Braun FlexXP System 5691 User manual

Flex XP 5691 KURTZ DESIGN 18.08.04
www.braun.com/register
Type
5 722
+
5325
5691
min
min
start • stop
5691
charge
5722459_5691_MN_S1 Seite 1 Donnerstag, 19. August 2004 11:09 11

Deutsch 6, 47, 51
English 9, 47, 51
Français 12, 47, 51
Español 16, 48, 51
Português 19, 48, 51
Italiano 22, 48, 51
Nederlands 25, 49, 51
Dansk 28, 49, 51
Norsk 31, 49, 51
Svenska 34, 50, 51
Suomi 37, 50, 51
Türkçe 40, 51
Ελληνικ 43, 50, 51
5-722-459/00/VIII-04/G2
D/GB/F/E/P/I/NL/DK/N/S/FIN/TR/GR
Printed in Germany
Braun Infoline
Haben Sie Fragen zu diesem
Produkt?
Rufen Sie an (gebührenfrei):
00 800 27 28 64 63
00 800 BRAUNINFOLINE
08 44 - 88 40 10
Servicio al consumidor para España:
9 01-11 61 84
Serviço ao Consumidor para Portugal:
808 20 00 33
Servizio consumatori:
(02) 6 67 86 23
Heeft u vragen over dit produkt?
Bel Braun Consumenten-infolijn:
(070) 4 13 16 58
Vous avez des questions sur ce produit ?
Appelez Braun Belgique
(02) 711 92 11
Har du spørgsmål om produktet? Så ring
70 15 00 13
Spørsmål om dette produktet? Ring
22 63 00 93
Frågor om apparaten? Ring Kundservice
020 - 21 33 21
Onko Sinulla kysyttävää tuotteesta? Soita
0203 77877
Müµteri Hizmetleri Merkezi:
0212 - 473 75 85
D
A
CH
E
P
I
NL
B
DK
N
S
FIN
TR
5722459_5691_MN_S2 Seite 1 Mittwoch, 18. August 2004 2:56 14

start • stop
3
6
2
4
7
Flex
600 5691
MN
Explo+Inuse
KURTZ
DESIGN
18
.
08
.
04
5
start • stop
8
5000
6000
Series
Flex Integral / Flex XP
100%
100%
2
3
5000
6000
Series
5691
charge
rt • stop
A 5691
1
4
5722459_5691_MN_S4 Seite 1 Donnerstag, 19. August 2004 11:07 11

Clean & Charge Flex 600 - 5691 MN- KURTZ DESIGN 18.08.04
2
old
new
new
1
2
3
1
4
5
charge
5691
charge
5691
charge
5691
start • stop
start • stop
start • stop
B 5691
5
5722459_5691_MN_S5 Seite 1 Donnerstag, 19. August 2004 11:10 11

9
AShaver
Our products are designed to meet the
highest standards of quality, functionality and
design. We hope you enjoy your new Braun
shaver.
Warning
Your shaver is provided with a special cord
set with integrated Safety Extra Low Voltage
power supply. Do not exchange or manipulate
any part of it. Otherwise there is a risk of
electric shock.
Description
1 Foil protection cap
2 Shaver foil
3 Cutter block
4 Release button
5 On/off switch («start/stop»)
6 Long hair trimmer
7 Charging light (green)
8 Special cord set
Charging the shaver
•
Using the special cord set, charge the shaver
directly off the mains for at least 4 hours
(shaver and special cord set might get warm).
•With normal use the shaver will be charged
automatically after every cleaning in the
Clean&Charge (see section B).
• The green charging light indicates that the
shaver is being charged.
•Afull charge will give up to 40 minutes of
cordless shaving time depending on your
beard growth. However, the maximum
battery capacity will only be reached after
several charging/discharging cycles.
• Best environmental temperature range for
charging is 15 °C to 35 °C.
•When fully discharged, you may also shave
with the shaver connected to the mains via
the special cord set.
Shaving
Turn on the shaver («start»):
The pivoting cutting system automatically
adjusts to every contour of your face.
Trimmer:
When the long hair trimmer is activated, it
allows the controlled trimming of moustache
or sideburns.
Keeping your shaver in top
shape
Automatic cleaning
Your shaver should be cleaned daily in the
Clean&Charge.
Once the shaver is put into in the
Clean&Charge, it is cleaned automatically (see
section B). Manual cleaning is recommended
only when the Clean&Charge is not available,
e.g. when travelling.
Manual cleaning
Always unplug the appliance before cleaning.
Remove the shaver foil (shaver head must be
in central position) and, using the brush, clean
the cutter block and the inner area of the
shaver head. Do not clean the shaver foil with
the brush.
When cleaning the shaver under running
water, make sure it is completely dry before
putting it into the Clean&Charge.
Tips for the perfect shave
• We recommend that you shave before
washing, as the skin tends to be slightly
swollen after washing.
•Hold the shaver at right angles (90°) to the
skin. Stretch the skin and shave against
the direction of beard growth.
• To maintain 100% shaving performance,
replace your foil and cutter block every
18 months or when worn.
English
5722459_5691_MN Seite 9 Mittwoch, 18. August 2004 2:54 14

