Lang 136S-M Manual

Star Manufacturing International 10 Sunnen Drive St. Louis, MO.63143-3800
Part Number: 2M-W354 Ph: 314-781-2777 Fax: [phone]
Rev.B WWW.STAR-MFG.COM May 31, 2007
Installation,
Operation, and
Maintenance Instructions
Electric/Seletronic Griddle-Marine
Models:
124S-M 136S-M
148S-M 160S-M
172S-M

NOTICE
THIS SUPPLEMENT IS FOR MARINE INSTALLED
EQUIPMENT ONLY.
THIS EQUIPMENT IS APPROVED FOR INSTALLATION
ONLY ON VESSELS GREATER THAN 65 FEET IN LENGTH,
IN ACCORDANCE WITH USCG REGULATIONS IN TITLE 46
CFR 110-113.
ANY WIRING USED IN THE INSTALLATION OF THIS
APPLIANCE MUST BE STRANDED COPPER.

3
Safety
CAUTION: THE GRIDDLE IS EXTREMELY HEAVY. FOR SAFE
HANDLING, INSTALLER SHOULD OBTAIN HELP AS
NEEDED, OR EMPLOY APPROPRIATE MATERIALS
HANDLING EQUIPMENT (SUCH AS A FORKLIFT,
DOLLY, OR PALLET JACK) TO REMOVE THE UNIT
FROM THE SKID AND MOVE IT TO THE PLACE OF
INSTALLATION.
CAUTION: ANY STAND, COUNTER OR OTHER DEVICE ON
WHICH GRIDDLE WILL BE LOCATED MUST BE
DESIGNED TO SUPPORT THE WEIGHT OF THE
GRIDDLE.
CAUTION: SHIPPING STRAPS ARE UNDER TENSION AND CAN
SNAP BACK WHEN CUT.
DANGER: THIS APPLIANCE MUST BE GROUNDED AT THE
TERMINAL PROVIDED. FAILURE TO GROUND THE
APPLIANCE COULD RESULT IN ELECTROCUTION
AND DEATH.
WARNING: INSTALLATION OF THE UNIT MUST BE DONE BY
PERSONNEL QUALIFIED TO WORK WITH
ELECTRICITY. IMPROPER INSTALLATION CAN
CAUSE INJURY TO PERSONNEL AND/OR DAMAGE
TO EQUIPMENT. UNIT MUST BE INSTALLED IN
ACCORDANCE WITH ALL APPLICABLE CODES.
NOTICE: The data plate is on top of the control box. The
griddle voltage, wattage, serial number, wire size,
and clearance specifications are on the data plate.
This information should be carefully read and
understood before proceeding with the installation.
NOTICE: The installation of any components such as a vent
hood, grease extractors, fire extinguisher systems,
must conform to their applicable National, State and
locally recognized installation standards.
NOTICE: During the first few hours of operation you may
notice a small amount of smoke coming off the unit,
and a faint odor from the smoke. This is normal for a
new griddle and will disappear after the first few
hours of use.
CAUTION: ALWAYS KEEP THE AREA NEAR THE APPLIANCE
FREE FROM COMBUSTIBLE MATERIALS.
CAUTION: KEEP FLOOR IN FRONT OF EQUIPMENT CLEAN
AND DRY. IF SPILLS OCCUR, CLEAN IMMEDIATELY,
TO AVOID THE DANGER OF SLIPS OR FALLS.

