Braun 7 series User manual

Series 7
www.braun.com
7893s
7855s
7842s
7840s
n.
co
m
Type 5697
Modèle 5697
Modelo 5697
91862290/IV-18
91862290_7893s_7855s_7842s_7840s_NA_S1.indd 191862290_7893s_7855s_7842s_7840s_NA_S1.indd 1 06.04.18 09:2306.04.18 09:23
Stapled booklet, 120 x 170 mm, 40 pages (incl. 8 pages cover), 2/2c = cyan + black
Business Use - P&G AUTHORIZED POA-00040079 Rev 001 Effective Date 2018-04-11 Printed 2018-07-25 Page 1 of 39

English 6
Français 17
Español 27
EN/FR/ES
Braun Infolines
Lignes d’assistance Braun
Líneas de información de Braun
Thank you for purchasing a Braun product.
We hope you are completely satisfied with your
new Braun shaver.
If you have any questions, please visit
www.service.braun.com or call:
US residents 1-800-BRAUN-11
1-800-272-8611
Canadian residents 1-800-387-6657
Merci d’avoir fait l’achat d’un produit Braun.
Nous espérons que vous serez entièrement
satisfait de votre nouveau rasoir Braun.
Si vous avez des questions, veuillez visiter le
www.service.braun.com ou appeler Braun
Canada : 1-800-387-6657
Gracias por haber comprado un producto Braun.
Esperamos que quede completamente
satisfecho con su nuevo producto Braun.
91862290_7893s_7855s_7842s_7840s_NA_S2.indd 191862290_7893s_7855s_7842s_7840s_NA_S2.indd 1 23.03.18 08:4023.03.18 08:40
Business Use - P&G AUTHORIZED POA-00040079 Rev 001 Effective Date 2018-04-11 Printed 2018-07-25 Page 2 of 39

trimmer
trimmer
trimmer
on
off
on
off
trimmer
trimmer
trimmer
wet & dry
1
23
7
4
5
8
10
12
11
9
9b
9a
9c
6
Series 7
Series 7
Series 7
trimmer
trimmer
trimmer
on
off
on
off
wet&dry
Series7 Series7
Series7
4
91862290_7893s_7855s_7842s_7840s_NA_S4.indd 191862290_7893s_7855s_7842s_7840s_NA_S4.indd 1 23.03.18 08:4223.03.18 08:42
Business Use - P&G AUTHORIZED POA-00040079 Rev 001 Effective Date 2018-04-11 Printed 2018-07-25 Page 3 of 39

lock
release
90°
re
le
a
s
e
Series 7
re
le
a
s
e
Series 7
Series 7
Series 7
Series 7
Series
trimmer
re
le
a
s
e
Series
trimmer
m
mer
re
le
a
s
e
Series
m
mer
re
le
a
s
e
Series
ri
mmer
tr
+
lock
trimmer
lock
lock
12
C
B
A
re
le
a
s
e
Series 7
Series 7
5
91862290_7893s_7855s_7842s_7840s_NA_S5.indd 191862290_7893s_7855s_7842s_7840s_NA_S5.indd 1 23.03.18 08:4123.03.18 08:41
Business Use - P&G AUTHORIZED POA-00040079 Rev 001 Effective Date 2018-04-11 Printed 2018-07-25 Page 4 of 39

6
English
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should always be
followed, including the following:
Read all instructions before using this appliance.
When disconnected, the hand-held part of this shaving appliance
may be used in a bath or shower. For safety reasons, the
appliance can only be operated cordless.
DANGER
To reduce the risk of electric shock:
1. The charger unit is not for immersion in water or for use in shower.
2. Do not reach for a charger that has fallen into water. Unplug
immediately.
3. Do not place, store or charge the appliance where it can fall or be
pulled into a tub or sink. Do not place in or drop into water or other
liquid.
4. Except when charging, always unplug this appliance from the
electrical outlet immediately after using.
5. This appliance is provided with a special cord set with integrated
Safety Extra Low Voltage power supply. Do not exchange or
manipulate any part of it.
6. Do not use an extension cord with this appliance.
7. Unplug this appliance before cleaning.
91862290_7893s_7855s_7842s_7840s_NA_S6-40.indd 691862290_7893s_7855s_7842s_7840s_NA_S6-40.indd 6 06.04.18 09:2306.04.18 09:23
Business Use - P&G AUTHORIZED POA-00040079 Rev 001 Effective Date 2018-04-11 Printed 2018-07-25 Page 5 of 39

