4
English
Our products are designed to meet the highest standards of quality,
functionality and design. We hope you enjoy your new Braun Shaver.
Read these instructions completely, they contain safety information.
Keep them for future reference.
Warning
Your shaving system is provided with a special cord set,
which has an integrated Safety Extra Low Voltage power sup-
ply. Do not exchange or tamper with any part of it, otherwise
there is risk of an electric shock. Only use the special cord set
provided with your appliance.
Do not shave with a damaged foil or cord.
The shaver head is suitable for cleaning under running
tap water. Detach the shaver from the power supply
before cleaning the shaver head in water.
This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning the safe use
of the appliance and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children unless they are
older than 8 years and supervised.
To prevent the cleaning fluid from leaking, ensure that the
Clean&Renew station is placed on a flat surface. When a
cleaning cartridge is installed, do not tip, move suddenly or
transport the station in any way as cleaning fluid might spill
out of the cartridge. Do not place the station inside a mirror
cabinet, nor over a radiator, nor place it on a polished or lac-
quered surface.
The cleaning cartridge contains a highly flammable liquid so
keep it away from sources of ignition. Do not smoke near the
station. Do not expose to direct sunlight for long periods of
time.
Do not refill the cartridge and use only original Braun refill car-
tridges.
97155783_790cc_S4-106.indd 4 18.11.14 14:43
CSS APPROVED Effective Date 20Nov2014 GMT - Printed 27Jan2015 Page 4 of 106

5
Description
Clean&Renew station
1Cleaning fluid display
2Lift button for cartridge exchange
3Station-to-shaver contacts
4Start button
DFast clean button
5Cleaning program indicators
6Station power socket
7Cleaning cartridge
Shaver
8Foil & Cutter cassette
9Cassette «release» button
0Shaver head «lock» switch
qPop-out long hair trimmer
wOn/off switch
e(–) setting button (sensitive)
r(+) setting button (intensive)
tReset button
zShaver display
uShaver-to-station contacts
iShaver power socket
oTravel case
pSpecial cord set
Before shaving
Prior to first use you must connect the shaver to
an electrical outlet using the special cord set p
or alternatively proceed as below.
Installing the Clean&Renew station
• Using the special cord set p, connect the
station power socket 6to an electrical outlet.
• Press the lift button 2to open the housing.
• Hold the cleaning cartridge 7down on a flat,
stable surface (e.g. table).
• Carefully remove the lid from the cartridge.
• Slide the cartridge into the base of the station
as far as it will go.
• Slowly close the housing by pushing it down
until it locks.
The cleaning fluid display 1will show how much
fluid is in the cartridge:
up to 30 cleaning cycles available
up to 7 cleaning cycles remaining
new cartridge required
f
a
s
t
c
l
e
a
n
f
a
s t
c
l
e
a
n
f
a
s
t
c
l
e
a
n
2
1
97155783_790cc_S4-106.indd 5 18.11.14 14:43
CSS APPROVED Effective Date 20Nov2014 GMT - Printed 27Jan2015 Page 5 of 106

6
Charging and cleaning the shaver
Insert the shaver head down into the cleaning
station. The contacts uon the back of the
shaver will align with the contacts 3in the
cleaning station. Important: The shaver needs
to be dry and free from any foam or soap
residue!
If required, the Clean&Renew station will auto-
matically charge the shaver. The hygiene status
of the shaver will also be analyzed and one of
the following cleaning program indicators 5will
light up:
shaver is clean
short economical cleaning required
normal level of cleaning required
high intensive cleaning required
If the station selects one of the required cleaning
programs, it will not start unless you press the
start button 4.For best shaving results, we
recommend cleaning after each shave.
Whilst cleaning is in progress, the respective
cleaning program indicator will blink. Each
cleaning program consists of several cycles,
where cleaning fluid is flushed through the
shaver head and a heat drying process dries
the shaver. Depending on the program selected
the total cleaning time will range from 32 to 43
minutes.
The cleaning programs should not be inter-
rupted. Please note that whilst the shaver is
drying, the shaver head may be hot and wet.
When the program is finished, the blue
indicator will light up. Your shaver is now clean
and ready for use.
Fast cleaning
Push the fast clean button Dto activate
the fast clean program without drying. This
program takes about 25 seconds only and is
recommended when you do not have time to
wait for one of the automatic cleaning programs.
If you remove the shaver just after the program
has finished, wipe off the shaver head with a
tissue to avoid dripping.
Stand-by mode
10 minutes after completing the charging or
cleaning session, the Clean&Renew station
switches to the stand-by mode: The indicators
of the Clean&Renew station turn off.
trimmer
Series 7
97155783_790cc_S4-106.indd 6 18.11.14 14:43
CSS APPROVED Effective Date 20Nov2014 GMT - Printed 27Jan2015 Page 6 of 106