10
Replacing the shaving parts
To maintain 100% shaving performance,
replace your foil and cutter block every 18
months or when worn. Change both parts at
the same time for a closer shave with less skin
irritation.
(Shaver foil and cutter block:
part no. 5000/6000)
Preserving the batteries
In order to maintain the optimum capacity of
the rechargeable batteries, the shaver has to
be fully discharged (through normal use) every
6 months approximately. Then recharge the
shaver to full capacity. Do not expose the
shaver to temperatures higher than 50 °C for
extended periods of time.
Environmental notice
This appliance is provided with nickel-
cadmium rechargeable batteries. To protect
the environment, do not dispose of the appli-
ance in the household waste at the end of its
useful life. Open the housing as shown on page
45, remove and dispose of the batteries at your
retail store or at appropriate collection sites
according to national or local regulations.
BClean&Charge
Braun Clean&Charge has been developed for
cleaning, charging and storing your shaver.
Clean your shaver daily in the Clean&Charge.
During the automated cleaning process, the
shaver is switched on and off at intervals to
obtain best cleaning results. Since the spe-
cially formulated cleaning fluid contains a
small amount of oil, the cleaning procedure
also fulfills the lubrication needs of the shaver.
Important
• Only use the special cord set supplied with
the shaver.
•In order to avoid any leakage of the cleaning
fluid, place the appliance on a flat, stable
surface. Do not tip, move suddenly or trans-
port in any way if a cleaning cartridge is
installed.
• Do not place the appliance in a mirror cabi-
net, nor store it over radiators, nor place it
on polished or laquered surfaces. Do not
expose to direct sunlight.
•The appliance contains highly flamma-
ble liquid. Keep it away from sources
of ignition. No smoking. Keep out of reach
of children. Do not refill cartridge. Use only
original Braun refill cartridge.
• When cleaning the shaver, its protection
cap should be removed.
Description
1 Lift button for cartridge exchange
2 Contact bow
3 Start/release button
4 Level indicator
5 Cleaning cartridge
Before using Clean&Charge
Installing the cartridge
•Press the lift button (1) to open the housing.
• Hold the cartridge down on a flat, stable
surface (e.g. table). Carefully remove the lid
5722459_5691_MN Seite 10 Mittwoch, 18. August 2004 2:54 14

11
from the cartridge. Slide the cartridge into
the base as far as it will go.
•Slowly close the housing by pushing it down
until it locks.
Replacing the cartridge
After having pressed the lift button to open the
housing, wait for a few seconds before
removing the used cartridge.
Before discarding the used cartridge, make
sure to close the openings using the lid of the
new cartridge, since the used cartridge will
contain contaminated cleaning solution.
The used cartridge can be disposed in the
household waste.
Operating your
Clean&Charge
• Connect your Clean&Charge with the
special cord set to the mains electricity
supply. The special socket at the back is
adjustable to save space. After each shave,
switch the shaver off and put it into the
Clean&Charge, upside down and with the
front showing.
•Push the start/release button (3) to lock and
connect the shaver. The cleaning process
will start (approx. 5 minutes cleaning,
4 hours drying).
• Do not interrupt the cleaning process, as it
leaves the shaver wet and not fit for use. If
interruption is needed nonetheless, press
the start/release button (3).
•After 4 hours the process is finished and the
shaver is ready for use.
To release it, push the start/release button.
•Acleaning cartridge should be sufficient
for about 30 cleaning cycles. When the level
indicator (4) has reached the «min» mark,
the remaining fluid in the cartridge is suffi-
cient for about 5 more cleaning cycles. Then
the cartridge should be replaced, when
used daily approx. every 4 weeks.
• The hygienic cleaning solution cartridge
contains alcohol which, once opened,
will naturally evaporate slowly into the
surrounding air. Each cartridge, if not used
daily should be replaced after approx.
8 weeks.
• Clean the housing from time to time with a
damp cloth, especially the opening where
the shaver rests.
Subject to change without notice.
This product conforms to the
EMC-Directive 89/336/EEC and to the
Low Voltage Regulation (73/23 EEC).
Electric specifications see printing on the
special cord set.
5722459_5691_MN Seite 11 Mittwoch, 18. August 2004 2:54 14