7
WARNING
To reduce the risk of burns, fire, electric shock, or injury to persons:
1. Close supervision is necessary when this appliance is used by, on, or
near children or persons with disabilities.
2. Use this appliance only for its intended use as described in this
manual. Do not use attachments not recommended by the
manufacturer.
3. Never operate this appliance if it has a damaged cord or plug, if it is
not working properly, if it has been dropped or damaged, or if the
power supply has been dropped into water. Return the appliance to
a service center for examination and repair.
4. Keep the cord away from heated surfaces.
5. Never drop or insert any object into any opening of the appliance.
6. Do not use outdoors or operate where aerosol (spray) products are
being used or where oxygen is being administered.
7. Do not use this appliance with a damaged or broken foil, as serious
skin injuries may occur.
8. Always attach plug to appliance first, then to outlet. To disconnect,
turn all controls off, then remove plug from outlet.
9. When plugging to an electrical outlet outside North America, use a
plug adapter to match the outlet’s pin configuration.
10. Caution: The battery used in this device may present a fire or
chemical burn hazard if mistreated. Do not disassemble, heat above
100 °C (212 °F), or incinerate.
11. To recharge the battery, only use the detachable power supply
provided with this appliance. If the appliance is marked
492, only use Braun power supplies coded 492-XXXX.
SAVE THESE INSTRUCTIONS
91862290_7893s_7855s_7842s_7840s_NA_S6-40.indd 791862290_7893s_7855s_7842s_7840s_NA_S6-40.indd 7 06.04.18 09:2306.04.18 09:23
Business Use - P&G AUTHORIZED POA-00040079 Rev 001 Effective Date 2018-04-11 Printed 2018-07-25 Page 6 of 39

8
Our products are designed to meet the highest standards of quality, functionality and
design. Thank you for your trust in Braun’s quality, and we hope you enjoy your new
Braun shaver.
Important
Do not open the appliance! Only at the end of the product’s useful life, disassemble the
rechargeable battery for disposal reasons as shown in the battery removal section.
This product is for household use only.
Description
1 Foil & Cutter cassette
2 Cassette release button
3 Shaver head lock switch
4 Pop-out long hair trimmer
5 On/off switch
6 – setting button (sensitive)
7 + setting button (intensive)
8 Reset button
9 Shaver display
9a Charging lights (green)
9b Low-charge light (red)
9c Replacement symbol
10 Shaver power socket
11 Travel case
12 Special cord set (design can differ)
Charging
Recommended ambient temperature for charging is 41 °F to 95 °F / 5 °C to 35 °C.
The battery may not charge properly or at all under extreme low or high temperatures.
Recommended ambient temperature for shaving is 60 °F to 95 °F / 15 °C to 35 °C.
Do not expose the shaver to temperatures higher than 122 °F / 50 °C for extended
periods of time.
• Using the special cord set (12), connect the shaver to an electrical outlet with the
motor switched off and charge it for at least one hour.
• A full charge provides up to 50 minutes of cordless shaving time. This may vary
according to your beard growth.
Charging lights (9a)
The green charging lights show the charge status of the batteries. The green charging
light blinks when the shaver is being charged or switched on. When the battery is fully
charged, all green charging lights shine permanently, provided the shaver is connected
to an electrical outlet. Some minutes after completing the charging, the shaver
switches to the stand-by-mode: The display turns off.
Low-charge light (9b)
The red low-charge light flashes when the battery is running low. The remaining battery
capacity is sufficient for 2 to 3 shaves.
91862290_7893s_7855s_7842s_7840s_NA_S6-40.indd 891862290_7893s_7855s_7842s_7840s_NA_S6-40.indd 8 06.04.18 09:2306.04.18 09:23
Business Use - P&G AUTHORIZED POA-00040079 Rev 001 Effective Date 2018-04-11 Printed 2018-07-25 Page 7 of 39

