BRABURA Griddle L CLASS 40 User manual

GRIDDLE
brabura
INSTRUCTIONS MANUAL
GAS GRIDDLE
MONSALUD 23 | 06220 VILLAFRANCA DE LOS BARROS (BADAJOZ) | SPAIN
GG ED00 | braburagriddle.com
22
0051

Model No: BGG0003
BRABURA L CLASS 20
22
0051
Model No: BGG0002
BRABURA L CLASS 30
Model No: BGG0001
BRABURA L CLASS 40

CONTENTS
Introduction 4
Safety and warnings 5
Quick reference guide 7
Brabura griddle dimensions 8
Before you begin 11
Lighting instructions 12
Installation 14
Gas connections 18
Leak testing 20
Care and cleaning 21
Troubleshoothing 22
Installer checklist 23
3GG ED00 | braburagriddle.com

INTRODUCTION
Welcome to your BRABURA Griddle
ThismanualhasbeenwrittentohelpyouuseyourBRABURA Griddle
with safety and satisfaction. It includes detailed information about
the griddle, the components supplied or installed, its systems,
and information about its operation. Please read it carefully, and
familiarize yourself with your BRABURA Griddle before you start
cooking.
NOTES:
-This instruction manual contains important information
necessary for the proper assembly and safe use of the
appliance.
-Read and follow all warnings and instructions before
assembling and using the appliance.
-Follow all warnings and instructions when using the
appliance.
-Keep this manual for future reference.
For support information on using your BRABURA Griddle, go to
https://www.braburagriddle.com/ayuda-soporte/.
To contact us, visit https://www.braburagriddle.com/.
* Example image: BRABURA L CLASS 40’’
4GG ED00 | braburagriddle.com

SAFETY AND WARNINGS
DANGER
WARNING
IF YOU SMELL GAS
-Shut off gas to the appliance.
-Extinguish any open flame.
-Open the lid.
-If odor continues, keep away from the appliance and
immediately call your gas supplier or your fire department.
Failure to follow these instructions could result in fire or explosion
which could cause property damage, personal injury or death.
-Do not store or use gasoline or other flammable liquids or
vapors in the vicinity of this or any other appliance.
-An LP cylinder not connected for use shall not be stored in the
vicinity of this or any other appliance.
5GG ED00 | braburagriddle.com

SAFETY AND WARNINGS
Safety warnings
To reduce the risk of fire, injury to persons or damage when using the appliance, follow the safety
instructions listed below. Read all the guidance before using the BRABURA Griddle. Do not use a
gas griddle for purposes other than intended.
- Use only in well ventilated areas.
- Never leave the product unattended when in use.
- Always open the lid before lighting. Do not close the lid during cooking or before the appliance
has cooled down.
- Do not use a flame to check for gas leaks.
- Do not attempt to disconnect any gas connection while your appliance is in use or the gas
supply is on.
- Never connect an unregulated gas line to the appliance.
- When not in use, make sure the gas supply is turned off at the supply cylinder.
- Keep appliance covered when not in use.
- After a period of storage or non-use, the appliance should be checked for gas leaks,
deterioration, proper mounting, and burner obstruction before use.
- Do not move the device during use.
- Children should not be left alone or unattended in an area where the product is in use.
- Never allow them to sit, stand or play on or around the unit at any time.
- Never use the appliance in a very windy area.
- Do not obstruct the flow of combustion and ventilation to the appliance.
- Spiders and insects can nest in burners or openings and can block or restrict the burner. This
can cause a flash back to the control panel, which can cause a fire.
- Do not place, store or operate the appliance on a slope.
- Unit should be inspected at least once a year or immediately if gas odor is present along
with burner flames appearing yellow, appliance does not come up to temperature or heats
unevenly, or unit makes popping noises.
- Do not smoke during leak test and extinguish all open flames.
- When cleaning burners, properly center burner in orifice and ensure burners are level before
lighting to avoid fire or explosion hazard.
- Do not place the unit directly on the ground or other unsupported surface. This will prevent
damage to the regulator/hose assembly.
- This appliance can be used with any brand of gas tank, provided it is compatible with a suitable
retention device (not included).
- Never use a cylinder with a damaged valve. The cylinder being used must have a collar to
protect the cylinder valve.
- All pipe sealants must be of an approved type and resistant to the actions of butane/propane
gases. Never use pipe sealant on flared fittings.
- Always check for leaks after every gas tank change.
- Do not use the appliance until all connections have been checked and are free of leaks.
- Before each use, inspect the gas supply pipe or hose before turning on the gas. If there is
evidence of cuts, wear or abrasion, it should be replaced before use. Replacement hose
assembly must be as specified by the manufacturer.
- If shall be used only outdoors, and shall not be used in a building, garage, or any other enclosed
area.
- If is not intended to be installed in or on a boat.
Keep these instructions
BRABURA Griddle cannot be held responsible for any damage incurred to objects or people resulting
from incorrect installation or use of the griddle.
6GG ED00 | braburagriddle.com