45
Deutsch
Akku-Entsorgung am Ende der Lebensdauer des
Gerätes
Vorsicht! Durch das Öffnen wird das Gerät zerstört. Keine
Garantie für ein geöffnetes Gerät.
English
Battery removal at the end of the product’s useful life
Caution: Opening the handle will destroy the appliance and
invalidate the guarantee.
Français
Retrait des batteries en fin de vie du produit
Attention : L’ouverture du corps du rasoir entraînera sa
destruction et invalidera la garantie.
Español
Batería extraible al final de su periodo vida
Precaución: la manipulación puede ocasionar daños a la
afeitadora e invalidar la garantía.
Português
Bateria substituida no fim do ciclo de vida do produto
Precaução: Se abrir a Máquina irá destruí-la e invalidar a sua
garantia.
Italiano
Eliminazione delle batterie alla fine del ciclo di vita del
prodotto
Attenzione: l’apertura del corpo motore distrugge lo
strumento ed invalida la garanzia del prodotto.
Nederlands
Het verwijderen van de batterij aan het eind van de
nuttige levensduur van het apparaat
Let op: Door het openen van het apparaat wordt deze
vernietigd en vervalt de garantie.
Dansk
Fjern batterierne når produktet er slidt op
Advarsel: Hvis du åbner shaveren ødelægges denne og
garantien dækker ikke.
Cd
+
+
Cd
+
+
5722459_5691_MN Seite 45 Mittwoch, 18. August 2004 2:54 14

47
Deutsch
Garantie
Als Hersteller übernehmen wir für dieses
Gerät – nach Wahl des Käufers zusätzlich
zu den gesetzlichen Gewährleistungsan-
sprüchen gegen den Verkäufer – eine Ga-
rantie von 2 Jahren ab Kaufdatum. Innerhalb
dieser Garantiezeit beseitigen wir nach un-
serer Wahl durch Reparatur oder Austausch
des Gerätes unentgeltlich alle Mängel, die auf
Material- oder Herstellungsfehlern beruhen.
Die Garantie kann in allen Ländern in An-
spruch genommen werden, in denen dieses
Braun Gerät von uns autorisiert verkauft wird.
Von der Garantie sind ausgenommen:
Schäden durch unsachgemäßen Gebrauch,
normaler Verschleiß und Verbrauch sowie
Mängel, die den Wert oder die Gebrauchs-
tauglichkeit des Gerätes nur unerheblich
beeinflussen. Bei Eingriffen durch nicht von
uns autorisierte Braun Kundendienstpartner
sowie bei Verwendung anderer als Original
Braun Ersatzteile erlischt die Garantie.
Im Garantiefall senden Sie das Gerät mit
Kaufbeleg bitte an einen autorisierten Braun
Kundendienstpartner. Die Anschrift für
Deutschland können Sie kostenlos unter
00800/27 28 64 63 erfragen.
English
Guarantee
We grant 2 years guarantee on the product
commencing on the date of purchase. Within
the guarantee period we will eliminate, free of
charge, any defects in the appliance resulting
from faults in materials or workmanship, either
by repairing or replacing the complete appli-
ance as we may choose.
This guarantee extends to every country
where this appliance is supplied by Braun or
its appointed distributor.
This guarantee does not cover: damage due
to improper use, normal wear or use as well as
defects that have a negligible effect on the
value or operation of the appliance.
The guarantee becomes void if repairs are
undertaken by unauthorised persons and if
original Braun parts are not used.
To obtain service within the guarantee period,
hand in or send the complete appliance with
your sales receipt to an authorised Braun
Customer Service Centre.
For UK only:
This guarantee in no way affects your rights
under statutory law.
Françe
Garantie
Nous accordons une garantie de 2 ans
sur ce produit, à partir de la date d’achat.
Pendant la durée de la garantie, Braun
prendra gratuitement à sa charge la réparation
des vices de fabrication ou de matière en
se réservant le droit de décider si certaines
pièces doivent être réparées ou si l’appareil
lui-même doit être échangé.
Cette garantie s’étend à tous les pays où cet
appareil est commercialisé par Braun ou son
distributeur exclusif.
Cette garantie ne couvre pas : les dommages
occasionnés par une utilisation inadéquate
et l’usure normale. Cette garantie devient
caduque si des réparations ont été effectuées
par des personnes non agréées par Braun et
si des pièces de rechange ne provenant pas
de Braun ont été utilisées.
Pour toute réclamation intervenant pendant la
période de garantie, retournez ou rapportez
l’appareil ainsi que l’attestation de garantie à
votre revendeur ou à un Centre Service Agréé
Braun.
Appelez au 01.47.48.70.00 pour connaître le
Centre Service Agréé Braun le plus proche de
chez vous.
Clause spéciale pour la France
Outre la garantie contractuelle exposée ci-
dessus, nos clients bénéficient de la garantie
légale des vices cachés prévue aux articles
1641 et suivants du Code civil.
5722459_5691_MN Seite 47 Mittwoch, 18. August 2004 2:54 14