4
WARNING: KEEP WATER AND SOLUTIONS OUT OF
CONTROLS. NEVER SPRAY OR HOSE
CONTROL CONSOLE, ELECTRICAL
CONNECTIONS, ETC.
CAUTION: MOST CLEANERS ARE HARMFUL TO THE SKIN, EYES,
MUCOUS MEMBRANES AND CLOTHING.
PRECAUTIONS SHOULD BE TAKEN TO WEAR RUBBER
GLOVES, GOGGLES OR FACE SHIELD AND
PROTECTIVE CLOTHING. CAREFULLY READ THE
WARNING AND FOLLOW THE DIRECTIONS ON THE
LABEL OF THE CLEANER TO BE USED.
NOTICE: Service on this or any other Lang appliance must be
performed by qualified personnel only. Consult your
Lang Authorized Service Agent Directory. You can call
our toll free number 1-800-807-9054 or visit our website
WWW.STAR-MFG.COM for the service agent nearest you.
WARNING: BOTH HIGH AND LOW VOLTAGES ARE PRESENT
INSIDE THIS APPLIANCE WHEN THE UNIT IS
PLUGGED/WIRED INTO A LIVE RECEPTACLE. BEFORE
REPLACING ANY PARTS, DISCONNECT THE UNIT
FROM THE ELECTRIC POWER SUPPLY.
CAUTION:USE OF ANY REPLACEMENT PARTS OTHER THAN
THOSE SUPPLIED BY LANG OR THEIR AUTHORIZED
DISTRIBUTORS CAN CAUSE BODILY INJURY TO THE
OPERATOR AND DAMAGE TO THE EQUIPMENT AND
WILL VOID ALL WARRANTIES.

5
Table of Contents
1. Notice...................................................................... 2
2. Precautions/Information.......................................... 3
3. Table Of Contents................................................... 5
4. Equipment Description............................................ 6
5. Unpacking ............................................................... 7
6. Installation............................................................... 8
7. Initial Start-Up ......................................................... 10
8. Operation ................................................................ 11
9. Cleaning.................................................................. 12
10. Troubleshooting ...................................................... 13 -14
11. Parts List ................................................................. 15 - 18
12. Wiring Diagram ....................................................... 19
13. Cruise Line Warranty .............................................. 20

6
Equipment Description
Exterior Construction
The griddle dimensions are 17". (43.18cm) High, 30" (76.20cm) deep,
and width depends on the actual model number.
The sides, bottom, and rear wall are constructed of double wall
stainless steel, which allows closer installation to combustible
surfaces.
The griddle surface is made of 1 in. thick, highly polished steel to
reduce hot and cold spots, recovery problems, warping, and ensure
even heat to the edges of the griddle.
Controls
Each twelve-inch section has its own temperature selector switch that
snaps into place to lock in any temperature from 175°F(79°C) to
450°F(232°C) in 25°increments.
Each twelve-inch section of the griddle is controlled by an area
sensitive RTD probe, which can sense and react to a temperature
change of +/- 4°F(-16°C).
Each twelve-inch section has a set of 6 kW elements for high
efficiency, quick recovery and outstanding performance
Technical
The Electric/Seletronic Marine Griddle operates on either 208/240V
or 480V. This must be specified when ordering.
Minimum clearances: 2” from side and back.

7
Unpacking
Receiving the Griddle
Upon receipt, check for freight damage, both visible and concealed. Visible damage should
be noted on the freight bill at the time of delivery and signed by the carrier's agent.
Concealed loss or damage means loss or damage which does not become apparent until
the merchandise has been unpacked. If concealed loss or damage is discovered upon
unpacking, make a written request for inspection by the carrier's agent within 15 days of
delivery. All packing material should be kept for inspection. Do not return damaged
merchandise to Star Manufacturing International. File your claim with the carrier.
Location
Prior to un-crating, move the griddle as near its intended location as practical. The crating
will help protect the unit from the physical damage normally associated with moving it
through hallways and doorways.
Un-crating
The griddle arrives assembled in a wood frame covered by a cardboard box and strapped to
a skid. Remove the cardboard cover, cut the straps and remove the wood frame.
CAUTION THE UNIT IS EXTREMELY HEAVY. FOR SAFE HANDLING, INSTALLER
SHOULD OBTAIN HELP AS NEEDED, OR EMPLOY APPROPRIATE
MATERIALS HANDLING EQUIPMENT (SUCH AS A FORKLIFT, DOLLY, OR
PALLET JACK) TO REMOVE THE UNIT FROM THE SKID AND MOVE IT TO
THE PLACE OF INSTALLATION.
CAUTION ANY STAND, COUNTER OR OTHER DEVICE ON WHICH UNIT WILL BE
LOCATED MUST BE DESIGNED TO SUPPORT THE WEIGHT OF THE UNIT.
CAUTION SHIPPING STRAPS ARE UNDER TENSION AND CAN SNAP BACK WHEN
CUT.
Remove griddle from skid and place in intended location.