7
Shaver display
The shaver display zshows the charge status
of the battery on the left, and the hygiene status
on the right. 6 dark segments are shown on each
side when the battery is fully charged and the
shaver is hygienically clean.
Battery segments:
During charging or when using the shaver, the
respective battery segments will blink. When
fully charged all 6 segments are shown. With
decreasing charge the segments gradually
disappear.
Low charge indicator:
The low charge indicator provided with a red
frame blinks to indicate that the charge has
dropped below 20%. The remaining battery
capacity is sufficient for 2 to 3 shaves.
Hygiene segments:
All 6 hygiene segments will appear after the
shaver has been cleaned in the Clean&Renew
station. When the shaver is being used, the
hygiene segments will gradually disappear.
Once the shaver is returned to the station, the
system will automatically select the appropriate
cleaning program and restore the segments
to maximum hygiene. Given that rinsing the
shaver under tap water is not as hygienic as the
cleaning station, the hygiene segments will only
restore themselves when the shaver has been
cleaned in the Clean&Renew station.
Charging information
• A full charge provides up to 50 minutes
of cordless shaving time. This may vary
according to your beard growth.
• Recommended ambient temperature for
charging is 5 °C to 35 °C. The battery may not
charge properly or at all under extreme low or
high temperatures. Recommended ambient
temperature for shaving is 15 °C to 35 °C.
Do not expose the appliance to temperatures
higher than 50 °C for extended periods of time.
Using your shaver
Personalizing your shaver
With the (–) eand (+) rbuttons you can choose
the best setting for shaving different areas of
your face and as per your specific needs.
The different settings are indicated by the pilot
light incorporated in the on/off switch w:
h
y
g
i
e
n
e
b
a
t
t
e
r
y
h
y
g
i
e
n
e
b
a
t
t
e
r
y
h
y
g
i
e
n
e
b
a
t
t
e
r
y
b
a
t
a
t
e
r
y
r
97155783_790cc_S4-106.indd 7 18.11.14 14:43
CSS APPROVED Effective Date 20Nov2014 GMT - Printed 27Jan2015 Page 7 of 106

8
• dark blue (powerful shave)
• light blue (normal)
• white (for a thorough comfortable shave in
sensitive areas of your face such as neck)
For a thorough and fast shave we recommend
the (+) setting.
When switching on next time, the last used
setting will be activated.
How to use
Press the on/off switch wto operate the shaver:
• The pivoting shaver head and floating foils
automatically adjust to every contour of your
face.
• To shave hard to reach areas (e.g. under the
nose) slide the shaver head «lock» switch 0to
the back position to lock the pivoting head at
an angle.
• To trim sideburns, moustache or beard, slide
the pop-out long hair trimmer upwards.
Tips for the perfect dry shave
For best shaving results, Braun recommends you
follow 3 simple steps:
1. Always shave before washing your face.
2. At all times, hold the shaver at right angles
(90°) to your skin.
3. Stretch your skin and shave against the
direction of your beard growth.
Shaving with the cord
If the shaver has run out of power (discharged),
and you do not have the time to recharge it in the
Clean&Renew station, you may also shave with
the shaver connected to an electrical outlet via
the special cord set.
Cleaning
Automatic cleaning
After each shave, return the shaver to the
Clean&Renew station and proceed as described
above in the section «Before shaving».
All charging and cleaning needs are then
automatically taken care of. With daily use, a
cleaning cartridge should be sufficient for about
30 cleaning cycles.
+normal
lock
lock
t
r
lock
12
trimmer
+
lock
release
90°
trimmer
97155783_790cc_S4-106.indd 8 18.11.14 14:43
CSS APPROVED Effective Date 20Nov2014 GMT - Printed 27Jan2015 Page 8 of 106

