BOWMAN BD601-0023 User manual

BOWMAN Dispensers
20325 71st Ave NE, Suite D, Arlington, WA 98223
800.962.4660 • www.BowmanDispensers.com
Product Videos:
BowmanDispensers.com/Product-Videos
Protection System Isolation Bundle
BD601-0023
Product Description:
• Bundle Includes:
-PS016-0223 Protection System
◦Holds disposable or reuseable gowns, three boxes of
gloves, one box of earloop masks, one box of shield
masks, and miscellaneous supplies
◦BOWMAN®Signature Series - Maple Fauxwood ABS Plastic
-MP-047 Sign Holder - Clip-On
◦Holds 8.5" x 11" signage
◦Clear PETG Plastic
Primary Area for Product Usage:
• Anywhere personal protective equipment is needed
Dispenses:
• Top left: Gowns, aprons, or coveralls/jumpsuits no larger than
14.90"W x 15.25"H x 4.50"D (37.8 cm x 38.7 cm x 11.4 cm)
• Top right: Box(es) no larger than 8.10"W x 9.90"H x 4.50"D
(20.6 cm x 25.1 cm x 11.4 cm)
• Middle right: Box(es) no larger than 8.00"W x 5.30"H x 4.50"D
(20.3 cm x 13.5 cm x 11.4 cm)
• Bottom: Box(es) no larger than 11.50"W x 5.50"H x 4.50"D
(29.2 cm x 14.0 cm x 11.4 cm)
• Bottom right: Item(s) no larger than 4.93"W x 5.50"H x 4.50"D
(12.5 cm x 14.0 cm x 11.4 cm)
Product Specications (overall assembled dimensions):
• 23.38"W x 26.63"H x 5.12"D (59.4 cm x 67.6 cm x 13.0 cm)
• 8.3 lbs (3.8 kg) - approximated
Package Specications:
• Package Quantity: 1 per case
• 32"L x 26"W x 6"H (81.3 cm x 66.0 cm x 15.2 cm)
• 11.0 lbs (4.9 kg) - approximated
Mounting Specications:
Mounting Specications:
Consumables not included
20.00
.75
12.00
R.13 (2x)
R.25 (2x)
Ø.26 (2x)

©2019 BOWMAN® Manufacturing Company, Inc. All Rights Reserved. Product specications subject to change without notication. Consumables not included. BD6010023TDSc
BD601-0023 - Installation
Information subject to change without notice. Dimensions are approximate. (Not to scale)
BOWMAN Dispensers
20325 71st Ave NE, Suite D, Arlington, WA 98223
800.962.4660 • www.BowmanDispensers.com
Assembly Instructions
Protection System Isolation Bundle
BD601-0023
• Mount securely to a wall with screws approved and supplied
by building maintenance.
• Use all four mounting holes provided.
• The exible tabs on the side are designed to hold product
securely in the dispenser.
• To add or remove product, press down on the tab and insert
or pull box out.
• Clip the Sign Holder over the top of the gown section and
insert desired signage.
• Free isolation signs can be downloaded at
www.BowmanDispensers.com.
1
2
3
Installation
Always mount dispensers securely prior to loading with product.
Parts included:
• Protection System • Sign Holder
Tools Required:
• No tools required to assemble dispenser

Designed for Long-Term, Heavy-Duty Applications Designed for Long-Term, Heavy-Duty Applications
The combination of copolymers (Acrylonitrile,
Butadiene, and Styrene) gives ABS an excellent
combination of strength, rigidity, and toughness. The
fauxwood nish is ARVINYL laminate created from a
semi-rigid lm.
ABS is chemical and stress-crack resistant. It is
tough, dimensionally stable, and will hold up to long-
term use. To ensure product longevity, fauxwood
products should not be mounted in very hot or cold
areas.
Copolyester resin is designed for heavy-duty
applications, and is used by BOWMAN® Dispensers.
We never use acrylic in our products.
Copolyester (PETG) is typically 15-20 times tougher
than general purpose acrylic. PETG is made to
withstand handling and reduce losses due to
breakage.
PETG resists a variety of chemicals and commonly
used cleaning agents. It is tough and durable (not
brittle), providing years of trouble-free functionality
and long life.
Clear optical characteristics mean the viewer can see
the content, read text, and see true colors through
the material. It complies with FDA regulations for food
contact.
Use mild soap and water to clean. Petroleum-based
oils, solvents, and paints should not be used.
Standard hospital cleaning supplies are approved for
use on our ABS plastic products.
Most cleaning chemicals do not weaken the surface
or cause damage to the material. Suggested cleaning
method is to use a soft cloth, warm water, and mild
soap.
Fauxwood ABS Plastic
PS016-0212
PETG Plastic
MP-047
Material Characteristics
Care and Cleaning
Characteristics & Care
BD601-0023
Protection System Isolation Kit
BD601-0023 - Characteristics & Care
Information subject to change without notice. Dimensions are approximate. (Not to scale)
