Tripp Lite BPE480VB Configuration guide

Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +[phone]
E-mail: [email protected]
Model #: BPE480VB
External Battery Pack for Select 3-Phase UPS Systems
Highlights
BPE480VB is an "empty" version of the Tripp Lite BP480V26B external battery
pack
Requires 40 user-supplied 12V 26AH batteries (BB Battery BP26-12 B1 or
equal)
Extends runtime of compatible Tripp Lite UPS Systems using +/- 240VDC
configuration
External battery case matches the appearance of compatible Tripp Lite UPS
systems; includes all required wiring and accessories for installation of internal
batteries
Empty configuration greatly reduces worldwide shipping costs
Hardwire internal batteries and connection to UPS
Description
BPE480VB is an "empty" version of the Tripp Lite BP480V26B external battery pack that requires 40 user-supplied 12V 26AH batteries. Compatible
with BB Battery model BP26-12 batteries with B1 type terminals (or equal). External battery case matches the appearance of compatible Tripp Lite
UPS systems and includes all required wiring and installation accessories, except batteries. Offers extended battery runtime for critical connected
loads. Includes internal disconnect for battery isolation. Multiple BP480V26B / BPE480VB cabinets can be daisy-chained to the UPS for even longer
extended run operation.
Compatible UPS Systems: SU40K, SU60K, SU80K, SU20KX, SU40KX, SU60KX, SU80KX, SU60KTV and SU80KTV only.
Applications
Ideal way to lengthen the battery runtime provided by compatible Tripp Lite UPS systems.
Package Includes
BPE480VB External Battery Pack
Warranty information
Owner's Manual
Specifications
BATTERY
Expandable
battery
runtime
Multiple battery packs can be daisy-chained to the UPS for extended runtime
DC system
voltage (VDC)
240

Battery
Access
Empty-case configuration without pre-installed internal batteries requires a quantity of 40 user-supplied 12 volt, 26 amp-hour
batteries with B1 terminals. Model number BP26-12 batteries with B1 bolt and nut compatible terminals made by BB Battery,
or equal are recommended ( http://www.bb-battery.com/productpages/BP/BP26-12.pdf ). Battery housing opens for
complete access for installation and maintenance of internal batteries. All battery wiring and installation hardware included,
except for batteries. See owner's manual for additional battery dimension and installation information.
Connects to
UPS via
Hardwire (contractor supplies wiring to connect battery pack to the UPS - see Owner's Manual for gauge recommendations)
Typical
battery
lifespan
3-5 years typical (North America)
PHYSICAL
Shipping
Dimensions
(HWD/in)
55.25 x 28.75 x 42.75
Shipping
Dimensions
(HWD/cm)
140.3 x 73 x 108.6
Shipping
weight (lbs)
390
Shipping
weight (kg)
177.1
Unit
Dimensions
(HWD/in)
45.7 x 20.5 x 33.7
Unit
Dimensions
(HWD/cm)
116.1 x 52.1 x 86.6
Unit weight
(lbs)
248
Unit weight
(kg)
112.6
Material of
construction
Steel
Form factors
supported
Tower
WARRANTY
Product
Warranty
Period
(Worldwide)
1-year limited warranty
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=4460.
Copyright © 2013 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous
improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