SPECIFICATIONS
Reference
Burners
Power kW
kW per Burner
Griddle Area
Griddle Surface
Dimension
Burger Count
Gas Type
Griddle Plate Material
Burner Material
Chassis Material
Ignition Type
Knobs
WARRANTY
Enameled Cast Iron Cooking Plate
Components
20’’
BGG0003
2
6.4
3.2
2160 cm2
48x45 cm
16
LP
Enameled Cast Iron
304 Stainless Steel
304 Stainless Steel
Continuous Spark
LED-lit, orange / white
Lifetime
Lifetime
QUICK REFERENCE GUIDE
MODELS
Brabura L Class 40
Brabura L Class 30
Brabura L Class 20
DIMENSIONS
Height
Width
Depth
FEATURES
Enameled Cast Iron
The enameled cast iron griddle has incredible heat retention
properties that sears foods perfectly, distributes heat for
even cooking. The enameled surface is durable, non-stick,
and cleans up easily.
High Quality Construction
The chassis and lid are constructed from heavy duty 304
stainless steel for easy cleaning and corrosion resistance.
The 304 stainless steel burner tubes are long-lasting and
dependable.
Exceptional Design
Independent burners provide different heat zones.
Robust LED knobs are shown when burners are lit.
The drain at the front of the griddle leads to a pull-out grease
tray for quick and easy clean-up.
20’’
330 mm
1016 mm
609 mm
30’’
330 mm
813 mm
609 mm
40’’
330 mm
506 mm
609 mm
30’’
BGG0002
3
9.6
3.2
3330 cm2
74x45 cm
22
LP
40’’
BGG0001
4
12.8
3.2
4230 cm2
94x45 cm
27
LP
7GG ED00 | braburagriddle.com

4 3/4"
120mm
19 15/16"
506mm
18 1/2"
470mm
8 1/4"
210mm
23 15/16"
609mm
22"
559mm
BRABURA GRIDDLE DIMENSIONS
BRABURA L CLASS 20” - Chassis + Enameled Cast Iron Cooking Plate
Enameled Cast Iron
Cooking Plate
front profile
Chassis
8GG ED00 | braburagriddle.com

BRABURA GRIDDLE DIMENSIONS
BRABURA L CLASS 30” - Chassis + Enameled Cast Iron Cooking Plate
4 3/4"
120mm
29 15/16"
760mm
18 1/2"
470mm
8 1/4"
210mm
23 15/16"
609mm
32"
813mm
Enameled Cast Iron
Cooking Plate
front profile
Chassis
9GG ED00 | braburagriddle.com

BRABURA GRIDDLE DIMENSIONS
BRABURA L CLASS 40” - Chassis + Enameled Cast Iron Cooking Plate
4 3/4"
120mm
37 15/16"
963mm
18 1/2"
470mm
8 1/4"
210mm
23 15/16"
609mm
40"
1016mm
Enameled Cast Iron
Cooking Plate
front profile
Chassis
10 GG ED00 | braburagriddle.com

BEFORE YOU BEGIN
The BRABURA Griddle it is delivered with five AA (1,5V) battery.
Ignition
Place a battery in the piezoelectric located on the bottom of the chassis.
Led Knob *
Place four batteries in battery cartridge located on the bottom of the chassis.
* Color Led
When a knob is in use, an orange halo around that knob will illuminate. This will
change from orange to white if the knob is turned to OFF.
11 GG ED00 | braburagriddle.com
* Example image: BRABURA L CLASS 40’’