8
Installation
DANGER THIS APPLIANCE MUST BE GROUNDED AT THE TERMINAL
PROVIDED. FAILURE TO GROUND THE APPLIANCE COULD
RESULT IN ELECTROCUTION AND DEATH.
WARNING INSTALLATION OF THE UNIT MUST BE DONE BY
PERSONNEL QUALIFIED TO WORK WITH ELECTRICITY.
IMPROPER INSTALLATION CAN CAUSE INJURY TO
PERSONNEL AND/OR DAMAGE TO EQUIPMENT. UNIT MUST
BE INSTALLED IN ACCORDANCE WITH ALL APPLICABLE
CODES.
NOTICE The data plate is located behind the access panel located
between the grease drawer and the control box. The unit
voltage, wattage, serial number, wire size, and clearance
specifications are on the data plate. This information should
be carefully read and understood before proceeding with the
installation.
NOTICE The installation of any components such as a vent hood,
grease extractors, and/or fire extinguisher systems, must
conform to their applicable National, State and locally
recognized installation standards.
Leg Installation
Screw legs into the 3/8-16 weld nuts provided on the underside of the
griddle.
Place the griddle into its intended location.
For bolt down legs see illustration below for dimensions.
Stand Installation
Assemble the stand and place in its intended place.
For bolt down legs see illustration below for dimension.

9
Installation
Technical Data
NOMINAL AMPS PER LINE
THREE PHASE SINGLE PHASE
208 Volt 240 Volt 480 Volt
MODEL
NUMBER
TOTAL
KW
L1 L2 L3 L1 L2 L3 L1 L2 L3
208V 240V
24” 12.0 50.0 28.8 28.8 43.3 25.0 25.0 21.7 12.5 12.5 57.7 50.0
36” 18.0 50.0 50.0 50.0 43.3 43.3 43.3 21.7 21.7 21.7 86.5 75.0
48” 24.0 75.0 75.0 50.0 65.0 65.0 43.3 32.5 32.5 21.7 115.5 100.0
#1 18.0 50.0 50.0 50.0 43.3 43.3 43.3 21.7 21.7 21.7 86.5 75.0
60” #2 12.0 50.0 28.8 28.8 43.3 25.0 25.0 21.7 12.5 12.5 57.7 50.0
#1 18.0 50.0 50.0 50.0 43.3 43.3 43.3 21.7 21.7 21.7 86.5 75.0
72” #2 18.0 50.0 50.0 50.0 43.3 43.3 43.3 21.7 21.7 21.7 86.5 75.0
PHASING BY WIRE
THREE PHASE SINGLE PHASE
MODEL
NUMBER LINE 1 LINE 2 LINE 3 LINE 1 LINE 2
24” 1,4 2 3 1,3 2,6
36” 1,4 2,5 3,6 1,3,5 2,4,6
48” 1,4,7 2,5,8 3,6,9 1,3,5,7 2,4,6,8
60” #1 1,4 2,5 3,6 1,3,5 2,4,6
60” #2 1,4 2 3 1,3 2,6
72” #1 1,4 2,5 3,6 1,3,5 2,4,6
72” #2 1,4 2,5 3,6 1,3,5 2,4,6
Electrical Connection
There is one power supply connection on the 24, 36, and 48-inch griddles. There are two power
supply connections on 60 and 72-inch griddles. Refer to the power supply chart below, for proper
power supply size.
There is (1) one 1 1/4-inch conduit knockout on 24, 36 and 48-inch griddles located at the rear of the
griddle, through the back and the bottom of the griddle body. There are (2) two 1 1/4-inch conduit
knockouts provided on the 60 and 72-inch griddles. Use a supply wire suitable for at least 194°F
(90°C).
This Selectronic-Marine griddle is shipped from the factory wired for 208/240 or 480 volts. The
208/240 griddle is a dual voltage design. Jumper wires on a terminal strip next to the main power
supply connection determine the griddle voltage. For a 208-volt power supply, leave the jumpers in
place. For a 240-volt power supply disconnect the jumpers as indicated on the tag on the terminal
strip. The 480-volt griddle can be operated on 480 volts only and must be specified when ordering.
Phasing
All griddles are shipped from the factory set up for a three-phase service. Please refer to the power
supply chart below for conversions to single-phase service.

