
» 1 cartomizador Titan de tanque con doble cabezal
» 1 cargador de pared
» 1 manual de usuario

17
CARACTERÍSTICAS DE VAPORFI REBEL
» Regulable de 3,0 a 6,0 voltios en incrementos de 0,1 voltios.
» La pantalla incorporada de tres dígitos le permite regular visualmente el voltaje y las
configuraciones de vataje.
» Funciona con una (1) batería 18650 o con dos (2) baterías 18350 de alta potencia,
especialmente diseñadas, y con protección de conexión inversa.
» Disponible en acabado de acero inoxidable.
» Compatible con roscas tipo 510 y Ego.
» Salida de 15 vatios como máximo.
» Potencia regulable de 3,0 a 6,0 vatios en incrementos de 0,5
» Los policlorobifenilos (PCB) de VaporFi Rebel le permiten una salida de hasta 4 AMPS.
» Botón giratorio de 360 grados antiadherente.

1. (UU) AJUSTE PARA UN MAYOR VOLTAJE
La pantalla LED incorporada de VaporFi Rebel le permite
configurar su nivel de voltaje preferido.
1. Presione el botón 3 veces hasta que aparezca “1.Uu” en la pantalla.
2. Cuando aparezca “Uu” en la pantalla, deje el botón inactivo durante 2 segundos.
3. La pantalla ahora mostrará la configuración de fábrica predeterminada de 3,0 voltios.
Para ajustar, simplemente presione el botón para avanzar a la siguiente configuración de mayor
voltaje (3,0, 3,1, 3,2, 3,3, etc.).Cuando llegue a 6,0, VaporFi Rebel se restablecerá en 3,0
voltios.
4. Una vez que haya llegado al nivel de voltaje deseado, deje el botón inactivo durante 2
segundos para fijar su selección y reanude el funcionamiento normal.
NO TA: El elemento de calefacción se calienta a medida que aumenta el nivel de voltaje.
Inicie siempre a una configuración de voltaje inferior y aumente la potencia hasta que esté
satisfecho con la producción de vapor. Si no le satisface su selección, presione el botón 3
veces para hacer otro cambio.