LIGHTING INSTRUCTIONS
The BRABURA griddle is equipped with a thermocouple and safety valve system which monitors the
burner. This will turn the gas off if the burner is not lit.
1. Open the lid and remove any cooking utensils. Ensure the grease tray is in place and all the
knobs are on the OFF position.
2. Connect the hose regulator to gas cylinder (see ‘gas connection’), hose regulator to griddle
manifold. Turn the gas supply ON at the cylinder. Check with the use of soapy water (see ‘leak
testing’) for any gas leakage between the bottle and hose regulator.
3. Push in and hold the selected dial for 2 seconds before turning to High. Hold for 10 seconds to
light the griddle.
4. If burner does not light after several attempts turn the dial to OFF, wait 5 minutes and repeat
step 3. If the burners do not stay alight, repeat step 3 and 4.
5. Adjust the heat by turning the knob to the high/low position.
6. To turn the BRABURA Griddle off turn the cylinder valve to the off position and then turn all the
control knobs on the appliance clockwise to the off position.
12 GG ED00 | braburagriddle.com
* Example image: BRABURA L CLASS 40’’

LIGHTING INSTRUCTIONS
Manual lighting
If the burner will not light after several attempts, the burner can be manually lit. If you have attempted
to light the burner with the ignition, allow 5 minutes for any accumulated gas to dissipate.
1. Open the lid and remove any cooking utensils. Ensure the grease tray is in place and all the
knobs are on the OFF position.
2. Using a special safety match, carefully light a match and insert it between enameled cast iron
cooking plate and chassis until reaching each burner.
3. Turn the control dial counter-clockwise to High. Hold for 10 seconds to light the griddle.
4. Adjust the heat by turning the knob to the high/low position.
6. To turn the BRABURA Griddle off turn the cylinder valve to the off position and then turn all the
control knobs on the appliance clockwise to the off position.
13 GG ED00 | braburagriddle.com
* Example image: BRABURA L CLASS 40’’

INSTALLATION
BRABURA Griddle must be located outdoors only. As with any gas appliance, harmful carbon monoxide is produced during the combustion process that should not be allowed to accumulate in a
confined space. Also, since hot air rises above the Griddle while in operation, covered locations should be avoided. Do not locate the Griddle where an overhang or awning may cover it. CAUTION should
be taken when grills are used near glass, vinyl siding or other temperature sensitive construction materials. In some cases it may be necessary to increase the clearance around the Griddle to avoid
damage to vinyl siding. Check with the manufacturer of the siding material for details.
BRABURA Griddle is design-certified for use outdoors only and is not intended to be installed in or on recreational vehicles and/or boats. This appliance must be on a level, stable surface in an area
clear of combustible material. An asphalt surface may not be acceptable for this purpose.
Our Griddles are designed for easy installation in one of three ways.
Countertop
Set the griddle on top of a non-combustible
counter.
Built-in
Installed into a non-combustible counter, or a
combustible counter using the Build-in liner
accessory.
Rolling Base
Mount the griddle to the Rolling Base
accessory to make a freestanding griddle.
Instructions included with the Rolling Base.
14 GG ED00 | braburagriddle.com
* Example image: BRABURA L CLASS 20’’

12"
305mm
12"
305mm
INSTALLATION - COUNTERTOP
Your BRABURA Griddle may be installed on top of a
non-combustible counter. The Griddle must be located
outdoors only. This appliance must be on a level, stable
surface in an area clear of combustible material.
Locating the Griddle
When determining a suitable location, take into account
concerns such as exposure to wind, proximity to traffic
paths, and keeping any gas supply line as short as possible.
- Locate the unit in a well-ventilated area.
- The counter and supporting ledges or deck must be
level and flat.
- The enclosure should have ventilation holes to
prevent gas build-up in the event of a leak.
BRABURA Griddle recommends installing the manual
shut-off valve in a location readily accessible by the
customer, so that gas to the appliance can be shut off in
an emergency situation. However, the appliance must not
be modified in any way to accommodate such placement.
Clearances to Combustible Surfaces - Countertop
The Griddle should not be located closer than 12”/305mm
to any adjacent combustible surface.
Allow 12”/305mm from the sides and rear to combustible
construction while in operation.
The Griddle should not be located under any overhead
unprotected combustible construction.
15 GG ED00 | braburagriddle.com
* Example image: BRABURA L CLASS 40’’