10
Initial Start Up
NOTICE During the first few hours of operation you may notice a small
amount of smoke coming from the griddle surface, and a faint
odor from the smoke. This is normal for a new unit and will
disappear after the first few hours of use.
CAUTION ALWAYS KEEP THE AREA NEAR THE APPLIANCE FREE FROM
COMBUSTIBLE MATERIALS.
CAUTION KEEP FLOOR IN FRONT OF EQUIPMENT CLEAN AND DRY. IF
SPILLS OCCUR, CLEAN IMMEDIATELY, TO AVOID THE
DANGER OF SLIPS OR FALLS.
Pre-Power On
Before starting the griddle for the first time, clean the griddle body and
cooking surface.
Use a mild soap and water solution, then rinse with clear water and dry.
Turning the Power On
Set the main power switch, located at the far left of the control panel, to the
"ON" (up) position (there are two "ON" switches on 5' and 6' griddles).
Set each cooking section's power switch, located next to each temperature
dial, to the "ON" (up) position.
Set the temperature dials to 200°F (93°C).
Heat the griddle at 200°F (93°C) for 2 hours to evaporate any moisture that
may be in the elements.
After 2 hours at 200°F (93°C), turn the griddle temperature up to 350°F
(177°C) for 30 minutes.
After the griddle reaches 350°F (177°C) for 30 minutes, turn the griddle up
another 50°F (10°C) for another ½ hour and repeat this until the griddle is at
450°F (232°C) for 30 minutes.
The griddle may emit a small amount of smoke as the cooking surface
passes the 300°F (149°C) point. Do not be alarmed, the smoke is caused by
oils associated with the manufacturing process and will stop when the griddle
reaches 350°F (177°C).
Seasoning the Cooking Surface
The cooking surface must be "seasoned" in order to eliminate product
sticking during cooking.
To season, heat the griddle to 250°F (121°C).
Once at 250°F (121°C), coat the cooking surface with non-salted vegetable
oil.
Allow the griddle to stand at 250°F (121°C) until the cooking surface looks
dry then coat it again.
Heat the griddle to 350°F (177°C) and repeat the procedure.

11
Operation
Setting the Temperature
If different temperature settings across the same griddle are to be
used, select one side of the griddle and run that at the lowest
temperature. Adjoining sections should be set at progressively higher
temperatures. Do not try to run the end sections hot and the center
sections cool.
Loading the Grill
An understanding of how the griddle sections are controlled will be a
valuable aid in loading your griddle.
A solid state controller independently controls each 12” section.
The sensor for each controller is mounted under the griddle plate in
the center of each cooking section.
If product is loaded directly over the temperature sensor, that section
will turn on and the element will heat the entire cooking section. If
the product is loaded to the side, front or back of the temperature
sensor, the controller will react to the temperature change of the
entire section instead of just one product.
During slow periods minimal loads, do not load directly over the
temperature sensors as this will unnecessarily turn the elements on
and over heat the reminder of the section not being utilized.
During busy periods, a systematic approach should be utilized in
loading the griddle. Load the entire section from rear to front and
continue cooking to the next section if necessary.
Turn the product and continue cooking until it has reached its desired
degree of doneness.
Remove the product from the griddle.
When reloading the griddle, first use the griddle surface on which a
previous load was not placed. This will ensure the proper griddle
temperature.

