BPS C-100 User manual

C-100 USER’S GUIDE

Your PAP device doesn’t have to
keep you from enjoying the great outdoors...
perfect for tent campers & use in RVs.
The freedom to power your
PAP device no matter
where your world takes you!

Table of Contents
INTRODUCTION
Product Specifications 1
Package Contents 2
Intended Use 3
Compatibility 3
Warranty 3
IMPORTANT NOTES
Run Times 4
ResMed Device Warning 4
Humidifier Usage 5
Power Backup Usage 5
ACCESSORIES
Power Inverter 6-7
24V Power Converter 8
GETTING STARTED
Control Board Identification 9
The Power Meter 9
Turning the Battery Pack On/Off 10
Initial Battery Usage 10
Using the Battery Pack Inside the Carrying Case 10
CHARGING THE BATTERY PACK
Charging with AC Power 11
Charging in a Foreign Country 11
Charing in a Vehicle 12
Dual Battery Configuration Charging 13

Table of Contents
POWERING YOUR PAP DEVICE
Introduction 13
Connector Tips 14
Respironics Devices 15
ResMed Devices 16
S9 Series Devices 16
S8 Series & Older Devices 17
Fisher & Paykel Devices 18
DeVilbiss Devices 19
POWERING OTHER DEVICES 20
BATTERY PACK CARE INSTRUCTIONS
Understanding Lithium-Ion Batteries 21
Battery Pack Storage 21
SAFETY WARNINGS 22
DISPOSAL OF LITHIUM-ION BATTERIES 22

1
Introduction
PRODUCT SPECIFICATIONS
DIMENSIONS
Size: 7.5” x 4.25” x 0.75” (L x W x H)
Weight: 1.6 lbs
ELECTRICAL
Cell Type: Rechargeable lithium-ion
Battery Capacity: 100 Wh
Output Voltage Range: 9 - 12.6 V
Output Current Range: 0 - 4.5 A (8A maximum)
Power Gauge: Four stage LED display
RECHARGE TIME
4-5 hours (per Battery Pack when fully discharged)
BATTERY LIFE SPAN
Under normal conditions the life span of the Battery Pack is generally
around 400-500 charge/discharge cycles.
The amount of charge the Battery Pack will hold will gradually decrease
due to usage and aging. This gradual decrease in charge capacity is true
for all rechargeable lithium-ion batteries.
Factors that can influence battery life span include:
how it is used
how often it is used
how well it is taken care of
how it is stored
See page 21 for Battery Pack Care Instructions.

2
Introduction
PACKAGE CONTENTS
Your Battery Pack comes with the items listed below. If you are missing
any of these items, please contact the company from whom you purchased
your Battery Pack.
DC POWER PIGTAIL CORD DC INPUT CORD
AC POWER SUPPLY &
POWER CORD
BATTERY PACK(S)CARRYING CASE CONNECTOR TIPS
Battery Pack is sold in a single or dual
battery configuration package.
ACCESSORIES (SOLD SEPARATELY)
24V POWER CONVERTER
For use with ResMed S9 devices only.
150W MODIFIED
SINE WAVE INVERTER
Seven (7) unique connector tips.

INTENDED USE
Battery Packs are intended to provide external power to PAP (positive
airway pressure) devices; however, when used in conjunction with a power
inverter, they may also be used to power other small electronic devices
such as smartphones, iPods, laptops and iPads. See page 20 for additional
information regarding powering other devices.
Please note that use of the Battery Pack with a device that requires higher
wattage requirements may cause the Battery Pack’s internal circuitry to
shut off to protect from overrun.
COMPATIBILITY
Battery Packs are compatible with most makes and models of PAP
devices; however, some devices will require the additional use of a power
converter or power inverter in conjunction with the Battery Pack.
See pages 15-19 for information regarding your specific PAP device.
The DC Power Pigtail Cord or Connector Tips included with the Battery
Pack may not be compatible with your PAP device as some manufacturers
require the use of a specific DC cable with built-in fuses or special
connection types. When in doubt, please contact the manufacturer of your
device. Below is the contact information for the most common PAP device
manufacturers:
Respironics 1-800-345-6443 www.respironics.com
ResMed 1-800-424-0737 www.resmed.com
Fisher & Paykel 1-800-707-5454 www.fphcare.com
DeVilbiss 1-800-338-1988 www.devilbisshealthcare.com
WARRANTY
Battery Pack, components and accessories are under warranty for
manufacturing and quality defects for six (6) months.
3
Introduction