19 11/16"
500mm
*
32 1/16"
815mm
7"
178mm
4"
102mm
1 1/4"
31mm
10"
254mm
40 1/16"
1018mm
22 1/16"
561mm
8 1/4"
210mm
*
INSTALLATION - BUILT-IN
The BRABURA Griddle is designed for easy installation into masonry enclosures. The griddle
is intended either for installation in a built-in enclosure constructed of non-combustible
materials or for an installation in a built-in enclosure constructed of combustible material
when installed with a BRABURA Build-In Liner.
Locating the Griddle
When determining a suitable location, take into account concerns such as exposure to wind,
proximity to traffic paths, and keeping any gas supply line as short as possible.
- Locate the unit in a well-ventilated area.
- The counter and supporting ledges or deck must be level and flat.
- The enclosure should have ventilation holes to prevent gas build-up in the event of a leak.
BRABURA Griddle recommends installing the manual shut-off valve in a location readily
accessible by the customer, so that gas to the appliance can be shut off in an emergency
situation. However, the appliance must not be modified in any way to accommodate such
placement.
Standard Cutout Dimensions
For non-combustible applications, the griddle drops into the opening shown in the cutout
detail drawing. A deck is required to support it from the bottom.
* Dimensions for all sizes
*
*
*
*
16 GG ED00 | braburagriddle.com

42"
1066mm
19 15/16"
506mm
*
34"
863mm
24"
609mm
8 9/16"
217mm
*
INSTALLATION - BUILT-IN
Cutout Dimensions - Combustible Construction with Build-in Liner
Combustible constructions refers to a building structure or decorative structure made of wood,
compressed paper, plant fibers, vinyl/plastic or other materials that are capable of transferring heat
or being ignited and burned. Such material shall be considered combustible even though flame-
proofed, fire-retardant treated or surface-painted, or plastered.
Build-in Liners
To install the Griddle into a enclosure constructed of combustible materials, use only the HearthStone
Outdoor Build-in Liner appropriate for the Griddle model. Our Build-in Liners have been specifically
designed and tested for this purpose.
- Build-in Liner / Brabura 40:
- Build-in Liner / Brabura 32:
- Build-in Liner / Brabura 22:
Review the detail drawing shown and take into account the provisions shown for gas line connection
clearance in the rear corner. It is required that ventilation holes are provided in the enclosure to
eliminate the potential build-up of gas in the event of a gas leak. The counter and supporting ledges
and/or deck must be level and flat and strong enough to support the griddle and Build-in Liner.
* Dimensions for all sizes
17 GG ED00 | braburagriddle.com

Gas Requirements
The BRABURA Griddle is certified according to the UNE-EN 498: 2012 standard.
Before installation ensure that the conditions for local distribution (gas type and gas pressure) and the setting of the appliance are compatible. The rating plate is located on the rear of the chassis reports
of the codes of all European Countries where the appliance can be operated.
The recall of the gas to be used is indicated on the packaging and on the rating plate of the BRABURA Griddle. The unit has been factory set for use with 28-30/37mbar butane/propane gas in bottle.
COUNTRY OF DESTINATION CATEGORY/IES TYPE OF GAS POWERSUPPLY PRESSURE ORIFICE SIZE
BG - CY - DK - EE - FI - HR - HU - IT - IS - LT
LU - MT - NL - NO - RO - SE - SI - TR I3B/P G30/G31 12.8 kW (G30: 931g/h; G31: 915g/h)30 mbar 0.88
BE - CY - CZ - ES - FR - GB - GR
IE - IT - LT - LU - PT - SI I3+ G30/G31 12.8 kW (G30: 931g/h; G31: 915g/h)28-30 / 37 mbar 0.88
AT - DE - CH I3B/P G30/G31 12.8 kW (G30: 931g/h; G31: 915g/h)50 mbar 0.78
PL I3B/P G30/G31 12.8 kW (G30: 931g/h; G31: 915g/h)37 mbar 0.82
FOR OUTDOOR USE ONLY. IF STORED INDOORS, DETACH AND LEAVE CYLINDER OUTDOORS.
1. READ INSTRUCTIONS BEFORE LIGHTING.
2. OPEN LID DURING LIGHTING AND DO NOT CLOSE WHILE IN USE.
3. IF IGNITION DOES NOT OCCUR IN 5 SECONDS, TURN THE BURNER CONTROL(S) OFF,
WAIT 5 MINUTES, AND REPEAT THE LIGHTING PROCEDURE.
- DO NOT USE THIS APPLIANCE UNDER OVERHEAD COMBUSTIBLE MATERIALS.
- TURN OFF LP SUPPLY AT CYLINDER WHEN APPLIANCE IS NOT IN USE.
- THIS APPLIANCE IS NOT INTENDED FOR COMMERCIAL USE.
ONLY FOR INSTALLATION IN BUILT-IN ENCLOSURE CONSTRUCTED OF NON-COMBUSTIBLE MATERIAL. FOR
INSTALLATION IN A BUILT-IN ENCLOSURE CONSTRUCTED OF COMBUSTIBLE MATERIALS WHEN INSTALLED WITH
INSULATING JACKET.
MANUFACTURED BY:
MONSALUD 23,
VILLAFRANCA DE LOS BARROS 06220 - SPAIN
Model No: BGG 0001 (Brabura 40’’ GRIDDLE) SERIAL NUMBER: G4022xxxx
22
0051
Read the instructions before using the appliance. WARNING: accessible parts may be very hot. Keep young children away
GAS CONNECTIONS
18 GG ED00 | braburagriddle.com
* Example image: BRABURA L CLASS 40’’