9
Using the shaver
How to use
Press the on/off switch (5) to operate the shaver:
• The pivoting shaver head and floating foils automatically adjust to every contour of
your face.
• To shave hard to reach areas (e.g. under the nose), first slide the shaver head to the
back position, afterwards move the head lock switch (3) to the back. The pivoting
head is locked at this angle.
• To trim sideburns, moustache or beard, slide the pop-out long hair trimmer (4)
upwards.
Tips for the perfect dry shave
For best shaving results, Braun recommends you follow 3 simple steps:
1. Always shave before washing your face.
2. At all times, hold the shaver at right angles (90°) to your skin.
3. Stretch your skin and shave against the direction of your beard growth.
Personalizing your shaver
By holding down the accelerator button –/+ (6) or (7) you can adjust the shaving power
to your individual needs in the different areas of your face from sensitive to intensive.
The pilot light in the on/off switch (5) changes within the following range:
(–) sensitive shave
– light blue
– dark blue
– green
(+) intensive shave
For a thorough and fast shave we recommend the green (intensive) setting.
When switching on next time, the last used setting will be activated.
Cleaning
Cleaning under running water
• Switch the shaver on (cordless) and rinse the shaver head under hot running
water until all residues have been removed. You may use liquid soap without
abrasive substances. Rinse off all foam and let the shaver run for a few more
seconds.
• Next, switch off the shaver, press the release button (2) to remove the Foil & Cutter
cassette (1) and let it dry. The shaver shall not be used until it has dried completely.
• If you regularly clean the shaver under water, then once a week apply a drop of light
machine oil (not included) on top of the Foil & Cutter cassette and the long hair
trimmer.
The shaver should be cleaned after each foam usage.
91862290_7893s_7855s_7842s_7840s_NA_S6-40.indd 991862290_7893s_7855s_7842s_7840s_NA_S6-40.indd 9 06.04.18 09:2306.04.18 09:23
Business Use - P&G AUTHORIZED POA-00040079 Rev 001 Effective Date 2018-04-11 Printed 2018-07-25 Page 8 of 39

10
Cleaning with a brush
• Switch off the shaver. Remove the Foil & Cutter cassette (1) and tap it out on a flat
surface. Using a brush, clean the inner area of the pivoting head. However, do not
clean the cassette with the brush as this may damage it.
Keeping your shaver in top shape
Replacing the Foil & Cutter cassette / reset
To maintain 100% shaving performance, replace the Foil & Cutter cassette (1), when
the replacement symbol (9c) lights up on the shaver display (after about 18 months)
or when cassette is worn. The replacement symbol will remind you during the next
7 shaves to replace the Foil & Cutter cassette. Then the shaver will automatically reset
the display.
After you have replaced the Foil & Cutter cassette, use a ball-pen to push the reset
button (8) for at least 3 seconds to reset the counter. While doing so, the replacement
light blinks and goes off when the reset is complete. The manual reset can be done at
any time.
Accessories
Available at your dealer or Braun Service Centres:
• Foil & Cutter cassette 70S/70B
Battery removal
This appliance contains a rechargeable battery. Before disposing of the appliance,
disassemble the housing as shown, remove the rechargeable battery and recycle or
dispose of properly, according to local guidelines.
Caution: Disassembling the appliance will destroy it and invalidate the warranty.
Li-Ion
1. 2. 3. 4.
The cleaning cartridge can be disposed of with regular household waste.
Subject to change without notice.
For electric specifications, see printing on the special cord set.
91862290_7893s_7855s_7842s_7840s_NA_S6-40.indd 1091862290_7893s_7855s_7842s_7840s_NA_S6-40.indd 10 06.04.18 09:2306.04.18 09:23
Business Use - P&G AUTHORIZED POA-00040079 Rev 001 Effective Date 2018-04-11 Printed 2018-07-25 Page 9 of 39

11
Trouble-Shooting
Problem Possible reason Remedy
SHAVER
Unpleasant
smell from the
shaver head.
1. Shaver head is cleaned
with water.
2. Cleaning cartridge is in use
for more than 8 weeks.
1. When cleaning the shaver head with
water only use hot water and from
time to time some liquid soap
(without abrasive substances).
Remove Foil & Cutter cassette to
let it dry.
2. Change cleaning cartridge at least
every 8 weeks.
Battery
Performance
dropped
significantly.
1. Foil and cutter are worn
which requires more power
for each shave.
2. Shaver head is regularly
cleaned with water but not
lubricated.
1. Renew Foil & Cutter cassette.
2. If the shaver is regularly cleaned
with water, apply a drop of light
machine oil on top of the foil once
a week for lubrication.
Shaving
Performance
dropped
significantly.
1. Foil and cutter are worn.
2. Personal setting of shaving
performance has been
changed.
3. Shaving system is clogged.
1. Renew Foil & Cutter cassette.
2. For a thorough and fast shave we
recommend the green (intensive)
setting.
3. Soak the Foil & Cutter cassette into
hot water with a drop of dish liquid.
Afterwards rinse it properly and tap
it out. Once dry apply a drop of light
machine oil on the foil.
Shaver turns
off with fully
charged battery.
Foil and cutter are worn
which requires more power
than the motor can deliver.
The appliance turns off.
– Renew Foil & Cutter cassette.
– Regularly oil the shaving system,
especially when cleaning with water
only.
Battery
segments in
the display are
skipped with
decreasing
battery capacity.
Foil and cutter are worn
which requires more power
for each shave.
– Renew Foil & Cutter cassette.
– Regularly oil the shaving system,
especially when cleaning with water
only.
Shaving parts
have been
changed recently
but replacement
symbol lights up.
Reset button has not been
pushed.
Push the reset button for at least
3 seconds to reset the counter.
91862290_7893s_7855s_7842s_7840s_NA_S6-40.indd 1191862290_7893s_7855s_7842s_7840s_NA_S6-40.indd 11 06.04.18 09:2306.04.18 09:23
Business Use - P&G AUTHORIZED POA-00040079 Rev 001 Effective Date 2018-04-11 Printed 2018-07-25 Page 10 of 39