4
Important Notes
RUN TIMES
Multiple factors will affect Battery Pack actual run times including, but
not limited to, device type, whether a power inverter or power converter
is used, pressure setting, and altitude. The use of heated humidification
or heated tubing will significantly reduce expected run times.
Average run times are based on Respironics System One and ResMed S-9
Series PAP devices with no heated humidification or heated tubing.
SINGLE BATTERY CONFIGURATION
Respironics & other 12V devices: 1-3 nights
*ResMed & other 24V devices: 1-2 nights
DUAL BATTERY CONFIGURATION
Respironics & other 12V devices: 3-5 nights
*ResMed & other 24V devices: 2-3 nights
*Use of a power converter or power inverter required.
RESMED DEVICE WARNING
If you are using any device manufactured by ResMed you must use either
a power converter or power inverter to complete the connection between
the device and the Battery Pack.
A power converter or power inverter must be used because ResMed
devices operate from a 24V direct current and the plugs may run opposite
polarity from other manufacturer devices.
Do not connect the Battery Pack directly to any ResMed model device
as doing so will damage the device.
See pages 16-17 for additional instructions regarding ResMed devices.

5
HUMIDIFIER USAGE
The use of heated humidification or heated tubing will significantly
reduce the expected run time of the Battery Pack due to the amount of
power required for the humidifier heating plate.
To obtain optimal Battery Pack performance we recommend you forgo the
use of heated humidification. Using cool or “passover” humidification will
not reduce expected run times.
Please note that some manufacturers do not recommend the use of
humidification when an external battery is used to power their device or
they may recommend the use of a modified or pure sine wave power
inverter in conjunction with the battery. Please check the manual for your
specific PAP device for disclaimers regarding humidification usage.
POWER BACKUP USAGE
Standard smart chargers keep the Battery Pack topped off and ready to go
as an emergency power backup during power outages.
If you know that a power outage is eminent or probable, you may connect
your device to the Battery Pack and plug the Battery Pack into a wall
outlet. In the event you lose power the Battery Pack will automatically
begin powering your device.
Do not consistently use the Battery Pack as a power backup option as
this will reduce its overall life. Only use the Battery Pack in this
manner when you know that a power outage is eminent.
Important Notes

6
Accessories
POWER INVERTER
Sine wave power inverters are used to change direct current (DC) to
alternating current (AC). Power inverters are universal and can be used
with any device. Using a modified or pure sine wave power inverter in
conjunction with the Battery Pack allows you to:


Power Devices Without DC Capability
To power a PAP device or other small electronic device that does not
have DC capability, you must use a power inverter to complete the
connection between the device and the Battery Pack.


Charge the Battery Pack in a Vehicle
The use of a power inverter in conjunction with the Battery Pack
AC Power Supply allows you to safely and efficiently recharge your
Battery Pack via the cigarette lighter (power) socket of a vehicle.
See page 12 for additional information.


Power Other Small Electronic Devices
To power a small electronic device that does not have a DC cable
with a cigarette lighter plug, use a power inverter to complete the
connection between the device and the Battery Pack.
See page 20 for additional information.
Battery Power Solutions offers an incredibly small, yet powerful 150 Watt
Modified Sine Wave Power Inverter. Sine wave inverters may also be
purchased from electronics retailers.
BATTERY POWER SOLUTIONS
MODIFIED SINE WAVE POWER INVERTER
(sold separately)
Output Rated Power:
120W (continuous) - 150W (maximum)
Dimensions: 5.25" x 2.75" x .5" (LxWxH)
Weight: 0.5 lbs

POWER INVERTER
CONNECTING THE 150 WATT INVERTER TO THE BATTERY PACK
Connect the DC Input Cord to the DC Out Jack of the Battery Pack.
Connect the Inverter Adaptor Cord to the side of the Inverter.
Connect the cigarette lighter plug end of the Inverter Adaptor Cord
into the DC Input Cord of the Battery Pack.
Accessories

DC Input Cord
DC Out
Jack
Inverter Adaptor
Cord Inverter

CONNECTING YOUR DEVICE TO THE 150 WATT INVERTER
Connect the AC power cord of your device to the Inverter by sliding
open the small spring loaded tab located on the back of the Inverter,
which will reveal the two-prong plug.
If your device has a USB cable, you can connect the device to the
Inverter via the USB port located on the back of the Inverter.
Once the connection between the Battery Pack, Inverter and your device
is complete, press the ON/OFF button on your device and it should
start functioning.
Note: It is normal for the Inverter
to become warm to the touch and
to hear the internal fan operating
when in use.