Gas Connection
BRABURA Griddle is set up for gas gas. Use butane or propane gas tanks 6 to 13kg and the
appropriate Regulator/Hose assembly. The gas tank used, equipped with the regulator/hose
assembly, must have a maximum height of 615mm and width of 310mm. If the installation the
Griddle is into a enclosure constructed or on the rolling cart gas, the gas tank must have a maximum
height of 400mm and depth of 310mm.
Ensure the main valve on the tank is completely closed, all burner dials are in the OFF position.
Insert the regulator/hose assembly inlet into the gas tank valve and turn the black coupler clockwise
until it tightens. Do not over tighten the coupler. Turn the main tank valve ON and the burner control
valves to HIGH for about 20 seconds to allow the air in the system to purge. Turn valves OFF and
wait 5 minutes before attempting to ignite the burners.
Butane gas: Use a regulator/hose assembly of 28 mbar which meets the NF-EN-16129 standard.
Propane gas: Use a regulator/hose assembly of 37 mbar which meets the NF-EN-16129 standard.
The connection from the BRABURA Griddle to the gas bottle (Butane or Propane) is carried out by
a flexible metal hose with an NF-D-36125 mechanical connector (unlimited usage) or a flexible
rubber hose equipped with an NF-D-36112 mechanical connector (10-year usage) with a maximum
length of 1.5 metres. Regularly check that the gas hose is in good condition and do not hesitate to
change it if shows cracks or signs of wear. Change when the expiry date printed on the hose has
been reached.
The BRABURA Griddle must be connected using the G3/8 connector located on the left-bottom
side of the griddle. After having connected the hose to the plancha, connect the pressure reducer
on the hose then on the gas tank by following the indications supplied with the hose and the
regulator/hose assembly.
Notes:
- If a gas leak is observed, close the gas bottle’s valve and double check the connections and
carry out another leak test.
- If the leak continues or originates from another part, contact the shop where you purchase
this appliance..
- Never use a leaking appliance.
GAS CONNECTIONS
3"
66mm
MIN
Changing the gas tank
When changing the gas tank, please respect the following instructions:
- Ensure the main tank valve is turned off and the control knobs in the off position before
turning the coupler counter clockwise, the inlet will then disengage. Remove the inlet from the
tank valve opening.
- Gas tank must be changed in a well ventilated place, away from any heat sources (cigarette,
electrical appliances, etc.).
- Wait for the appliance to have completely cooled down.
- Always check for gas leaks after every gas tank change.
Corrugated metal pipe
Advice: Do not modify the appliance
19 GG ED00 | braburagriddle.com

LEAK TESTING
Leak Test Procedure
A complete gas tightness check must be performed at the installation site. Periodically check the
whole system for leaks, or immediately if the smell of gas is present.
1. Prepare soap solution by combining one part of liquid detergent and one part of water.
2. Ensure all control valves are in the OFF position before turning the gas supply ON.
3. Check all connections from the supply line or LP cylinder by applying the solution around the
connection, tubing and end of the manifold.
4. If bubbles appear to “grow” on any of the connections, you have a gas leak. IMMEDIATELY turn
off the gas supply.
5. Tighten any leaking connections. Turn gas ON, and recheck. If you cannot stop a gas leak turn
the gas supply OFF, do not use your BRABURA Griddle and contact the shop where you purchase
this appliance.
Advice: before each use of the BRABURA Griddle clean and inspect the hose. If there is evidence of abrasion, wear, cuts, or leaks, the hose must be replaced prior to the appliance being put into
operation.
Corrugated metal pipe
Advice: Do not modify the appliance
20 GG ED00 | braburagriddle.com