12
Cleaning
WARNING KEEP WATER AND SOLUTIONS OUT OF CONTROLS. NEVER
SPRAY OR HOSE CONTROL CONSOLE, ELECTRICAL
CONNECTIONS, ETC.
CAUTION MOST CLEANERS ARE HARMFUL TO THE SKIN, EYES, MUCOUS
MEMBRANES AND CLOTHING. PRECAUTIONS SHOULD BE
TAKEN TO WEAR RUBBER GLOVES, GOGGLES OR FACE
SHIELD AND PROTECTIVE CLOTHING. CAREFULLY READ THE
WARNING AND FOLLOW THE DIRECTIONS ON THE LABEL OF
THE CLEANER TO BE USED.
•Always start with a cold griddle.
•The stainless exterior can easily be cleaned using a good non-abrasive cleaner.
•Always follow the cleaner manufacturer's instructions when using any cleaner.
•Always apply these cleaners when the griddle is cold and rub in the direction of the
metal's grain.
•At least once a day, remove the waste drawer and wash in the same way as an ordinary
cooking utensil. The drawers are removed by pulling forward until they are released from
their track.
Griddle Surface Care (non-chromium surfaces)
It takes very little time and effort to keep the griddle attractive and performing at top efficiency.
If grease is permitted to accumulate, it will form a gummy cake and then carbonize into a hard
substance which is extremely difficult to remove. To prevent this condition, the following
suggestions for cleanliness should be followed:
After each use, scrape the griddle with a scraper or flexible spatula to remove excess grease
and food. A waste drawer is provided for the scrapings. If there is an accumulation of burned
on grease and food, the griddle should be thoroughly scoured and seasoned. Use pumice or
griddle stone while the griddle is warm.
Do not use steel wool because of the danger of steel slivers getting into the food.

13
Troubleshooting
NOTICE
Service on this or any other Lang Manufacturing appliance must be
performed by qualified personnel only. Consult your authorized service
agent directory or call the factory at 1-800-807-9054, or visit our website
at WWW.STAR-MFG.COM For the service agent nearest you.
WARNING
BOTH HIGH AND LOW VOLTAGES ARE PRESENT INSIDE THIS
APPLIANCE WHEN THE UNIT IS PLUGGED/WIRED INTO A LIVE
RECEPTACLE. BEFORE REPLACING ANY PARTS, DISCONNECT THE
UNIT FROM THE ELECTRIC POWER SUPPLY.
CAUTION
USE OF ANY REPLACEMENT PARTS OTHER THAN THOSE SUPPLIED
BY LANG OR THEIR AUTHORIZED DISTRIBUTORS CAN CAUSE
BODILY INJURY TO THE OPERATOR AND DAMAGE TO THE
EQUIPMENT AND WILL VOID ALL WARRANTIES.
Troubleshooting is not an exact science. Several factors may play a part in why your machine is not operating
correctly. The following symptoms are a general idea of what may be causing the malfunction and should not
be considered the complete answer to the situation that you have with your machine. Here are some of the
possible problems you may encounter and possible solutions to those problems.
If the information does not assist you in correcting the problem, contact the nearest Lang service
representative or Lang Manufacturing.
Refer to the Symptoms column to locate the type of failure then to the Possible Cause for the items to be
checked.
To test for a possible cause, refer to the TEST section and locate the Possible Cause then refer to test to
identify test procedures.
Symptom Possible Cause
Whole griddle will not heat •No power to griddle
•Failed power switch
•Failed transformer.
One section will not heat •Failed power switch (for that section)
•Failed probe
•Failed circuit board
•Failed 12-position switch
•Failed contactor
•Failed element.
Product burning •Product left on griddle too long
•Failed probe
•Failed circuit board
•Failed 12-position switch
Product under cooked •Product removed too soon
•Failed probe
•Failed circuit board
•Failed 12-position switch

14
Troubleshooting Cont’d
Testing
Possible Cause Test
Product is cooked too long •No test available, operational condition
Failed probe •Check probe for proper resistance
Failed circuit board •Confirm that circuit board is getting correct voltage and putting out correct
voltage*
Failed transformer •Check both primary and secondary coils for correct voltage*
Failed contactor •Remove the wires from the contactor coil and check for continuity across the
contactor coil connection*
•Ensure the contactor moveable points move freely up and down
Failed element •Confirm that elements are getting correct voltage and have continuity*
* If an item on the list is followed by an asterisk (*) the work should be done by a factory authorized service
representative.