USB Port

Two-Prong Plug

7


8
24V POWER CONVERTER
DC to DC power converters convert a source of direct current (DC) from
one voltage to another (i.e. 24V to 12V). Power converters are generally
proprietary to a specific device.
Battery Power Solutions’ 24V Power Converter was specifically designed
for use with ResMed S9 Series PAP devices and the C-100 Battery Pack.
This single component connection provides a clean, efficient conversion
from 24V to 12V direct current. See page 16 for additional information.
You may also use ResMed’s DC Power Converter to make the connection
between a ResMed PAP device and the Battery Pack. ResMed DC Power
Converters may be purchased from medical equipment retailers who sell
ResMed products. See page 17 for additional information.
Accessories
BATTERY POWER SOLUTIONS 24V POWER CONVERTER
(sold separately)
Input: 12V / 24V
Output: 24V / 3.75A
Length: 4 ft (connector to connector)
Weight: 0.35 lbs
- for use with ResMed S9 Series PAP devices only -

9
Getting Started
CONTROL BOARD IDENTIFICATION
The Control Board includes the DC In and DC Out Jacks, charge lights and
the Power Meter, which indicates the remaining power level.
The On Light (F) will be green when a device is plugged into the
DC Out Jack (D).
The Charging Light (E) will be red when the Battery is being charged.
The Full Charged Light (C) will be green when the Battery Pack has
completed charging.
THE POWER METER
The LED display Power Meter indicates the remaining power level of the
Battery Pack. The Power Meter may be activated after the first time you
charge your Battery Pack.
Press the Power Meter Button and the number of LED lights displayed on
the Power Meter will show you the power level of the Battery Pack.
4 green LED lights > 85%
3 green LED lights 50-85%
2 green LED lights 15-50%
1 green LED light < 15%
ADC In Jack BPower Meter Button CFull Charged Light
DDC Out Jack ECharging Light FOn Light
GPower Meter
EF
C
BAD
G






POWER METER
POWER METER BUTTON

10
TURNING THE BATTER PACK ON/OFF
The Battery Pack will turn on or off automatically when a device is plugged
into or disconnected from the Battery Pack. If the Battery Pack stops
functioning, reconnect the AC Power Supply to the Battery Pack to reset
the internal circuitry.
INITIAL BATTERY USAGE
Before using your Battery Pack for the first time be sure to charge it fully
using AC power (a wall outlet).
During the initial charge, the Battery Pack may indicate that charging is
complete after just 10 or 15 minutes as the Battery Pack is already charged
before it leaves the factory.
USING THE BATTERY PACK INSIDE THE CARRYING CASE
The Carrying Case of the Battery Pack was designed with a clear access
window which allows you to use and/or charge the Battery Pack while it is
inside of the Carrying Case.
Place the Battery Pack in the Carrying Case with the Control Board
facing toward the clear access window.
If you are using the Battery Pack in the dual configuration, place both
Battery Packs in the Carrying Case with the Control Boards facing toward
the clear access window.
Pull open the flap of the clear access window.
Insert the appropriate connection cord (DC Power Pigtail Cord, DC Input
Cord, Power Converter Cord, or AC Power Supply Cord) to the DC Out
Jack of the Battery Pack.
Note: The connection cord used will depend upon whether you are
charging or using the Battery Pack. See pages 11-20 for connection
configuration information.
Getting Started

11
Charging the Battery Pack
CHARGING WITH AC POWER (A WALL OUTLET)
Connect the AC Power Cord to the AC Power Supply.
Connect the Output Cable of the AC Power Supply to the DC In Jack
of the Battery Pack.
Connect the AC Power Supply to a wall outlet.
After you have fully charged the Battery Pack the Full Charged light
on the Control Board will display green.
When charging is complete disconnect the AC Power Supply from the
wall outlet and the Battery Pack.
Output Cable of
AC Power Supply

AC Power Supply

AC Power Cord
Note: It is normal for the AC Power Supply and the Battery Pack to be
warm to the touch during the charging process.
CHARGING IN A FOREIGN COUNTRY
The Battery Pack AC Power Supply will operate on any AC current from
100 V to 240 V and 50/60 Hz without any adjustment.
You will only need an international electrical adapter plug in order to charge
the Battery Pack from AC power (a wall outlet) in a foreign country.
International adapter plugs can be purchased from electronics retailers.
DC In Jack


CHARGING IN A VEHICLE
The use of a power inverter in conjunction with the Battery Pack AC Power
Supply allows you to safely and efficiently charge the Battery Pack via the
cigarette lighter (power) socket of a vehicle.
Connect the AC Power Supply to the Battery Pack.
Connect the AC Power Supply to the Inverter.
Plug the Inverter Adaptor Cord into the cigarette lighter (power)
socket of the vehicle.
Start the vehicle to begin charging. Keep the vehicle running during
the charging process to avoid draining the vehicle battery.
When the charging process is complete remove the Inverter Adaptor
Cord from the cigarette lighter (power) socket of the vehicle.
12
Charging the Battery Pack
Note: Charge times will vary depending upon inverter and vehicle battery
type. It is normal for the Inverter to become warm to the touch and to hear
the internal fan operating when in use.
AC Power Supply