9
The hygienic cleaning cartridge contains ethanol
or isopropanol (specification see cartridge),
which once opened will naturally evaporate
slowly. Each cartridge, if not used daily, should
be replaced after approximately 8 weeks.
The cleaning cartridge also contains lubricants,
which may leave residual marks on the outer foil
frame after cleaning. However, these marks can
be removed easily by wiping gently with a cloth
or soft tissue paper.
Manual cleaning
Rinsing the shaver head under running water
is an alternative way to keep the shaver clean,
especially when travelling:
• Switch on the shaver (cordless) and rinse the
shaver head under hot running water until all
residues have been removed. You may use
liquid soap without abrasive substances.
Rinse off all foam and let the shaver run for a
few more seconds.
• Next, switch off the shaver, press the «release»
button 9to remove the Foil & Cutter cassette
8and let it dry.
• If you regularly clean the shaver under
water, then once a week apply a drop of
light machine oil on top of the Foil & Cutter
cassette.
Alternatively, you may clean the shaver using a
brush:
• Switch off the shaver. Remove the Foil & Cutter
cassette 8and tap it out on a flat surface.
Using the brush, clean the inner area of the
pivoting head. However, do not clean the
cassette with the brush as this may damage it.
Cleaning the housing
From time to time clean the housing of the
shaver and the Clean&Renew station with a
damp cloth, especially inside the cleaning
chamber where the shaver rests.
Replacing the cleaning cartridge
After having pressed the lift button 2to open the
housing, wait for a few seconds before removing
the used cartridge to avoid any dripping.
Before discarding the used cartridge, make sure
to close the openings using the lid of the new
cartridge, since the used cartridge will contain
contaminated cleaning solution.
er
re le
a
s
e
trimmer
re le
a
s
e
re
le
a
s
e
Series 7
Series 7
Series
Series
trimmer
re
le
a
s
e
re
le
a
s
e
re
le
a
s
e
Series 7
Series 7
new old
97155783_790cc_S4-106.indd 9 18.11.14 14:43
CSS APPROVED Effective Date 20Nov2014 GMT - Printed 27Jan2015 Page 9 of 106

10
Keeping your shaver in top shape
Replacing the Foil & Cutter cassette / reset
To maintain 100% shaving performance, re-
place the Foil & Cutter cassette 8, when the
replacement symbol lights up on the shaver
display zafter about 18 months or when
cassette is worn.
The replacement symbol will remind you during
the next 7 shaves to replace the Foil & Cutter
cassette. Then the shaver will automatically reset
the display.
After you have replaced the Foil & Cutter
cassette, use a ball-pen to push the reset button
tfor at least 3 seconds to reset the counter.
While doing so, the replacement light blinks and
goes off when the reset is complete. The manual
reset can be done at any time.
Accessories
Available at your dealer or Braun Service
Centres:
• Foil & Cutter cassette 70S
• Cleaning cartridge Clean&Renew CCR
Environmental notice
Product contains batteries and/or
recyclable electric waste. For environment
protection do not dispose of in household
waste, but for recycling take to electric
waste collection points provided in your country.
The cleaning cartridge can be disposed of with
regular household waste.
Subject to change without notice.
For electric specifications, see printing on the
special cord set.
h
y
g
i
e
n
e
b
a
t
t
e
r
y
re
le
a
s
e
Series 7 70S
70S
97155783_790cc_S4-106.indd 10 18.11.14 14:43
CSS APPROVED Effective Date 20Nov2014 GMT - Printed 27Jan2015 Page 10 of 106