15
Parts List May 31, 2007, Rev. B
124S-480VM Selectronic Marine Griddle
PART NO. DESCRIPTION Qty Application
2A-72500-05 LEG 4 W/BOLT DOWN ADJ 4 124S-480VM
2E-30303-06 SWT TOG ON-ON DPDT BLK 3 124S-480VM
2E-30304-22 SWTCB175-450oFW/41100-13 2 124S-480VM
2E-30500-02 TRM STRP 4 POLE 30A 600V 1 124S-480VM
2E-30500-07 TRM BLOCK 3PLELRGE 125AMP 1 124S-480VM
2E-30501-03 TERM STRP 4 POLE W/PUSH 1 124S-480VM
2E-30701-04 CONTC 2POLE 30A 24VAC 2 124S-480VM
2E-31400-15 XFRMR 480/24VAC 1 124S-480VM
2E-40101-19 CIRBD SI TEMP CNTRL NO 2 124S-480VM
2E-41100-17 TEMP PROBE SEL LG GRIDDLE 2 124S-480VM
2J-31601-02 PILOT LT 480V 6LEAD BLK 2 124S-480VM
2J-31601-07 PILOT LT 28V 6 LEAD WHT 1 124S-480VM
2N-11030-31 ELMNT GRID 480V 5991W 2 124S-480VM
2P-50100-05 GROOVED GRIDDLE CLEANING
2P-50100-051 GRVED GRDLE BRUSH REPL
2P-50100-052 GRVED GRDLE BRUSH REPL
K9-XL-235-1 GREASE BUCKET ASSY S/S 1 124S-480VM
K9-XL-722-15 PLATE ASY 2' SEL .5 GRV 1 124S-480VM
2R-70701-28 KNB BLK 1/4BUSH2SETSCW@90 2 124S-480VM
136S-440VM & 136S-480VM Selectronic Marine Griddle
PART NO. DESCRIPTION Qty Application
2A-72500-05 LEG 4 W/BOLT DOWN ADJ 4 136S-440VM & 480VM
2E-30303-06 SWT TOG ON-ON DPDT BLK 4 136S-440VM & 480VM
2E-30304-22 SWTCB175-450oFW/41100-13 3 136S-440VM & 480VM
2E-30500-03 TRM STRP 6 POLE 30A 300V 1 136S-440VM & 480VM
2E-30500-07 TRM BLOCK 3PLELRGE 125AMP 1 136S-440VM & 480VM
2E-30501-05 TRM STRP 6 POLE W/2PUSH 1 136S-440VM & 480VM
2E-30701-04 CONTC 2POLE 30A 24VAC 3 136S-440VM & 480VM
2E-31400-15 XFRMR 480/24VAC 1 136S-440VM & 480VM
2E-40101-19 CIRBD SI TEMP CNTRL NO 3 136S-440VM & 480VM
2E-41100-17 TEMP PROBE SEL LG GRIDDLE 3 136S-440VM & 480VM
2J-31601-02 PILOT LT 480V 6LEAD BLK 3 136S-440VM & 480VM
2J-31601-07 PILOT LT 28V 6 LEAD WHT 1 136S-440VM & 480VM
2N-11030-31 ELMNT GRID 480V 5991W 3 136S-480VM
2N-11030-48 ELE GRD 440V 5991W XL/LG 3 136S-440VM
2P-50100-05 GROOVED GRIDDLE CLEANING
2P-50100-051 GRVED GRDLE BRUSH REPL
2P-50100-052 GRVED GRDLE BRUSH REPL
2R-70701-28 KNB BLK 1/4BUSH2SETSCW@90 3 136S-440VM & 480VM
K9-XL-235-1 GREASE BUCKET ASSY S/S 1 136S-440VM & 480VM
K9-XL-722-16 PLATE ASY 3' SEL .5 GRV 1 136S-440VM & 480VM