DC In Jack

Inverter
Adaptor Cord

Inverter 

DUAL BATTERY CONFIGURATION CHARGING
If you are using the Battery Pack in the dual configuration you may charge
both Battery Packs at the same time.
Connect the DC Power Pigtail Cord to the DC In Jack of both Batteries.
Connect the DC Power Pigtail Cord to the Output Cable of the AC Power
Supply and follow the remaining charging instructions listed on
page 11 (charging with AC power) or page 12 (charging in a vehicle).
Charging the Battery Pack
13
Powering Your PAP Device
INTRODUCTION
The DC capability, voltage requirements and plug polarity of your PAP device
will determine how your device connects to the Battery Pack.
Some PAP devices can be connected directly to the Battery Pack via the
DC Pigtail Power Cord; while others will require the additional use of a
power inverter or power converter in order to complete the connection
between the Battery Pack and your PAP device.
Please refer to the following pages for specific setup instructions for Philips
Respironics, ResMed, Fisher & Paykel, and DeVilbiss PAP devices. Do not
attempt to connect the Battery Pack to your PAP device until you
have read and understand the following instructions. Failure to do so
may damage your PAP device.
Output Cable
of AC
Power Supply
DC Power Pigtail Cord



Powering Your PAP Device
14
DC Power
Pigtail Cord


Connector
Tip
PAP DC
Input Port
CONNECTOR TIPS
If your PAP device can be connected directly to the Battery Pack
(Respironics and DeVilbiss PAP devices) you will need to insert one of the
provided Connector Tips into the end of the DC Power Pigtail Cord in order
to connect the PAP device to the Battery Pack.
Locating the appropriate Connector Tip for your device:
Compare the Connector Tips provided with your Battery Pack to the
tip of the PAP device AC power supply. Choose the Connector Tip that
you feel most closely matches.
Locate the DC input port on the PAP device.
Try to insert the Connector Tip you have chosen into the DC input port
of the device. The Connector Tip should insert easily - do not force it.
Make sure the Connector Tip sits securely in the DC input port. If the
Connector Tip is loose try another one as you want to avoid using a
loose Connector Tip if there is a better match.
Once you have found the best fitting Connector Tip, insert it into the
female end of the DC Power Pigtail Cord.
We recommend either keeping the Connector Tip you have chosen
inserted into the DC Power Pigtail Cord or storing it a separate place
away from the other Connector Tips so it can be easily located when
you are ready to use your Battery Pack.


Powering Your PAP Device
15
RESPIRONICS DEVICES
Respironics PAP devices may be connected directly to the Battery Pack.
Connect the DC Power Pigtail Cord to the DC Out Jack of the Battery
Pack. Note: If you are using the Battery Pack in the dual configuration,
simply connect the DC Power Pigtail Cord to the DC Out Jack of both
Battery Packs.
Insert the appropriate Connector Tip into the female end of the DC
Power Pigtail Cord. See page 14 for Connector Tip instructions.
Connect the DC Power Pigtail Cord with appropriate Connector Tip
to the DC input port of the Respironics PAP device.
Press the ON/OFF button on the PAP device and the device should
start functioning.
DC Out Jack
DC Power
Pigtail Cord

SINGLE BATTERY CONFIGURATION
DUAL BATTERY CONFIGURATION
PAP DC
Input Port



16
Powering Your PAP Device
RESMED DEVICES
If you are using any device manufactured by ResMed you must use either
a power converter or inverter to complete the connection between the
device and the Battery Pack. Do not connect the Battery Pack directly
to any ResMed device as doing so will damage the PAP device.
RESMED S9 SERIES DEVICES
Battery Power Solutions designed a 24V Power Converter specifically for
use with ResMed S9 Series PAP devices. See page 8 for more information.
CONNECTION USING BPS 24V POWER CONVERTER
Connect the male end of the 24V Power Converter to the DC Out Jack
of the Battery Pack. You must connect the 24V Power Converter
to the Battery Pack before you connect to the ResMed S9 device.
Note: If you are using the Battery Pack in the dual configuration,
connect the DC Power Pigtail Cord to the DC Out Jack of both Battery
Packs and connect the 24V Power Converter to the end of the DC Power
Pigtail Cord.
Connect the female end of the 24V Power Converter to the DC input
port of the ResMed S9 Series device.
Press the ON/OFF button on the PAP device and the device should
start functioning.
24V Power Converter
DC Out Jack
PAP DC Input Port


