Bowers & Wilkins CCM 636 Manual

CCM 636
The CCM 636 is a ceiling speaker distinguished by its adjustable tilt offset 25mm
(1 in) soft dome tweeter. It brings both smoother and more detailed high frequency
performance to a package that also includes a woven glass fibre 165mm (6½ in)
bass/midrange driver and three-position switchable high frequency equalisation.
Installation simplicity is catered for by a simple and effective integrated swing out
dog fixing chassis. CCM 636 is a classically simple and cost effective route to high
quality ceiling mount sound.
See nothing, hear everything
Three-position EQ switch
Adjustable offset tilt soft dome tweeter
Swing-out dog fixings
2-way in-ceiling speaker system
1x ø25mm (1 in) soft dome high-frequency
1x ø165mm (6.5 in) woven fibreglass mid/bass
-6dB at 40Hz and 30kHz
50Hz-22kHz ±3dB on reference axis
89dB spl (2.83V, 1m)
8 Ω (minimum 3.0 Ω )
3.2kHz
20W - 130W continuous into 8
Ω on unclipped programme
Diameter: 232mm (9.1 in)
Diameter: 205mm (8.1 in)
103mm (4.1 in) from ceiling surface
1.5kg (3.3lb)
Semi-matt white suitable for customising or pre-painting
(paint mask included)
Pre-mount kit for new construction (PMK c65)
Technical features
Description
Drive units
Frequency range
Frequency response
Sensitivity
Nominal impedance
Crossover frequency
Recommended amplifier power
Frame size
Cut-out size
Min depth req
Net weight
Finish
Accessories
Technical Specification
©2005 B&W Group Ltd.

CCM 636
Copyright © B&W Group Ltd. E & OE.
B&W Group Ltd reserves the right to amend details of the specifications
without notice in line with technical developments.
The loudspeaker system shall be of the mono-amped 2-way type comprising of a single flush mountable circular
enclosure containing one 6.5in bass-mid driver with woven glass fibre cone and one offset mounted adjustable tilt 1in
textile dome tweeter with 3 position EQ switch.
Performance specifications of a typical production unit shall meet or exceed the following:
Frequency response shall be 50 – 22kHz ± 3dB. Nominal impedance shall be 8 Ohm. Total power handling shall be
130W continuous into 8 Ohm on unclipped programme. Sensitivity measured with 2.83V at 1-meter distance on axis,
mean averaged between 50 – 22kHz shall be 89dB.
External dimensions shall be 232mm (9.1in) diameter x 107mm (4.2in) depth. Total weight shall be 1.5kg (3.3lb).
The loudspeaker system shall be the B&W CCM 636. No other system shall be acceptable unless the above combined
performance are equalled or exceeded.
Architectual and Engineering Specifications
UK Group (UK Sales)
T [phone]
E [email protected]
B&W Group North America
T [phone]
E [email protected]
B&W Group Ltd
Dale Road
Worthing West Sussex
BN11 2BH England
T [phone]
F [phone]
[email protected]
www.bwspeakers.com B&W Group Asia Ltd
T [phone]
E [email protected]
Polar Response Horizontal Polar Response Vertical Frequency Response
Dimensions