16
Parts List May 31, 2007, Rev. B
148S-480VM Selectronic Marine Griddle
PART NO. DESCRIPTION Qty Application
2A-72500-05 LEG 4 W/BOLT DOWN ADJ 4 148S-480VM
2E-30303-06 SWT TOG ON-ON DPDT BLK 5 148S-480VM
2E-30304-22 SWTCB175-450oFW/41100-13 4 148S-480VM
2E-30500-07 TRM BLOCK 3PLELRGE 125AMP 1 148S-480VM
2E-30501-03 TERM STRP 4 POLE W/PUSH 2 148S-480VM
2E-30701-04 CONTC 2POLE 30A 24VAC 4 148S-480VM
2E-31400-15 XFRMR 480/24VAC 1 148S-480VM
2E-40101-19 CIRBD SI TEMP CNTRL NO 4 148S-480VM
2E-41100-17 TEMP PROBE SEL LG GRIDDLE 4 148S-480VM
2J-31601-02 PILOT LT 480V 6LEAD BLK 4 148S-480VM
2J-31601-07 PILOT LT 28V 6 LEAD WHT 1 148S-480VM
2N-11030-31 ELMNT GRID 480V 5991W 4 148S-480VM
2P-50100-05 GROOVED GRIDDLE CLEANING
2P-50100-051 GRVED GRDLE BRUSH REPL
2P-50100-052 GRVED GRDLE BRUSH REPL
2R-70701-28 KNB BLK 1/4BUSH2SETSCW@90 4 148S-480VM
K9-XL-235-1 GREASE BUCKET ASSY S/S 1 148S-480VM
K9-XL-722-17 PLATE ASY 4' SEL .5 GRV 1 148S-480VM
160S-M Selectronic Marine Griddle
PART NO. DESCRIPTION Qty Application
2A-72500-05 LEG 4 W/BOLT DOWN ADJ 8 160S-M
2E-30303-06 SWT TOG ON-ON DPDT BLK 7 160S-M
2E-30304-22 SWTCB175-450oFW/41100-13 5 160S-M
2E-30500-02 TRM STRP 4 POLE 30A 600V 1 160S-M
2E-30500-03 TRM STRP 6 POLE 30A 300V 1 160S-M
2E-30500-07 TRM BLOCK 3PLELRGE 125AMP 2 160S-M
2E-30501-03 TERM STRP 4 POLE W/PUSH 1 160S-M
2E-30501-05 TRM STRP 6 POLE W/2PUSH 1 160S-M
2E-30701-04 CONTC 2POLE 30A 24VAC 5 160S-M
2E-31400-26 XFORMR 208-240/24-12 40VA 2 160S-M
2E-40101-19 CIRBD SI TEMP CNTRL NO 5 160S-M
2E-41100-17 TEMP PROBE SEL LG GRIDDLE 5 160S-M
2J-31601-01 PILOT LT 250V 6LEAD BLK 7 160S-M
2M-60301-29 PNLLBL SELCT SWTDIAL 450o 5 160S-M
2N-11030-29 ELE GRD 208/240V4.5KW/6KW 5 160S-M
2N-11030-30 ELMNT GRID 208V 1257W 5 160S-M
2R-70701-28 KNB BLK 1/4BUSH2SETSCW@90 5 160S-M
K9-50302-17 5' GRAB BAR ASSY XL-LG 1 160S-M
K9-XL-235-1 GREASE BUCKET ASSY S/S 2 160S-M

17
Parts List May 31, 2007, Rev. B
172S-440VM Selectronic Marine Griddle
PART NO. DESCRIPTION Qty Application
2A-72500-05 LEG 4 W/BOLT DOWN ADJ 8 172S-440VM
2E-30500-03 TRM STRP 6 POLE 30A 300V 2 172S-440VM
2E-30500-07 TRM BLOCK 3PLELRGE 125AMP 2 172S-440VM
2E-30501-05 TRM STRP 6 POLE W/2PUSH 2 172S-440VM
2E-30701-04 CONTC 2POLE 30A 24VAC 6 172S-440VM
2E-31400-15 XFRMR 480/24VAC 2 172S-440VM
2E-40101-19 CIRBD SI TEMP CNTRL NO 6 172S-440VM
2E-41100-17 TEMP PROBE SEL LG GRIDDLE 6 172S-440VM
2J-31601-02 PILOT LT 480V 6LEAD BLK 6 172S-440VM
2J-31601-07 PILOT LT 28V 6 LEAD WHT 2 172S-440VM
2M-60301-29 PNLLBL SELCT SWTDIAL 450o 6 172S-440VM
2N-11030-48 ELE GRD 440V 5991W XL/LG 6 172S-440VM
2R-70701-28 KNB BLK 1/4BUSH2SETSCW@90 6 172S-440VM
K9-50302-18 6' GRAB BAR ASSY XL/LG 1 172S-440VM
K9-XL-235-1 GREASE BUCKET ASSY S/S 2 172S-440VM

18
Wiring Diagram
WIRI

STAR MANUFACTURING
10 Sunnen Drive, St. Louis, MO 63143 U.S.A.
[phone] [phone]
Parts & Service [phone]
www.star-mfg.com