13
How to obtain service in Canada
Should your Braun product require service, please call 1-800-387-6657
to be referred to the Authorized Braun Service Center closest to you or
visit www.service.braun.com.
To obtain service:
A. Carry the product in to the Authorized Braun Service Center of your
choice or,
B. Ship the product to the Authorized Braun Service Center of your choice.
Pack the product well.
Ship the product prepaid and insured (recommended).
Include a copy of your proof of purchase to verify warranty
coverage, if applicable
To obtain original Braun replacement parts & accessories:
Contact a Braun Authorized Service Center.
Please call 1-800-387-6657 to be referred to the Authorized Braun
Service Center closest to you or visit www.service.braun.com.
To speak to a Braun Service Representative:
Please call 1-800-387-6657.
91862290_7893s_7855s_7842s_7840s_NA_S6-40.indd 1391862290_7893s_7855s_7842s_7840s_NA_S6-40.indd 13 06.04.18 09:2306.04.18 09:23
Business Use - P&G AUTHORIZED POA-00040079 Rev 001 Effective Date 2018-04-11 Printed 2018-07-25 Page 12 of 39

14
60 day money back satisfaction guarantee
for men’s grooming products
Braun Shavers
Braun Beard Trimmers
Once you have tried your new Braun shaver or beard trimmer, we are
confident you will appreciate its performance. We suggest using the
product regularly for 2 to 3 weeks. If you are not satisfied with the
product, please call 1-800-211-6661 for instructions on how to return the
product. Return the unit and all parts within 60 days of purchase. Retain
original cash receipt, product and all product parts, including the box.
Do not return to the retailer for guarantee fulfillment.
Please note: No refunds will be made for any product damaged by
accident, neglect or unreasonable use.
Your product must be shipped in its original packaging, with your original
sales slip indicating the date of purchase.
Please include the following information when you return your product:
Name
Street
City
State
Zip code
Telephone number
Please allow 6-8 weeks for handling.
91862290_7893s_7855s_7842s_7840s_NA_S6-40.indd 1491862290_7893s_7855s_7842s_7840s_NA_S6-40.indd 14 06.04.18 09:2306.04.18 09:23
Business Use - P&G AUTHORIZED POA-00040079 Rev 001 Effective Date 2018-04-11 Printed 2018-07-25 Page 13 of 39

16
FOR CANADA ONLY
2 year limited warranty
(foil and cutter block excluded)
In the event a Braun Shaver fails to function within 2 years from date
of purchase, because of defects in material or workmanship, and the
consumer returns the unit to an authorized service center, Braun Canada,
will, at its option, either repair or replace the unit without additional charge
to the consumer.
This guarantee does not cover any product, which has been damaged by
dropping, tampering, wrong current, servicing performed or attempted
by unauthorized service agencies, misuse or abuse, kinks in the shaver
foil as well as the normal wear of the shearing parts.
Exclusion of Warranties: The foregoing warranty is the sole warranty
offered by Braun Canada. Braun Canada hereby disclaims any implied
warranty or merchantability or fitness for any particular purpose. In no
event will Braun Canada be responsible for consequential damages
resulting from the use of this product.
91862290_7893s_7855s_7842s_7840s_NA_S6-40.indd 1691862290_7893s_7855s_7842s_7840s_NA_S6-40.indd 16 06.04.18 09:2306.04.18 09:23
Business Use - P&G AUTHORIZED POA-00040079 Rev 001 Effective Date 2018-04-11 Printed 2018-07-25 Page 15 of 39
